Garrett PD 6500i User manual

USER MANUAL
PD 6500i
MODEL 11684xx
OUTSIDE USA
International Division
Garrett Metal Detectors
1881 West State Street
Garland, Texas 75042-6797 USA
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.garrett.com
USA
Security Division
Garrett Metal Detectors
1881 West State Street
Garland, Texas 75042-6797 USA
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.garrett.com

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
3
MANUFACTURER CAUTION
Read Thoroughly Before Operating
CAUTION! Use of this equipment in a manner not specied by the manufacturer may result in damage to
property or injury to persons.
Electrical: 100 – 240 V~ +10% – -15%
1.0 - 0.5A
50/60 Hz
Installation Category: II
Pollution Degree: 2
Maximum Relative Humidity: 95% non-condensing
Operating Temperature: -4ºF (-20ºC) to +158ºF (70ºC)
Maximum Altitude: 3000 meters
CAUTION! PD 6500i must be rmly anchored to the oor or optional adhesive oor mounts attached to
reduce the risk of injury to persons or property damage due to accidental knock down.
Warning! Battery Safety: The optional Battery Backup Module and the CMA Interface module contain
rechargeable batteries that may contain small amounts of harmful substances.
• Caution: Do not short circuit. Serious burns may result.
• Caution: Do not dispose of batteries in a re. They may explode.
• Caution: Do not open or mutilate batteries. They may contain an electrolyte which is toxic and harmful
to the skin and eyes.
• Caution: Replace batteries with the same type and number of batteries as originally installed in the
equipment.
• Caution: Do not put the batteries in trash that is disposed of in landlls. When disposing of the battery,
comply with local ordinances or regulations and your company’s safety standards.
• Recycling centers and retailers with recycling programs may be found at www.rbrc.org.
SYMBOLS:
Garrett Metal Detectors and garrett.com are trademarks and registered trademarks of Garrett Electronics,
Inc. If further assistance is required, please contact the factory using contact information on front cover.
Alternating
current
Protective
conductor
terminal
CAUTION!
Risk of
electric
shock
CAUTION!
Refer to
accompanying
documentation
Recycle

PD 6500iUSER MANUAL
4© 2008 Garrett Metal Detectors PN 1532010 REV F1
MEDICAL SAFETY
Garrett Metal Detectors makes every effort to ensure its products are safe for use. Extensive research by
Garrett has produced no information which would indicate that its products have any adverse effects on
medical implants, pregnancy, recording media or magnetic strips. Garrett makes every effort to cooperate
with medical device manufacturers and to communicate with agencies such as the United States Food
and Drug Administration and Health Canada as a means of assuring product safety. The electromagnetic
elds produced by Garrett products are similar to those encountered in the daily environment and meet
U.S. and International standards for electromagnetic emissions.
Garrett recognizes that certain medical devices may have additional requirements which may require
special care. Any recommendations or directives issued by personal physicians or medical device manu-
facturers should be followed. If, for any reason, (e.g. doctors orders, etc.), a patron objects to being
scanned with a metal detector, it is recommended that alternative procedures be used.
The following should be considered when developing a security checkpoint screening plan.
• Trafc Flow - Trafc ow should remain consistent and encourage unrestricted trafc
ow as a means of minimizing the time a person remains within the archway of a walk-
through metal detector.
• AlternativeScreening- Alternative screening methods such as scanning with a hand-
held metal detector, hand searching or denial of access should be clearly dened in
checkpoint screening procedures as approved alternatives to screening with the walk-
through metal detector.
• PersonnelTraining- Security screening personnel should be instructed in the care of
persons with special medical needs and use of alternative screening methods that meet
the requirements of medical practitioners or medical device manufacturers.

