G-Lite Luxury PP-8600 User manual

1
PP-8600
Energy Board
Luxury series
USER'S MANUAL

2
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the ENERGY BOARD.
1. It is the responsibility of the owner to ensure
that all users of this ENERGY BOARD are
adequately informed of all warnings
and precautions.
2. Use the ENERGY BOARD only as described
in this manual.
3. Place the ENERGY BOARD on a level surface,
with at least eight feet of clearance behind it.
Do not place the ENERGY BOARD on any surface
that blocks air openings.
To protect the floor or carpet from damage,
place a mat under the ENERGY BOARD.
4. Keep the ENERGY BOARD indoors,
away from moisture and dust. Do not put
the ENERGY BOARD in a garage or covered
patio, or near water.
5. Do not operate the ENERGY BOARD where
Aerosol products are used or where oxygen
is being administered.
6. Keep children under the age of 12 and pets
away from the ENERGY BOARD at all times.
7. The ENERGY BOARD should not be used
by persons weighing more than 300 pounds.
8. Never allow more than one person on the
ENERGY BOARD at a time.
9. When connecting the power cord ,
plug the power cord into a surge suppressor
(not included). Do not use an extension cord.
10. Keep the power cord and the surge suppressor
away from heated surfaces.
11. Never leave the ENERGY BOARD unattended
while it is running. Always remove unplug the power
cord when the ENERGY BOARD is not in use.
12. Do not attempt to raise, lower, or move the
ENERGY BOARD until it is properly assembled.
13. Inspect and tighten all parts of the ENERGY BOARD
regularly. Wrong usage could influence the stability of
the ENERGY BOARD. For Example, the post is made to
support you during an exercise to keep you in balance.
One should NOT PUSH the post for stretching or use
the post to create more tension.
14.Inspect and tighten all parts of the ENERGY BOARD
regularly.
15. Never insert or drop any object into any
opening.
16.DANGER: Always unplug the power
cord immediately after use, before cleaning
the ENERGY BOARD, and before performing the
maintenance and adjustment procedures described
in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized service
representative only.
17. This ENERGY BOARD is intended for in-home use
only. Do not use this ENERGY BOARD in any
commercial, rental, or institutional setting.
WARNING: Before beginning this or any exercise program, consult your physician. This is especially
important for persons over the age of 35 or persons with pre-existing health problems. Read all instructions
before using. SAVE THESE INSTRUCTIONS

3
Handlebar
Display Panel
BodyFat sensor
Main support tube
Power cord
ENERGY BOARD plate
Motorcase
Adjustablefootpad
BEFORE YOU BEGIN
Thank you for selecting the revolutionary PP-8600
ENERGY BOARD. The PP-8600 offers an impressive array
of features to make your home workouts more enjoyable
and effective.
For your benefit, read this manual carefully before
using the ENERGY BOARD. If you have additional
questions,please call our Customer Service Department To
help us assist you, please note the product model
number and serial number before calling. The model
number of the ENERGY BOARD is PP-8600. The serial
number can be found on a decal attached to the ENERGY
BOARD Before reading further, please familiarize yourself
with the parts that are labeled in the drawing below.
`
`
LEFT SIDE
RIGHT SIDE

4
1
3
4
5
6
11
12
7
8
9
10
ITEM PARTS Qty
1
1
1
1
1
2
4
4
4
4
4
Vibrator
Left Handle
Handle Cover
Connectors from Main Tube L1
PowerPlugL2M 
Pulse Detector L2
Bolt M8 15
Bolt M8 50
Washer 17 8.0 1.5T
Spring Washer 14 8.0 3.0T
Washer 17 8 1.5T(R30)
1
2
Display Connectors L1 L2 L3
EXPLODED DRAWING Model No. PP-8600
Right Handle 
Main Tube 
Bottom Tube Connector L4  
Vibrator Connector L4 
Foot
Pulse Detector L3

Washer 12 5 1.0T 
Plug for wiring hole 13 12 
Spring Washer 9 5 1.5T 
Display Meter 
Philips Screws M5 15 
15
16
17
18
19
23
20
21
22
ITEM PARTS Qty
1
1
1
1
1
1
1
4
4
4
4
13
14

5
ASSEMBLY
Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench
Unpacking your ENERGY BOARD where will be using it. Being careful
Not to damage . Place your ENERGY BOARD on a level flat surface.
It is recommended that you place a protective covering
on your floor.
STEP 1 . Mount the stand tube onto the main unit,
connect the down- lead from the both parts.
See Figure 1 .
STEP 2 Attach the main tube to the vibrator
with bolts and washers provide.
STEP 3:Insert the parts of handle bar together,
Positioning by the 4 holes.
STEP 4:Put washers and bolts into their
correspondent holes and then fix them
with a spanner or wrench.

