GE AJEQ10DCF Series Operating instructions

Write the model and serial
numbers here:
Model # _________________________
Serial # ____________________________
Find these numbers on a labelonthefrontof
the base pan behind the front grille.
Air Conditioners
GEAppliances.com
Room
49-7710-1 2-14 GE
Safety Instructions ......... 2,3
Operating Instructions .....4-7
Care and Cleaning
AirFilter.......................10-11
Front Grille ........................10
Grille and Case................... 10
OutdoorCoils.................... 10
Installation Instructions
BeforeYouBegin...............12-13
Installing a J-Model in
anExistingWallCase.............14
Through-the-Wall
Installation....................... 15
Troubleshooting Tips ....... 16
Normal Operating Sounds ....... 16
Consumer Support
Consumer Support...... Back Cover
Warranty......................... 19
Owner’s Manual and
Installation Instructions
Español
For a Spanish version of this manual, visit
our Website at GEAppliances.com.
Para consultar una version en español de
este manual de instrucciones, visite nuestro
sitio de internet GEAppliances.com.
Française
For a French version of this manual, visit
our Website at GEAppliances.com.
Pour une version française de ce manuel
d’utilisation, veuillez visiter notre site web
à l’adresse GEAppliances.com.
As an ENERGY STAR®partner, GE has
determined that this product meets the
ENERGY STAR®guidelines for energy efficiency.
*ENERGY STAR®labeled product
Cool Only: AJCM 08, 10 ACF*
AJCM 10, 12 DCF*
AJCQ 06 LCF*
AJCQ 08, 10, 12 ACF*
AJCQ 09, 10, 12 DCF*
Heat/Cool: AJEM 12 DCF*
AJEQ 06 LCF*
AJEQ 08 ACF*
AJEQ 09, 10, 12 DCF*

2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING! Risk of electric shock. Can
cause injury or death. For your safety,
the information in this manual must be followed to
minimize the risk of fire, electric shock or personal
injury.
 Use this appliance only for its intended
purpose as described in this Owner’s Manual.
This air conditioner must be properly
installed in accordance with the Installation
Instructions before it is used.
Never unplug your air conditioner by pulling
on the power cord. Always grip plug firmly
and pull straight out from the receptacle.
 Replace immediately all electric service
cords that have become frayed or
otherwise damaged. A damaged power
supply cord must be replaced with a new
power supply cord obtained from the
manufacturer and not repaired. Do not
use a cord that shows cracks or abrasion
damage along its length or at either the
plug or connector end.
 Turn OFF and unplug your air conditioner
before making any repairs or cleaning.
NOTE: We strongly recommend that any
servicing be performed by a qualified individual.
 For your safety…do not store or use
combustible materials, gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
 All air conditioners contain refrigerants,
which under federal law must be removed
prior to product disposal. If you are getting
rid of an old product with refrigerants, check
with the company handling disposal about
what to do.
SAFETY PRECAUTIONS
WARNING! Risk of electric shock.
Can cause injury or death. This appliance
must be properly grounded. Do not, under any
circumstances, cut or remove the third (ground)
prong from the power cord. For personal safety,
this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall
outlet to minimize the possibility of electric
shock hazard from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
Power cord may include a current interrupter
device. A test and reset button is provided
on the plug case. The device should be
tested on a periodic basis by first pressing
the TESTbutton and then the RESETbutton.
If the TEST button does not trip or if the
RESETbutton will not stay engaged,
discontinue use of the air conditioner and
contact a qualified service technician.
Where a 2-prong wall outlet is encountered,
it is your personal responsibility and
obligation to have it replaced with a properly
grounded 3-prong wall outlet.
WARNING! Risk of electric shock. Can
cause injury or death.
The air conditioner should always be plugged
into its own individual electrical outlet which
has a voltage rating that matches the rating
plate. This provides
the best performance and also prevents
overloading house wiring circuits which
could cause a fire hazard from overheated
wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical
connection requirements.
HOW TO CONNECT ELECTRICITY
SAVE THESE INSTRUCTIONS

