OWNER’S MANUAL
AIR CONDITIONER
RV
49-5000406 Rev. 7 05-23 GEA
SAFETY INFORMATION .........3
INSTALLATION INSTRUCTIONS
Before You Begin ......................4
Tools You will Need....................4
RARMN_ _ Parts List ...................5
RAREN_ _ Parts List ...................6
RARED_ _ Parts List ...................7
RPREN_ _ Parts List....................8
RPRED_ _ Parts List....................9
Roof Requirements ...................10
Roof Requirements and Prep ...........12
Electrical Requirements ...............12
Placing Unit on Roof ..................12
Installing Unit ........................13
Electrical Control Installation...........15
USING THE AIR CONDITIONER
Controls .............................17
Air Direction .........................18
Normal Operating Sounds .............18
CARE AND CLEANING
Indoor Panel .........................19
Air Filter.............................19
Annual Maintenance...................19
TROUBLESHOOTING........... 20
SCHEMATIC DIAGRAMS ........21
LIMITED WARRANTY ...........23
CONSUMER SUPPORT ......... 24
Rooftop Units:
PLC13XHH_
PLH13XHH_
PLC13XAH_
PLH13XAH_
PLC15XAH_
PLH15XAH_
Indoor Assemblies
RARMN_ _
RAREN_ _
RARED_ _
RPREN_ _
RPRED_ _
ENGLISH
Write the model and serial numbers
here:
Model #_______________
Serial # _______________
You can find them on a label on the
air conditioner.

249-5000406 Rev. 7
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR RV
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GEAppliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual.

49-5000406 Rev. 7 3
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
For your safety, the information in this manual must be followed to minimize the risk of
fire, electric shock or personal injury.
Ŷ8VHWKLVDSSOLDQFHRQO\IRULWVLQWHQGHGSXUSRVHDV
described in this Owner’s Manual.
ŶThis air conditioner must be properly installed in accordance
with the Installation Instructions before it is used.
ŶReplace immediately all electric service cords that
have become frayed or otherwise damaged.
ŶTurn the unit OFF and disconnect all power to the
vehicle before cleaning and servicing.
ŶTo avoid risk of injury or property damage, the air
conditioner should only be serviced by a qualified
servicer who holds a current valid certificate from
an industry-accredited assessment authority, which
authorizes their competence to handle refrigerants
safely in accordance with industry recognized
assessment specifications.
ŶFor your safety, do not store or use combustible
materials, gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
ŶAll air conditioners contain refrigerants, which under federal
law must be removed prior to product disposal. If you are
getting rid of an old product with refrigerants, check with
the company handling disposal about what to do.
ŶThese R410A air conditioning systems require
contractors and technicians to use tools, equipment
and safety standards approved for use with this
refrigerant. DO NOT use equipment certified for R22
refrigerant only.
WARNING
READ AND SAVE THESE INSTRUCTIONS

449-5000406 Rev. 7
General Knowledge
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•Save these instructions for local inspector’s use.
•Observe all governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires a
qualified RV technician.
• Completion time – Approximately 1 hour
• We recommend that two people install this product.
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is not
covered under the Warranty.
 <RX0867XVHDOOVXSSOLHGSDUWVDQGXVHSURSHU
installation procedures as described in these
instructions when installing this air conditioner.
Questions? Call 1-877-540-7837 or Visit our Website at: GEAppliances.com
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measure
Pencil
Level
Scissors or knife
Torque Wrench (0-60 in-lbs)
Drill and 1/8” drill bit
CAUTION
Be cautious of sharp edges as they may cause injury.
When lifting the air conditioner, use 2 people to lift.
Electrical wiring may be present between roof and
ceiling. Be sure that power is disconnected at the
mains and battery. Be sure that the gas supply is shut
off. Failure to do so may result in injury or death.
INSTALLATION GUIDE
,QGRRU8QLWV
GE Appliances GE Profile
RARMN Mechanical
Non-Ducted RAREN Electronic Non-Ducted RARED Electronic Ducted RPREN Electronic Non-Ducted RPRED Electronic Ducted
Elec. Control
R_REC1A
R_REC2A
R_REC3A
XXXX
Wall Thermostat
R_RWT XXXX
Table #1 - Model Compatibility List
,QGRRU8QLWV Breaker Size
GE Appliances GE Profile
2XWGRRU8QLWV RARMN
Mechanical
Non-Ducted
RAREN
Electronic
Non-Ducted
RARED
Electronic
Ducted
RPREN
Electronic
Non-Ducted
RPRED
Electronic
Ducted
MCA MOP
PRC13XHH_ X X X X X 15A 20A
PRC13XAH_ X X X X X 20A 20A
PRC15XAH_ X X X X X 20A 20A
PRH13XHH_ X X X X 15A 20A
PRH13XAH_ X X X X 20A 20A
PRH15XAH_ X X X X 20A 20A

