GE Monogram ZGU3650 User guide

Specification Created 7/00
Monogram.
™
ZGU3650—GE Monogram 36” Updraft Cooktop with 5 Burners
Dimensions and Specifications (in inches)
Note:
Reference, Updraft Cooktop Installation Instructions, packed with product, for complete details.
*LP Gas Conversion JXLP56 must be ordered for LP applications.
Important:
Must order a white JXBA56WW or black JXBA56BB housing and blower assembly kit. JBXC55
optional outdoor cover accessory may be ordered for installation of motor and blower assembly
on outside wall.
†See written warranty for details.
2-15/16"
min.
3"
36" 19-3/4"
34-7/16"
8"
min. to
side wall
2-1/4"
min. to
front edge
8" min. to side
wall
18-5/16"
2" Min
Below Bottom
Of Counter
1-5/8" From Right
of Cutout
5/8" Forward of
Back of Cutout
For answers to your Monogram,
®
GE Profile Performance Series,
™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.

For answers to your Monogram,
®
GE Profile Performance Series,
™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
Monogram.
™
Specification Created 7/00
Dimensions and Clearances (in inches) Advance Planning
19-3/4"
36"
3"
18-1/8"
4-5/8" Min.
to Vertical
Combustible
Surface
2-1/4"
Min.
34-1/2"
8-13/16" Min.
to Wall
13"
Max.
36" Min.
3-7/8" Min.
to Vertical
Combustible
Surface When
Installed
8" Min. to Wall
When Installed
Both Sides
1-1/2" Min. to Front of
Countertop When Installed
18"
Min.
30"
Min.
• Refer to “Installation Preparation”, found in
installation instructions packed with product,
for information on appropriate placement and
necessary clearances when planning installation.
• Avoid placing cabinetry directly above cooktop
when possible.
• If cabinetry is used above the cooking surface:
–Use cabinets no more than 13” deep.
–Maintain 30” minimum clearance between
the cooktop and unprotected cabinets directly
above the cooktop.
–If clearance is less than 30”, protect cabinet
bottoms with flame-retardant millboard at least
1/4” thick, or gypsum board at least 3/16” thick,
covered with 28 gauge sheet steel or .02”
thick copper.
–Clearance between cooktop and protected
cabinetry must not be less than 24”.
–An exhaust hood that projects at least 5”
beyond front of cabinets can reduce risk of
burns caused by reaching over heated
surface units.
–Working areas adjacent to the cooktop should
have 18” minimum clearance between cooktop
and cabinet bottom.
• Use the Monogram gas updraft cooktop with any
36” or wider exhaust hood, if desired; no special
ventilation is required.
• Installation must conform with local codes. In the
absence of local codes, the gas cooktop must
comply with the National Fuel Gas Code,
ANSI Z223.1, latest edition.
ZGU3650—GE Monogram 36”Updraft Cooktop with 5 Burners

For answers to your Monogram,
®
GE Profile Performance Series,
™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
Monogram.
™
Specification Created 7/00
4-5/8" Min.
Cutout to Vertical
Combustible Surface
8-13/16" Min.
to Side Wall
8-13/16"
Min.
Cutout
To Side
Wall
34-1/2"
2-1/4"
Min. From
Front of
Countertop
18-1/8"
Cutout Information
Measure carefully when cutting countertop.
Make sure sides of opening are parallel and rear
and front cuts are exactly perpendicular to sides.
•The Monogram gas cooktop is designed to fit in
a 36”or larger base cabinet.
•The countertop cutout for cooktop must be:
–34-1/2”wide
–18-1/8”deep
–Allow at least 4-5/8”clearance between back
of cutout and wall.
–Allow at least 8-13/16”clearance from right
and left side of cutout to adjacent wall.
–Allow at least 2-1/4”clearance between front
of cutout and front edge of countertop.
•Cooktop requires 3”free space below countertop
•If installing cooktop above a cabinet with drawers,
is may be necessary to use a shorted length
drawer to allow clearance for gas connection.
•In some cases, two 3/8”I.D. 45°elbows and a
pipe nipple may be added between regulator and
cooktop to move regulator further back in order to
avoid interference with drawer.
ZGU3650—GE Monogram 36”Updraft Cooktop with 5 Burners
Cautioin:
Wallcoverings, countertops and cabinets should
withstand 200°F heat generated by the cooktop.

Specification Created 7/00
Monogram.
™
Features and Benefits
•36”Updraft Gas Cooktop
•Five Cooking Areas with Sealed Cooktop Burners
•(1) 12,000 BTU Gas Burner
•(3) 9,500 BTU Gas Burners
•(1) 5,000 BTU Gas Burner
•Burner Flame Stability Chamber
•Electronic Pilotless Ignition
•Tempered Glass Surface
•Continuous Porcelainized Burner Grates
•Front-Mounted Controls
•Model ZGU3650WBWG—White on white
•Model ZGU3650BBBG—Black on black
HIGH
OFF
LO
LIGHT
HIGH
OFF
LO
LIGHT
HIGH
OFF
LO
LIGHT HIGH
OFF
LO
LIGHT
HIGH
OFF
LO
LIGHT
Monogram.
ZGU3650—GE Monogram 36”Updraft Cooktop with 5 Burners