3
GEAppliances.com
RISK OF FIRE. Could cause serious injury or
death.
 DO NOT use an extension cord with this
Built-in Air Conditioner.
 DO NOT use surge protectors or multi-outlet
adaptors with this Built-in Air Conditioner.
USE OF EXTENSION CORDS
WARNING! Risk of electric shock. Can
cause injury or death.
 We strongly recommend against the use of
an adapter plug.
 If you must use an adapter, where local
codes permit, a temporary connection may
be made to a properly grounded 2-prong
wall outlet by use of a UL-listed adapter
available at most local hardware stores.
 The larger slot in the adapter must be
aligned with the larger slot in the wall outlet
to provide proper polarity in the connection
of the power cord.
 When disconnecting the power cord from
the adapter, always hold the adapter in
place with one hand while pulling the power
cord plug with the other hand. If this is not
done, the adapter ground terminal is very
likely to break with repeated use.
 If the adapter ground terminal breaks, DO
NOT USE the air conditioner until a proper
ground has been established.
 Attaching the adapter ground terminal to
a wall outlet cover screw does not ground
the appliance unless the cover screw is
metal, not insulated, and the wall outlet
is grounded through the house wiring.
You should have the circuit checked by a
qualified electrician to make sure the outlet
is properly grounded.
USE OF ADAPTER PLUGS
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
WARNING!

Power
Cool
On
High
Med
Low
Off
Fan
Mode
Temp
Delay
Hrs
4
On
Cool
Delay Hrs Temp
Off
On
Mode
Power
On/Off
Off Reset
Filter
Fan
Hi
Med
Low
Air Conditioner Controls
Power On/Off
Turns air conditioner on and off.
Display
Displays the temperature setting. Displays
hours when setting the timer.
Mode
On the remote control, use to set the air
conditioner to Cool or Fan mode.
On the air conditioner controls, use to set
Cool or Fan mode at High, Med or Low fan
speed. Indicator lights on the air conditioner
controls will show the mode and fan speed
selected.
Temp Increase + /Decrease – Pads
Use to set temperature when in COOL mode.
Fan Speeds
Use to set the fan speed at Low, Med or
High.
Delay Hrs
2Q³When the air conditioner is off, it can
be set to automatically turn on in half an
hour to 24 hours at its previous setting. Each
touch will set the time in half hours up to 10
and then in hours up to 24.
To cancel the Delay Timer, press the On pad until
“CL” appears. Then wait until the display turns off.
2II³When the air conditioner is on, it can be set to
automatically turn off in half an hour to 24 hours.
Each touch will set the time in half hours up to 10
and then in hours up to 24.
To cancel the Delay Timer, press the Off pad until
“CL” appears and wait for the set temperature to
be displayed. The unit will now resume normal
operation.
Reset Filter
LED will turn on when fan has accumulated 250
hours of run time as a reminder to clean filter.
Press Reset Filter to turn off the LED and reset the
accumulated run time.
Remote Control Signal Receiver
NOTE: When the air conditioner is turned on, it will
automatically start in the setting last used.
To ensure proper operation, aim the remote
control at the signal receiver on the air
conditioner.
The remote control signal has a range of up to
21 feet.
Make sure nothing is between the air conditioner
and the remote control that could block the
signal.
Make sure batteries are fresh and installed
FRUUHFWO\³VHHWKH&DUHDQG&OHDQLQJVHFWLRQ
Remote Control
$ERXWWKHFRQWUROVRQWKHDLUFRQGLWLRQHU³&RRO2QO\0RGHOV
Appearance may vary.
Remote Control
Lights beside the touch pads on the air conditioner
control panel indicate the selected settings.
Controls

5
GEAppliances.com
Cool Mode
Remote Control
1. Press Cool pad.
2. Press Low, Med or High pads to set desired fan speed.
3. Press the Increase +/ Decrease –pads to set
the desired temperature 60°F to 85°F in 1°F
increments.
Control Panel
1. Press the Mode pad until the Cool indicator light is lit
and the Low, Med or High indicator light is lit for the
desired fan speed.
2. Press the Increase + / Decrease – pads to set the
desired temperature 60°F to 85°F in 1°F increments.
A thermostat is used to maintain the room temperature.
The compressor will cycle on and off to keep the room
at the set level of comfort. Set the thermostat at a lower
number and the indoor air will become cooler.
Set the thermostat at a higher number and the indoor air
will become warmer.
NOTE:If the air conditioner is off and is then turned on
while set to Cool, it will take approximately 3 minutes
for the compressor to start and cooling to begin.
Cooling Descriptions
)RU1RUPDO&RROLQJ³Select the Cool mode and High or
Med fan with a middle set temperature.
)RU0D[LPXP&RROLQJ³Select the Cool mode
and HIGH fan with a lower set temperature.
)RU4XLHWHUDQG1LJKWWLPH&RROLQJ³Select the Cool
mode and Low fan with a middle set temperature.
NOTE: If you switch from a Cool setting to Off or to
a fan setting, wait at least 3 minutes before switching
back to a Cool setting.
FAN MODE
Use the Fan mode to provide air circulation and filtering
without cooling. Since fan-only settings do not provide
cooling, a temperature setting will not be displayed.
Remote Control
Press Fan pad. Press Low, Med or High pads to set
desired fan speed.
Control Panel
Press the Mode pad until the Fan indicator light is lit
and the Low, Med or High indicator light is lit for the
desired fan speed.

