Garden Sun GS4400SS User manual

Owner’s
Manual
CSA International Requirement NO.5.90.US (5th Edition)
IMPORTANT
Read this manual carefully before
assembling, using or servcing this
heater keep this manual for future
reference.
PATIO HEATER
RR
GS4400SS
GS4400GN
GS4400BK
GS4400CP
GS4400GD
GS4400WH



1
ontents
General Safety Information....................................... 1
snoitcurtsnIylbmessA
omponents & Hardware.......................................
.
3
Additional Requirements ........................................ 3
ssecorPnoitallatsnI
Step1 - Attach Wheel Assembly to Base................. 4
Step 2 – Attach Bucket to Base.............................. 4
Step 3 –Attach Support Brackets to Base..............
.
5
Step 4 – Attach Post to Support Brackets............... 5
Step 5 – Load ylinder Housing onto Post............. 5
Step 6 – Attach Reflector Studs to Screen over... 5
Step 7 – Attach Head Assembly to Post.................
.
5
Step 8 – Install Reflector.........................................
...............................................
6
Step 9 – Attach Reflector Assembly to Studs.........
.
7
Step 10 – onnect Hose & Regulator to ylinder... 7
Leak heck............................................................. 8
Operation................................................................ 8
01tsilkcehnoitarepO
Troubleshooting...................................................... 11
Maintenance........................................................... 11
Storage...................................................................
.
12
Service.................................................................... 12
General Safety Information
This manual contains important information about the
assembly, operation and maintenance of this patio heater.
General safety information is presented in these first few
pages and is also located throughout the manual.
Keep this manual for future reference and to educate
new users of this product. This manual should be read in
conjunction with the labeling on the product.
Safety precautions are essential when any mechanical
or propane fueled equipment is involved. These
precautions are necessary when using, storing, and
servicing. Using this equipment with the respect and
caution demanded will reduce the possibilities of personal
injury or property damage.
The following symbols shown below are used extensively
throughout this manual. Always heed these precautions,
as they are essential when using any mechanical or
fueled equipment.
DANGER
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates an imminently hazardous situation
which, if not avoided, could result in death or serious injury.
AUTION
AUTION indicates an imminently hazardous situation
which, if not avoided, may result in minor or moderate
personal injury, or property damage.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapor and liquids in the vicinity of
this or any other appliance.
WARNING: For Outdoor Use Only
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Read the instructions
thoroughly before installing or servicing this
equipment.
DANGER
Failure to comply with the precautions and instructions
provided with this heater can result in death, serious bodily
injury and property loss or damage from hazards of fire,
explosion, burn, asphyxiation, and/or carbon monoxide
poisoning.
Only persons who can understand and follow the
instructions should use or service this heater.


2
DANGER
• EXPLOSION - FIRE HAZARD
• Keep solid combustibles, such as building materials,
paper or cardboard, a safe distance away from the heater
as recommended by the instructions.
• Provide adequate clearances around air openings into
the combustion chamber.
• Never use the heater in spaces which do or may contain
volatile or airborne combustibles, or products such as
gasoline, solvents, paint thinner, dust particles or unknown
chemicals.
• During operation, this product can be a source of
ignition. Keep heater area clear and free from combustible
materials, gasoline, paint thinner, cleaning solvents and
other flammable vapors and liquids. Do not use heater in
areas with high dust content. Minimum heater clearances
from combustible materials: three (3) feet from the sides &
two (2) feet from the top.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish open flame.
3. If odor continues, immediately call your gas
supplier.
WARNING
We cannot foresee every use which may be made of our
heaters.
heck with your local fire safety authority if you have
questions about heater use.
Other standards govern the use of fuel gases and heat
producing products for specific uses. Your local authorities
can advise you about these.
If no local codes exist, follow National Fuel Gas ode,
ANSI Z223.1. In anada, installation must conform to local
codes. If no local codes exist, follow the current National
standards of ANADA AN/ GA-B 149.2.
DANGER
• CARBON MONOXIDE HAZARD
• This heater is a combustion appliance. All combustion
appliances produce carbon monoxide ( O) during the
combustion process. This product is designed to produce
extremely minute, non-hazardous amounts of O if used
and maintained in accordance with all warnings and
instructions. Do not block air flow into or out of the heater.
• arbon Monoxide ( O) poisoning produces flu-like
symptoms, watery eyes, headaches, dizziness, fatigue and
possibly death. You can't see it and you can't smell it. It's
an invisible killer. If these symptoms are present during
operation of this product get fresh air immediately!
• For outdoor use only .
• Never use inside house, or other unventilated or
enclosed areas.
• This heater consumes air (oxygen). Do not use in
unventilated or enclosed areas to avoid endangering
your life.
AUTION
• SERVICE SAFETY
• Keep all connections and fittings clean. Make sure
propane cylinder valve outlet is clean.
• Inspect hose before use. Replace if there is evidence of
abrasion or wear.
• During set up, check all connections and fittings for leaks
using soapy water. Never use a flame.
• Use as a heating appliance only. Never alter in any way or
use with any device.
• heck entire hose at least annually.
WARNING
• BURN HAZARD
• Never leave heater unattended when hot or in use.
• Keep out of reach of children.