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
5
TABLE OF CONTENTS
1. GENERAL DESCRIPTION OF PD 6500i.....................................................................6
1.1 TECHNICAL SPECIFICATIONS....................................................................................7
1.2 REGULATORY INFORMATION.....................................................................................7
1.3 DESCRIPTION OF CONTROLS, DISPLAYS AND ALARMS........................................9
2. INSTALLATION ........................................................................................................... 11
2.1 SITE SELECTION & REQUIREMENTS ...................................................................... 11
2.2 UNIT ASSEMBLY.........................................................................................................16
2.3 MULTIPLE WALK-THROUGH SITE INSTALLATION ..................................................19
2.4 STABILIZING ...............................................................................................................22
2.5 INSTALLATION COMPLETION ...................................................................................22
3. CONTROLS & ADJUSTMENTS .................................................................................22
3.1 MENU TABLE ..............................................................................................................22
3.2 POWER ON / OFF.......................................................................................................23
3.3 SELF TEST..................................................................................................................24
3.4 SUPERVISOR AND ADMINISTRATOR LEVEL ACCESS...........................................24
3.5 DETECTOR SETTINGS ..............................................................................................24
3.6 FACTORY DEFAULT SETTINGS ................................................................................34
3.7 CODE RESET .............................................................................................................35
4. PROGRAM & SENSITIVITY SETTINGS ....................................................................36
4.1 PROGRAM SELECTION.............................................................................................36
4.2 SELECTING SENSITIVITY AND ZONE BOOST SETTINGS......................................36
5. OPERATION................................................................................................................38
5.1 OPERATIONAL TESTING ...........................................................................................38
5.2 OPERATOR RESPONSIBILITIES...............................................................................38
6. MAINTENANCE / TROUBLESHOOTING...................................................................40
6.1 LOCATING AND RESOLVING NOISE SOURCES......................................................40
6.2 ERROR CODE TABLE DIAGNOSTICS.......................................................................42
6.3 REPAIR........................................................................................................................44
6.4 REPLACEMENT PARTS .............................................................................................45
6.5 WARRANTY INFORMATION ......................................................................................47
7. RELAY OPTIONS........................................................................................................48
7.1 AC CONTROL .............................................................................................................48
7.2 DC CONTROL .............................................................................................................48
8. ACCESSORIES...........................................................................................................50
8.1 BATTERY BACKUP MODULE ....................................................................................50
8.2 POWER CORD JUMPER - 10’....................................................................................50
8.3 DESKTOP REMOTE CONTROL.................................................................................51
8.4 MAGNADOLLY WHEEL TRANSPORTER ..................................................................52
8.5 ADHESIVE FLOOR MOUNTS.....................................................................................53
8.6 STABILIZER BARS......................................................................................................53
8.7 CMA INTERFACE MODULE .......................................................................................54
8.8 OPERATIONAL TEST PIECE (OTP) & FLAT TEST PIECE (FTP)..............................54

PD 6500iUSER MANUAL
6© 2008 Garrett Metal Detectors PN 1532010 REV F1
1. GENERAL DESCRIPTION OF PD 6500i
BasicDescription The Garrett PD 6500i(Model #11684xx) is a digitally controlled pulse induction
metal detector.
Memory All program selections and settings are maintained in electrically erasable non-
volatile memory. The unit will maintain all settings even when disconnected
from power. No battery is required for memory retention.
Unique Target The Garrett PD 6500iis an advanced Digital Signal Processor (DSP)-based
Pinpointing walk-through metal detector that provides superior target detection with excel-
lent metal discrimination capabilities. Multiple targets are pinpointed on the left,
center or right side of the body from head to toe within 33 distinct areas using
a unique array of Light Emitting Diodes (LED’s) located on the exit side of each
panel. Independent zone by zone calibration capability insures optimal archway
eld uniformity, regardless of installation challenges.
Improved An improved multi-coil design allows programming for the detection of the
Sensitivity smallest of metallic targets regardless of shape and orientation.
Trafc   Pacing lights with international “wait” ( ) and “proceed” ( ) symbols are
Flow   located on the entrance side of each panel and allow smooth and efcient trafc
ow. The PD 6500i trafc counter tracks the number of patrons that have passed
through the detector, the number of alarms and calculates the alarm percentage.
Security   All settings are secured with a key lock and 3 levels of user access. Further security
is accomplished with a cabinet lock which prevents unauthorized access to cables,
connectors and circuit boards.
Controls/ The PD 6500iutilizes backlit Liquid Crystal Displays (LCD’s) and LED bar
Displays graphs for continuous on-line operating status and self-diagnostic reporting. All
controls and settings are simplied with menu selections and touchpad controls.
Optional Optional accessories include a Battery Back-Up Module for emergency or
Accessories  remote use, Desktop Remote Control, a wheel assembly for easy portabil-
ity, adhesive oor mounts and a computerized Control Monitor Analyzer (CMA)
interface module. CMA software provides network capabilities for remote access to
data collection, alarm statistics and real-time “detector events” for monitoring and
/ or analyzing.
Note: This revised manual describes several new features which are available with
software versions 2.23–1.37 or greater.

