GEIGER INline System GSI56 r Series User manual

1
www.geiger.de EN
EN
DE Original-Montage- und
Betriebsanleitung
Original assembly and
operating instructions
Notice originale de montage
et d’utilisation
Instrucciones originales de
instalación y funcionamiento
Istruzioni originali di installazione
e funzionamento
EN
FR
ES
IT
GEIGER INline System GSI56..r
with mechanical end stop for the facade technology

2Gerhard Geiger GmbH & Co. KG | 100W1577 0920V000en
EN
EN
Index
1. General information..................................................................2
2. Guarantee ..................................................................................2
3. Intended use..............................................................................3
4. Safety instructions....................................................................3
5. Safety instructions for assembly ............................................4
6. Assembly instructions .............................................................5
7. Information for the specialist electrician................................6
8. Setting the end positions .........................................................7
9. What to do if…...........................................................................8
10. Maintenance ..............................................................................8
11. Technical data ...........................................................................9
12. Declaration of conformity ......................................................10
13. Notes on waste disposal ........................................................ 11
1. General information
Dear customer,
By purchasing a GEIGER motor you have decided on a quality product from GEIGER.
Thank you very much for your decision and the condence placed in us.
Before you put this drive into operation please observe the following safety instructions. It
serves for the prevention of danger and for the avoidance of personal injury and damage to
property.
The installation and operating instructions contain important information for the installer, the
specialist electrician and the user. Please pass on these instructions if you transfer the product.
These instructions should be kept by the user.
2. Guarantee
In the case of incorrect installation contrary to the installation and operating instructions and/
or constructional modication, the legal and contractual guarantee for property damage and
product liability lapses.

3
www.geiger.de EN
EN
3. Intended use
The motors of the GSI 56..r series with mechanical end stop are designed for operation with
Venetian blinds that are within a façade whereas the motor is outside the cavity.
The motors may not be used for the operation of roller grilles, garage doors, furniture and lifting
tools.
GJ 56 xx x
Design options
Torque in Nm
Motor diameter
GEIGER INline System
4. Safety instructions
I ATTENTION: Important safety instructions. For personal safety,
it is important to follow these instructions. Please keep these
instructions for future reference.
fDo not allow children to play with stationary controls. Keep remote controls away
from children.
fThe installation is to be checked regularly for defective balance, signs of wear or
damaged cables and springs, if relevant.
fDo observe the moving sun protection system and keep persons away until it has
closed completely.
fWhen operating the manual release with the sun protection system open, please be
cautious as it can fall down quickly if springs or tapes wear off or are broken.
fDo not operate the device if operations such as, for example, window cleaning are to
be carried out in the vicinity.
fDisconnect the automatic controlled device from the mains power supply if opera-
tions such as, for example, window cleaning are being carried out in the vicinity.
fDuring operation observe the danger zone.
fDo not use the installation if people or objects are in the danger zone.
fUrgently shut down damaged installations until repair.
fUnconditionally shut down the unit during maintenance and cleaning operations.
fPinching and shearing points are to be avoided and must be secured.
fThis appliance can be used by children aged 8 and above and persons whose
physical, sensorial or mental capacities are impaired, or who have no experience or
know-how if they have been supervised or been given instructions on the use of the
appliance and if they understand the possible resulting dangers. Children are not
permitted to play with the device. Cleaning and maintenance should not be carried
out by children.
fThe rated sound pressure level is less than 70 dB(A).
fDisconnect the device from the mains power supply for maintenance and replace-
ment of parts.
If the motor is disconnected via a plug connection the operator must be able to
control - from any place to which it has access – that the plug is removed.
If this is not possible - due to design or installation - the disconnection from the
power supply must be ensured via locking in the disconnected position (e.g. isolator).
fThe motor tube can get very hot during prolonged use.
When working on the unit, do not touch the tube before it has cooled down.

