GE Profile 1496508 User manual

49-3000244 Rev 1
SAFETY INFORMATION .........3
USING THE DRYER................5
Appliance Communication ............ 5
LOADING ..........................9
VENTING .........................10
CARE AND CLEANING .......... 11
TROUBLESHOOTING TIPS......12
LIMITED WARRANTY ...........15
CONSUMER SUPPORT ..........16
ENGLISH/ FRANÇAIS/
ESPAÑOL
OWNER’S MANUAL
Write the model and serial
numbers here:
Model #_________________
Serial # _________________
They are on the label on
the front of the dryer
behind the door.
07-21 GEA
DRYERS
GE is a trademark of the General Electric Company. Manufactured under trademark license.

249-3000244 Rev 1
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.

49-3000244 Rev 1 3
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
WARNING
To reduce the risk of fire, explosion, electric shock, or injury to persons when using your
appliance, follow basic precautions, including the following:
Ŷ
Read all instructions before using the appliance.
Ŷ
DO NOT dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline,
dry-cleaning solvents, or other flammable or explosive substances, as they give off vapors that could ignite
or explode.
Ŷ
DO NOT place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a load to catch fire. To reduce the risk of fire due to
contaminated loads, the final part of the tumble dryer cycle occurs without heat (cool down period). Avoid
stopping a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
Ŷ
DO NOT allow children to play on or in this appliance. Close supervision of children is necessary when this
appliance is used near children.
Ŷ
Before the appliance is removed from service or discarded, remove the door to the drying compartment.
Ŷ
DO NOT reach into the appliance if the drum is moving.
Ŷ
DO NOT install or store this appliance where it will be exposed to the weather.
Ŷ
DO NOT tamper with controls.
Ŷ
DO NOT climb or stand on this unit.
Ŷ
DO NOT repair or replace any part of this appliance or attempt any servicing unless specifically recommended
in the user-maintenance instructions or in published user-repair instructions that you understand and have the
skills to carry out.
• Follow all fabric care instructions and warnings to prevent melting of garments or damage to the appliance.
Ŷ
DO NOT use fabric softeners or products to eliminate static unless recommended by the manufacturer of the
fabric softener or product.
Ŷ
DO NOT dry articles containing foam rubber or similarly textured rubber-like materials.
Ŷ
Clean lint screen before or after each load.
Ŷ
DO NOT operate the dryer without the lint filter in place.
Ŷ
DO NOT store combustible materials, gasoline or other flammable liquids near the dryer. Keep area around
the exhaust opening and adjacent surrounding areas free from the accumulation of lint, dust and dirt.
Ŷ
The interior of the appliance and exhaust duct should be cleaned periodically by qualified service personnel.
Ŷ
Unplug the appliance or turn off the circuit breaker before servicing. Pressing the Power or Start/Pause
button DOES NOT disconnect power.
Ŷ
DO NOT operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or
broken parts, including a damaged cord or plug.
Ŷ
DO NOT spray any type of aerosol into, on or near dryer at any time. DO NOT use any type of spray cleaner
when cleaning dryer interior. Hazardous fumes or electrical shock could occur.
Ŷ
See “ELECTRICAL CONNECTION” located in the Installation Instructions for grounding instructions.
READ AND SAVE THESE INSTRUCTIONS
Proper Disposal of your Appliance
Ŷ
Dispose of or recycle your appliance in accordance with Federal and Local Regulations. Contact your local
authorities for the environmentally safe disposal or recycling of your appliance.
Ŷ
Consider recycling options for your appliance packaging material.

449-3000244 Rev 1
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
Failure to follow safety warnings exactly could result in serious injury, death, or property
damage.
- DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
Ŷ
DO NOT try to light any appliance.
Ŷ
DO NOT touch any electrical switch; DO NOT use any phone in your building.
Ŷ
Clear the room, building, or area of any occupants.
Ŷ
Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
Ŷ
If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency, or
the gas supplier.
ADDITIONAL GAS DRYER WARNINGS
- Fire or Explosion Hazard
WARNING

