Ganz ZC-YHW702 Series User manual

Operation Manual
CCD CAMERA
ZC-YHW702 Series

En-1
Read the “Instructions for Use” prior to operation.
Retain this operation manual for future reference.
Follow these important safety instructions at all times.
Heed the following explanations of “Warning” and “Caution”.
Indicates danger of death or injury to the user if not
operated properly.
Indicates danger of injury to the user or material
damage if not operated properly.
㻃Warning
Do not open the cover or disassemble the main casing.
This may result in burns or injury due to contacting high temperature areas
inside the main body or damaged part.
Do not insert foreign objects.
Do not spill liquids or drop flammable items or metal inside.
This may cause fire. Disconnect the power plug and contact a dealer.
Do not use in conditions such as rain, water, moisture, dust,
greasy fumes and hot air.
This may cause fire.
Do not place in the vicinity of thermal appliances.
This may cause the casing to warp or high temperatures inside the device
which could result in fire.
Avoid direct sunlight.
This may cause high temperatures inside the device which could result in fire.
Disconnect the cables immediately upon detecting smoke or an
unusual odor.
Subsequent to disconnecting power, confirm that there is no smoke or unusual
odor and contact a dealer. Failing to do so may result in fire.
Do not touch the device or the connecting cables in the case of
lightning.
This may cause electric shock.
Ask a dealer for installation.
Failing to do so may result in fire, electric shock and accident.
Warning
Cautio
n

En-2
㻃Caution
Turn off the power before connecting any devices.
Failing to do so could result in electric shock or fire.
Make sure that connecting cables are inserted fully.
Failing to do so can result in fire.
Disconnect the power and cables before moving the device.
Failing to do so can result in injury and damage to the device.
Install connecting cables in an area where they won’t be
pulled or be caught.
Failing to do so can result in injury.

Item Page
Introduction 4
Instructions for Use 4
Component Names and Functions 5
Lens Mounting 6
Wiring Connector 6
Applicable Lenses 6
Lens Adjustment 6
Back Focus Adjustment 7
Connecting the Power 8
Connecting the AC Power 8
Connecting the DC Power 8
Settings for Various Functions 9
Settings Operation 11
Setting Items 11
Mode Select (MODE SELECT) 11
Settings for the Exposure Function (CONFIGURATION) 13
Settings for Other Functions (FUNCTION SET.) 15
Camera Setup (CAMERA SETUP) 19
Lens Setup (LENS SETUP) 19
Mode Save (MODE SAVE) 20
Defect Correction (WHITE SPOT CORRECTION) 20
Initialize (INITIALIZE) 21
External Control Signal Terminal 22
Connection 22
Settings 23
Specifications 24
En-3
Table of Contents

Thank you for purchasing our product.
This device is a multifunctional, high performance CCD camera developed for high end
security.
The characteristics of this camera are as follows.
(1) Wide dynamic range function (WD)
Displays both light and dark objects at the same time (Dynamic range of 60-dB max).
(2) Day and Night modes (DAY & NIGHT)
Displays a high quality color picture during the day and a clear black and white picture at
night.
(3) Electronic sensitivity UP function (SENS UP)
(4) Electronic zoom function (E-ZOOM)
(5) On screen display function (OSD)
(6) High definition
Area to use/store
This device is an indoor camera. Do not use it outside.
Do not expose the camera to extreme light sources (lighting and sunlight) regardless of use.
Avoid using and storing in the following locations.
Extremely hot or cold locations (operating temperature -10C to +50C)
High humidity or dusty locations
In rainy locations or locations exposed to water
Locations exposed to rigorous vibration
Near TV and radio transmitting station with strong signals
Care
Wipe dirt off the casing with a soft dry cloth. For heavy soil, wipe off using a dry cloth after
cleaning with a cloth with a small amount of mild detergent. Disconnect the power cord prior
to cleaning.
Do not use flammable liquids such as alcohol, benzene or thinner. This may damage the
surface finish.
Do not touch the surface of the CCD. If it gets dusty, wipe off with lens cleaning paper.
Other
White spots may appear on the screen due to normal characteristics of the imaging device.
However, this is not a defect.
White spots may also be noticeable when using the electronic sensing UP function (SENS
UP). However, this is not abnormal.
Colors may differ somewhat from actual colors depending on the lighting but this is not a
defect.
Highly light-intensive objects (such as lamps) may cause vertical stripes to appear on the
screen. This is a normal characteristic of the imaging device and is not a defect.
En-4
Instructions for Use
Introduction


