gefran EXP-DN-BDI-VDI User manual

EXP-DN-BDI-VDI
English
Instruction Manual for
Communication Module

EXP-DN-BDI-VDI User Manual V01 pag. 2
Thank you for choosing this Gefran product.
We will be glad to receive any possible information which could help us improve this manual.
The e-mail address is the following: t[email protected].
Before using the product, read the safety instruction section carefully.
Keep the manual in a safe place and available to engineering and installation personnel during
the product functioning period.
Gefran Drives and Motion S.r.L. has the right to modify products, data and dimensions without
notice.
The data can only be used for the product description and they can not be understood as
legally stated properties.
All rights reserved

EXP-DN-BDI-VDI User Manual V01 pag. 3
Content
CHAPTER 1 SUMMARY......................................................................................................................1
1.1 System Structural Diagram.............................................................................................. 1
1.2 Structure of the unit ......................................................................................................... 2
1.3 Description of Communication Module............................................................................ 3
CHAPTER 2 INSTALLATION.............................................................................................................. 4
2.1 Installation and Dimensions............................................................................................. 4
2.2 Connecting power supply ................................................................................................ 5
2.3 Connected with DeviceNet system.................................................................................. 5
2.4 Connected with Inverter by Modbus ................................................................................ 6
2.5 Terminating resistors........................................................................................................ 6
2.6 Baud rate and max transmit length.................................................................................. 6
2.7 Climatic condition............................................................................................................. 7
CHAPTER 3 OPERATION...................................................................................................................8
3.1 Initial power up................................................................................................................. 8
3.2 Networking Settings......................................................................................................... 8
3.3 Network Address Settings and Self-adjust Baud Rate .................................................... 8
3.4 LED indicator ................................................................................................................... 9
CHAPTER 4 COMMUNICATION MODULE FUNCTIONS ........................................................... 11
4.1 Net Description ...............................................................................................................11
4.2 EXP-DN-BDI-VDI Object Modeling................................................................................ 12
4.3 Object Class Define ....................................................................................................... 14
4.4 EDS file .......................................................................................................................... 29
CHAPTER 5 DIAGNOSTICS FAST .................................................................................................30
LED indicator Diagnosis ...................................................................................................... 30
APPENDIX............................................................................................................................................ 31
Technical parameters:.......................................................................................................... 31
EDS file ........................................................................ Errore. Il segnalibro non è definito.

EXP-DN-BDI-VDI User Manual V01 pag. 1
Chapter 1 Summary
EXP-DN-BDI-VDI can connect with DeviceNet by DeviceNet Extended Communication
Module. To DeviceNet, EXP-DN-BDI-VDI DeviceNet Communication Module is a Group2
Only Slave device; it is a slave station of DeviceNet.
To Inverter, EXP-DN-BDI-VDI Communication Module connected with Inverter by RS485
communication port.
DIP switch SW1_8 is required to be set OFF if EXP-DN-BDI-VDI Module is connected
with the inverters of VDI100/BDI50 series.
The VDI100/BDI50 series have built-in RS485 interface so they can connect with
different extended communication module by Modbus protocol, such as DeviceNet
Communication module, Profibus Communication module. If Inverter connected with
DeviceNet Communication module, it can`t connected with other communication modules.
1.1 System Structural Diagram
It is the slave station of DeviceNet when EXP-DN-BDI-VDI Communication Module is
connected with the inverter via RS485. Refer to Fig.1.1:
SLC and other
DeviceNet Master
Devices
Client Tool
DeviceNet
EXP-DN-BDI-VDI
Module 1
VDI100 Series
Motor
Other DeviceNet Devices
Inverter RS485
Figure1.1: Bus System Structure of DeviceNet

EXP-DN-BDI-VDI User Manual V01 pag. 2
Figure1.2: EXP-DN-BDI-VDI system
1.2 Structure of the unit
NS
DNET
MS
V
+
CAN_H
Shield
CAN_L
V_
Figure1.3: Structure of the EXP-DN-BDI-VDI Extended Module
①
Power supply terminals
②
Retractable mounting feet
③
DIP Switch
(2PIN：Selection of Network Terminating Resistor
）
④
Module Status indicator/Network Status indicator
⑤
Press-button
⑥
DIP Switch
(8PIN：Settings of Network ID and functions）
⑦
RS485
⑧
Terminals
PLC : SLC500

