GE 350-A9 User manual

*1601-9092-AJ*
350
Feeder Protection System
Feeder protection and control
GE
Grid Solutions
Quick Start Guide
350 revision: 2.3x
Manual P/N: 1601-9092-AJ
GE publication code: GEK-113535S
LISTED
52TL
IND.CONT. EQ.
E83849

© 2017 GE Multilin Inc. All rights reserved.
GE Multilin 350 Feeder Protection System QuickStart Guide for revision 2.3x.
350 Feeder Protection System, EnerVista, EnerVista Launchpad, and EnerVista 3 Series
Setup are registered trademarks of GE Multilin Inc.
The contents of this manual are the property of GE Multilin Inc. This documentation is
furnished on license and may not be reproduced in whole or in part without the permission
of GE Multilin Inc. The content of this manual is for informational use only and is subject to
change without notice.
Part number: 1601-9092-AJ (June 2017)
Storage
Store the unit indoors in a cool, dry place. If possible, store in the original packaging. Follow
the storage temperature range outlined in the Specifications.
To avoid deterioration of electrolytic capacitors, power up units that are stored in a de-
energized state once per year, for one hour continuously.
Warranty
For products shipped as of 1 October 2013, GE warrants most of its GE manufactured
products for 10 years. For warranty details including any limitations and disclaimers, see
our Terms and Conditions at https://www.gegridsolutions.com/multilin/warranty.htm
For products shipped before 1 October 2013, the standard 24-month warranty applies.
Repairs
The firmware and software can be upgraded without return of the device to the factory.
For issues not solved by troubleshooting, the process to return the device to the factory for
repair is as follows:
• Contact a GE Grid Solutions Technical Support Center. Contact information is found in
the first chapter.
• Obtain a Return Materials Authorization (RMA) number from the Technical Support
Center.
• Verify that the RMA and Commercial Invoice received have the correct information.
• Tightly pack the unit in a box with bubble wrap, foam material, or styrofoam inserts or
packaging peanuts to cushion the item(s). You may also use double boxing whereby
you place the box in a larger box that contains at least 5 cm of cushioning material.
• Ship the unit by courier or freight forwarder, along with the Commercial Invoice and
RMA, to the factory.
Customers are responsible for shipping costs to the factory, regardless of whether the
unit is under warranty.
• Fax a copy of the shipping information to the GE Grid Solutions service department.
Use the detailed return procedure outlined at
https://www.gegridsolutions.com/multilin/support/ret_proc.htm
The current warranty and return information are outlined at
https://www.gegridsolutions.com/multilin/warranty.htm

Note GENERAL SAFETY PRECAUTIONS - 350
• Failure to observe and follow the instructions provided in the equipment manual(s)
could cause irreversible damage to the equipment and could lead to property
damage, personal injury and/or death.
• Before attempting to use the equipment, it is important that all danger and
caution indicators are reviewed.
• If the equipment is used in a manner not specified by the manufacturer or
functions abnormally, proceed with caution. Otherwise, the protection provided by
the equipment may be impaired and can result in Impaired operation and injury.
• Caution: Hazardous voltages can cause shock, burns or death.
• Installation/service personnel must be familiar with general device test practices,
electrical awareness and safety precautions must be followed.
• Before performing visual inspections, tests, or periodic maintenance on this device
or associated circuits, isolate or disconnect all hazardous live circuits and sources
of electric power.
• Failure to shut equipment off prior to removing the power connections could
expose you to dangerous voltages causing injury or death.
• All recommended equipment that should be grounded and must have a reliable
and un-compromised grounding path for safety purposes, protection against
electromagnetic interference and proper device operation.
• Equipment grounds should be bonded together and connected to the facility’s
main ground system for primary power.
• Keep all ground leads as short as possible.
• At all times, equipment ground terminal must be grounded during device
operation and service.
• In addition to the safety precautions mentioned all electrical connections made
must respect the applicable local jurisdiction electrical code.
• Before working on CTs, they must be short-circuited.
• LED transmitters are classified as IEC 60825-1 Accessible Emission Limit (AEL) Class
1M. Class 1M devices are considered safe to the unaided eye. Do not view directly
with optical instruments.
This product cannot be disposed of as unsorted municipal waste in the European
Union. For proper recycling return this product to your supplier or a designated
collection point. For more information go to www.recyclethis.info.

Safety words and definitions
The following symbols used in this document indicate the following conditions
Note Indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
Note Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
Note Indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
Note Indicates practices not related to personal injury.
For further assistance
For product support, contact the information and call center as follows:
GE Grid Solutions
650 Markland Street
Markham, Ontario
Canada L6C 0M1
Worldwide telephone: [phone]
Europe/Middle East/Africa telephone: [phone]
North America toll-free: 1 800 547 8629
Fax: [phone]
Worldwide e-mail: multil[email protected]
Europe e-mail: multil[email protected]
Website: http://www.gegridsolutions.com/multilin

