GE VAT20 User manual

gGE Industrial Systems
AC SPEED CONTROL EQUIPMENT
VAT20
1ph, 200V-240V System, 0.2-0.75kW / 1/4-1HP
1ph/3ph, 200V-240V System, 1.5-2.2kW / 2-3 HP
3ph, 380-460V System 0.75-2.2kW / 1-3 HP
INSTRUCTION MANUAL
---------------------------------NOTICE ------------------------------------------
1. Read this manual thoroughly before using the VAT20, and store
in a safe place for reference.
2. The contents of this manual can be changed without notice
GE POWER CONTROLS

II
Table of Contents
Foreword..................................................................................... 1
Chapter 1 Safety Precautions
1. Precautions of operation......................................... 2
2. Precautions of operation environment.................... 4
Chapter 2 Hardware Instruction and Installation
1. Operation Environment........................................... 5
2. Model No. Instructions............................................ 6
3. Specifications......................................................... 7
4. Wiring..................................................................... 9
5. Dimensions & terminal block layout...................... 15
Chapter 3 Software Index
1. Control Panel Instructions .................................... 20
2. List of Parameters................................................ 21
3. Parameter Function Description........................... 22
4. Malfunction Indication and Countermeasure ........ 31
5. General Troubleshooting Method......................... 34
Chapter 4 Maintenance and Peripherals

1
1. Foreword
To fully employ all functions of the inverter, and to ensure the safety of users, please read
through this operating manual in detail. Should you have any further query, please feel free to
contact your local distributor or sales person of GE Power Controls.
Precaution
Inverter is a power electronic device, for safety reason, please take special care for paragraphs
with “WARNING” or “CAUTION” symbol. They are important safety precautions to be aware of
while transporting, installation, operating or examining the inverter. Please following these
precaution to ensure your safety.
WARNING Personnel injury may be resulted by improper operation.
CAUTION The inverter or mechanical system may be damaged by improper operation.
WARNING
lDo not touch the PCB or components on the PCB right after turning off the power before the
charging indicator went off.
lDo not attempt to wire circuitry while power is on. Do not attempt to examine the components
and signals on the PCB while the inverter operating.
lDo not attempt to disassemble or modify internal circuitry, wiring, or components of the
inverter.
lThe grounding terminal of the inverter must be grounded properly with 200V class type III
standard.
CAUTION
lDo not attempt to proceed dielectric strength test to internal components of the inverter. There
are sensitive semiconductor-devices vulnerable to high voltage in the inverter.
lDo not connect the output terminals: T1(U), T2(V), and T3(W) to AC power outlet.
lThe CMOS IC on the primary PCB of the inverter is vulnerable to static electrical charges. Do
not contact the primary PCB of the inverter.
2. Examination before installation
Every GE Power Controls inverter has been fully tested and examined before shipment. Please
carry out following examination procedures after unpacking your inverter.
lCheck to see the model number of the inverter. It should be the one that you ordered.
lCheck to see if there is any damage during the transportation. Do not connect the inverter
to the power supply if there is any sign of damage.
Report to regional sale representative if you find any abnormal condition as mentioned above.

2
Chapter 1. Safety Precaution
1. Precautions of operation
Before turning ON power
CAUTION
Choose appropriate power source with correct voltage setting as the input voltage
specification of the inverter.
WARNING
Special care must be taken while wiring the primary circuitry panel. The L1 and L2
terminal must be connected to input power source and must not be mistakenly
connected to T1, T2 or T3 terminal. This may damage the inverter when the power is
turned on.
CAUTION
lDo not attempt to transport the inverter by the front of the cover. Securely hold the
inverter by the heat-sink mounting chassis to prevent the inverter from falling, this
may cause personnel injury or damage to the inverter itself.
lInstall the inverter onto a firm metal base plate or another non-flammable type
material. Do not install the inverter onto or nearby any flammable material.
lAn additional cooling fan may need to be installed if several inverters are installed
into one control panel. The inside temperature inside an enclosed panel should be
below 40 degrees to avoid overheating.
lTurn off the power supply before proceeding to remove or perform any work on any
panel. Carry out installation procedures according to instructions given in order to
avoid a situation resulting in an operational malfunction.
lSuitable for use on a circuit capable of delivering not more than 5000 RMS
symmetrical amperes. 240 Volts maximum.
lThis product is not provided with over speed protection.
lOnly intended for use in a pollution degree 2 macro environment or equivalent
When power is applied
WARNING
Do not attempt to install or remove connector of inverter when the power supply is
turned on. Otherwise, the inverter may be damaged due to the surge peak caused by
the insertion or removal of power.

