GE Zoneline AZ41E09DAB Operating instructions

GEAppliances.com
0
0_
0_
0
U
Safety Instructions ............. 2
Operating Instructions
Air Direction ....................... 4
Auxiliary Controls ................ 5-8
Controls ........................... 3
To Remove the Room Cabinet ...... 4
Ventilation Control ................. 4
Care and Cleaning
Air Filters ......................... 10
Base Pan .......................... 9
Outdoor Coils ...................... 9
Room Cabinet and Case ............ 9
Ventilation Filter .................... 9
Installation Instructions
Electrical Connection .......... 13-16
Installing the Zoneline ......... 17, 18
Optional Drain Kit ................. 19
Preparation ....................... 11
Replacing an Existing Unit7 ........ 12
Troubleshooting Tips ..... 2o,21
Normal Operating Sounds ......... 22
Consumer Support
Consumer Support ........ Back Cover
Warranty ......................... 23
Heat/Cool Model 4100
Heat Pump Model 6100
Espa_ol
For aSpanish version of this
manual, visit our Website at
www.zoneline.com/literuture.
Para consultar una version
en espahol de este manual
de instrucciones, visite nuestro
sitio de internet
www.zoneline.com/literature.
Frangais
For aFrench version of this
manual, visit our Website at
www.zoneline.com/literuture.
Pour un version frangais de
ce manuel d'utilisation, veuillez
visiter notre site web 6 I'adresse
www.zoneline.com/literature.
Write the model and serial
numbers here:
Model #
Serial #
Find these numbers on a label
behind the room cabinet on the
base pan. TINSEA576JBRZ 49-7612-1 12-10 GE

IMPORTANTSAFETYINFORMATION.
READALL INSTRUCTIONSBEFOREUSING.
WARNING!
Foryour safety, the information in this manual must be followed to minimize the risk of fire
or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
SAFETY PRECAUTIONS
This Zoneline must be properly installed
in accordance with the Installation
Instructions before it is used. See the
Installation Instructions in the back
of this manual.
Replace immediately oil electric service
cords that hove become frayed or
otherwise damaged. A damaged power
supply cord must be replaced with a
new power supply cord obtained from
the manufacturer and not repaired.
Do not use a cord that shows cracks
or abrasion damage along its length
or at either the plug or connector end.
Unplug or disconnect the Zoneline
at the fuse box or circuit breaker
before making any repairs.
NOTE: We strongly recommend that any
servicing be performed by a qualified
individual.
•These R410A air conditioning systems
require contractors and technicians to
use tools, equipment and safety
standards approved for use with this
refrigerant. DO NOT use equipment
certified for R22 refrigerant only.
Replacing an existing unit?
For details, see the Installation Instructions
in this manual.
READANDFOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVETHESEINSTRUCTIONS

About the controlsonyour Zoneline. GEAppliances.com
in HiGH =mmCOOL
LOW _FAN
AUTO _ HEAT m !
TEIVlP FAN MODE SLEEP OPERATION
TEMPCONTROL FAN,MODE& SLEEPOPERATION
Controls
Temp Control
Thetemp control isusedto maintain theroom
temperature.Thecompressorwillcycleon
and off to keepthe roomat the samelevel
of comfort.
Pressthe • padto raisethe temperature.
Pressthe • pad to lowerthetemperature.
NOTE:Thedisplayshowsthesettemperature,
not theroomtemperature.
Sleep
Pressto settheair conditionerto runfor 8 hours
beforeitautomaticallyreturnstothe previous
setting.
Wheninthe coolingmodeand thesleeptimer
isset,the settemperaturewill automatically
increase2°Fafter thesecondhourthen :].°F
eachhour overthe next two hours.Also,the
fan speedwill changeto low.Wheninthe
heatingmode,thesettemperature will
decreaseinthe same manner.
Tocancelthe sleepmode,presstheMODEpad
or theSLEEPpada secondtime.
Fan, Mode and Operation Control
FAN--Setsthe fan operationfor HIGH,
LOWorAUTO speed.Whensetat AUTO,
itautomaticallyswitchesbetweenLOW
and HIGHasroomtemperature changes.
MODE--COOL--Forcooling
FAN--Forfan-only operation
HEAT--Forheating
OPERATION--ON/STOP--Turnsthe unit
on oroff. Powerremainsconnectedto
the Zoneline.TheFreeze/HeatSentinel
featuresstillfunctionif active.Seethe
Freezer/HeatSentinelsectionon page6.
NOTE:Thetemperaturedisplaywillflash
toindicateapossibleunitmalfunction.Set
operation control to STOPand then restart
the unit. If theflashing light reappearswithin
30 minutes,coil forservice.
Quick Heat Recovery
Activateseachtime thethermostat isswitchedfrom
STOPor COOLmodeto HEATmode.Electricheaters
areenergizeduntilthe thermostatset point
isreached.On heatpump models,the heatpump
operationwill resumeat the nextcallfor heat.
About Vour Heat Pump (6100 Series only)
Heat pumps can save money by removing heat
from the outside air-even when the outside
temperature isbelow freezing-and releasing
that heat indoors.
Toget the best performance from your heat pump,
don't change the room thermostat very often.
Raisingthe heat setting 2-3 degreeswill cause
the Zonelineto useits electric heating elements in
order to reach the new temperature setting quickly.
There isa 3-minuteminimum compressor
run time at any setting to prevent short cycling.
Theindoor fan motor starts before the compressor
and stops after the compressor cycles off.
When the outdoor temperature islower than 25°F,
heat isprovided bythe electric heater in the air
conditioner instead of bythe heat pump.
Theelectric heating elements usemuch
more electricity than heat pumps and cost
more to operate. 3