4Gerhard Geiger GmbH & Co. KG | 100W1577 0920V000en
EN
EN
5. Safety instructions for assembly
I ATTENTION: Important safety instructions. Follow all installation
instructions, as incorrect installation can lead to serious injuries.
fWhen mounting the motor without any mechanical protection of the driven parts and
of the tube which may become hot, the motor must be installed at a height of at least
2.5 m above the ground or of another level which provides access to the drive.
fBefore the motor is installed, all cables which are not needed are to be removed and
all equipment which is not needed for power-operated actuation is to be put out of
operation.
fThe actuating element of a manual release must be mounted at a height of less than
1.8 m.
fIf the motor is controlled by a switch or pushbutton, the switch or pushbutton must
be mounted within eyeshot of the motor. The switch or pushbutton must not be
located in the vicinity of moving parts. The height of installation must be at least
1.5mabovetheoor.
fPermanently installed control devices must be attached visibly.
fIn case of devices extending horizontally, a horizontal distance of at least 0.4 m must
berespectedbetweenthefullyextendedpartandanyotherxedelement.
fThe rated speed and the rated torque of the motor must be compatible with the
device.
fThe mounting accessories that are used must be designed in accordance with the
selected rated torque.
fGood technical knowledge and good mechanical skills are necessary for the motor
installation. Incorrect installation can lead to serious injury.
Electricalworkmustbecarriedoutbyaqualiedelectricianinaccordancewiththe
regulations in force locally.
fOnly use connecting cables that are suitable with the environmental conditions and
which meet the construction requirements. (see accessories catalogue)
fIf the device is not equipped with a connecting cable and a plug, or other means for
disconnecting from the mains with a contact opening on each pole according to the
conditions of the overvoltage category III for full disconnection, a disconnecting
device of this type must be incorporated into the permanently installed electrical
installation according to the wiring rules.
fDo not mount the connecting cables near hot surfaces.
fA plug for the disconnection of the motor from the power supply must be accessible
after installation.
fDamaged connecting cables must be replaced by GEIGER connecting cables of the
same type.
fThe device must be mounted as described in the installation instructions. Fixations
shall not be made with adhesives since they are regarded as unreliable.

5
www.geiger.de EN
EN
6. Assembly instructions
I A prerequisite for a safe functioning of our system components is
a proper assembly taking into account the relevant standards and
guidelines in the production of element facades.
I The system components supplied by GEIGER may not be repro-
cessed or altered, otherwise the warranty expires.
I Before installation, the motor and the other system parts should be
checked for visible damage.
Connecting element:
The connecting element must be screwed at right angles to the mounting surface. It is important
to ensure that the mounting surface is cleaned and the seal of the connecting element ts
cleanly and evenly on the mounting surface.
Please make sure that the connecting element and the facade element are rmly and durably
connected. Tightening torques depend on the facade element and must be determined by the
facade manufacturer.
The tightness of the connection between the connecting element and the facade element must
be checked on site during installation.
A centering bore optionally used for double-walled proles may not be larger than + 0.3 mm
compared to the centering collar.
Cavity gear:
The cavity gear must be xed within the cavity in such a way that the hexagonal rod of the
connecting element can be inserted without tension into the hexagonal holding of the gear.
The screws must be secured with a screw-lock.
The hexagonal rod of the connecting element must t exactly into the hexagonal housing of the
anged gear and must not be subject to tension during operation.
Motorwithangedgear–Parallelmounting:
Screw mounting
For parallel mounting (radial), the drive is
placed on the 7 mm hexagonal rod of the
connecting element. The drive is attached
to the xing bracket on the angle gear using
2 galvanized countersunk head screws DIN-
EN-ISO 14581 8.8 M5 x 10 and a tightening
torque M = 2Nm.
The screws must be secured with a high-
strength screw-lock.
The hexagonal rod of the connecting element
must t exactly into the hexagonal housing of
the anged gear and must not be subject to
tension during operation.