49-3000244 Rev 1 5
Throughout this manual, features and appearance may vary from your model.
• If the screen is dark,
press the Power
button to “wake up”
the display.
Step 2 Step 3 Step 4
Step 1
• Select a dry cycle. (Defaults are set
for each dry cycle. These default
settings can be changed. See the cycle
descriptions for more information.)
• Press the Start/
Pause button.
• Clean lint filter
• Loosely add items.
• Close door.
NOTE: Dryer will not
start with door open.
USING THE DRYER
Using the dryer
To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY
INFORMATION before operating this appliance.
WARNING
Appliance communication
WiFi Connect (For customers in the United States only - on some models)
Depending on the model, your dryer is either GE Appliances
WiFi Connect enabled, or compatible using the optional
GE Appliances U+ Connect module.
If enabled: Visit GEAppliances.com/connect and enter
your model number to show you the proper steps to
connect your appliance.
If compatible: To connect this appliance to the
internet you will need to purchase a GE Appliances
U+ Connect module and attach it to your appliance
through the communication port. The GE Appliances
U+ Connect module will allow your appliance to
communicate with your smartphone for remote
appliance monitoring, control and notifications.
WiFi Connectivity: For assistance with the appliance
or the GE Appliances U+ Connect network connectivity,
please call GE Appliances Connected Home Support at
800.220.6899.
Please visit GEAppliances.com/connect to learn
more about connected appliance features, to learn
what connected appliance apps will work with your
smartphone and to learn where you can purchase a
U+ Connect module.
The U+ Connect module has the FCC/IC ID located
on the back of the module.
Part Number Accessory
PBX23W00Y0 WiFi U+ Connect module
Ŷ
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Ŷ
DO NOT dry anything that has ever had anything
flammable on it (even after washing).
Ŷ
No washer can completely remove oil.
Ŷ
DO NOT dry anything that has ever had any type of oil
on it (including cooking oils).
Ŷ
Items containing foam, rubber, or plastic must be dried
on a clothesline.
Ŷ
Failure to do so can result in death, explosion, or fire.
- Fire Hazard
WARNING
NORMAL TOWELS
MIXED LOADS BULKY
DELICATES QUICK DRY
JEANS SANITIZE
DOWNLOADED TIMED DRY
Sheets
Cottons

649-3000244 Rev 1
A
B
C
Power
Press to “wake up” the display. If the display is active, press to put the dryer into idle mode.
NOTE: Pressing Power does not disconnect the appliance from the power supply.
Start and Pause
Press Start to begin the cycle. NOTE: The door must be closed for the dryer to start the cycle. Pressing Start
again will pause the cycle, the Start light will blink and “Pause” will display.
To continue the cycle, press Start again.
Display and Status Lights
The display shows the approximate time remaining until the end of the cycle.
In addition, this display will show the dryer status:
Features and appearance will vary.
Using the dryer
USING THE DRYER
Pause
(on some models) The Start/Pause light will flash and the message “Pause” will show in the display when the dryer’s cycle is paused. The cycle may be re-started by pressing the Start button.
WiFi
(on some models)
Will allow your appliance to communicate with your smartphone for remote appliance
monitoring control and notifications.
Controls The dryer is locked - will blink once if you press any button or turn the cycle knob.
Sensing Indicates the dryer is sensing the level of dampness to determine estimated cycle time
remaining.
Clean Lint Filter The Clean Lint Filter light will stay on for 15 seconds after the cycle stops.
Vent Blocked
(on some models)
The Vent Blocked light indicates an issue has been found due to reduced airflow from a
possible blocked or restricted vent. Checking and/or cleaning the vent system is recommended.
See the, “Vent Blocked” light is on in the Troubleshooting Tips section.
Sensing Garments need additional time to be dried.
Drying Clothes dryer is removing moisture.
Cooling Air fluff cooling time after drying process.
Done Cycle has been completed and it will display the legend “END”.
Vent + Test Venting system diagnostic test.
A E
B F HI J
GC
A
A
E
E
G
G
G
C
C
C
NORMAL TOWELS
MIXED LOADS BULKY
DELICATES QUICK DRY
JEANS SANITIZE
DOWNLOADED TIMED DRY Damp Alert
My CycleTemp Level
Time
ecoDry
Sheets
Cottons
10
20
40
60
90 min
Hold 3s to Save
Hot Max Dry
No Heat Damp
Washer Link Wrinkle Care
BlockedVent Test
Clean Lint Filter
Sensing Cooling DoneDrying
DK

49-3000244 Rev 1 7
E
F
USING THE DRYER
Using the dryer
Drying
Cycles
Sensor cycles automatically determine fabric dryness.
Timed cycles run for the selected time.
SANITIZE This option reduces certain types of bacteria including: Staphylococcus aureus, Pseudomonas
aeruginosa and Klebsiella pneumoniae. The anti-bacterial process occurs when high heat is
used during a portion of the drying cycle; cool down also will be longer to protect you from a hot
garment.
NOTE: Do not use this cycle on delicate fabrics.
BULKY For large coats, bed spreads, mattress covers, sleeping bags, and similar large/bulky items such
as blankets, comforters, jackets, and small rugs.
TOWELS/
Sheets For most towels and linens.
NORMAL/
Cottons For cottons and most linens. NOTE: ENERGY STAR®models are tested on NORMAL/ Cottons with default settings (Dry level, Hot temperature and ecoDry).
MIXED LOAD For loads consisting of cottons and poly-blends.
DOWNLOADED A cycle with 3 options through the GE Appliances Laundry App:
Casual (Default): Wrinkle care and permanent press items.
Active Wear: Special sport items that need extra drying care.
Warm Up: Provides 10 minutes of heating to warm up clothes.
DELICATES For delicate items, special-care fabrics and knits.
QUICK DRY For small loads that are needed in a hurry, such as sport or school uniforms. Can also be used if the
previous cycle left some items damp, such as collars or waistbands. NOTE: On some models, the
time remaining in the cycle will show counting down in the display.
JEANS For jeans.
TIMED DRY Set the Cycle Selector at the desired drying time.
WARM UP Provides 10 minutes of warming time to warm up clothes.
AIR FLUFF Provides 10 minutes of tumbling time with no heat. NOTE: On models without AIR FLUFF
cycle, select TIMED DRY and set Temp to No Heat.
ecoDry
Available for BULKY, TOWELS/Sheets, NORMAL/Cottons, MIXED LOAD, JEANS, and DELICATES. When
the ecoDry button is pressed, cycle settings change to reduce the total energy consumption of the selected
sensor cycle. NOTE: Cycle times will change when ecoDry is selected. The ecoDry option will default to on
for NORMAL/Cottons. For optimal energy savings, turn ecoDry on. For optimal drying times, turn ecoDry
off. NOTE: Energy savings will vary across loads and cycles.
DControl Lock
You can lock the controls to prevent any selections from being made. Or you can lock the controls after you have
started a cycle. Children cannot accidentally start the dryer by touching buttons with this option selected.
To lock/unlock the dryer controls, press and hold the ecoDry button for 3 seconds. The control lock icon will
flash while locking/unlocking, stay on when locked, and turn off when unlocked.
NOTE: The Power button can still be used when the machine is locked.