On
Cool
Timer Temp
Off
On
Mode
Power
On/Off
Off Fan
Fan
Hi
Heat
Low
Air Conditioner Controls
ON/OFF
Turns air conditioner on and off.
Display
Displays the temperature setting. Displays
hours when setting the timer.
MODE
On the air conditioner controls, use to set
COOL, HEAT or FAN mode. Indicator lights
on the air conditioner controls will show the
mode selected.
TEMP Increase + /Decrease – Pads
Use to set temperature when in COOL
or HEAT mode.
FAN Speeds
Use to set the fan speed at LOW or HIGH.
Indicator lights will show the speed selected.
TIMER
21³When the air conditioner is off, it
can be set to automatically turn on in
half an hour to 24 hours at its previous
setting.
Each touch will set the time in half hours
up to 10 and then in hours up to 24.
To cancel the On Timer, press the ON
pad until “CL” appears. Then wait until
the display turns off.
2))³When the air conditioner is on, it
can be set to automatically turn off in
half an hour to 24 hours. Each touch will
set the time in half hours up to 10 and
then in hours up to 24.
To cancel the Off Timer, press the OFF
pad until “CL” appears and wait for the
set temperature to be displayed. The unit
will now resume normal operation.
Remote Control Signal Receiver
NOTE: When the air conditioner is turned on,
it will automatically start in the setting last used.
To ensure proper operation, aim the
remote control at the signal receiver
on the air conditioner.
The remote control signal has a range
of up to 21 feet.
Make sure nothing is between the air conditioner
and the remote control that could block the
signal.
Make sure batteries are fresh and installed
FRUUHFWO\³VHHWKH&DUHDQG&OHDQLQJVHFWLRQ
Remote Control
$ERXWWKHFRQWUROVRQWKHDLUFRQGLWLRQHU³+HDW&RRO0RGHOV
Appearance may vary.
Remote Control
Lights beside the touch pads on the air conditioner
control panel indicate the selected settings.
Controls
6

GEAppliances.com
COOL MODE
Remote Control
1. Press COOL pad.
2. Press LOW or HIGH pads to set desired fan speed.
3. Press the ,1&5($6('(&5($6(²pads to set the desired
temperature 60°F to 85°F in 1°F increments.
Control Panel
1. Press the MODE pad until the COOL indicator light is lit.
2. Press the FAN pad until HIGH or LOW indicator light
is lit for desired fan speed.
3. Press the,1&5($6('(&5($6(²pads to set the desired
temperature 60°F to 85°F in 1°F increments.
A thermostat is used to maintain the room temperature. The
compressor will cycle on and off to keep the room
at the set level of comfort. Set the thermostat at a lower
number and the indoor air will become cooler.
Set the thermostat at a higher number and the indoor air will
become warmer.
NOTE: If the air conditioner is off and is then turned on while set
to COOL, it will take approximately 3 minutes
for the compressor to start and cooling to begin.
Cooling Descriptions
)RU1RUPDO&RROLQJ³Select the COOL mode and HIGH fan
with a middle set temperature.
)RU0D[LPXP&RROLQJ³Select the COOL mode
and HIGH fan with a lower set temperature.
)RU4XLHWHUDQG1LJKWWLPH&RROLQJ³Select the COOL mode
and LOW fan with a middle set temperature.
NOTE: There will be a 3-minute delay between setting
changes such as COOL to OFF and back to COOL.
FAN
Use the FAN to provide air circulation and filtering without
cooling or heating. Since fan only settings do not provide
cooling or heating, a temperature setting will not be displayed.
Remote Control
Press FAN pad. Press LOW or HIGH pads to set desired fan
speed.
Control Panel
Press the MODE pad until the FAN indicator light is lit
and the LOW or HIGH indicator light is lit for the desired fan
speed.
HEAT MODE
Remote Control
1. Press HEAT pad.
2. Press LOW or HIGH pads to set desired fan speed.
3. Press the ,1&5($6('(&5($6(²pads to set the desired
temperature 60°F to 85°F in 1°F increments.
Control Panel
1. Press the MODE pad until the HEAT indicator light is lit.
2. Press the FAN pad until HIGH or LOW indicator light
is lit for desired fan speed.
3. Press the ,1&5($6('(&5($6(²pads to set the
desired temperature 60°F to 85°F in 1°F increments.
A thermostat is used to maintain the room temperature. The
heater will cycle on and off to keep the room
at the set level of comfort. Set the thermostat at a higher
number and the indoor air will become warmer.
Set the thermostat at a lower number and the indoor air will
become cooler.
NOTE:If the air conditioner is off and is then turned on while set
to HEAT, it will take approximately 1 minute
for the heater to start and heating to begin.
Heating Descriptions
)RU1RUPDO+HDWLQJ³Select the Heat mode and HIGH fan
with a middle set temperature.
)RU0D[LPXP+HDWLQJ³Select the HEAT mode
and HIGH fan with a higher set temperature.
)RU4XLHWHUDQG1LJKWWLPH+HDWLQJ³Select the HEAT mode
and LOW fan with a middle set temperature.
7

