GE GNUT03B Safety guide

GNUT03B
GXUT03B
GE Appliances
Water Filtration System
Part No. 215C1044P002–1 Pub. No. 49-50006–2 3-99 CG (JR)
7205677
Owner’s Manual
and Installation
Faucet
GNUT03B and GXUT03B are
Tested and Certified by NSF
International against ANSI/NSF
Standard 42 for Particulate
Reduction Class I, Chlorine
Reduction Class Iand Taste
and Odor Reduction.

Congratulations!
You are Now Part of the GE Family.
Safety Information . . . . . . . . . . . 3
Operating Instructions . . . .4–7
Specification Guidelines . . . . . . . . . . . . .4
Using the System . . . . . . . . . . . . . . . . . .5
Filter Cartridge Replacement . . . . . . . . . .5
Flush Procedure . . . . . . . . . . . . . . . . . . . .6
Installation Instructions . .7–11
Important Recommendations . . . . . . . . . .7
Tools/Materials Required . . . . . . . . . . . .7
Step-by-Step Instructions . . . . . . . . .8–11
Feed Water Supply . . . . . . . . . . . . . . . .8
Faucet Installation . . . . . . . . . . . . . . . . .9
Wall Mounting . . . . . . . . . . . . . . . . . . .10
Tubing Connection . . . . . . . . . . . . . . . .10
Filter Cartridge Replacement . . . . .10, 11
Troubleshooting Tips
Before You Call For Service . . . . . . . . . . .12
Customer Service
Product Registration . . . . . . . . . . . . .13, 14
Parts List . . . . . . . . . . . . . . . . . . . . . .15, 16
Warranty . . . . . . . . . . . . . . . . . . . . . . . . .19
Service Telephone
Numbers . . . . . . . . . . . . . . . . . . . . . . . . .20
2
Welcome to the GE family. We’re proud of our quality products and we are
committed to providing dependable service. You’ll see it in this easy-to-use Owner’s
Manual and you’ll hear it in the friendly voices of our customer service department.
Best of all, you’ll experience these values each time you use the Water Filtration
system. That’s important, because your new system will be part of your family for
many years. And we hope you will be part of ours for a long time to come.
We thank you for buying GE. We appreciate your purchase, and hope you will
continue to rely on us whenever you need quality appliances for your home.
FOR YOUR RECORDS
Write the model and serial numbers here:
#
#
You can find them on the sump bracket.
Staple sales slip or cancelled check here.
Proof of the original purchase date is needed to obtain service under
the warranty.
IMPORTANT!
Fill out and return the Consumer Product Registration Card that is
packed with this product. If you cannot find it, please send in the
duplicate card printed in the back of this manual.
Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
Inside you will find many helpful hints on how to use and maintain
your water system properly. Just a little preventive care on your part
can save you a great deal of time and money over the life of your
system.
READ THIS MANUAL
IF YOU NEED SERVICE
You’ll find many answers to common problems in the Before You Call
For Service section. If you review our chart of Troubleshooting Tips first,
you may not need to call for service at all.
If you do need service, you can relax knowing help is only a phone
call away. A list of toll-free customer service numbers is included in
the back section.

SAVE THESE INSTRUCTIONS
Read and follow this Safety Information carefully.
■ Install or store where it will not be exposed to
temperatures below freezing or exposed to any
type of weather. Water freezing in the system
will damage it. Do not attempt to treat water
over 100°F.
WARNING: Discard all unused and packaging
material after installation. Small parts remaining
after installation could be a choke hazard.
■ Your Water Filtration system will withstand up to
125 pounds per square inch (psi) water pressure.
If your house water supply pressure is higher than
100 psi, install a pressure reducing valve before
installing the Water Filtration system.
3
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING! For your safety, the information in this manual must be followed to minimize the risk of
property damage or personal injury.
SAFETY PRECAUTIONS
■ Check with your local public works department
for plumbing codes. You must follow these
guidelines as you install the Water Filtration
system.
■Use the Water Filtration system on a potable,
safe-to-drink, home COLD water supply only.
The filter cartridges will not purify the water,
or make it safe to drink.
■ Do not use on a hot water supply (100°F. max.) .
WARNING: Do not use with water that is
microbiologically unsafe or of unknown quality
without adequate disinfection before or after
the system. Systems certified for cyst reduction
may be used on disinfected water that may contain
filterable cysts.
PROPER INSTALLATION
This Water Filtration system must be properly installed and located in accordance with the Installation
Instructions before it is used.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions

