Gaggenau CV 282 User manual

en Instruction manual
CV 282
Flex induction cooktop with integrated ventilation system

2
:
,(&
:

: :
:







3
en
Table of contents
en Instruction manual
Intended use 4
( Important safety information 5
Causes of damage 8
Environmental protection 8
Saving energy 8
Environmentally-friendly disposal 8
f Induction cooking 9
Advantages of induction cooking 9
Cookware 9
* Getting to know your appliance 11
Your new appliance 11
Special accessories 11
The control panel 12
Residual heat indicator 13
Operating modes 13
Before using the appliance for the first time 13
Initial use 13
j Twist-Pad with Twist knob 14
Removing the twist knob 14
Storing the twist knob 14
1 Operating the appliance 14
Switching the hob on and off 14
Setting a hotplate 14
Switching the ventilation system on and off 15
Intensive setting 16
Automatic start 16
Automatic mode with sensor control 16
Run-on function 16
Interval ventilation 17
Chef's recommendations 17
Flex function 20
Advice on using cookware 20
As two independent hotplates 20
As a single hotplate 20
Transfer function 21
Professional chef function 22
Activation 22
Deactivating 22
Changing the settings 22
Timer functions 23
Cooking timer 23
The short-term timer 23
Stopwatch function 24
Saucepan booster function 24
Activating 24
Deactivating 24
Frying pan booster function 25
Recommendations for use 25
Activating 25
Deactivating 25
z Keep warm function 25
Activating 25
Deactivating 25
Automatic functions 26
Types of automatic functions 26
Suitable cookware 27
Sensors and special accessories 27
Functions and heat settings 27
Recommended dishes 31
Preparation and maintenance of the wireless
temperature sensor 35
Declaration of Conformity 37
A Childproof lock 37
Activating and deactivating the childproof lock 37
Display cleaning protection 37
b Automatic safety cut-out 37
Q Basic settings 38
To access the basic settings: 39
Cookware test 40
D Cleaning 40
Cleaning agents 40
Components to clean 41
Hob surround (only on appliances with hob surrounds)
42
Hob 42
Ventilation system 42
Cleaning the overflow container 45
Twist knob 45
Wireless temperature sensor 45

4
en Intended use
{ Frequently Asked Questions (FAQ) 46
Trouble shooting 47
4 Customer service 49
Additional information on products, accessories,
replacement parts and services can be found at
www.gaggenau.com and in the online shop
www.gaggenau.com/zz/store
Intended use
Intendeduse Read these instructions carefully. Only then will
you be able to operate your appliance safely
and correctly. Retain the instruction manual
and installation instructions for future use or for
subsequent owners.
Check the appliance after removing it from the
packaging. If it has suffered any damage in
transport, do not connect the appliance,
contact the Technical Assistance Service and
provide written notification of the damage
caused, otherwise you will lose your right to
any type of compensation.
This appliance must be installed according to
the installation instructions included.
This appliance is intended for private domestic
use and the household environment only. The
appliance must only be used for the
preparation of food and beverages. The
cooking process must be supervised. A short
cooking process must be supervised without
interruption. Only use the appliance in
enclosed spaces.
This appliance is intended for use up to a
maximum height of 2000 metres above sea
level.
Do not use covers. These can cause accidents,
for example due to overheating, catching fire or
materials shattering.
Only use safety devices or child protection
grilles approved by ourselves. Unsuitable
safety devices or child protection grilles may
result in accidents.
This appliance is not intended for operation
with an external clock timer or a remote control.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are supervised
or are instructed by a person responsible for
their safety how to use the appliance safely and
have understood the associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at a
safe distance from the appliance and power
cable.
When using the cooking functions, set the
hotplate on which you have placed the
saucepan with the temperature sensor.
We advise that you exercise caution using or
standing near an induction hob while it is in
operation, if you wear a pacemaker or a similar
medical device. Consult your doctor or the
device manufacturer concenring its conformity
or any possible incompatibilities,

