Gazer MMR51 SERIES User manual

Gazer MMR51хх/MMR71хх
MUR51хх/MUR71xx
USER MANUAL
CAR REARVIEW MIRROR WITH BUILT-IN MVR

RU
ENG
UA
User manual ............................................... 4
Руководство пользователя ........................ 15
Посібник користувача ............................... 27

ENG
4
Contents
1. Warning ............................................................................. 5
2. Important information.......................................................... 6
3. Package contents................................................................. 7
4. Controls ............................................................................. 8
5. Usage ...............................................................................10
6. Mirror installation ...............................................................13
7. Specications.....................................................................14

5
ENG
Warning
Congratulations on your purchase of Gazer
car rearview mirror with built-in MVR.
Please read this manual carefully, before using the device.
Warnings
• Do not use chemicals to clean the device. Please use a soft cloth to
clean the body, mirror surface and lens.
• Avoid shocks, falls and mechanical damage to the device.
• Do not use or store the device in hot or cold places.
- Storage temperature: of -30°C to +70°C
- Operating temperature: of -20°C to +65°C
• Do not attempt to repair the appliance yourself. In case of any
damage contact your dealer or service center.
• To install and connect the mirror without voiding your car’s war-
ranty, please consult with the personnel of service stations where
your car is serviced.
• The manufacturer is not responsible for any losses or missed op-
portunities due to use of videos and data obtained with the help of
this device.

ENG
6
Important information
Warning!
• Do not insert or remove the SD card when the device is on. This
can lead to the built-in MVR malfunction. Wait for 30 seconds
after MVR shut down and only then safely remove the memory
card.
• Set the correct time and date before using the device.
• Use at least 0.5 seconds time interval while pressing control
buttons, this guarantees proper functioning of the device.
• When connecting the device, use only the original power supply
cable.
• If after you have started the car (when the power supply cable is
connected to the MVR), the device failed to switch to the recor-
ding mode automatically, simply unplug the power supply cable
for ten seconds and then try again.
• Use the restart option by (long pressing ON/OFF button) in the
following cases:
• power indicator is not on when the power supply cable is con-
nected;
• the device does not switch from the standby to the recording
or control mode;
• the device fails to function properly.
• Files protected from overwriting by G-sensor are recorded in a
loop with a 15 les limit. Closely monitor the free space remaining
on the memory card to avoid loss of protected les due to loop
overwriting that takes place within the limits allocated for such
les on the memory card.

7
ENG
Package contents
Rearview Mirror with
built-in MVR Gazer
MMR51xх/MMR71xх
MUR51xх/MUR71xх
The cable to connect the
camera power is +12V
Switching unit
The remote control
Pad on the
windshield for
cable management
User manual

ENG
8
Controls
Fig. 1
1. Built-in display 4,3’’
2. Mirror
3. Status indicator
4. Mirror ON/OFF button –
switch on/switch off the
monitor; reset switch ( by
long pressing); adjust the
monitor brightness setting (in
the mode broadcast signal
from rear-view camera).
5. Interior light sensor
6. Switching unit connection
socket
7. Lens
8. Exterior light sensor
9. Back CAR SIGNAL –control
wire.
10. АСС+, GND, BAT+ –wires
supply.
11. Filter unit/fuse
12. DC 12V –camera’s power
wire.
13. Camera – video input for
rear-view camera.
14. Mirror connection socket
1
14
10
6
7
11 9
2
3
4
5
ACC+(red)
BAT+
Back CAR SIGNAL (green)
GND (black)
(video input)
Camera
DC 12V
(camera power)
FUSE
13
12
8

9
ENG
Fig. 2
1. POWER –switch on/switch
off the display.
2. SEL/REC –stop/start
recording; activation of the
setting.
3-4. UP/DOWN –navigation
menu.
5. The lines parking set-
tings button
6. MODE –switch between
video.
7-8. The line parking angle
setting button
9. MENU –input/output menu.
Controls
POWER SEL/REC
DOWN/
MODE
P
UP/MENU
1 2
3
4
5
6
78
9