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
7
1.1 TECHNICAL SPECIFICATIONS
1.1.1 DIMENSIONS
• Passage Interior: Width: 30” (0.76m) Height: 80” (2m) Depth: 23” (0.58m)
• Overall Exterior: Width: 35” (0.9m) Height: 87” (2.2m) Depth: 23” (0.58m)
• Shipping: Width: 35.5” (0.9m) Height: 92” (2.3m) Depth: 6.5”(0.17m)
• Shipping Weight: 165 lbs (74 kg)
1.1.2 OPERATING CONDITIONS
Temperature: -4ºF (-20ºC) to +158ºF (70ºC)
Humidity: Up to 95% non-condensing.
1.2 REGULATORY INFORMATION
The PD 6500imeets or exceeds industry safety and electromagnetic compatibility
(EMC) standards and conforms to international directives (CE approved).
The PD 6500iis made of scratch and mar resistant laminate with resilient end caps,
a control panel and heavy-duty aluminum crosspiece. A smooth, rounded corner
design ensures no puncturing, cutting or tearing of the skin or clothing or other-
wise causing bodily injury. A key lock panel protects critical circuitry, wires, cables,
data cables and power connectors to prevent tampering or injury.
1.2.1 ELECTRICAL SAFETY
The Garrett PD 6500ihasbeentestedandfoundtocomplywith:
• Canadian Standard - CAN / CSA-C22.2 No. 1010.1 and CAN / CSA- C22.2 No.
1010.1B-97 Safety Requirements for Measurement, Control and Laboratory Use,
Part 1: General Requirements.
• United States Standard - UL 3101-1 1993 Electrical Equipment for Laboratory
Use, Part 1: General Requirements.
• International Standard (CB Certication) - IEC 610010-1 Safety Requirements for
Electrical Equipment for Measurement, Control and Laboratory Use, Part 1:
General Requirements.
• OSHA Regulation 1910.147 De-energizing Equipment.
1.2.2 MAGNETIC FIELD SAFETY
The Garrett PD 6500i has been tested and found to comply with:
• AICGH-0302 (1996), Sub-Radio Frequency (30 kHz and below) Magnetic Fields.
• Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999, “IEEE Standard
for Safety Levels with Respect to Human Exposure to Radio Frequency
Electromagnetic Fields, 3 kHz to 300 GHz.”
• International Commission for Non-Ionizing Radiation Protection (ICNIRP),
“Guidelines for Limiting Exposure to Time-Varying Electric, Magnetic and
Electromagnetic Field (Up to 300 GHz).”
• NBS Special Publication 500-101, “Care and Handling of Computer Magnetic
Storage Media.”

PD 6500iUSER MANUAL
8© 2008 Garrett Metal Detectors PN 1532010 REV F1
• Canada Health and Welfare: Performance Standards (Walk-Through), RPB-SC-18 section
3.2.2 which addresses the issue of electromagnetic effects to cardiac pacemakers.
• Occupational and Safety Health Administration: Radiation Protection Guide, CFR 1910.97
section (2) i.
• National Institute of Law Enforcement and Criminal Justice: Standards for Walk-Through
Metal Detectors for use in Weapons Detecting NILECJ-STD-0601.00 Section 4.11.
• OSHA Regulation 1910.47 (a) (2) (i) Non-Ionizing Radiation.
1.2.3 ELECTROMAGNETIC COMPATIBILITY
The Garrett PD 6500ihasbeentestedandfoundtocomplywith:
• FCC 47 CFR, Part 15, Subpart B: 1998, Class A for Power Line Conducted Emissions.
• FCC 47 CFR, Part 15, Subpart B: 1998, Class A for Radiated Emissions.
• EN 55022: 1998, Radiated Emissions for Class A Information Technology Equipment.
• EN 55024: 1998, for Immunity.
1.2.4 PHYSICAL
The Garrett PD 6500ihasbeentestedandfoundtocomplywith:
• IEC 68-2-27, 29 for Shock and Bump.
• ASTM F1468-95 Section 5.4 Tip Over (requires anchoring).
• IEC 529 IP55 for protection from water and foreign objects.
1.2.5 PRODUCT PERFORMANCE
• The PD 6500iis Transportation Security Administration (TSA) qualied to meet the new
Enhanced Metal Detector (EMD) specication for walk-through metal detectors.
• The Garrett PD 6500i has been tested and found to comply with:
• Federal Aviation Administration (FAA) three-gun test.
• National Institute of Law Enforcement and Criminal Justice Standards #0601.00,
levels 1-5.