EXP-DN-BDI-VDI User Manual V01 pag. 3
1.3 Description of Communication Module
DeviceNet Communication
·Support Self-adjust Baud Rate
Support
Support duplicate MAC Id check
Support predefine master slave connection
Support predefine explicit message connection
Support predefine poll IO message connection
Support explicit and IO message fragment

EXP-DN-BDI-VDI User Manual V01 pag. 4
Chapter 2 Installation
2.1 Installation and Dimensions
Installation
EXP-DN-BDI-VDI Module can be installed vertically shown as the left side of Fig. 2.1. Fix
the module to DIN rail and the rail is gripped accurately to the plastic groove. It is suggested
to add clips at rail terminal to fix it. It is also suggested to install the screw M4 directly to
EXP-DN-BDI-VDI module, shown as the right side of Fig.2.1.
Figure 2.1: Fixed Installation
Dimensions
Unit: mm（1 inch＝25.4mm）
Figure 2.2: Dimensions

EXP-DN-BDI-VDI User Manual V01 pag. 5
2.2 Connecting power supply
Network power supply 24VDC / 50mA and backup power supply are applied to
EXP-DN-BDI-VDI module. Supply voltage range is 21.8V~26.2V.
Warning: Ensure the safe electrical isolation between Extra Low Voltage and 24V power
supply.
①：Fast Fuse, Breaker, Circuit Protection
②：Filter
Figure 2.3: Connection of Backup Power Supply
2.3 Connected with DeviceNet system
Using 5 pins connector connecting with device net bus system.
Using bus connector and cable defined by ODVA. The type of cable used determines the
permissible maximum bus length and the transfer rate.
Max cable length = 5m.
1 GND Black
2 CAN_L Blue
3 screen Bare-wire
4 CAN_H White
5 24V Red
Figure 2.4 connector defines
All pins must be connected accurately, it can ensure bus communication safety and
accurately.
Figure 2.5: Installation of Terminal Blocks

EXP-DN-BDI-VDI User Manual V01 pag. 6
2.4 Connected with Inverter by Modbus
Communication module setting is regular to be 19200bps of baud rates, 8bit of data bits, and
1bit of stop bits. The parity bits do not exist in this module. The communication protocol is
ModBus RTU and ID is fixed at 1. Refer to the sections of communication parameters and
interface usage in the user manuals of inverter VDI100/BDI50 series series for more details
of communication setting and wiring.
2.5 Terminating resistors
DeviceNet requires a terminating resistor to be installed at each end of the trunk.
It is controlled by the 2-bit SW2 on the module to set in or not.
Figure 2.6 terminating resistor RT=120Ω
2.6 Baud rate and max transmit length
EXP-DN-BDI-VDI can support baud rate prescribed by ODVA.
125kbps
250kbps
500kbps
Bus maximum length is decided by cable type:
thin cable
thick cable
flat cable
ODVA prescribes the cable transmission length:
Baud rate
（kbps）
Max length of cable（m）
Thick cable Thick cable Thick cable
125
500
100
420
250
250
100
200
500
100
100
100

EXP-DN-BDI-VDI User Manual V01 pag. 7
2.7 Climatic condition
Temperature : -10°C~+40°C
Humidity : 95%.

