Geller AX-100 User manual

AX-100
AX-100 QUICK SET-UP GUIDE

1
AX-100
QUICK SET-UP GUIDE
For further information please refer to the standard
Operating Manual supplied with the AX-100
AX-100 Features Covered in this Guide
916 Departments – Programmable Alpha
9200 Plu’s – Programmable Alpha
958mm Single Station Audit Thermal Receipt Printer
9Programmable Customer Receipt Header message and Trailer Message
9Electronic Journal & Management Reports
9PC Link ‘David’ Geller Utility for Programming
9Soft Programmable Keyboard Layout
9Tax Rates
9Receipt On/Off toggle with optional Receipt after sale
9Clerk IDs with Optional passwords
9Programmable Transaction Names
9Negative Items
9Compulsory Cash Declaration
9Training Mode
9Calculator Mode
9Management control with Passwords for reports and Void Functions
Optional - An AX-100 Comms kit is available from your dealer as an option
for programming the cash register via your PC. This includes a 2 metre Cable,
AX-100 David Utilities and supporting documentation.

2
INDEX
DESCRIPTION Page
AX-100 FEATURES 1
INDEX 2
PAPERROLLS 3-4
PROGRAMMING LAYOUT 5
DIAGRAM EXPLANATION 6
DATE AND TIME SETTINGS 7
FLAG SET-UP PROCEDURES 8
CHARACTER CODE TABLE 9
PROGRAMMING DEPARTMENTS 10
HALO – HIGH AMOUNT LOCK OUT 11
PROGRAMMING THE RECEIPT LOG 12-15
VAT/TAX PROGRAMMING 16
PASSWORDS 17-19
PROGRAM CONFIRMATION 20
ERROR CODES 21
REPORTS – End of Day Report Z1 22
REPORTS – Electronic Journal 23
DISPLAYING A REPORT 24
PC COMMUNICATIONS 25
CABLE CONFIGURATION 26
AX-100 DAVID UTILITY 27
GLOSSARY 28-32

3
PAPER ROLLS
Installing the Paper Roll into your AX-100
Your cash register comes fitted with a thermal printer which uses a 58mm paper
roll. If a customer receipt is not always required, then there is a paper saving
option available by pressing the button on the keyboard (this is indicated
by an LED on the display). A receipt is available on request after the sale by
depressing the button.
Fig 1
Before installing the paper roll, be sure to do the following:
Orient the paper roll so that it rotates in a counter clockwise direction, as shown in
above.
Note
1. As thermal paper is used, it has a right and wrong side for printing. If you
install it the wrong way round (the heat sensitive side away from the print
head) no printing will be possible.
2. Carefully avoid touching the metal paper cutter when removing the paper
cover, it is very sharp.

4
Installing the Paper Roll for the Receipt
1. Ensure the Control lock is in the ‘R’ Position
2. Simply lift up the printer cover from the front as shown below in Fig 2
Fig 2
3. Set the paper roll gently into the paper location as shown in Fig 3
4. Insert the end of the paper roll into the paper entrance as shown in Fig 4
(At this point the paper will feed automatically into position)
5. Press and hold the FEED button until approx 30cm of paper has fed through
6. Replace the printer cover, ensuring that the end of the paper is fed through
the paper tear off slot correctly.
Fig 3 Fig 4

5
PROGRAMMING LAYOUT
This is the default programming layout which is always activated when the key is
turned to the ‘P’ position. It is advisable to leave the function buttons in their
original positions. It will make it easier to follow the programming instructions.

6
CASH TEND X/
T
IME
1
9
Diagram Explanation
We have used simple diagrams to indicate programming procedures.
Indicates the Control Lock and the letter describes the position of the
key.
Indicates a numeric button, the number inside the circle is the
button required to be depressed.
Indicates the function button required to be
depressed.
AX-100
SYSTEM CLEAR
WARNING
This procedure will clear all sales data and program settings
Power off by removing plug from wall socket!
The message ‘SYSTEM CLEAR’ will print on the receipt. The ECR’s memory
has now been cleared.
P
P
CLR INSERT PLUG/
POWER ON CLR
(HOLD DOWN) (RELEASE AFTER 5 SECONDS)

7
DATE &TIME SETTINGS
Setting the Date
Example: 20070320 = 20th March 2007
Note:
To check the date, Press the button in the ‘R’ position. Press
again to show the Time.
Setting the Time
Note:
To check the time, Press the button in the ‘R’ position. The
Time will be shown on the display. Pressing the button again
toggles the date and time
X/
T
IME
1
P
CASH
TEND
0
2
0
7
0
3
2
0
P
X/
T
IME
X/
T
IME
2
P
CASH
TEND
3
1
0
0
P
X/
T
IME
X/
T
IME
X/
T
IME
R

8
FLAG SET-UP PROCEDURE
The following flag settings will manually configure your AX-100
for a simple operation without the use of the David Software
(Decimal point, receipt print)
(Second receipt, programmable soft keyboard)
(Date format, full size font print)
(Card over tender, no electronic journal)
For an explanation of all the flags, please consult the manual
supplied with the machine.
1
1
0
0
0
0
RA
0
1
CASH
TEND
P
4
1
1
0
0
0
RA
0
0
CASH
TEND
P
1
7
1
0
0
0
RA
0
1
CASH
TEND
P
0
6
1
0
1
0
0
RA
0
0
CASH
TEND
P
0

9
CHARACTER CODE TABLE
The character code table is used as a reference for text input via
Departments, PLUS, Receipt Logos, Clerk Names and Transaction Names
Example
To program the letter N, the value 4E should be entered
To program the letter T, the value 54 should be entered
To program a Space, the code 20 should be entered
To program a Double Size Character, the code 12 should be entered
Select this character first
