GE Monogram ZV750 User manual

Owner’s
Manual
Stainless Steel
Range Hood with
Recirculating
Accessory
ZV750
ZX758C
ZX7510C
ZV850
ZX858C
ZX859C
ZX8510C

Consumer Information
Stainless Steel Hood
2
Introduction
Your new Monogram stainless steel hood makes an eloquent statement of style, convenience and
kitchen planning flexibility. Whether you chose it for its purity of design, assiduous attention to
detail—or for both of these reasons—you’ll find that your Monogram stainless steel hood’s
superior blend of form and function will delight you for years to come.
Your Monogram stainless steel hood was designed to provide the flexibility to blend in with your
kitchen cabinetry. Its sleek design can be beautifully integrated into the kitchen.
The information on the following pages will help you operate and maintain your stainless steel
hood properly.
Contents
Consumer Information
Important Phone Numbers . . . . . . . . . . . . . . 9
Model and Serial Numbers . . . . . . . . . . . . . . 2
Problem Solver . . . . . . . . . . . . . . . . . . . . . . . . 8
Product Registration . . . . . . . . . . . . . . . . 11, 12
Safety Instructions . . . . . . . . . . . . . . . . . . . . . 4
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls and Features . . . . . . . . . . . . . . . . . . 5
Care and Cleaning
Charcoal Filters . . . . . . . . . . . . . . . . . . . . . . . .6
Light Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Metal Grease Filter . . . . . . . . . . . . . . . . . . . . . 6
Stainless Steel Surfaces . . . . . . . . . . . . . . . . . .7
Before using
your stainless
steel hood
Read this manual carefully. It is intended to help
you operate and maintain your new stainless steel
hood properly.
Keep it handy for answers to your questions.
If you don’t understand something or need
more help, there is a list of toll-free consumer
service numbers included in the back section
of this manual.
OR
Visit our Website at: www.monogram.com
Write down
the model
& serial
numbers
You’ll find them on a label on the hood.
These numbers are also on the Consumer
Product Ownership Registration Card packed
separately with your hood.
Before sending in this card, please write these
numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or
service calls concerning your hood.
If you
received a
damaged
hood
Immediately contact the dealer (or builder)
that sold you the hood.

3
Save time
& money
Before you request service, check the Problem
Solver in the back of this manual.
It lists causes of minor operating problems that
you can correct yourself.
If you need
service
To obtain service, see the Consumer Services
page in the back of this manual.
We’re proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some steps
to follow for further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details—including your phone number—to:
Manager, Customer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
Consumer Information
Stainless Steel Hood