Other features of your Zoneline.
Ventilation Control
NOTE:Two shippingscrews must beremoved
from the vent door beforeuse.Seethe Installation
Instructionsin the back ofthis manual. Ifyou do not
plan to usetheventilation feature,leavethesetwo
screws in place.
Theventilation control leverislocated at
the middle left sideof the Zoneline unit,
behind the room cabinet.
When set at the closed position,only the air
insidethe room iscirculated and filtered.
When set at the open position, some outdoor
air will be drawn into the room. Thiswill reduce
the heating or cooling efficiency.
Energy Tip: Keepthe vent control in the closed
position.Theroom air will be filtered and circulated.
Open
position
l
Ventcontrol
(shownin
middleposition)
Closed
position
To Remove the Room Cabinet
Additional controls are located behind the
room cabinet.
Toremove: Pullout at the bottom to releaseitfrom
the tabs (D.Then lift up (2).
@
Toreplace: Placethe tubs overthe top rail (D.Push
inward at the bottom until it snaps into place(2).
@
Air Direction
Tochange the air direction, remove the room
cabinet. Removethe 7 louverscrews that hold
the louverinsert in place. Flipthe louverinsert 180°,
replace the screws and the room cabinet.
Louverscrews
flemovethe roomcabinetandflip the/ouver
inserttochangethe air direction.
Default
position
/4 Louverscrews

Auxiliary controlsonyour Zoneline.
Auxiliary Controls--Aux Set Button
Theauxiliary set controls are located behind
the room cabinet, below the control panel.
Removethe room cabinet. Seethe ToRemove
the Room Cabinetsection.
Theowner isresponsiblefor ensuringthe auxiliary
controls are set to the desired function. Thereare 9
different modes that can be set usingthe auxiliary
set button. Tochange modes, pressAUXSET("AU"
appears on the display).Pressthe mode button on
the control pad untilthe first digit in the display
shows the number corresponding to the mode you
are choosing and the correct HEAT/COOLLEDislit.
Pressthe up or down arrow (shown in the second
digit ofthe display)to make the mode setting
selectionwhere applicable. Pressthe At.IXSET
button to confirm the selection.
RFirst Digit
BLoad
Shedding
_ constantFan
temperature
Limit _ _Ac_
Class 2Mode
_"_ Duet Mode
AH i2R Mode(AZ61 OnHy)
Boost Heat
(AZ61 Ortly)
GEAppliances.com
AuxiliarySet Button
AccessCover
USecond Digit
Press A /V
_,_ = Cycle// j_j -Continue
Lq-off // _'_ -On
COOL HEAT
O; 80F=85F o: 60F-65F
1: 64F=85F 1: 6OF-7OF
2: 66F=85F 2: 60FW2F
3: 68F=85F 3: 60F-74F
\\\\ 4: 70F=85F 4: 60F-76F
5: 72F-85F 5: 60F-78F
6: 74F-85F 6: 60F-80F
, 7: 76F=85F 7: 60F-85F /
//'U-o_ P_-on
/
MODE iISmart Fan--Cooling/Heating
Thedefault setting for Mode 1 isasfollows:
Cooling:Continuous(ON)
Heating:Cycle(OFF)
PressMODEuntil a iappears in the first digit of the
display for Smart Fan coolmode. TheCOOLLED
light on the main control will be on.Tochange to
heat mode, pressNODE again.TheHEATLEDlight
on the main control will be lit. Pressthe down arrow
to set the indoor fan to cycleon/off when the unit is
heating or cooling "u ."Pressthe up arrow to set
the indoor fan to run continuously" n." Thisis
shown in the second digit ofthe display.PressAUX
SETto confirm your selectionand exitAUXSET
mode, or pressNODEto continue setting other
functions.
*Note: In cyclic cooling mode, the indoor fan will activate occasionally to
verify airtemperature in the room. In cyclic heating mode, the fan will
continue to operate for 90seconds after the heating function has stopped in
order to increase unit efficiency.
-- HIGH _ COOL
t --LOW --FAN
_LJ --AUTO --HEAT
Cooling- Cycle*
#h'_ --HIGH _COOL
--LOW --FAN
--AUTO --HEAT
Cooling- Continuous
l -- HIGH -- COOL
lU --LOW --FAN
--AUTO _HEAT
Heating - Cycle*
Ib"_ --HIGH --COOL
--LOW --FAN
--AUTO _HEAT
Heating- Continuous
[ MODE 2 Load Shedding (Central Desk Control)
Thedefault setting for Hode 2 isOFF.
Thisfeature isactive only ifthe unit isconnected to
a CDCand the CDChascontrol. PressNODE untila
2 appears in the first digit of the display for Load
Shedding mode. Pressthe down arrow for OFF"u
"or the up arrow for ONI--I ."Thisisshown in the
second digit of the display.When this mode ison,
onlythe indoor fan can be turned ONor OFFwith
the unit controls.When this mode isoff, all
operation isdisabledexcept Heat/FreezeSentinel
(Mode3).PressAUXSETto confirm your selection
and exitAUXSETmode,or pressNODEto continue
setting other functions.
_7
Eu E
Load Load
Shedding Shedding
OFF ON