ձLens mount
A suitable type CS mount lens may be attached. C mount lenses can be attached using a
C/CS mount adapter.
ղBack focus lock screw
A ALLEN WRENCH can be inserted here to stabilize the lens mount using a screw to
adjust the distance between the lens mounting surface and the imaging surface. Refer to
“Lens Mounting: Back Focus Adjustment” for adjustment.
ճCamera mount area
The camera can be mounted using either the top or bottom of the main body. Use 1/4 - 20
screw for mounting.
մVIDEO OUT (Video output) terminal
This is an output terminal for the video signal. (BNC type)
յLens terminal
4 Pin connector for an auto iris lens. Refer to “Lens Mounting: Wiring Connector” for wiring.
նRS485 Terminal switch
Use this when connecting an external device using the external control terminal of this
device.
ON: Terminal with 100 Ω. OFF: No terminal
շPower indicator light
This lights up when powered on.
ոSwitch for function settings
This is a switch for the function settings. This is used when a menu is displayed and
settings are determined.
For details, refer to “Settings for Various Functions: Settings Operation”.
չPower input terminal
This is the input terminal where power is supplied. This uses both 12 V DC and 24 V AC.
պExternal control terminal
This can be used to connect an RS-485 I/O compatible terminal. It can also be used for an
external control terminal for the DAY & NIGHT function. For details, refer to "External
Control Signal Terminal".
Component Names and Functions
En-5
Figure 1
Top Front View
Rear View

This device uses a DC voltage auto iris lens. A VIDEO signal control lens can not be used.
Wiring Connector 㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃
Refer to chart 1 for the connector wiring diagram.
Applicable Lenses 㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃
Lenses can be used, which have a thread length less than that specified below. Longer lenses
may damage the imaging device.
Back focus is adjusted for CS mount type lenses when this device is shipped.
Use a C/CS mounting adaptor to attach a C mount lens.
Lens Adjustment 㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃
Adjust the mechanical iris lens.
Mount the lens on this device and adjust the lens before using.
Operating procedure
1. Move the cursor to “LENS SETUP” and press the switch. The “LENS SETUP” screen is
displayed.
2. Move the cursor to “INITIAL FINE ADJ.” and press the switch.
Move the cursor to “OK” and press the switch. Adjustment will be carried out.
Carry out adjustment using a bright light source with no flicker.
3. The “LENS SETUP” screen will be displayed upon completion of adjustment.
Note) Repeat this adjustment procedure any time a lens is replaced.
Lens Mounting
En-6
(Appearance of the connector entry point)
Auto iris lens
Connector
Connector
Pin No.
DC voltage drive
Auto iris lens
Chart 1
Figure 2
Figure 3

Back Focus Adjustment 㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃
The factory settings include back focus adjustment for a CS mount lens. However, adjustment
may be required depending on the lens used. Use the back focus adjustment function to do this.
Adhere to the following adjustment procedure.
Operating procedure
1. Push the function settings switch up. (Jump function). The back focus adjustment screen is
displayed. (Figure 4-1)
When this screen is displayed, the lens is open.
The back focus adjustment screen can also be reached from the “TOP MENU LENS SETUP”
screen using the “Setting Operation” procedure.
2. Loosen the back focus lock screw using the ALLEN WRENCH. Adjust the lens mounting to
fix the focus. Secure the lens mount with back focus lock screw.
3. Press the function settings switch to end the back focus adjustment.
Note)
Use the included ALLEN WRENCH for adjustment. Insert the long end of ALLEN WRENCH into
the adjustment hole of the camera.
Rotate it in a clockwise approximately 15 degrees to fasten the lens mount.
If the back focus lock screw is too tight, the threads of the lens mount may be damaged.
When using a zoom lens:
1. Objects further than 25 meters (70 feet) can be captured.
2. Set the focus to FAR.
3. Set the zoom to wide angle.
4. Complete the above procedures 1-3.
5. Set the zoom to telephoto.
6. Adjust the focus.
En-7
Figure 4
ALLEN WRENCH
Camera
EASY BACK FOCUS ADJ.
Figure 4-1

