GE WSLP1500 Original instructions

ge.com
WSLP1500
WSLS1500
Owner’s Manual &
Installation Instructions
Washers
175D1807P628 49-90361-1 12-08 JR
Safety Information . . . . . . . . . . . 2, 3
Operating Instructions
Control and Indicator Settings . . . . . .5, 6
Loading and Using the Washer . . . .7, 8
Special Washer Features . . . . . . . . . . . .4
Installation Instructions
Alcove or Closet Installation . . . . . . . 12
Electrical Requirements . . . . . . . . . . . 10
Grounding Instructions . . . . . . . . . . . . 10
Installation Requirements . . . . . . . . . . . 9
Leveling the Washer . . . . . . . . . . . . . . 10
Washer Connections for
Portable Model . . . . . . . . . . . . . . . . 13–16
Washer Connections for
Stationary Model . . . . . . . . . . . . . . 11, 12
Troubleshooting Tips
Before You Call For Service . . . . . 17–20
Status Indicators . . . . . . . . . . . . . . . . . . 17
Consumer Support
Consumer Support . . . . . . . Back Cover
Ownership Registration for
Customers in Canada Only . . . . .21, 22
Warranty for Customers
in Canada . . . . . . . . . . . . . . . . . . . . . . . . .24
Warranty for Customers
in the U.S.A. . . . . . . . . . . . . . . . . . . . . . . .23
Write the model and serial
numbers here:
#
#
You can find them on a label
on the back of the washer.
Laveuses
Lavadoras
Manuel d’utilisation
et d’installation
Manual del propietario
e instalación
La section française commence à la page 25
La sección en español empieza en la página 49

2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
■Install or store where it will not be exposed
to temperatures below freezing or exposed
to the weather, which could cause permanent
damage and invalidate the warranty.
■Properly ground washer to conform with all governing
codes and ordinances. Follow details in Installation
Instructions.
WARNING! For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, electric shock, or to prevent property damage, personal injury or
loss of life.
The instructions in this manual and all other literature included with this washer are
not meant to cover every possible condition and situation that may occur. Good, safe
practices and caution MUST be applied when installing, operating and maintaining
any appliance.
WATER HEATER SAFETY
Under certain conditions, hydrogen gas may be produced in a water heater that has not been used for two weeks
or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by
turning on
all hot water faucets and allowing them to run for several minutes. Do this before using any electrical
appliance which is connected to the hot water system. This simple procedure will allow any built-up hydrogen
gas to escape. Since the gas is flammable, do not smoke or use an open flame or appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions before it is used.
■Keep the area underneath and around your
appliances free of combustible materials such as
lint, paper, rags and chemicals.
■Do not leave the washer door open. An open door
could entice children to hang on the door or crawl
inside the washer.
■Close supervision is necessary if this appliance is
used by or near children. Do not allow children to
play on, with or inside this or any other appliance.
YOUR LAUNDRY AREA

3
Consumer Support
Troubleshooting Tips
Operating Instructions
Safety Instructions Installation
Instructions
ge.com
■Never reach into washer while it is moving.
Wait until the machine has completely stopped
before opening the door.
■Do not mix chlorine bleach with ammonia
or acids such as vinegar and/or rust remover.
Mixing different chemicals can produce a toxic
gas which may cause death.
■Do not wash or dry articles that have been
cleaned in, washed in, soaked in or spotted
with combustible or explosive substances (such as
wax, oil, paint, gasoline, degreasers, dry-cleaning
solvents, kerosene, etc.) which may ignite or
explode. Do not add these substances to the
wash water. Do not use or place these substances
around your washer or dryer during operation.
■The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
wash and care instructions.
■To minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the building’s
distribution panel by removing the fuse or
switching off the circuit breaker before attempting
any maintenance or cleaning. NOTE: Pressing the
power button does NOT disconnect the appliance
from the power supply.
■Never attempt to operate this appliance
if it is damaged, malfunctioning, partially
disassembled, or has missing or broken parts,
including a damaged cord or plug.
WHEN USING THE WASHER
■Turn off water faucets to relieve pressure on
hoses and valves and to minimize leakage if
a break or rupture should occur. Check the
condition of the fill hoses; GE recommends
changing the hoses every 5 years.
■Before discarding a washer, or removing it
from service, remove the washer door to prevent
children from hiding inside.
■Do not attempt to repair or replace any part of
this appliance unless specifically recommended
in this Owner’s Manual, or in published user-repair
instructions that you understand and have the
skills to carry out.
■Do not tamper with controls.
WHEN NOT IN USE
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Use this
appliance
only for its
intended
purpose as
described in
this Owner’s
Manual.