Auxiliary controlsonyour Zoneline.
I MODE31
[ MODE 4
[ MODE 5
[ MODE 6
Freeze Sentinel/Heat Sentinel
Inthe defaultsettingfor Mode3,HeatSentinelisoff,Freeze
Sentinelison.
PressMODEuntila 3appearsinthefirstdigitofthedisplayfor
FreezeSentinelmode.TheCOOL.LEDlightqnthemaincontrol.
willbeon.PressHQDEagaintochanqetotheHeatSentinel.The
HEATLEDlightonthemaincontrolw_lbeon.Pressthedown
arrowforOFF"u "or theuparrowforON"n." Thisisshown
inthesecond`digitatthedisplay.PressAUXSETto contirmyour
selectionandexitAUXSETmode,or pressMODEtocontinue
settingotherfunctions.
VhenFreezeSentinelisactivated,it automaticallyprovides
eatwithout userinterface.Thishelpsto preventplumbing
damagebyturningthe heaterandindoorfan ONat41%and
OFFat 46%.
WhenHea_Sentinelisactivated,it automaticallyprovides
coolingwithout userinterface.Thishelpsto preventan
excessivelyhotroombyturningtheair conditionerONat85%
andOFFat80°F.
NOTE:Thesefunctionsare activewheneverthe unitis
pluggedin,evenifthe unit isin the STOPposition.
HIGH
U--LOW
-- AUTO
FreezeSentinelOFF
3B_ HIGH
-- LOW
-- AUTO
FreezeSentinelON
HIGH
U--LOW
-- AUTO
HeatSentinelOFF
3b'_ HIGH
-- LOW
-- AUTO
HeatSentinelON
Constant ON Fan
Thedefaultsettingfor Mode4 isOFF.
PressMODEuntila4 appearsin thefirstdigitofthedisplaytoset
thefanto runcontinuouslyathighspeed,eveniftheunitisin
theSTOPposition.PressthedownarrowforOFF"u" ortheup
arrowforON"n." Thisisshownin theseconddigitofthe
display.PressAUXSETto confirmyourselectionandexitAUX
SETmode,or pressMODEto continuesettingotherfunctions.
h
Constant Constant
FanOFF FanON
Temperature Limiting
Thedefault settinqfor Mode5 isasfollows:
Cool:0 (60%to 8_°F}
Heat:7 (60%to 85°F}
PressMODEuntila5 appearsin thefirstdigitofthedisplayfor
TemperatureLimitingcool.mode.Th,eCOOLt_EDlightonthe
maincontrolwillbelit.Tochange.toheatmode,pressMODE
agai.nandtheHEATnEDlightonthemaincontrolwillbelit.To
setthetempeEaturelimits,presstheupordownarrow keys.The
seconddigitatthedisplaywillbebel_ween0 and7 dependingon
thelimityouwantto set.Thechartshowsthe limitsavailable.
PressAUXSETto confirmyourselectionandexitAUXSETmode,
or pressMODEtocontinuesettingotherfunctions.
Temperaturelimits--Cool Temperaturelimits--Heat
0=60°Fto 85% 0 =60% to 65%
1=64°Fto 85% 1=60% to 70%
2= 66°Fto 85% 2 =60% to 72%
3 =68°Fto 85% 3 =60% to 74%
4= 70°Fto 85% 4 =60% to 76%
5=72°Fto 85% 5 =60% to 78%
6=74°Fto 85% 6 =60% to 80°F
7 =76°Fto 85% 7 =60% to 85%
_COOL
-- FAN
-- HEAT
_COOL
-- FAN
-- HEAT
Remote Thermostat -Class 2
Thedefaultsettingfor Mode6isOFF.
SettingthismodetoONwillallowtheunittooperate.witha Class
2 RemoteContro/WallThermostat:PressNODEuntila6 appears
inthefirstdigitotthe displayforClass2 mode.Pressthedown
arrowtoturntheoptionOFF"u." Presstheuparrowtoturnthis
optionON"m." Thisisshownintheseconddigitotthe display.
PressAUXSETtoconfirmyourselectionandexitAUXSETmode,
or pressMODEto continuesettingotherfunctions.
--COOL
-- FAN
HEAT
--COOL
-- FAN
HEAT
C Cn
Class2OFF Class2 ON
HIGH --COOL
53 --LOW --FAN
--AUTO reHEAT
TemperatureLimitingHeat- Limit3
_ HIGH _ COOL
_# _ -- LOW -- FAN
--AUTO --HEAT
TemperatureLimitingCool- Limit2