Use 24 V AC / 12 V DC for this device.
Connecting the AC Power 㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃
Use 24 V AC (20.4 - 27.6 V AC) 50 Hz / 60 Hz to power the device. Refer to figure 5 as to
connecting the power.
Peel back the casing of the power cord about 10 mm and insert the twisted wire directly into the
terminal.
If the power cord can not be inserted, try pressing the button on the terminal and inserting
again.
Connecting the DC Power 㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃
Use 12 V DC (10.2 – 13.8 V DC). Refer to figure 6 as to connecting the power.
When a fuse is necessary, connect a slow blow fuse within 10 cm of the power terminal (+
terminal side).
Connecting the Power
En-8
Warning: Be careful not to short circuit the power cord when connecting it to the
device.
Pay attention to the power polarity.
390 mA of current is required for each device.
Be careful with following items when choosing and connecting the
power cord.
1) Allowable current for the power cord
2) Power cord size and length
Back panel
Button
Transformer
DC power
Fuse
Button
Pull on the power cord and make sure that it is connected.
Make sure the wire of power cord is not exposed outside of the terminal.
Use class 2 power supply. Connect the GND line to GND terminal.
Caution
270 mA (24 V AC) of current is used by this device.
The capacity to supply multiple connections is required when multiple
devices are connected to one power source.
Caution
Caution
Figure 6
Figure 5

This device is equipped with an OSD (On Screen Display) feature and various functions can be
set using this camera’s monitor screen.
A list of settings menu is as follows.
Settings for Various Functions
En-9
TOP MENU
MODE SELECT
CONFIGURATION
FUNCTION SET.
CAMERA SETUP
LENS SETUP
MODE SAVE
WHITE SPOT CORRECTION
INITIALIZE
END
MODE SELECT
STANDARD
DAY&NIGHT
WIDE
CASINO
USER MODE
RETURN END
LENS SETUP
EASY BACK FOCUS ADJ.
INITIAL FINE ADJ.
OK CANCEL
CAMERA SETUP
ADDRESS
COM SPEED
EASY BF JUMP
RETURN END
CONFIGURATION
AE MODE →WD
BRIGHT LEVEL →3
FLICKERLESS →OFF
AGC →ON
SENS UP →OFF
DAY&NIGHT →AUTO
DETECT TIME →5 sec
FILTER LIMIT →OFF
RETURN END
FUNCTION SET.
SYNC SELECT
WHITE BALANCE
CHROMA
GAMMA
E-ZOOM
CRISPNESS
PRIVACY MASKING
TITLE
RETURN END
MODE SAVE
CURRENT SETTINGS
ARE SAVED
OK CANCEL
WHITE SPOT CORRECTION
COVER THE LENS
OK CANCEL
INITIALIZE
ALL SETTINGS ARE
INITIALIZED
OK CANCEL
Next page
→
→AUTO
→
→NORMAL
→
→1
→
→
→1
→19200
→ON

En-10
CHROMA
RY GAIN →-1
BY GAIN →-1
RY HUE →1
BY HUE →-2
RETURN END
SYNC SELECT
SYNC MODE AUTO
LL PHASE →
RETURN END
E-ZOOM
ZOOM →OFF
POSITION
RETURN END
PRIVACY MASKING
MASK →OFF
MASK EDIT
MASK ERASE
RETURN END
TITLE
TITLE →OFF
TITLE EDIT
RETURN END
LL PHASE SHIFT
Phase Value = 33
POSITION
PRIVACY MASK SETTING
TITLE EDIT
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
a b c d e f g h i j k l m
n o p q r s t u v w x y z
0 1 2 3 4 5 6 7 8 9 - /
RETURN BS
Notice) With AUTO settings
Notice) With Zoom settings
Notice) With MASK setting ON
Notice) With TITLE setting ON

