4 SLICE TOASTER
Model Number:
169211
UPC: 681131692113
Customer Assistance
1 877 207 0923 (US)
1 877 556 0973 (Canada)
Thank you for purchasing a small GE appliance.
In keeping with the GE ecomagination initiative, please consider the option to recycle
the packaging material and donate the appliance you are no longer using.
To read more about GE's ecomagination commitment, visit:
ge.ecomagination.com
169211-03 (EN).indd 1 6/26/09 12:50:56 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 2 (of 11 pages)
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to
prevent the risk of fire, electric shock, burns, or other injuries or damages.
• Read all instructions before use.
• Donottouchhotsurfaces.Usehandlesorknobs.
• Toprotectagainstelectricalshockdonotimmersecordorpluginwaterorother
liquids.
• Closesupervisionisnecessarywhenanyapplianceisusedbyornearchildren.
• Unplugfromoutletwhennotinuseandbeforecleaning.Allowittocoolbefore
putting on or taking off parts.
• Do not operate appliance with a damaged cord or plug, or after the appliance
malfunctions or has been dropped or damaged in any manner. Call our toll-
free customer assistance number for information on examination, repair, or
adjustment.
• The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
• Donotuseoutdoors.
• Donotletcordhangoveredgeoftableorcounter,ortouchhotsurfaces.
• Donotplaceonornearahotgasorelectricburner,orinaheatedoven.
• Todisconnect,turneverycontrolto“off”,thenremoveplugfromthewalloutlet.
• Donotusethisapplianceforanythingotherthanitsintendeduse.
• Oversizedfoods,metalfoilpackages,orutensilsmustnotbeinsertedinthetoaster
as they may cause a risk of fire or electric shock.
• Aremayoccurifthetoasteriscoveredortouchingammablematerial,including
curtains, draperies, walls, etc., when in operation.
• Donotattempttodislodgefoodwhentoasterispluggedin.
• Donotoperatetoasterunattended.
• Riskofreifthecrumbtrayisnotcleanedregularly.
• Donotusemetalscouringpadsforcleaning.Piecescangetbroken,andthereisa
risk of electric shock if the pad comes in contact with electrical parts.
• Donotcook,warmortoastricecakes,friedfoods,ornon-breaditems.
SAVE THESE INSTRUCTIONS!
2
169211-03 (EN).indd 2 6/26/09 12:50:56 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 3 (of 11 pages)
ADDITIONAL SAFEGUARDS
This appliance is for HOUSEHOLD USE ONLY.
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE, OR IF
APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
Extension cord use
A short power-supply cord is to be provided to reduce the risk resulting from becoming
entangled in or tripping over a longer cord. Longer detachable power-supply cords or
extension cords are available and may be used if care is exercised in their use. If a longer
detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance, and
2) The cord should be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over unintentionally.
3) If the appliance is of the grounded type, the extension cord should be a grounding-
type 3-wire cord.
GROUNDING INSTRUCTIONS
This appliance must be grounded while in use.
CAUTION: To ensure continued protection against risk of electric shock, connect to
properly ground outlets only.
GROUNDING INSTRUCTIONS – US ONLY
The appliance has a plug that looks like Figure A. An adaptor, as shown in Figure B, should
be used for connecting a 3-prong grounding plug to a 2-wire receptacle. The grounding
tab, which extends from the adaptor, must be connected to a permanent ground such
as a properly grounded receptacle as shown in Figure C, using a metal screw.
3
(B)
Circuit grounding conductor
connected properly
Grounding prong
Adapter
(A)
Grounding means
AA220
Cover of grounded
outlet box
Metal mounting
screw
(C)
169211-03 (EN).indd 3 6/26/09 12:50:56 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 4 (of 11 pages)
PARTS
1
2
3
4
568910 7
1. Slots with self-centering guides
2. Toast lift
3. Power cord with power plug
4. Cord storage
5. reheat button
6. frozen button
7. Electronic browning control knob
(browning levels: 1to 7)
8. Crumb tray
9. bagel button
10. cancel button
NOTE: This toaster contains two independently operating toasting units. Each unit
consists of two toasting slots. Both units are controlled by an individual set of operation
buttons (ill. f).
4
169211-03 (EN).indd 4 6/26/09 12:50:57 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 5 (of 11 pages)
ILLUSTRATIONS
5
b
a
ef
d
hi
g
l
k
j
c
169211-03 (EN).indd 5 6/26/09 12:51:04 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 6 (of 11 pages)
OPERATION
Before first use
• Removeallpackagingmaterial,labelsand/orstickersfromyourtoaster.Makesure
there is no packaging material remaining in the slots.
• Cleantoasterthoroughlybeforeusingitforthersttime( Cleaning).
NOTE: Due to the manufacturing process, the toaster may emit a slight burning odor.
