TOP
Mounting Bracket
For Outdoor Base Station Panel Antennas
DESCRIPTION:
This steel mounting bracket is suitable for all
Galtronics outdoor Base Station Panel antennas
4’ height and above, and can be assembled
onto poles ranging from 3” (76.2 mm) to
5”(127 mm).
Specifications
Model Number
MK-06807
Environmental
Conditions
Outdoor
Weight
14.0 lbs (6.36 Kg)
Dimensions
(LxHxW)
11.34” x 6.30” x 6.81”
(288.0mm x 160.0mm x
172.9mm)
Material
Galvanized Steel
Wind Speed
Resistance
150mph (240kmh)
Pole Diameter Range
”(.2mm) 
” (mm)
Mounting Style
Pole Mount
Mounting Hardware
to Antenna
Supplied with Bracket
Mounting Hardware
to Pole without Tilt
Supplied with Bracket
Mounting Hardware
to Pole with Tilt
Supplied with Bracket
Mounting Hardware
to Wall
Partially supplied with
Bracket
Down Tilt Range
0° to 10°
BOTTOM
COMPATIBLE ANTENNA MODELS* GALTRONICS 4’ and ABOVE WITH BASE STATION ANTENNAS

Copyright © 2019 –Galtronics Canada Ltd.
Proprietary Information. All rights reserved. Galtronics reserves the right to modify or amend any antenna or specification without prior notice.
Model No: MK-06807 | Mounting kit for outdoor Base Station Panel Antennas page 2 of 4
WWW.GALTRONICS.COM
MK-06807 Release Date: 19-SEP-2019; Revision: R2
Figure 1. TOP & SIDE View of TOP Mounting Bracket
Figure 2. TOP & SIDE View of BOTTOM Mounting Bracket
Table 1
Top Mounting Hardware to
Pole with Tilt
Item
QTY
DESCRIPTION
1
10
1/2” Flat
Washer
2
6
1/2”Split Lock
Washer
3
12
1/2” Hex Nut
4
4
1/2” – 13X1-
3/4” Hex Bolt
5
2
1/2” X 1.5 OD
Flat Washer
6
1
Top Mount
Bracket Index
7
1
Top Front Side
Bracket
8
1
Rear Side
Bracket
9
2
1/2” - 13X8”
Hex Bolt
Table 2
Mounting Hardware to Pole
without Tilt
Item
QTY
DESCRIPTION
1
2
1/2” X 13X8”
Hex Bolt
2
6
1/2” Flat
Washer
3
1
Bottom Front
Side Bracket
4
1
Rear Side
Bracket
5
4
1/2” Split
Lock Washer
6
4
1/2” Hex Nut

Copyright © 2019 –Galtronics Canada Ltd.
Proprietary Information. All rights reserved. Galtronics reserves the right to modify or amend any antenna or specification without prior notice.
Model No: MK-06807 | Mounting kit for outdoor Base Station Panel Antennas page 3 of 4
WWW.GALTRONICS.COM
MK-06807 Release Date: 19-SEP-2019; Revision: R2
Assembly instructions
Step 1 –Mounting Bracket TOP VIEW
Step 2 –Mounting Bracket SIDE VIEW
For pole mounting both top and bottom brackets are required
Step 3 –Mounting Antenna
Attach the antenna onto the pole mounted bracket using the 1/2 “- 13 X 1 - 3/4” hex head.
Apply a thread lubricant and tighten the Hex Nuts to proper torques (40 ft/lb).

Copyright © 2019 –Galtronics Canada Ltd.
Proprietary Information. All rights reserved. Galtronics reserves the right to modify or amend any antenna or specification without prior notice.
Model No: MK-06807 | Mounting kit for outdoor Base Station Panel Antennas page 4 of 4
WWW.GALTRONICS.COM
MK-06807 Release Date: 19-SEP-2019; Revision: R2
ASSEMBLY DWG;
Table 3
Assembly Drawing
ITEM
NO.
PART
NO.
QTY
DESCRIPTION
1
A60-
00203
1
BRACKET, TOP
MOUNT,
INDEX, MK-
6807
2
A60-
00205
1
BRACKET, TOP
MOUNT, SIDE
MOUNT, MK-
6807
3
A60-
00206
2
BRACKET,
REAR SIDE
MOUNT, MK-
6807
4
A60-
00209
1
BRACKET,
FRONT SIDE
MOUNT, MK-
6807
5
A70-
00204
20
NUT, HEX,
1/2" -13 UNC,
6
A70-
00205
6
SCREW, HEX
HEAD, 1/2"-13
UNC, 1-3/4" L,
18-8 SS
7
A70-
00206
4
SCREW, HEX
HEAD, 1/2"-13
UNC, 8" L, 18-
8 SS
8
A70-
00207
18
WASHER,
FLAT, 1/2"
SCREW, 18-8
SS
9
A70-
00208
10
WASHER,
SPLIT LOCK,
1/2" SCREW,
18-8 SS
10
A70-
00225
2
WASHER,
FLAT, 1/2"
SCREW, 1.5"
OD, 18-8 SS