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
9
1.3 DESCRIPTION OF CONTROLS, DISPLAYS AND ALARMS
1.3.1 DESCRIPTION OF VISUAL CONTROLS AND DISPLAYS
Figure 1-1
1.3.1.1 BAR GRAPH
The LED bar graph is comprised of a series of lights. The bar graph light activity
represents the level of metal detection intensity occurring within the archway. The
detection intensity is dependent upon the quantity and composition of the metallic object(s),
and the program and sensitivity settings of the unit.
The bar graph also indicates the presence of electrical interference and interference from
nearby moving metallic objects.
1.3.1.2 READY LIGHT
The green READY light appears when power is on and the PD 6500iis ready to detect
metal. The ready light must be illuminated before a patron is permitted to enter the walk-
through. A rapidly blinking ready light is an indication that AC power has been discon-
nected and the unit is operating on the optional battery backup system.
1.3.1.3 BACKLIT LCD
The LCD is a visual display located in the overhead panel. The LCD reports calibration
and operational information, including program and sensitivity settings, operator functions
and fault indication. The LCD displays all self-prompting regulation and control functions
as well as trafc count information.
1.3.1.4 ALARM LIGHT
The red ALARM light is a visual indication of an alarm when the unit detects a targeted
amount of metal within the walk-through according to the program and base sensitivity
settings. When a target is detected the alarm light appears even if audio volume is off.
1.3.1.5 TOUCHPAD KEY LOCK
Disables touchpad to prevent tampering.
TOUCHPADS TOUCHPAD KEY LOCK

PD 6500iUSER MANUAL
10© 2008 Garrett Metal Detectors PN 1532010 REV F1
1.3.1.6 TOUCHPADS
Use to turn unit on, access and adjust setup and programming. Function of touchpad
depends upon key lock and user access level.
1.3.1.6.1 OPERATE (ON / TEST)
The OPERATE touchpad is used to turn the PD 6500i on. The unit will be ready to operate
within ten seconds. Activate the manual self-test at any time by pressing OPERATE.
1.3.1.6.2 OFF
The OFF touchpad is used to turn the PD 6500i off, ensuring that all of the information and
settings are stored in memory until the detector is ready to resume full operation.
1.3.1.6.3 COUNTER
The COUNTER touchpad is used to obtain an automatic update on the trafc count that
appears on the LCD. The counter also reports alarm statistics such as alarm count and
alarm count %. If operator access is enabled, the counter may be reset by pressing the
COUNTER touchpad for approximately ten seconds.
1.3.1.6.4 VOLUME
The VOLUME touchpad is used to access the volume control of the audio alarm.
1.3.1.6.5 (+) and (–)
The plus (+) and minus (–) touchpads are used to change numerical settings, activate certain
on/off functions and adjust the volume of the audio alarm.
1.3.1.6.6 PROGRAM
The PROGRAM touchpad enables the user to view the current program and base
sensitivity settings on the LCD.
1.3.1.6.7 ACCESS
The ACCESS touchpad is used to initiate the log-in process and to scroll through menu
items.
1.3.1.7 PACING LIGHTS
Pacing lights located on side panels of the entrance side indicate whether or not a patron
may enter the walk-through. The green “proceed” ( ) symbol indicates the unit is ready for
a patron, while the red “wait” ( ) symbol indicates the patron should wait. (See Figure
1-2.)