4
Special washer features.
Detergent and Fabric Softener Dispenser Drawer
The detergent and fabric softener dispensers
will automatically release their contents at
the proper time during the cycle.
To Use the Detergent Dispenser:
Add measured detergent to the dispenser.
Make sure detergent is spread evenly and
is level.
To Use the Fabric Softener Dispenser:
Use only liquid fabric softener. Pour into
dispenser, using amount recommended
on package.
■Do not fill any higher than the top of the
maximum fill tower.
■Never pour fabric softener directly on
clothes. It may stain them.
Cleaning the Detergent and Fabric Softener Dispenser Drawer
1. Remove the drawer by opening it fully
then tilting the front of the door down.
Pull out.
2. Rinse the drawer with water. If necessary
use a soft cloth to wipe off any debris.
3. Line up the drawer with the opening and
push the dispenser drawer straight in.
Lint Filter
Clean the lint filter inside the wall of
the wash basket once a week for best
filtering results.
To remove:
Press the tab at the top of the filter and
pull out.
To clean:
Open the filter. Clean the filter with
a toothbrush.
Maximum
Fill Tower
Before starting the washer:
•Load the laundry in the washer.
•Add the detergent and fabric softener to the dispenser drawer.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Installation
Instructions Safety Instructions
Operating Instructions

Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation
Instructions
EXTRA LARGE
LARGE
SOAK COLORS
WHITES
DELICATES
SPEED WASH
LOAD SENSING
CUSTOM CYCLE
WASH
RINSE
SPIN
COLD
HOT WARM
LOCK
HOLD 3SECS TO
LOCK/UNLOCK
CONTROLS
MEDIUM
SMALL
EXTRA SMALL
HEAVY DUTY
EST. MINUTES
REMAINING
TEMP
LOAD
OPTIONS
ULTRA
CLEAN
CYCLES
DELAY WASH
1 to 18 HOURS
POWER
START
PAUSE
About the control and indicator settings. ge.com
POWER ON/OFF
Press the POWER ON/OFF button to turn on the control panel.
WASH OPTIONS
Choose the wash options you would like to include in the cycle. Press the WASH OPTIONS button
until all the options you want to include are lit. More than one option can be selected.
2
1
To Use Automatic One-Touch Washing
START
PAUSE
The LOAD SENSING feature automatically senses the size of your load, fills with the appropriate amount
of water, and calculates the amount of wash time required to complete the cycle.
NOTE: When using the LOAD SENSING feature, it is normal for the pulsator to rotate before water fills
in the tub.
To choose the automatic LOAD SENSING feature, press POWER ON/OFF.
The COLORS indicator light will light up automatically unless you have selected one of the other LOAD
SENSING cycles such as WHITES, DELICATES, SPEED WASH, CUSTOM CYCLE or ULTRA CLEAN.
Then simply press START/PAUSE.
To Choose Your Own Cycle Selections
Before starting the washer:
•Load the laundry in the washer.
•Add the detergent and fabric softener to the dispenser drawer.
Soak+Wash Soak+Wash+Heavy Wash+Rinse Wash+Heavy Wash Rinse Wash Rinse Spin
Cycle +Rinse+Spin Duty+Rinse+Spin +Spin Duty+Rinse+Spin +Rinse +Spin Only Only Only
COLORS X X X X X X X X X
WHITES X X X X X X X X X
DELICATES X X X X X X X X X
SPEED X X X X X X X X X
WASH
CUSTOM X X X X X XXXX
CYCLE
ULTRA X
CLEAN
5

