Revision A Corometrics®170Series 1
September, 2004 2000947-007
PN 2000947-007
Addendum to Corometrics® 170 Series Service Manual
Electromagnetic Compatibility (EMC) and
Electrostatic Discharge (ESD)
Electromagnetic Compatibility (EMC)
Corometrics Model 171
Changes or modifications to this system not expressly approved by
GE Medical Systems can cause EMC issues with this or other
equipment. This system is designed and tested to comply with
applicable regulation regarding EMC and must be installed and put
into service according to the EMC information stated as follows.
WARNING
Use of portable phones or other radio frequency (RF) emitting
equipment near the system may cause unexpected or adverse
operation.
WARNING
The equipment or system should not be used adjacent to, or
stacked with, other equipment. If adjacent or stacked use is
necessary, the equipment or system should be tested to verify
normal operation in the configuration in which it is being
used.

2 Corometrics®170Series Revision A
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Emissions
The Corometrics Antepartum Monitor, Model 171, is intended for use
in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Antepartum Monitor, Model 171, is used in such an environment.
Emissions Test Compliance Electromagnetic Environment – Guidance
RF Emissions
EN 55011 Group 1 The equipment uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
RF Emissions
EN 55011 Class B
Harmonic Emissions
EN 61000-3-2 Not applicable The equipment is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low-voltage power
supply network that supplies buildings used for domestic purposes.
Voltage Fluctuations/
Flicker Emissions
EN 61000-3-3
Not applicable

Revision A Corometrics®170Series 3
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity
The Corometrics Antepartum Monitor, Model 171 is intended for use
in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Antepartum Monitor, Model 171 is used in such an environment.
NOTE:
Utis the AC mains voltage prior to application of the test level.
Immunity Test EN 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Electrostatic
Discharge (ESD)
EN 61000-4-2
± 6 kV contact ± 6 kV contact Floors should be wood, concrete or ceramic tile. If
floorsarecoveredwithsyntheticmaterial,therelative
humidity should be at least 30%.
± 8 kV air ± 8 kV air
Electrical Fast
Transient/Burst
EN 61000-4-4
± 2 kV for power supply lines N/A Mains power should be that of a typical commercial
or hospital environment.
±1 kV for input/output lines
Surge
EN 61000-4-5 ± 1 kV differential mode N/A Mains power should be that of a typical commercial
or hospital environment.
± 2 kV common mode
<5% Ut (>95% dip in Ut)
for 0.5 cycles <5%Ut(>95%dipinUt)
for 0.5 cycles
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
EN 61000-4-11
<40% Ut (>60% dip in Ut)
for 5 cycles <40% Ut (>60% dip in
Ut) for 5 cycles Mains power should be that of a typical commercial
or hospital environment. If the user of the
Corometrics Antepartum Monitor, Model 171,
requires continued operation during power mains
interruptions, it is recommended that the host
monitor be powered from an uninterruptible power
supply.
<70% Ut (>30% dip in Ut)
for 25 cycles <70% Ut (>30% dip in
Ut) for 25 cycles
<5% Ut (>95% dip in Ut)
for 5 s <5%Ut(>95%dipinUt)
for 5 s
Power Frequency
(50/60 Hz)
Magnetic Field
EN 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.

4 Corometrics®170Series Revision A
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity
The Corometrics Antepartum Monitor, Model 171, is intended for use
in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Antepartum Monitor, Model 171, is used in such an environment.
Immunity Test EN 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Portable and mobileRFcommunicationsequipment should not
be used closer to any part of the equipment, including cables,
thanthe recommendedseparation distancecalculatedfrom the
equation applicable to the frequency of the transmitter.
Recommended separation distance
Conducted RF
EN 61000-4-6 3 Vrms 150 KHz to 80 MHz 3 V rms d= 1.2
Radiated RF
EN 61000-4-3 3 V/m 80 MHz to 2.5 GHz 3 V/m d= 1.2 80 MHz to 800 MHz
d= 2.3 800 MHz to 2.5 GHz
where Pis the maximum output power rating of the transmitter
inwatts(W)accordingto the transmitter manufacturer, anddis
the recommended separation distance in meters (m).
Fieldstrengths from fixedRFtransmitters, as determined byan
electromagnetic site surveya, should be less than the
compliance level in each frequency rangeb.
Interferencemayoccur in thevicinityofequipment marked with
the following symbol:
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by reflection from structures, objects,
and people.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radio,
AM and FM radio broadcast, and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the
measured field strength in the location in which the equipment is used exceeds the applicable RF compliance level above,
the equipment should be observed to verify normal operation. If abnormal performance is observed, additional measures
may be necessary, such as re-orienting or relocating the equipment.
bOver the frequency range 150 KHz to 80 MHz, field strengths should be less than 3 V/m.
P
P
P

