Gardena 11120 User manual

1,25 L Art. 11120
EN Operator’s manual
Pressure Sprayer
EN

2
0 – 340°C
O1
max. 1,25 l
1
8
9
7
0
2
O2
3
O3
5
e
q
4
6
w

3
EN GARDENA Pressure Sprayer 1.25 l
Intended use:
The GARDENA Pressure Sprayer is intended for distributing solvent-free liquid
pesticides
1), herbicides 1), fertilisers 1), window cleaners 1), and car wax 1) in
domestic gardens and allotments. It must not be used in public places, parks,
sport arenas, or in agriculture or forestry. Compliance with the specifications
in this operating manual is a requirement for the proper use of the Pressure
Sprayer.
1) According to the Plant Protection Law as well as the Detergents and Cleaning Agents Law, only
approved agents may be used (authorised specialist dealers).
Please note:
Due of the risk of physical injury, the GARDENA Pressure Sprayer must not be
used for spraying substances other than those specified by GARDENA.
Also, no acids, disinfectants or impregnators, aggressive and solvent-containing
cleaning agents, petrol or spray oil may be sprayed.
1. SAFETY
Danger of physical injuries:
Never open the Pressure Sprayer or unscrew the nozzle and the dosing cap
when the Pressure Sprayer is still pressurised. To prevent injury, never connect
the Pressure Sprayer to an air-compressor. Always hold the Pressure Sprayer
upright before the safety relief valve 6(Fig. O3) is pressed.
When spraying insecticides, herbicides and fungicides or other liquid plant
protection products, you must comply with all special precautionary measures
specified by the manufacturer of the product you are using.
Before each opening of the Pressure Sprayer, thoroughly release
pressure by pressing the safety relief valve 6.
EN

4
Operation:
CAUTION: The tank may only be filled with a maximum of 1.25 litres
liquid. Inspect the Pressure Sprayer visually before each use. Never leave your
Pressure Sprayer unattended or for long periods when full and pressurised.
Keep the unit out of the reach of children. You are responsible for the safety
of others. Keep your Pressure Sprayer away from heat sources and hot
environments. Screw on the spray nozzle 1tightly by hand (do not use tools)
and ensure that the O-ring 7(Fig. O1) is positioned correctly.
Cleaning:
Release the pressure after each use, empty the container, clean it carefully and
rinse with clear water. Then leave the pressure sprayer open and allow it to
dry. Do not dispose of residual fluids in the sewerage system (local disposal
systems). Always clean the Pressure Sprayer before using a different product
to avoid chemical reactions. When using several Pressure Sprayers, the tanks
and spray nozzle may not be exchanged between them. We recommend
that you have your Pressure Sprayer thoroughly inspected (preferably at
a GARDENA Service Centre) after using it for 5 years.
Storage:
Before storing, loosen the tank cap and always empty your Pressure Sprayer
completely (also after cleaning with water). Store away from frost.
Carry the pressure sprayer by the handle eand not by the pump handle 3.
2. OPERATION
Please observe the safety and proportioning instructions provided by the
manufacturer of the product you are going to spray.
To spray the liquid [Fig. O1/O2/O3]:
1. Push the safety relief valve 6.
2. Unscrew the spray head 1or the dosing cap qand fill the container 2.
3. If necessary, fill in an additive via the dosing cap q.
(Scale wwith 10 and 20 ml).
4. Screw the spray head 1or dosing cap qback onto the container.
5. Pump with the pump handle 3.
6. Adjust the spray jet (clockwise rotation vspray mist; counterclockwise
rotation vspray jet) and the spray angle via the nozzle 4.
7. Push the button 5to spray the liquid.
3. MAINTENANCE
To clean the pressure sprayer:
Always clean your Pressure Sprayer after spraying. Use the Pressure Sprayer
only with clear water (possibly with addition of dish detergent) and spray empty.
The valves, the suction hose and the nozzle 4are cleaned. In the case of
outer dirtying of cover and tank, thoroughly clean the area thread and thread-
O-ring 7.
4. STORAGE
To put into storage:
vClean the pressure sprayer (see 3. MAINTENANCE).
5. TROUBLESHOOTING
To clean the filter [Fig. O1]:
vRemove the filter 0from the suction hose and clean it.
Problem Possible Cause Remedy
Pump does not build up
pressure Spray nozzle 1or cap q
too lightly screwed on.
v Screw on spray nozzle 1
or cap qon tighter.
Pump pipe 8is loose. v Screw on pump pipe 8
tighter.
O-Ring 7is not correctly
positioned.
v Check correct position of
O-Ring 7.
Sealing cap 9is dirty/
defective.
v Clean/exchange sealing
cap 9.
Pressure Sprayer does not
spray although there is
sufficient pressure or only
sprays with a weak spray jet
Nozzle 4is blocked. v Unscrew nozzle 4and clean.
Filter 0is clogged. v Remove filter 0from the
suction hose and clean it.
It is difficult to open and
close the container Container pressure too high. v Release the container pres- sure completely by means of
the safety relief valve 6.
NOTE: For any other malfunctions please contact the GARDENA service
department.