3
Under Operation
WARNING
Do not use a separate device to switch ON or OFF motor during operation. Otherwise,
the inverter may experience an over-current breakdown.
WARNING
lDo not remove the front cover of the inverter when the power is ON to avoid
personnel injury caused by electrical shock.
lWhen the automatic restart function is enabled, the motor and machinery will be
restarted automatically.
CAUTION
lDo not touch the heat-sink base.
lThe inverter can be easily operated from low-speed to high-speed range. Please
reconfirm the operating range of motor and machinery.
lDo not examining the signals on the PCB of the inverter when it is under operation.
lAll inverter had been properly adjusted before delivery.
CAUTION
Do not proceed with disassemble or examination procedure before ensuring that the
power is off and the Power LED extinguished.
When examination and maintenance
CAUTION
Inverter environment should be within temp: –10OC ~ +40OC, humidity under 95% RH
without condensing.
CAUTION
After the removal of shield sticker, the environment temperature should be
within –10OC ~ +50OC and humidity under 95% RH without condensing. Besides, the
inverter should be free from water dripping or metal dust.

4
2. Precautions of operation environment
Avoid direct sunlight Keep away from
corrosive gas or liquid
Keep away from oil
grease and gas
Keep away from salty
environment
Keep away where rain or
dripping water may get
into the inverter
Avoid metal dust and
dusty environment
Avoid massive vibration
Avoid heat
Avoid where environment
temperature is too high
Keep away from high
electrical-magnetic wave
or ultra-high wave.
Keep away from
radio-active matter Keep away from
flammable material
oil

5
Chapter 2. Hardware Instruction and Installation
1. Operation Environment
Theinstallation siteof theinverter isvery important.It relatesdirectly tothe functionalityand the
life span of your inverter. Please check the installation to meet the following requirements:
lMount the unit vertically
lEnvironment temperature: -10OC ~ +50OC
lAvoid placing close to any heating equipment
lAvoid water dripping or humid environment
lAvoid direct sunlight
lAvoid oil or salty corrosive gas
lAvoid contacting corrosive liquid or gas
lPrevent foreign dusts, flocks, or metal scraps from entering interior
lAway from radioactive matter or flammable material
lAvoid electric-magnetic interference (soldering or power machinery)
lAvoid vibration, if vibration can not be avoided, anti-rattler should be installed to reduce it.
lIf the inverter is installed in an enclosed control panel, please remove the shield sticker
located at the top of the inverter. This will allow additional airflow and cooling.
External Fan Placement needs to be over the top of the inverter
lFor proper Installation of the inverter you must place the front side of the inverter facing
front and the top of the inverter in the up direction for better heat dissipation
lInstallation must be compliant to the following requirements.
NOTE: Maximum temperature in the enclosure 50ºC
Correct Alignment Wrong Alignment Correct Alignment Wrong Alignment
Ventilation & Installation Direction
Front View
(*)
(*)
Keep (*) ≥7cm for following drives:
N1K5, N2K2, X0K7, X1K5, X2K2

6
2. Model No. Instructions
Inverter Model ßMODEL: U20N0K7S (for example)
Input Power RatingßI/P: AC 1PH 200 ~ 240V 50/60 Hz
Output Rating ßO/P: AC 3PH 0 ~ 240V 1.6KVA 4.2A
U20 -
N 0K7- S
Series Power Voltage KW Power
Rated
Option
N: 200V, 1ph 0K2: 0.2kW S: Standard
0K4: 0.4kW Model with
0K7: 0.75kW EMC Filter
N: 200V, 1ph or 3ph
1K5: 1.5kW SX: Standard Without
EMC Filter
X: 400V,3ph
2K2: 2.2kW
0K7: 0.75kW
1K5: 1.5kW
2K2: 2.2kW