350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
Table of Contents
1. INTRODUCTION Overview ................................................................................................................................1
Description of the 350 Feeder Protection System..............................................2
350 order codes..................................................................................................................5
Specifications.......................................................................................................................9
Password security....................................................................................................................9
Protection.....................................................................................................................................9
Metering........................................................................................................................................14
Data capture ..............................................................................................................................14
Control...........................................................................................................................................15
Monitoring....................................................................................................................................17
Inputs .............................................................................................................................................17
Outputs..........................................................................................................................................18
Power supply..............................................................................................................................20
Communications ......................................................................................................................21
Testing and certification .......................................................................................................22
Physical.........................................................................................................................................23
Environmental............................................................................................................................24
2. INSTALLATION Mechanical installation ...................................................................................................25
Dimensions..................................................................................................................................26
Product identification .............................................................................................................28
Mounting ......................................................................................................................................28
Standard panel mount.........................................................................................................28
Mounting using the S1/S2/MDP/IAC or SR735 adapter plate............................32
Drawout unit withdrawal and insertion.........................................................................35
IP20 Cover (optional) ...............................................................................................................36
Arc flash sensors.......................................................................................................................37
Sensor fiber handling & storage ......................................................................................38
Point sensor installation ......................................................................................................39
Loop sensor installation.......................................................................................................43
Electrical installation ........................................................................................................46
Typical wiring diagrams........................................................................................................47
350 Terminal identification..................................................................................................49
Wire range...................................................................................................................................52
Phase sequence and transformer polarity..................................................................52
Current inputs ............................................................................................................................53
Ground and sensitive ground CT inputs ........................................................................53
Zero sequence CT installation............................................................................................54
Voltage inputs............................................................................................................................55
Control power ............................................................................................................................55
Contact inputs ...........................................................................................................................56
Trip and Close output relays...............................................................................................57
Serial communications..........................................................................................................59
IRIG-B .............................................................................................................................................60
3. INTERFACES Front control panel interface........................................................................................62
Description ..................................................................................................................................63
Display...........................................................................................................................................64
Working with the Keypad ...................................................................................................64

350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
LED status indicators - Front panel with non-programmable LEDs................66
LED status indicators - Front panel with programmable LEDs..........................67
Relay messages........................................................................................................................68
Target messages.....................................................................................................................68
Self-test errors..........................................................................................................................68
Flash messages .......................................................................................................................70
Software setup....................................................................................................................71
Quick setup - Software interface......................................................................................71
EnerVista 3 Series Setup Software...................................................................................72
Hardware and software requirements.........................................................................72
Installing the EnerVista 3 Series Setup software......................................................72
Upgrading the software.......................................................................................................75
Connecting EnerVista 3 Series Setup to the relay ...................................................75
Configuring serial communications...............................................................................75
Using the Quick Connect feature ....................................................................................76
Configuring Ethernet communications ........................................................................77
Connecting to the relay .......................................................................................................78
Working with setpoints and setpoint files....................................................................79
Engaging a device..................................................................................................................79
Entering setpoints...................................................................................................................79
Setting programmable LEDs..............................................................................................81
File support ................................................................................................................................82
Using setpoint files .................................................................................................................82
Downloading and saving setpoint files ........................................................................83
Adding setpoint files to the environment ....................................................................83
Creating a new setpoint file...............................................................................................84
Upgrading setpoint files to a new revision .................................................................85
Printing setpoints and actual values .............................................................................86
Printing actual values from a connected device .....................................................86
Loading setpoints from a file.............................................................................................87
Uninstalling files and clearing data................................................................................87
Upgrading relay firmware ...................................................................................................88
Loading new relay firmware .............................................................................................88
Advanced EnerVista 3 Series Setup features..............................................................90
Flexcurve editor .......................................................................................................................90
Transient recorder (Waveform capture).......................................................................91
Protection summary .............................................................................................................94
Password security..................................................................................................................96
4. QUICK SETUP -
FRONT CONTROL
PANEL
Quick Setup settings.........................................................................................................100
5. MAINTENANCE General maintenance......................................................................................................104
In-service maintenance........................................................................................................104
Out-of-service maintenance ..............................................................................................104
Unscheduled maintenance (system interruption)....................................................104

350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE 1
350 Feeder Protection System
Chapter 1: Introduction
GE
Grid Solutions
Introduction
Overview
The 350 is a microprocessor-based relay for primary and backup over-current protection
of medium and low voltage distribution feeders. The relay is also suitable for providing
over-current and backup protection for small and medium size motors, transformers,
generators, and distribution bus-bars. The small footprint and the withdrawable option
make the 350 relay ideal for panel mounting on either new or retrofit installations. The
combination of proven hardware, a variety of protection and control features, and
communications, makes the relay ideal for total feeder protection and control. Equipped
with serial (RS485), USB, and Ethernet ports with the possibility of adding redundancy
(IEC62439, PRP and HSR), and a wide selection of protocols such as Modbus, DNP3.0, IEC
60870-5-103, 60870-5-104, IEC61850 GOOSE, OPC-UA, the 350 relay is the best-in-class
for MCCs and PCCs, SCADA and inter-relay communications. The 350 relay provides
excellent transparency with respect to power system conditions and events, through its
four-line 20-character display, as well as the EnerVista 3 Series Setup program.
Conveniently located LEDs provide indication of relay operation, alarm, and pickup, as well
as breaker, and relay status.
The 350 relay provides the following key benefits:
• Withdrawable small footprint – saves on rewiring and space. (non-draw out version is
also available)
• Multiple protection groups with the added flexibility of switching through a wide
selection of overcurrent protection and control features.
• Fast setup (Quick Setup) menu for power-system setup and a simple overcurrent
protection configuration.
• Large four-line LCD display, LEDs, and an easy-to-navigate keypad.
• Multiple communication protocols for simultaneous access when integrated into
monitoring and control systems.