Let the toaster complete a few toasting cycles without food, until no odor or smoke
is present. Note: use the toaster in a well ventilated area and select 7as the highest
setting.
Operating instructions
• Makesurenofoodorotherobjectsareinsidetheslots (1). Place the toaster on a
at,level,heat-resistantsurface.
• Makesurebothcrumbtrays(8) are inserted properly (ill. a).
• Removeanyprotectivewrappingsfromfoodsbeforeplacingthemintheslots(1).
Do not toast torn food as it may become lodged in the slots (1).
NOTE: Both toasting units work independently from each other. You can, for example,
toast food with the left unit's two toasting slots (1), while simultainously toasting bagels
with the right unit.
• Insertthebreadslicesinoneoftheslotpairs(1) (ill. b). Select the desired browning
setting with the browning control knob (7) of the chosen toasting unit (ill. c).
Choose between settings 1to 7according to your preference.
• Inserttheplug(3)intoa120V~60Hzwalloutlet(ill. d).
• Pressdownthetoastlift(2) (ill. d). The toasting process begins.
• Duringthetoastingcycle,the cancel button (10) is illuminated blue. To stop or
interrupt a toasting cycle, press the cancel button (ill. g); toaster food will pop
up and the toaster will turn off.
• The toaster food will pop up when it has reached the corresponding browning
level (ill. h).
6
169211-03 (EN).indd 6 6/26/09 12:51:05 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 7 (of 11 pages)
OPERATION
• Thistoasterisequippedwithanextratoastlifttoassistinremovingtoasterfood
from the slots (1). Pull the toast lift (2) upwards to lift the toaster food higher for ease
of removal (ill. i).
• Alwaysunplugthetoasterfromthewalloutletwhennotinuse.
NOTE: The toast lift (2) will not stay in the down position unless the toaster is connected
toanenergizedwalloutlet.
Using the second slot pair
• Whiletherstslotpair(1) is in use, place food in the second slot pair (ill. e).
• Select the desired browning setting with the browning control knob (7) of the
chosen toasting unit (ill. c). Choose between settings 1to 7according to your
preference.
• Pressdownthetoastlift (2) (ill. e). The toasting process begins.
• The toaster food will pop up when it has reached the corresponding browning
level (ill. h).
Reheat
• Placefoodintheslots(1) (ill. b).
• Lockthetoastlift (2) in the down position and press the reheat button (5) (ill. g)
within the next 5 seconds. The reheat button lights up blue.
• The food will pop up when it has reached the corresponding browning
level (ill. h).
Frozen food function
• Placefrozenfoodintheslots (1) (ill. b).
• After selecting the browning level with the browning control knob (7) (ill. c), press
down the toast lift (2) (ill. d) until it is locked in the down position.
• Pressthe frozen button (6) (ill. g) within 5 seconds after the toast lift (2) is
locked down. The frozen button (6) will light up blue after it is pressed.
• Thedefrostedbreadorfoodwill popupwhenithasreachedthecorresponding
browning level (ill. h).
7
169211-03 (EN).indd 7 6/26/09 12:51:05 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 8 (of 11 pages)
OPERATION
Toasting bagels and English muffins
• Cut bagel or English muffin in half. Do not force bagel or English muffin into slots.
It may be necessary to cut food in slices to fit in comfortably. Place the bagel or
the English muffin in the slots (1) and turn the cut sides of the bagel or the English
muffin towards the middle of the toaster to achieve a better result.
• Afterselectingthebrowninglevelwiththebrowningcontrolknob(8) (ill. c), press
down the toast lift (2) (ill. d) until it is locked in the down position.
• Press the bagel button (9) (ill. g) within 5 seconds after the toast lift (2) is
locked down. The bagel button will light up blue after being pressed.
• ThebagelorEnglishmufnwill popup when it has reached the corresponding
browning level (ill.
h
).
Combining programs
It is possible to combine the bagel button (9) with the frozen and reheat
functions. If the bagel button is pressed before or after the reheat or frozen
buttons, the toaster will operate on a lower power setting.
Reheat Defrost
Bagel • Press bagel (9) and reheat
(5) (ill. g). Both buttons will
light up blue.
• Reheatwillstartwithlow
power setting.
• Adjust the browning level with the
browning control knob (7) (ill. c).
• Press bagel (9) and frozen
(6) (ill. g). Both buttons will light
up blue.
NOTE: Both buttons must be pressed within 5 seconds after the toast lift is locked in
down position.
CAUTION: Before cleaning and storing, unplug the toaster to prevent electric shock and
let the toaster cool down completely.
8
169211-03 (EN).indd 8 6/26/09 12:51:06 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 9 (of 11 pages)
CLEANING
Clean the toaster regularly. This appliance contains no user serviceable parts and
requires little maintenance. Leave any servicing or repairs to qualified personnel.