4
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
READ AND SAVE THESE INSTRUCTIONS.
SAFETY PRECAUTIONS
WARNING—TO REDUCE THE
RISK OF FIRE, ELECTRIC SHOCK OR
INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
A. Use this unit only in the manner intended
by the manufacturer. If you have questions,
contact the manufacturer.
B. Before servicing or cleaning unit, switch
power off at service panel and lock the
service disconnecting means to prevent
power from being switched on accidentally.
When the service disconnecting means
cannot be locked, securely fasten a
prominent warning device, such as a tag,
to the service panel.
C. Do not use this unit with any solid-state
speed control device.
D. This unit must be grounded.
CAUTION—FOR GENERAL
VENTILATING USE ONLY. DO NOT USE
TO EXHAUST HAZARDOUS OR EXPLOSIVE
MATERIALS AND VAPORS.
WARNING—TO REDUCE THE
RISK OF INJURY TO PERSONS IN THE
EVENT OF A RANGE TOP GREASE FIRE,
OBSERVE THE FOLLOWING*:
A. SMOTHER FLAMES with a close-fitting lid,
cookie sheet, or metal tray, then turn off
the burner. BE CAREFUL TO PREVENT
BURNS. If the flames do not go out
immediately, EVACUATE AND CALL
THE FIRE DEPARTMENT.
B. NEVER PICK UP A FLAMING PAN—
You may be burned.
C. DO NOT USE WATER, including wet
dishcloths or towels–a violent steam
explosion will result.
D. Use an extinguisher ONLY if:
1. You know you have a Class ABC
extinguisher, and you already know
how to operate it.
2. The fire is small and contained in the
area where it started.
3. The fire department is being called.
4. You can fight the fire with your back
to an exit.
*Based on “Kitchen Firesafety Tips” published
by NFPA.
WARNING—TO REDUCE THE
RISK OF A RANGE TOP GREASE FIRE:
A. Never leave surface units unattended at high
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on
low or medium settings.
B. Always turn hood ON when cooking at high
heat or when flambéing food (i.e. Crepes
Suzette, Cherries Jubilee, Peppercorn Beef
Flambé).
C. Clean ventilating fans frequently. Grease
should not be allowed to accumulate on
fan or filter.
D. Use proper pan size. Always use cookware
appropriate for the size of the surface
element.
WARNING—TO REDUCE THE
RISK OF FIRE, ELECTRIC SHOCK OR
INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
A. Installation work and electrical wiring must
be done by qualified person(s)in accordance
with all applicable codes and standards,
including fire-related construction.
B. Sufficient air is needed for proper
combustion and exhausting of gases
through the flue (chimney) of fuel burning
equipment to prevent back drafting. Follow
the heating equipment manufacturer’s
guideline and safety standards such as those
published by the National Fire Protection
Association (NFPA), and the American
Society for Heating, Refrigeration and
Air Conditioning Engineers (ASHRAE),
and the local code authorities.
C. When cutting or drilling into wall or ceiling,
do not damage electrical wiring and other
hidden utilities.
D. Ducted fans must always be vented to
the outdoors.
WARNING—TO REDUCE
THE RISK OF FIRE, USE ONLY METAL
DUCTWORK.
•Do not attempt to repair or replace any
part of your hood unless it is specifically
recommended in this manual. All other
servicing should be referred to a qualified
technician.

5
FanControls
LightControls
FanControl
Controls and Features
Stainless Steel Hood
Controls
NOTE: Avoid using food products that produce
flames under the range hood.
1ON/OFF. It remembers the last fan speed
used. (Four speed fan.)
2Lowers the speed.
3Increases the speed.
4High speed “instant on.”
5Delayed fan shut-off. Choose 5, 10 or 20
minutes by pushing this button.
6Light ON/OFF. It remembers the last light
level used. (Six light levels.)
7Dims the light.
8Brightens the light.
9Lights after 30 hours of “on” time to remind
you to clean the metal grease filters. The light
blinks until the filters are replaced. If the
lights are blinking and the filters are in,
adjust them in place. Then the timer resets
automatically.
10 Indicates the time the fan is set to run, before
automatically shutting off. (5, 10 or 20 minutes.)
11 Fan indicator.

Care and Cleaning
Stainless Steel Hood
6
For your
safety
Before servicing or cleaning the unit, switch
power off at the service panel and lock the
service panel to prevent power from being
switched on accidentally. If the service panel
cannot be locked, fasten a tag or prominent
warning label to the panel.
Metal
grease
filters
Clean the grease filter after 30 hours of “on”
time. A signal light will alert you when 30 hours
has passed.
Remove the grease filters and wash them
either by hand or in the dishwasher using
non-abrasive soap.
To clean, swish the filters in hot soapy water or
wash them in the dishwasher. Do not use abrasive
cleansers.
Charcoal
filters
(on some models)
NOTE: To remove filters,
push them back and
down using the knob.
Front
For proper operation, be sure to use
the lower set of filter holders.
If the model is not vented to the outside, the air
will be recirculated through disposable charcoal
filters that help remove smoke and odors.
The charcoal filters should be replaced when
they are noticeably dirty or discolored (usually
after 6 to 12 months, depending on hood
usage).
NOTE: DO NOT rinse, or put charcoal filters
in an automatic dishwasher.
The charcoal filters cannot be cleaned.
They must be replaced.
Order Charcoal Filter Kit (3 filters) WB02X10731.
This kit can be ordered from your GE Supplier.
NOTE: To remove the metal filters,
push them back and down using
the knob. Push the charcoal filters
back and down using the tab.
Front
For proper operation, be sure to use
the charcoal filters in the upper set
of filter holders and metal filters in
the lower set of filter holders.
Metal Filters
Charcoal Filters