6Gerhard Geiger GmbH & Co. KG | 100W1577 0920V000en
EN
EN
7. Information for the specialist electrician
H Caution: Important installation instructions.
Please follow all installation instructions
since incorrect installation can lead to
the destruction of the motor and the
switching unit.
Motors with mechanical limit stops cannot be connected in
parallel but must be connected via a multipolar switch or a
cut-off relay.
Switches and controls must not execute simultaneous UP
and DOWN commands.
When changing the running direction the switchover must
be effected through an off-position.
With a three-phase network, please use the same external
conductor in order to control the UP and DOWN directions.
Connecting cables with plug connectors of the Hirschmann
Company are tested and approved with couplings of the
Hirschmann Company.
12 3
PE N
L1
N
PE
Electronic /
mechanical
limit stop
blue brown black green/yellow
Mains: 230V / 50Hz

7
www.geiger.de EN
EN
8. Setting the end positions
The GSI56.. has two integrated, freely adjustable limit switches. If required, the factory settings
can be changed at any time and as often as you like.
I Depending on the installation position of the motor and the features
of the adapted gear, the upper and lower end position can swap!
The arrow embossed on the motor (connector side) indicates the
rotation direction of the sun protection when moving upwards in the
standard installation.
Standard Installation
If the sun protection moves upwards in this rotation direction,
then:
• the black setting key controls the upper end position
• the white setting key controls the lower end position
Setting the upper end position
1. Move the blind approximately 300 mm below the required
end position.
2. Press the black setting key.
3. Move the blind upwards to the selected nal position.
4. Move the blind about 6 seconds downwards until the
black setting key jumps back audibly (click).
The upper end position is stored.
Setting the lower end position
1. Move the blind approximately 300 mm above the required
end position.
2. Press the white setting key.
3. Move the blind downwards to the selected nal position.
4. Move the blind about 6 seconds upwards until the
white setting key jumps back audibly (click).
The lower end position is stored.
Inverted installation
If the sun protection moves downwards in this rotation
direction, then:
• the black setting key controls the lower end position
• the white setting key controls the upper end position
Setting the upper end position
1. Move the blind approximately 300 mm below the required
end position.
2. Press the white setting key.
3. Move the blind upwards to the selected nal position.
4. Move the blind about 6 seconds downwards until the
white setting key jumps back audibly (click).
The upper end position is stored.
Setting the lower end position
1. Move the blind approximately 300 mm above the required
end position.
2. Press the black setting key.
3. Move the blind downwards to the selected nal position.
4. Move the blind about 6 seconds upwards until the
black setting key jumps back audibly (click).
The lower end position is stored.

8Gerhard Geiger GmbH & Co. KG | 100W1577 0920V000en
EN
EN
9. What to do if…
Problem Solution
Motor does not run. • Motor not plugged in.
Please check the plug connection.
• Check connecting cable for possible
damage.
• Check the mains voltage and allow the
cause of the voltage breakdown to be
tested by a specialist
electrician.
Instead of in the upwards direction, motor
runs downwards.
• The control leads are interchanged.
Exchange black/brown control leads.
Motor only runs in one
direction.
• Motor in the end position.
Run motor in the opposite direction.
Readjust teh end positions, if necessary.
After running several times,
the motor breaks down and
no longer responds.
• The motor became too hot and has
switched off.
Try it again after a cooling time of about
15 min.
After setting of the lower end position the
blind only runs in DOWN direction.
• The motor has been installed upside down
(see assembly note).
10. Maintenance
The drive is maintenance-free.

9
www.geiger.de EN
EN
11. Technical data
Technical data GSI56..r with mechanical end stop
GSI5606r GSI5610r
Voltage 230 V~/50 Hz
Current 0,40 A 0,60 A
Cos Phi (cosj)> 0,95
Inrush current (factor) x 1,2
Power 93 W 135 W
Torque 6 Nm 10 Nm
Speed 26 rpm
Protection class IP 54
Limit switch range 80 rotations
Operating mode S2 4 min
Sound pressure level1) 34 db(A) 35 db(A)
Length2) 301 mm 311 mm
Diameter 55 mm
Weight2) ca. 1,50 kg ca. 1,70 kg
Storage temperature/
Humidity
T = -15°C .. +70°C / dry and non-condensing place
1) The average sound pressure level data are intended for guidance only. The values were determined by
GEIGER at a distance of 1 m, with a hanging motor at idle speed and averaged over 10 seconds. There is
no reference to any specific test standard.
2) With angel gear GSI1…: total length + 52 mm / weight + 0,4 kg
Subject to technical modifications. Please find information to the ambient
temperature range of our GEIGER motors under www.geiger.de

