GE ADT521PGFBS Manual

27-1/2"
24"*
MAX. 23-3/4"
3/ "
to
33- 8 MIN.
.
adj
34-5/8"AX
M
4"(toekick)
29-7/8"
*Add 2.4" for handle.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® Cafe™Series,
Profile™Series or GE®appliance questions, visit
our website at geappliances.com or call GE
Answer Center®service, 800.626.2000.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
ADT521PGF
GE Artistry™Series Dishwasher with Top Controls
Specification Revised 8/13 350243
Listed by
Underwriters
Laboratories
•The rough cabinet opening must be at least 24" deep,
24" wide and approximately 34-1/2" high from floor to
underside of the countertop.
4"
6"
5" 5"
4"
Figure A
Floor MUST be Even
With Room Floor
Cabinets
Square
and
Plumb
This Wall Area
must be Free
of Pipes or
wires
24"
Min.
24"
Min.
33-1/2" to 34-3/4"
Underside of
Countertop
to Floor
Plumbing and Electric Service
Must Enter Inside This Area
Electrical Rating
Voltage AC.......................................................... 120
Hertz..................................................................... 60
Total connected load amperage............. 7.1
Calrod®heater watts......................... 415/800
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.

ADT521PGFBS_ADT521PGFWS
Features and Benefits
• GE’s most advanced wash system - Consistently clean and dry dishes are ensured with
GE’s most advanced wash system, featuring 65% more wash power.*
*Wash power delivered to each rack. Compared to previous GE models.
• Piranha™Hard Food Disposer with Removable Filter - To ensure consistently clean
items, this stainless steel blade rotates at 3,600 RPM to pulverize food particles and
helps to prevent large particles from clogging the wash arms
• Steam PreWash - Loosens tough soils before any cycle virtually eliminating the need
for soaking or pre-rinsing dishes
• Sanitize option (NSF Residential) - High-temperature rinse sanitizes and reduces 99.99%
of bacteria found on dishes
• SpaceMaker®Silverware Basket - Enjoy table-ready silverware and loading flexibility
with this unique basket that can be placed on the rack or onto the door
• Pearlescent dark gray nylon racks with ball tip tines - Offer durability and secure dishes
• 2/4/8-Hour Delay Start - Wash dishes at your convenience
• Model ADT521PGFWS - White
• Model ADT521PGFBS - Black
ADT521PGF
GE Artistry™Series Dishwasher with Top Controls
Specification Revised 8/13 350243
