Garland ED-15THSE User manual

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
Designer Series
Electric Hot Plate
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
Designer Series Electric Hot Plate
Models:
ED-15THSE
Specifications:
Dependable 7-1/2" (192 mm) diameter sealed solid
element hot plate and recessed top ensure quicker
clean-ups. Each plate element is controlled by
a switch with six heat positions. Elements are
protected with a high limit which automatically
reduces power to prevent over heating.
Standard Features:
• Stainless steel front & black painted sides
• Two 7-1/2" (192 mm) diameter sealed elements
• Each element rated 2000 watts
• Each element controlled by a switch with six
heat positions that automatically cycles down
to a low heat when left unused
• Heat-On indicating lamps
• 4" (102mm) stainless steel legs
• One-year limited parts & labor warranty
(USA & Canada only)
Optional Features:
Stainless steel body side
Stainless steel back and bottom
Note : Stand is available see form # CS24/CSD
Model ED-15THSE

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
24"
(610mm)
15"
(381mm)
11-1/4"
(286mm)
11-3/4 "
(298mm)
2-1/4"
(57mm)
4"
(102mm)
Ø7-1/2"
(192mm)
2 Sealed
Solid Elements
Designer Series Electric Hot Plate
Form# ED-15THSE (03/25/2008)
Garland products are not approved or authorized
for home or residential use, but are intended
for commercial applications only. Garland will
not provide service, warranty, maintenance or
support of any kind other than in commercial
applications.
NOTE: - All 208V 1 phase 60 hZ models will be
equipped with a 4-ft (1219mm) power cord and
NEMA L6-30P plug (HUBBELL HBL2621 or
equivalent)
Total kW
Load kW Load Per Phase Nominal Amperes Per Line
Single Phase 3-Phase
208V 240V
208V 240V 208 240 208 240
X-Y Y-Z X-Z X-Y Y-Z X-Z X Y Z X Y Z
4.0 4.0 2.0 2.0 2.0 2.0 19.2 16.7 9.5 9.5 16.7 8.3 8.3 14.4
FOR VOLTAGE OPTIONS OUTSIDE NORTH AMERICA, PLEASE CONTACT THE FACTORY
Overall Dimensions Clearances
Cu. Ft. Shipping
Weight
Installation Entry
H W D Sides Rear Crated Uncrated
11-1/4"
(286mm)
15"
(381mm)
24"
(610mm)
1-1/2"
(38mm)
1-1/2"
(38mm)
18-1/2"
(470mm)
15"
(381mm) 550lbs. (23kg)