7
3.Specifications
Basic Specification, 200V Series
Model No: VAT20-U20N0K2_ U20N0K4_ U20N0K7_ U20N1K5_ U20N2K2_
Suitable Motor Power Rating (KW) 0.2 0.4 0.75 1.5 2.2
Motor HP 1/4 1/2 123
Current A 1.4 2.3 4.2 7.5 10.5
Capacity KVA 0.53 0.88 1.6 2.9 4.0
Rated
Weight (Kg ) 0.76 0.77 0.8 1.66 1.76
Input Voltage Max. Single phase (and Three phase for 1.5 and 2.2kW only)
200-240V (+10%-15%) , 50/60Hz (+/-5%)
Output Voltage Max. Three phase 200-240V +10%-15%
Dimensions 72x132x118 118x143x172
Basic Specification, 400V Series
Model No: VAT20-U20X0K7_ U20X1K5_ U20X2K2_
Suitable Motor Power Rating (KW) 0.75 1.5 2.2
Motor HP 123
Current A 2.3 3.8 5.2
Capacity KVA 1.6 2.9 4.0
Rated
Weight (Kg )
Input Voltage Max. Three phase 380-480V (+10%-15%) , 50/60Hz (+/-5%)
Output Voltage Max. Three phase 380-480V +10%-15%
Dimensions 118x143x172

8
Functional Specification
Type drive VAT20 CPU version 1.6
(Check function F_29) CPU Version from 1.9 (Check function F_29)
Input Signal Type PNP type (SOURCE) input
Control Method Sinusoidal wave PWM control
Freq. Range 0~120 Hz 0~200 Hz
Frequency Resolution Digital : 0.1Hz(0~99.9Hz)
1Hz(100~120Hz)
Analog: 0.06Hz/60Hz
D: 0.1Hz(0~99.9Hz)
1Hz(100~120Hz)
A: 0.06Hz/60Hz
Keyboard Setting Directly setup by 65 buttons.
External Signal Setting 0~10V, 4~20mA , 0~20mA
Freq.
Control
Other function Frequency upper and lower limit
Carrier frequency 1-8kHz 1-16kHz
Accelerate/Decelerate time 0.1~ 999 Sec
V/F Pattern 6 Patterns
Torque control Torque boost level adjustable (manual torque boost)
Multi-Function input 2 point, to be used as multi-speed 1(Sp1) / Jog / External
emergency stop / Reset
Multi-Function output 1a Relay terminal, to be setup as Fault / Running / Frequency.
Braking Torque About 20% . Not allowable external
braking resistor. 100% with external resistor
General
Control
Other function Decelerate or free run stop, Auto reset, DC braking frequency /
Voltage / Time can be setup by constants.
Indication function 7 segments*3 indicate frequency / inverter parameter / fault
record / program version.
Operating temperature -10 ~ 50ºC
Humidity 0~95% RH non-condensing.
Vibration Under 1 G ( 9.8 m/s2)
EMC specification Class A ( Filter build in )
Protection level IP20
UL UL508C
Overload protection 150% for 1min.
Over-voltage DC voltage > 410V (200V series), DC >800V (400V Series)
Under voltage DC voltage < 200V (200V series), DC <400V (400V Series)
Momentary power-loss 0 ~ 2 sec : VAT20 can be restart by speed search
Protection
function
Stall Prevention Accelerate / Decelerate / Constant speed
Output terminal short-circuit Electronic circuitry protection
Grounding fault Electronic Circuitry protection
Protection
function Other function Heat sink protection , Current limit
Dimension(W*H*D) mm 72*132*118 118*143*172
Installation Install by mounting screw or DIN rail (Option).

9
4. Wiring
Molded-Case Circuit Breaker / Magnetic Contact
lGE Power Controls maintenance and service do not apply to damage caused by
following situation:
(1) Damage to the inverter caused by the lack of appropriate molded-case circuit breaker or
when a circuit breaker with too large of capacity is installed between the power supply
and the inverter.
(2) Damage to the inverter caused by the magnetic contact, phase advancing capacitor, or
surge-protector installed between the inverter and the motor.
Model No: U20N 0K2, 0K4, 0K7 1K5, 2K2
Model No: U20X 0K7, 1K5, 2K2
Molded-case circuit breaker line
Made by GE 20A 30A 15A
Magnetic Contact
(MC)
Made by GE
CL00
Made by GE
CL00
Made by GE
CL00
Primary Circuit Terminal (TM1) Wire dimension
2.5mm2
Terminal screw M3
Wire dimension
4 mm2
Terminal screw M3
Wire dimension
2.5mm2
Terminal screw M3
Signal Terminal (TM2)
1~11
Wire dimension 0.75mm2(#18 AWG), Terminal screw M3
lPlease utilize three-phase squirrel-cage induction motor with appropriate capacity.
lIf a inverter is used to drive more than one motor, the total capacity must be smaller
than the capacity of the inverter. Additional thermal relay must be installed in front of
every motor. Use the Fn_18 at 1.0 times of the rated value specified on the motor
nameplate at 50Hz, 1.1 times of the rated value specified on the motor nameplate at
60Hz.
lDo not install phase advancing capacitor, LC, or RC component between the inverter
and the motor.
T3
T1
T2
L1
L2