About the controls on the air conditioner
Vent Control
The vent control is located behind the front grille on the right
side of the air discharge area. When CLOSED, only the air
inside the room will be circulated and conditioned. When
OPEN, the vent allows outdoor fresh air exchange.
To open or close the vent:
1. Remove the front grille.
2. Remove the vent card screw.
3. Remove vent card, turn it over and replace it by locating
rear hole in card over locating pin inside air discharge and
reattaching screw at front.
Horizontal louvers
on the front grille let you
control the air direction
up and down.
Remove the front grille to adjust
the vertical louvers side-to-side
to direct the air left
or right.
Air Direction
Locating hole
Screw hole
OPEN position
(Mesh end toward back) CLOSE position
(Mesh end toward front)
Locating hole
Screw hole
The unit leaves the factory set at the CLOSE position.
No function (reserved
for future use)
Auxiliary Controls – Dip Switches (location varies by model)
The auxiliary dip switch controls are
ORFDWHGEHKLQGWKHURRPFDELQHW³DV
shown in this figure.
The owner is responsible for checking
switches and ensuring they are in the
desired position.
Fan Cycle/Continuous - Cool
Fan Cycle/
Continuous - Heat
Class 2
ON
ON
OFF
ON
ON
COOL
FAN
HIGH
MED
OFF
OFF SLEEP
MODE
TIMER TEMP
+
-Filter Reminder
Function
Auxiliary Controls – Dip Switches (location varies by model)
The auxiliary dip switch controls are located
EHKLQGWKHURRPFDELQHW³DVVKRZQLQWKLVILJXUH
The owner is responsible for checking switches
and ensuring they are in the desired position.
Fan Cycle/Continuous - Cool
Fan Cycle/Continuous - Cool
Filter Reminder Funtion
When this switch is enabled (RIGHT), it allows the indoor
fan to cycle on/off with the compressor. When this
switch is disabled (LEFT), it allows the indoor fan to run
continuously. The default setting is right (fan cycle).
When this switch is enabled (RIGHT), an LED will light
up the user interface after 250 of accumulated fan run
time. It serves as a reminder to clean the filter. When
this switch is disabled (LEFT), the function is disabled.
The default setting is right (enabled).
ON ON
Fan Cycle/Continuous - Cool
Filter Reminder Function
Cool Only Models
Heat/Cool Models
8