849-3000244 Rev 1
Settings
Individual settings for cycle minutes (Time), dryness level (Level) and temperature (Temp) can be set from the
minimum (lowest in column) to maximum (highest in column). In general, the higher up the column, the more
energy will be used.
H
I
J
G
Using the dryer
USING THE DRYER
Dryness Level Description Light ON from bottom
indicates setting:
Max Dry Use for heavy-duty fabrics. 5
More Dry Use for mixed type fabrics. 4
Dry Use for a normal dryness level suitable for most loads. This is the
preferred cycle for energy savings. 3
Less Dry Use for lighter fabrics. 2
Damp For leaving items partially damp. 1
Temperature Description Light ON from bottom
indicates setting:
Hot For regular to heavy cottons. 5
Medium For synthetics, blends, delicates and items labeled permanent press. 4
Low For delicates, synthetics and items labeled tumble dry low. 3
Extra Low For delicates, synthetics and items labeled extra care or gentle dryness. 2
No Heat For fluffing items without heat. For use only with the TIMED DRY cycle. 1
Wrinkle Care
Use this option to minimize the wrinkles in clothes. It provides 1 hour of no-heat tumbling after the clothes are
dry. If you have Sound option enabled and you select the Wrinkle Care option, a signal will sound at the end of
the drying time and several times during the Wrinkle Care cycle. This will remind you that it is time to remove
the clothes.
Sound
Press and hold the Wrinkle Care button for 3 seconds to toggle Sound option between enabled and disabled.
“Sound on” will show on the display and a tone will play when enabled. “Sound off” will show on the display
and no tone will play when disabled.
Damp Alert
This option causes the dryer to beep when clothes have dried to a damp level. Remove items that you wish
to hang dry. The Damp Alert will only beep when this option is selected (but the dry cycle will keep running).
Removing clothes and hanging them when they are damp, can reduce the need to iron some items. The light
beside the button will be lit when Damp Alert is on.
Drum Light
The drum light will turn on if, the Damp Alert button is pressed for 3 seconds, or the door is opened. It will turn
off when the door is shut, the Damp Alert button is pressed again for 3 seconds or after 5 minutes if the door is
left open.
• Remove garments promptly at the sound of signal. Place clothes on hangers so wrinkles will not set in.
• Use the Damp Alert especially when drying fabrics like polyester, knits and permanent press. These fabrics
should be removed so wrinkles will not set in.
My Cycle
As the cycle selector knob is turned, the Time (timed dry), Level (dryness level) and Temp (temperature)
settings change to automatic pre-set default settings. If you desire a different setting, press the appropriate
button(s). Then press and hold the My Cycle button for 3 seconds and the dryer will “remember” these settings
for that Knob Selection. In the future, when you turn the selector knob to that cycle, your settings will be
automatically recalled. NOTE: Signal sound cannot be set for My Cycle.
Washer Link
This feature wirelessly links your washer to your dryer and uses the connection information to automatically
adjust the settings of your dryer for the clothes just washed. If the dryer has a valid WiFi connection, and the
Washer Link option is selected, either via the button or the App, the light above the button will be lit. If the
option is not selected then the light will turn off. If the dryer does not have a valid WiFi connection, and this
option is selected, either via the button or the App, the WiFi light and the Washer Link light will blink and an
error tone will play.
K

