Geemarc CL9000 User manual

4G Phone with SOS Emergency
Call
NOTE:
This phone may be used by people with hearing problems.
It has a variable volume headset until 40dB. On first use,
make sure that the handset volume is set to minimum. The
hearing impaired person may subsequently increase the
volume to suit their needs.
English

1
Please refer to our website: www.geemarc.com for an up to
date user guide, as there may be important updates and
changes you need to be aware of!
Contents ......................................................................1
Prior To Use ................................................................5
- Congratulations ................................................................. 5
- Safety Precautions ............................................................ 6
- Setting Up ......................................................................... 7
●Check the contents of the box ..............................................7
●Choosing a location ..............................................................7
●Battery and Adapter installation ...........................................7
- Connecting the Telephone ................................................ 8
- Wall mounting ................................................................... 9
- Location of controls ......................................................... 10
- Keys description .............................................................. 11
- LCD description ................................................................ 12
Settings .....................................................................14
- Phone settings ................................................................ 14
●Time & Date .........................................................................14
●Language settings................................................................14
●Restore factory setting .........................................................15
- Call settings ...................................................................... 15
●Voice mail server..................................................................15
●Divert Call ............................................................................15
●Call waiting...........................................................................15
●Call barred ...........................................................................16
●Reply SMS after reject .........................................................16
●Call time minute reminder ....................................................16
- Display .............................................................................. 16
●Contrast ...............................................................................16
●Backlight ..............................................................................16
Contents

2
- Security............................................................................. 17
●Pin........................................................................................17
●Blacklist................................................................................17
- Connection........................................................................ 17
- Version.............................................................................. 18
- Led switch......................................................................... 18
- Low battery to SMS .......................................................... 18
- Boost setting ..................................................................... 18
●Tone Control ........................................................................18
●Boost lock ............................................................................19
- Short key, Silence mode................................................... 19
Profiles ......................................................................20
- Ring settings ..................................................................... 20
- Adjust volume ................................................................... 21
- Other alert rings ................................................................ 21
Using the telephone .................................................22
- Outgoing call..................................................................... 22
- Incoming call & Receiving a call (CID) ............................. 23
- Dial from Contacts .......................................................... 23
- Speed dial ....................................................................... 23
- Photo key dialing .............................................................. 24
- Dialing a Number from the Redial List.............................. 24
- Dialing a Number from the Missed Calls List.................... 24
- Dialing a Number from the Received Call List.................. 24
- Muting the Microphone ..................................................... 24
- Using the Amplification Function ...................................... 25
- Using your Phone with hearing aids ................................. 25
- Hands-free ........................................................................ 25
- Tone Response ................................................................ 25
Contents

3
Phonebook ...............................................................26
- Contacts............................................................................ 26
- Create a Phone Book Engtry............................................ 26
- View Contacts Entries....................................................... 27
- Options within Contacts.................................................... 27
- Store number in Speed dial or Photo key......................... 28
SMS ...........................................................................29
- Message (SMS) ................................................................ 29
- Send a Text Message....................................................... 29
- Receiving a Text Message ............................................... 30
- Reviewing Stored Text Messages (Inbox)........................ 30
- Outbox .............................................................................. 30
- Drafts ................................................................................ 31
- Delete SMS....................................................................... 31
- Templates ......................................................................... 31
- Broadcast Messages ........................................................ 32
- SMS Settings .................................................................... 32
- Messages Capacity .......................................................... 32
Call Record ...............................................................33
- Call logs ............................................................................ 33
- Display Missed Calls......................................................... 33
- Display Outgoing Calls ..................................................... 34
- Display Received Calls..................................................... 34
- Delete All .......................................................................... 34
- Call duration...................................................................... 34
Application ...............................................................35
- Application ........................................................................ 35
●Alarm....................................................................................35
●Timer....................................................................................35
●Bluetooth..............................................................................35
- Name Recorder ................................................................ 36
Contents

4
SOS ...........................................................................37
- SOS function..................................................................... 38
- SOS Number Settings ...................................................... 38
- SOS Announce message ................................................. 38
- SOS Message Record ...................................................... 39
- SOS Text Message........................................................... 39
- Pairing a new SOS remote ............................................... 39
- Battery replacement.......................................................... 40
- Range ............................................................................... 40
Technical specifications .........................................41
Features ....................................................................42
Troubleshooting ........................................................43
Safety Information .....................................................45
Hearing aid information ............................................47
Network services .......................................................48
Guarantee...................................................................49
Recycling Directives ................................................50
Contents

5
Congratulations
Congratulations on purchasing our product.
Please read the manual carefully to learn all about the features
available and how your telephone works. This will help you to get
the best of your new phone.
Prior To Use