ENG
10
Usage
• Car Rearview Mirror with built-in monitor and Super HD MVR
Gazer MMR51xх/MMR71xх/MUR51xх/MUR71xх is designed as a
replacement of the original mirror. The last digit of «xх» labeling
model indicates the type of mounting on the windshield compatible
with the bracing of certain car models.
• Gazer mirrors series MMR51xх/MMR71xх/MUR51xх/MUR71xх have
a built-in 4.3’’(16:9) display supporting two video inputs and PAL or
NTSC videostandards (the monitor automatically detects the signal
format and switch to operate in the desired standard).
• When the built-in MVR is on, the image will be continuously displayed
on the screen. Use the ON/OFF button to switch the built-in display
on or off (the MVR will continue recording).
•Camera video input is designed for receiving video feed from the
rear-view camera. When the car is driving in reverse (with video feed
provided by the rear-view camera), the image will be displayed on
the built-in monitor. Camera video input is prioritized: when the
MVR and the rear-view camera provide video feed simultaneously,
the monitor automatically switches to the rear-view camera viewing
mode. If the monitor was turned off by pressing the ON/OFF button,
it will turn on automatically when the Camera video input receives
video feed and turn off when the video feed is terminated. When
the rear-view camera is turned on, the MVR recording does not stop.
• Gazer MMR71xx/MUR71xx/MMR51xx/MUR51xx built-in monitor has
an automatic brightness adjustment function. This function is enabled
by default, and depending on the lighting conditions inside the car,
the monitor will automatically adjust the screen brightness to the
required level.
• When the built-in display receives video feed from the rear-view
camera, one can adjust the brightness setting by pressing the ON/
OFF button (brightness is set at a minimal level by default). The
selected brightness level will be stored in the device memory and
the next time the display is turned on, the brightness level will be set
automatically based on the last setting.

11
ENG
Usage
Note: Use the remote control that comes in the supply package to
set up and control the mirror.
1. Interface language setting. Stop the recording by pressing the SEL/
REC button and then go to the settings menu by double pressing the MENU
button. Use the UP/DOWN buttons to navigate to the «Language» item
and select the interface language. You may then resume the recording by
pressing the SEL/REC button.
2. Date and time setting. The mirror allows adding date and time
watermarks to recorded videos. To set the correct date and time, stop the
recording by pressing the SEL/REC button and then go to the settings
menu by double pressing the MENU button. Use the UP/DOWN buttons
to navigate to the «Date and time» item and set the desired date and time.
You may then resume the recording by pressing the SEL/REC button.
3. Video resolution setting. The MVR supports the following video
recording resolutions:
2560x1080 @30fps; 2304x1296 @30fps; 1920x1080
@45fps; 1920x1080 @30fps; HDR1920x1080 @30fps; 1280x720 @60fps;
1280x720 @30fps.
To select the recording resolution, rst stop the
recording by pressing the SEL/REC button and then go to the settings
menu by double pressing the MENU button. Use the UP/DOWN buttons to
navigate to the «Video resolution» item and select the required parameter.
You may then resume the recording by pressing the SEL/REC button.
4. Loop recording. To enable/disable the МVR’s loop recording function,
rst stop the recording by pressing the SEL/REC button and then go to
the settings menu by double pressing the MENU button. Use the UP/
DOWN buttons to navigate to the «Loop recording» item and select the
required value from the available parameters. You may then resume the
recording by pressing the SEL/REC button.
Recommendation: Selecting the shortest duration of recorded
video clips allows minimizing pauses between them.
5. Automatic power-up on ACC signal. The mirror supports automatic
activation of the recording mode when АСС signal is transmitted (this function
is enabled by default). To disable this function, rst stop the recording by
pressing the SEL/REC button and then switch to the settings menu by
double pressing the MENU button. Use the UP/DOWN buttons to navigate
to the «Recording activation» item and select the required parameter. You
may then resume the recording by pressing the SEL/REC button.
6. G-sensor. The mirror features a built-in G-sensor (a three-axis
accelerometer) that traces any sharp changes in the vehicle’s driving pattern
(hard braking, acceleration, and impacts). Files recorded when the G-sensor
is tripped are automatically protected from deletion due to loop overwriting