GEAppliances.com
[ MODE 7 IDuct Mode
Thedefaultsettingfor Mode7isOFF.
Thissettingisusedwhentheunitisinstalledusinga
duct adapterkit.if theunitisducted,theDuctNode
needsto besetto ON.Thisincreasesthefanspeedto
ensurepropercirculation.
PressMODEuntila 7 appearsin thefirstdigitofthe
display.Pressthe upor downarrowkeysto setthis
sw_tchtoOFF"u" or ON"n." Thisisshowninthe
seconddigitofthedisplay.PressAUXSETto confirm
your selectionand exitAUXSETmode.
ForHodelAZ6100,pressMODEto continuesetting
otherfunctions.PressingMODEon ModelAZ/4IO0will
returnyouto AUXSETmodeandan "AU"willappearin
the display.
t7 J-i J-_
ILl I
DuctModeOFF DuctModeON
[ MODE 8 All-Electric Heat (AZ6100 only)
Thedefaultsettingfor Mode8isOFF.
Thiselectricheatoptionfunctionsonlyonthe 6100
model.WhenthisoptionisON"n," heatpump
operationislockedout, causingthe unitto provide
onlyelectricresistanceheat.
TosetAll-ElectricHeatoption,press MODEuntilan 8
appears in thefirst digit of the display.Pressthe upor
downarrowkeysto setthisswitchto OFF"u" or
ON"n." Thisisshownin theseconddigitofthedisplay.
PressAUXSETtoconfirmyourselectionandexitAUXSET
mode,or pressNODEtocontinuesettingotherfunctions.
on
All-Electric All-Electric
HeatOFF HeatON
[ MODE 9Heat Boost (AZ6100 only)
ThedefaultsettingforHode9 isOFF.
WhenHeatBoostisONandoutertemperaturesare
between25°Fand46°F,heatpumponlyoperationis
lockedout.Thissettingisusedto providesupplementary
heatto theheatpumpoperationbyelectricresistance
heatin conditionswherethe heatpump-onlyoperation
isnotsufficientto maintaina consistent,comfortable
roomtemperature.NOTE:TemperatureBoostoption
shouldnotbeusedwith remotethermostatoperation.
Thiswillcausetheunitto switchto resistanceheatwhen
theoutdoortemperatureis46°F.
TosetHeatBoost,pressMODEuntila 9appearsinthe
firstdigitofthedisplay.Presstheupor downarrowkeys
to setthisswitchtoOFF"u" orON"n ."Thisisshown
intheseconddigitofthedisplay.PressAUXSETto
confirmyourselectionandexitAUXSETmode.
HeatBoostOFF HeatBoostON
Auxiliary Controls--Terminal Connections
Theauxiliarycontrolsarelocatedbehindtheroom
cabinetbeneaththeaccesscover.
Turnoff andunplugtheunit.
r--_Removetheroomcabinet.SeetheToRemovethe
RoomCabinetsection.
[] Removethescrewfromtheaccesscover.
I--_Tomakewiringconnections,insertthewiresintothe
bottomoftheterminalsandtightenscrewssecurely.
I_lAfter alldesiredconnectionshavebeenmade,
replacetheaccesscoverandroomcabinet.
ExternalFan
CentralDeskControl
Theownerisresponsiblefor makingallconnectionsand
settingtheappropriateAUXSETmode.
.4,CAUTION:
improperwiringmaydamagetheZonelineelectronics.
Nocommonbusingispermitted.Damageorerratic
operationmay result.Aseparatewirepairmustberun
from eachseparatecontrollingswitchto eachindividual
Zoneline.
oo
zz
,,<
z
oo o°
I LCommon
_ hite - Heater
Yellow- Compressor
Black- Solenoid(AZ61only)
Green-HighSpeedFan
Green- LowSpeedFan 7
Red- 24V AConly

Auxiliary controlsonyour Zoneline.
External Fan (Obtained locally)
Whenconnected,an auxiliaryor externalfancanbe
controlledwith theindoorfan motoron theZoneline.
Connectionsprovide24VACtoenergizea remoterelay,
turningontheexternalfan. I I II
h_ ExternalFan
Central Desk Control
Whenconnected,theunitcanbeturnedONorOFFwith
aswitchlocatedat theCentralControlPanel.A separate
wirepairmustbe runfrom eachseparatecontrolling
switchtoeachindividualZoneline.
Referto NODE2on page5forfansettingoptions. o°j °o 0.1o
I__J
I__ CentralDeskControl
Remote Thermostat
Whenconnectedto a remotethermostat,theindoorair
temperaturesensingisshiftedfromtheunittothe
remotethermostat.Forthisreason,theunitswilloperate
slightlydifferentlywhenconnectedtoa remote
thermostat.Thefollowingchartshowstheunitoperation
whenconnectedtoa remotethermostat.
NOTE:TheClass2Nodesetting(Mode6)mustbesetto
ON"n" fortheunittooperatewith a Class2Remote
WallThermostat.(Seetheinstallationinstructions
"1 llll
/
Red- 24V AConly J
Green-LowSpeedFan--
supplied with the remote thermostat and Hode Green- HighSpeedFan--
instructions on page 7.) Black-Solenoid
5b'_ Yellow- Compressor
White- Heater
Common
Class2ShownON
IMPORTANT:TheZonelinethermostat
connectionsprovide24VAConly. ACAUTION:
Damageto awallthermostatortotheZoneline
electronicscanresultfrom improperconnections.Special
Ifusingadigital/electronicwallthermostat,youmustset caremustbeusedinconnectingthewires.Noline
ittothe24VACsetting.SeetheInstallationInstructions voltageconnectionsshouldbemadeto anycircuit.
forthewallthermostat. Isolateallwiresin buildingfromlinevoltage.
Feature
Indoor Frost Control
FreezeSentinel
Auto FanSpeed
Electronic Temperature Limiting
Switch to Resistance Heat Based
OnIndoor Temperature
Switch to Resistance Heat Based
OnOutdoorTemperature
ReverseCycle Defrost
Simultaneous Resistance Heat
with Heat Pump
Resistance Heat Lockout
"Smart Fan" Fan Cycle
Heat Pump
Yes
Yes
No
No
Determined by
Remote Thermostat
Yes
ElectricHeat
Yes
Yes
No
No
N/A
N/A
Yes N/A
No N/A
Yes N/A
Fan ON/AUTOSet On FanON/AUTOSet On
Remote Thermostat RemoteThermostat
Central Desk Control Yes Yes