6
Safety Precautions
To prevent any risk of electrical shock and injury, please follow
these basic safety precautions before using the phone:
1. Carefully read and observe the instructions in this manual.
2. The phone is capable of amplifying sounds to a loud volume. It
is important to instruct all potential users of its proper operation.
It is advised to adjust the volume control to its minimum level
(Low) when not in use and alert other users that hearing damage
can potentially result from misuse.
3. When cleaning, first unplug the phone. Then use a damp cloth
to wipe it. Do not use liquid or aerosol cleaners.
4. Do not place objects on the line cord as this may cause damage.
5. Do not use this phone in wet surroundings or environments where
there is a risk of explosion.
6. Refer servicing to qualified service personnel only.
7. Use only the power supply provided.
8. Install the telephone where no one will step or trip on the cord.
9. Do
not overload wall outlets or extension cords as this can
increase the risk of fire or electrical shock .
10. Never push any objects through the slots in the telephone. They
can touch dangerous voltage points or short out parts that could
result in a risk of fire or electrical shock.
11. Never spill liquid of any kind on the telephone.
Prior To UsePrior To Use
Prior To Use

7
Setting Up
CHECK THE CONTENTS OF THE BOX
Box should contain:
zHandset with handset cord and phone base
z3.7V, 900mAh Li-polymer rechargeable battery
zUser's manual
zRemote for emergency call with his battery CR2025
zPower adapter (5V DC 2.0A, 10W)
zType A to type C USB cable (length 1.8m)
zWall mount bracket
CHOOSE A LOCATION
The unit should be located in an area where it is easy to see the
visual display and lighted ringer.
Choose a location that is out of the way of normal daily activities
so that it is not knocked or there is no danger of tripping over wires.
BATTERY AND ADAPTER INSTALLATION
For using all features e.g. Hands-Free and Amplification, it is
essential that the telephone is powered by the power supply or
the battery.
Unclip the battery door with a screw driver in the hole.
Connect the rechargeable battery plug to the battery socket in the
open battery compartment. Pay attention to the correct polarity.
Only use the rechargeable battery provided with the phone.
Close the battery compartment cover.
Pay attention that the telephone is not connected mains power
connection when the battery are being inserted or replaced.
Battery low: If battery is low, the phone will emit loud BEEP, show
“battery low” in the display and send a SMS at the phone number
recorded. Please plug in USB Type C power adapter into the device.
Prior To Use

8
Connecting the telephone
- Connect the handset coil cord (RJ9 plug) (1).
- Plug your Nano SIM card to SIM slot at the rear of the base (2).
- Unclip the battery door with a screw driver in the hole.
Connect the rechargeable battery plug to the battery socket (3).
In case of power failure, battery are required for the ring.
- Snap the battery door back in place.
- Connect the USB cable (type A plug) to the adapter (4).
- Connect the adapter cord (type C plug) to the telephone (5).
- Connect the adapter to you wall socket (*) (6).
- Press and hold Power(mute) on/off key , the phone will be
turned ON.
(*) Classified “hazardous voltage” according to EN62368-1 standard.
Note : Rechargeable battery is for back up purpose in case of
power failure, you should plug in USB type C power adaptor
all the time.
Prior To Use

9
Wall mounting
The telephone can also be installed on a wall. You require
two screws in order to fix the telephone on a wall.
Feed the guide tabs (1) on the wall-mounting bracket (2) in the
slots (3) on the rear side of the telephone. Slide the wall bracket
(2) 10mm upwards until it audibly snaps into place.
Warning: Ensure that there are no cables or pipes etc. under
the surface of the wall where you want to drill the holes.
Drill two holes whose distance 84mm in vertical, insert the
screws and allow them to project 5mm from the wall.
Position the telephone on the bracket, fit the screws in the slots
and slide the telephone downwards a little.
Turn the receiver hook (4) in the receiver cradle 180oso that
the receiver can be hooked in.
Prior To Use

10
1. Audio In/Out ( 3.5mm)CTIA 10. Receiver +40 dB Boost button
2. Nano SIM card slot 11. Handsfree
3. DC IN (type-C) 12. Handsfree mode indicator
4. LCD screen 13. Incoming ring indicator/new call
5. Photo keys (x3) 14. Menu / OK button
6. Call log / Backspace / Delete 15. Left / Contacts
7. Up / Adjust Volume setting 16. Right / Write SMS
8. Down / Adjust Volume
setting 17. SOS button
9. Power (mute) on/off 18. Emergency call unit
Prior To Use