6
About the control and indicator settings.
LOAD SIZE
The water level should just cover the clothes. Adjust the load size accordingly. Loosely load
clothes no higher than the top row of holes in the washer basket.
WASH CYCLE
These wash cycles control the length of the washing process. The chart below will help match the
WASH CYCLE setting to your specific laundry needs. When a cycle is selected, the automatic
temperature that the machine defaults to can be changed to whatever temperature you desire.
Default Wash/Rinse Temperatures
COLORS For easy care and wrinkle-resistant items. WARM / COLD
WHITES For heavy to lightly soiled cotton, household HOT / COLD
linens, towels, work and play clothes.
DELICATES For lingerie and delicate fabrics with COLD / COLD
light to normal soils.
SPEED For one or two lightly soiled items WARM / COLD
WASH that are needed quickly.
CUSTOM Manually selected options of water WARM / COLD
temperature, load size, and wash
options saved for future uses.
ULTRA Maximizes detergent efficiency by adding WARM / COLD
CLEAN water in steps and slowly diluting the
detergent to the standard level.
TEMP WASH/RINSE
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s
care label or instructions when laundering.
NOTE FOR PORTABLE MODELS: When using a one-faucet connection, adjust the water flow mix
and water temperature at the faucet.
START/PAUSE
Press the START/PAUSE button to start the wash cycle.
EST. MINUTES REMAINING
Displays the time remaining in the wash cycle. It will also display Status Indicators.
See Troubleshooting Tips.
NOTE: When the cycle is complete the control panel will turn off automatically.
3
4
5
6
7
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Installation
Instructions Safety Instructions
Operating Instructions

7
Consumer Support
Troubleshooting Tips
Operating Instructions
Safety Instructions Installation
Instructions
Loading and using the washer.
Always follow fabric manufacturer’s care label when laundering. ge.com
Sorting Wash Loads
Loading the Washer
Load dry items loosely, no higher than the top row of
holes in the washer tub. When loading wet items
make sure you set the load/water level high enough
to allow the items to move freely. Water level should
just cover the clothes. To add items after washer has
started, open the lid and add the additional items.
Close the lid. Washer will start automatically.
■Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.).
■When the lid is up, a signal will sound and “Lo” will
appear in the display. The washer will not agitate
with the lid up.
Colors
Whites
Lights
Darks
Soil
Heavy
Normal
Light
Fabric
Delicates
Easy Care
Sturdy Cottons
Lint
Lint Producers
Lint Collectors
Care and Cleaning of the Washer
Wash Basket: Leave the lid open after washing to
allow moisture to evaporate. If you want to clean
the basket use a clean, soft cloth dampened with
liquid detergent, then rinse. (Do not use harsh
or gritty cleaners.)
Fill Hoses: Hoses connecting washer to faucet should
be replaced every 5 years.
Exterior: Immediately wipe off any spills. Wipe with
damp cloth. Try not to hit surface with sharp objects.
Moving and Storage: Ask the service technician to
remove water from drain pump and hoses. Do not
store the washer where it will be exposed to the
weather.
Long Vacations: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will
be below freezing.
Proper Use of Detergent
Add detergent and fabric softener before adding
clothes so that the detergent can work effectively.
Using too little or too much detergent is a common
cause of laundry problems.
Use less detergent if you have soft water, a smaller
load or a lightly soiled load.
GE recommends the use of High Efficiency
detergents. HE detergents are formulated
to work with low water wash and rinse systems.
HE detergents reduce the oversudsing problems
commonly associated with regular detergents.

Loading and using the washer.
8
Fabric Care Labels
Machine
wash
cycle Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Hand wash Do not wash Do not wring
Water
temperature Hot
(50°C/120°F)
Warm
(40°C/105°F)
Cold/cool
(30°C/85°F)
Tumble
dry
Dry Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Do not tumble dry
Do not dry
(used with
do not wash)
Heat
setting
High Medium Low No heat/air
Special
instructions Line dry/
hang to dry Drip dry Dry flat In the shade
WASH LABELS
DRY LABELS
Below are fabric care label “symbols” that affect the clothing you will be laundering.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Installation
Instructions Safety Instructions
Operating Instructions

