GE MONOGRAM ZSC2000FWW/BB Manual

Specification Created 9/02
ZSC2000FWW/BB – GE Monogram Built-In Advantium™Oven
Dimensions (in inches)
29-25/32"
15"
(Recessed
Portion)
21-7/8"
15-27/32"*
28-7/16"
27/32"
14-1/8"
15/32"
27/32"
20-27/32"
11/16"
7/8"
13"
9/16"
Electrical Requirements
Single Speedcook Installation
Product rating is 120/208 or 120/240 volt, 60 Hz, 30 amps. This product must be
connected to a supply circuit of the proper voltage and frequency and protected
by a time delay fuse or circuit breaker. The power supply should be brought to a
separate 30 ampere branch circuit. Wire size must conform to the requirements
of the National Electric Code or the prevailing local code.
Combined Speedcook and Wall Oven Installation:
When installed in combination with a GE single wall oven, use separate
electrical junction boxes,
OR,
Install a single junction box connected to 50 amp supply circuit or properly
rated supply circuit.
• Refer to single oven installation instructions for electrical requirements of
that product.
• These connections must be made by a qualified electrician. All electrical
connections must meet National Electrical code or prevailing local codes.
Combined Speedcook and Warming Drawer Installation:
When installing the Speedcook oven over a GE electric warming drawer, a
separate 120V, 60Hz, properly grounded receptacle must be installed. See
instructions packed with the warming drawer.
Installation Requirements
•These ovens may be installed directly into a wall
or wall oven cabinetry, 30" minimum width.
•The front surface of the oven will be nearly flush
with surrounding cabinetry doors.
•This oven can be installed over any GE single
electric built-in oven or a single GE electric
built-in warming drawer.
•This oven must be installed at least 36" above
the floor.
IMPORTANT: This oven is not approved for use
above another built-in Speedcook oven, side by
side or under the countertop installations.
•For personal safety, this oven cannot be installed
in a cabinet arrangement such as an island
or peninsula.
•Cabinets installed adjacent to wall ovens must
have an adhesion spec of at least 194°F
temperature rating.
•Allow for clearance to adjacent corners, walls,
drawers, etc.
*Excludes Handle
For answers to your Monogram,
® GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories

36-3/4" Min.
Required
30" 19"
Min
Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
28-1/2"
21"
36-3/4" Min.
30" 24"
Min. Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
2" Min.
Install 2 x 4
or 2 x 2
Runners or
Solid Bottom,
Must Support
100 lbs.
28-1/2"
21"
9-1/4"
*45-1/4"
30" 24"
Min. Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
2" Min.
Per Oven
Requirement
28-1/2"
21"
Single Speedcook Installation
Order a 30" wide single oven cabinet or cut the
opening in a wall to dimensions shown.
The rough opening must be:
•Depth –19" Min.
•Width –28-1/2" Min.
•Height –21" Min.
•36-3/4" from the floor to the cutout is required.
•These ovens require 3/4" overlap on each side, top
and bottom of the cutout.
•Oven overlaps will conceal cut edges on all sides
of the opening.
Specification Created 9/02
Note: Additional clearance between the cutouts may be required.
Check to be sure the oven supports above the warming drawer
location do not obstruct the required interior 23-1/2" depth and
9-1/4" height. See installation instructions for details.
Speedcook Oven Installation above a GE Built-In Wall Oven
Speedcook Oven Installation above a GE Warming Drawer
For answers to your Monogram,
®GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
ZSC2000FWW/BB –GE Monogram Built-In Advantium™Oven

Specification Created 9/02
ZSC2000FWW/BB –GE Monogram Built-In Advantium™Oven
Features and Benefits
•Revolutionary Speedcook Technology Cooks
Oven-Quality with Light in One-Fourth the Time
•Over 100 Pre-Programmed Menu Items with
Repeat Last and Help Modes
•Bakes, Browns, Broils, Grills and Roasts –
All with No Preheating
•Converts to Fully Functional 950 Watt
Microwave Oven
•Family-Size Oven with Stainless Steel Interior
•Electronic Scrolling Display with Variable
Scroll Speed
•Monogram Appearance
•Microwave Oven Features Auto Defrost/
Time Defrost
•Cooking Complete Reminder with Beeper
Sound Level Control
•Interior Oven Light
•Child Lock-Out
•Frameless Glass Oven Door with Window
•Cookbook and Pan Set Included
•Model ZSC2000FWW –White on white
•Model ZSC2000FBB –Black on black
•Model ZSC2001FSS –Stainless steel
SPEED
COOK
REPEATLAST
RECIPE
MANUAL
COOK
POWER
LEVEL
OPTIONS
TIMER
HELP
MICRO
WAVE
BACK
MICRO
EXPRESS
START
PAUSE
CLEAR
OFF
T
U
R
N
T
O
S
E
P
R
E
S
S
T
O
E
N
T
E
R