Revision A Corometrics®170Series 5
2000947-007
Recommended Separation Distances
The table below provides the recommended separation distances (in
meters) between portable and mobile RF communication equipment
and the Corometrics Antepartum Monitor, Model 171.The
Corometrics Antepartum Monitor, Model 171, is intended for use in
the electromagnetic environment on which radiated RF disturbances
are controlled. The customer or the user of the Corometrics
Antepartum Monitor, Model 171, can help prevent electromagnetic
interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and the
Corometrics Antepartum Monitor, Model 171, as recommended
below, according to the maximum output power of the
communications equipment.
For transmitters rated at a maximum output power not listed above,
the recommended separation distance [d] in meters (m) can be
estimated using the equitation applicable to the frequency of the
transmitter, where Pis the maximum output power rating of the
transmitter in watts (W) according to the transmitter manufacturer.
NOTE:
These guidelines may not apply in all instances. Electromagnetic
propagation is affected by absorption and reflection from
structures, objects and people.
Separation Distance in Meters (m) According to Frequency of Transmitter
Rated Maximum Output
Power of Transmitter in
Watts
150 kHz to 80 MHz c
d= 1.2
80 MHz to 800 MHz c
d= 1.2
800 MHz to 2.5 GHz c
d= 2.3
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
11.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
cAt 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
P P P

6 Corometrics®170Series Revision A
2000947-007
Compliant Cables and Accessories
WARNING
The use of accessories, transducers and cables other than
those specified may result in increased emissions or
decreased immunity performance of the equipment or
system.
The table below lists cables, transducers, and other applicable
accessories with which GE Medical Systems claims EMC compliance.
NOTE: Any supplied accessories that do not affect EMC compliance
are not included.
Part No Description Maximum Lengths
Ultrasound Cables
5700HAX Nautilus Ultrasound Transducer Cable, loopstyle 2.4m / 8ft
5700JAX Nautilus Ultrasound Transducer Cable, button-style 2.4m / 8ft
5700LAX Nautilus Ultrasound Transducer Cable, button-style 3m / 10ft
5700MAX Nautilus Ultrasound Transducer Cable, loop-style 3m / 10ft
TOCO Cables
2264HAX Nautilus Tocotransducer Cable, loop-style 2.4m / 8ft
2264JAX Nautilus Tocotransducer Cable, button-style 2.4m / 8ft
2264LAX Nautilus Tocotransducer Cable, button-style 3m / 10ft
2264MAX Nautilus Tocotransducer Cable, loop-style 3m / 10ft
Remote Mark Cables
0146AAY Fetal Acoustic Stimulator 2.4m / 8ft
3919BAO Remote Event Marker Cable 2.4m / 8ft
Telemetry Cable
1563AAO 120/340 Interface Cable 3m / 10ft
Accessories
2020760-001 NeST AC/DC Power Supply N/A
600028 AC cord, Hospital grade, AHA 2.4m / 8ft
600034 AC cord, Hospital grade, IEC 2.4m / 8ft
600049 AC cord, Hospital grade, UK 2.4m / 8ft