9
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT – Save these instructions
for local inspector’s use.
•IMPORTANT – Observe all governing
codes and ordinances.
•Note to Installer – Be sure to leave these
instructions with the Consumer.
•Note to Consumer – Keep these instructions
for future reference.
•Skill level – Installation of this appliance requires
basic mechanical skills.
•Completion time – 1 hour
•Proper installation is the responsibility of the installer.
•Product failure due to improper installation is not
covered under the Warranty.
•Note – This appliance must be properly grounded,
and electrical service to the washer must conform
with local codes and ordinances and the latest
edition of the National Electrical Code, ANSI/NFPA 70.
Washer must be installed on firm flooring to minimize
vibration during spin cycles. Concrete flooring is best,
but wood base is sufficient providing floor support
meets FHA standards. Washer should not be installed
on rugs or exposed to the weather.
Install or store where it will not be exposed to
temperatures below freezing or exposed to the weather.
WASHER LOCATION
Installation Washers
Instructions WSLP1500 and WSLS1500
•WATER PRESSURE—Must be 10 p.s.i. minimum to 150
p.s.i. maximum dynamic pressure measured at faucet.
•WATER TEMPERATURE—Household water
heater should be set to deliver water at 120° to 150°F
(50° to 66°C) IN THE WASHER when HOT wash is
selected.
•SHUT-OFF VALVES—Both hot and cold shut-off valves
(faucets) should be supplied.
•DRAIN—Water may be drained into a standpipe or set
tub. The discharge height MUST NOT BE LESS THAN
30" nor more than 8' above the base of the washer.
The standpipe must be 11⁄2" minimum inside diameter
and must be open to the atmosphere.
PLUMBING
•Ensure washer is centered between the rack sides.
RACK INSTALLATION
This appliance must be supplied with the voltage and
frequency indicated on the rating plate (located on
the back of the washer) and connected to an individual,
properly grounded branch circuit, protected by a 15- or
20-amp circuit breaker or time-delay fuse.
If the washer is plugged into the dryer’s 115-volt outlet,
then the dryer needs to be on a dedicated circuit.
ELECTRICAL
Pliers
TOOLS REQUIRED
Water Hoses (2)
PARTS SUPPLIED
Drain Hose
Rubber Washers (4)
If you have any questions, call 800.GE.CARES (800.432.2737) or visit our Website at: ge.com
In Canada, call 1.800.561.3344 or visit GEAppliances.ca

10
CAUTION: For personal safety, do
not use an extension cord or adapter plug with this
appliance.
Do not, under any circumstances, cut or remove the
third grounding prong from the power cord. Follow
National Electrical Codes or prevailing local codes
and ordinances.
This appliance must be supplied with the voltage and
frequency indicated on the rating plate (located on the
back of the washer) and connected to an individual,
properly grounded branch circuit, protected by a
15- or 20-amp circuit breaker or time-delay fuse.
If the electric supply provided does not meet the above
requirements, call a licensed electrician.
ELECTRICAL REQUIREMENTS
Installation Instructions
This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of electric shock by providing a path of least
resistance for electrical current.
This appliance is equipped with a cord having an
equipment grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet that
is properly installed and grounded in accordance with all
local codes and ordinances.
DANGER: Improper connection of the
equipment-grounding conductor can result in a risk of
electrical shock. Check with a qualified electrician if you
are in doubt as to whether the appliance is properly
grounded.
Do not modify plug with this appliance; if it will not fit
the outlet installed, have a proper outlet installed by
a qualified electrician.
Insure proper ground
exists before use
CAUTION: Before plugging in washer, read the following electrical requirements.
GROUNDING INSTRUCTIONS
Before connecting the hoses, the washer must be level.
Leveling locks are located at the bottom front of the left
and right sides of the washer.
LEVELING THE WASHER—
STATIONARY MODELS
MAKE SURE THE WASHER IS IN ITS
FINAL LOCATION
1
PULL OUT THE LEVELING LOCKS
2
This releases the spring loaded leveling feet.
The washer will automatically level itself.
PUSH THE LEVELING LOCKS BACK IN
3
Do not kick or step on the leveling locks.