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
11
1.3.1.8 PINPOINT LIGHTS
Pinpoint lights are located on the exit side of each panel and provide location information
using 11 vertical and 3 horizontal positions for a total of 33 pinpoint areas. These lights
help the operator to identify the precise location of a metal object within the walk-through,
whether it is on the left, right or in the center of the body, from head to toe. (See Figure 1-3.)
ENTRANCE EXIT
Figure 1-2 Figure 1-3
1.3.2 DESCRIPTION OF AUDIO RESPONSES
1.3.2.1 TARGET ALARMS
The steady, single pitch audio alarm indicates that a target has been identied according to the
program and sensitivity settings.
1.3.2.2 WARBLE ALARM
A quickly alternating two-tone alarm occurs when a very large metal object, such as a wheel-
chair, piece of furniture or metal container, moves through or near the PD 6500iand overloads
the detector’s circuits. The warble sound prompts the operator to correct the situation before
allowing anyone to pass through the metal detector.
1.3.2.3 TAMPER ALARM
When the ACCESS touchpad is pressed, the detector beeps for about ten seconds until a
valid user is selected and a numeric access code is entered. If a person or object passes
through the archway during this time, a loud low-toned alarm will activate. If an invalid code
is entered, the message: ACCESS DENIED appears on the LCD, and an audible tamper
alarm momentarily sounds and normal operation resumes.
2. INSTALLATION
2.1 SITE SELECTION & REQUIREMENTS
Before choosing a site for the PD 6500iWalk-Through Metal Detector, it is important to
consider the volume and throughput requirements of patron trafc, space availability and
overall environmental conditions. The PD 6500imust always be installed on a level, stable
oor. The following site requirements are provided as a guide to successful installation.
LED pacing lights
(red=wait; green=walk)
LED pinpoint detection
lights (red)

PD 6500iUSER MANUAL
12© 2008 Garrett Metal Detectors PN 1532010 REV F1
Garrett Metal Detectors has years of experience designing, installing and
operating security screening checkpoints. Garrett’s experience ranges from very small—
one and two detector checkpoints—to very large, 900-detector Olympic operations. Garrett
always prefers to work closely with its clients when designing checkpoints. Every client has
a unique situation and needs a somewhat customized solution. Garrett is happy to assist in
designing and implementing these solutions. This section is intended to provide general in
formation for designing security screening checkpoints.
2.1.1 ELECTRICAL POWER
Electricity is a critical element for successful, trouble-free installations. Garrett metal detectors
require 100-240 Volt, 50/60 Hertz power, and draw less than 2 amperes each. Consequently,
“power load” is minimal for any group of detectors.
Due to their pulse induction technology, it is required that all PD 6500iunits
within 25’ to 100’ of each other be connected to the same phase of the AC power source;
otherwise, a Master / Slave conguration must be used. (See Section 2.3.)
Connecting to a single power source can be easily accomplished using extension power cords
connected to the same outlet if existing power does not, or cannot, meet this requirement. An
optional 10’ power cord jumper is available to simplify this connection. (See Section 8.2.)
Garrett metal detectors are very versatile and can be connected to power from either
the top or bottom of either side. This makes connecting power very convenient and gives
users more options when designing their sites. When “running” power along the ground it is
recommended that cords be secured to the ground using highly visible industrial tape or cable
trays. This ensures that the cord is visible to patron trafc and prevents personal injury as well
as equipment damage. When “running” power overhead it is recommended that power cords
be suspended above the detector. This keeps the cord accessible for maintenance, but out of
reach of regular trafc.
2.1.2 PHYSICAL SITE
Appropriate selection and preparation of a site is paramount for successful, efcient and
effective checkpoint screening operations. The site must be at, level and free from obstruc-
tions. The surface must be solid and free from any vibration or movement. Most indoor
surfaces are already adequate. Outdoor surfaces should be asphalt or concrete; wooden or
metal platforms can NOT be used. The site should be free from running or standing water and
should provide protection from weather elements. An industrial, four-walled tent is the best
way to provide shelter from the weather elements when outdoors. The tent must be strong
enough to repel rain, snow, sleet and a fair amount of wind.
2.1.3 CHECKPOINT CONFIGURATION
A site must also allow for efcient spacing and conguration of metal detectors. If a
site is too small the operation of the checkpoint becomes “choked” and “bottlenecks”
form. This severely hampers the ow of “trafc” through a checkpoint and can be troublesome
when trying to operate within time constraints. If a site is too big it becomes difcult to oversee
the checkpoint, and valuable space is wasted. As a general rule a rectangular block of space,

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
13
8’ wide and at least 10’ deep, should be reserved for every checkpoint lane. There are many
ways to arrange detectors at a checkpoint. Garrett has found the following congurations to
work best. Please refer to the following illustrations.
See Section 2.3 for additional equipment spacing requirements and set-up information.
Pacer
Wanding Area
Staff Member
X-Ray
or
Search Table
Detector
Operator
12” (30 cm)
min
Traffic Flow
24” (60 cm)
min
Bag Screener
Pacing Line
SUGGESTED SINGLE LANE CONFIGURATION