Revision A Corometrics®170Series 7
2000947-007
Corometrics Model 172
Changes or modification to this system not expressly approved by GE
Medical Systems could cause EMC issues with this or other
equipment. This system is designed and tested to comply with
applicable regulation regarding EMC and needs to be installed and
put into service according to the EMC information stated as follows.
WARNING
Use of portable phones or other radio frequency (RF) emitting
equipment near the system may cause unexpected or adverse
operation.
WARNING
The equipment or system should not be used adjacent to, or
stacked with, other equipment. If adjacent or stacked use is
necessary, the equipment or system should be tested to verify
normal operation in the configuration in which it is being
used.
Guidance and Manufacturer's Declaration - Electromagnetic
Emissions
The Corometrics Antepartum Monitor, Model 172, is intended for use
in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Antepartum Monitor, Model 172, is used in such an environment.
Emissions Test Compliance Electromagnetic Environment – Guidance
RF Emissions
EN 55011 Group 1 The equipment uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
RF Emissions
EN 55011 Class B
Harmonic Emissions
EN 61000-3-2 Not applicable The equipment is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low-voltage power
supply network that supplies buildings used for domestic purposes.
Voltage Fluctuations/
Flicker Emissions
EN 61000-3-3
Not applicable

8 Corometrics®170Series Revision A
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity
The Corometrics Antepartum Monitor, Model 172 is intended for use
in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Antepartum Monitor, Model 172 is used in such an environment.
NOTE:
Utis the AC mains voltage prior to application of the test level.
Immunity Test EN 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Electrostatic
Discharge (ESD)
EN 61000-4-2
± 6 kV contact ± 6 kV contact Floors should be wood, concrete or ceramic tile. If
floorsarecoveredwithsyntheticmaterial,therelative
humidity should be at least 30%.
± 8 kV air ± 8 kV air
Electrical Fast
Transient/Burst
EN 61000-4-4
± 2 kV for power supply lines N/A Mains power should be that of a typical commercial
or hospital environment.
±1 kV for input/output lines
Surge
EN 61000-4-5 ± 1 kV differential mode N/A Mains power should be that of a typical commercial
or hospital environment.
± 2 kV common mode
<5% Ut (>95% dip in Ut)
for 0.5 cycles <5%Ut(>95%dipinUt)
for 0.5 cycles
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
EN 61000-4-11
<40% Ut (>60% dip in Ut)
for 5 cycles <40% Ut (>60% dip in
Ut) for 5 cycles Mains power should be that of a typical commercial
or hospital environment. If the user of the
Corometrics Antepartum Monitor, Model 172,
requires continued operation during power mains
interruptions, it is recommended that the host
monitor be powered from an uninterruptible power
supply.
<70% Ut (>30% dip in Ut)
for 25 cycles <70% Ut (>30% dip in
Ut) for 25 cycles
<5% Ut (>95% dip in Ut)
for 5 s <5%Ut(>95%dipinUt)
for 5 s
Power Frequency
(50/60 Hz)
Magnetic Field
EN 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.

Revision A Corometrics®170Series 9
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity
The Corometrics Antepartum Monitor, Model 172, is intended for use
in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Antepartum Monitor, Model 172, is used in such an environment.
Immunity Test EN 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Portable and mobileRFcommunicationsequipment should not
be used closer to any part of the equipment, including cables,
thanthe recommendedseparation distancecalculatedfrom the
equation applicable to the frequency of the transmitter.
Recommended separation distance
Conducted RF
EN 61000-4-6 3 Vrms 150 KHz to 80 MHz 3 V rms d= 1.2
Radiated RF
EN 61000-4-3 3 V/m 80 MHz to 2.5 GHz 3 V/m d= 1.2 80 MHz to 800 MHz
d= 2.3 800 MHz to 2.5 GHz
where Pis the maximum output power rating of the transmitter
inwatts(W)accordingto the transmitter manufacturer, anddis
the recommended separation distance in meters (m).
Fieldstrengths from fixedRFtransmitters, as determined byan
electromagnetic site surveya, should be less than the
compliance level in each frequency rangeb.
Interferencemayoccur in thevicinityofequipment marked with
the following symbol:
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by reflection from structures, objects,
and people.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radio,
AM and FM radio broadcast, and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the
measured field strength in the location in which the equipment is used exceeds the applicable RF compliance level above,
the equipment should be observed to verify normal operation. If abnormal performance is observed, additional measures
may be necessary, such as re-orienting or relocating the equipment.
bOver the frequency range 150 KHz to 80 MHz, field strengths should be less than 3 V/m.
P
P
P