11
Cable Tie
Cable Tie
Cable Tie
Laundry Tub
Stand Pipe
WARNING :Make sure the washer is unplugged.
Run some water from the hot and cold faucets to flush
the water lines and remove particles that might clog up
the water valve screens.
FLUSH WATER LINES
1
Installation Instructions
WASHER CONNECTIONS FOR STATIONARY MODEL WSLS1500
Connect the inlet hose ends to the HOT and COLD water
faucets tightly by hand, then tighten another 2⁄3turn with
pliers. Turn the water on and check for leaks.
CONNECT TO WATER LINES
2
CAREFULLY MOVE THE WASHER TO
ITS FINAL LOCATION
3
Form a U shape on the end of the drain hose with
the hose pointed toward the drain. Place the hose in
a laundry tub or stand pipe and secure it with a cable
tie (not included).
NOTE: If the drain hose is placed in a stand pipe without
forming a U shape, a siphoning action could occur. There
must be an air gap around the drain hose. A snug hose
fit can also cause a siphoning action.
CONNECT DRAIN HOSE
4
PLUG THE POWER CORD INTO A
GROUNDED OUTLET
5
Insure proper ground
exists before use

ALCOVE OR CLOSET INSTALLATION
12
60 sq. in.
(387.1 sq. cm)
60 sq. in.
(387.1 sq. cm)
Closet door
Installation Instructions
WASHER CONNECTIONS FOR STATIONARY MODEL WSLS1500
RUN THE WASHER THROUGH A
COMPLETE CYCLE
7
Check for water leaks and proper operation.
REMOVE THE PROTECTIVE FILM
COVERING THE CONTROL PANEL
8
It contains valuable and helpful information that will save
you time and money.
READ THE REST OF THIS OWNER’S
MANUAL
9
NOTE: If your washer does not operate, please review
the Before You Call For Service section.
If your washer is approved for installation in an alcove or
closet, there will be a label on the back of the machine
describing requirements.
•Minimum clearances between washer and adjacent
walls or other surfaces are: 0" either side, 2" front,
3" rear.
•Minimum vertical space from floor to overhead
shelves, cabinets, ceilings, etc. is 96".
•Closet doors must be louvered or otherwise ventilated
and have at least 60 square inches open area for
washer only, or if the closet contains both a washer
and dryer, doors must contain at least 120 square
inches of open area equally distributed.
NOTE: The clearances stated on this label are minimums.
Consideration must be given to providing adequate
clearances for installation and servicing.
INSTALLATION CHECKLIST
6
Before starting the washer, check to make sure:
❏ Main power is turned on.
❏ The washer is plugged in.
❏ The water faucets are turned on.
❏ The unit is level.
❏ The drain hose is properly tied up.
❏ There are no leaks at the faucet, drain line
or washer.

13
Hose Connector
Locking Collar
Uni-Coupler Hose
Faucet Connector
Drain Connection
COLD Water
Supply Connector
Water Filter
Installation Instructions
WASHER CONNECTIONS FOR PORTABLE MODEL WSLP1500—
ONE-FAUCET CONNECTIONS
REMOVE THE UNI-COUPLE®HOSE
FROM INSIDE THE WASHER BASKET
1
CONNECT TO WATER LINE
2
Use the hose connector provided with the washer for a
one-faucet connection.
TO CONNECT THE WASHER:
Attach the hose connector to the faucet adapter by
pulling down on the locking collar while lifting up on
the connector until it snaps into place. Make sure the
water filter provided is in place.
CONNECT TO VALVE INLET
3
Attach the COLD water supply connector to the COLD
water valve inlet (color BLUE). Make sure the washer is
inside the connector before tightening.
TIGHTEN CONNECTOR
4
Tighten the connector, ensuring the threads are
aligned properly for tightest fit. Inspect for kinks
or binding of the hose.
NOTE: Do not remove the plastic cap from the HOT
water inlet for uni-coupler connections as leakage may
occur.
Plastic Cap
CONNECT DRAIN HOSE
5
Attach the drain hose to the rear of the washer. Install
the clamp on the drain hose and tighten to prevent
leakage of water.

14
Installation Instructions
WASHER CONNECTIONS FOR PORTABLE MODEL WSLP1500—
ONE-FAUCET CONNECTIONS (CONT.)
MAKE SURE THE TEMPERATURE
SELECTOR IS SET AT COLD/COLD
6
SLOWLY TURN ON THE WATER
FAUCET ALL THE WAY TO THE
DESIRED TEMPERATURE SETTING
7
PLUG THE POWER CORD INTO A
3-PRONG GROUNDED OUTLET
8
Insure proper ground
exists before use
The electrical power cord is on the back of the washer.
REMOVE THE PROTECTIVE FILM
COVERING THE CONTROL PANEL
9
INSTALLATION CHECKLIST
10
Before starting the washer, check to make sure:
❏ Main power is turned on.
❏ The washer is plugged in.
❏ The water faucets are turned on.
❏ The unit is level.
❏ There are no leaks at the faucet, drain line
or washer.