5
Important safety information en
m ( Important safety
information
Importantsafetyinformation The appliance can only be used safely if it is
correctly installed according to the safety
instructions. The installer is responsible for
ensuring that the appliance works perfectly at
its installation location.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
Dangerous or explosive materials and vapours
must not be extracted.
Ensure that no small parts or liquids get into
the appliance.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
This appliance is not intended for operation
with an external clock timer or a remote control.
mWarning – Danger of suffocation!
Packaging material is dangerous to children.
Never allow children to play with packaging
material.
mWarning – Danger of death!
Risk of poisoning from flue gases that are
drawn back in.
Always ensure adequate fresh air in the room if
the appliance is being operated in exhaust air
mode at the same time as room air-dependent
heat-producing appliance is being operated.
Room air-dependent heat-producing
appliances (e.g. gas, oil, wood or coal-operated
heaters, continuous flow heaters or water
heaters) obtain combustion air from the room
in which they are installed and discharge the
exhaust gases into the open air through an
exhaust gas system (e.g. a chimney).
In combination with an activated vapour
extractor hood, room air is extracted from the
kitchen and neighbouring rooms - a partial
vacuum is produced if not enough fresh air is
supplied. Toxic gases from the chimney or the
extraction shaft are sucked back into the living
space.
▯Adequate incoming air must therefore
always be ensured.
▯An incoming/exhaust air wall box alone will
not ensure compliance with the limit.
Safe operation is possible only when the partial
vacuum in the place where the heat-producing
appliance is installed does not exceed 4 Pa
(0.04 mbar). This can be achieved when the air
needed for combustion is able to enter through
openings that cannot be sealed, for example in
doors, windows, incoming/exhaust air wall
boxes or by other technical means.
In any case, consult your responsible Master
Chimney Sweep. He is able to assess the
house's entire ventilation setup and will
suggest the suitable ventilation measures to
you.
Unrestricted operation is possible if the vapour
extractor hood is operated exclusively in the
circulating-air mode.

6
en Important safety information
mWarning – Risk of fire!
▯Hot oil and fat can ignite very quickly. Never
leave hot fat or oil unattended. Never use
water to put out burning oil or fat. Switch
off the hotplate. Extinguish flames carefully
using a lid, fire blanket or something
similar.
Risk of fire!
▯The hotplates become very hot. Never
place combustible items on the hob. Never
place objects on the hob.
Risk of fire!
▯The appliance gets hot. Do not keep
combustible objects or aerosol cans in
drawers directly underneath the hob.
Risk of fire!
▯The hob switches off automatically and can
no longer be operated. It may switch on
unintentionally at a later point. Switch off
the circuit breaker in the fuse box. Contact
the after-sales service.
Risk of fire!
▯Grease deposits in the grease filter may
catch fire.
Clean the grease filter at least once a
month.
Never operate the appliance without the
grease filter.
Risk of fire!
▯Fatty deposits in the filters may catch fire.
Clean the appliance as described.
Comply with the cleaning intervals. Never
operate the appliance without the grease
filter.
Risk of fire!
▯Grease deposits in the grease filter may
catch fire. Never work with naked flames
close to the appliance (e.g. flambéing). Do
not install the appliance near a heat-
producing appliance for solid fuel (e.g.
wood or coal) unless a closed, non-
removable cover is available. There must be
no flying sparks.
mWarning – Risk of burns!
▯The hotplates and surrounding area
(particularly the hob surround, if fitted)
become very hot. Never touch the hot
surfaces. Keep children at a safe distance.
Risk of burns!
▯The hotplate heats up but the display does
not work. Switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of burns!
▯Metal objects on the hob quickly become
very hot. Never place metal objects (such
as knives, forks, spoons and lids) on the
hob.
Risk of burns!
▯The filter cover made from cast iron is very
hot on the hob. Never place the filter cover
on the hob. Do not place pots, pans or
other hot objects on the filter cover.
Risk of fire!!
▯After each use, always turn off the hob at
the main switch. Do not wait until the hob
turns off automatically after the pan is
removed.
Risk of burns!
▯The accessible parts become very hot
when in operation. Never touch hot parts.
Keep children at a safe distance.
Risk of burns!
▯The appliance will become hot during
operation. If hot liquids penetrate the
appliance, leave the appliance to cool for at
least two hours before removing the filter
cover, the metal grease filter, the container,
the overflow reservoir or the appliance
housing.