10 Corometrics®170Series Revision A
2000947-007
Recommended Separation Distances
The table below provides the recommended separation distances (in
meters) between portable and mobile RF communication equipment
and the Corometrics Antepartum Monitor, Model 172.The
Corometrics Antepartum Monitor, Model 172, is intended for use in
the electromagnetic environment on which radiated RF disturbances
are controlled. The customer or the user of the Corometrics
Antepartum Monitor, Model 172, can help prevent electromagnetic
interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and the
Corometrics Antepartum Monitor, Model 172, as recommended
below, according to the maximum output power of the
communications equipment.
For transmitters rated at a maximum output power not listed above,
the recommended separation distance [d] in meters (m) can be
estimated using the equitation applicable to the frequency of the
transmitter, where Pis the maximum output power rating of the
transmitter in watts (W) according to the transmitter manufacturer.
NOTE:
These guidelines may not apply in all instances. Electromagnetic
propagation is affected by absorption and reflection from
structures, objects and people.
Separation Distance in Meters (m) According to Frequency of Transmitter
Rated Maximum Output
Power of Transmitter in
Watts
150 kHz to 80 MHz c
d= 1.2
80 MHz to 800 MHz c
d= 1.2
800 MHz to 2.5 GHz c
d= 2.3
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
11.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
cAt 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
P P P

Revision A Corometrics®170Series 11
2000947-007
Compliant Cables and Accessories
WARNING
The use of accessories, transducers and cables other than
those specified may result in increased emissions or
decreased immunity performance of the equipment or
system.
The table below lists cables, transducers, and other applicable
accessories with which GE Medical Systems claims EMC compliance.
NOTE: Any supplied accessories that do not affect EMC compliance
are not included.
Part No Description Maximum Lengths
Ultrasound Cables
5700HAX Nautilus Ultrasound Transducer Cable, loopstyle 2.4m / 8ft
5700JAX Nautilus Ultrasound Transducer Cable, button-style 2.4m / 8ft
5700LAX Nautilus Ultrasound Transducer Cable, button-style 3m / 10ft
5700MAX Nautilus Ultrasound Transducer Cable, loop-style 3m / 10ft
TOCO Cables
2264HAX Nautilus Tocotransducer Cable, loop-style 2.4m / 8ft
2264JAX Nautilus Tocotransducer Cable, button-style 2.4m / 8ft
2264LAX Nautilus Tocotransducer Cable, button-style 3m / 10ft
2264MAX Nautilus Tocotransducer Cable, loop-style 3m / 10ft
Remote Mark Cables
0146AAY Fetal Acoustic Stimulator 2.4m / 8ft
3919BAO Remote Event Marker Cable 2.4m / 8ft
Telemetry Cable
1563AAO 120/340 Interface Cable 3m / 10ft
Accessories
2020760-001 NeST AC/DC Power Supply N/A
600028 AC cord, Hospital grade, AHA 2.4m / 8ft
600034 AC cord, Hospital grade, IEC 2.4m / 8ft
600049 AC cord, Hospital grade, UK 2.4m / 8ft

12 Corometrics®170Series Revision A
2000947-007
Corometrics Model 173
Changes or modification to this system not expressly approved by GE
Medical Systems could cause EMC issues with this or other
equipment. This system is designed and tested to comply with
applicable regulation regarding EMC and needs to be installed and
put into service according to the EMC information stated as follows.
WARNING
Use of portable phones or other radio frequency (RF) emitting
equipment near the system may cause unexpected or adverse
operation.
WARNING
The equipment or system should not be used adjacent to, or
stacked with, other equipment. If adjacent or stacked use is
necessary, the equipment or system should be tested to verify
normal operation in the configuration in which it is being
used.
Guidance and Manufacturer's Declaration - Electromagnetic
Emissions
The Corometrics Intrapartum Monitor, Model 173, is intended for
use in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Intrapartum Monitor, Model 173, is used in such an environment.
Emissions Test Compliance Electromagnetic Environment – Guidance
RF Emissions
EN 55011 Group 1 The equipment uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
RF Emissions
EN 55011 Class B
Harmonic Emissions
EN 61000-3-2 Not applicable The equipment is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low-voltage power
supply network that supplies buildings used for domestic purposes.
Voltage Fluctuations/
Flicker Emissions
EN 61000-3-3
Not applicable