TO DISCONNECT THE WASHER:
15
Hose Connector
Water Flow
Button
TURN WATER FAUCET OFF
1
UNPLUG POWER CORD AND RETURN
IT TO THE STORAGE AREA
2
PRESS THE RED WATER FLOW
BUTTON TO RELEASE THE WATER
PRESSURE
3
DISCONNECT FROM WATER LINE
4
Installation Instructions
Hose Connector
Locking Collar
Move the locking collar down and pull the hose
connector down to disengage from the faucet
adapter.
DRAIN WATER
5
Drain water from the hoses through the
hose connector.

16
TO DISCONNECT THE WASHER:
TO CONNECT THE WASHER:
If you have two separate water connections, your washer
can be connected to both the hot and cold water faucets.
This kit can be purchased from your dealer or from Parts
and Accessories. In the United States, call 800.626.2002.
In Canada, consult the yellow pages for your local Camco
number.
WASHER CONNECTIONS FOR PORTABLE MODEL WSLP1500—
TWO-FAUCET CONNECTIONS
CONNECT TO WATER LINE
1
Connect HOT and COLD water inlet hoses to the HOT
and COLD faucets.
Cable
Tie
Cable
Tie
Sink Stand Pipe
Secure the drain hose to the sink or stand pipe.
CONNECT DRAIN HOSE
2
PLUG THE POWER CORD INTO A
3-PRONG GROUNDED OUTLET
3
Insure proper ground
exists before use
TURN WATER FAUCETS OFF
1
UNPLUG POWER CORD AND RETURN
IT TO THE STORAGE AREA
2
DISCONNECT THE DRAIN AND WATER
SUPPLY HOSES
3
Hang them on the storage rack.
Installation Instructions
INSTALLATION CHECKLIST
4
Before starting the washer, check to make sure:
❏ Main power is turned on.
❏ The washer is plugged in.
❏ The water faucets are turned on.
❏ The unit is level.
❏ The drain hose is properly tied up.
❏ There are no leaks at the faucet, drain line
or washer.

17
Consumer SupportTroubleshooting Tips
Operating Instructions
Safety Instructions Installation
Instructions
Before you call for service… ge.com
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
FF
■Indicates washer failed to fill. Ensure wall faucets are on and fill hose is
not clogged or kinked.
dr
■Indicates water has not drained from washer. Ensure the drain hose is
not kinked or connected improperly.
Ub
■Indicates the laundry load is unbalanced. Reposition laundry evenly in
basket, and ensure washer is level.
Lo
■Indicates the lid is open. Close the lid.
Status Indicators
LE
■Indicates washer has leakage. Check the drain hose connection.
IE
■Press POWER ON/OFF and call service.
OE
■Indicates water has overflowed. Restart after spinning.

18
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips Installation
Instructions Safety Instructions
Operating Instructions
Troubleshooting Tips Installation
Instructions Safety Instructions
Operating Instructions
Before you call for service…
Troubleshooting Tips
WATER POSSIBLE CAUSES WHAT TO DO
Too many suds Type of detergent •Switch to HE detergent.
Very soft water •Try less detergent.
Too much detergent •Measure your detergent carefully. Use less soap if you
have soft water, a smaller load or a lightly soiled load.
Water leaks Fill hoses or drain hose is •Make sure hose connections are tight at faucets and the
improperly connected washing machine. Make sure the end of the drain
hose
is correctly inserted and secured to the drain.
Household drain may •Check household plumbing. You may need to call
be clogged a plumber.
Constant water pressure •Tighten hoses at the faucets and turn the water off
to the fill hoses at the after each use.
water source •Check condition of the fill hoses; they may need
replacement after 5 years.
Using too much detergent •Use less detergent. Use less soap if you have soft water,
in washer a smaller load or a lightly soiled load.
Water temperature Water supply is turned off •Turn both hot and cold faucets fully on and make sure
is incorrect or improperly connected hoses are connected to correct faucets.
Water valve screens are • Turn off the water source and remove the water
stopped up connection hoses from the upper back of the washer.
Remove screens and use a brush or toothpick to clean the
screens in the machine. Reinstall screens, reconnect the
hoses and turn the water back on.
House water heater is •Make sure house water heater is delivering water
not set properly at 120°F–140°F (48°C–60°C).
Water won’t drain Drain hose is kinked or •Straighten drain hose and make sure washer is not
improperly connected sitting on it.
•Top of drain outlet should be less than 8 ft. above floor.