11
Keys Description
The 3 pictures keys are used as one-touch
speed dial keys.
Press this key to enter in Menu.
Press this key to access to the function EDIT
when you are in Phonebook contact.
Press this key to access at the function
DELETE or DELETE ALL when you are
positioned on CID number.
Press OK to confirm your selection.
Press OK to start a call when the contact is
selected.
Call logs / Backspace / Delete
Call logs list, as described in page 24.
When you dial a phone number, press this
key will delete the last digit(s).
Left / Right keys, Short cut in stanby mode:
Left key: Contacts list.
Right key: Write an SMS.
This key is used for emergency dialling.
Highlight or scroll through the menu options.
Short cut: Adjust Volume setting
Power on/off key, Mute key.
Long press to power the telephone on and off.
When you press this key during the call, the
LED turns ON to inform you that the Boost
mode is activated.
Handsfree / Make / Answer / End a call.
Activates the speakerphone if pressed during
a call, as described in page 25: Hands-free.
The LED is ON to inform you that the function
is activated.
Prior To Use

12
Hash key
Press to switch between different input modes
while composing a text message or editing a
contact name.
In stanby status, Press and Hold to enable /
disable silence mode.
Asterisk key
Press this key to insert one or more symbol
while composing a message or editing a
phonebook entry name.
(more detail please see P22: Asterisk key).
Note : Menu (OK) key and Call logs (Back space)
key also work as soft keys i.e. they take on different functions
depending on the menu displayed. The current function is always
displayed at the lower left and right corner.
LCD description
The LCD screen is split into three distinct areas:
The icon area (status bar). This is found at the top of the
screen. This displays the various system icons which help
you to use the telephone.
The main area. This is found across the centre of the screen.
It displays the following:
•number being dialled
•caller ID information
•phonebook
•menu information
•in standby mode current time, date and service provider name.
The soft key area. This is found at the bottom of the screen.
Prior To Use

13
Signal Strength icon
This is always displayed when your telephone is switched
on. It shows the current signal strength. More bars indicate
more si
g
nal stren
g
th. There is one of these icons per SIM.
VoLTE
You are in 4G and can make a good call.
E means that the network is in 2G
Alarm icon
The alarm has been set to rin
g
at a specified time.
Battery Status icon
This is always displayed when your telephone is switched
on. It shows the level of battery charge. More bars indicate
more batter
y
char
g
e.
Roaming icon
A roaming call is taking place i.e.international call –
outgoing or incoming.
SMS icon
A new SMS (text message) has been received.
Silent icon (press and hold #key to activate / disable)
The telephone is in silent mode. There will be no call alert.
Headset icon
The headset is plugged in.
Blue tooth icon
When blue tooth is ON.
Ear symbol
If Boost is on, Ear icon will be showed on the status bar.
Missed Call
During coversation
You are on line.
SOS is ON
Use power adaptor only / Use battery only
Battery Charging / Battery full Charged
Prior To Use

14
Phone settings
Time and Date
Time and date has been preset to be obtained from your service
provider. You can still able to set it manually.
User is also able to set the time, date format.
zPress Menu/OK key to display the main menu list.
zPress the keys to move to Settings ÆÆPhone
settings ÆÆTime & date, and press to move
to Set time.
zPress key twice, enter the correct hour and minutes with
the keypad then press .
zPress the key to move to Set date, Press key, Enter
the correct day, month and year with the keys or or
keypad, and press .
zPress the key to move to Time Format, Press key,
Use or key to move to the desired date format 12
Hours or 24 Hours then press .
zPress the key to move to Date Format, Press key,
Use or key to move to the desired date format Year-
Mon-Day / Mon-Day-Year or Day-Mon-Year then press .
zPress the key to move to Update time settings, Press
key. Use or key to move to the desired Auto
update time or Manual update time then press .
zPress key to Done.
zPress key to Exit.
Note: if you have the function CID on your network, at the first
call, the date & Hour will be set automatically.
Language settings
Menu/OK ÆSettings ÆPhone settings Ælanguage
User can change the languages. Up to 12 languages are available.
(English / French / German / Spanish / Portuguese / Arabic / Dutch
/ Italian / Hebrew / Russian / Polish / Czech.
Settings

15
Restore factory setting
User can restore factory setting. It needs password to proceed.
The password is 1-2-3-4.
Call settings
Menu/OK ÆSettings ÆÆCall Settings
Voice mail server
The voicemail function allows you to listen to any voicemail
messages people may have left for you.
The voice mailbox is a network service to which you may need to
subscribe. Contact your service provider if in doubt.
If your service provider does give you access to voice mail, the
telephone number used to access the voice mail system will
normally be set up on your telephone. If it is not, you can manually
input your voice mail number here.
From standby, you can access voicemail by simply pressing and
holding 1. You will be connected to voice.
Divert Call
Incoming calls can be diverted to a specified telephone number
(voicemail number generally). There are 5 options available with
this function:
zDivert all: Call divert is applied to all incoming calls.
zIf Busy: Call divert is applied to all incoming calls if your line is
busy.
zIf No Answer: Call divert is applied to all incoming calls if you
do not answer the call.
zIf Unreachable: Call divert is applied to all incoming calls if your
phone is switched off or you are not in a service area.
zCancel all diverts.
Call waiting
This can be activated or cancel or check status. Please check that
this service is available from your service provider.
Settings