Revision A Corometrics®170Series 13
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity
The Corometrics Intrapartum Monitor, Model 173, is intended for
use in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Intrapartum Monitor, Model 173, is used in such an environment.
NOTE:
Utis the AC mains voltage prior to application of the test level.
Immunity Test EN 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Electrostatic
Discharge (ESD)
EN 61000-4-2
± 6 kV contact ± 6 kV contact Floors should be wood, concrete or ceramic tile. If
floorsarecoveredwithsyntheticmaterial,therelative
humidity should be at least 30%.
± 8 kV air ± 8 kV air
Electrical Fast
Transient/Burst
EN 61000-4-4
± 2 kV for power supply lines N/A Mains power should be that of a typical commercial
or hospital environment.
±1 kV for input/output lines
Surge
EN 61000-4-5 ± 1 kV differential mode N/A Mains power should be that of a typical commercial
or hospital environment.
± 2 kV common mode
<5% Ut (>95% dip in Ut)
for 0.5 cycles <5%Ut(>95%dipinUt)
for 0.5 cycles
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
EN 61000-4-11
<40% Ut (>60% dip in Ut)
for 5 cycles <40% Ut (>60% dip in
Ut) for 5 cycles Mains power should be that of a typical commercial
or hospital environment. If the user of the
Corometrics Intrapartum Monitor, Model 173,
requires continued operation during power mains
interruptions, it is recommended that the host
monitor be powered from an uninterruptible power
supply.
<70% Ut (>30% dip in Ut)
for 25 cycles <70% Ut (>30% dip in
Ut) for 25 cycles
<5% Ut (>95% dip in Ut)
for 5 s <5%Ut(>95%dipinUt)
for 5 s
Power Frequency
(50/60 Hz)
Magnetic Field
EN 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.

14 Corometrics®170Series Revision A
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity
The Corometrics Intrapartum Monitor, Model 173, is intended for
use in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Intrapartum Monitor, Model 173, is used in such an environment.
Immunity Test EN 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Portable and mobileRFcommunicationsequipment should not
be used closer to any part of the equipment, including cables,
thanthe recommendedseparation distancecalculatedfrom the
equation applicable to the frequency of the transmitter.
Recommended separation distance
Conducted RF
EN 61000-4-6 3 Vrms 150 KHz to 80 MHz 3 V rms d= 1.2
Radiated RF
EN 61000-4-3 3 V/m 80 MHz to 2.5 GHz 3 V/m d= 1.2 80 MHz to 800 MHz
d= 2.3 800 MHz to 2.5 GHz
where Pis the maximum output power rating of the transmitter
inwatts(W)accordingto the transmitter manufacturer, anddis
the recommended separation distance in meters (m).
Fieldstrengths from fixedRFtransmitters, as determined byan
electromagnetic site surveya, should be less than the
compliance level in each frequency rangeb.
Interferencemayoccur in thevicinityofequipment marked with
the following symbol:
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by reflection from structures, objects,
and people.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radio,
AM and FM radio broadcast, and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the
measured field strength in the location in which the equipment is used exceeds the applicable RF compliance level above,
the equipment should be observed to verify normal operation. If abnormal performance is observed, additional measures
may be necessary, such as re-orienting or relocating the equipment.
bOver the frequency range 150 KHz to 80 MHz, field strengths should be less than 3 V/m.
P
P
P