49-3000244 Rev 1 9
Drying Rack (on some models)
A handy drying rack may be used for drying delicate items such as
washable sweaters.
To install the drying rack:
1Lift the lint filter slightly. (Do not remove the lint filter completely).
2Place the rack in the dryer and lower its front legs and hook them in
the slots.
3Press the rack down flat and lower the lint filter back down into
position.
NOTES:
• The drying rack must be used with the TIMED DRY cycle. Use with
sensor cycles may result in damp items or extended cycle times.
• Do not use this drying rack when there are other clothes in the dryer.
• If your model did not come with a drying rack, order WE01X25160
on-line at GEApplianceparts.com, 24 hours a day or by phone at
877.959.8688 during normal business hours.
Always follow fabric manufacturer’s care label when laundering.
As a general rule, if clothes are sorted properly for the washer, they are sorted properly for the dryer. Try also to
sort items according to size. For example, do not dry a sheet with socks or other small items.
Do not add fabric softener sheets once the load has become warm. They may cause fabric softener stains. Bounce®
Fabric Conditioner Dryer Sheets have been approved for use in this dryer when used in accordance with the
manufacturer’s instructions.
Do not overload. This wastes energy and causes wrinkling.
Sorting and Loading Hints
LOADING
Loading
Lift filter and hook front
rack legs into slots
Ŷ
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Ŷ
DO NOT dry anything that has ever had anything
flammable on it (even after washing).
Ŷ
No washer can completely remove oil.
Ŷ
DO NOT dry anything that has ever had any type of oil
on it (including cooking oils).
Ŷ
Items containing foam, rubber, or plastic must be dried
on a clothesline.
Ŷ
Failure to do so can result in death, explosion, or fire.
- Fire Hazard
WARNING

10 49-3000244 Rev 1
VENTING
Venting
Venting the Dryer
For the best drying performance, the dryer needs to be properly vented. The dryer will use more energy and run longer if it is
not vented to the specifications below. Carefully follow the details on Exhausting in the Installation Instructions.
Use only rigid metal 4” diameter ductwork inside the dryer cabinet. Use only rigid metal or UL listed flexible metal 4”
diameter ductwork for exhausting to the outside.
Do not use plastic or other combustible ductwork.
Use the shortest length possible.
Do not crush or collapse.
Avoid resting the duct on sharp objects.
Venting must conform to local building codes.
This dryer MUST be exhausted to the outdoors.
Use only 4” rigid metal ducting for the home exhaust duct.
Use only 4” rigid metal or UL-listed dryer transition duct to connect the dryer to the home exhaust.
DO NOT use a plastic vent.
DO NOT exhaust into a chimney, kitchen exhaust, gas vent, wall, ceiling, attic, crawl space, or
concealed space of a building.
DO NOT install a screen in or over the exhaust duct.
DO NOT install a booster fan in the exhaust duct.
DO NOT use duct longer than specified in the exhaust length table.
Failure to follow these instructions can result in death or fire.
WARNING - Fire Hazard
Correct
Venting
Incorrect
Venting
Vent Health
Is a diagnostic test to verify the status of the venting system. NOTE: To run the test, ambient temperature must be
below 85°F (if temperature is above 85°F the test will be invalid and the main display will show “00”).
To enter Vent Health test mode:
1Ensure the drum is empty.
2Ensure the lint filter is clean.
3Press and hold the Time and Level buttons for 3 seconds.
4Close the door and press Start.
After the test is run, the display will show a number. Use the table below to understand the result and the action needed.
Main Display LED Display Result Action*
01 OFF Clean/Normal Your house vent is in good condition
and no action is required.
02 OFF May need attention
Your house vent condition may affect your
dryer’s performance. Check and clean
or make adjustments to improve.
03 Vent Blocked Blocked
Your house vent is highly restricted and
is affecting your dryer’s performance.
Clean and/or make needed
adjustments to improve.
*Also see Interior and Duct in the Care and Cleaning section.

49-3000244 Rev 1 11
Lint Filter
Clean the lint filter before each use.
Remove by pulling straight up. Run your fingers across the filter. A waxy buildup may
form on the lint filter from using dryer added fabric softener sheets.
To remove this buildup, wash the lint screen in warm, soapy water. Dry thoroughly
and replace.
Vacuum the lint from the dryer lint filter area if you notice a change in dryer
performance.
NEVER OPERATE THE DRYER WITHOUT ITS FILTER IN PLACE.
CARE AND CLEANING
Care and Cleaning
Exterior
Wipe or dust any spills or washing compounds with a damp cloth. Dryer control panel and finishes may be damaged
by some laundry pretreatment soil and stain remover products. Apply these products away from the dryer. The fabric
may then be washed and dried normally. Damage to your dryer caused by these products is not covered by your
warranty.
Stainless Steel
To clean stainless steel surfaces use a damp cloth with a mild, non-abrasive cleaner suitable for stainless steel
surfaces. Remove the cleaner residue and then dry with a clean cloth.
The stainless steel used to make the dryer drum provides the highest reliability available in a GE Appliances dryer.
If the dryer drum should be scratched or dented during normal use, the drum will not rust or corrode. These surface
blemishes will not affect the function or durability of the drum.
Interior and Duct
The interior of the appliance and exhaust duct should be cleaned once a year by qualified service personnel.
The Exhaust Duct: Inspect and clean the exhaust ducting at least once a year to prevent clogging. A partially clogged
exhaust can lengthen the drying time.
Follow these steps:
1Turn off electrical supply by disconnecting the plug from the wall socket.
2Disconnect the duct from the dryer.
3Vacuum the duct with the hose attachment and reconnect the duct.
The Exhaust Hood: Check with a mirror that the inside flaps of the hood move freely when operating. Make sure that there
is no wildlife (birds, insects, etc.) nesting inside the duct or hood.
Drum Light
The drum light is an LED light. Replacement must be done by a qualified technician.