7
Light bulbs
To change the light bulbs:
1. Remove the trim ring by turning it
counterclockwise.
2. Grasp the bulb on the edges and pull it
straight out.
3. Replace with the same size bulb.
These 12 volt, 20 watt halogen bulbs are
available at specialty lighting stores. Ask for GE
bulb or equivalent: Q20MR16/C/CG40–BAB.
Stainless
steel
surfaces
Do not use a steel-wool pad; it will scratch
the surface.
To clean the stainless steel surface, use a hot,
damp cloth with a mild detergent suitable
for stainless steel surfaces. Use a clean, hot,
damp cloth to remove soap. Dry with a dry,
clean cloth.
If food soil remains, try a general kitchen
cleaner, such as Fantastik® , Simple Green® ,
or Formula 409® .
For hard-to-clean soil, use a standard stainless
steel cleaner, such as Bon-Ami®or Cameo® .
Apply cleaner with a damp sponge. Use a clean,
hot, damp cloth to remove cleaner. Dry with a
dry, clean cloth. Always scrub lightly in the
direction of the grain.
After cleaning, use a stainless steel polish, such
as Stainless Steel Magic® , Revere Copper and
Stainless Steel Cleaner® , or Wenol All Purpose
Metal Polish® . Follow the product instructions
for cleaning the stainless steel surface.
Care and Cleaning
Stainless Steel Hood

8
The Problem Solver
Stainless Steel Hood
Questions?
Use this
problem
solver!
PROBLEM POSSIBLE CAUSE
FAN DOES NOT • A fuse may be blown or a circuit breaker tripped. Replace fuse or
OPERATE WHEN reset circuit breaker.
THE SWITCH IS ON
FAN FAILS TO • Fan blade striking the hood shell.
CIRCULATE AIR • Excessively soiled filter should be checked and corrected before
using the hood again.
FAN OPERATES BUT • Check to be sure the filter is clean. If replacing the filter does not
MOVES AIR SLOWER correct the problem, call for service.
THAN NORMAL
FAN KEEPS GOING • The motor is probably overheating and turning itself off. This can
OFF AND ON be harmful to the motor. Check to be sure the filter is clean. If off
and on cycling continues, call for service.
FAN FILTER LIGHT IS • Filters are not in place or not properly seated. Replace the filters
ON OR IS BLINKING or if the filters are in, adjust them in place.

9
With the purchase of your new Monogram appliance, receive the
assurance that if you ever need information or assistance from GE,
we’ll be there. All you have to do is call—toll- free!
GE Answer
Center
®
800.626.2000
Whatever your question about any Monogram major appliance, GE Answer Center®
information service is available to help. Your call—and your question—will be answered
promptly and courteously. And you can call any time. GE Answer Center®service is open
24 hours a day, 7 days a week.
OR
Visit our Website at: www.monogram.com
In-Home Repair
Service
800.444.1845
A GE consumer service professional will provide expert repair service, scheduled at a time
that’s convenient for you. Many GE Consumer Service company-operated locations offer you
service today or tomorrow, or at your convenience (7:00 a.m. to 7:00 p.m. weekdays, 9:00 a.m.
to 2:00 p.m. Saturdays). Our factory-trained technicians know your appliance inside and out—
so most repairs can be handled in just one visit.
Service Contracts
800.626.2224
You can have the secure feeling that GE Consumer Service will still be there after your
warranty expires. Purchase a GE contract while your warranty is still in effect and you’ll
receive a substantial discount. With a multiple-year contract, you’re assured of future
service at today’s prices.
Parts and
Accessories
800.626.2002
Individuals qualified to service their own appliances can have parts or accessories sent directly
to their home. The GE parts system provides access to over 47,000 parts…and all GE Genuine
Renewal Parts are fully warranted. VISA, MasterCard and Discover cards are accepted.
User maintenance instructions contained in this manual cover procedures intended to be
performed by any user. Other servicing generally should be referred to qualified service
personnel. Caution must be exercised, since improper servicing may cause unsafe operation.
For Customers
With Special
Needs…
800.626.2000
GE offers, free of charge, a brochure to assist in planning a barrier-free
kitchen for persons with limited mobility.
Consumers with impaired hearing or speech who have access to a
TDD or a conventional teletypewriter may call 800.TDD.GEAC
(800.833.4322) to request information or service.
Consumer Services
Stainless Steel Hood