6
STEP 5 : .
Screw the handle bar to the stand tube tightly,
Pull out the endcap (23) for the wiring hole
on the rear of the stand tube (19)
STEP 6
Fix the hand-pulse wire (8)Ε(16) to the endcap for wiring
hole, make it enter through the wiring hole on the rear of st-
and tube, make the terminals of the wire be out of the stand
tube then mount the endcap to the corresponding holes on
the stand tube.
STEP 7:
Connect the down-leads of the computer to that of stand
tube and the hand-pulse down-lead of the handle bar.
STEP 8:
Mount the computer (13) onto the stand tube and screw
hem together with flat washer(14),
spring washer(15) and bolt(18).
STEP 9:
Mount the ornament cover to the back of the handle tube,
Insert the power cord to the plug on the rear of the main
unit, then you can enjoy the ENERGY BOARD.
Make sure that all parts are tightened before you use the Energy Board.
To protect the floor or carpet from damage, place a mat under the Energy
Board.

Training hints
With buying this training item you have done the first step for healthy fitness. With the help of this item you can exercise your
muscles at home every time you feel like.
Further is the exercise good for your health as the training is also good for your endurance.
Goal of training:
Building of muscles
General fitness
Endurance
Better feeling
The training success is mainly depending on the following points.
Continuous training
Good nourishment
Control of training progress
Who can exercise?
Generally every healthy person, young or old, can start to exercise.
Capacity:
The body, especially the heard and the circulation, need time to adapt to the new circumstances.
Because of this reason it is really important to start really slowly with the training and to make brakes between and after the
training. Only exercise on a training level where you don’t reach your limit.
Start to exercise in a tempo that you feel comfortable with. After continuous training you can extend your training or adjust the
item to a higher level.
Important:
Start your exercise slowly and increase intensity of exercises gradually. You have a lot of time as you do your exercise at
home. You have to do some warm–up without item before training.
Start and end your training with a little expenditure or energy. After training you should also do some stretching.
Tips for a successful and healthy training:
·Always remember that the training with your item can be really helpful for your health if you follow the important rules. It is
not helpful to do some exercises in a short time, but in long-term and continuously.
·Please wear comfortable clothe, we propose to wear sporting cloth.
·Never exercise with a full stomach. Do not have a meal about one hour before and after the training.
·Do not exercise if you are already tired or feel exhausted.
·Always remember that your body needs enough liquid if you exercise.
You should follow this necessity.
7

8
Training:
Warming up should generally be done with every sportive activity. All physical and psychically components will be stimulated
and increased; further the risk or injury will be decreased. With the following exercises you will warm up the muscle groups,
this succeed the best by moving.
Run for about 5-10 minutes calmly on one place or through the room. You can jump in between a couple of times.
Stretching:
Following exercises are light but appropriate movements, which will wake up your body, stimulate your circulation and make
your ankles more flexible.
Please do these warming up exercises more than once before starting your training.
SUGGESTED STRETCHES
The correct form for several basic stretches is shown at the right. Move slowly as you
stretch—never bounce.
1. Toe Touch Stretch
Stand with your knees bent slightly and slowly bend forward
from your hips. Allow your back and shoulders to relax as you
reach down toward your toes as far as possible. Hold for 15
counts, then relax. Repeat 3 times. Stretches: Hamstrings,
back of knees and back.
2. Hamstring Stretch
Sit with one leg extended. Bring the sole of the opposite foot
toward you and rest it against the inner thigh of your extended
leg. Reach toward your toes as far as possible. Hold for 15
counts, then relax. Repeat 3 times for each leg. Stretches:
Hamstrings, lower back and groin.
3. Calf/Achilles Stretch
With one leg in front of the other, reach forward and place your
hands against a wall. Keep your back leg straight and your
back foot flat on the floor. Bend your front leg, lean forward and
move your hips toward the wall. Hold for 15 counts, then relax.
Repeat 3 times for each leg. To cause further stretching of the
achilles tendons, bend your back leg as well. Stretches:
Calves, achilles tendons and ankles.
4. Quadriceps Stretch
With one hand against a wall for balance, reach back and
grasp one foot with your other hand. Bring your heel as close
to your buttocks as possible. Hold for 15 counts, then relax.
Repeat 3 times for each leg. Stretches: Quadriceps and hip muscles.
5. Inner Thigh Stretch
Sit with the soles of your feet together and your knees outward .Pull your feet toward your groin area as far as possible. Hold
for 15 counts, then relax. Repeat 3 times. Stretches: Quadriceps and hip muscles.

