Geemarc DALLAS10 User manual

0
Big Button Telephone With VolumeControl
Téléphone À Grandes Touches Avec
Réglage De Volume
Groβtastentelefon mit Lautstärkeregelung
If you are using this telephone with a hearing aid, set your
hearing aid to the «T» setting.
Si vous utilisez ce téléphone avec une aide auditive,
basculez-la sur la postion T.
Sollten Sie diese Telefon mit einer Hörhilfe verwenden, so
stellen Sie diese bitte auf den «T» - modus.
English 2~9
Français 10~17
Deutsch 18~26

1
English:
!!! Please refer to our website:
www.geemarc.com for an up to
date user guide, as there may be
important updates and changes
you need to be aware of.!!!
Français:
!!!Voir sur notre site internet si
une version plus récente de cette
notice d’utilisation est disponible.!!!
Deutsch:
!!!Prüfen Sie auf unserer Website
ob eine neuere Version dieser
Bedienungsanleitung verfügbar
ist.!!!

2
General Description
(*) Classified TNV-3 according to EN60950 standard.
(**) Please note that this switch is not to be moved after setting.
SETTING UP
Line cord
socket* Indirect
memory
button
3 direct
memories
Ringer
On / Off
Sending
level
switch
Pule /
Tone
switch**
Handset
Last number
redial
Time break
recall button
Memory
storing key
Volume
reception
adjustment

3
1 - CONNECTING TELEPHONE
1 - Connect the handset cord.
2 - Connect the line cord to the socket located at rear of
telephone then connect the PTT plug*.
2 - RINGER SETTINGS
A switch located on right side allows the ringer to be
switched On ( ) or Off ( ).
3 - WALL MOUNTING
To wall-mount your telephone, slide out the clip turn
around and slide back into the wall mounting position
(located in the base unit, just below the ear piece).This
will ensure that the handset stays firmly in position.
Make 2 holes in the wall 85mm apart, insert the wall
plugs and the wall mounting screws. The screws should
protrude from wall by 6-7mm. Place the phone onto the
screw-heads and slide down to secure.
4 - TONE/PULSE SWITCH (T/P)**
The Tone/Pulse switch is factory pre-set to Tone
position (T).In the UK, all telephone exchanges now use
Tone dialing. If your phone does not dial out it is
probably being used from an older private switch board
(PBX). In this case, the Tone/Pulse switch must be
moved to Pulse (P).
SETTING UP

4
1 - ANSWERING INCOMING CALL
- When an incoming call is received the phone will ring
and flash. To answer the call lift the handset and speak.
- On completion of the call, carefully replace the handset
in the cradle to release the line.
2 - VOLUME RECEIVING ADJUSTMENT
You can increase the volume according to your own
hearing requirements.
Use the VOL button, located on the right side, to adjust
the level according to your own hearing requirements.
3 - MAKING A CALL
- Lift the handset.
- Await the dial tone and dial required number.
- On completion of the call, carefully replace the handset
in the cradle.
USING THE PHONE

5
4 - SENDING LEVEL ADJUSTMENT
If your voice is quiet or called parties have difficulty
hearing you, you can increase the sending level volume
with the switch located on the right side.
5 - LAST NUMBER REDIAL
- Lift the handset.
- Await the dial tone and press button.
- The previously dialled number will be automaticaly
redialled (not in use for memory numbers).
6 - R, * & # BUTTONS
These are used with the new services provided on
digital exchanges. For details please contact your
network operator.
7 - STORING TELEPHONE NUMBERS
Your phone can store 3 direct and 10 indirect memories
(16 digits maximum for each memory).
- Lift the handset.
- Press button.
- Dial the telephone number you wish to store.
USING THE PHONE

6
- Press button.
- Press one of the direct memory buttons, M1, M2, M3.
Or press MEM and any button 0 to 9 on the key pad
under which you wish to store the telephone number in
indirect memory.
- Replace the handset.
Note: Numbers will be lost if you disconnect your phone.
Entering a new number in memory will automatically
erase the previous number.
8 - DIALLING STORED NUMBER
- Lift the handset and await the dial tone.
- Press appropriate direct memory button M1, M2, or M3.
The stored number will be dialled out automatically.
Or press the MEM button followed by the keypad 0 to 9
button under which the desired number is stored. The
stored number will be dialled out automatically.
To register your stored phones numbers, use the index
located on the base.
USING THE PHONE

7
General
Do not open the unit. Contact the helpline for all repairs.
The phone is capable of amplifying sounds to a loud
volume. It is important to instruct all potential users of its
proper operation. It is advised to adjust the volume
control to its minimum level (Low) when not in use and
alert other users that hearing damage can potentially
result from misuse.
Cleaning
Clean the telephone with a soft cloth. Never use
polishes or cleaning agents - they could damage the
finish or the electrics inside.
Environmental
Do not expose to direct sunlight.
Always ensure there is a free flow of air over the
surfaces of the telephone.
Do not place any part of your product in water and do
not use it in damp or humid conditions e.g. bathrooms.
Do not expose your product to fire or other hazardous
conditions.
Unplug your phone from the telephone socket during
thunderstorms because it could damage your telephone.
Your guarantee does not cover thunderstorm damage.
The telephone is designed for working within a
temperature range of 5°C to 45°C.
SAFETY INFORMATION

8
From the moment your Geemarc product is purchased,
Geemarc guarantee it for the period of two years. During
this time, all repairs or replacements (at our discretion)
are free of charge. Should you experience a problem
then contact our help line or visit our website at
www.geemarc.com. The guarantee does not cover
accidents, negligence or breakages to any parts. The
product must not be tampered with or taken apart by
anyone who is not an authorized Geemarc
representative. The Geemarc guarantee in no way limits
your legal rights.
IMPORTANT: YOUR RECEIPT IS PART OF YOUR
GUARANTEE AND MUST BE RETAINED AND
PRODUCED IN THE EVENT OF A WARRANTY CLAIM.
DECLARATION: Geemarc Telecom SA hereby
declares that this product is in compliance with the
essential requirements and other relevant provisions of
the Radio and Telecommunications Terminal Equipment
Directive 2014/53/UE and in particular article 3 section
1a, 1b and section 2. The telephone does not operate if
the line current is lower than 18 mA.
The declaration of conformity may be consulted at
www.geemarc.com
Please note: The guarantee applies to
the United Kingdom only
GUARANTEE

9
Telephone connection: Voltages present on the
telecommunication network are classified TNV-3
(Telecommunication Network Voltage) according to the
EN60950 standard.
The WEEE (Waste Electrical and Electronic Equipment)
has been put in place for the products at the end of their
useful life are recycled in the best way.
When this product is finished with, please do not put it in
your domestic waste bin.
Please use one of the following disposal options:
- Remove the batteries and deposit them in an
appropriate WEEE skip. Deposit the product in an
appropriate WEEE skip.
- Or, hand the old product to the retailer. If you purchase
a new one, they should accept it.
Thus if you respect these instructions you ensure human
health and environmental protection.
For product support and help visit our website at
www.geemarc.com
Telephone [phone]
Or fax [phone]
RECYCLING DIRECTIVES