EXP-DN-BDI-VDI User Manual V01 pag. 8
Chapter 3 Operation
3.1 Initial power up
EXP-DN-BDI-VDI can use net power, if power is lower because many devices in
devicenet system and, it also can use DC power with itself.
Before power up, check that you have connected the power supply, the bus connection
and the connection to the basic unit correctly.
If the EXP-DN-BDI-VDI unit is factory setting, the net address and baud rate of the station
must be set.
3.2 Networking Settings
EXP-DN-BDI-VDI module is built in the function of automatic identification drive. Use DIP
switch SW1_8 (8PIN) to set up. Set SW1_8 to be OFF if it is connected to the inverter of
VDI100/BDI50 series.
3.3 Network Address Settings and Self-adjust Baud Rate
In the net system, each device has one unique node address (MAC ID), user can set
node address form 0 to 63, and each node MAC ID must be unique in the net system.
EXP-DN-BDI-VDI module use SW1.1～SW1.6 to setting node address.
EXP-DN-BDI-VDI communication module supports the self-adjust communication baud
rate, three kinds of 123K, 250K and 500K in compliance with DeviceNet specifications. When
device is at power on, the module is only connected to network and obtains the baud rate
from the detection of network package. After the baud rate is self-adjusted, it is connected to
DeviceNet in normal operating mode.
After powering on the device at the basis of hardware setting address, it is disabled when
baud rate and network bits address are modified by network tool.

EXP-DN-BDI-VDI User Manual V01 pag. 9
Setting value of DIP Switch SW1 (DIP Switch ON is 1):
Functions DIP Switch position DIP Switch status Information
Adderss setting SW1_6~SW1_1
000000 Net address is 0
000001 Net address is 1
000010 Net address is 2
…… ……
111110 Net address is 62
111111 Net address is 63
Function setting
SW1_8
0 Connect
VDI100/BDI50 series
1 Reserved
SW1_7 Reserved
3.4 LED indicator
There are two LED indicators built in EXP-DN-BDI-VDI communication module to quickly
determine and monitor its state and bus communication.
Module status LED（MS）
Two colors LED (green and red) indicate EXP-DN-BDI-VDI module status, it can be
used watch the device working correctly or not.
MS LED information:
LED status Status Information Remark
Off No exist No power up
Green and red
flash
Self check Power up self checking
Green flash Waiting Connected with Inverter
basic unit error
Green on
Operation
The device is operating in a
normal condition.
Red flash Recoverable
Fault
Recoverable Fault. Communication
with Inverter basic
unit error.
Red on
Unrecoverable
Fault
The device has an
unrecoverable fault; may
need replacing.
Device hardware
error.

EXP-DN-BDI-VDI User Manual V01 pag. 10
Net status LED（NS）
Two colors LED (green and red) indicate the status of net bus; it can be used watch
EXP-DN-BDI-VDI status in the net.
NS LED information:
Net led（NS）Status Information Remark
Off No exist No power up
Off Not on line The device h
as not
completed the
Dup_MAC_ID test yet.
Green flash
On line , but not
connected
The device has passed
the Dup_MAC_ID test,
is on–line, but has no
established
connections to other
nodes.
Green on
On line and
connected
The device is on–line
and has connections in
the established state.
Red flash Connection time out IO connection time out
Red on
Communication
error
Dup_MAC_ID check
error or Bus-off event.
Red light flash Communication fault
and receive
point-to-point
protocol
Without supporting
the fault packet
message

EXP-DN-BDI-VDI User Manual V01 pag. 11
Chapter 4 Communication module functions
4.1 Net Description
DeviceNet is a connection based protocol. That is data exchange among devices should
be through connected cable.
Net stations can communication with IO message or explicit message.
4.1.1 IO message
IO message transmits application and process data in DeviceNet. The related IO
message, sent via higher CAN identifier, is always sent from producer to consumer. The
connection identifier provides the related information. The transmission is realized through
the connected object which is setup before message transmitted.
The most important feature of IO message frame is transmission data through CAN data
layer. The nod terminal judges the importance of the proceed data via the CAN message
identifier.
4.1.2 Explicit message
Explicit message is used on ordinary data exchange between two devices in DeviceNet. It
is sent via lower CAN identifier. Explicit message is point and point transmitted with the
typically request/response mode. It is commonly used in equipment configuration and trouble
shooting. The transmission of the explicit message should be through connected objects.
The Explicit message request specifies object, instance, property, and the called classificated
service through the path to the related object.
The most important feature of explicit message is the any parts of CAN identifier can not
be used in explicit message transmission protocol. All the protocol should be included in CAN
data layer which is used in connecting ID. Each Explicit message channel needs 2 CAN
identifier, one is for request message, and the other is for response message. The identifier is
already specified as the connection sets up.
4.1.3 EXP-DN-BDI-VDI deviceNet function
•Support self-adjust baud rate
•Support duplicate nodes and check the packet
•Support predefine master slave connection
•Support predefine explicit message connection
•Support predefine poll IO message connection
•Support explicit and IO message fragment