ENG
12
Usage
and stored in a separate «EVENT» folder (a maximum of 15 les) where loop
overwriting feature also applies. This recording principle ensures the device’s
continuous operation with no additional maintenance required – the space
on the SD card is freed up automatically.
To adapt the G-sensor to external operating conditions, the mirror allows
adjusting the sensor’s sensitivity. To set the G-sensor sensitivity, rst stop
the recording by pressing the SEL/REC button and then go to the settings
menu by double pressing the MENU button. Use the UP/DOWN buttons
to navigate to the «G-sensor sensitivity» item and select the required value
from the available parameters. You may then resume the recording by
pressing the SEL/REC button.
7. Motion sensor. Thanks to the motion sensor, the built-in МVR supports
automatic activation of the recording mode upon detection of motion in the
frame as well as automatic deactivation of this mode 2 seconds after the
motion in the frame stops. To enable and congure this function, rst stop
the recording by pressing the SEL/REC button and then go to the settings
menu by double pressing the MENU button. Using UP/DOWN buttons
navigate to the «Motion sensor» item to enable/disable the function or to
«MD sensitivity» item to select the sensitivity level.
8. Parking mode. When the parking mode is activated, the built-in MVR
will continue recording up to 12 hours after the ACC signal is terminated.
In this case, the monitor and status indicators will be turned off. To enable
this function, rst stop the recording by pressing the SEL/REC button and
then go to the settings menu by double pressing the MENU button. Use the
UP/DOWN buttons to navigate to the «Parking mode» item and select the
desired MVR operation time from the available parameters.
Note: Car Rearview Mirror with built-in MVR Gazer has the minimal
system voltage control function. As soon as the specied level 11,7V is
reached, the MVR shuts down and the parking mode will not be active.
This makes it possible to prevent the vehicle’s battery from discharging
to a critical level after which it will be impossible to start the car engine.
9. LDWS+FCWS intelligent technologies. The device utilizes intelligent
LDWS (Lane Departure Warning System) and FCWS (Forward Collision
Warning System) systems. LDWS system is designed to alert the driver
about the departure from a chosen lane. FCWS will promptly warn you about
the violation of a safe distance between your car and another vehicle thus
helping avoid a possible accident or collision.
To enable and congure this function, rst stop the recording by pressing the
SEL/REC button and then go to the settings menu by double pressing the
MENU button. Using UP/DOWN buttons navigate to the «LDWS»/«FCWS»
item to enable/disable the function or to «Calibration» item to calibration of
the systems.

13
ENG
Mirror installation
Connect the black wire (GND) to the car chassis, the yellow BAT+ wire -
directly to the +12V terminal of the car battery or to the power line with
the constant voltage of +12V.
Connect the red wire (ACC+) to the car’s +12V ACC+ power wire (ACC
power turns on when the car engine starts and turns off when it stops).
Connect the green wire (Back CAR SIGNAL) to the +12V power wire
of the rear lights. In this case, whenever the reverse gear is engaged,
the mirror will switch to the rear-view camera mode.
Connect the Camera video input jack with the rear-view camera video
output jack (VIDEO OUT). Connect the switching unit jack to the
corresponding jack on the mirror.
Fig. 3
ACC+(red)
Back CAR SIGNAL (green)
GND (black)
BAT+ (yellow)
(video output) (video input)
VIDEO OUT Camera
DC 12V
(camera power)
Rear-view camera
FUSE

ENG
14
Specications
Display TFT LCD 4,3”
Display resolution 480х272 (16:9)
Display brightness 1000 cd/m2
Video Input CVBS (RCA)
Signal format PAL/NTSC auto-detect function
Processor Ambarella A7
Memory Card Support micro SDHC, up to 32 Gb
Auto-dimming Yes*
Sensor 1/3” CMOS
Viewing angle 140°
Video resolution
2560x1080 @30fps
2304x1296 @30fps
1920x1080 @45fps
1920x1080 @30fps
HDR1920x1080 @30fps
1280x720 @60fps
1280x720 @30fps
Video characteristics MP4, H.264
Audio Built-in microphone and speaker
G-sensor Yes, with additional setting
sensitivity
Motion detector Yes, with additional setting
sensitivity
Parking mode Yes
Minimal system voltage
control function Yes, to the specied level 11,7V
Power supply DC 12V
*for MMR71xх/MUR71xх models.