12 49-3000244 Rev 1
TROUBLESHOOTING TIPS
Troubleshooting Tips... Before you call for service
Problem Possible Cause What To Do
Dryer shakes or
makes noise Some shaking/noise is normal. Dryer may be sitting unevenly. Move dryer to an even floor space, or adjust leveling legs as necessary until even.
Clothes take
too long to dry Improper or obstructed ducting Check the Installation Instructions to make sure the dryer venting is correct.
Make sure ducting is clean, free of kinks and unobstructed.
Check to see if outside wall damper operates easily.
Improper sorting Separate heavy items from lightweight items (generally, a
well-sorted washer load is a well-sorted dryer load).
Large loads of heavy fabrics
(like beach towels) Large, heavy fabrics contain more moisture and take longer to dry.
Separate large, heavy fabrics into smaller loads to speed drying time.
Controls improperly set Match control settings to the load you are drying.
Lint filter is full Clean lint filter before every load.
Blown fuses or tripped
circuit breaker Replace fuses or reset circuit breakers. NOTE: Some electric dryers use 2 fuses/breakers, make sure both are operating.
Overloading/combining loads Do not put more than one washer load in the dryer at a time.
Underloading If you are drying only one or two items, add a few items to ensure
proper tumbling.
ecoDry is enabled The ecoDry feature is designed to operate your dryer in the
most energy efficient mode, which is not always the fastest
mode. In some instances, dry times may be extended to
reduce overall energy usage for the cycle.
The Dry dryness
level was
chosen but load
is still damp
Load consists of a mixture of
heavy and light fabrics When combining heavy and light fabrics in a load, choose Max Dry.
Exhaust system is blocked Inspect and clean exhaust system.
Dryer doesn’t
start Control panel is “asleep” This is normal. Press Power to activate the control panel.
Dryer is unplugged Make sure the dryer plug is pushed completely into the outlet.
Fuse is blown/circuit breaker
is tripped Check the building’s fuse/circuit breaker box and replace fuse or reset breaker. NOTE: Some electric dryers use two fuses/
breakers, make sure both are operating.
Dryer was accidentally paused
when starting Delay Dry If the light on the Start/Pause button is flashing, the dryer is paused. Press Start/Pause to restart the countdown.
No numbers
displayed
during cycle,
only lights
Dryer is continuously
monitoring the amount of
moisture in the clothes
This is normal. When the dryer senses a low level of moisture in
the load, the dryer will display the dry time remaining.
Time Remaining
jumped to a
lower number
The estimated time may
change when a smaller load
than usual is drying
This is normal.
Cannot make a
selection and
the dryer beeps
twice
The dryness Level, Temp or
option that you are trying to
select is incompatible with
the chosen dry cycle
This is normal.
Dryer is running
but 00 is
displayed in
Time Remaining
The Wrinkle Care option
was chosen This is normal. During extended tumbling, the time remaining is not displayed. The extended tumbling option lasts approximately
60 minutes.
“Vent Blocked”
light is on
Lint filter is full Clean lint filter, dry a load on an automatic cycle and verify that
light turns off.
Improper or obstructed
ducting Check the Installation Instructions to make sure the dryer venting is correct.
Make sure ducting is clean, free of kinks and unobstructed. Check
to see if outside wall damper operates easily.
Dry a load on an automatic cycle and verify that light turns off.
Exhaust system is blocked Inspect and clean the exhaust system.
Dry a load on an automatic cycle and verify that light turns off.