Settings Operation 㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃
This device is equipped with an OSD (On Screen Display) feature. Operate as follows to
change settings using the menu.
1. Press and hold the function setting switch on the back panel for about two seconds. (Figure
1).
2. The settings screen shown in figure 7-1 is displayed.
3. Move the cursor to the item that you want to change using the switch. The selected menu is
displayed.
4. Adjust the setting value of the item you want to change.
5. Move the cursor to “END” to finish the settings and press the switch.
Move the cursor to “RETURN” to return to the previous item and press the switch.
Figure 7-1 TOP MENU
Note)
If the menu is not operated for one minute, the menu will automatically turn off.
The setting for each item is saved when "RETURN'' and "END" are selected.
* is displayed for the items limited based on the setting of a function.
Setting Items 㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃㻃
(1) Mode Select (MODE SELECT)
Camera is operated using the preset settings by selecting the various modes.
It is possible for the user to register user determined settings (USER MODE).
Refer to “MODE SAVE” for the setting procedure for “USER MODE”.
The following modes can be selected.
STANDARD
DAY&NIGHT
WIDE
CASINO
USER MODE
Figure 7-2 MODE SELECT menu
En-11
TOP MENU
MODE SELECT
CONFIGURATION
FUNCTION SET.
CAMERA SETUP
LENS SETUP
MODE SAVE
WHITE SPOT CORRECTION
INITIALIZE
END
→
→
→
→
MODE SELECT
STANDARD
DAY&NIGHT
WIDE
CASINO
USER MODE
RETURN END

The details of each of the mode settings are as follows.
STANDARD
Figure 7-3 STANDARD settings
DAY&NIGHT
Figure 7-4 DAY&NIGHT settings
WIDE
Figure 7-5 WIDE settings
CASINO
Figure 7-6 CASINO settings
En-12
FUNCTION SET.
SYNC SELECT
WHITE BALANCE
CHROMA
GAMMA
E-ZOOM
CRISPNESS
PRIVACY MASKING
TITLE
RETURN END
→AUTO
→AUTO
→
→NORMAL
→
→0
→
→
CONFIGURATION
AE MODE
BRIGHT LEVEL
FLICKERLESS
AGC
SENS UP
DAY&NIGHT
DETECT TIME
FILTER LIMIT
RETURN END
→NORMAL
→0
→OFF
→ON
→4
→COLOR
→5sec
→OFF
CONFIGURATION
AE MODE
BRIGHT LEVEL
FLICKERLESS
AGC
SENS UP
DAY&NIGHT
DETECT TIME
FILTER LIMIT
RETURN END
→NORMAL
→0
→OFF
→ON
→OFF
→AUTO
→5sec
→10min
FUNCTION SET.
SYNC SELECT
WHITE BALANCE
CHROMA
GAMMA
E-ZOOM
CRISPNESS
PRIVACY MASKING
TITLE
RETURN END
→AUTO
→AUTO
→
→
→
→1
→
→
FUNCTION SET.
SYNC SELECT
WHITE BALANCE
CHROMA
GAMMA
E-ZOOM
CRISPNESS
PRIVACY MASKING
TITLE
RETURN END
→AUTO
→AUTO
→
→NORMAL
→
→0
→
→
CONFIGURATION
AE MODE
BRIGHT LEVEL
FLICKERLESS
AGC
SENS UP
DAY&NIGHT
DETECT TIME
FILTER LIMIT
RETURN END
→WD
→3
→OFF
→ON
→OFF
→COLOR
→5sec
→OFF
FUNCTION SET.
SYNC SELECT
WHITE BALANCE
CHROMA
GAMMA
E-ZOOM
CRISPNESS
PRIVACY MASKING
TITLE
RETURN END
→INT
→INDOOR
→
→SCENE1
→
→0
→
→
CONFIGURATION
AE MODE
BRIGHT LEVEL
FLICKERLESS
AGC
SENS UP
DAY&NIGHT
DETECT TIME
FILTER LIMIT
RETURN END
→NORMAL
→0
→OFF
→ON
→4
→COLOR
→5sec
→OFF