2350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
DESCRIPTION OF THE 350 FEEDER PROTECTION SYSTEM CHAPTER 1: INTRODUCTION
Description of the 350 Feeder Protection System
CPU
Relay functions are controlled by two processors: a Freescale MPC5554 32-bit
microprocessor measures all analog signals and digital inputs and controls all output
relays; a Freescale MPC520B 32-bit microprocessor controls all the Ethernet
communication protocols.
Analog Input and Waveform Capture
Magnetic transformers are used to scale-down the incoming analog signals from the
source instrument transformers. The analog signals are then passed through a 960 Hz low
pass anti-aliasing filter. All signals are then simultaneously captured by sample and hold
buffers to ensure there are no phase shifts. The signals are converted to digital values by a
12-bit A/D converter before finally being passed on to the CPU for analysis.
Both current and voltage are sampled thirty-two times per power frequency cycle. These
‘raw’ samples are scaled in software, then placed into the waveform capture buffer, thus
emulating a fault recorder. The waveforms can be retrieved from the relay via the
EnerVista 3 Series Setup software for display and diagnostics.
Frequency
Frequency measurement is accomplished by measuring the time between zero crossings
of the Bus VT phase A voltage. The signals are passed through a low pass filter to prevent
false zero crossings. Sampling is synchronized to the Va-x voltage zero crossing which
results in better co-ordination for multiple 350 relays on the same bus.
Phasors, Transients, and Harmonics
Current waveforms are processed four times every cycle with a DC Offset Filter and a
Discrete Fourier Transform (DFT). The resulting phasors have fault current transients and all
harmonics removed. This results in an overcurrent relay that is extremely secure and
reliable; one that will not overreach.
Processing of AC Current Inputs
The DC Offset Filter is an infinite impulse response (IIR) digital filter, which removes the DC
component from the asymmetrical current present at the moment a fault occurs. This is
done for all current signals used for overcurrent protection; voltage signals bypass the DC
Offset Filter. This filter ensures no overreach of the overcurrent protection.
The Discrete Fourier Transform (DFT) uses exactly one sample cycle to calculate a phasor
quantity which represents the signal at the fundamental frequency; all harmonic
components are removed. All subsequent calculations (e.g. RMS, power, etc.) are based
upon the current and voltage phasors, such that the resulting values have no harmonic
components.
Protection Elements
Protection elements are processed up to four times every cycle to determine if a pickup
has occurred or a timer has expired. The protection elements use RMS current/voltage,
based on the magnitude of the phasor. Hence, protection is impervious to both harmonics
and DC transients.
NOTE
NOTE: Arc Flash protection elements are processed up to 8 times every cycle.

CHAPTER 1: INTRODUCTION DESCRIPTION OF THE 350 FEEDER PROTECTION SYSTEM
350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE 3
Figure 1-1: Functional block diagram
Table 1-1: ANSI device numbers and functions
898742A7.CDR
A350 RELAYY
TRIP
BUS
LOAD
3
1
52
CLOSE
50G/
51G
50P 50N
79
22
21
METERING
TRANSIENT RECORDER
EVENT RECORDER
FAULT REPORT
51N51P 50_2
111
49
1
27X
59P27P
59X
59_2 59N 81U 81O
CLP
50BF
1
11
1
1122
MONITORING
BUS VT
67P
1
1
51_2 67N
1
CTS
25
51G/SG 67G/SG50G/SG
I/I
12
27_1
1
86
VTFF
1
24
32N
2
32
50P HS
1
1
50G/SG
HS
AF
SENSORS
ANSI Code 61850 Logical Node Description
24 PVPH Volts per Hertz
25 RSYN1 Synchrocheck
27_1 psseqPTUV1 Positive Sequence Undervoltage
27P phsPTUV1, phsPTUV2,
phsPTUV3, phsPTUV4
Phase Undervoltage
27X auxPTUV1 Auxiliary Undervoltage
32 PDOP1, PDOP2 Directional Power
32N ndPDOP Wattmetric Ground Fault
I1/I2 (46BC) -Broken Conductor
49 PTTR1 Thermal Overload
50_2 ngseqPIOC1 Negative Sequence Overcurrent
50BF RBRF1 Breaker Failure
50G/SG gndPIOC1, gndPIOC2/
hsePIOC1, hsePIOC2
Ground/Sensitive Ground Instantaneous Overcurrent
50N ndPIOC1, ndPIOC2 Neutral Instantaneous Overcurrent
50P phsPIOC1, phsPIOC2 Phase Instantaneous Overcurrent
51_2 ngseqPTOC1 Negative Sequence Time Overcurrent
51G/SG gndPTOC1/hsePTOC1 Ground/Sensitive Ground Time Overcurrent
51N ndPTOC1 Neutral Time Overcurrent
51P phsPTOC1 Phase Time Overcurrent
59_2 ngseqPTOV1,
ngseqPTOV2
Negative Sequence Overvoltage

4350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
DESCRIPTION OF THE 350 FEEDER PROTECTION SYSTEM CHAPTER 1: INTRODUCTION
Table 1-2: Other device functions
59N ndPTOV1, nfPTOV2,
ndPTOV3, ndPTOV4
Neutral Overvoltage
59P phsPTOV1, phsPTOV2,
phsPTOV3, phsPTOV4
Phase Overvoltage
59X auxPTOV1 Auxiliary Overvoltage
60CTS -CT Supervision
67G/SG gndRDIR1/hseRDIR1 Ground/Sensitive Ground Directional Element
67N ndRDIR1 Neutral Directional Element
67P phsRDIR1 Phase Directional Element
79 RREC1 Autoreclose
81O PTOF1, PTOF2, PTOF3,
PTOF4 Overfrequency
81U PTUF2, PTUF2, PTUF3,
PTUF4
Underfrequency
86 -Lockout
CLP -Cold Load Pickup
VTFF (60VTS) -Voltage Fuse Failure
-MMXU1 Voltage, Energy, Power Metering
Description
2nd Harmonic Blocking
Arc Flash Detector
Ambient Temperature
Breaker Control
Breaker Health
Breaker Maintenance
CT Failure Detection
Data Logger
Demand (in metering)
Digital Counters
DNP 3.0 Communications
Event Recorder
Fault Report
Flexcurves
HSR Communications
IEC 60870-5-103 Communications
IEC 60870-5-104 Communications
IEC 61850 Communications
IEC 61850 GOOSE Communications
Lockout (86)
Logic Elements
Metering: current, voltage, power, PF, energy, frequency, 2nd harmonics
Modbus User Map
Modbus RTU Communications
Modbus TCP Communications
Non-volatile Latches
OPC-UA Communications
ANSI Code 61850 Logical Node Description