7
Important safety information en
mWarning – Risk of electric shock!
▯Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the
appliance from the mains or switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
Risk of electric shock!
▯Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
▯A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Risk of electric shock!
▯Cracks or fractures in the glass ceramic
may cause electric shocks. Switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
mWarning – Electromagnetic hazards!
▯This appliance complies with safety and
electromagnetic compatibility standards.
However, people with pacemakers or
insulin pumps must refrain from using this
appliance. It is impossible to ensure that all
of these devices available on the market
comply with current electromagnetic
compatibility standards, and that
interference which may prevent the device
from working correctly will not occur. It is
also possible that people with other types
of devices, such as a hearing aids, could
experience some discomfort.
Hazard due to magnetism!
▯The wireless temperature sensor and the
twist knob are magnetic. The magnetic
elements may damage electronic implants,
e.g. pacemakers or insulin pumps. People
fitted with electronic implants should
therefore not carry the temperature sensor
or the twist knob in their pocket and always
keep these items at least 10 cm away from
their pacemaker or similar medical device.
mWarning – Risk of injury!
▯When cooking in a bain marie, the hob and
cooking container could shatter due to
overheating. The cooking container in the
bain marie must not directly touch the
bottom of the water-filled pot. Only use
heat-resistant cookware.
Risk of injury!
▯Saucepans may suddenly jump due to
liquid between the pan base and the
hotplate. Always keep the hotplate and
saucepan bases dry.
Risk of injury!
▯Components inside the appliance may have
sharp edges. Wear protective gloves.
Risk of injury!
▯Cookware and cooktops become very hot.
Never reach across the hot cooktop or take
hold of hot cookware.
Risk of injury!
▯The battery in the wireless temperature
sensor may become damaged or explode if
it gets too hot. Remove the sensor from the
hob after cooking and do not store it near
sources of heat.
Risk of injury!
▯The temperature sensor may be very hot
when removing it from the saucepan. Wear
oven gloves or use a tea towel to remove it.
Risk of injury!
▯Unsuitable woks may cause accidents.
Only use woks supplied by the
manufacturer (available as optional
accessories).
mWarning – Malfunction risk!
The hob is equipped with a fan in the lower
section. If there is a drawer under the hob it
should not be used to store small objects or
paper, since they could damage the fan or
interfere with the cooling if they are sucked into
it.
There should be a minimum of 2 cm between
the contents of the drawer and fan intake.

8
en Causes of damage
Causes of damage
Causesofdamage Caution!
– Objects that are hard or sharp may damage the hob.
Do not allow hard or sharp objects to fall on the
hob.
– Heating cookware when empty may cause surface
damage. Never leave empty cookware on the heat.
– Hot pots or pans may damage the hob. Never place
hot pots or pans on the control panel, the displays/
indicators, the hob surround or the filter cover.
– Never leave aluminium foil or plastic containers on
hot hotplates as this may damage the hob. No not
use oven liners.
– Using unsuitable cleaning products may cause
surface damage, discolouration and stains. Only
use cleaning products that are suitable for this type
of hob.
– Friction from pots and pans may cause surface
damage and discolouration. Always lift pots and
pans up before repositioning them; do not slide
them across the surface of the hob.
– Burnt-on food may cause surface damage and
staining. Immediately remove any food that has
boiled over using a glass scraper.
– Salt, sugar and sand may cause surface damage.
Do not use the hob as a work surface or storage
space.
– Using cookware with a rough base may cause
surface damage. Check all cookware before use.
– Sugar and foods with a high sugar content may
cause surface damage or conchoidal fracturing.
Immediately remove any food that has boiled over
using a glass scraper.
Environmental protection
Environmentalprotection In this section, you can find information about saving
energy and disposing of the appliance.
Saving energy
▯Always place suitable lids on saucepans. Cooking
without a lid consumes significantly more energy.
Use a glass lid so that you can see into the pan
without having to lift the lid.
▯Use pots and pans with flat bases. Uneven bases
increase the energy consumption.
▯The base diameter of pots and pans should be the
same size as the hotplate. Please note: Cookware
manufacturers often specify the diameter of the top
of the saucepan, which is usually larger than the
diameter of the base of the saucepan.
▯Use small saucepans for small quantities. Using a
large saucepan with little in it consumes a lot of
energy.
▯Cook with only a little water. This will save energy
and preserve the vitamins and minerals in
vegetables.
▯Switch back to a lower heat setting in good time.
This will save energy.
▯During cooking, ensure that there is a sufficient
supply of air to enable the ventilation system to
work efficiently and with a low level of operating
noise.
▯Adjust the fan speed to the amount of steam
produced during cooking. Only use intensive mode
when required. The lower the fan speed, the less
energy is consumed.
▯If cooking produces large amounts of steam, select
a higher fan speed in good time. If the cooking
steam has already spread around the kitchen, the
ventilation system will need to be operated for
longer.
▯Switch the appliance off when you are not using it.
▯Clean and (if required) replace the filter at regular
intervals in order to increase the effectiveness of
the ventilation system and to prevent the risk of fire.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
The wireless temperature sensor is battery-powered.
Dispose of used batteries in an environmentally
responsible manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.