49-3000244 Rev 1 13
Troubleshooting Tips... Before you call for service
TROUBLESHOOTING TIPS
Problem Possible Causes What To Do
Dryer doesn’t
heat Fuse is blown/circuit breaker is tripped; the dryer may
tumble but not heat
Check the building’s fuse/circuit breaker box and replace both
fuses or reset both breakers. Your dryer may tumble if only one
fuse is blown or one breaker tripped. NOTE: Some electric
dryers use 2 fuses/breakers, make sure both are operating.
Gas service is off (gas
models only) Make sure gas shutoff at dryer and main shutoff are fully open.
LP gas supply tank is empty
or there has been a utility
interruption of natural gas
(gas models only)
Refill or replace tank. Dryer should heat when utility service is
restored.
No heat temperature selected Select another heat setting
Inconsistent
drying times Type of heat Drying time will vary according to the type of heat used. If you recently changed from an electric to a gas (natural or LP)
dryer, or vice versa, the drying time could be different.
Type of load and drying
conditions The load size, types of fabric, wetness of clothes and the length and condition of the exhaust system will affect drying
times.
Clothes are still
wet and dryer
shut off after a
short time
The door was opened
mid-cycle. The load was then
removed from the dryer and
a new load put in without
selecting a new cycle
A dry cycle must be reselected each time a new load is put in.
Small load When drying 3 items or less, choose QUICK DRY or TIMED DRY.
Load was already dry except
for collars and waistbands Choose QUICK DRY or TIMED DRY to dry damp collars and
waistbands. In the future, when drying a load with collars and
waistbands, choose More Dry.
Dryer is not level Move dryer to an even floor space or adjust leveling legs as
necessary until even.
Clothes are
wrinkled Overdrying Select a shorter drying time. Remove items while they still hold a slight amount of moisture.
Select a Less Dry or Damp setting.
Letting items sit in dryer after
cycle ends Remove items when cycle ends and fold or hang immediately, or use the Wrinkle Care option.
Overloading Separate large loads into smaller ones.
Clothes shrink Some fabrics will naturally
shrink when washed. Others
can be safely washed, but
will shrink in the dryer.
To avoid shrinkage, follow garment care labels exactly.
Some items may be pressed back into shape after drying.
If you are concerned about shrinkage in a particular
item, do not machine wash or tumble dry it.
Greasy spots
on clothes Improper use of fabric softener Follow directions on fabric softener package.
Drying dirty items with clean
ones Use your dryer to dry only clean items. Dirty items can stain clean items and the dryer.
Clothes were not completely
clean Sometimes stains which cannot be seen when the clothes are wet appear after drying. Use proper washing procedures before drying.
Lint on clothes Lint filter is full Clean lint screen before each load.
Improper sorting Sort lint producers (like chenille) from lint collectors (like corduroy).
Static electricity can attract
lint See suggestions in this section under Static occurs.
Overloading Separate large loads into smaller ones.
Paper, tissue, etc., left in
pockets Empty all pockets before laundering clothes.

14 49-3000244 Rev 1
TROUBLESHOOTING TIPS
Troubleshooting Tips... Before you call for service
Problem Possible Causes What To Do
Static occurs No fabric softener was used Try a fabric softener.
Bounce®Fabric Conditioner Dryer Sheets have been approved for
use in all GE Appliances dryers when used in accordance with the
manufacturer’s instructions.
Overdrying Try a fabric softener.
Adjust setting to Damp.
Synthetics, permanent press
and blends can cause static Try a fabric softener.
Collars and
waistbands still
wet at end of
cycle
The dryness monitor senses
that the body of the clothes
is dry
Choose QUICK DRY or TIMED DRY to dry damp collars and
waistbands. In the future, when drying a load with collars and
waistbands, choose Max Dry.
Slight variation
in metallic color This is normal Due to the metallic properties of paint used for this unique product, slight variations of color may occur due to viewing angles and
lighting conditions.
Dryer continues
to tumble after
display says
Complete
Wrinkle Care was selected Ensure Wrinkle Care option is not selected.

49-3000244 Rev 1 15
GEAppliances.com
All warranty service is provided by our Factory Service Centers, or an authorized Customer Care®technician. To schedule
service online, visit us at GEAppliances.com/service, or call GE Appliances at 800.GE.CARES (800.432.2737). Please
have your serial number and your model number available when calling for service.
Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE Appliances factory
service technician the ability to quickly diagnose any issues with your appliance and helps GE Appliances improve its
products by providing GE Appliances with information on your appliance. If you do not want your appliance data to be
sent to GE Appliances, please advise your technician not to submit the data to GE Appliances at the time of service.
LIMITED WARRANTY
GE Appliances Dryer Limited Warranty
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
For the period of: We will replace:
One year
From the date of the
original purchase
Any part of the dryer which fails due to a defect in materials or workmanship. During
this limited one-year warranty, we will also provide, free of charge, all labor and
related service to replace the defective part.
What is not covered:
ŶService trips to your home to teach you how to use
the product.
ŶImproper installation, delivery or maintenance.
ŶFailure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
ŶReplacement of house fuses or resetting of circuit
breakers.
ŶProducts which are not defective or broken, or which
are working as described in the Owner’s Manual.
Ŷ 'DPDJHWRWKHSURGXFWFDXVHGE\DFFLGHQWILUH
floods or acts of God.
Ŷ ,QFLGHQWDORUFRQVHTXHQWLDOGDPDJHFDXVHGE\
possible defects with this appliance.
Ŷ 'HIHFWVRUGDPDJHGXHWRRSHUDWLRQLQIUHH]LQJ
temperatures.
Ŷ 'DPDJHFDXVHGDIWHUGHOLYHU\
Ŷ 3URGXFWQRWDFFHVVLEOHWRSURYLGHUHTXLUHGVHUYLFH
Extended Warranties: Purchase a GE Appliances extended warranty and learn about special discounts that are
available while your warranty is still in effect. You can purchase it online anytime at
GEAppliances.com/extended-warranty
or call 800.626.2224 during normal business hours. GE Appliances Service will still be there after your warranty expires.
In the United States:
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for home use
within the USA. If the product is located in an area where service by a GE Appliances Authorized Servicer is not available,
you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE Appliances
Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: GE Appliances, aHaier Company, Louisville, KY 40225
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or the
shortest period allowed by law.
In Canada:
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased in Canada
for home use within Canada. If the product is located in an area where service by a GE Appliances Authorized Servicer is
not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized
GE Appliances Service location.
Some provinces do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from province to province. To know what
your legal rights are, consult your local or provincial consumer affairs office.
Warrantor: MC Commercial Inc., Burlington, ON, L7R 5B6