(2) Settings for the Exposure Function (CONFIGURATION)
This is a menu to adjust the camera exposure. Two menus are available based on the AE
MODE setting.
A . For “AE MODE” settings other than "MANUAL" B. For “MANUAL” setting in “AE MODE”
Figure 8-1 CONFIGURATION menu
AE MODE
Sets the exposure mode.
The mode can be changed to WD →NORMAL →BLC →MANUAL, in this order.
WD: Selects the Wide Dynamic Range function.
This is used when objects with different lighting or a mix of indoor and outdoor are used.
“E-ZOOM” can not be set when this item is selected.
NORMAL: Exposure is controlled by the mechanical iris and electronic shutter.
BLC: Back light correction function operates.
Dark objects resulting from back light are adjusted to the best suited brightness.
MANUAL: Shutter speed is manually set. Set with “SHUTTER SPEED”.
BRIGHT LEVEL
Adjusts the brightness of the screen. Setting values: -5 to 5
Note) This can be adjusted using “AE MODE” in addition to “BLC”.
FLICKERLESS
When an “AE MODE” other than “MANUAL” is selected, the flickerless function can be set
ON/OFF.
If ON is selected, the shutter speed is fixed at 1/100 s (NTSC) or 1/120 s (PAL).
SHUTTER SPEED
The shutter speed can be set when the “AE MODE” is set to “MANUAL”.
Setting values: 1/60(NTSC), 1/50(PAL), 1/100(NTSC), 1/120(PAL), 1/250, 1/500, 1/1000,
1/2000, 1/4000, 1/10000, 1/20000, 1/50000
AGC
Gain is automatically adjusted when AGC is ON based on the brightness of the object. AGC
OFF locks the gain at a minimum.
SENS UP
The brightness is increased by lengthening the CCD imaging time over several fields.
Setting values: OFF, 2, 4, 6, 8, 10, 20, 40 (The setting indicates the maximum imaging time.
The imaging time will change automatically based on the brightness of the object.)
Note) This item can not be selected when the selected “AE MODE” is “MANUAL”. It is
automatically switched to OFF.
When the magnification of “SENS UP” is increased, the screen may look rough, washed
out, or have white spots. This is not a defect.
En-13
CONFIGURATION
AE MODE
BRIGHT LEVEL
FLICKERLESS
AGC
SENS UP
DAY&NIGHT
DETECT TIME
FILTER LIMIT
RETURN END
→WD
→3
→OFF
→ON
→OFF
→AUTO
→5 sec
→OFF
CONFIGURATION
AE MODE
BRIGHT LEVEL
SHUTTER SPEED
AGC
SENS UP
DAY&NIGHT
DETECT TIME
FILTER LIMIT
RETURN END
→MANUAL
→3
→1/60
→ON
→OFF
→AUTO
→5 sec
→OFF

DAY & NIGHT
This is used to switch between day (color) and night (black/white) settings.
AUTO: This switches between color mode and black/white mode automatically based on
the brightness of the screen.
COLOR: Selects color mode.
BW: Selects black/white mode.
EXT.: This switches modes based on an external control signal. For details, refer to
“External Control Signal Terminal”.
Note)
If "AGC" is set to "OFF", then "DAY&NIGHT” can not be set to “AUTO” or “EXT”.
If “AGC” is set to “OFF”, this will be forcibly set to “COLOR or BW” when “DAY&NIGHT” is
set to “AUTO”.
The mode can switch automatically based on the brightness of the object when using the
"AUTO" settings, however, it may not switch depending on the lighting conditions and angle
of view.
Hunting may occur if using near infrared lighting at night. This device includes a function to
stop filtering when hunting occurred as a countermeasure for this problem. You can set the
stopping time with the "FILTER LIMIT" item to use this function. Selecting "EXT" in switch
mode from external input is recommended to ensure that it switches.
DETECT TIME (Use the “AUTO” and “EXT” settings for “DAY&NIGHT”.)
The detection time for DAY&NIGHT can be set.
If the brightness level change continues for longer than the time set in this item, the mode will
switch.
5 sec, 30 sec
FILTER LIMIT (Use the “AUTO” and “EXT” settings for “DAY&NIGHT”.)
The time to stop filtering when hunting occurs during DAY䟹NIGHT operation can be set.
OFF, 10 min, 30 min
Note) * is displayed before the “FILTER LIMIT” during the operation of this function.
En-14