49-5000406 Rev. 7 5
INSTALLATION GUIDE
Exploded View
RARMN_ _- Mechanical Non-Ducted
Check the contents of the accessories supplied with your air conditioner as shown below:
Number Part Name QTY.
1 Filter Cover 1
2 Filter 1
3 Knobs 2
4 Ceiling Panel 1
5 Side Discharge Ports 4
6 Direct Discharge Guide 1
7 Mounting template 1
8 Junction Box Cover 1
9 Connection Shield 1
10 Air division baffle 1
11 M8 Mounting Bolts 4
12 Wood screws 8
13 Sheet metal screws 2
11
1
2
3
4
5
6
7
8
9
10
12 13

649-5000406 Rev. 7
Exploded View
INSTALLATION GUIDE
Number Part Name QTY.
1 Filter Cover 1
2 Filter 1
3 Ceiling Panel 1
4 Side Discharge Ports 4
5 Direct Discharge Guide 1
6 Mounting template 1
7 Blanking Plate 1
8 Air Division Baffle 1
9 M8 Mounting Bolts 4
10 Wood screws 8
11 Sheet metal screws 8
1
23
4
5
6
7
9
10
8
11
RAREN_ _- Electronic Non-Ducted
Check the contents of the accessories supplied with your air conditioner as shown below:

49-5000406 Rev. 7 7
Number Part Name QTY.
1 Filter Cover 1
2 Filter 1
3 Screw Cover (left and right) 2
4 Ceiling Panel 1
5 Mounting template 1
6 Air Division Baffle 1
7 M8 Mounting Bolts 4
8 Wood Screws 8
9 Sheet metal screws 9
1
2
3
4
5
6
7
8
9
RARED_ _- Electronic Ducted
Check the contents of the accessories supplied with your air conditioner as shown below:
Exploded View
INSTALLATION GUIDE

849-5000406 Rev. 7
Exploded View
INSTALLATION GUIDE
RPREN_ _- Electronic Non-Ducted
Check the contents of the accessories supplied with your air conditioner as shown below:
1
2
3
10
9
4
5
6
7
8
Number Part Name QTY.
1 Air Division Baffle 1
2 Mounting Template 1
3 Ceiling Panel Base 1
4 Ceiling Panel Cover 1
5 Filter Retainer 1
6 Filter 1
7 Filter Tray 1
8 Side Discharge Louver 4
9 M8 Mounting Bolts 4
10 Sheet Metal Screws 6

49-5000406 Rev. 7 9
RPRED_ _- Electronic Ducted
Check the contents of the accessories supplied with your air conditioner as shown below:
Exploded View
INSTALLATION GUIDE
9
8
1
2
3
4
5
6
7
Number Part Name QTY.
1 Air Division Baffle 1
2 Mounting Template 1
3 Direct Discharge Guide 1
4 Ceiling Panel Base 1
5 Filter Retainer 1
6 Filter 1
7 Ceiling Panel Cover 1
8 M8 Mounting Bolts 4
9 Sheet Metal Screws 6

10 49-5000406 Rev. 7
Figure 3: GE Appliances Indoor Non-Ducted Unit:
14 - 3/8”
3 - 3/8”
14
-
3/8”
6”
2 - 5/8”
INSTALLATION INSTRUCTIONS
Installation Instructions
A. ROOF REQUIREMENTS AND DETERMINING LOCATION FOR INSTALLATION
Air conditioners covered in this manual are designed
for installation on an RV’s roof.
Installation of this air conditioner must be in accordance
with NFPA 1192 and NFPA 70.
For proper installation, there must be a 14 ñ»๢” x 14 ñ»๢”
(+/-ï»๞”) square opening in the roof and ceiling of the
RV.
There must be 2 to 6 inches between the RV ceiling
and roof.
Air conditioners covered in this manual are designed to
fit over preexisting roof vent openings.
If a roof vent opening isn’t available, use the following
guidelines:
8QLWLVWREHLQVWDOOHGFHQWHUHGVLGHWRVLGHRQWKH59URRI
8QLWLVWREHLQVWDOOHGRQDVHFWLRQRIURRIZKLFKLVOHYHOZLWK
respect to the RV roof if parked on a flat, level surface .
Roof at the point of installation can have a maximum 15
degree tilt towards the front or rear of the RV.
Figure 1: GE Appliances Outdoor Unit
Figure 2: GE Profile Outdoor Unit
Figure 3: GE Appliances Indoor Non-Ducted Unit
(RARMN)
Figure 4: GE Appliances Indoor Ducted Unit (RAREN)
Figure 5: GE Profile Indoor Non-Ductged Unit
(RPREN)
Figure 6: GE Profile Indoor Ducted Unit (RPRED)
Figure 1: GE Appliances Outdoor Unit:
Figure 2: GE Profile Outdoor Unit:
Roof opening
WARNING ELECTRICAL SHOCK HAZARD
Death or serious injury can result from failure to follow these instructions.
• Disconnect 115VAC and 12VDC power supply before beginning installation and/or servicing
• Ensure product is properly grounded according to the applicable codes
• Replace all parts and panels before operating
32 - 7/8” 27 - 3/4”
13 - 7/8”
18”
Center Line of unit
Keep at least 18” free of obstructions at rear of unit.
Roof opening
Front
13 - 3/4” 4 - 3/4”
23”
21”
2 -1/2”
21.238” 3.834”