16
Call barred
There are many settings available:
Call Barring: Incoming and outgoing calls to and from your phone
can be limited. There are 4 options available with this function:
zAll outgoing Calls: No outgoing calls can be made.
zAll incoming Calls: No incoming calls can be received.
zIncoming calls when roaming
ISD calling: If activate it, then all international outgoing call will
be blocked. (Password is 0000).
Dial when INTL roaming: If activate it, then no outgoing call can
be made during roaming, no outgoing (Password is 0000).
zCancel all barring.
Reply SMS after reject:
If you set it to ON, then if user rejects the incoming call, the display
will show “1 missed call” to inform you that you have misses an
incoming call, select EXIT then “Reply” will be showed. Press OK
then you can send a template SMS message in answer.
Call time minute reminder
Set it ON, the phone will emit a beep according to your setting.
Customize if you want a reminder of how long you have been on the
phone. You have the possibility to set on OFF, 50, 55, 60 seconds
or customize this time.
Display
Menu/OK ÆSettings ÆDisplay
Contrast
zUse Left() /Right() key to move to the desired contrast
then press Menu/OK to valid.
Backlight
Backlight auto off time (15s /30s /1min /5min), default is 15 seconds.
zUse Up() / Down() key to move to the desired time then
press Menu/OK to valid.
zPress key to exit.
Settings

17
Security
Menu/OK ÆSettings ÆÆSecurity
PIN
This mobile telephone allows you to set up Pin code to help protect
your telephone from unauthorized use.
The PIN and PIN2 codes are supplied with your SIM card. The PIN
code help to protect the SIM card from unauthorized use. The PIN2
code is required to access certain services.
The PUK (PIN) and PUK2 (PIN2) codes may be supplied with the
SIM card. If you enter the PIN code incorrectly three times in
succession, the PUK will be required. If the codes are not supplied,
contact your service provider.
Blacklist
The ability to Reject and blacklist numbers except the SOS numbers.
zBlacklist: Select Blacklist then Options, use and
key to select New (enter the name and the phone number) or
Import contacts then press to valid.
zSelect your contact in the list then press to valid.
zSelect Mark then press to valid.
zSelect Options then press .
zPress key to exit.
Note: You have in option the possibility to delete, delete all, edit an
contact or all contacts of the blacklist.
Connection
Menu/OK ÆSettings ÆOK ÆConnection
You have the possibility to set the DATA Service or Data roaming.
Network selection: you have the possibility to select your network
operator.
Network type: choose the type of network.
Volte: Voice over Long-Term Evolution, this function is to make an
call in 4G quality.
Settings

18
Version
Menu/OK ÆSettings ÆOK ÆVersion
Hardware and Software version will be showed here. Normally it is
for technical service department.
Led switch
Menu/OK ÆSettings ÆOK ÆLed switch
You have the possibility to activate or no the Led situate in front of
to inform you that you have a new message or a new call.
Low battery to SMS
Menu/OK ÆSettings ÆOK ÆLow battery to SMS
When you have actívate this function, the phone number that you
have set will be receive two SMS, one to inform him that the battery
is low and one second one hour after.
In this case, you must double check that the power adaptor is
properly connected or wait that the power failure is finished.
Boost setting
Menu/OK ÆSettings ÆOK ÆBoost setting
In choose this menu, you can set the tone of your handset and to
activate or no the boost in automatic.
Tone Control:
You have the choose between 3 possibilities: Normal, Middle and
Treble.
If you choose Treble, you increased the high frequencies, if you
choose Bass, you increase the Low frequencies.
During your call, you can change your setting inusing the keys Left
() / Right (). You can see on the display the Tone control
position that you have selected.
The Tone modifications is activated only with the boost function
activated.
Settings

19
Boost lock
When you activate this function, every times that you will do a
conversation with the handset, the boost will be activate
automatically.
Other settings
•Short key
When you press a short key, you have directly Access at the
function:
Up arrow : Volume adjustment (Profiles)
Down arrow : Volume adjustment (Profiles)
Right arrow : Write an SMS
Left arrow : Contacts list
•Silence mode
Press and Hold key to enable silence mode in standby
mode, if silence mode is enabled, silence mode icon will
be displayed. Press and Hold key to disable silence mode.
Settings
