Garmin Approach S2 Instruction manual

Quick Start Manual
操作手冊
快速入门手册
คู่มือ Quick Start
Panduan Cepat Pengoperasian
Approach®S2

2
Approach®S2
Getting Started
WARNING
See the Important Safety and Product
Information guide in the product box for
product warnings and other important
information.
When using the device the rst time, complete
these tasks.
1Charge the device (page 1).
2Turn on the device (page 2).
3Start a round (page 4).
Charging the Device
WARNING
This device contains a lithium-ion battery. See
the Important Safety and Product Information
guide in the product box for product warnings
and other important information.

3
NOTICE
To prevent corrosion, thoroughly dry the
contacts and the surrounding area before
charging or connecting to a computer.
1 Plug the USB cable into a USB port on your
computer.
2 Align the charger posts with the contacts
on the back of the device, and press the
charger ➊ until it clicks.
3 Charge the device completely.
Turning on the Device
The rst time you use the device, you are
prompted to choose your language.
NOTE: The time of day and date are set
automatically when you are outdoors. You can
also set them manually (page 7).
1 Hold .
2 Select your language.
3 Play a game of golf (page 4).

4
Keys
➊Hold to turn the device on
and off.
Select to turn on the
backlight.
➋Select to scroll through
menus, holes, and settings.
➌Select to scroll through
menus, holes, and settings.
➍Hold to open the menu for
the current screen.
OK Select to choose menu
options and acknowledge
messages.
Icons
Battery is low.
Odometer is measuring dis-
tance and time (GPS active).
Alarm is on.

5
Playing Golf
Before you can play golf, you must wait until
the device acquires satellite signals, which
may take 30–60 seconds.
1 Hold .
2 Select Start Round.
3 Select a course from the list.
The device automatically starts on the hole
closest to your present location.
Hole View
The device shows the current hole you are
playing, and automatically transitions when
you move to a new hole.
NOTE: Because pin locations change, the
device calculates the distance to the front,
middle, and back of the green, but not the
actual pin location.
➊Current hole number.
➋Distance to the back of the green.
➌Distance to the middle of the green.
➍Distance to the front of the green.
➎Par for the hole.
Measuring a Shot
1 Hold .

6
2 Select Measure Shot.
3 Walk to your ball.
The distance automatically resets when you
move to the next hole.
Viewing Layup and Dogleg Distances
You can view a list of layup and dogleg
distances for par 4 and 5 holes.
From the hole view (page 4), select .
Layup ➊ and distance to reach the layup
➋appear on the screen.
NOTE: Distances are removed from the list
as you pass them.
Sunrise/Sunset
The sunrise/sunset information is to provide
you the reference of planning a golf play
and tempo to prevent yourself from dim
environment.
Select > Sunrise/Sunset to check the sunrise/
sunset information.
Pause Round
To pause the game, you can press the menu
for the Pause Round function to disable the
device (switch to watch mode) in order to save
battery.
Press Menu for Resume Round if you want to
continue the game.

7
1. When you are at the Hole View page, hold
the menu button to enter the page with
Pause Round function.
2. After you press the Pause Round button, it
will automatically switch back to the watch
mode.
3. To be back to the game, hold the menu
button to see the Resume Round button.
Continue Round
If nishing the rst nine hole, you can press
Continue Round to continue the rest of the
nine holes. The hole information will start from
10.
1. When you are at the ninth-hole, hold the
menu button to Start Scoring.
2. After you nish entering your record, hold
menu to show the Continue Round button,
press it to save your previous nine-hole
scorecard.
3. Hold menu button to Continue Round page,
after you press it will inform you to select a
course.
4. Then it will start from the tenth-hole.
Dual Green
Support Dual Green
Press Change Green to switch green.
1. Hold the menu button to change green if
you are at a course which has dual green.
2. The change will be shown on the upper left
side of the page.