10
Application and precautions of Peripherals
Power Source
lApply the power source at the correct rated voltage to prevent
from damaging the inverter.
l
A Power Disconnect or Circuit breaker must be installed between
the AC power supply and the inverter.
Molded-case circuit breaker:
lUtilize appropriate circuit breaker suitabl
e for the rated voltage
and current ratings of the inverter to switch ON/OFF the power
supply to the inverter and as a protection for the inverter.
l
Do not operate the circuit breaker to switch ON or OFF the
inverter and operational sequence motor’s run/stop.
Leakage circuit breaker:
l
Leakage circuit breaker should be added to prevent false
operation cause by leakage current and to ensure personnel
safety.
Magnetic Contact:
l
The Magnetic Contact can be omitted at ordinary operation. To
utilize external contr
ol, automatic restart, or breaking controller
the magnetic contact must be added at the primary side.
l
Do not operate the magnetic contact to switch ON or OFF the
inverter.
Power improvement AC Reactor:
lIf large capacity power source is applied (over 600KV
A),
additional AC reactor may be added to improve power factor.
Inverter:
l
Power supply input terminals L1 and L2 is not differentiated on
phase sequence, they can be arbitrarily connected. Their
connection may be exchanged.
lOutput terminal T1, T2, and T3
should be connected to the U, V,
and W terminals of the motor respectively. If motor turns in
opposite direction of the inverter, simply exchanging two of three
wire connection may correct this problem.
lOutput terminal T1, T2, and T3 must not be connected
to power
source to prevent from damaging inverter.
lGrounding terminal
Properly ground the grounding terminal in
compliance to local codes
Power supply
Molded-case
circuit breaker
or ground fault
interrupter
Electrical-
Mangnetic
contactor
AC reactor
for power
factor
improve-ment
Grounding
VAT20
Inverter
Motor
Grounding

11
External wiring should be carried out in accordance with following requirement. Check and reassure
the wiring is correct after the wiring is complete. (Do not utilize the control circuitry buzzer to check
the wiring.)
EMI connecting:
It is very important that the connections between the inverter, the shielded motor cable, and the EMI
filters are tested as follows.
lUse a metal grounding plate and place the frequency inverter and the EMI filter on the plate.
lUse a screened motor cable with 4 connectors ( U,V,W,& Earth ), don’t use the shielding as
safety earth ( shield is high frequency earth )
lRemove painting around the two metal coupling nut holes. So that the metal coupling nuts
( and the shielding ) make contact with the frequency inverter and the motor.
lDon't solder a conductor to the shielding
lUse a metal clamp to connect the shielding from the motor cable with the metal grounding
plate. Now there is a perfect high frequency earth connection between frequency inverter .
grounding plate and EMI filter.
lKeep the distance between frequency inverter and EMI filter as short as possible ( < 30cm )
otherwise use screened cable with a metal coupling nut and a metal clamp addle to connect
the shielded cable to the frequency inverter and metal grounding plate.
lThe only earth connection between the LISN and the test plate should be via the EMI filter.
lUse a motor which equals the power rating or below of the inverter rating.
lInstall a noise filter for inverter onto the output side of the primary circuitry can suppress
conducting noise (For residential environment only). To reduce radio active noise, use a
shielded wire between motor and drive, this wiring should be away from control wiring for
more than 30 cm.
Class B (Residential Environment)
U20AF__

12
Class A, Industrial Environment (only for drives built-in with EMC class A filter (U20----S)
lWhen the distance between the inverter and motor is longer than 100m, connection wire
should be carefully chosen to reduce the wiring resistance below 3% and the voltage drop
(V) = v3 x Wire resistance (Ω/km) x wire length (m) x current x 10-3
(B) Controlcircuitry wiring must be separatedterminated and away from theprimary power circuitry
and other high-voltage or large-current power lines to avoid noise interference.
lTo reduce the noise interference and avoid possible operational problems, shielded twisted
pair cable should be used to wire the control circuitry, as shown below. Connect the
shielding wire onto the grounding terminal. Only connect one end of the shield
Wiring distance must be under 50m.
(C) The grounding terminal of the inverter must be correctly grounded in compliance with local
codes.
lGrounding wire should be wired in accordance to electrical equipment (AWG) with the
length of the grounding wire as short as possible.
lThe grounding wire of the inverter must not be grounded together with other large current
loads (such as soldering machines or large current motors). They should be grounded
separately.
lGrounding circuitry must not be formed when grounding several inverters together.
Shielding
Glove
To Inverter terminal
Connect to system grounding terminal Wrapped with
insulating tape
To control machine
Do not connect the shielding
wire at this end