EXP-DN-BDI-VDI User Manual V01 pag. 12
4.2 EXP-DN-BDI-VDI Object Modeling
DeviceNet describes seeable data and function through the object modules. One
DeviceNet equipment can be defined as a group which is based on a clear device module.
DeviceNet object module describes all the EXP-DN-BDI-VDI communication function
which is the basic principal of the application layer.
Figure 4.1 Communication module object modeling
EXP-DN-BDI-VDI object class：
Class code Object class name Instance
number
0x01 Identity 1
0x02 Router 1
0x03 DeviceNet 1
0x04 Assemble 6
0x05 Connection 2
0x28
Motor
1
0x29
Control Supervisor
1
0x2A
AC Driver
1
0x64
Interface Object
1
0x65 Driver Object1 1
0x66 Driver Object2 1
Application class
Control
Optional
Must
Devicenet
Connection
IO
Explicit
DeviceNet
Router
Identity
Assemble
IN
OUT
SG2 extend
Interface
*Reserved

EXP-DN-BDI-VDI User Manual V01 pag. 13
The said object can be classified into 3 parts:
•Managing class
•Connection class
•Application class
4.2.1 Managing class
Define the data and function of the device should be supported by all the equipments in the
net.
•Identity object class
Identity object (class code: 01hex) provides identification of and general information about
the device. Such as vendor id, device type, device code, it also include device status, series
number, slaver name.
•Router object class
Router object (class code: 02hex) provides a messaging connection point through which a
Client may address a service to any object class or instance residing in the physical device.
4.2.2 Connection class
Define the message transmission in net.
•Devicenet object class
All net devices must be support devicenet object (class code: 03hex). It provides the
configuration and status of a DeviceNet port. DeviceNet product must support one (and only
one) DeviceNet object per physical connection to the DeviceNet communication link.
•Connection object class
All net devices must support at least one object instance. It provides operation net data
by IO message or explicit message, producer/consumer data router and length.
4.2.3 Application class
Define the certain data and function of the equipment (application object, parameter
object, and assemble object).
•Application object class
Extend object (class code: 28hex、2Ahex、65hex、66hex) provides the parameters of
Inverter, it can be used in automation project.
•Assemble object class
Assemble object (class code: 04hex) allocates and manages the internal resources
associated with both I/O and Explicit Messaging Connections.

EXP-DN-BDI-VDI User Manual V01 pag. 14
4.3 Object Class Define
4.3.1 Identity Object
Class code：0x01
The Identity Object is required on all DeviceNet devices. It provides product
identification and general information.
Class attribute
Attribute
ID
Access
rule
Name Data
type
Description of
Attributes and
Semantics
Default
value
Byte
number
1 Get Class Revision UINT Revision of this class 1 2
Instance
Attribu
te ID
Access rule Name Data type
Description of
Attributes and
Semantics
Default
value
Byte
numb
er
1 Get Vendor ID UINT Id
entification of each
vendor by number.
8988 2
2 Get Device Type UINT
Indication of general
type of product.
0x0C 2
3 Get Product Code UINT
Indication of a
particular product of an
individual vendor.
0x07 2
4 Get Revision STRUCT
Revision of the item the
identity object
represents.
2
Major USINT Major revision. 0x02 1
Minor USINT Minor revision. 0x01 1
5 Get Status WORD Present state of the
device as represented
by the state transition
diagram.
0 = Nonexistent
1 = Device Self testing
2 = Standby
3 = Operational
4 = Recoverable Fault
5 = Major
Unrecoverable Fault
0x00 2
6 Get Serial UDINT Serial number of
number.
0x12345
678
4
7 Get Product Name STRUCT Product Name 32