4
Specification guidelines.
Many bad tastes and/or odors are removed
from water using activated carbon filter
cartridges. They are most often used to
remove a chlorine taste and odor. They can
also reduce other undesirable elements
from drinking water supplies, such as
organic chemical contaminants and lead.
NOTE: Small amounts of hydrogen sulfide
(noticeable as “rotten egg” odor) may be
reduced by taste and odor filters for a short
time, but the carbon media is quickly
exhausted. Other water conditioning
equipment is usually required for the
continuous treatment of hydrogen sulfide.
About the water filtration system.
Filter I FXUSB—
a sediment filter cartridge
•Reduces dirt, rust and sediment
Filter II FXUTB—
a taste and odor filter cartridge
•6000 gallons
•Reduces unpleasant tastes and odors
•Reduces 99.5% chlorine
•1 micron, carbon block
Minimum - Maximum Supply Water Pressure — 40–125 pounds per square inch (psi)
Minimum - Maximum Supply Water Temperature — 40–100°F.
Inlet - Outlet — 3/8 ″ NPT, fittings and tubing included
Maximum Filtered Water Flow — 0.6 gpm
Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
Using the Water Filtration System and About the Filter Cartridge
The countertop faucet dispenses filtered
drinking water when opened. It has a hand-
operated, spring-loaded closed lever to
prevent waste. You can keep the faucet
open by pushing upward on the lever to
lock it against the faucet spout.
Filter Cartridge Life— Several variables
determine how long the cartridges
will last in your Water Filtration system.
These include:
How much water you use.
How much sediment, taste and/or odor, lead,
or other unwanted substance, is in the
water.
No matter which Water Filtration system
you have, you should replace the cartridges
every six months.
Apply the Filter Replacement Reminder Label to
one of the filter sumps between the ribs. Mark
the date for filter replacement six months from
the installation date.
In extremely poor water supplies, you
may notice the return of the unwanted
substance in your water before the six
months are up. In this case the cartridges
should be replaced immediately.
NOTE: If the water supply contains high
amounts of sediments, the carbon filters
may plug with them, reducing filtered
water flow to the system faucet. Cartridge
replacement is needed to restore flow.
2
1
Filter Replacement
Reminder Label
Filtered water faucet
Open
Lock
open
The Water Filtration system uses two filter cartridges.

Customer ServiceTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
Filter Cartridge Replacement
CAUTION: Never remove the sumps when water pressure is in the Water Filtration system.
Close the water supply/saddle valve to the filter. (See Fig. 1 in the Installation Overview section
for location of the saddle valve.) Open the filtered water faucet.
Remove the sump, using the sump wrench tool provided, from the filter head by rotating the
sump as shown in the below illustration. Be careful, the sump may be full of water. Be sure to
keep the large o-ring seal.
If you are replacing a filter cartridge, remove and discard the used filter cartridge.
Be sure the inside of the sump is clean. Thoroughly wash the inside of the sump with hot,
soapy water and rinse.
Remove the wrapper from the new filter cartridge and insert the filter cartridge in the sump.
Some cartridges fit either way, while others fit only one way. Observe markings on the
cartridge.
NOTE: The Water Filtration system uses two different types of filter cartridges. Be sure to
install them correctly.
The sediment (FXUSB) filter cartridge should always be placed in the Filter I sump.
Lightly lubricate the o-ring seal in the sump with clean silicone grease. Be sure it is fully
seated in its groove.
Hold the sump up to the filter head, aligning the center hole in the cartridge with the
protrusion on the bottom of the head.
Being careful not to cross-thread, rotate the sump onto the filter head and tighten securely
by hand.
NOTE: If the sump will not tighten up to the head, you may have the cartridge in upside
down. Take the cartridge out and check for correct orientation.
Repeat steps 2 through 8 for the taste/odor (FXUTB) filter cartridge in the Filter II sump.
Turn on the filtered water faucet. Then, slowly open the water supply/saddle valve and allow
the filter housing to fill.
Close the filtered water faucet. Then, check for leaks between the sump and the head.
NOTE: If leaking, turn off the water supply and turn on the filtered water faucet. Disassemble
the filter and check the o-ring for cuts, flat spots, etc., and sealing surfaces for foreign
material. Clean the o-ring and lightly lubricate with clean silicone grease. Carefully press
into the groove in the sump.
The filter cartridges contain activated carbon. When new, turn on the filtered water faucet
for ten minutes to flush the system.
12
11
10
9
8
7
6
5
4
3
2
1
Filter I
Filter II
O-ring seal
Cartridge
Sump
Sump
Sump
Label
TURN SUMP
TO INSTALL
TURN SUMP
TO REMOVE
Head
Bracket
Turn sump wrench tool
provided clockwise
5