8
Keeping Score
Before you begin keeping score, you must
start a round (page 4).
1 From the hole view (page 4), hold .
2 Select Start Scoring.
3 Select or to set the score.
Your total score ➊is updated.
Reviewing Scores
You can edit individual scores but not the total
score.
1 Hold .
2 Select Scorecard.
3 Select or to select the hole.
4 Select OK to edit.
Viewing Scorecards on a Computer
You can view all saved scorecards on your
computer.
1 Connect the device to a USB port on your
computer using the charging cradle.
2 The device appears as a removable drive in
My Computer on Windows® computers, and
as a mounted volume on Mac®computers.
3 Open ScorecardViewer.html to view your
scorecards.

9
Using the Odometer
You can use the odometer to record the
time and distance traveled. The odometer
automatically starts and stops when you start
or end a round, and you can also start and
stop it manually.
1 Hold or .
2 Select Odometer to view or start the
odometer.
3 Select an option:
• Select > Continue to keep using the
odometer.
• Select > Turn Off to stop the odometer.
• Select > Reset to reset the time and
distance.
Customizing Your Device
Settings
Hold , and select Setup.
Time: Sets the time to automatic or manual
(page 7).
Format: Sets the time format to 12- or 24-
hour.
Tones: Turns audible tones on or off.
Language: Sets the language.
Units: Sets to measure distance in yards or
meters.
Setting the Time Manually
By default, the time is set automatically when
the device acquires satellite signals.
1 Hold .
2 Select Setup > Time > Manual.

10
3 Select or to set the hour and minute.
4 Select AM or PM.
Setting the Alarm
1 Hold .
2 Select Alarm > Set.
3 Select or to set the hour and minute.
4 Select AM or PM.
5 Verify the alarm is set to On.
Viewing Device Information
You can view the software version and unit ID.
1 Hold .
2 Select About.
Appendix
Device Care
NOTICE
Avoid extreme shock and harsh treatment,
because it can degrade the life of the product.
Avoid pressing the keys under water.
Do not use a sharp object to clean the device.
Avoid chemical cleaners, solvents, and
insect repellents that can damage plastic
components and nishes.
Thoroughly rinse the device with fresh
water after exposure to chlorine, salt water,
sunscreen, cosmetics, alcohol, or other harsh
chemicals. Prolonged exposure to these
substances can damage the case.
Do not store the device where prolonged
exposure to extreme temperatures can occur,
because it can cause permanent damage.

11
Cleaning the Device
1 Wipe the device using a cloth dampened
with a mild detergent solution.
2 Wipe it dry.
Specications
Battery type Lithium-ion
Battery life Watch only: 3 weeks
Playing golf: 8 hours
NOTE: The actual battery
life of a fully charged battery
depends on how much time
you use GPS, the backlight,
and power save mode.
Exposure to extremely
cold temperatures will also
reduce battery life.
Operating
temperature
From -4º to 140º F (from
-20º to 60º C)
Charging
temperature
From 40º to 104º F (from 5º
to 40º C)
Water
resistance
32.8 ft. (10 m)
NOTE: The device is not
intended to be used while
swimming.
Power Save
After a period of inactivity, the device goes into
power save mode. The device displays the
time and date but does not use GPS. The
device will not enter power save mode if the
odometer is on. You can select to exit
power save mode.

12
Clearing User Data
NOTE: This deletes all user-entered data.
1 Hold and simultaneously.
2 Select Yes.
Getting More Information
• Go to www.garmin.com/intosports.
• Go to www.garmin.com/learningcenter.
• Go to http://buy.garmin.com, or contact
your Garmin® dealer for information about
optional accessories and replacement
parts.
Registering Your Device
Help us better support you by completing our
online registration today.
• Go to http://my.garmin.com.
• Keep the original sales receipt, or a
photocopy, in a safe place.
Updating Software and Courses
Before you can update your device software,
you must download Garmin CourseView
Updater. Go to http://www.garmin.com/support
/courseview_updater.html for more information.
1 Connect the device to a USB port on your
computer using the charging cradle.
2 Start CourseView Updater.
3 Follow the on-screen instructions.
Software License Agreement
BY USING THE DEVICE, YOU AGREE TO BE
BOUND BY THE TERMS AND CONDITIONS
OF THE FOLLOWING SOFTWARE LICENSE
AGREEMENT. PLEASE READ THIS