16 49-3000244 Rev 1
Printed in Mexico
CONSUMER SUPPORT
Consumer Support
GE Appliances Website
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day
of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support
services designed for your convenience. In the US: GEAppliances.com.
In Canada: GEAppliances.ca.
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail in
the pre-printed registration card included in the packing material. In the US: GEAppliances.com/register.
In Canada: Prodsupport.mabe.ca/crm/Products/ProductRegistration.aspx.
Schedule Service
Expert GE Appliances repair service is only one step away from your door. Get on-line and schedule your service at
your convenience any day of the year. In the US: GEAppliances.com/service or call 800.432.2737 during normal
business hours.
In Canada: GEAppliances.ca/en/support/service-request or call 800.561.3344.
Extended Warranties
Purchase a GE Appliances extended warranty and learn about special discounts that are available while your
warranty is still in effect. You can purchase it on-line anytime. GE Appliances Services will still be there after your
warranty expires. In the US: GEAppliances.com/extended-warranty or call 800.626.2224 during normal business
hours.
In Canada: GEAppliances.ca/en/support/purchase-extended-warranty or call 866.277.9842.
Remote Connectivity
For assistance with wireless network connectivity (for models with remote enable), in the US visit our website at
GEAppliances.com/connect or call 800.220.6899.
In Canada: GEAppliances.ca/connect or call 800.220.6899.
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today 24 hours every day.
In the US: GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
In Canada: GEAppliances.ca/en/products/parts-filters-accessories or call 800.661.1616.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the
details including your phone number, or write to:
In the US: General Manager, Customer Relations | GE Appliances, Appliance Park | Louisville, KY 40225
GEAppliances.com/contact or call 800.626.2000
In Canada: Director, Consumer Relations, MC COMMERCIAL INC. | Suite 310, 1 Factory Lane | Moncton, N.B. E1C 9M3
GEAppliances.ca/en/contact-us or call 877.994.5366

49-3000244 Rev 1
CONSIGNES DE SÉCURITÉ ......3
UTILISATION
DE LA SÉCHEUSE.................5
CHARGEMENT ....................9
VENTILATION....................10
ENTRETIEN ET NETTOYAGE... 11
CONSEILS DE DÉPANNAGE....12
GARANTIE LIMITÉE .............15
SERVICE À LA CLIENTÈLE .....16
GUIDE DE
L’UTILISATEUR
07-21 GEA
GE est une marque déposée de General Electric Company. Fabriqué sous licence de marque.
SÉCHEUSES
Inscrivez ici les numéros
de modèle et de série :
Modèle #________________
Série #__________________
Ces informations figurent sur
l’étiquette située à l’avant de
la sécheuse, derrière la porte.
FRANÇAIS

249-3000244 Rev 1
NOUS VOUS REMERCIONS D’ACCUEILLIR GE APPLIANCES CHEZ VOUS
Que vous ayez grandi avec GE Appliances ou qu’il s’agisse de votre première acquisition, nous
sommes heureux de vous accueillir dans notre famille.
Nous sommes fiers du savoir-faire, de l’innovation et de l’esthétique qui composent chaque appareil
GE Appliances, et nous pensons que vous le serez aussi. Dans cette optique, nous vous rappelons
que l’enregistrement de votre électroménager vous assure la communication de renseignements
importants sur le produit et la garantie lorsque vous en avez besoin.
Enregistrez votre électroménager GE en ligne dès maintenant. Des sites Web et des numéros de
téléphone utiles figurent dans la section Soutien au consommateur de ce manuel d’utilisation. Vous
pouvez aussi poster la fiche de garantie préimprimée incluse dans l’emballage.