9
Induction cooking en
f Induction cooking
Inductioncooking Advantages of induction cooking
Induction cooking is very different from traditional
cooking methods, as heat builds up directly in the item
of cookware. This offers numerous advantages:
▯Saves time when boiling and frying.
▯Saves energy.
▯Easier to care for and clean. Spilled food does not
burn on as quickly.
▯Heat control and safety – the hob increases or
decreases the heat supply as soon as the user
changes the setting. The induction hotplate stops
the heat supply as soon as the cookware is removed
from the hotplate, without having to switch it off
first.
Cookware
Only use ferromagnetic cookware for induction cooking,
such as:
▯Cookware made from enamelled steel
▯Cookware made from cast iron
▯Special induction-compatible cookware made from
stainless steel.
To check whether your cookware is suitable for
induction cooking, refer to the section entitled ~"Flex
function".
To achieve a good cooking result, the ferromagnetic
area on the base of the pan should match the size of the
hotplate. If a hotplate does not detect an item of
cookware, try placing it on another hotplate with a
smaller diameter.
If the flexible cooking zone is being used as a single
hotplate, larger items of cookware can be used as these
are particularly suited to this area. You can find
information on positioning cookware in the section
entitled ~"~"Basic settings" on page 38"
on page 13.
Some induction cookware does not have a fully
ferromagnetic base:
▯If the base of the cookware is only partially
ferromagnetic, only the area that is ferromagnetic
will heat up. This may mean that heat will not be
distributed evenly. The non-ferromagnetic area may
not heat up to a sufficient temperature for cooking.
▯The ferromagnetic area will also be reduced if the
material from which the base of the cookware is
made contains aluminium, for example. This may
mean that the cookware will not become sufficiently
hot or even that it will not be detected.
Unsuitable pans
Never use diffuser hobs or pans made from:
▯common thin steel
▯glass
▯earthenware
▯copper
▯aluminium
Properties of the base of the cookware
The material(s) from which the base of the cookware is
made can affect the cooking result. Using pots and pans
made from materials that distribute heat evenly through
them, such as stainless-steel pans with a three-layer
base, saves time and energy.
Use cookware with a flat base; if the base of the
cookware is uneven, this may impair the heat supply.
Absence of pan or unsuitable size
If no pan is placed on the selected hotplate, or if it is
made of unsuitable material or is not the correct size,
the power level displayed on the hotplate indicator will
flash. Place a suitable pan on the hotplate to stop the
flashing. If this takes more than 90 seconds, the
hotplate will switch off automatically.
FP FP
FP

10
en Induction cooking
Empty pans or those with a thin base
Do not heat empty pans, nor use pans with a thin base.
The hob is equipped with an internal safety system.
However, an empty pan may heat up so quickly that the
"automatic switch off" function may not have time to
react and the pan may reach very high temperatures.
The base of the pan could melt and damage the glass on
the hob. In this case, do not touch the pan and switch
the hotplate off. If it fails to work after it has cooled
down, please contact the Technical Assistance Service.
Pan detection
Each hotplate has a lower limit for pan detection. This
depends on the diameter of the ferromagnetic area of
the cookware and the material from which its base is
made. For this reason, you should always use the
hotplate that best matches the diameter of the base of
the pan.

11
Getting to know your appliance en
* Getting to know your appliance
Gettingtoknowyourappliance You can find information on the dimensions and power
of the hotplates in~Page 2
In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Your new appliance
Special accessories
Suitable cookware
There are pans that are optimally suited for the frying
sensor function. They can be purchased from specialist
retailers or through our technical after-sales service.
Always quote the relevant reference number.











No. Name
1 Filter cover
2 Metal grease filter
3 Container
4 Hob
5 Control panel
6 Fan housing
7 Overflow container
8 Housing cover
9 Piping*
10 Activated charcoal filter*
11 Exhaust pipe**
* in air recirculation mode only
** in air extraction mode only
Temperature sensor CA 060 300
Flat duct connection piece CA 284 010
Air recirculation module CA 282 810
Activated charcoal filter CA 282 110
Magnetic knob, black CA 230 100
Multilayer teppanyaki griddle pan CA 051 300
Cast aluminium grill plate CA 052 300
Small pan – 15 cm diameter GP 900001
Medium pan – 18 cm diameter GP 900002
Large pan – 21 cm diameter GP 900003

12
en Getting to know your appliance
The control panel
Touch keys
When the hob heats up, the symbols for the touch keys
available at this time light up.
Touching a symbol activates the associated function. A
confirmation signal sounds.
Notes
– The corresponding symbols for the touch keys light
up depending on whether they are available.
The indicators for the available functions light up in
white. Once a function is selected, its indicator
lights up in orange.
– Always keep the control panel clean and dry.
Moisture can prevent it from working properly.
– Do not pull cookware close to the displays and
sensors. The electronics could overheat.
Touch keys
ÿSwitch the appliance on and off
¨Switch on the cooking sensor function
ÚSwitch on the frying sensor function
6Set the cooking timer
ŽActivate the saucepan booster function
©Activate the frying pan booster function
£Activate the keep-warm function
ªActivate the flex function
tOpen the basic settings
¬Activate the professional chef function
}Switch between the settings area for the hob
and the ventilation system/set the ventilation
level/switch on intensive mode, automatic
start and the intermittent function for the ven-
tilation system
®Switch on the stopwatch
ŠSet the timer
Indicators/symbols
‹Operating status
v x
uy
Hotplate
‚-ŠHeat settings/fan settings
¨Cooking sensor function
ÚFrying sensor function
6Cooking timer
˜Saucepan booster function/intensive
mode for ventilation
›Frying pan booster function
–Keep-warm function
•/œResidual heat
‹‹ Timer function
‹‹.‹‹ Stopwatch function
šDisplay cleaning protection
HChildproof lock
ªFlex function activated
«Flex function deactivated
ˆTransfer function
}Ventilation system switched on
»Ventilation system intermittent function
‘Ventilation system automatic mode
¥Ventilation system run-on function
”‚¯†“ ¥£ Metal grease filter not inserted correctly
”’•‘¯®“ Activated charcoal filter saturation indica-
tor
””—–– Metal grease filter saturation indicator
Indicators/symbols