GEAppliances.com
When connected, the unit will be controlled
by a remote thermostat.
NOTE: The number 3 dip switch must be in
the enabled (UP) position to activate the remote
thermostat. (See the installation instructions
supplied with the remote thermostat.)
IMPORTANT:
The thermostat connections provide 24 V AConly.
If using a digital/electronic wall thermostat,
ensure it is compatible with 24 VAC signal. See
the Installation Instructions for the wall thermostat.
NOTICE:
Damage to a wall thermostat or to the electronics
can result from improper connections. Special
care must be used in connecting the wires. No line
voltage connections should be made to any circuit.
Isolate all wires in building from line voltage.
Terminal Connections Remote Thermostat - Class 2 (on some models)
The controls are located under a plastic cover
behind the front grille.
1Remove the front grille. See the Front Grille
section of Care and Cleaning.
2Remove the screws securing the plastic cover
over the wiring connections. Set aside screws
and plastic cover.
3To make wiring connections, insert the wires
into the bottom of the terminals and tighten
screws securely.
4After all desired connections have been made,
replace the plastic cover and front grille.
The owner is responsible for making all
connections and setting the appropriate dip
switches.
Terminal
connections
location
under front
grille
Fan Cycle/Continuous - Cool
When this switch is enabled (UP), it allows the indoor
fan to cycle on/off with the compressor. When this
switch is disabled (DOWN), it allows the indoor fan to run
continuously. The default setting is DOWN (continuous).
Fan Cycle/Continuous - Heat
When this switch is enabled (UP), it allows the indoor
fan to cycle on/off with the heater operation. When this
switch is disabled (DOWN), it allows the indoor fan to run
continuously. The default setting is UP (cyclic).
Class 2 - Remote Thermostat
When this switch is enabled (UP), it allows the unit
to operate with a Class 2 Remote Control Wall
Thermostat. The unit controls are disabled.
The default setting is DOWN (disabled).
Fan Cycle/Continuous - Cool
Fan Cycle/Continuous - Heat
Class 2
9
Red - 24 V AC only
Green - Low Speed Fan
Green - High Speed Fan
Yellow - Compressor
White - Heater
Common - Ground
No Function
(reserved for furture use)
No Function
(reserved for furture use)

10
Care and cleaning of the air conditioner.
The front grille can be removed for more thorough
cleaning and to locate the model and serial numbers
on the front of the base pan.
To remove:
1. Pull the filter out.
2. Remove the two grille screws.
3. Pull the grille out from the bottom and lift up
from the tabs on the top of the case.
To replace:
Hook the tabs on the front grille even with the tabs on
the case and snap into place.
Replace the screws and filter.
Front Grille
Outdoor Coils
The coils on the outdoor side of the air conditioner
should be checked regularly.
If they are clogged with dirt or soot they may be
professionally steam cleaned, a service available
through your GE service outlet.
Grille and Case
Turn the air conditioner off and remove the plug
from the wall outlet before cleaning. To clean, use water and a mild detergent. Do not use bleach or abrasives.
Grille
Tab
On some models
On some models
Grille
Tab

How to Insert the Batteries in the Remote Control
1Remove the battery cover by sliding it according
to the arrow direction.
2Insert new batteries making sure that the
(+) and (–) of battery are installed correctly.
3Reattach the cover by sliding it back
into position.
NOTES:
Use 2 AAA (1.5 volt) batteries. Do not use
rechargeable batteries.
Remove the batteries from the remote control
if the system is not going to be used for a long time.
Do not mix old and new batteries. Do not mix
alkaline, standard (carbon-zinc) or rechargeable
(ni-cad, ni-mh, etc) batteries. 11
To maintain optimum performance, clean the filter at least every 30 days.
Air Filter
FRONT FRONT
'LUW\ILOWHU³1HHGVFOHDQLQJ &ORJJHGILOWHU³*UHDWO\
reduces cooling, heating
and airflow.
Turn the air conditioner off before cleaning.
The most important thing you can do to maintain the
air conditioner is to clean the filter at least every 30
days. A clogged filter reduces cooling, heating and air
flow.
Keeping the air filter clean will:
Decrease cost of operation.
Save energy.
Prevent clogged heat exchanger coils.
Reduce the risk of premature component failure.
To clean the air filters:
Vacuum off the heavy soil.
Run water through the filters.
Dry thoroughly before replacing.
To remove the air filter, on some models:
Carefully pull the tab forward, up and out.
To remove the air filter, on other models:
Pull it down.
To
replace the air filter:
Replace the clean filter by pushing it back
into place.
NOTICE:Do not operate the air conditioner
without the filter in place. If a filter becomes torn or
damaged it should be replaced immediately.
Operating without the filter in place or with a damaged
filter will allow dirt and dust to reach
the indoor coil and reduce the cooling, heating, airflow
and efficiency of the unit.
Replacement filters are available from your salesperson,
GE dealer, GE Service and Parts Center or authorized
Customer Care®servicers.
Care and cleaning of the air conditioner. GEAppliances.com