(3) Settings for Other Functions (FUNCTION SET.)
This is a menu to set various functions other than exposure.
Figure 9-1 FUNCTION SET. menu
(3-1) SYNC SELECT
The synchronization can be set.
Figure 9-2 SYNC SELECT menu
SYNC MODE
This selects the sync system.
AUTO: This operates with LineLock for the AC power and operates with Internal for DC
power.
INT: This always operates using internal sync.
LL PHASE
This adjusts the vertical synch phase during LineLock operation.
Method for adjustment
1. Set "SYNC MODE" to "AUTO".
2. Move the cursor to "LL PHASE" and press the switch to display the "LL PHASE SHIFT"
screen.
3. The vertical sync phase can be adjusted by moving the switch up or down from "LL PHASE
SHIFT" screen. Refer to figure 9-3.
Note) The power supply frequency for when power synchronized function is used is
NTSC : 60 Hz and PAL : 50 Hz.
En-15
FUNCTION SET.
SYNC SELECT
WHITE BALANCE
CHROMA
GAMMA
E-ZOOM
CRISPNESS
PRIVACY MASKING
TITLE
RETURN END
→
→AUTO
→
→NORMAL
→
→1
→
→
SYNC SELECT
SYNC MODE 㻃→AUTO
LL PHASE →
RETURN END
LL PHASE SHIFT
PHASE Value = 33
Phase Value Range
More than 180°
Figure 9-3 PHASE SHIFT

(3-2) WHITE BALANCE
WHITE BALANCE
The mode for white balance can be selected.
AUTO: White balance is adjusted automatically.
HOLD: The white balance used right before changing to this mode is maintained. This is
suitable for imaging in a location where lighting doesn’t change. Refer to the
following setting method.
White balance maintained using the “HOLD” mode is lost if it is switched to the
“AUTO” mode.
Method for the HOLD setting
1. “WHITE BALANCE” is set to “AUTO” in the condition that the object is captured.
2. “WHITE BALANCE” is switched “AUTOHOLD”.
㻃㻃In this process, the white balance is maintained.
INDOOR㻃 㻃 : Fixed white balance for lighting of approximately 2800 K.
OUTDOOR㻃: Fixed white balance for lighting of approximately 6000 K.
(3-3) CHROMA
The gain and hue of the chroma signal can be adjusted.
Figure 9-4 CHROMA menu
RY GAIN
This adjusts the gain of chroma signal. Adjustment range㻃-5 ~ 5
BY GAIN
This adjusts the gain of chroma signal. Adjustment range㻃-5 ~ 5
RY HUE
This adjusts the hue of chroma signal. Adjustment range㻃-5 ~ 5
BY HUE
This adjusts the hue of chroma signal. Adjustment range㻃-5 ~ 5
(3-4) GAMMA
GAMMA
This selects the gamma setting.
NORMAL (approx. 0.6), SCENE1 (approx. 0.45), SCENE2 (approx. 1.0)
Note) This can not be selected when using the “AE MODE” “WD” setting.
En-16
CHROMA
RY GAIN
BY GAIN
RY HUE
BY HUE
RETURN END
→-1
→-1
→1
→-2