13
Before using the appliance for the first time en
Residual heat indicator
The hob has a residual heat indicator for each hotplate.
This indicates that a hotplate is still hot. Do not touch a
hotplate while the residual heat indicator is lit up.
The following indicators are shown depending on the
amount of residual heat:
▯Display •: High temperature
▯Display œ: Low temperature
If you remove the cookware from the hotplate during
cooking, the residual heat indicator and the selected
heat setting will flash alternately.
When the hotplate is switched off, the residual heat
indicator will light up. Even after the hob has been
switched off, the residual heat indicator will stay lit for
as long as the hotplate is still warm.
Operating modes
This appliance can be used in exhaust-air mode or
circulating-air mode.
Exhaust air mode
Note: The exhaust air must not be conveyed into a
functioning smoke or exhaust gas flue or into a shaft
which is used to ventilate installation rooms which
contain heat-producing appliances.
▯Before conveying the exhaust air into a non-
functioning smoke or exhaust gas flue, obtain the
consent of the heating engineer responsible.
▯If the exhaust air is conveyed through the outer wall,
a telescopic wall box should be used.
Circulating-air mode
Note: To bind odours in circulating-air mode, you must
install an activated carbon filter. The different options
for operating the appliance in circulating-air mode can
be found in the brochure. Alternatively, ask your dealer.
The required accessories are available from specialist
outlets, from customer service or from the Online Shop.
Before using the appliance for the
first time
Beforeusingtheapplianceforthefirsttime Please read the following information before using the
appliance for the first time:
Clean the appliance and all accessory parts thoroughly.
Before you can use your new appliance, you must apply
certain settings.
Initial use
Note: When it is delivered, the appliance is preset to air
recirculation mode.
Possible settings:
▯In air recirculation mode, if ’Š is displayed, the
value ‹(factory setting) is set.
▯In air extraction mode, if ’Š is displayed, the value
‚is set.
To switch the appliance to air extraction mode, see
~"Basic settings" on page 38.
The air which is drawn in is cleaned
by the grease filters and conveyed to
the exterior by a pipe system.
The air which is drawn in is cleaned by the
grease filters and an activated carbon filter
and conveyed back into the kitchen.

14
en Twist-Pad with Twist knob
j Twist-Pad with Twist knob
Twist-PadwithTwistknob The twistpad is the control panel where you can use the
twist knob to select the hotplates and heat settings.
The twist knob is magnetic and is placed in the middle
of the area marked on the twistpad. To activate a
hotplate, press the twist knob so that it tilts in the
appropriate area for the required hotplate. Turning the
twist knob selects the heat setting.
Position the twist knob on the twist pad so that it is in
the centre of the indicators which delimit the twist pad
area.
Note: Even if the twist knob is not entirely central, this
will not affect how the twist knob works.
Removing the twist knob
Removing the twist knob activates the wipe protection
function.
The twist knob can be removed during cooking. The
wipe protection function is activated for 10 minutes. If
the twist knob is not returned to its position before this
time elapses, the hob will switch off.
mWarning – Risk of fire!
If a metallic object is placed in the twist pad area during
these 10 minutes, the hob may continue to heat up. For
this reason, always switch off the hob using the main
switch.
Storing the twist knob
A strong magnet is located inside of the twist knob.
Keep the twist knob away from magnetic data carriers
such as credit cards and cards with magnetic strips.
Otherwise, these data carriers may be damaged beyond
repair.
The magnet may also cause faults on televisions and
screens.
Note: The twist knob is magnetic. Metal particles stuck
to the bottom may scratch the surface of the hob.
Always clean the twist knob thoroughly.
1 Operating the appliance
Operatingtheappliance This chapter explains how to set a hotplate. The table
shows heat settings and cooking times for various
meals.
mWarning – Risk of burns!
The filter cover made from cast iron is very hot on the
hob. Never place the filter cover on the hob. Do not
place pots, pans or other hot objects on the filter cover.
Note: Switch on the ventilation system when you start
cooking and switch it off again a few minutes after you
have finished cooking. This is the most effective way of
removing steam from the kitchen.
Note: Never use the appliance without the container,
metal grease filter or filter cover.
Switching the hob on and off
Switch the hob on and off using the main switch.
To switch on: Position the twist knob on the control
panel. Touch the #symbol. The symbols for the
hotplates and the functions available at this time light
up. ‹lights up next to the hotplates. The hob is ready
for use.
To switch off: Touch the # symbol until the display
goes out. All hotplates are switched off. The residual
heat indicator remains lit until the hotplates have cooled
down sufficiently.
Notes
– The hob will switch itself off automatically if all the
hotplates have been switched off for more than 20
seconds and the ventilation system is switched off.
– The selected settings are stored for 5 seconds after
the hob has been switched off.
If the hob is switched back on during this time, the
heat settings that were previously set will flash. To
apply these settings, tap on the twist knob within
the next 5 seconds.
If you do not tap the twist knob or you touch a
different sensor button, all the previous settings will
be deleted.
Setting a hotplate
Set the required hotplate using the twist knob.
Heat setting 1 = lowest setting.
Heat setting 9 = highest setting.
Every heat setting has an intermediate setting. This is
shown in the hotplate display as .5.