12
(/(&75,&$/5(48,5(0(176
WARNING! Risk of electric shock. Can
cause injury or death. This appliance must be
properly grounded. Where a 2-prong wall outlet
is encountered, it is your responsibility and
obligation to have it replaced with a properly
grounded 3-prong outlet.
Some models require a 115/120-volt a.c.,
60-Hz grounded outlet protected with a
15-amp time delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the possibility of
electric shock hazard. If the wall outlet you plan to use
is only a 2-prong outlet, it is your responsibility to have it
replaced with a properly grounded 3-prong wall outlet.
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
Do not change the plug on the power cord of this
air conditioner.
Aluminum house wiring may present special
SUREOHPV³FRQVXOWDTXDOLILHGHOHFWULFLDQ
Some models require 230/208-volt a.c., protected
with a time delay fuse or circuit breaker. These
modelsshouldbeinstalledon their own single
branch circuit for best performance and to prevent
overloading house or apartment wiring circuits,
which could cause a possible fire hazard from
overheating wires.
BEFORE YOU BEGIN
Read these instructions completely
and carefully.

,03257$17 ³6DYHWKHVHLQVWUXFWLRQV
for local inspector’s use.

,03257$17 ³2EVHUYHDOOJRYHUQLQJFRGHV
and ordinances.
Note to Installer – Be sure to leave these instructions
with the Consumer.
Note to Consumer – Keep these instructions
for future reference.
Skill level – Installation of this appliance requires basic
mechanical skills.
Completion time – Approximately 1 hour
:HUHFRPPHQGWKDWWZRSHRSOHLQVWDOOWKLVSURGXFW
3URSHULQVWDOODWLRQLVWKHUHVSRQVLELOLW\RIWKHLQVWDOOHU
3URGXFWIDLOXUHGXHWRLPSURSHULQVWDOODWLRQ
is not covered under the Warranty.
Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: GEAppliances.com
Installation
Air Conditioner
Instructions
,03257$17
GE strongly recommends the removal of the old wall case
DQGWKHLQVWDOODWLRQRIDQHZ*(:DOO&DVH,I\RX'2127
use a GE Wall Case, you run the risk of poor performance
or product failure. This is not covered under the terms of the
GE warranty.
Air conditioner break-in period
NOTE – As with any mechanical device with moving
parts, this unit will have a wear-in period. AFTER
INSTALLATION, this unit should be operated for 48
hours to achieve optimum efficiency.

*(.,7180%(56
Installation Instructions
USE GE
 .,7180%(5 )25 '(6&5,37,21
RAB46A ,46, Use these kits for all GE Standard wall case for “J” model chassis. RAG13 stamped
47A, 47, 48A, models and other brands aluminum exterior grille included. Remove the existing case
48B & 48 not listed and replace.
RAK65A1 All GE Models Kit for window installation.
RAK690 RAB36, 37, 38, 46, 47 or 48 If you attach a custom architectural outdoor grille, use this kit
(J-Chassis) to ensure proper airflow.
RAG13 RAB36, 37, 38, 46, 47 or 48 Standard aluminum exterior grille (included with RAB46, 47, 48,
(J-Chassis) RAB46A, 47A, 48A, and 48B wall cases).
RAG14E RAB36, 37, 38, 46, 47 or 48 Architectural louvered exterior grille.
(J-Chassis)
Read these instructions completely and carefully.
722/6<280$<1(('
Adjustable Wrench Level
Phillips-head
screwdriver
Hand or Saber Saw
Drill
Pencil
Ruler or Tape Measure Scissors or knife
13
Power cord may include a current interrupter device.
A test and reset button is provided on the plug case.
The device should be tested on a periodic basis by first
pressing the TESTbutton and then the RESETbutton.
If the TESTbutton does not trip or if the RESETbutton
will not stay engaged, discontinue use of the air
conditioner and contact a qualified service technician.
$'$&RPSOLDQFH
Operation by
Remote Control A Remote Control device is shipped with GE Built-In Air Conditioners. When operated by Re- mote Control GE Built-in ACs meet all federal ADA compliance requirements.
Operation at
&RQWURO3DQHO GE Built In Air Conditioners intended to be operated at the control panel meet federal ADA compliance requirements when installed so that the controls are more than 15” from ground
and less than 48” from the ground.
Operation by
Thermostat GE Air Conditioners intended to be operated via a wall thermostat meet federal ADA compli- ance requirements when used in conjunction with an ADA compliant wall thermostat mounted
more than 15” and less than 48” from the ground.