PD 6500iUSER MANUAL
14© 2008 Garrett Metal Detectors PN 1532010 REV F1
Pacer
Pacer
Pacer
Wanding Area
Staff Member
Wanding Area
Staff Member
Wanding Area
Staff Member
X-Ray
or
Search Table
Detector
Operator Operator Operator
12” (30 cm)
min
X-Ray
or
Search Table
Detector
12” (30 cm)
min
Traffic Flow
24” (60 cm)
min
Traffic Flow
Pacing Line
24” (60 cm)
min
Traffic Flow
24” (60 cm)
min
Bag Screener
Bag Screener
Pacing Line Pacing Line
X-Ray
or
Search Table
Detector
12” (30 cm)
min
Bag Screener
SUGGESTEDMULTI-LANECONFIGURATION–A

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
15
SUGGESTEDMULTI-LANE,BACK-TO-BACKCONFIGURATION–B
Traffic Flow
Traffic Flow
Pacer
Wanding Area
Staff Member
Detector
X-Ray
or
Search Table
12” (30 cm)
min
12” (30 cm)
min
Detector
Pacer
Pacer
OperatorOperator
Wanding Area
Staff Member
2” (5 cm)
min
2” (5 cm)
min
DetectorDetector
Pacer
Bag Screener
Bag Screener
Bag Screener
OperatorOperator
Traffic Flow
Traffic Flow
X-Ray
or
Search Table
X-Ray
or
Search Table
X-Ray
or
Search Table
12” (30 cm)
min
12” (30 cm)
min
24” (60 cm)
min
24” (60 cm)
min
Pacing LinePacing Line

PD 6500iUSER MANUAL
16© 2008 Garrett Metal Detectors PN 1532010 REV F1
2.1.4 INTERFERENCE
Many variables can potentially cause interference with any metal detector operation.
However, there are some major variables which may be identied and addressed during
site selection. Electrical sources of interference including generators, transformers, elec-
trical panels, etc., should be kept as far away as possible. Large moving or stationary
metallic objects such as revolving doors, elevators, garbage cans, barricades, etc., should
be kept as far away as possible. Search tables and personnel should be placed a
minimum of 6” from the detector. X-ray machines and other complementary screening
equipment should be placed a minimum distance of 12” from the detector.
See section 6.1 for information about identifying and resolving sources of interference.
2.2 UNIT ASSEMBLY
Assemble the unit and position at the checkpoint location, connect to power, set desired
program / operating procedures, check for interference and perform necessary tests.
2.2.1 ASSEMBLY
The enclosed instructional video provides detailed assembly instructions.
1. Verify that the following contents are included:
• Panel “A”
• Panel “B”
• Detection Unit (Head)
• Crosspiece (Support Brace)
• 2’ AC Jumper Cord
• 10’ Power Cord
• Eight 1/4-20x3” Screws
• Eight Finishing Washers
Accessories:
• User Manual
• Instruction DVD
• Pocket Item Container (Coin Tray)
• Stabilizing Plates (Optional)
2. Arrange the major components as shown in Figure 2–1.
Figure 2-1

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
17
3. Place the packing insert on oor as shown in Figure 2–2.
Lay detection unit (with touchpad panel facing down) on packing insert. Connect detection
unit to panels A and B using four screws and nishing washers. Do not tighten!
Figure 2-2
4. Connect Panel Cables
Open the door of the detection unit. Connect cables A and B into the corresponding
panels. (See Figure 2–3.)
Figure 2-3
PANEL B
PANEL A
CABLE RECEPTACLE

