GE Unitized Spacemaker WSM2420D User guide

GE Appliances
WSM2420/80D – GE®24” Unitized Spacemaker®Washer/Dryer
Specification Created 6/03
Dimensions (in inches)
theewndcnnfnkjtheewndcnnfnkj
theewnd
theewnd
theewnd
theewnd
theewndtheewnd
theewnd
theewndtheewnd
thee
thee
theewnd
theewnd
theewnd
35
35
35theewndcnnfnkj
35
35
35
35
35
35
35
35
35
35
Floor line
Distance from
vent to back 4-1/2
28-5/8
Water
inlet-
cold
1" For leveling legs
32-1/8
27-1/4 23-7/8
27-5/8
71-3/4
32-1/2
23-7/8
27-5/8
27-1/4
38
71-3/4
1-1/2
21-5/16 8
Drain
27-1/2
Electrical Requirements:
WSM2420D:
Electric Dryer –This appliance should be connected to an individual, properly ground-
ed branch circuit with 120/240V single-phase 60Hz electrical service and should be
protected by 30-amp time-delay fuses or circuit breakers. This appliance is
manufactured with the neutral connected to the frame. Power cord should be
purchased separately.
Note: These appliances are not approved for 120-volt operation.
WSM2480D:
Gas Dryer –This appliance should be connected to an individual,
properly grounded branch circuit with a three-prong grounding-type receptacle and
120-volt single-phase 60 Hz electrical service and should be protected by 15- or
20-amp time-delay fuses or circuit breakers. This appliance is equipped with a 6-foot
long flexible U.L. listed 20-amp power cord to match a 15-amp receptacle.
Gas Rated input 10,500 BTU/HR. Factory equipped for natural gas. Tested for LP gas.
Exhaust Information:
Exhausting the dryer to the outside is strongly recommended to prevent large amounts of
moisture and lint from being blown into the room. Closet installations must be exhausted
to the outside.
Installation Information:
For complete information, see installation instructions packed with the product.
Power Cord Location
Back View
Power
Cord Hole
41-1/2''
9-1/2''
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
® GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.

GE Appliances
WSM2420/80D – GE®24” Unitized Spacemaker®Washer/Dryer
Specification Created 6/03
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal exhaust duct. If “all rigid metal” duct cannot be
used, then “flexible all metal” venting can be used, but it will reduce the maximum recommended duct length.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or bottom of dryer, add one turn.
2. The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated is shown in the table. The maximum length
for flexible ducts are less than for rigid duct.
A turn of 45° or less may be ignored. Two 45° turns within the duct length should be treated as a 90° elbow. A turn over 45° should
be treated as a 90° elbow.
Exhausting the dryer to the outside is strongly recommended to prevent large amounts of moisture and lint from being blown
into the room. Gas dryers or any dryer located in a closet must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed house floor (crawl space), or into an attic,
since the accumulated lint could create a fire hazard or moisture could cause damage. Never terminate the exhaust into a common
duct or plenum with a kitchen exhaust, since the combination of lint and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting, etc. The wall cap must also be
located at least 12" above the ground or any other obstruction with the opening pointed down. Other terminations, such as
louvered wall boxes, are acceptable provided they are equivalent to a 4" opening dampered wall cap.
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side
3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52".
• Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq. in. of open area equally distributed.
If this closet contains both a washer and a dryer, doors must contain a minimum of 120 sq. in. of open area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" both sides
3" rear
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
® GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
060 ft. 48 ft. 30 ft. 18 ft.
152 ft. 40 ft. 22 ft. 14 ft.
244 ft. 32 ft. 14 ft. 10 ft.
5.7 Capacity Electric 3 32 ft. 24 ft. — —
and Gas Dryers 4 28 ft. 16 ft. — —
Spacemaker ® Models
DSKS433EB 0 46 ft. 37 ft. 30 ft. 24 ft.
DSKS333EC 1 38 ft. 30 ft. 25 ft. 20 ft.
DSKP333EC 2 31 ft. 22 ft. 20 ft. 14 ft.
WSM2780D 3 24 ft. 15 ft. 16 ft. 10 ft.
056 ft. 42 ft. 30 ft. 22 ft.
146 ft. 36 ft. 22 ft. 14 ft.
Spacemaker Model 2 34 ft. 28 ft. 16 ft. 10 ft.
WSM2700D 3 32 ft. 18 ft. 10 ft. 5 ft.
Spacemaker Models 0 43 ft. 36 ft. 30 ft. 24 ft.
WSM2420D 1 33 ft. 26 ft. 24 ft. 18 ft.
WSM2480D 2 23 ft. 16 ft. 16 ft. 10 ft.
Number
of
90°
Turns
Maximum Length of 4"
Dia. Rigid Metal Duct
Maximum Length of 4"
Dia. Flexible Metal Duct
Exhaust Hood Type Exhaust Hood Type
Domestic
Dryer Models
A
4" Opening
B
2-1/2"
Opening
A
4" Opening
B
2-1/2"
Opening
A
4
Best Performance
B
2-1/2
A

GE Appliances
WSM2420/80D – GE®24” Unitized Spacemaker®Washer/Dryer
Features and Benefits
• Two Wash/Spin speeds – Matches wash action to fabric type for better cleaning and
clothes care.
• Three Wash Cycles – A cycle for almost every fabric, from permanent press to delicates.
• Three Wash/Rinse Temperatures – Allow you to select the right temperature for better wash
results and long fabric life.
• Three Water Levels – Minimize water waste, allowing you to select water level based on
load size.
• Electromechanical Controls – Selector knob turns smoothly in either direction, simplifying
cycle selection.
• Model WSM2420DWW – White on white (Electric)
• Model WSM2420DCC – Bisque on bisque (Electric)
• Model WSM2480DWW – White on white (Gas)
Specification Created 6/03