&$5()8//<6/,'($,5&21',7,21(5
INTO CASE
Make sure that the tubing on the unit does
not touch the wall case and that the case
installation is secure.
Installation Instructions
5(029($//6+,33,1*0$7(5,$/
,)35(6(17,16,'($,5&21',7,21(5
1(;772&2035(6625
5(,167$///2&.,1*3/$7(:,7+7$%
%(+,1':$//&$6()/$1*(7,*+7(1
SCREW
,167$//,1*$-02'(/,1$1(;,67,1*:$//&$6(
Read these instructions completely and carefully.
R(029(7+(),/7(5$1')5217*5,//(
Remove the two screws behind the filter then remove
the front grille.
1
2
$77$&+)5217*5,//(
An opening for the power cord is on the bottom
of the front grille.
4
5
Locking
plate
Tighten
screw
3
14

Installation Instructions
35(3$5(23(1,1*,1:$//
Make certain a wall receptacle is available close
to the hole location or make arrangements to install
a receptacle.
The cord length for the 115-volt models is 72s
to the right and 47sto the left.
For the 230/208-volt models the cord length is 65s
to the right and 39sto the left.
1
,167$//,1*7+528*+7+(:$//
Read these instructions completely and carefully.
68332575(48,5(0(176)25$,5
&21',7,21(5
The air conditioner wall case may be installed
with 1/4smin. extension out from the inside wall
or with 1/4smin. extension out from the outside wall.
The finished sides of the opening should be structural
wall members.
/LQWHO² Use a lintel in brick veneer and brick
and block types of wall to support the bricks
or blocks above the opening. Do not allow the wall
case to be used in lieu of a lintel.
)ODVKLQJ² Install flashing (drip rail) as shown
to prevent water from dripping inside the wall
and down the outside of the building.
2
Trim
molding
(if desired)
Plaster line
Caulking
(above
and
below the
flashing)
1/4smin. extension
inside the wall from
the trim molding
Room side
Flashing
(drip rail)
Brick veneer
Caulking
(on all 4 sides
on the outside
and inside
of the case)
Lintel angle
(if required)
68332575(48,5(0(176)25$,5
&21',7,21(5
Mortar between the case and the brick wall around
the case may be undercut at about 45° for
improved caulking.
3
Caulking
Top of case
Inside
Outside
Undercut
mortar
 0,1,080
 ),1,6+('
 23(1,1*
 ',0(16,216 &$6(',0(16,216
 +HLJKW :LGWK +HLJKW :LGWK 'HSWK
   
153ø4s 261ø8s 155ø8s 261ø16s16s

*Dimensions may need
to be increased to fit
unique situations in the
field if using case angles.
15

16
Before you call for service…
Troubleshooting Tips: Save time and money! Review the chart below first and you may not need to call for service.
Normal Operating Sounds
 You may hear a pinging noise caused by
water being picked up and thrown against the
condenser on rainy days or when the humidity
is high. This design feature helps remove
moisture and improve efficiency.
 You may hear the thermostat click when the
compressor cycles on and off.
 Water will collect in the base pan during high
humidity or on rainy days. The water may
overflow and drip from the outdoor side of
the unit.
 The fan may run even when the compressor
does not.
Problem Possible Causes What To Do
Air conditioner The air conditioner 0DNHVXUHWKHDLUFRQGLWLRQHUSOXJLVSXVKHGFRPSOHWHO\
does not start is unplugged. into the outlet.
7KHIXVHLVEORZQFLUFXLW &KHFNWKHKRXVHIXVHFLUFXLWEUHDNHUER[DQGUHSODFH
breaker is tripped. the fuse or reset the breaker.
3RZHUIDLOXUH ,ISRZHUIDLOXUHRFFXUVWXUQWKHDLUFRQGLWLRQHUOFF. When
power is restored, wait 3 minutes to restart the air conditioner
to prevent tripping of the compressor overload.
The current interrupter  3UHVVWKHRESET button located on the power cord plug.
device is tripped. ,IWKHRESET button will not stay engaged, discontinue use
of the air conditioner and contact a qualified service
technician.
Air conditioner does Airflow is restricted. 0DNHVXUHWKHUHDUHQRFXUWDLQVEOLQGVRUIXUQLWXUHEORFNLQJ
not cool or heat (some the front of the air conditioner.
models) as it should The temp control may ,QCOOL mode or HEAT mode (some models), press the
not be set correctly. DECREASE – pad.
The air filter is dirty. &OHDQWKHILOWHUDWOHDVWHYHU\GD\V
See the Operating Instructions section.
The room may have been hot. :KHQWKHDLUFRQGLWLRQHULVILUVWWXUQHGRQ\RXQHHG
to allow time for the room to cool down.
Cold air is escaping. &KHFNIRURSHQIXUQDFHUHJLVWHUVDQGFROGDLUUHWXUQV
  0DNHVXUHWKHDLUFRQGLWLRQHU·VYHQWLVLQWKHFORVHGSRVLWLRQ
Cooling coils have iced up. 6HH“Air conditioner freezing up” below.
Air conditioner Ice blocks the airflow 6HWWKHFRQWUROVDWHIGH FAN or HIGH COOL and set the
freezing up and stops the air conditioner thermostat to a higher temperature to allow the ice to melt.
from cooling the room. &KHFNILOWHUIRUFOHDQOLQHVV
The remote control is The batteries are inserted &KHFNWKHSRVLWLRQRIWKHEDWWHULHV7KH\VKRXOGEH
not working incorrectly. inserted correctly.
The batteries may be dead. 5HSODFHWKHEDWWHULHV
Water drips outside +RWKXPLGZHDWKHU 7KLVLVQRUPDO
Water drips indoors The air conditioner is not )RUSURSHUZDWHUGLVSRVDOPDNHVXUHWKHDLUFRQGLWLRQHU
tilted to the outside. case is level or slants slightly from the case front to the rear.
Water collects in 0RLVWXUHUHPRYHGIURPDLU 7KLVLVQRUPDOIRUDVKRUWSHULRGLQDUHDVZLWKOLWWOH
base pan and drains into base pan. humidity; normal for a longer period in very humid areas.