13
(a)good (b) good (c) not good
(D) Wire specification Choose appropriate wire with correct diameter for primary power circuitry and
control circuitry in accordance with electricity regulations.
(E) Upon completion, check out to reassure the wiring correctness, broken wires, and secure
terminal screws.
VAT20 Wiring Diagram
Terminations to Inverter must be made with either listed field wiring lug kits or listed crimp
type ring terminals
lOther connections(external 24V supply)
Power Supply Input
Single phase drives:
L1-L2 or L1-L3
Three phase drives:
L1-L2-L3
Multifunction
input
2.5-10K
Multifunction
Output
For factory
test only
Grounding

14
VAT20 series inverter terminal descriptions
Primary circuitry terminal black ( TM1 ) descriptions
Terminal symbol Function description
L1/L (R)
L2 (S)
L3/N (T)
Primary power source input to drive
Single phase (1ph) drives: L1, L2 or L, N
Three phase (3ph) drives: L1, L2, L3
P
R
External braking resistor terminals
Only for drives 1.5 and 2.2kW
T1 (U)
T2 (V)
T3 (W)
Inverter output to motor
* Tightening torque for TM1 is 0.98Nm for frame up to 0.75kW or 1.274Nm for frame 1,5 -2.2kW.
* Wire voltage rating must be a minimum of 300V(200V series)/600V(400V series)
VAT20 control circuitry terminal block ( TM2 ) description
Terminal symbol Terminal function description
1
2
TRIP
RELAY
Fault relay output terminal. This is a multi function output (refer to F_21)
Connection point rated capacity 250VAC/1A ( 30VDC / 1A )
3FWD
4REV
Operation control terminals (refer to Fn_03)
5+ 12V Common point of terminal 3 / 4 / 6 / 7
6SP1
7RESET
Multifunction input terminals (refer to Fn_19)
8+10V Power terminal of potentiometer ( Pin 3 )
9Analog input point Analog frequency signal input terminal ( Pin 2 of
potentiometer or positive terminal of 0~10V / 4~20mA /
0~20mA)
10
0V
(FM -) Analog common point
Analog signal common point ( Pin 1 of potentiometer or
negative terminal of 0~10V / 4~20mA / 0~20mA )
11 FM+ Analog output positive
connection point Analog frequency signal output terminal
Output terminal signal is 0 ~ 10VDC/Fn6
* Tightening torque for TM2 is 0.4 Nm.
* Wire voltage rating must be a minimum of 300V for 200V inverters and 600V for 400 inverters.
* Control wiring should not run in the same conduit or race way with power or motor wiring
* Single Input and Output Terminals (TM2) Ratings are ALL Class 2

15
SW1 function description
SWITCH 1 External signal type
0~20mA analog signal ( When Fn11 set to 1 )
4~20mA analog signal ( When Fn11 set to 2 )
0~10 VDC analog signal ( When Fn11 set to 1 )
3. Dimensions and terminal block layout
Frame 1: U20N0K2, U20N0K4, U20N0K7
Unit (mm)
MODEL: U20N__ ABCDEFG
0K2S/0K4S/0K7S 132 116 130 8.2 118 61 72

16
Frame 2: U20N1K5, U20N2K2, U20X0K7, U20X1K5, U20X2K2
B
C
F
G
D
E
MODEL
LENGTH
A
143.1 127.5
B
140
C
D
8.0
U20X0K7, X1K5,
X2K2 171.7
E
108
F
118
G
Unit:mm
TM1
TM2
GROUND
3X O 4.5
TM2
TM1
U20N1K5, N2K2
A

17
Dimensions & Installation of class B Filter(U20AF0K7)
M4x14L
Inverter with class B filter (U20AF0K7) mounted. Inverter with class B filter (U20AF0K7) &
Din rail (U20AR0K7) mounted.

18
Mounting instructions
Din rail (U20AR0K7) mounting diagram
middle rib
Retention rib
Inserting hole
Step1-
Aim and insert the
4 retention ribs of
U20AR0K7 at the
4 holes in rear
panel of VAT20 .
Step2-
Push the
U20AR0K7
forward until the
middle rib grips
firmly with real
panel
Step1-
Use small screw
driver inserting
the middle rib of
U20AR0K7 and
press the screw
driver in order to
strip U20AR0K7
from VAT20.