• Neverimmersetoasterorpowercord (3) in water or any other liquid.
• Donotuseaforkorothermetallicutensilstoremovelodgedfoodasthismayresult
in electric shock or fire (ill. k).
• Useasoftclothoradampspongeandamilddetergenttocleantheoutsideofthe
toaster and the cord (3). Do not use any abrasive cleaning agents, metallic utensils,
metal scouring pads, etc.
• Tocleanthecrumbtray (8), pull it out completely and throw crumbs away.
Rinse the crumb tray with water and a little detergent, and dry it with a soft cloth
(ill. j). Reinsert the crumb tray (8) (ill. a) carefully.
• Donotwrapthecordaroundthetoaster(ill. l). Store the cord in the cord storage
(4) underneath the toaster.
9
169211-03 (EN).indd 9 6/26/09 12:51:06 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 10 (of 11 pages)
TROUBLESHOOTING
Problem Solution
Toaster is not working. Check power connection. The plug (3) should be
inserted properly in the outlet.
Food stuck in the toaster. Unplug the toaster and let cool. Carefully remove the
slice(s) from the toaster.
Toast too dark or too light. The selected browning setting is too high or too low.
Toaster emits smoke. The selected browning setting is too high for the type
of food which is being toasted. Press the cancel
button (10) (ill. g) to stop the toasting cycle.
Food ejects very quickly. Push down the toast lift (2) (ill. d) completely.
If additional assistance is needed, please contact our Customer Assistance at
1.877.207.0923 (U.S.) or 1.877.556.0973 (Canada).
TECHNICAL DATA
Ratedvoltage: 120V~,60Hz
Rated current: 13.5A
Rated power input: 1600W
10
169211-03 (EN).indd 10 6/26/09 12:51:06 PM

Client: Select Brands (Wal*Mart)
Project: 169211
Language: EN (US)
Date: 26.06.2009
Version: 03
Page: 11 (of 11 pages)
CUSTOMER ASSISTANCE
If you have a claim under this warranty, please call our Customer Assistance Number. For faster
service, please have the model number and product name ready for the operator to assist you. This
number can be found on the bottom of your appliance and on the front page of this manual.
Model Number: __________________ Product Name: __________________
Customer Assistance Number 1.877.207.0923 (U.S.) or 1.877.556.0973 (Canada).
Keep these numbers for future reference!
For more information, please visit us at WWW.GEHOUSEWARES.COM
Two-year limited warranty
What does your warranty cover?
• Anydefectinmaterialorworkmanship.
For how long after the original purchase?
• Twoyears.
What will we do?
• Provideyouwithanewone.
• Forthoseitemsstillunderwarrantybut
no longer available, WAL-MART reserves
the right to replace with a similar GE
branded product of equal or greater
value.
How do you make a warranty claim?
• Saveyourreceipt.
• Properlypackyourunit.Werecommend
using the original carton and packing
materials.
• Returntheproducttoyournearest
WAL-MART store or call Customer
Assistance at 1-877-207-0923 (U.S.)
or 1-877-556-0973 (Canada).
What does your warranty not cover?
• Partssubjecttowear,including,without
limitation, glass parts, glass containers,
cutter/strainer,blades,seals,gaskets,
clutches,motorbrushes,and/oragitators,
etc.
• Commercialuseoranyotherusenot
found in printed directions.
• Damagefrommisuse,abuse,or
neglect, including failure to clean
product regularly in accordance with
manufacturer's instructions.
How does state law relate to this warranty?
• Thiswarrantygivesyouspeciclegal
rights, and you may also have other rights
which vary from state to state or province
to province.
• Thiswarrantyisinlieuofanyother
warranty or condition, whether express or
implied, written or oral, including, without
limitation, any statutory warranty or
condition of merchantability or fitness for
a particular purpose.
• WAL-MART,GEandtheproduct
manufacturer expressly disclaim all
responsibility for special, incidental, and
consequential damages or losses caused
by use of this appliance. Any liability is
expressly limited to an amount equal to
the purchase price paid whether a claim,
however instituted, is based on contract,
indemnity, warranty, tort (including
negligence), strict liability, or otherwise.
Some states or provinces do not allow
this exclusion or limitation of incidental
or consequential losses, so the foregoing
disclaimer may not apply to you.
What if you encounter a problem with this
product while using it outside the country of
purchase?
• Thewarrantyisvalidonlyinthecountryof
purchase and if you follow the warranty
claim procedure as noted.
is a trademark of General Electric
Company and is used under the
license by Wal-Mart Stores Inc.,
Bentonville, AR 72716
Marketed in Canada by:
Wal-Mart Canada Corp.
1940 Argentia Road, Mississauga,
Ontario L5N1P9
169211-03 (EN).indd 11 6/26/09 12:51:06 PM