15
RU
Содержание
1. Меры предосторожности ....................................................16
2. Важная информация ..........................................................17
3. Комплектация ...................................................................18
4. Элементы управления........................................................19
5. Особенности использования...............................................21
6. Подключение зеркала........................................................25
7. Технические характеристики..............................................26

RU
16
Меры предосторожности
Поздравляем Вас с приобретением автомобильного
зеркала заднего вида Gazer со встроенным видеорегистратором.
Перед использованием устройства, пожалуйста, внимательно
ознакомьтесь с данным руководством.
Меры предосторожности
• Не используйте химические средства для чистки устройства.
Пожалуйста, используйте мягкую ткань для очистки корпуса,
зеркальной поверхности и линзы объектива.
• Избегайте ударов, падений и механических повреждений
устройства.
• Не используйте и не храните устройство в слишком холодных
или горячих местах.
- Температура хранения: от -30°С до +70°С
- Температура использования: от -20°С до +65°С
• Не пытайтесь ремонтировать устройство самостоятельно. В
случае возникновения каких-либо поломок, обратитесь к
продавцу или в сервисный центр.
• Во избежание потери гарантийного обслуживания на Ваш
автомобиль, для установки и подключения устройства,
пожалуйста, обратитесь к специалистам СТО, на котором
производится обслуживание Вашего автомобиля.
• Завод-производитель и продавец не несут ответственности за
убытки, а также упущенную выгоду, возникшие в результате
использования или потери информации, полученной с помощью
данного устройства.

17
RU
Важна информация
Внимание!
• Не вставляйте и не вынимайте SD-карту памяти при
включенном питании. Это может привести к нарушениям в
работе встроенного видеорегистратора. Перед установкой
или извлечением карты памяти убедитесь, что питание
устройства отключено не менее 30 секунд назад.
• Перед началом эксплуатации обязательно выполните точную
настройку даты и времени.
• Для корректной работы видеорегистратора интервал времени
между нажатием кнопок управления должен составлять не
менее 0,5 секунды.
• Для подключения устройства используйте только
оригинальный кабель питания, который поставляется в
комплекте.
• Используйте перезагрузку видеорегистратора с помощью
длительного нажатия кнопки ON/OFF (на корпусе зеркала)
в следующих случаях:
• после подключения кабеля питания отсутствует индикатор
питания;
• устройство не переходит из режима ожидания в режим
записи или управления;
• работа устройства не соответствует заданным режимам.
• Файлы, защищенные от перезаписи после срабатывания
G-сенсора, записываются циклически в пределах 15-ти
файлов. Внимательно следите за заполнением карты памяти,
чтобы избежать потери защищенных файлов в процессе
циклической перезаписи в рамках объема, отведенного для
них на карте памяти.

RU
18
Комплектация
Зеркало заднего
вида со встроенным
видеорегистратором
Gazer MMR51xх/MMR71xх/
MUR51xх/MUR71xх
Кабель для
подключения питания
камеры +12В
Блок коммутации и
управления
Пульт дистанционного
управления
Накладка на лобовое
стекло для скрытия
кабеля
Руководство
пользователя

19
RU
Элементы управления
Рис. 1
1. Встроенный дисплей 4,3”
2. Зеркало
3. Индикатор состояния
4. Кнопка ON/OFF –
включение/выключение
монитора; кнопка сброса
(длительное нажатие);
настройка яркости монитора (в
режиме отображения сигнала
с камеры заднего вида).
5. Датчик освещенности в
салоне
6. Разъем подключения к
блоку коммутации
7. Объектив
8. Датчик освещенности
вокруг авто
9. Back CAR SIGNAL – провод
управления.
10. АСС+, GND, BAT+ –провода
подключения питания.
11. Блок фильтра/
предохранитель
12. DC 12V –провод питания
камеры заднего вида.
13. Camera –видеовход для
камеры заднего вида.
14. Разъем подключения
зеркала
ACC+(красный)
BAT+
Back CAR SIGNAL (зеленый)
GND (черный)
(видеовход)
Camera
DC 12V
(питание камеры)
1
14
10
6
7
11 9
2
3
4
5
FUSE
13
12
8

RU
20
Элементы управления
Рис. 2
1. POWER –включение/
выключение дисплея.
2. SEL/REC –стоп/старт
записи; применение
настройки.
3-4. UP/DOWN –навигация по
меню.
5. Кнопка настройки
парковочной разметки
6. MODE –переключение
режимов отображения
видеосигнала.
7-8. Кнопки настройки углов
наклона парковочных
линий
9. MENU –вход/выход из
меню.
POWER SEL/REC
DOWN/
MODE
P
UP/MENU
1 2
3
4
5
6
78
9