6
About the water filtration system.
Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
Flush Procedure
Whenever water of unknown quality is passed through the Water Filtration system, filter
elements should be discarded and the filtration system flushed.
Circumstances that may require flushing the system are:
■Boil-water advisory.
■Flooding of the Water Filtration system.
■Long-term non-use.
The procedure for flushing the Water Filtration system is:
See Filter Cartridge Replacement section and follow steps 1 through 4.
Next, reinstall the sumps (without the filter elements), turn water on, and flush water
through the faucet for one minute.
Then, turn water off, remove sumps, empty water out of sumps and install new filter
elements.
Follow steps 6 through 9 in the Filter Cartridge Replacement section to complete.
4
3
2
1

Installation Overview
7
Installation Instructions.
Customer Service
Troubleshooting Tips
Operating InstructionsSafety Instructions Installation Instructions
Important Installation Recommendations
Read entire manual. Failure to follow all guides and rules could cause personal injury or property damage.
■ Check with your local public works department for plumbing codes. You must follow their guides as you install
the Water Filtration system.
■ Use the Water Filtration system on a potable, safe-to-drink, home COLD water supply only. The filter cartridges will
not purify water or make unsafe water safe to drink. DO NOT use on HOT water (100° F. max.).
■ Protect the Water Filtration system and piping from freezing. Water freezing in the system will damage it.
■ Your Water Filtration system will withstand up to 125 psi water pressure. If your house water supply pressure is
higher than 100 psi during the day (it may reach higher levels at night), install a pressure reducing valve before
the system.
WARNING: Do not use with water that is microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system. The water should be tested periodically to verify that the system is
performing satisfactorily. Small parts remaining after the installation could be a choke hazard. Discard safely.
■Slotted and Phillips screwdrivers
■Pliers and adjustable jaw wrench
■Hand or battery powered drill and 1 ⁄ 4 ″bit
(saddle valve installation)
■Electric drill and drill bit to drill 1″−1-1⁄4″hole
(type as required) if mounting hole is needed for
faucet
CAUTION: To avoid damaging the sink, consult
a qualified plumber or installer for drilling
procedures. Special drill bits may be needed
for porcelain or stainless steel.
Contents included with the product:
■Water filter assembly, including mounting bracket
and screws
■Product Literature (Owner’s Manual and
Installation, Product Data Sheet, Owner Product
Registration Card)
■Water supply/saddle valve
■Filtered water faucet, for sink or countertop
mounting
■3 ⁄ 8″tubing and fittings to make all needed
connections
■Sump wrench
Fig. 1
Filtered
water faucet
Sink
Hot
Shutoff valve
NOTE:To change the filter cartridge, you
must turn off the water. A nearby shutoff
valve is convenient. Most sinks already have
shutoff valves on the supply pipes.
Cold
Water supply/saddle valve
Washer
Adapter
Nut
Water
in
Water
out
Tubing
Insert
Mounting
screw (2)
Filter I
Filter II
Nut
Tubing
1-1/2″to 2″
Locate the drinking water
system on the cold water
supply pipe, under the
kitchen and/or bathroom
sink, to filter the cold
drinking water.
Tools and Materials Required for Installation