10
YOUR MONOGRAM HOOD WARRANTY
Staple sales slip or cancelled check here. Proof of original
purchase date is needed to obtain service under warranty.
WHAT IS
COVERED
FULL ONE-YEAR WARRANTY
For one year from date of original purchase, we will provide, free of charge, parts and
service labor in your home to repair or replace any part of the hood that fails because
of a manufacturing defect.
This warranty is extended to the original purchaser and any succeeding owner for products
purchased for ordinary home use in the 48 mainland states, Hawaii and Washington, D.C.
In Alaska the warranty is the same except that it is LIMITED because you must pay to ship
the product to the service shop or for the service technician’s travel costs to your home.
All warranty service will be provided by our Factory Service Centers or by our authorized
Customer Care®servicers during normal working hours.
Should your appliance need service, during warranty period or beyond, call 800.444.1845.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights which vary from state to state.
To know what your legal rights are in your state, consult your local or state consumer affairs
office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
WHAT IS NOT
COVERED
• Service trips to your home to teach you how
to use the product.
• Replacement of house fuses or resetting of
circuit breakers.
• Replacement of the replaceable filters.
• Damage to the product caused by accident,
fire, floods or acts of God.
• Failure of the product if it is used for
other than its intended purpose or used
commercially.
• Improper installation.
•If you have an installation problem, contact
your dealer or installer. You are responsible
for providing adequate electrical, gas,
exhausting and other connecting facilities
as described in the Installation Instructions
provided with the product.
• Incidental or consequential damage caused
by possible defects with this appliance.
WARRANTOR IS NOT RESPONSIBLE FOR
CONSEQUENTIAL DAMAGES.
Warranty
Stainless Steel Hood

11
General Electric Company
Warranty Registration Department
P.O. Box 32150
Louisville, KY 40232-2150
Place
1st Class
Letter
Stamp
Here
GE Appliances
Consumer Product
Ownership Registration
Important Mail Today

Important: To ensure that your product is registered, mail the separate product registration card.
If the separate product registration card is missing, fold and mail the form below. No envelope is needed.
Consumer Product Ownership Registration
Product Model Serial
Range Hood
Important
Mail
Today!
First
Name
Apt. #
Street
Address
City
Last
Name
Zip
CodeState
Date Placed
In Use
Month Day Year Phone Number
TAPE CLOSED
FOLD HERE
Mr. Ms. Mrs. Miss 
General Electric Company
Louisville, KY 40225
www.monogram.com
Monogram®
✄ ✄
✄
164D4290P012
49-80043-1
Printed in Italy
01-05 JR
Consumer Product Ownership Registration
Dear Customer:
Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to
have you as a customer!
Follow these three steps to protect your new appliance investment:
1Complete and mail
your Consumer
Product Ownership
Registration today.
Have the peace of mind
of knowing we can
contact you in the
unlikely event of a
safety modification. 2After completing this
registration, write your
model and serial numbers
in this manual. You will
need this information
should you require
service. Our service
number is 800.444.1845. 3Read your Owner’s
Manual carefully.
It will help you
operate your new
appliance properly.