15
Operating the appliance en
Selecting a hotplate and heat setting
The hob must be switched on.
1Select the hotplate. To do this, touch the twist knob
in the appropriate area for the required hotplate.
2Within the next 10 seconds, turn the twist knob until
the required heat setting appears in the heat setting
display.
The heat setting is set.
Notes
– When placing an item of cookware on the flexible
cooking zone, it must be positioned correctly
according to size; see the section entitled ~"Flex
function".
The cookware is detected and the hotplate is
selected automatically. You can now configure the
settings.
– If the indicators flash after you have changed the
settings, check whether the cookware is suitable for
induction cooking. See the section entitled
~"Cookware test".
Changing the heat setting
Select the hotplate and change the heat setting using
the twist knob.
Switching off the hotplate
Select the hotplate and turn the twist knob until ‹
appears. The hotplate switches itself off and the
residual heat indicator lights up.
Notes
– If there is no cookware on the induction hotplate,
the heat setting display flashes. After a while, the
hotplate will switch itself off.
– If there is cookware on the hotplate before
switching the hob on, this is detected at most 20
seconds after touching the main switch and the
hotplate is selected automatically. Set the heat
setting within the next 10 seconds. Otherwise the
hotplate will switch itself off again after 20
seconds.
Even if there are several pots and pans on the hob
when it is switched on, only one item of cookware is
detected.
Switching the ventilation system on
and off
Note: Always adjust the setting according to the current
conditions. To eliminate strong cooking smells, select a
high fan setting.
Note: If no metal grease filter is available, the
ventilation system cannot be switched on. Insert the
metal grease filter. The hob functions are also available
if there is no metal grease filter.~"Cleaning"
on page 40
Note: Using tall items of cookware may prevent the
extraction system from working at optimum power. The
extraction power can be improved by placing a lid on the
cookware at an angle.
Note: Do not obstruct the ventilation openings. Do not
place objects on the filter cover, as this will reduce the
power of the ventilation system.
Switching on the ventilation system
Note: If ”‚¯†“ ¥£ flashes on the display panel and
}symbol is not available, insert the metal grease filters
correctly.
}is shown on the display panel. The ventilation system
can be switched on.
1Touch the }symbol.
The }symbol will be lit orange. The ventilation
system will start at fan setting ƒ. The fan setting
that is selected will be shown on the display panel.
Notes
–Heat settings cannot be changed while the
ventilation system fan settings are being
configured.
–During a period of a few seconds, a fan setting
for the ventilation system can be selected. The
}symbol will be lit white when the Twist knob
can be used to configure the heat settings again.
2Use the twist knob to select the required setting.
The fan setting that is selected will be shown on the
display panel.
3To set a different fan setting, touch the }symbol
and use the twist knob to select the required
setting.
The fan setting that is selected will be shown on the
display panel.
ZZ
 