Revision A Corometrics®170Series 15
2000947-007
Recommended Separation Distances
The table below provides the recommended separation distances (in
meters) between portable and mobile RF communication equipment
and the Corometrics Intrapartum Monitor, Model 173. The
Corometrics Intrapartum Monitor, Model 173, is intended for use in
the electromagnetic environment on which radiated RF disturbances
are controlled. The customer or the user of the Corometrics
Intrapartum Monitor, Model 173, can help prevent electromagnetic
interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and the
Corometrics Intrapartum Monitor, Model 173, as recommended
below, according to the maximum output power of the
communications equipment.
For transmitters rated at a maximum output power not listed above,
the recommended separation distance [d] in meters (m) can be
estimated using the equitation applicable to the frequency of the
transmitter, where Pis the maximum output power rating of the
transmitter in watts (W) according to the transmitter manufacturer.
NOTE:
These guidelines may not apply in all instances. Electromagnetic
propagation is affected by absorption and reflection from
structures, objects and people.
Separation Distance in Meters (m) According to Frequency of Transmitter
Rated Maximum Output
Power of Transmitter in
Watts
150 kHz to 80 MHz c
d= 1.2
80 MHz to 800 MHz c
d= 1.2
800 MHz to 2.5 GHz c
d= 2.3
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
11.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
cAt 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
P P P

16 Corometrics®170Series Revision A
2000947-007
Compliant Cables and Accessories
WARNING
The use of accessories, transducers and cables other than
those specified may result in increased emissions or
decreased immunity performance of the equipment or
system.
The table below lists cables, transducers, and other applicable
accessories with which GE Medical Systems claims EMC compliance.
NOTE: Any supplied accessories that do not affect EMC compliance
are not included.
Part No Description Maximum Lengths
FECG Cables
1590AAO Leg Plate Cable, Qwik Connect Plus® 2.4m / 8ft
1590CAO Spiral Electrodes, Qwik Connect Plus® N/A
Intrauterine Pressure Catheters
2076BAO Saflex® Intrauterine Pressure Catheter N/A
1336AAO Saflex® Intrauterine Pressure Catheters Cable 3.6m / 12 ft
1336BAO Saflex® Intrauterine Pressure Catheters Cable 3.6m / 12 ft
1336EAO Softrans Intrauterine Pressure Catheters Cable 3.6m / 12 ft
Ultrasound Cables
5700HAX Nautilus Ultrasound Transducer Cable, loopstyle 2.4m / 8ft
5700JAX Nautilus Ultrasound Transducer Cable, button-style 2.4m / 8ft
5700LAX Nautilus Ultrasound Transducer Cable, button-style 3m / 10ft
5700MAX Nautilus Ultrasound Transducer Cable, loop-style 3m / 10ft
TOCO Cables
2264HAX Nautilus Tocotransducer Cable, loop-style 2.4m / 8ft
2264JAX Nautilus Tocotransducer Cable, button-style 2.4m / 8ft
2264LAX Nautilus Tocotransducer Cable, button-style 3m / 10ft
2264MAX Nautilus Tocotransducer Cable, loop-style 3m / 10ft
Remote Mark Cables
0146AAY Fetal Acoustic Stimulator 2.4m / 8ft
3919BAO Remote Event Marker Cable 2.4m / 8ft

Revision A Corometrics®170Series 17
2000947-007
Telemetry Cable
1563AAO 120/340 Interface Cable 3m / 10ft
Accessories
2020760-001 NeST AC/DC Power Supply N/A
600028 AC cord, Hospital grade, AHA 2.4m / 8ft
600034 AC cord, Hospital grade, IEC 2.4m / 8ft
600049 AC cord, Hospital grade, UK 2.4m / 8ft
Part No Description Maximum Lengths

18 Corometrics®170Series Revision A
2000947-007
Corometrics Model 174
Changes or modification to this system not expressly approved by GE
Medical Systems could cause EMC issues with this or other
equipment. This system is designed and tested to comply with
applicable regulation regarding EMC and needs to be installed and
put into service according to the EMC information stated as follows.
WARNING
Use of portable phones or other radio frequency (RF) emitting
equipment near the system may cause unexpected or adverse
operation.
WARNING
The equipment or system should not be used adjacent to, or
stacked with, other equipment. If adjacent or stacked use is
necessary, the equipment or system should be tested to verify
normal operation in the configuration in which it is being
used.
Guidance and Manufacturer's Declaration - Electromagnetic
Emissions
The Corometrics Intrapartum Monitor, Model 174, is intended for
use in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Intrapartum Monitor, Model 174, is used in such an environment.
Emissions Test Compliance Electromagnetic Environment – Guidance
RF Emissions
EN 55011 Group 1 The equipment uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
RF Emissions
EN 55011 Class B
Harmonic Emissions
EN 61000-3-2 Not applicable The equipment is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low-voltage power
supply network that supplies buildings used for domestic purposes.
Voltage Fluctuations/
Flicker Emissions
EN 61000-3-3
Not applicable