49-3000244 Rev 1 3
LIRE ET CONSERVEZ CES DIRECTIVES
CONSIGNES DE SÉCURITÉ IMPORTANTES
LIRE TOUTES LES CONSIGNES AVANT D’UTILISER L’APPAREIL
Pour réduire le risque d’incendie, d’explosion, de choc électrique ou de blessure aux
personnes utilisant cet appareil, observez des précautions élémentaires dont les suivantes :
Ŷ
Lisez toutes les instructions avant d’utiliser l’appareil.
Ŷ
NE séchez PAS les articles qui ont été précédemment nettoyés, lavés, trempés, ou détachés à l’aide d’essence,
de solvants de nettoyage à sec ou d’autres substances inflammables ou explosives, puisqu’ils peuvent émettre
des vapeurs susceptibles de s’enflammer ou d’exploser.
Ŷ
NE placez PAS d’articles exposés aux huiles de cuisson dans la sécheuse. Les articles souillés par les huiles de
cuisson peuvent faciliter des réactions chimiques susceptibles d’enflammer une brassée. Pour réduire le risque
d’incendie en raison de charges contaminées, la dernière partie du cycle de sèche-linge se produit sans chaleur
(période de refroidissement). Évitez d’arrêter une sécheuse avant la fin du cycle de séchage à moins que tous les
articles soient rapidement enlevés et répartis de telle sorte que la chaleur est dissipée.
Ŷ
N’autorisez PAS les enfants à jouer sur ou dans cet appareil. Une surveillance étroite est requise lorsque des
enfants se trouvent à proximité de l’appareil en fonctionnement.
Ŷ
Enlevez la porte de la sécheuse lorsque l’appareil est mis hors service ou au rebut.
Ŷ
NE vous penchez PAS dans l’appareil lorsque le tambour est en rotation.
Ŷ
N’installez PAS et ne rangez PAS cet appareil à un endroit exposé aux intempéries.
Ŷ
NE modifiez PAS les commandes.
Ŷ
ABSTENEZ-VOUS de grimper ou de vous tenir sur l’appareil.
Ŷ
NE réparez PAS cet appareil, en totalité ou en partie, en remplacez une quelconque pièce, à moins que cela ne
soit expressément recommandé dans les instructions d’entretien ou de réparation destinées à l’utilisateur dont
vous avez une compréhension et une compétence suffisantes pour les appliquer.
Ŷ
Suivez toutes les instructions et avertissements de soin des tissus pour éviter que les vêtements fondent ou des
dommages à l’appareil.
Ŷ
N’employez PAS de produits assouplissants NI d’agents antistatiques à moins que leur utilisation ne soit
recommandée par leurs fabricants.
Ŷ
NE sécher PAS des articles qui contiennent du caoutchouc mousse ou des matières à texture caoutchouteuse
similaire.
Ŷ
Nettoyez le filtre à charpie et nettoyez avant ou après chaque chargement.
Ŷ
N’utilisez PAS la sécheuse sans que le filtre à charpie ne soit en place.
Ŷ
NE rangez PAS de matières combustibles, de l’essence ni d’autres liquides inflammables à proximité de la
sécheuse. Gardez la zone autour de l’ouverture d’évacuation et tout l’espace adjacent libres de charpie, de
poussière et de saletés.
ŶL’intérieur de l’appareil et le tuyau d’évacuation doivent être nettoyés régulièrement par du personnel qualifié.
Ŷ
Débranchez l’appareil ou fermez le disjoncteur avant une réparation. Le fait d’appuyer sur le bouton Power
(Alimentation) ou sur le bouton Start/Pause (Mise en marche/pause) NE coupe PAS l’alimentation électrique.
Ŷ
NE faites PAS fonctionner cet appareil s’il est endommagé, ne fonctionne pas correctement, est en partie
démonté, ou encore si des pièces sont manquantes ou abîmées, y compris le cordon électrique ou sa fiche.
Ŷ
NE vaporisez AUCUN type d’aérosol dans, sur ou à proximité de la sécheuse, et ce en tout temps. N’utilisez
AUCUN type de nettoyant en vaporisateur lorsque vous nettoyez l’intérieur de la sécheuse. Cela poserait un
risque de vapeurs dangereuses ou de choc électrique.
Ŷ
Consultez la section « RENSEIGNEMENTS SUR LES RACCORDS ÉLECTRIQUES » des instructions
d’installation pour connaître la procédure de mise à la terre.
AVERTISSEMENT
CONSIGNES DE SÉCURITÉ
Mise au rebut adéquate de votre électroménager
Ŷ
Veuillez jeter ou recycler votre électroménager conformément aux règlements fédéraux ou locaux. Communiquez
avec les instances locales pour en savoir plus sur la mise au rebut ou le recyclage de votre électroménager.
Ŷ
Considérez les options de recyclage des matériaux d’emballage de votre électroménager.

449-3000244 Rev 1
CONSIGNES DE SÉCURITÉ
AVERTISSEMENTS SUPPLÉMENTAIRES CONCERNANT
LES SÉCHEUSES À GAZ
AVERTISSEMENT
Le non-respect strict des avertissements de sécurité pourrait entraîner des blessures
graves, la mort ou des dommages matériels.
- N’entreposez PAS et n’utilisez PAS d’essence NI d’autres vapeurs ou liquides
inflammables dans les alentours de cet appareil ou de tout autre.
- QUE FAIRE SI UNE ODEUR DE GAZ EST DÉTECTÉE :
Ŷ
N’allumez AUCUN appareil.
Ŷ
NE touchez à AUCUN commutateur électrique ; n’utilisez AUCUN téléphone dans
votre immeuble.
Ŷ
Faites évacuer la pièce, l’immeuble ou la zone de tous ses occupants.
Ŷ
Communiquez immédiatement avec votre fournisseur de gaz au moyen du téléphone
d’un voisin. Observez les directives du fournisseur de gaz.
Ŷ
Si vous ne pouvez pas joindre votre fournisseur de gaz, appelez le service d’incendie.
- L’installation, l’entretien et les réparations doivent être exécutés par un installateur
agréé, un organisme de service ou le fournisseur de gaz.
- Risque d’incendie ou d’explosion
CONSIGNES DE SÉCURITÉ IMPORTANTES
LIRE TOUTES LES CONSIGNES AVANT D’UTILISER L’APPAREIL