Care and cleaning.
Room Cabinet and Case
Turnthe Zoneline off and disconnect the
power supply. Toclean, usewater and a mild detergent.
Donot usebleach or abrasives.Somecommercial
cleaners may damage the plastic parts.
Outdoor Coils
Thecoilson the outdoor side ofthe Zonelineshould
be checked regularly. If they are clogged with dirt
or soot, they may be professionally steam cleaned.
Youwill need to remove the unit from the wall
sleeveto inspectthe coils.Thedirt buildup occurs
on the fan sideof the outdoor coil.
Coils
Grille
Cleanthe outsidecoilsregularly.
Base Pan
In some installations,dirt or other debrismay be
blown into the unit from the outside and settle in
the basepan (thebottom of the unit).
Insome areas of the United States,a naturally
occurring "gel-like"or "slime-like"substancemay be
seeninthe basepan.
Checkit periodically and clean, if necessary.
Ventilation Filter
If the vent door is open,accessrequirestheremoval
of the unit from the wallsleeve.Cleanthe vent filter
twice ayear or as required.
TurntheZonelineoff and unplug beforecleaning.
i ....
j i
shipping screws
(if operation is
desired)
Toclean the vent filter:
IMPORTANT:
Thisfilter is not removable.Trying to remove this
filter will damage the unit.
• Usea vacuum to remove debris from the filter.
• Usea damp rag to wipe down the filter and
surrounding area after vacuuming.
9

Care and cleaning.
Tomaintain optimum performance, cleanthe filters at leastevery30 days.
Air Filters
D#ty filter--Needs cleaning Clogged filter--Great/y
reduces cooling, heating
and airf/ow
Turn the Zoneline off before cleaning.
Themost important thing you can do to maintain
the Zoneline isto clean the filter at least every
30 days.Cloggedfilters reduce cooling, heating
and air flow.
Keeping these filters cleanwill'.
• Decreasecost ofoperation.
• Saveenergy.
• Preventclogged heat exchanger coils.
• Reducethe risk ofpremature component failure.
Tocleanthe air filters:
• Vacuum offthe heavy soil.
• Runwater through the filters from the
back side.
• Drythoroughly before replacing.
NOTE:The air filters are interchangeable
and will fit in either the right or left side.
Toremove the air filters:
Pullupt
2Airfilters
To replace the air filters:
Pushdown
^,.,CAUTION:oonot operate the
Zoneline without the filters in place. If a filter
becomes torn or damaged, it should be replaced
immediately.
Operating without the filters in place or with
damaged filters will allow dirt and dust to reach
the indoor coiland reduce the cooling, heating,
airflow and efficiency of the unit.
Replacementfilters are available from your
salesperson,GEdealer,GEServiceand Parts
®
Center or authorized Customer Care servicers.
10

Installation
Instructions Zoneline Air Conditioners
IQuestions? cull 800.GE.CARES (800.432.2737) or visitour Website at:GEAppliunces.com I
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT -Sovetheseinstructionsfor
Io¢oiinspector'suse
•IMPORTANT -Observeo,,governing
codes ond ordinonces
• Note to Installer- Be sure to leovethese
instructionswiththe owner
•Note to Owner - Keep these instructionsfor
futurereference
• Proper instollotionisthe responsibilityof the instolier
• Product foiluredue to improper instollotionisnot
covered under the Worronty
TOOLS YOU WILL NEED
Phillipsscrewdriver
IMPORTANTELECTRICAL
SAFETY-READCAREFULLY
-_ CAUTION:
Follow the National Electrical Code (NEC)or local
codes and ordinances.
For personal safety, this Zoneline must be properly
grounded.
Protective devices (fuses or circuit breakers)
acceptable for Zoneline installations are specified
on the nameplate of each unit.
Do not use an extension cord with this unit.
Aluminum building wiring may present special
problems-consult a qualified electrician.
When the unit is in the OFF position, there is
still voltage to the electrical controls.
Disconnect the power to the unit before
servicing by:
1 Removing the power cord (if it has one) from
the wall receptacle.
OR
2 Removing the branch circuit fuses or turning
the circuit breakers off at the panel.
ZONELINE COMPONENTS
Appearance may vary.
unit
Exteriorgrille/louver_ 3
Wallcase_J
Shippedwith the Zonelineunit
_ Checkthe "EssentialElements"list onthe unitlocatedonfront of the basepan
-Power supplykit_
11