16
en Operating the appliance
Switching off the ventilation system
If you want to switch off the appliance, touch the
#symbol. If you only want to switch off the ventilation
system, proceed as follows:
1Touch the }symbol.
2Use the twist knob to select the fan setting ‹.
3Touch the }symbol to switch to the setting area
for the hob.
Note: If the run-on has been switched on, you can only
switch the ventilation system off via the twist knob.
~"Run-on function" on page 16
Intensive setting
Activate intensive mode if strong odours or large
amounts of steam are produced. In this mode, the
ventilation system briefly operates at maximum power. It
automatically switches back to a low setting after a
short time.
Switching on
1Touch the }symbol.
2Turn the rotary knob until ˜appears.
Intensive mode is now activated.
Note: After 6 minutes, the appliance will automatically
switch back to fan setting „.
Switching off
1Touch the }symbol.
2Use the twist knob to select the fan setting ‹.
3Touch the }symbol to switch to the setting area
for the hob.
Automatic start
Depending on the basic settings selected, the following
options will be available once you have selected the fan
setting for a cooking zone:
▯The ventilation system will not start.
▯The ventilation system will start at the fan setting
selected by the sensor.
▯The ventilation will start at a specified fan setting.
Select the option you want to use in the basic settings.
The basic settings also offer the option to adjust the
sensitivity of the sensor.
Automatic mode with sensor control
Switching on
1Touch the }symbol.
The ventilation starts with fan setting ƒ.
2Turn button to the right until ‘is displayed.
3Touch the }symbol.
The optimum setting is set automatically using a
sensor.
Switching off
1Touch the }symbol.
2Use the twist knob to select another fan setting or
turn it until ‹appears.
The fan setting that is selected will be shown on the
display panel. Automatic mode with sensor control
is switched off.
Run-on function
Note: The run-on function will only start if at least one of
the cooking zones has been switched on for at least a
minute.
The run-on function leaves the ventilation system
running for a few minutes after it has been switched off.
This eliminates any remaining cooking smells. The
ventilation system will switch off automatically
afterwards.
If the automatic function with sensor-controlled run-on is
activated in the basic settings, the run-on will stop
automatically when the appliance is switched off.
When the appliance is switched off or all of the cooking
zones are switched off, ¥will be shown on the display
panel. }will be lit white. The run-on function is now on.

17
Operating the appliance en
Switching off
1Touch the }symbol.
The }symbol will be lit orange.
2Use the twist knob to select the required fan
setting ‹.
3Touch the }symbol.
The run-on function will be switched off.
The run-on function will be switched off if the appliance
is switched on and one of the cooking zones is switched
back on.
Interval ventilation
Switching on
With interval ventilation, the ventilation switches on
automatically for 6 minutes every hour.
1Touch the }symbol.
2Turn the twist knob until »appears.
3Touch the }symbol.
The Intermittent function has now been activated.
Note: After power is turned off, »and }symbol light
up.
Switching off
1Touch the }symbol.
2Use the twist knob to select the fan setting ‹.
3Touch the }symbol to switch to the setting area
for the hob.
Intermittent ventilation has now been switched off.
Chef's recommendations
Recommendations
▯Stir occasionally when heating up purees, creamy
soups and thick sauces.
▯For preheating, select a heat setting 8 or 9.
▯When cooking with the lid on, turn the heat setting
down as soon as steam escapes between the lid
and the cookware.
▯After cooking, keep the lid on the cookware until
you serve the food.
▯To cook with the pressure cooker, follow the
manufacturer's instructions.
▯Do not cook food for too long, otherwise nutrients
will be lost. The kitchen timer can be used to set the
optimum cooking time.
▯For healthier cooking results, oils and fats should
not be heated to their smoke point.
▯To brown food, fry small portions in succession.
▯Cookware may reach high temperatures while the
food is cooking. We recommend that you use oven
gloves.
▯You can find recommendations for energy-efficient
cooking in the section entitled ~"Environmental
protection"

18
en Operating the appliance
Cooking table
The table shows which heat setting is suitable for each
type of food. The cooking time may vary depending on
the type, weight, thickness and quality of the food.
Heat
setting
Cooking
time (mins)
Melting
Chocolate coating 1 - 1.5 -
Butter, honey, gelatine 1 - 2 -
Heating and keeping warm
Stew, e.g. lentil stew 1.5 - 2 -
Milk* 1.5 - 2.5 -
Heating sausages in water* 3 - 4 -
Defrosting and heating
Spinach, frozen 3 - 4 15 - 25
Goulash, frozen 3 - 4 35 - 55
Poaching, simmering
Potato dumplings* 4.5 - 5.5 20 - 30
Fish* 4 - 5 10 - 15
White sauces, e.g. Béchamel sauce 1 - 2 3 - 6
Whisked sauces, e.g. sauce béarnaise, hollandaise 3 - 4 8 - 12
Boiling, steaming, braising
Rice (with double the volume of water) 2.5 - 3.5 15 - 30
Rice pudding*** 2 - 3 30 - 40
Unpeeled boiled potatoes 4.5 - 5.5 25 - 35
Boiled potatoes 4.5 - 5.5 15 - 30
Pasta, noodles* 6 - 7 6 - 10
Stew 3.5 - 4.5 120 - 180
Soups 3.5 - 4.5 15 - 60
Vegetables 2.5 - 3.5 10 - 20
Vegetables, frozen 3.5 - 4.5 7 - 20
Cooking in a pressure cooker 4.5 - 5.5 -
Braising
Roulades 4 - 5 50 - 65
Pot roast 4 - 5 60 - 100
Goulash*** 3 - 4 50 - 60
* Without lid
** Turn several times
*** Preheat to heat setting 8 - 8.5