13
AGREEMENT CAREFULLY.
Garmin Ltd. and its subsidiaries (“Garmin”)
grant you a limited license to use the software
embedded in this device (the “Software”) in
binary executable form in the normal operation
of the product. Title, ownership rights, and
intellectual property rights in and to the
Software remain in Garmin and/or its third-
party providers.
You acknowledge that the Software is the
property of Garmin and/or its third-party
providers and is protected under the United
States of America copyright laws and
international copyright treaties. You further
acknowledge that the structure, organization,
and code of the Software, for which source
code is not provided, are valuable trade
secrets of Garmin and/or its third-party
providers and that the Software in source code
form remains a valuable trade secret of
Garmin and/or its third-party providers. You
agree not to decompile, disassemble, modify,
reverse assemble, reverse engineer, or reduce
to human readable form the Software or any
part thereof or create any derivative works
based on the Software. You agree not to
export or re-export the Software to any country
in violation of the export control laws of the
United States of America or the export control
laws of any other applicable country.

14
Important Safety and
Product Information
WARNING
Failure to avoid the following potentially
hazardous situations could result in death or
serious injury.
Off-Road Navigation Warnings
Some Garmin recreational products are able
to suggest off-road routes for various outdoor
activities, such as biking, hiking, and all-terrain
vehicles. Follow these guidelines to ensure
safe off-road navigation.
• Always use your best judgment and exercise
common sense when making off-road
navigational decisions. The Garmin device is
designed to provide route suggestions only.
It is not a replacement for attentiveness and
proper preparation for outdoor activities. Do
not follow the route suggestions if they
suggest an illegal course or would put
you in an unsafe situation.
• Always carefully compare information
displayed on the device to all available
navigation sources, including trail signs,
trail conditions, weather conditions, and
other factors that may affect safety while
navigating. For safety, always resolve any
discrepancies before continuing navigation,
and defer to posted signs and conditions.
• Always be mindful of the effects of the
environment and the inherent risks of
the activity before embarking on off-road
activities, especially the impact that weather
and weather-related trail conditions can have
on the safety of your activity. Ensure that you

15
have the proper gear and supplies for your
activity before navigating along unfamiliar
paths and trails.
Health Warnings
• Always consult your physician before
beginning or modifying any exercise
program. If you have a pacemaker or other
implanted electronic device, consult your
physician before using a heart rate monitor.
• The device, the heart rate monitor, and other
Garmin accessories are consumer devices,
not medical devices, and could suffer from
interference from external electrical sources.
The heart rate readings are for reference
only, and no responsibility is accepted for the
consequences of any erroneous readings.
Battery Warnings
If these guidelines are not followed, the
internal lithium-ion battery may experience
a shortened life span or may present a risk
of damage to the GPS device, re, chemical
burn, electrolyte leak, and/or injury.
• Do not leave the device exposed to a heat
source or in a high-temperature location,
such as in the sun in an unattended vehicle.
To prevent damage, remove the device from
the vehicle or store it out of direct sunlight,
such as in the glove box.
• Do not disassemble, modify, remanufacture,
puncture or damage the device.
• Do not immerse or expose the device to
water or other liquids, re, explosion, or
other hazard.
• When storing the device for an extended
time period, store within the temperature

16
ranges specied in the printed manual in the
product packaging.
• Do not operate the device outside of the
temperature ranges specied in the printed
manual in the product packaging.
• Contact your local waste disposal
department to dispose of the device/battery
in accordance with applicable local laws and
regulations.
Additional User-Replaceable Battery
Warnings:
• Do not use a sharp object to remove the
battery.
• Keep the battery away from children.
• Never put batteries in mouth. If swallowed,
contact a physician or poison control center.
• Do not disassemble, puncture, or damage
the battery.
• If using an external battery charger, only use
the Garmin accessory approved for your
product.
• Only replace the battery with the correct
replacement battery. Using another battery
presents a risk of re or explosion. To
purchase a replacement battery, see your
Garmin dealer or the Garmin Web site.
• Replaceable coin cell batteries may contain
perchlorate material. Special handling may
apply. See www.dtsc
.ca.gov/hazardouswaste/perchlorate.
Additional Non-User-Replaceable Battery
Warning: Do not remove or attempt to remove
the non-user-replaceable battery.

