Designer Series
Gas Hot Plate
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
Designer Series Gas Hot Plate
Models:
GD-152H GD-152HFF GD-304H GD-304HFF
Specifications:
Gas designer series hot plates, 15" (381mm) Wide,
GD-152H, two open burners and 30" Wide
(762mm) GD-304H, four open burners. Designed
as free standing or to be banked with other GD
series equipment. 24" (610mm) deep x 11-1/4"
(286mm) high, easy clean design with stainless
steel front and black painted sides. Piezo spark
ignition, natural or propane gas, 14,800 BTU input
per burner. "CE" approved models are equipped
with Flame-Failure protection and have suffix "FF"
Standard Features:
• Stainless steel front and black painted sides
• 4" (102mm) Sanitary legs
• Easy clean design
• 18" (457mm) deep cooking surface
• Piezo spark ignition
• Rear gas connection w/pressure regulator
• Natural or propane gas
• 15" (381mm) or 30" (762mm) widths
• Two or four open burners, one valve per open
burner
• 14,800 BTU per burner
• "CE" approved models are equipped with
Flame-Failure protection and have suffix "FF"
Optional Features:
Stainless steel sides
Stainless steel back and bottom
Note : Stands are available see form # CS24/CSD
Model GD-152H

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
Designer Series Gas Hot Plate
Form# GD-152H/GD-304H (05/07)
MODEL No
Burners
Overall Dimensions Total Input
BTU/Kw
Cu.
FT.
Ship Wt
Lb/kg
Width Height Depth
GD-15H (FF) 2 15" (381mm) 11-1/4" (286mm) 24" (610mm) 29,600/8.67 5 70/32
GD-304H (FF) 4 30" (761mm) 11-1/4" (286mm) 24" (610mm) 59,200/17.34 9 125/57
Clearances To
Combustible Wall Type of
Floor or Base
Sides Back
6" (152mm) 6" (152mm) Combustible
Manifold
Inlet Size
NPT
Manifold Operating Pressure
Natural Propane
“WC mbar “WC mbar
3/4" 4.0 10 10 23.9
Gas Input ratings shown here are for installations
up to 2,000 ft. (610m) above sea level. Specify alti-
tudes over 2,000 ft.
Garland products are not approved or authorized
for home or residential use, but are intended for
commercial applications only. Garland will not pro-
vide service, warranty, maintenance or support of
any kind other than in commercial applications.
21 29/32"
[556mm]
24 15/32"
[621mm]
1 1/2"
[38mm]
1 5/16"
[33mm]
11 25/32"
[299mm]
11 1/4"
[286mm]
24"
(610mm)
15"
[381mm]
WIDTH