19
Operating the appliance en
Roasting/frying with little oil*
Escalope, plain or breaded 6 - 7 6 - 10
Escalope, frozen 6 - 7 8 - 12
Chop, plain or breaded** 6 - 7 8 - 12
Steak (3 cm thick) 7 - 8 8 - 12
Poultry breast (2 cm thick)** 5 - 6 10 - 20
Poultry breast, frozen** 5 - 6 10 - 30
Rissoles (3 cm thick)** 4.5 - 5.5 20 - 30
Hamburgers (2 cm thick)** 6 - 7 10 - 20
Fish and fish fillet, plain 5 - 6 8 - 20
Fish and fish fillet, breaded 6 - 7 8 - 20
Fish, breaded and frozen, e.g. fish fingers 6 - 7 8 - 15
Scampi, prawns 7 - 8 4 - 10
Sautéeing fresh vegetables and mushrooms 7 - 8 10 - 20
Stir-fry, vegetables, meat cut in Asian-style strips 7 - 8 15 - 20
Stir fry, frozen 6 - 7 6 - 10
Pancakes (baked in succession) 6.5 - 7.5 -
Omelette (cooked in succession) 3.5 - 4.5 3 - 6
Fried eggs 5 - 6 3 - 6
Deep-fat frying* (150-200 g per portion in 1-2 l oil, deep-fat fried in portions)
Frozen products, e.g. chips, chicken nuggets 8 - 9 -
Croquettes, frozen 7 - 8 -
Meat, e.g. chicken portions 6 - 7 -
Fish, breaded or in beer batter 6 - 7 -
Vegetables, mushrooms, breaded or battered, tempura 6 - 7 -
Small baked items, e.g. doughnuts, fruit in batter 4 - 5 -
Heat
setting
Cooking
time (mins)
* Without lid
** Turn several times
*** Preheat to heat setting 8 - 8.5

20
en Flex function
Flex function
Flexfunction The flexible cooking zone can be used as a single
hotplate or as two independent hotplates, as required.
It consists of four inductors that work independently of
each other. If the flex function is in use, only the area
that is covered by cookware is activated.
Advice on using cookware
To ensure that the cookware is detected and heat is
distributed evenly, correctly centre the cookware:
As two independent hotplates
The flexible cooking zone is used like two independent
hotplates.
Activating
See the section entitled ~"Operating the appliance"
on page 14
As a single hotplate
Using the entire cooking zone by connecting both
hotplates.
Linking the two hotplates
1Set down the cookware. Select one of the two
hotplates in the flexible cooking zone and set the
heat setting.
2Touch the ªsymbol. The ªindicator lights up next
to the cooging zone display.
The flexible cooking zone has now been activated. The
heat setting appears in the two displays for the flexible
cooking zone.
Notes
– If both hotplates are set to different heat settings
before being linked, switch both hotplates to 0 on
activation.
– If there is a cooking timer programmed for one
hotplate, this will also be assigned to the second
hotplate when the two are linked.
Changing the heat setting
Select one of the two hotplates assigned to the flexible
cooking zone and set the heat setting using the twist
knob.
Adding new cookware
1Set down additional cookware in the appropriate
position according to size.
If correctly positioned, cookware is detected and
the hotplate is selected automatically; the
corresponding part of the display ªflashes.
2Use the twist knob to confirm the setting within
90 seconds. The indicators stop flashing and the
cookware is heated up.
Note: If the indicators continue to flash, check
whether the cookware is suitable for induction
cooking
Note: If the cookware is moved to the hotplate being
used or lifted up, the hotplate begins an automatic
search and the heat setting selected previously is
retained.
Unlinking the two hotplates
1Select one of the two hotplates assigned to the
flexible cooking zone.
2Touch the ªsymbol.
3The «symbol appears in the cooking zone display.
This deactivates the flexible cooking zone. The two
hotplates will now function independently.
Note: If the hob is switched off, and then switched back
on again later, the flexible cooking zone is reset to
function as two independent hotplates.
As a single hotplate
Diameter smaller than or equal to 13
cm
Place the cookware on one of the four
positions that can be seen in the illus-
tration.
Diameter greater than 13 cm
Place the cookware on one of the
three positions that can be seen in the
illustration.
If the cookware takes up more than
one hotplate, place it starting on the
upper or lower edge of the flexible
cooking zone.
As two independent hotplates
The front and rear hotplates each have two
inductors and can be used independently of
each other. Select the required heat setting
for each of the hotplates. Use only one item
of cookware on each hotplate.