(3-5) E-ZOOM
This operates the electronic zoom and electronic pan/tilt function.
These functions are set using this menu.
Figure 9-5 E-ZOOM menu
ZOOM
This sets zoom magnification.
OFF, 1.5, 2.0, 2.5
Note) “PRIVACY MASKING” and “AE MODE: WD” can not be used with this item setting.
POSITION
The frame position is set for zooming. This can be used only when zoom magnification is
selected.
Adjustment method
1. Set “ZOOM” to more than 1.5 times.
2. Move the cursor to “POSITION” and press the switch to display the “POSITION” screen.
3. The frame position can be changed by moving the switch up and down and left and right on
the "POSITION" screen.
Note) The tilt function is limited by the zoom magnification. The highest magnification with
which it can tilt fully is up to 1.5X.
(3-6) PRIVACY MASKING
Sets the mask setting for the screen.
Figure 9-6 PRIVACY MASKING menu
MASK
This sets the MASK display ON/OFF.
MASK EDIT
This edits the created mask. In total, up to 8 masks can be set.
Method to create a mask
1. Set “MASK” to “ON”.
2. Move the cursor to “MASK EDIT” and press the switch to display the “PRIVACY MASK
SETTING” screen.
En-17
E-ZOOM
ZOOM →2.0
POSITION →
RETURN END
POSITION
PRIVACY MASKING
MASK
MASK EDIT
MASK ERASE
RETURN END
→OFF
→
PRIVACY MASK SETTING

3. An arrow is displayed on the screen. Determine the position of the mask to be created using
this arrow.
First, move the arrow to upper left of mask to be created and select the position with the
switch.
Move the arrow next to the lower right, and mask will be created by selecting the position
with the switch.
MASK ERASE
This erases the created mask.
Method to erase a mask
1. Move the cursor to "MASK ERASE”.
2. Press the switch in this position to erase the mask.
Note)㻃If multiple masks have been created, the masks are erased in the opposite order
the masks were created.
(3-7) TITLE
This creates text and sets it to display on the screen.
Figure 9-7 TITLE menu
TITLE
This sets the display of text ON/OFF.
TITLE EDIT
This edits the text to be displayed. Up to 16 characters can be displayed.
Method to create a title
1. Set "TITLE" to "ON".
2. Move the cursor to “TITLE EDIT” and press the switch to display the “TITLE EDIT” screen.
3. Move the cursor to the text you want to display and press the switch. The selected text is
displayed in the editing area.
4. Repeat the above steps until editing is complete.
5. Move the cursor to “BS” and press the switch to erase one character.
(3-8) CRISPNESS
This sets edge enhancement. It sharpens the image in the “+” direction and softens the image
in the “-” direction.
Figure 9-8 CRISPNESS menu
En-18
TITLE
TITLE →ON
TITLE EDIT →
RETURN END
TITLE EDIT
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
a b c d e f g h i j k l m
n o p q r s t u v w x y z
0 1 2 3 4 5 6 7 8 9 - /
RETURN BS
FUNCTION SET.
SYNC SELECT
WHITE BALANCE
CHROMA
GAMMA
E-ZOOM
CRISPNESS㻃 㻃 䊲1
PRIVACY MASKING
TITLE
RETURN END
TITLE
TITLE →ON
TITLE EDIT →

(4) Camera Setup (CAMERA SETUP)
This device is equipped with an external control input terminal (RS-485) and settings for each
function can be changed from an external unit.
For details, refer to “External Control Signal Terminal”.
Figure 10 CAMERA SETUP menu
ADDRESS
This sets numbers to identify multiple cameras. Up to 30 cameras can be connected.
Note) If these numbers overlap in the system, it won’t operate properly.
COM SPEED
This sets the communication speed with the external unit.
2400, 4800, 9600 and 19200 can be selected.
EASY BF JUMP
This switches the jump function to jump to the back focus adjustment screen.
ON: Valid, OFF: Invalid
(5) Lens Setup (LENS SETUP)
This adjusts the back focus and reference voltage for the mechanical iris.
Figure 11 LENS SETUP menu
EASY BACK FOCUS ADJ.
For details, refer to “Lens Mounting: Back Focus Adjustment”
Optical back focus adjustment and lens focus adjustment are possible using this function.
INITIAL FINE ADJ.
For details, refer to “Lens Mounting: Lens Adjustment”.
En-19
CAMERA SETUP
ADDRESS
COM SPEED
EASY BF JUMP
RETURN END
→1
→19200
→ON
LENS SETUP
EASY BACK FOCUS ADJ.
INITIAL FINE ADJ.
OK CANCEL