8
Step-by-step installation instructions.
Feed Water Supply
Check and comply with local plumbing codes as you plan, then install a cold feed water supply fitting. For new
home installation using standard plumbing fittings, see Fig. 2A below. A typical installation for existing
homes using the saddle valve is shown in Fig. 2B below.
A. PREFERRED INSTALLATION
B. OPTIONAL INSTALLATION Where codes permit
NOTE: Codes in the state of Massachusetts require installation by a licensed plumber and do not
permit the use of the saddle valve. For installation, use plumbing code 248-CMR of the Commonwealth
of Massachusetts.
Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
Turn off the cold water supply
and attach saddle valve as
shown in Fig. 2B.
DANGER: To protect yourself
from serious injury or fatal
shock, use a battery powered
hand drill only to make the
hole. DO NOT USE AN
ELECTRIC DRILL.
Close the water supply valve by
turning the handle clockwise.
Open the main water supply
valve and several house
faucets to purge air from the
system. Close faucets when
water runs smoothly.
321
Turn off the cold water supply. Complying with plumbing codes, install a
fitting on the cold water pipe to adapt 3 ⁄ 8 ″OD
tubing. A typical connection is shown in Fig. 2A
(parts not included). Make sure a water supply
valve is used.
21
Fig. 2A.
Preferred water supply connection
(using compression fitting)
Insert
Cold
water
pipe 3⁄8″tubing to inlet
Ferrule
Water supply valve
Typical location
Cold
water
Optional water supply connection (using saddle valve)
Pre-drill
1⁄4″hole Seal—make sure the
seal is in place
Clamp X
Nut (2)—not required if
holes in clamp are threaded
Valve
Handle
Tubing adapter
Washer
Compression nut
❵
Clamp Z
Fig. 2B.
Use to connect the tubing

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
Faucet Installation
Be sure there is room underneath the sink to
make the needed connections. Select one of the
following places to install the faucet:
—IN an existing sink spray attachment or soap
dispenser hole.
—IN a hole to be drilled in the sink top.
—IN a hole to be drilled in the countertop, next
to the sink.
NOTE: Looking at Fig. 3B, be sure the faucet base
will fit flat against the surface at the selected
location so the gasket will seal.
If drilling is needed, make a 1″–1-1 ⁄ 4 ″dia.
hole. Be sure to use the proper procedure for
drilling porcelain or stainless steel. Special
drill bits may be needed.
Place small gasket, base and large gasket (in
that order) on to the faucet stem. Next, place
lock washer and hex nut onto faucet stud.
Insert washer into tubing adapter. Securely
tighten to faucet stud.
Feed the length of 3 ⁄ 8 ″OD tube from the
bottom, up through the mounting hole.
Connect to the tubing adapter as shown in
Fig. 3B, tightening the compression nut
securely.
Remove the short shipping tube and insert
the spout into the faucet body. Rotate spout
into place.
Lower the faucet assembly into place. Place
the mounting bracket above the lock washer.
While holding the mounting bracket in
place, securely tighten the hex nut.
6
5
4
3
2
1
Fig. 3A. Fig. 3B.
Sink
Base
Lock washer
Faucet
Lever
Spout
Faucet
stud
Small gasket
Large gasket
Compression nut
Tubing adaptor
Mounting bracket
Hex nut
Plastic washer
3/8″tubing, (run
to
Filter II outlet)
Compression nut
9
ASSEMBLED

10
Step-by-step installation instructions.
Filter Cartridge Installation or Replacement
Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
Mounting Bracket to Cabinet Wall
The bracket can be used as a template for marking the location of the mounting screws. When determining the
location of the bracket make sure you leave 1-1 ⁄ 2 ″ to 2″ of free area under the sumps to allow for sump removal and
enough space on either side to make the tubing connections.
Make Tubing Connections
Run the length of 3⁄8″tubing, connected to the bottom of faucet, to the filter system outlet, Fig.1 in the
Installation Overview section. Allow enough slack in the tubing to be able to place the system on the floor in front
of the sink. Measure and cut the end of the tubing square.
Slide a compression nut onto the end of the tubing and push a tubing insert into the tubing.
Connect the tubing and tighten the compression nuts securely.
Repeat the preceding steps to connect a length of tubing between the filter system inlet and the water
supply/saddle valve, Fig. 1 in the Installation Overview section.
4
3
2
1
CAUTION: Never remove sumps with water pressure in the Water Filtration system.
Close the water supply/saddle valve (Fig. 1 and 2A) to the filter. Open the filtered water faucet.
Turn the sump off of the filter head as shown (use the sump wrench provided). Be careful, the sump
is full of water. Locate and save the large o-ring seal. Remove and discard the used filter cartridge.
Be sure the inside of the sump is clean. Thoroughly wash with hot, soapy water and rinse.
Remove the wrapper and labels from the new filter cartridge and insert the filter cartridge in the sump. Some
cartridges fit either way, while others fit only one way. Observe markings on the end of the cartridge. The sediment
(FXUSB) filter cartridge should always be placed in the Filter I sump.
Lightly lubricate the o-ring seal, in the sump, with clean silicone grease. Be sure it is fully seated in its groove.
Hold the sump up to the filter head, aligning the center hole in the cartridge with the protrusion on the bottom
of the head.
NOTE: If the sump will not tighten up to the head, you may have the cartridge in upside down. Take the cartridge
out and check the markings on the end of the cartridge for correct orientation.
Being careful not to cross-thread, turn the sump onto the filter head and hand tighten securely (see Fig. 5).
CAUTION: If using the sump wrench to tighten the sump, do not overtighten.
7
6
5
4
3
2
1
Fig. 4
Filter I
Filter II
Sump
Mounting
screws
Tubing
connector
Tubing
connector
Mounting
bracket
Sump
7-9⁄16″
1-1⁄2″to 2″