PD 6500iUSER MANUAL
18© 2008 Garrett Metal Detectors PN 1532010 REV F1
5. Determine the location of the AC power outlet and select a power connection means. If
power is to be supplied from an overhead source, remove the rubber access plug in the
top of the detection unit, feed the power cord (or the 2’ AC jumper cord if required) into the
detection unit and plug directly into the power module.
If power is to be supplied at oor level, determine the panel that is nearest the power
outlet. Within the Detection Unit, plug in the 2’ AC jumper cord from the selected panel
to the power module. Retrieve the power cable at the bottom of the entrance side of the
selected panel through the 1½ inch diameter opening in the bottom of the boot. Slip the
power cord into the clamp, as shown in Figure 2-4, to prevent pinching and abrasion when
the unit is set upright. Secure the connection with electrical tape or other means if required.
Figure 2-4 Figure 2-5
6. Use the four remaining screws and washers to attach the crosspiece to the two panels.
(See Figure 2–5.)
7. If optional adhesive oor mounts are to be used, attach the mounting plates to side panels.
Do not remove adhesive protectors at this time. Follow instructions provided in the
mounting kit.
8. Use two or more people to lift the PD 6500ito a vertical position and move to desired location.
(See Figure 2–6, below.)
Figure 2-6
NOTE: Wrap plugs with
electrical tape if needed.

© 2008 Garrett Metal Detectors PN 1532010 REV F1
PD 6500iUSER MANUAL
19
9. Ensure the PD 6500i is physically stable and does not sit on top of power cord.
10. Tighten all screws with a screwdriver.
2.2.2 POWER CORD WIRING DESCRIPTION
The PD 6500i(Model 11684xx) includes a standard American ground power cord. To replace
or remove plug, or to hard wire to an AC junction box, use:
Green To Ground
Black To line Hot
White To line Neutral
The PD 6500i (Model 1168420) (INTERNATIONAL) includes a European power cord. To
replace or remove plug, or to hard wire to an AC junction box, use:
Green/Yellow To Ground
Brown To line Hot
Blue To line Neutral
 2.3   MULTIPLEWALK-THROUGHSITEINSTALLATION
For multiple walk-through metal detector (WTMD) operation (units within 25’ to 100’ of each
other depending on sensitivity setting), certain power requirements and installation
adjustments are necessary to avoid crosstalk (interference) among units.
There are several ways to successfully install multiple walk-throughs in close proximity with no
crosstalk. The following examples are aimed to help the installer determine an appropriate
method for eliminating crosstalk.
2.3.1 CASE 1
Description:
• All detectors are PD 6500is. (See Figure 2–7.)
• All detectors are connected to the same AC-Line Phase.
Figure 2-7
Procedure:
1. Set all PD 6500is synchronization to Sync: MASTER.
2. Set end unit to CHANNEL 1.
3. Set next unit to CHANNEL 2.
4. Set next unit to CHANNEL 1.
5. Repeat alternating pattern for channels 1 and 2 for any additional PD 6500is.
Master
CH1
PD-6500i
PD-6500i
Master
CH2
2”
(5 cm)
min.
Master
CH1
PD-6500i
PD-6500i
Master
CH2
10 ft. (3m)
min.
2”
(5 cm)
min.

PD 6500iUSER MANUAL
20© 2008 Garrett Metal Detectors PN 1532010 REV F1
2.3.2 CASE 2
Description:
• All detectors are PD 6500is. (See Figure 2–8.)
• Detectors are connected to different AC-Line Phases or operating from battery back-up.
Master
CH1
PD-6500i
PD-6500i
Slave
CH2
Slave
CH1
PD-6500i
PD-6500i
Slave
CH2
10 ft. (3m)
min.
Procedure:
1. Switch units off and disconnect PD 6500is from power line.
2. Open access door of detection unit.
3. Remove the three screws that hold controller cover. (See Figure 2-9.)
4. Use synchronization wire (18 to 24-gauge, 2 conductor) between units; connect to pins
1 and 2 as shown in Figure 2-10 and on inside of controller cover. Connector block is a plug
in and may be removed to facilitate connection of the wires.
5. With the exception of the end units, the SH1 jumper, located on the controller board
assembly must be removed. (See Figure 2-10.)
6. Replace cover and reconnect power.
7. Set the end unit (i.e., rst or last in a series of PD 6500is) synchronization to MASTER
CHANNEL 1 and make sure it is always connected to either AC power or battery power.
8. Set all other units synchronize to SLAVE.
9. Set the remaining units alternately to CHANNEL 2 and CHANNEL 1 as shown.
10. Repeat alternating pattern of channels 1 and 2 for any additional PD 6500is.
Figure 2-10
Figure 2-9
Controller
Cover
Screws
Remove
SH1
Jumper SH1
Synchronization wires
Figure 2-8
2”
(5 cm)
min.
2”
(5 cm)
min.
