CL1100
Amplified Desk Telephone
With Volume And Tone Control
English

1
!!! Please refer to our website: www.geemarc.com for an up to
date user guide, as there may be important updates and changes
you need to be aware of !!!
INDEX.....................................................................1
DESCRIPTION........................................................2
SETTING UP...........................................................4
- Connecting the telephone.....................................4
- Ringer settings......................................................4
- Dialling types and grounding (UK version)...........5
- Time break recall switch.......................................6
VOLUME AND TONE ADJUSTMENT...................7
- Receiving volume and tone ..................................7
- Sending volume level adjustment.........................8
USING THE PHONE...............................................9
- Answering incoming call.......................................9
- Making a call.........................................................9
- Last number redial................................................9
- Recall, * & # buttons .............................................9
- Mute button.........................................................10
- Storing telephone numbers.................................10
- Dialling stored number........................................11
SAFETY INFORMATION .....................................12
GUARANTEE .......................................................13
RECYCLING DIRECTIVES..................................14
INDEX

2
DESCRIPTION
Direct memory
buttons Flashing incoming
ring indicator Phonebook
insert card
Tone reception
adjustment
Volume reception
adjustment
Extra volume and
tone activation
Memory storing
key
Time break
recall button
Mute button
Last number
redial

3
DESCRIPTION
Sending
level switch
Line cord socket*
Tone / Pulse / Grounding
switch Time break recall switch
(R=100ms/300ms)
Volume & Tone adjustment
ON/OFF switch
Ringer level
adjustment switch
Reception volume
adjustment Reception Tone
adjustment

4
1 - CONNECTING THE TELEPHONE
1. Connect the handset cord.
2. Open the battery compartment by pulling back
the latch.
3. Insert correctly 4 x AAA 1.5V alkaline batteries
(not supplied) in the battery compartment (*).
Batteries are required if you wish to increase
the ringer level up to 10 dB.
4. Snap the battery door back in place.
5. Connect the line cord to the socket (*).
(*) Classified TNV-3 according to EN60950 standard.
2 - RINGER SETTINGS
A switch located on the upper side allows the
ringer to be switched HI, LOW, OFF :
: Off,
: Low,
: Hi
Your phone comes with the ringer switched to
«High» and the melody set to «6»:
Low Mid High
Melody 1 1 2 3
Melody 2 4 5 6 (by default)
Melody 3 7 8 9
SETTING UPSETTING UP

5
If you don’t like the ringer melody, you can
choose a new one by changing the settings as
per instructions below:
- Lift the handset.
- Press button.
- Press # button.
- Press any of the 1 - 9 dial keys.
The new ringer settings will be activated with the
next incoming call.
Note: The ringer level will be increased up to 10
dB if you insert batteries into the battery
compartment.
3 - DIALLING TYPES AND GROUNDING
A switch ETR/PR/T located on the upper side is
equipped on some models. If you wish to connect
your CL1100 to a public UK/French switch-board
(PBX), move switch ETR/PR/T to position 3 (T).
This will ensure optimal compatibility of your
phone with most (99%) PBX.
SETTING UP

6
Positions:
Position 1:
Pulse dialling. The Ris grounded. This option
can be used only within the UK in very special
cases.
Position 2:
Pulse dialling. The R is set according to the
determined adjustment (see «Time Break Recall
Setting for R Function» p.9).
Position 3:
Tone dialling. The R is set according to the
determined adjustment (see «Time Break Recall
Setting for R Function» p.9).
If you are using your CL1100 with a hearing aid, set
your hearing aid to “T” position.
4 -TIME BREAK RECALL SWITCH (300/100)
Check the Time Break Recall setting of your
CL1100. For the UK the Time Break Recall
should be set to 100 mS. It can be switched to
300 mS for other locations or PBX’s.
SETTING UP

7
1 - RECEIVING VOLUME AND TONE
ADJUSTMENT
You can adjust the receiving volume and tone
according to your own hearing requirements.
The button allows extra volume and tone
functions to be activated or deactivated during
the conversation.
Tone and volume adjustment (15dB to 30dB) is
only activated when the switch located at the
upper side of your phone is set to ON. When this
button is set to OFF only the volume can be
adjusted from 0dB to 15dB.
When the function is activated, the red light of
extra receiving and tone function button is
lit.
Note: When the tone (treble), earpiece volume
and sending levels are set to the maximum,
whistling may occur. If whistling occurs the
sending level settings should be decreased with
the switch .
TONE AND VOLUME ADJUSTMENT