9
Display Meter – Function Introduction:
Take care that nobody can stumble over any cables.
Keep the “Energy Board” at place which children can not reach.
Turning on:
1. Connect the electricity supply into the outlet with 230V.
2. Turn the Power Button(ON) .LED lighted.
3. Now you have different possibilities to adjust item.
Display Meter Operation
Κ
1. OFF – Press this button to stop it.
2. ON – Press this button to start working.
3. Set up your work-out time: Before you start, you can press ENTER to set up
your preferred workout time. When you see “00” flashing on
the display TIMER, you can press +(UP) to increase
or –(DOWN) to set up the timer, from 1 to 10 minutes.
Default workout period is 10 minutes.
4. Set up speed range: After you start working on it, you can adjust the
speed range by pressing + (UP) to increase or – (DOWN)
to select a right speed range to fit your needs. Speed range:
0~30.

10
5. Set up programs: Before you start workout, you can choose one of
the built-in programs by pressing the button PROGRAM:
You can see programs in sequences .“ 88-P1-P2-P3-FA”.
A. “88” is a manual mode. After pressing ON, you can choose different speed ranges
by pressing + (UP) or – (DOWN). “
B. P1~P3” are built-in automatic programs. You can choose P1~P3 and simply
press the button ON to enjoy a 10-minute workout.
C. “FA” program allows you to check body fat. Select “FA” programÆPress
button ONÆinput your gender (use buttons +/- to select a right entry, 1 for male,
2 for female)ÆPress ENTERÆinput your ageÆPress ENTERÆinput your
heightÆPress ENTERÆinput your weightÆPress ENTERÆYou see “- - - “ on the
main displayÆPut both hands on the handle bars and the display will show your
BMI (Body Mass Index) figure in about 5 seconds.
The figure is just for your reference, not for medical check-ups.
See the display results:
Gender Results Displayed on FAT/PULSE/SPEED
Female 17 and less 17-27 More than 27
Male 14 and less 14-23 More than 23
Meanings You are slim Perfect Figure Need more workout
SPEED
TIME ( 2 Mins Per Section)

11
Operation Manual
2. Stand on the plate, hold the handlebar and bend
your knees.
Mainly train the part of back, hips and legs.
1. Put one foot on the plate, another on ground and
hold on the handlebar.
Mainly train the part of waists, stomach muscles
and legs.
3. Stand on one side and balance body on your toes.
Knee only slightly bended.
Stomach muscles flexed.
4. Stand at Ease and put one hand on the handlebar.
This will train your back, arm and whole body muscles.

12
5. Put your hands on the plate and squat next to the
machine.
Mainly train the part of legs muscles, hands and
shoulder.
6. Sit on the plate, fold your legs and hands hold
on the handlebar.
Mainly train the part of legs muscles, shoulder,
waists muscles and stomach.
7. L Shape
Sit on one side of the plate and balance your body
with your hands hold on the handlebar.
This will train your arm, hip and thigh muscles.
8. Massage your legs
Put your legs on the plate and your hands on the ground
to support your body.
This will train your leg, arm and stomach muscles.

13
10. Stand on
Simply stand on the plate with your hands
on the handle bars.
This will train your whole body muscles.
9. Sit on Chair
Sit on a chair with your feet on the plate.
This will train your leg and stomach
muscles.