17
Declaration of Conformity
Hereby, Garmin declares that this product is in
compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
To view the full Declaration of Conformity, go to
www.garmin.com/compliance.
FCC Compliance
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC
rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and may cause
harmful interference to radio communications
if not installed and used in accordance with the
instructions. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and the receiver.

18
• Connect the equipment into an outlet that is
on a different circuit from the GPS device.
• Consult the dealer or an experienced radio/
TV technician for help.
This product does not contain any user-
serviceable parts. Repairs should only be
made by an authorized Garmin service center.
Unauthorized repairs or modications could
result in permanent damage to the equipment,
and void your warranty and your authority to
operate this device under Part 15 regulations.
Industry Canada Compliance
Category I radiocommunication devices
comply with Industry Canada Standard RSS-
210. Category II radiocommunication devices
comply with Industry Canada Standard RSS-
310. This device complies with Industry
Canada license-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that
may cause undesired operation of the device.
Product Environmental Programs
Information about Garmin’s product recycling
program and WEEE, RoHS, REACH, and
other compliance programs can be found at
www.garmin.com/aboutGarmin
/environment.
Software License Agreement
BY USING THE DEVICE, YOU AGREE TO BE
BOUND BY THE TERMS AND CONDITIONS
OF THE FOLLOWING SOFTWARE LICENSE
AGREEMENT. PLEASE READ THIS
AGREEMENT CAREFULLY.

19
Garmin Ltd. and its subsidiaries (“Garmin”)
grant you a limited license to use the software
embedded in this device (the “Software”) in
binary executable form in the normal operation
of the product. Title, ownership rights, and
intellectual property rights in and to the
Software remain in Garmin and/or its third-
party providers.
You acknowledge that the Software is the
property of Garmin and/or its third-party
providers and is protected under the United
States of America copyright laws and
international copyright treaties. You further
acknowledge that the structure, organization,
and code of the Software, for which source
code is not provided, are valuable trade
secrets of Garmin and/or its third-party
providers and that the Software in source
code form remains a valuable trade secret of
Garmin and/or its third-party providers. You
agree not to decompile, disassemble, modify,
reverse assemble, reverse engineer, or reduce
to human readable form the Software or any
part thereof or create any derivative works
based on the Software. You agree not to
export or re-export the Software to any country
in violation of the export control laws of the
United States of America or the export control
laws of any other applicable country.
Limited Warranty
Garmin’s non-aviation products are warranted
to be free from defects in materials or
workmanship for one year from the date of
purchase. Within this period, Garmin will, at its
sole option, repair or replace any components

20
that fail in normal use. Such repairs or
replacement will be made at no charge to
the customer for parts or labor, provided
that the customer shall be responsible for
any transportation cost. This warranty does
not apply to: (i) cosmetic damage, such as
scratches, nicks and dents; (ii) consumable
parts, such as batteries, unless product
damage has occurred due to a defect in
materials or workmanship; (iii) damage caused
by accident, abuse, misuse, water, ood, re,
or other acts of nature or external causes;
(iv) damage caused by service performed
by anyone who is not an authorized service
provider of Garmin; (v) damage to a product
that has been modied or altered without the
written permission of Garmin; or (vi) damage
to a product that has been connected to power
and/or data cables that are not supplied by
Garmin. In addition, Garmin reserves the right
to refuse warranty claims against products
or services that are obtained and/or used in
contravention of the laws of any country. This
product is intended to be used only as a travel
aid and must not be used for any purpose
requiring precise measurement of direction,
distance, location or topography. Garmin
makes no warranty as to the accuracy or
completeness of map data in this product.
THE WARRANTIES AND REMEDIES
CONTAINED HEREIN ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER WARRANTIES EXPRESS,
IMPLIED, OR STATUTORY, INCLUDING ANY
LIABILITY ARISING UNDER ANY WARRANTY
OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, STATUTORY OR