3
WARNING
• This product is fueled by propane gas. Propane gas is
invisible, odorless, and flammable. An odorant is normally
added to help detect leaks and can be described as a
“rotten egg” smell. The odorant can fade over time so
leaking gas is not always detectable by smell alone.
• Propane gas is heavier than air and leaking propane will
sink to the lowest level possible. It can ignite by ignition
sources including matches, lighters, sparks or open flames
of any kind many feet away from the original leak. Use only
propane gas set up for vapor with draw.
• Propane gas should be stored or used in compliance with
local ordinances and codes or with ANSI/NFPA 58. Turn off
propane when not in use.
DANGER
• EXPLOSION - FIRE HAZARD
• Never store propane near high heat, open flames, pilot
lights, direct sunlight, other ignition sources or where
temperatures exceed 120 degrees F (49° ).
• Propane is heavier than air and can accumulate in low
places. If you smell gas, leave the area immediately.
• Never install or remove propane cylinder while heater is
lighted, near flame, pilot lights, other ignition sources or
while heater is hot to touch.
• This heater is red hot during use and can ignite
flammables too close to the burner. Keep flammables at
least 3 feet from sides & 2 feet from top. Keep gasoline and
other flammable liquids and vapors well away from heater.
• The propane cylinder must always be stored outdoors in a
well ventilated space. Never store propane cylinder in an
enclosed area (house, garage, etc.). If heater is to be
stored indoors, disconnect the propane cylinder for outdoor
storage.
Assembly Instructions
Components
 Remove all components from package.
GS4400-P1: REFLECTOR PANEL
GS4400-P5: HEATER BURNER
SCREEN
GS4400-P6: HEAD ASSEMBLY
GS4400-P7: CYLINDER HOUSING
GS4400-P8: POST
GS4400-P9: SUPPORT BRACKET
GS4400-P10: GAS HOSE
GS4400-P11: REGULATOR
GS4400-P12: BASE
GS4400-P4: NUTS AND BOLTS PACKAGE
GS4400-P7, GS4400-P8, & GS4400-P12 REQUIRE COLOR
-GN (GREEN), -SS (STAINLESS), -WH (WHITE)
-BK (BLACK), -CP (COPPER), -GD (GOLD),

4
Picture Qty Description Used in
Step(s)
6 Large Bolt 4
5 Medium Bolt 1 & 3
4 Small Bolt
4 Large Screw 2
9 Small Screw 8
9Large Flat
Washer 6 & 9
9Small Flat
Washer 8
2Large Flange
Nut 1
6Small Flange
Nut 4
4 Large Nut 2
9 ap Nut 8
3 Wing Nut 9
3 Reflector Stud 6
1 Wrench 1 / 3 / 4 /
7 / 8
Additional Requirements
The following items are not included, but are necessary for
the proper assembly of your heater. Do NOT attempt to
assemble without proper tools.
. 7/16” open-end wrench.
.Philips screwdriver w/ medium blade.
. Adjustable opening wrench.
. Leak Detection Solution(Instructions on how to make
solution are included in step )
Note: You must follow all steps to properly assemble
heater.
(For models without Wheels , skip to Step 2)
Step 1 – Attach Wheel Assembly to Base
. Line up holes in Wheel Bracket with corresponding
holes in Base, Insert 2 Medium Bolts through holes,
finger tighten 2 Large Flange Nuts.
. Be sure that the Wheel Assembly is parallel to the
base, and fully tighten bolts.
Wheel Assembly
(For models without Bucket , skip to Step 3)
Step 2 – Attach Bucket to Base
Bucket
. Slip 4 Large Screw through holes of Base.
2 Req’d Medium Bolts 2 Req’d Large Flange Nuts
4 Req’d Large Screws 4 Req’d Large Nuts
Hardware Installation process
(GS4400-P4)