10 Gerhard Geiger GmbH & Co. KG | 100W1577 0920V000en
EN
EN
12. Declaration of conformity
Current declarations of conformity are available under www.geiger.de
Schleifmühle 6 |D-74321 Bietigheim-Bissingen
Phone [phone] |Fax [phone] |[email protected] |www.geiger.de
Sitz Bietigheim-Bissingen |Amtsgericht Stuttgart HRA 300591 | USt-IdNr. DE145002146
Komplementär: Geiger Verwaltungs-GmbH |Sitz Bietigheim-Bissingen |Amtsgericht Stuttgart HRB 300481
Geschäftsführer: Roland Kraus |WEEE-Reg.-Nr. DE47902323
Gerhard Geiger GmbH & Co. KG
300H0204
EU Declaration of Conformity
Bietigheim-Bissingen, 25.06.2019 Roland Kraus (General Manager)
Product designation:
Venetian blinds motor, motor for rolling shutters, motor for awnings
Type designation:
GR45.. GJ56..
GS45.. GS56..
GU45.. GSI56..
GB45..
Applied directives:
2006/42/EC
2014/30/EU
2014/53/EU
2011/65/EU + (EU)2015/863 + (EU)2017/2102
Applied standards:
DIN EN 60335-1 (VDE 0700-1):2012-10; EN 60335-1:2012
DIN EN 60335-1 Ber.1 (VDE 0700-1 Ber.1):2014-04; EN 60335-1:2012/AC:2014
EN 60335-1:2012/A11:2014
DIN EN 60335-2-97 (VDE 0700-97):2017-05; EN 60335-2-97:2006+A11:2008+A2:2010
+A12:2015
DIN EN 62233 (VDE 0700-366):2008-11; EN 62233:2008
DIN EN 62233 Ber.1 (VDE 0700-366 Ber.1):2009-04; EN 62233 Ber.1:2008
DIN EN ISO 12100:2011-03; EN ISO 12100:2010
DIN EN 55014-1:2012-05; EN 55014-1:2006 + A1:2009 + A2:2011
DIN EN 55014-2:2016-01; EN55014-2:2015
DIN EN 61000-3-2:2015-03; EN 61000-3-2:2014
DIN EN 61000-3-3:2014-03; EN 61000-3-3:2013
ETSI EN 301 489-1 V1.9.2(2011-09)
ETSI EN 301 489-3 V1.6.1(2013-08)
ETSI EN 300 220-2 V3.1.1(2017-02)
Authorized representative for technical data:
Gerhard Geiger GmbH & Co. KG
Address:
Schleifmühle 6, D-74321 Bietigheim-Bissingen
en
Gerhard Geiger GmbH & Co. KG
Antriebstechnik
Schleifmühle 6
D-74321 Bietigheim-Bissingen
0619100W1518

11
www.geiger.de EN
EN
13. Notes on waste disposal
Recycling of packaging materials
In the interest of environmental protection, please contact your local government’s recycling or
solid waste management department to learn more about the services it provides.
Waste disposal of electric and electronic equipment
Electrical and electronic equipment must be collected and disposed of separately in accordance
with EU regulations.

12 Gerhard Geiger GmbH & Co. KG | 100W1577 0920V000en
EN
EN
For technical questions, please call our service team at: [phone].
They will be happy to assist you.
Gerhard Geiger GmbH & Co. KG
Schleifmühle 6 | D-74321 Bietigheim-Bissingen
T [phone] | F [phone]
[e-mail] | www.geiger.de