Installation Instructions
REPLACING AN EXISTING UNIT?
Checkthe"Essential
Elements"labelfor
importantinformation.
Use the correct wall case
This unit isdesignedto be installed in u GEplastic or
insulated metal wall case.Thisminimizes condensation
from forming on the room sideof the case.
If the current wall case is not insulated,you can reduce
the possibility of condensation forming by installing
insulation kit RAK901L,availablewhere you purchased
the unit.
NOTE:There are several extra holesinthe unit sideflanges
for installation in wall casesother than GE.To avoid
damaging the flange insulation,the installer should use
an awl or other sharptool to puncture the insulation in
the appropriate holes before installing the attachment
screws.
Use the correct outdoor grille
You should use the outdoor grilles shown on the
"Essential Elements" label on the base pan.
• If an existinggrille isnot replaced, capacity and
efficiency will be reduced and the unit may fail to
operate properly or fail prematurely. A deflector kit,
RAK40,may be usedwith grillesthat were not designed
for your new GEZonelines.TheRAK40contains air
deflectors and gaskets that mount to the unit to direct
the hot exhaust air away from the air intake to allow
the unitto function properly.Thegrille must have a
65% minimum free area.
• Anyvertical deflectors in the existing rear grille should
be removed to decrease condenser air recirculation
that can cause the unit to "short-cycle" and lead to
premature component failure.
Use the correct power cord
Local codes may require the use of arc fault or leakage
current detection devices on 230/208-volt installations.
Replacing a ducted unit
New ducted installation:
If this unit isto be installed in a new ducted application
usinga duct adapter kit, the kit must be installed before
the unit isplaced in the wall case.The installation
instructions are packed with the kit.
Duct kits available:
RAK6052
RAK601/602
Existing ducted installation:
Replacement of an existing ducted unit may require
different components. Requestthis information from your
salesrepresentative.
• Replacing 230/208 volt units:
Seepage 13.
• Replacing 265 volt units:
Seepage 14.
When usinga duct kit,you must always turn Mode7 to
ON"Ira ."SeeMode instructions on page 7.
DuctMode
ShownON
12

Installation Instructions
230/208 VOLT ELECTRICAL CONNECTION OPTIONS
HOW TO CONNECT
1. Remove the room cabinet.
2. Connect to electrical power.
3. Review the following steps for applicable supply
voltages.
4. Reinstall the room cabinet.
Power cords may include an arc fault interruption
or a leakage current detection interruption device.
A test and reset button is provided on the plug case
or the inline case. The device should be tested on
a periodic basis by first pressing the TESTbutton
and then the RESETbutton. If the TESTbutton does
not trip or if the RESETbutton will not stoy engaged,
discontinue use of the Zoneline and contact a
qualified service technician.
POWER CORD
CONNECTION
A power supplykit with LCDImust be usedto supply power
to the Zonelineunit.Theappropriatekit isdetermined by
the voltage, the means of electrical connection and
the amperage of the branch circuit.
Power supply kit
Connections of 208 or 230-volt circuits may be with (]
power supply kit or (]junction box kit.
All wiring, including installation of the receptacle, must
be in accordance with the NECand local codes,
ordinances and regulations. Codes require the use of
an arc fault or leakage current detection device on the
power cord except direct connect. Be sure to select the
correct cord for your installation.
Tandem Perpendicular LargeTandem
15Amp. 20Amp. 30 Amp.
230/208-voltreceptacleconfiguration.
Branch Circuit and Proper GE Power Cord
Unit Amperage Rating with LCDI Device
15 RAK3153A
20 RAK3203A
30 RAK3303*
*Not Gpproved for use on 7000 BTU models.
ELECTRICALSUBBASE
CONNECTION
230/208-volt models may be installed using one
of the following electrical subbases:
Branch Circuit and Proper GE
Unit Amperage Rating Subbase Kit
15 RAK204D15P
20 RAK204D20P
30 RAK204D30P*
*Not approved for use on 7000 BTUmodels.
Electricalsubbases provide an enclosure for direct
connection or enclosed receptacles.Thesubbase kit
includes the power cord.
The instructions provided with the selectedsubbase kit
must be carefullyfollowed. It isthe responsibility of the
installer to ensurethe connection of components isdone
in accordance with these instructions and all electrical
codes.
13
DIRECT CONNECTION
Order the following Kit for 2:30/208-volt direct
connection us required:
Branch Circuit and Power Supply Power
Unit Amperage Rating Accessory Supply Kit
15 RAK4002A RAK4157
20 RAK4002A RAK4207
30 RAK4002A RAK4307*
*Not approved for use on 7000 BTU models.
Skip to the "MAKE ELECTRICALCONNECTION TO THE UNIT"
section.