CHAPTER 1: INTRODUCTION 350 ORDER CODES
350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE 5
Figure 1-2: Main Menu structure
350 order codes
The information to specify a 350 relay is provided in the following order code figure.
Output Relays
PRP Communications
Relay Maintenance
Remote Inputs (32)
Setpoint Groups (2)
Test Mode
Transient Recorder (Oscillography)
Trip and Close Coil Monitoring
User Curves
User-programmable LEDs
Virtual Inputs (32)
Virtual Outputs (32)
Description
ACTUAL VALUES
COMMANDS
SETPOINTS
MAINTENANCE
ACTUAL VALUES
A1 STATUS
A2 METERING
A3 RECORDS
A4 TARGET MESSAGES
QUICK SETUP
RELAY STATUS
NOMINAL FREQUENCY
PH CT PRIMARY
PH CT SECONDARY
VT SEC. VOLTAGE
VT RATIO
AUX VT SECONDARY
AUX VT RATIO
PH TOC FUNCTION
NTRL TOC FNCTN
PH IOC1 FUNCTION
NTRL IOC1 FNCTN
▼
SETPOINTS
S1 RELAY SETUP
S2 SYSTEM SETUP
S3 PROTECTION
S4 CONTROLS
S5 INPUTS/OUTPUTS
▼
MAINTENANCE
M1 RELAY INFO
M3 BKR MAINTENANCE
M5 RELAY MAINT
M6 FACTORY SERVICE
M4 BKR MONITOR
▼
898756A3.cdr
[S]GND CT SECONDARY
S6 MONITORING
M7 TESTING
QUICK SETUP
[S]GND CT PRIMARY
VT CONNECTION
[S]GND TOC FUNCTION
[S]GND IOC1 FNCTN

6350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
350 ORDER CODES CHAPTER 1: INTRODUCTION
Figure 1-3: Order Codes
350  * * * * * * * * * * * *
Interface 350 |||||||||||| 350 Feeder Protection System
User Interface E | | | | | | | | | | | English without programmable LEDs
L | | | | | | | | | | | English with programmable LEDs
Phase Currents
a
a. Phase Current options PX/P0 and Ground Current options GX/G0 are only available with the non-drawout Case Design N.
PX|||||||||| No CT
P0|||||||||| 1 A or 5 A configurable phase current inputs
P1|||||||||| 1 A 3-phase current inputs
P5|||||||||| 5 A 3-phase current inputs
Ground Currents
b
b. Ground Currents G1/G5 and S1/S5 must match the corresponding P1/P5 Phase Currents (i.e. 5A and 1A must not be mixed).
Ground Current GX requires PX Phase Current, and is only available with Case N, Current Protection N, Other Options V, and Input/Output E.
Ground Current G0/S0 must match the P0 Phase Current, and is only available with the non-drawout Case Design N.
GX | | | | | | | | | No CT
G0 | | | | | | | | | 1 A and 5 A configurable ground current input
G1 | | | | | | | | | 1 A ground current input
G5 | | | | | | | | | 5 A ground current input
S0 | | | | | | | | | 1 A or 5A configurable sensitive ground current input
S1 | | | | | | | | | 1 A sensitive ground current input
S5 | | | | | | | | | 5 A sensitive ground current input
Power Supply L | | | | | | | | 24 to 48 V DC
H|||||||| 125 to 250 V DC/120 to 230 V AC
Input/Output
c
c. Input/Output option A is only available with the non-drawout Case Design N
E | | | | | | | Standard (10 Inputs, 7 relay outputs)
A | | | | | | | Standard (10 inputs, 5 relay outputs, 2 MOSFET loads) + 4 Arc Flash detectors
Current Protection
d
d. Current Protection option S has been discontinued.
N|||||| None (voltage and frequency relay, requires a PX/GX configuration)
E|
|| || || || || |Extended configuration: User selectable 49, 50P(2), 50G/SG(2), 50N(2), 51P(1), 51G/SG(1), 51N(1)
M|
|| || || || || |Advanced configuration: Extended + 51_2 or 46(1), 50_2 (1) or 46(1), I1/I2(46BC)
Control N | | | | | CLP, Lockout (86)
C | | | | | CLP, 50BF, Lockout (86), Autoreclose (79)
Other Options
e
e. CLP, 79, and 50BF are not supported when V is selected under Other Options.
N| | | | No selection
V|
|| || || |27P(4), 27X(1), 27P_1(1), 59P(4), 59N(4), 59X(1), 59_2(2), 81O(4), 81U(4), 25(1), VTFF(1), 24(1), Voltage Metering (requires a PX/GX configuration)
D| | | | Neutral and Ground Directional Overcurrent Protection: 67N(1), 67G/SG(1), 60CTS
M| | | | Voltage, Power, and Energy Metering, 60CTS
R|
|| || || |Phase, Neutral, and Ground Directional Overcurrent Protection: 67P(1), 67N(1), 67G/ SG(1), 32N(2), VTFF + Voltage, Power, and Energy Metering, 60CTS
P| |
|
|
|
|
|
|
|
|
|
|
Extended Protection: 27P(2), 27X(1), 27P_1 (1), 59P(2), 59N(1), 59X(1), 59_2(1), 81O(2),
81U(2), 67P(1), 67N(1), 67G/SG(1), VTFF(1), 25(1), 60CTS, Voltage, Power, and Energy
Metering
W| | | | Advanced Protection: Extended + 32(2)
Communications
f
f. Communications option 4E allows the selection of either IEC 61850 or OPC-UA; both cannot be used at the same time.
Communications option 5E is only available with Case Design D or X. 898800AA.PDF
S N | | Standard: Front USB, Rear RS485: Modbus RTU, DNP3.0, IEC60870-5-103
1 E |
|| |Standard + Ethernet (Copper & Fiber - MTRJ), Modbus TCP/IP, DNP3.0, IEC 60870-5-104
2 E |
|| |Standard + Ethernet (Copper & Fiber - MTRJ), Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850 GOOSE
3 E |
|| |Standard + Ethernet (Copper & Fiber - MTRJ), Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850
4 E |
|| |Standard + Ethernet (Copper & Fiber - MTRJ),Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850, OPC-UA
5 E |
|| |Standard + Ethernet (Dual Fiber - MTRJ),Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850, OPC-UA, PRP, HSR, 1588, PTP
Case Design D | Protection Relay with drawout design
N| Protection Relay with non-drawout design
X| Protection Relay (drawout design) with no chassis
Harsh Environment NNone
HHarsh Environment Conformal Coating