Revision A Corometrics®170Series 19
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity
The Corometrics Intrapartum Monitor, Model 174, is intended for
use in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Intrapartum Monitor, Model 174, is used in such an environment.
NOTE:
Utis the AC mains voltage prior to application of the test level.
Immunity Test EN 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Electrostatic
Discharge (ESD)
EN 61000-4-2
± 6 kV contact ± 6 kV contact Floors should be wood, concrete or ceramic tile. If
floorsarecoveredwithsyntheticmaterial,therelative
humidity should be at least 30%.
± 8 kV air ± 8 kV air
Electrical Fast
Transient/Burst
EN 61000-4-4
± 2 kV for power supply lines N/A Mains power should be that of a typical commercial
or hospital environment.
±1 kV for input/output lines
Surge
EN 61000-4-5 ± 1 kV differential mode N/A Mains power should be that of a typical commercial
or hospital environment.
± 2 kV common mode
<5% Ut (>95% dip in Ut)
for 0.5 cycles <5%Ut(>95%dipinUt)
for 0.5 cycles
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
EN 61000-4-11
<40% Ut (>60% dip in Ut)
for 5 cycles <40% Ut (>60% dip in
Ut) for 5 cycles Mains power should be that of a typical commercial
or hospital environment. If the user of the
Corometrics Intrapartum Monitor, Model 174,
requires continued operation during power mains
interruptions, it is recommended that the host
monitor be powered from an uninterruptible power
supply.
<70% Ut (>30% dip in Ut)
for 25 cycles <70% Ut (>30% dip in
Ut) for 25 cycles
<5% Ut (>95% dip in Ut)
for 5 s <5%Ut(>95%dipinUt)
for 5 s
Power Frequency
(50/60 Hz)
Magnetic Field
EN 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.

20 Corometrics®170Series Revision A
2000947-007
Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity
The Corometrics Intrapartum Monitor, Model 174, is intended for
use in the electromagnetic environment specified below. It is the
responsibility of the customer or user to assure that the Corometrics
Intrapartum Monitor, Model 174, is used in such an environment.
Immunity Test EN 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Portable and mobileRFcommunicationsequipment should not
be used closer to any part of the equipment, including cables,
thanthe recommendedseparation distancecalculatedfrom the
equation applicable to the frequency of the transmitter.
Recommended separation distance
Conducted RF
EN 61000-4-6 3 Vrms 150 KHz to 80 MHz 3 V rms d= 1.2
Radiated RF
EN 61000-4-3 3 V/m 80 MHz to 2.5 GHz 3 V/m d= 1.2 80 MHz to 800 MHz
d= 2.3 800 MHz to 2.5 GHz
where Pis the maximum output power rating of the transmitter
inwatts(W)accordingto the transmitter manufacturer, anddis
the recommended separation distance in meters (m).
Fieldstrengths from fixedRFtransmitters, as determined byan
electromagnetic site surveya, should be less than the
compliance level in each frequency rangeb.
Interferencemayoccur in thevicinityofequipment marked with
the following symbol:
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by reflection from structures, objects,
and people.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radio,
AM and FM radio broadcast, and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the
measured field strength in the location in which the equipment is used exceeds the applicable RF compliance level above,
the equipment should be observed to verify normal operation. If abnormal performance is observed, additional measures
may be necessary, such as re-orienting or relocating the equipment.
bOver the frequency range 150 KHz to 80 MHz, field strengths should be less than 3 V/m.
P
P
P