8
Adjust the TONE and VOLUME buttons to fit the
levels to your own hearing requirements.
2 - SENDING VOLUME LEVEL ADJUSTMENT
If your voice is quiet or called parties have
difficulty hearing you, you can increase the
sending level volume with the switch located on
the upper side. You can also decrease the
sending volume if required.
TONE AND VOLUME ADJUSTMENT

9
1 - ANSWERING INCOMING CALLS
- When an incoming call is received the phone
will ring and the incoming call indicator will
flash. To answer the call lift the handset and
speak.
- On completion of the call, carefully replace the
handset in the cradle to release the line.
2 - MAKING A CALL
- Lift the handset.
- Await the dial tone and dial required number.
- On completion of the call, carefully replace the
handset in the cradle.
3 - LAST NUMBER REDIAL
- Lift the handset.
- Await the dial tone and press button.
- A previously dialled number will be
automatically redialled (not in use for memory
numbers).
4 - RECALL, * & # BUTTONS
These are used with the new services provided
on digital exchanges. For details please contact
your network operator.
USING THE PHONE

10
5 - MUTE BUTTON
If you wish to speak privately to someone else in
the room without your caller overhearing, press
and hold the button. You will still be able to
hear the caller but they cannot hear you during
the mute operation. To resume normal
conversation, release the button.
6 - STORING TELEPHONE NUMBERS
Your telephone CL1100 can store 12 direct
memories.
To store a number please follow instructions
below:
- Lift the handset.
- Press button.
- Press M1, M2, ... M12 to locate the number.
- Dial the number.
- Press again Button.
Numbers will be lost after few hours if you
disconnect your phone. Entering a new number
in the same location will automatically erase the
previous number.
USING THE PHONE

11
7 - DIALLING STORED NUMBERS
- Lift the handset and await the dial tone
- Press the appropriate location button M1, M2...
M12 and the number stored in this location will be
dialed automatically.
To register your stored phone numbers, use the
index located on the front of your phone.
USING THE PHONE

12
General
Do not open the unit. Contact the helpline for all repairs.
Cleaning
Clean the telephone with a soft cloth. Never use polishes or
cleaning agents – as these could damage the finish or the
electrics inside.
Environmental
Do not expose to direct sunlight.
Always ensure there is a free flow of air over the surfaces of
the telephone.
Do not place any part of your product in water and do not
use it in damp or humid conditions e.g. bathrooms.
Do not expose your product to fire or other hazardous
conditions.
Unplug your phone from the telephone socket during
thunderstorms to prevent damage to your telephone. Your
guarantee does not cover thunderstorm damage.
The telephone is designed for working within a temperature
range of 5°C to 45°C.
SAFETY INFORMATION

13
From the moment your Geemarc product is purchased,
Geemarc guarantee it for the period of two years. During this
time, all repairs or replacements (at our discretion) are free
of charge. Should you experience a problem then contact
our help line or visit our website at www.geemarc.com. The
guarantee does not cover accidents, negligence or
breakages to any parts. The product must not be tampered
with or taken apart by anyone who is not an authorized
Geemarc representative. The Geemarc guarantee in no way
limits your legal rights.
IMPORTANT: YOUR RECEIPT IS PART OF YOUR
GUARANTEE AND MUST BE RETAINED AND
PRODUCED IN THE EVENT OF A WARRANTY CLAIM.
DECLARATION: Geemarc Telecom SA hereby declares
that this product is in compliance with the essential
requirements and other relevant provisions of the Radio and
Telecommunications Terminal Equipment Directive
2014/53/UE and in particular article 3 section 1a, 1b and
section 2. The telephone does not operate if the line current
is lower than 18 mA.
The declaration of conformity may be consulted at
www.geemarc.com
Telephone connection: Voltages present on the
telecommunication network are classified TNV-3
(Telecommunication Network Voltage) according to the
EN60950 standard.
Please note: The guarantee applies to
the United Kingdom only
GUARANTEE

14
The WEEE (Waste Electrical and Electronic Equipment) has
been put in place for products at the end of their useful life,
so that these products are recycled in the best way.
When this product is finished with, please do not put it in
your domestic waste bin.
Please use one of the following disposal options:
- Remove the batteries and deposit them in an appropriate
WEEE skip. Deposit the product in an appropriate WEEE
skip.
- Or, hand the old product to the retailer. If you purchase a
new one, they should accept it.
Thus if you respect these instructions you ensure human
health and environmental protection.
For product support and help visit our website at
www.geemarc.com
Telephone [phone]
Or fax [phone]
RECYCLING DIRECTIVES