CHAPTER 1: INTRODUCTION 350 ORDER CODES
350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE 7
NOTE
NOTE: Features related to each order number are subject to change without notice.
Arc Flash System
The 350 protection relay with Input/Output option “A” supports up to 4 Arc Flash sensors,
which are ordered separately so that the connected sensor fiber lengths can be
customized.
FAST PATH: The total sensor fiber length connected to each loop sensor must not exceed 70 meters of
single sensor fiber. Black sensor fiber is duplex, and must be doubled in calculations.
For example, a loop sensor with a 25 meter transparent sensor fiber plus a sensor fiber
extension of 10 meters would have a total of 2 x 10m + 25m = 45m of single sensor fiber.
FAST PATH: The total sensor fiber length connected to each point sensor must not exceed 35 meters of
black (duplex) cable.
NOTE
NOTE: Generally each loop sensor is used with a sensor fiber extension, in order to minimize
exposure to ambient light when running the sensor fiber between cabinets. A duplex
sensor fiber extension connects the relay to the loop sensor, and can be gently pulled
apart to connect to the loop sensor connectors if they are not adjacent. Consider your
installation needs carefully when ordering sensor and extension lengths.
Empty chassis
The 350 protection relay chassis used with a drawout relay is available separately, for use
as a partial replacement or in test environments. Many features are supported by the
cards and ports within the chassis, as is reflected in the chassis order code.
NOTE
NOTE: The chassis order code and drawout relay order code must match exactly.
FAST PATH: A drawout relay cannot be used in a chassis with different order code options.
897800AF-A1.fm
AFC  * *
AF System Component E | Sensor Fiber Extension (black sensor fiber with two single
bulkhead connectors, used with loop sensors)
L | Loop Sensor with transparent sensor fiber
P | Point Sensor with black sensor fiber
Sensor Fiber Length XX Sensor fiber length:
01 to 35 meters for Point Sensors and Extensions
01 to 70 meters for Loop Sensors

8350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
350 ORDER CODES CHAPTER 1: INTRODUCTION
Figure 1-4: 350 chassis order codes
Other accessories
• 1819-0103 350 Retrofit Kit for 735
• 1819-0102 350 Retrofit Kit for IAC Relay
• 1819-0101 350 Retrofit Kit for MDP Relay
• 1819-0100 350 Retrofit Kit for S1/S2 Cut-Out
• 18L0-0075 3 Series Depth reducing collar - 1.375”
• 18L0-0076 3 Series Depth reducing collar - 3.00”
• 18L0-0080 3 Series IP20 Kit
• 3S-NDO-STCONKIT 3 Series NDO straight terminal block kit
• 0804-0458 USB A-B configuration cable - 6’
NOTE
NOTE: Refer to the 3 Series Retrofit Instruction Manual for the retrofit of Multilin MI, MII, MLJ, and
TOV relays.
350  CH  * * * * * *
Phase Currents P1 | | | | | 1 A 3-phase current inputs
P5 | | | | | 5 A 3-phase current inputs
Ground Currents
a
a. Ground current options G1/G5 must match the corresponding P1/P5 Phase currents
G1 | | | | 1 A ground current input
G5 | | | | 5 A ground current input
S1 | | | | 1 A sensitive ground current input
S5 | | | | 5 A sensitive ground current input
Other Options N | | | No selection
D| | | Neutral and Ground Directional Overcurrent Protection: 67N(1), 67G/SG(1), 60CTS
M| | | Voltage, Power, and Energy Metering, 60CTS
R|
|| || |Phase, Neutral, and Ground Directional Overcurrent Protection: 67P(1), 67N(1), 67G/SG(1), 32N(2), VTFF + Voltage, Power, and Energy Metering, 60CTS
P|
|| || |
Extended Protection: 27P(2), 27X(1), 27P_1 (1), 59P(2), 59N(1), 59X(1), 59_2(1), 81O(2),
81U(2), 67P(1), 67N(1), 67G/SG(1), VTFF(1), 25(1), 60CTS, Voltage, Power, and Energy
Metering
W| | | Advanced Protection: Extended + 32(2)
Communications
b
b. Communications option 4E allows the selection of either IEC 61850 or OPC-UA; both cannot be used at the same time.
898800CH-A2.PDF
S N | Standard: Front USB, Rear RS485: Modbus RTU, DNP3.0, IEC60870-5-103
1 E |
|Standard + Ethernet (Copper & Fiber - MTRJ), Modbus TCP/IP, DNP3.0, IEC 60870-5-104
2 E |
|Standard + Ethernet (Copper & Fiber - MTRJ), Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850 GOOSE
3 E |
|Standard + Ethernet (Copper & Fiber - MTRJ), Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850
4 E |
|Standard + Ethernet (Copper & Fiber - MTRJ),Modbus TCP/IP, DNP3.0, IEC 60870-5- 104, IEC 61850, OPC-UA
5 E |
|Standard + Ethernet (Dual Fiber - MTRJ),Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850, OPC-UA, PRP, HSR, 1588, PTP
Harsh Environment N None
HHarsh Environment Conformal Coating