19
Consumer SupportTroubleshooting Tips
Operating Instructions
Safety Instructions Installation
Instructions
ge.com
OPERATION POSSIBLE CAUSES WHAT TO DO
Washer pauses in cycle The washer normally pauses
between washing steps
Washer won’t operate Washer is unplugged •Make sure cord is plugged securely into a working outlet.
Water supply is turned off •Turn both hot and cold faucets fully on.
Controls are not set properly •Make sure all selections have been made.
Lid is open •Close lid and press START/PAUSE.
Circuit breaker/fuse is •Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have separate outlet.
Washer has not been •Press the POWER ON/OFF button.
turned on
PERFORMANCE POSSIBLE CAUSES WHAT TO DO
Colored spots Incorrect use of fabric •Check fabric softener package for instructions and
softener follow directions for using dispenser.
•Pretreat stain and rewash.
Dye transfer •Sort whites or lightly colored items from dark colors.
Grayed or yellowed Not enough detergent •Use more detergent (especially with larger loads).
clothes Hard water •Use a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough •Make sure water heater is delivering water at
120°F–140°F (48°C–60°C).
Washer is overloaded •Select load size to match clothes load.
Dye transfer •Sort clothes by color. If fabric label states wash separately,
unstable dyes may be indicated.
Lint or residue on Clothes are air or line dried •If you do not dry your clothes with a clothes dryer,
clothes your clothes may retain more lint.
Incorrect sorting •Separate lint producers from lint collectors.
Washing too long •Wash small loads for a shorter time than larger loads.
Overloading •Load clothes no higher than the top row of holes in the
washer tub.
•Make sure load size selector matches clothes load size.
Incorrect use of fabric softener •Check fabric softener package for instructions and
follow directions for using dispenser.
Pilling Result of normal wear on •While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics

20
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips Installation
Instructions
Troubleshooting Tips Installation
Instructions
Before you call for service…
PERFORMANCE (cont.) POSSIBLE CAUSES WHAT TO DO
Snags, holes, tears, rips Pins, snaps, hooks, sharp •Fasten snaps, hooks, buttons and zippers.
or excessive wear buttons, belt buckles, •Remove loose items like pins, objects in pockets
zippers, and sharp objects and sharp buttons.
left in pockets
•Turn knits (which snag easily) inside out.
Undiluted chlorine bleach •Check bleach package instructions for proper amount.
•Never add undiluted bleach to wash or allow clothes
to come in contact with undiluted bleach.
Chemicals like hair bleach •Rinse items that may have chemicals on them before
or dye, permanent wave washing.
solution
Wrinkling Improper sorting •Avoid mixing heavy items (like work clothes) with
light items (like blouses).
•Try a fabric softener.
Overloading or •Load your washer so clothes have enough room
incorrect water level to move freely.
Repeated washing in •Wash in warm or cold water.
water that is too hot
NOISE POSSIBLE CAUSES WHAT TO DO
Washer is noisy Washer is uneven •Level the washer. See Leveling the Washer.
Washer load is
•Press the START/PAUSE button to stop the washer, open
unbalanced the lid and redistribute the load evenly. Close the lid
and restart.
Washer is sitting too close •Pull washer away from the wall; about 4" is needed.
to wall (causes knocking
during cycle)
Dragging noise prior When using the LOAD •This is normal.
to water filling in SENSING feature, the
the tub agitator rotates before
water fills in the tub
OTHER POSSIBLE CAUSES WHAT TO DO
Labels on the exterior Occasionally the adhesive •Use a hair dryer set at the lowest heat setting, directing
of the washer will not used on the labels does the air at the label for a short amount of time. This will
peel off cleanly not release cleanly release the adhesive easily, without damaging the surface
of the washer.
Troubleshooting Tips