17
Notes.

18
Notes.

This warranty is extended to the original purchaser and any succeeding owner for products purchased for home
use within the USA and Canada. If the product is located in an area where service by a GE Authorized Servicer
is not available, you may be responsible for a trip charge or you may be required to bring the product to an
Authorized GE Service location for service. In Alaska, the warranty excludesthe cost of shipping or service calls to
your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives
you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
19
Air Conditioner Warranty.
Service trips to your home to teach you how to use
the product.
Improper installation, delivery or maintenance. If you
have an installation problem, or if the air conditioner is of
improper cooling capacity for the intended use, contact
your dealer or installer. You are responsible for providing
adequate electrical connecting facilities.
Failure of the product resulting from modifications to the
product or due to unreasonable use including failure to
provide reasonable and necessary maintenance.
In commercial locations labor necessary to move the unit
to a location where it is accessible for service by
an individual technician.
Replacement of house fuses or resetting of circuit
breakers.
Failure due to corrosion on models not corrosion-
protected.
'DPDJHWRWKHSURGXFWFDXVHGE\LPSURSHUSRZHUVXSSO\
voltage, accident, fire, floods or acts of God.
Incidental or consequential damage caused by possible
defects with this air conditioner.
'DPDJHFDXVHGDIWHUGHOLYHU\
3URGXFWQRWDFFHVVLEOHWRSURYLGHUHTXLUHGVHUYLFH
What GE Will Not Cover:
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule service,
on-line visit us at GEAppliances.com, or call 800.GE.CARES
(800.432.2737). For service in Canada, contact Gordon Williams
Corp. at 1.888.209.0999. Pleasehaveserialnumberand model
number available when calling for service.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain
service under the warranty.
For The Period Of: GE Will Replace:
One Year Any part of the air conditioner which fails due to a defect in materials or workmanship.
From the date of the During this limited one-year warranty, GE will also provide, free of charge, all labor
original purchase and related service to replace the defective part.
Five Years Any part of the sealed refrigerating system (the compressor, condenser, evaporator
From the date of the and all connecting tubing) which fails due to a defect in materials or workmanship.
original purchase During this four-year limited additional warranty, GE will also provide, free of charge,
all labor and related service to replace the defective part.
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQWKLV/LPLWHG
Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose,
are limited to one year or the shortest period allowed by law.

Consumer Support.
GE Appliances Website GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts or even schedule service on-line.
Schedule Service GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours.
Real Life Design Studio GEAppliances.com
*(VXSSRUWVWKH8QLYHUVDO'HVLJQFRQFHSW³SURGXFWVVHUYLFHVDQGHQYLURQPHQWVWKDWFDQEHXVHGE\
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen design
ideas for people with disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.
GEAC (800.833.4322).
Extended Warranties GEAppliances.com
Purchase a GEextended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories GEAppliancesparts.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or
by phone at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance GEAppliances.com
5HJLVWHU\RXUQHZDSSOLDQFHRQOLQH³DW\RXUFRQYHQLHQFHTimely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.
Printed in China