CHAPTER 1: INTRODUCTION SPECIFICATIONS
350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE 9
Specifications
NOTE
NOTE: Specifications are subject to change without notice.
NOTE
NOTE: To obtain the total element operating time, i.e. from the presence of a trip condition to
initiation of a trip, add 8 ms output relay time to the operate times listed below, with the
exception of Arc Flash SSR loads.
Password security
PASSWORD SECURITY
Master Password: ...............................................8 to 10 alpha-numeric characters
Settings Password:.............................................3 to 10 alpha-numeric characters for local and remote
access
Control Password:...............................................3 to 10 alpha-numeric characters for local and remote
access
Protection
BROKEN CONDUCTOR (I1/I2 OR 46BC)
Minimum operating positive current:........ 0.05 to 1.00 x CT in steps of 0.01 x CT
Maximum operating positive current:....... 0.05 to 5.00 x CT in steps of 0.01 x CT
Pickup level:........................................................... 20.0% to 100.0% in steps of 0.1%
Dropout level:........................................................ 97% to 98% of the pickup level
Pickup time delay: .............................................. 0.000 to 65.535 s in steps of 0.001 s
Timer accuracy: .................................................. ± 3% of delay setting or ± ¾ cycle (whichever is greater)
from pickup to operate
Operate time:........................................................ <30 ms at 60 Hz
WATTMETRIC GROUND FAULT (32N)
Measured power: ................................................ zero sequence
Number of elements: ........................................ 1
Characteristic angle: ......................................... 0º to 359º in steps of 1°
Pickup threshold:................................................. 0.001 to 1.200 pu in steps of 0.001 pu
Pickup level accuracy:...................................... ± 2% or ± 0.03 pu, whichever is greater
Hysteresis:.............................................................. 3% or 0.001 pu, whichever is greater
Pickup delay:......................................................... Definite Time (0.00 to 600 .0 s in steps of 0.1 s), Inverse Time,
or Flexcurve
Inverse time multiplier:..................................... 0.01 to 2.00 in steps of 0.01
Curve timing accuracy:.................................... ± 3.5% of operate time or ± ¼ cycle (whichever is greater)
from pickup to operate
Operate time:........................................................ <30 ms at 60 Hz

10 350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
SPECIFICATIONS CHAPTER 1: INTRODUCTION
DIRECTIONAL POWER (32)
Measured power:................................................ 3-phase
Characteristic angle:......................................... 0º to 359º in steps of 1°
Power pickup range: ......................................... -1.200 to 1.200 x Rated Power in steps of 0.001
Pickup level accuracy:...................................... 2.5% or 0.01 pu, whichever is greater
Hysteresis: ............................................................. 2% or 0.001 x Rated Power, whichever is greater
Pickup time delay:.............................................. 0.0 to 600.0 s in steps of 0.1 s
Operate time:........................................................ < 55 ms at 1.1 x pickup at 60 Hz
< 65 ms at 1.1 x pickup at 50 Hz
Timer accuracy:.................................................. ± 3% of delay setting or ± ¼ cycle (whichever is greater)
from pickup to operate
VOLTS PER HERTZ (24)
Inputs: ...................................................................... Van (Wye VTs), Vab (Delta VTs)
Pickup Level: ......................................................... 0.80 to 4.00 x V/Hz in steps of 0.01 x V/Hz
Dropout Level:...................................................... 97% to 98% of pickup
Level Accuracy: ................................................... ± 0.02 x V/Hz or 2% of set value, whichever is greater
Time Curves:......................................................... Definite Time, Inverse A/B/C, FlexCurves A/B
TD Multiplier: ......................................................... 0.00 to 600.00 s in steps of 0.01 s
Reset Delay: .......................................................... 0.00 to 600.00 s in steps of 0.01 s
Time Accuracy:.................................................... ± 3% of operate time of ±15 cycles (whichever is greater) for
values greater than 1.1 x pickup
PHASE/NEUTRAL/GROUND/NEGATIVE SEQUENCE TIME OVERCURRENT (51P/51N/51G/
51_2)
Pickup Level: ......................................................... 0.05 to 20.00 x CT in steps of 0.01 x CT
Dropout Level:...................................................... 97% of Pickup @ I > 1 x CT
Pickup - 0.02 x CT @ I < 1 x CT
Curve Shape:......................................................... ANSI Extremely/Very/Moderately/Normally Inverse
Definite Time (0.1 s base curve)
IEC Curve A/B/C and Short Inverse
IAC Extreme/Very/-/Short Inverse
User Curve, FlexCurve™A/B (programmable curves)
Curve Multiplier: .................................................. 0.05 to 50.00 in steps of 0.01
Reset Time: ............................................................ Instantaneous, Linear
Curve Timing Accuracy:.................................. ±3% of expected inverse time or 1.5 cycle, whichever is
greater, from pickup to operate
Level Accuracy: ................................................... per CT input
SENSITIVE GROUND TIME OVERCURRENT (51SG)
Pickup Level: ......................................................... 0.005 to 3.000 x CT in steps of 0.001 x CT
Dropout Level:...................................................... 97% of Pickup @ I > 0.1 x CT
Pickup - 0.002 x CT @ I < 0.1 x CT
Curve Shape:......................................................... ANSI Extremely/Very/Moderately/Normally Inverse
Definite Time (0.1 s base curve)
IEC Curve A/B/C/Short Inverse
IAC Extreme/Very/-/Short Inverse
User Curve, FlexCurve™A/B
Curve Multiplier: .................................................. 0.05 to 50.00 in steps of 0.01
Reset Time: ............................................................ Instantaneous, Linear
Curve Timing Accuracy:.................................. ±3% of expected inverse time or 1 cycle, whichever is
greater, from pickup to operate
Level Accuracy: ................................................... per CT input