EXP-DN-BDI-VDI User Manual V01 pag. 15
BYTE Length 11 1
STRING Name EXP-DN-B
DI-VDI
11
8 Get State USINT Device status 0x00 1
Class Service
Service code Service Name Description
0x0E Get Attribute Single Returns the contents of
the specified attribute.
Instance Service
Service code Service Name Description
0x0E Get Attribute Single Returns the contents of
the specified attribute.
0x05 Reset
Invokes the Reset
service for the device.
4.3.2 Router Object
Class code：0x02
The Message Router Object provides a messaging connection point through which a Client
may address a service to any object class or instance residing in the EXP-DN-BDI-VDI devices.
Class Attribute
Attribute
ID
Access
rule
Name Data
type
Descriptio
n of
Attributes and
Semantics
Default
value
Byte
number
1 Get Class Revision UINT
Revision of this class
1 2
Class Service
Service code Service Name Description
0x0E Get Attribute Single
Returns the contents of
the specified attribute.
Instance Attributes
No.
Instance Service
No.
4.3.3 DeviceNet Object
Class code：0x03

EXP-DN-BDI-VDI User Manual V01 pag. 16
The DeviceNet Object contains information about the EXP-DN-BDI-VDI DeviceNet
interface configuration.
Class Attribute
Attribute
ID
Access
rule
Name Data
type
Description of
Attributes and
Semantics
Default
value
Byte
number
1 Get Class Revision UINT
Revision of this class
2 2
Instance Attribute
Attribute
ID
Access
rule
Name Data
type
Description of
Attributes and
Semantics
Default
value
Byte
number
1 Get Mac ID USINT Node Address, Range
0~63
63 1
2 Get Baud Rate USINT Baud rate setting
0 125K
1 250K
2 500K
0 1
5 Get Allocation STRUCT Allocate Master/Slave
Connection Set
2
Choice BYTE Indicates which
Connections from the
Predefined
Master/Slave
Connection Set is to
be
allocated/configured
for use by the Master.
0x00 1
My Master USINT
MAC ID of Master
0xFF 1
8 Get
Mac Switch
Value
USINT
Actual value of Node
1
Class Service
Service code Service Name
Description of service
0x0E Get Attribute Single Returns the contents of
the specified attribute.
Instance Service
Service code Service Name
Description of service
0x0E Get Attribute Single
Returns the contents of the specified attribute.

EXP-DN-BDI-VDI User Manual V01 pag. 17
0x4B Allocate Master Slave
Connection Set
Requests the use of the Predefined Master/Slave
Connection Set.
0x4C Release Master Slave
Connection Set
Indicates that the specified Connections within
the Predefined Master/Slave Connection Set are
no longer desired. These Connections are to be
released (Deleted).
4.3.4 Connection Object
Class code：0x05
The Connection Class allocates and manages the internal resources associated with
both I/O and Explicit Messaging Connections.
Class Attribute
Attribute
ID
Access
rule
Name Data
type
Description of
Attributes and
Semantics
Default
value
Byte
number
1 Get Class Revision UINT
Revision of this class
1 2
Instance 1 : Explicit Message Connection
Attribu
te ID
Access
rule
Name Data
type
Description of
Attributes and
Semantics
Default
value
Byte
number
1 Get State USINT 0 = non-existent
3 = established
5 = Deferred Delete
00 1
2 Get Instance Type USINT
Indicates either I/O or
Messaging Connection:
0 explicit connection, 1
IO connection
00 1
3 Get
Transport Class
Trigger
BYTE Defines behavior of the
Connection
0x83 1
4 Get
Produced Conxn
ID
UINT
Placed in CAN
Identifier Field when
the Connection
transmits, ****** is MAC
ID
10******011 2
5 Get
Consumed Conxn
ID
UINT
CAN Identifier Field
value that denotes
message to be
received, ****** is MAC
ID
10******100 2
6 Get
Initial Comm
BYTE
Defines the Message
0x21 1