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
Repeat steps 2 through 7 for the taste/odor (FXUTB) filter cartridge in the Filter II sump
Open the filtered water faucet. Then, slowly open the water supply/saddle valve and allow the filter
housing to fill.
Close the filtered water faucet. Then, check for leaks between the sump and the head.
NOTE: If leaking, turn off the water supply and open the filtered water faucet. Then, disassemble the
filter and check the o-ring for cuts, flat spots, etc., and sealing surfaces for foreign material. Clean the o-
ring and lubricate with clean silicone grease. Carefully press into the groove in the sump.
The filter cartridges contain activated carbon. When new, open the filtered water faucet for ten minutes
to flush the system.
11
10
9
8
Fig. 5
Filter I
O-ring seal
Cartridge
Sump
Sump
Replacement label
TURN SUMP
TO INSTALL
TURN SUMP
TO REMOVE
Head
Bracket
Sump
wrench
To
loosen
11
Filter II

12
Before you call for service…
Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
Problem Possible Causes What To Do
Water contains tiny New filter cartridges contain •Turn on the filtered water faucet and allow these
black particles activated carbon, which is a harmless carbon particles to purge from the cartridge.
harmless black powder. Turn off the faucet when the water is clear.
Water has air bubbles Air in system after installation. •Will go away after water runs for a while.
and is cloudy
Chlorine taste and /or The filter cartridges are no • Replace both filter cartridges.
odor in the product water longer removing chlorine
from the water supply.
Troubleshooting Tips
Save time and money! Review the chart below
first and you may not need to call for service.

13
General Electric Company
Warranty Registration Department
P.O. Box 34070
Louisville, KY 40232-4070
GE Service Protection Plus™
GE, a name recognized worldwide for quality and dependability, offers you Service
Protection Plus™—comprehensive protection on all your appliances—No Matter
What Brand!
Benefits Include:
•Backed by GE
•All brands covered
• Unlimited service calls
•All parts and labor costs included
•No out-of-pocket expenses
•No hidden deductibles
•One 800 number to call
You will be completely satisfied with our service protection or you may request your money back
on the remaining value of your contract. No questions asked. It’s that simple.
Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!
Plus there’s no extra charge for emergency service and low monthly financing is available. Even icemaker
coverage and food spoilage protection is offered. You can rest easy knowing that all your valuable
household products are protected against expensive repairs.
Place your confidence in GE and call us in the U.S. toll-free at 800-626-2224
for more information.
*All brands covered, up to 20 years old, in the continental U.S.
We’ll Cover Any Appliance.
Anywhere. Anytime.*
Please place in envelope and mail to:
✁Cut here

14
Consumer Product Ownership Registration
Model Number Serial Number
Important
Mail
Today!
GE Appliances
General Electric Company
Louisville, Kentucky 40225
First
Name
Mr. ■■Ms. ■■Mrs. ■■Miss ■■
Street
Address
City
State
Date Placed
In Use
Month Day Year
Zip
Code
Apt. #
Last
Name
Phone
Number __
Consumer Product Ownership Registration
Dear Customer:
Thank you for purchasing our product and thank you for placing your
confidence in us. We are proud to have you as a customer!
Follow these three steps to protect your new appliance investment:
Complete and mail
your Consumer
Product Ownership
Registration today.
Have the peace of
mind of knowing we
can contact you in
the unlikely event of
a safety modification.
After mailing
the registration
below, store this
document in a safe
place. It contains
information you
will need should
you require service.
Our service number
is 800-GE-CARES
(800-432-2737).
Read your Owner’s
Manual carefully.
It will help you
operate your new
appliance properly.
If you have questions,
or need more
information call the
GE Answer Center®
800.626.2000.
Important: If you did not get a registration card with your product,
detach and return the form below to ensure that your
product is registered.
123
Model Number Serial Number
✁Cut here