Installation Instructions
265 VOLT ELECTRICAL CONNECTION OPTIONS
WARNING:
Connectionof this 265V ACproduct to a branch circuit
MUSTbe done bydirect connection in accordance with
the National ElectricalCode. Pluggingthis unit into a
building-mounted exposed receptacle isnot permitted
by code.
These models must be installed usingthe appropriate
GEpower supply kit for the branch circuit amperage and
the electrical resistance heater wattage desired.Usethe
POWERCONNECTIONCHARTon page 16to determine
the correct kit required.One of the following installation
methods (Aor B)must be used.
A. FOR SUBBASE INSTALLATION
Electricalsubbase kitsare availableto provide a flexible
enclosurefor direct connection.
Branch Circuit and Proper GE Power
Unit Amperage Rating Subbase Kit Supply Kit
15 RAK204E15 RAK5172
20 RAK204E20 RAK5202
30 RAK204E30 RAK5302*
*Not approved for useon 7000 BTUmodels.
The instructions provided with the selected subbase kit
must be carefullyfollowed. It isthe responsibility of the
installer to ensure the connection of components isdone
in accordance with these instructions and all electrical
codes.
I
B. FOR DIRECTCONNECT
INSTALLATION
If an electricalsubbase isnot used,direct connection to
branch circuit wiring insidethe providedjunction box must
be done in accordance with the following steps.
Orderthe following Kit for 265-volt direct connection
asrequired:
Branch Circuit and Power
Unit Amperage Rating Supply Kit
15 RAK5157
20 RAK5207
:30 RAK5307*
*Not approved for use on 7000 BTUmodels.
Proceed to the "MAKE ELECTRICALCONNECTION TO THE
UNIT" section.
NOTE:Order Kit RAK4002CWto enable a quick
disconnect inside the junction box. I
14

Installation Instructions
I
MAKE ELECTRICAL CONNECTION TO THE UNIT
m REMOVE JUNCTION BOX
1. Removethejunction boxcover by removing the front
two screws.
2. Removethe junction box by removing the top and
bottom rear screws. Note how the tabs on the lower
left sideof thejunction box serveto hold the sidein
place.Thiswillhelpwhenthe boxisbeing reinstalled.
Unitconnector
Junction
boxcover
\Junction
box
Izl CONNECT THE CORDSET
Plug the connector, provided in the Direct Connect Kit,
fully into place in the unit mating connector. Be sure
the locking tabs at the sides are engaged.
NOTE:Order Kit RAK4OO2CWto enable a quick
disconnect inside the junction box. I
IYJATTACH CONDUIT
1. Usethe roundknockoutatthe bottomofthejunction box
to attachconduitcomingfrom the branchcircuit.
Removetheknockout,attachthe conduitand bringwires
intothejunction box.Leave6" ofwirefreeattheend of
theconduitto allowconnectionsto be made.
2. If a fuse and fuseholder are to be used,the
knockout at the top of the box isfor mounting
a Bussfuseholder. Besurethe fuse and fuseholder
ore of the same rating asthe branch circuit.
Leadwiresat the fuse can be either soldered in place
or attached using UL-listed1/4" female (receptacle)
crimp connectors. Follow localcodes.
_-I REINSTALL JUNCTION BOX
• Reinstallthejunction box byengaging the left tabs
on the lower right face of the unit, aligning the screw
holesat the top and bottom and driving the two
screws until secure.Be surethat allwire leadsare
insidethe boxand not pinched between the box and
the unit. Thegreen insulated ground wire from the unit
MUSTbe connected to the branch circuit ground wire.
Make all wire connections by using appropriate
UL-listedelectrical connectors and techniques
(blackto black,white to white and green to green).
[] REINSTALLJUNCTION BOXCOVER
1. Carefullytuck all wires and connections back inside
thejunction box.Besure there are no loose
connections or stray uninsulated wires exposed.
2. Placethejunction box cover in place. Replacethe two
screws removed earlier and tighten securely.
15

Installation Instructions
POWER CONNECTION CHART
Power Cord Connections
230/208 Volt
Power Supply Kits
with Current Leakage
Detection Device
RAK3153A I
RAK3203A
RAK3303*
Wall Plug
Configuration
Tandem J
Perpendicular
Large Tandem
Circuit Protective Device Heater Wattage
@230/208 Volts
15-Amp Time-Delay Fuse or Breaker
20-Amp Time-Delay Fuse or Breaker
30-Amp Time-Delay Fuse or Breaker
2.40/2.32 KW
3.30/3.20 KW
4.70/4.53 KW
Direct Connections
230/208 Volt
Power Supply Kits
RAK4157 I
RAK4207
RAK4307*
265 Volt
Power Supply Kits
Circuit Protective Device
15-Amp Time-Delay Fuseor Breaker
20-Amp Time-Delay Fuseor Breaker
30-Amp Time-Delay Fuseor Breaker
Heater Wattage
@2301208Volts
Circuit Protective Device
2.40/2.:32 KW
:3.30/3.20 KW
4.70/4.53 KW
RAK5157 J 15-Amp Time-Delay Fuseor Breaker
RAK5207 J 20-Amp Time-Delay Fuseor Breaker
RAK5307* 30-Amp Time-Delay Fuseor Breaker
*Not approved for use on 7000 BTUHunits.
Heater Wattage
@ 265 Volts
2.40 KW
:3.40 KW
4.80 KW
16