CHAPTER 1: INTRODUCTION SPECIFICATIONS
350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE 11
PHASE/NEUTRAL/GROUND/NEGATIVE SEQUENCE INSTANTANEOUS OVERCURRENT
(50P/50N/50G/50_2)
Pickup Level:.......................................................... 0.05 to 20.00 x CT in steps of 0.01 x CT
Dropout Level: ...................................................... 97% of Pickup @ I > 1 x CT
Pickup - 0.02 x CT @ I <1 x CT
Time Delay:............................................................ 0.00 to 300.00 sec in steps of 0.01
Operate Time:....................................................... <30 ms @ 60Hz (I > 2.0 x PKP, No time delay)
<35 ms @ 50Hz (I > 2.0 x PKP, No time delay)
Time Delay Accuracy: ...................................... 1% or 1 cycle, whichever is greater (Time Delay selected)
Level Accuracy:.................................................... per CT input
SENSITIVE GROUND INSTANTANEOUS OVERCURRENT (50SG)
Pickup Level (Gnd IOC):..................................... 0.005 to 3.000 x CT in steps of 0.001 x CT
Dropout Level: ...................................................... 97% of Pickup @ I > 0.1 x CT
Pickup - 0.002 x CT @ I < 0.1 x CT
Time Delay:............................................................ 0.00 to 300.00 sec in steps of 0.01
Operate Time:....................................................... <30 ms @ 60Hz (I > 2.0 x PKP, No time delay)
<35 ms @ 50Hz (I > 2.0 x PKP, No time delay)
Time Delay Accuracy: ...................................... 1% or 1 cycle, whichever is greater (Time Delay selected)
Level Accuracy:.................................................... per CT input
PHASE DIRECTIONAL (67P)
Directionality: ....................................................... Co-existing forward and reverse
Operating:............................................................... Phase Current (Ia, Ib, Ic)
Polarizing Voltage:.............................................. Quadrature Voltage
(ABC phase sequence: Vbc, Vca, Vab)
(CBA phase sequence: Vcb, Vac, Vba)
Polarizing voltage threshold: ......................... 0.05 to 1.25 x VT in steps of 0.01
MTA (Maximum Torque Angle): ..................... From 0ºto 359ºin steps of 1°
Angle Accuracy: .................................................. ±4º
Operational Delay: ............................................. 20 to 30 ms
NOTE
NOTE: The selection of the “P” or “R” option from “350 OTHER OPTIONS” in the order code table,
will enable the Phase directional element. The polarizing voltage used for this element is
the line voltage.
GROUND DIRECTIONAL (67G)
Directionality: ....................................................... Co-existing forward and reverse
Operating:............................................................... Ground Current (Ig)
Polarizing Voltage:.............................................. -V0calculated using phase voltages (VTs must be connected
in “Wye”)
-3V0measured from Vaux input. (3V0provided by an
external open delta connection).
MTA (Maximum Torque Angle): ..................... From 0ºto 359ºin steps of 1°
Angle Accuracy: .................................................. ±4º
Operational Delay: ............................................. 20 to 30 ms
NOTE
NOTE: The selection of the “D” option from “350 OTHER OPTIONS” in the Order Code table, will
enable the Ground Directional element with voltage polarizing 3V0measured from the
Vaux voltage input.
NOTE
NOTE: The selection of the “P”, “R”, or “W” option from “350 OTHER OPTIONS” in the order code
table, will enable the Ground directional element. The polarizing voltage used for this
element is the computed V0from the measured phase voltage inputs.

12 350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
SPECIFICATIONS CHAPTER 1: INTRODUCTION
NEUTRAL DIRECTIONAL (67N)
Directionality: ....................................................... Forward and reverse
Polarizing:............................................................... Voltage, Current, Dual
Polarizing Voltage:.............................................. - V0calculated using phase voltages (VTs must be
connected in “Wye”)
-3V0measured from Vaux input (3V0provided by an
external broken delta connection).
Polarizing Current:.............................................. IG
MTA:........................................................................... From 0ºto 359ºin steps of 1°
Angle Accuracy: .................................................. ±4º
Operational Delay:............................................. 20 to 30 ms
NOTE
NOTE: The selection of the “D” option from “350 OTHER OPTIONS” in the Order Code table, will
enable the Neutral Directional element with voltage polarizing 3V0measured from the
Vaux voltage input.
The selection of “P”, “R”, or “W” option from “350 OTHER OPTIONS” in the Order Code table,
will enable the Neutral Directional elements with voltage polarizing V0computed from the
measured phase voltage inputs.
The ground polarizing current, IG, is available for selection in both cases.
THERMAL OVERLOAD (49)
Current:.................................................................... RMS current - max (Ia, Ib, Ic)
Pickup Accuracy: ................................................ per current inputs
Timing Accuracy:................................................ See graph below
Figure 1-5:
The graph shows the trip time error with respect to the ratio of cable load and thermal
model pickup setting. With a smaller I/Ipkp ratio, the time error tends to be higher, as
accumulated through the logarithmic formula, the measurement error, and the time of
measurement. For higher I/Ipkp ratios, the time to trip is substantially more accurate. Each
point on the graph represents a trip time error, with the I/Ipkp ratio kept constant during
the test.
PHASE/AUXILIARY/POSITIVE SEQUENCE UNDERVOLTAGE (27P, 27X, 27_1)
Minimum Voltage: .............................................. Programmable from 0.00 to 1.25 x VT in steps of 0.01
Pickup Level: ......................................................... 0.00 to 1.25 x VT in steps of 0.01
Dropout Level:...................................................... 102% of pickup (pickup > 0.1 x VT)
Pickup + 0.02 x VT (pickup < 0.1 x VT)
Curve: ....................................................................... Definite Time, Inverse Time
Time Delay: ........................................................... 0.00 to 600.00 s in steps of 0.01
Operate Time: ...................................................... Time delay ±30 ms @ 60 Hz (V < 0.85 x PKP)
Time delay ±40 ms @ 50 Hz (V < 0.85 x PKP)
Time Delay Accuracy:...................................... ±3% of expected time, or 1 cycle, whichever is greater
Level Accuracy: ................................................... Per voltage input