15
Saddle valve*
Parts List.
Customer ServiceTroubleshooting Tips
Operating InstructionsSafety Instructions Installation Instructions

16
General Electric parts catalog.
Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety InstructionsOperating Instructions
REF. NO. PART NO. PART DESCRIPTION
0001 WS02X10001 SCREW #10-14 X 3/4″88
0002 WS28X10010 MOUNTING BRACKET 1 1
0003 WS22X10008 NUT 3/8″ ΤUΒΕ 22
0004 WS22X10007 INSERT 3/8″ ΤUΒΕ 22
0005 WS02X10003 SCREW #10-14 X 1/4″22
0006 WS22X10002 ELBOW 3/8″ NPT X 3/8″22
0007 WS19X10011 HEAD 2 2
0008 WS03X10001 O-RING 3-3/8″ X 3-5/8″22
0009 WS30X10002 SUMP 2 2
0010 WS22X10003 NIPPLE 3/8″ NPT X 1-1/2″11
0012 WS07X10008 TUBING 3/8″ X 20 FT–WH 1 1
0014 WS02X10004 NUT 3/8″22
0015 WS03X10003 ADAPTER TUBING 2 2
0016 WS03X10002 WASHER 2 2
0017 WS15X10008 SADDLE VALVE /SUPPLY 1 1
0018 WS15X10022 FAUCET ASM. 1 1
0025 FXUTB FILTER-TASTE & ODOR 1 1
FXUSB FILTER-SEDIMENT 1 1
0200 WX5X140 WRENCH SUMP 1 1
0999 49-50006 PM MANUAL USE & CARE/ 1 1
INSTALLATION
GG
NX
UU
TT
00
33
BB

Notes.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
17

Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation InstructionsCustomer Service Troubleshooting Tips Installation Instructions Safety Instructions
Operating Instructions
Customer Service Troubleshooting Tips Installation Instructions Safety Instructions
Operating Instructions
Notes
18

19
GE Water Filtration System Warranty.
Customer ServiceTroubleshooting Tips
Operating InstructionsSafety Instructions Installation Instructions
For The Period Of: GE Will Replace:
One Year Any part of the Water Filtration system (excluding filters) which fails due to a defect in materials or
From the date of the workmanship. During this limited one-year warranty, GE will also provide, free of charge, all labor
original purchase (does not include service trip to home) to replace the defective part.
All warranty service provided by our SmartWater™ Authorized Servicer Network.
For service, call 800-GE-CARES.
■Service trips to your home to teach you how to use the
product.
■Improper installation.
■Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
■Use of this product where water is microbiologically
unsafe or of unknown quality, without adequate
disinfection before or after the system. Systems certified
for cyst reduction may be used on disinfected water that
may contain filterable cysts.
■Filter cartridges.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods or
acts of God.
■Incidental or consequential damage to personal property
caused by possible defects with this appliance.
What GE Will Not Cover:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home
use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives
you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225

Customer Service Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
Printed in Louisville, KY
20
Service Telephone Numbers.
GE Answer Center
®
800.626.2000
The GE Answer Center® is open 24 hours a day, 7 days a week.
In-Home Repair Service 800-GE-CARES (800-432-2737)
Expert GE repair service is only a phone call away.
Special Needs Service 800.626.2000
800-TDD-GEAC (800-833-4322)
GE offers, free of charge, a brochure to assist in planning a barrier-free kitchen for persons
with limited mobility.
Service Contracts 800-626-2224
Purchase a GE service contract while your warranty is still in effect and you’ll receive a
substantial discount. GE Consumer Service will still be there after your warranty expires.
Parts and Accessories 800-626-2002
Individuals qualified to service their own appliances can have parts or accessories sent directly
to their homes (VISA, MasterCard and Discover cards are accepted).
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since
improper servicing may cause unsafe operation.
Service Satisfaction
If you are not satisfied with the service you receive from GE:
First, contact the people who serviced your appliance.
Next, if you are still not pleased, write all the details—including your phone number—to:
Manager, Customer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
Finally, if your problem is still not resolved, write:
Major Appliance Consumer Action Program
20 North Wacker Drive
Chicago, IL 60606