Installation Instructions
INSTALLING THE ZONELINE
[] INSTALL THE WALL CASE AND
EXTERIOR GRILLE
TheRAB71Aseriesor RAB77A4wall case must be
properly installed per instructions packed with the case.
• Removethe corrugated stiffener and the outdoor
protective panel. Usethe slit in the outdoor panel
asa handhold and push out.
panel
Stiffener
• Installthe exterior grille from the room sidefollowing
instructions packed with the grille.
Insulated Wall Case
Thisunit is designedto be installed in a GEplastic
or an insulated steelwall case.This minimizes
condensation from forming on the room sideof
the case.
TheRAB71Aserieswall casesare insulated.Insulation kit
RAK901Lisavailable for usewith RAB77A4or existing
uninsulated wall caseswhen needed.
NOTE:Forinstallation with a subbase or duct adapter,
seethe instructions packed with those kits.
IYI PREPARE THE UNIT
• Carefullyremove shippingtape and foam shipping
blocksfrom the room cabinet, compressor and
vent door. Theremay be multiple blocks and pieces
of shipping tape that need to be removed.
(Locationsma,
• Removethe room cabinet by pulling itout at the
bottom to releaseit (1);then lift it up to clear the rail
along the unit top (2).
• Ifvent door isto be operational, removeshippingscrews
from the front sideofthe vent door,ifpresent.
Removetwo
screws
(ifoperationis
desired)
17

Installation Instructions
INSTALLING THE ZONELINE (cont.)
IYI INSTALL THE UNIT INTO THE
WALL CASE
Slidethe unit into the wall case and secure with four
screws through the unit flange holes.
NOTE:There are several extra holes in the unit side
flanges for installation in wall cases other than GE.
To avoid damaging the flange insulation, the installer
should use an awl or other sharp tool to puncture the
insulation in the appropriate holes before installing the
attachment screws.
[] REPLACE THE ROOM CABINET
Reinstallthe room cabinet byhooking the top over
the rail along the unit top (D,then pushing it in at
the bottom (2).
18

Installation Instructions
OPTIONAL--DRAIN KIT INSTALLATION
Dry Air 25 Series models are designed to improve dehumidification by 25%. Since more moisture will be removed from
the air, there is a greater possibility that water will drip from the wall case than with a standard unit. To prevent this
water from dripping onto external building walls, we recommend the use of RADIO Drain Kit.
External Drain
See the Installation Instructions
in the RADIOkit.
Squaredrainholes
Steelmountingplate
"_g -._-_Type "A" screw for metal case or
Type"B"screwfor moldedcase
Alternate:
6" long,1/2" 0.D.straight
coppertube
Internal Drain
See the Installation Instructions in
the RADIOkit.
(Thedrainis located
underthecabinet)
Squaredrainholes Neoprenespongegasket
Steelmountingplate
- _ ,ty_l._Type "A" screw for metal case or
Type"B"screwfor moldedcase
19

Beforeyou call for service...
TrOubleshooting Tips
Save time and money! Review the charts on the
following pages first and you may not need to call for
ervice.
Problem Possible Causes What To Do
Zoneline does The unit is • Hake surethe Zoneline plug ispushed completely
not start unplugged, into the outlet.
The power cord is not • Removethe room cabinet and make sure that the
firmly attached, yellow connector on the end ofthe power cord is
firmly engaged.
Thefuse isblown/circuit • Checkthe housefuse/circuit breaker box and replace
breaker istripped, the fuse or reset the breaker.
The unit is waiting for • Thisisnormal. TheZonelinewill start again after
the campressor overload it resets.
protector to reset.
Power failure. • Ifpower failure occurs,set the mode control to STOP.
When power isrestored,set the mode control to the
desiredsetting.
• Thereisa protective time delay(up to 3 minutes)to
prevent tripping of the compressor overload. Forthis
reason,the unit may not start normal heating or cooling
for 3 minutes after it isturned back on.
Thecurrent interrupter
device is tripped. • Pressthe RESETbuttonlocated on the power cord plug or the box near the plug.
• Ifthe RESETbutton will not stay engaged,discontinueuse
ofthe Zonelineand contact a qualified servicetechnician.
Zoneline does not cool Indoor airflow • Hakesurethere are no curtains, blinds or furniture
or heat as it should is restricted, blocking the front of the Zoneline.
Buming odor at the start
of heating operation
Outdoor airflow is
restricted or recirculated. • Hake surethe rear grille isnot restricted.Thiscon
cause the unitto cycle off due to the compressor
overload protector.
• Outdoor grille must have a minimum of 65% free area.
Non-GEgrillesmay betoo restrictive for proper
performance. Consultyour salespersonfor assistance.
The temp control may • Turn the control to a lower or higher setting.
not be set properly. NOTE:The temperature limiter may be limiting the
temperature range.
The air filter is dirty. • Clean the filter at least every 30 days.
See the Operating Instructions section.
The room may hove • When the Zoneline isfirst turned on you need to
been hot or cold. allow time for the room to cool down or warm up.
Outdoor air is • Set the vent control to the closed position.
entering the room.
Dust is on the surfoce
of the heating element. • This con cause a "burning" odor at the beginning of the heating operation. This odor should quickly fade.
20