CHAPTER 1: INTRODUCTION SPECIFICATIONS
350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE 13
PHASE/AUXILIARY/NEUTRAL/NEGATIVE SEQUENCE OVERVOLTAGE (59P, 59X, 59N, 59_2)
Pickup Level:.......................................................... 0.00 to 1.25 x VT in steps of 0.01
Dropout Level: ...................................................... 98% of pickup (pickup > 0.1 x VT)
Pickup - 0.02 x VT (pickup < 0.1 x VT)
Time Delay:............................................................ 0.00 to 600.00 s in steps of 0.01
Operate Time:....................................................... Time delay ±35 ms @ 60Hz (V > 1.1 x PKP)
Time delay ±40 ms @ 50Hz (V > 1.1 x PKP)
Time Delay Accuracy: ...................................... ±3% of expected time, or 1 cycle, whichever is greater
Level Accuracy:.................................................... Per voltage input
UNDERFREQUENCY (81U)
Minimum Voltage:............................................... 0.00 to 1.25 x VT in steps of 0.01
Pickup Level:.......................................................... 40.00 to 70.00 Hz in steps of 0.01
Dropout Level: ...................................................... Pickup + 0.05 Hz
Time Delay:............................................................ 0.10 to 600.0 s in steps of 0.01
Time Delay Accuracy: ...................................... 0 to 6 cycles (Time Delay selected)
Operate Time:....................................................... Typically 10 cycles @ 0.1Hz/s change
Level Accuracy:.................................................... ±0.03 Hz
OVERFREQUENCY (81O)
Minimum Voltage:............................................... 0.3 x VT
Pickup Level:.......................................................... 40.00 to 70.00 Hz in steps of 0.01
Dropout Level: ...................................................... Pickup - 0.05 Hz
Time Delay:............................................................ 0.1 to 600.0 s in steps of 0.01
Time Delay Accuracy: ...................................... 0 to 6 cycles (Time Delay selected)
Operate Time:....................................................... Typically 10 cycles @ 0.1Hz/s change
Level Accuracy:.................................................... ±0.03 Hz
ARC FLASH HS PHASE/GROUND INSTANTANEOUS OVERCURRENT HS 50P/50G
Current:.................................................................... RMS Magnitude (special high speed algorithm)
Pickup Level:.......................................................... 0.050 to 30.000 x CT in steps of 0.001 x CT
Dropout Level: ...................................................... 97 to 98% of Pickup
Level Accuracy:.................................................... For 0.1 to 0.2 x CT: ± 0.2% of reading or 1.5% of rated
current, whichever is greater
For > 0.2 x CT: ± 5% of reading
Operate Time:....................................................... 4 ms at >6 x Pickup at 60 Hz
5 ms at >6 x Pickup at 50 Hz
4-8 ms at > (3-6) x Pickup at 60 Hz
4-10 ms at > (3-6) x Pickup at 50 Hz
NOTE
NOTE: The operate times listed require that SSR output relays (Aux 5 and 6) be used for Arc Flash
detection.
ARC FLASH SENSOR/FIBER
Number of Sensors: ........................................... 4
Detection Radius:................................................ 180 degree
Maximum Duplex Fiber Length (Point
Sensor):............................................................... 35 m
Maximum Single Fiber Length (Loop
Sensor):............................................................... 70 m
Fiber Size:................................................................ 1.0 mm core diameter
2.2 mm total diameter (single)
4.4 mm total diameter (duplex)
Mode:........................................................................ Multi-mode
Connector:.............................................................. Small Media Interface (SMI)
Fiber Type:.............................................................. Plastic Optical Fiber
Bend Radius: ......................................................... 35 mm minimum
Product Type:........................................................ Class 1 Laser product

14 350 FEEDER PROTECTION SYSTEM – QUICKSTART GUIDE
SPECIFICATIONS CHAPTER 1: INTRODUCTION
Metering
NOTE
NOTE: Negative values (-) represent lead and positive values (+) represent lag.
CURRENTS
Parameters:...........................................................Phase A, Phase B, Phase C, Neutral, Ground, Sensitive
Ground, Positive Sequence, Negative Sequence, Zero
Sequence, and 2nd Harmonic
Accuracy: ...............................................................See the Inputs section in Chapter 1: Specifications
VOLTAGES
Parameters:...........................................................Wye VTs: AN, BN, CN, Negative Sequence, Zero Sequence
and Auxiliary
Delta VTs: AB, BC, CA, Negative Sequence, Zero Sequence
and Auxiliary
Accuracy: ...............................................................See the Inputs section in Chapter 1: Specifications
Data capture
TRANSIENT RECORDER
Buffer size: ............................................................. 3 s
No. of buffers:....................................................... 1, 3, 6
No. of channels:...................................................14
Sampling rate:......................................................4, 8, 16, or 32 samples per cycle
Triggers: .................................................................. Manual Command
Contact Input
Virtual Input
Logic Element
Element Pickup/Trip/Dropout/Alarm
Data: ......................................................................... AC input channels
Contact input state
Contact output state
Virtual input state
Logic element state
Data storage:........................................................RAM - battery backed-up
FAULT RECORDER
Number of records:............................................ 1
Content:................................................................... Date and Time, first cause of fault, phases,
Currents: Ia, Ib, Ib, Ig/Isg, In - magnitudes and angles
Voltages: Van, Vbn, Vcn, Vab, Vbc, Vca, Vaux - magnitudes
and angles
System frequency
PARAMETER ACCURACY
(full scale for
CT Input is 3 x CT)
RESOLUTION RANGE
3-Phase Real Power (MW or kW) ±1% of full scale 0.1 MW ± 100000.0 kW
3-Phase Reactive Power (Mvar or kvar) ±1% of full scale 0.1 Mvar ± 100000.0 kvar
3-Phase Apparent Power (MVA or kVA) ±1% of full scale 0.1 MVA ± 100000.0 kVA
3-Phase Positive Watthour (MWh) ±1% of full scale ±0.001 MWh 50000.0 MWh
3-Phase Negative Watthour (MWh) ±1% of full scale ±0.001 MWh 50000.0 MWh
3-Phase Positive Varhour (Mvarh) ±1% of full scale ±0.001 Mvarh 50000.0 Mvarh
3-Phase Negative Varhour (Mvarh) ±1% of full scale ±0.001 Mvarh 50000.0 Mvarh
Power Factor ±0.05 0.01 -0.99 to 1.00
Frequency ±0.05 Hz 0.01 Hz 40.00 to 70.00 Hz
