Gemini GWSF12 User manual

1
--
Before using your product for first time,please read this instruction manual.
在使用本產品前，請仔細閱讀本說明書並保存好。

2
Safety Precautions
Thank you for choosing our products. For your consumer rights and interests, please
carefully read the warranty card and keep it properly. Items related to the product
warranty are specified as follows:
-This appliance is not intended for the use by person (including children under 8 years
old), with reduced physical, sensory or mental capabilities or lack of experiences and
knowledge unless they have been given initial supervision or instruction concerning
use of the appliance by a person responsible for their safety.
-Please read and comply with the user manual prior to the initial operation of your
appliance and keep the user manual for later use.
-Do not operate the appliance in way that does not mentioned at the user manual to
avoid accident.
-Children shall not play with the appliance, power cord, any parts and accessories at
any time. Cleaning and user maintenance shall not be made by children unless they
are older than 8 and supervised.
-Never connect to power supply socket and turn on the appliance if the blades, front
/ rear guard are not welly assembled to avoid serious accident.
-Do not turn on the appliance if there is no people supervision.
-Do not let children and pets get close with it, close adult supervision is necessary
when appliance is used by or near children and pets.
-If the appliance fall down, unplug from power supply socket immediately, place the
appliance well on floor, check all parts to confirm no problems, then appliance can
be used again. If you are not sure the appliance is safe to use, take it to repair center
for checking.
-This appliance is not water resistance, never immerse the main body, power plug,
power cord and remote control in water nor rinse it under the tap to avoid accident.
Only use soft dry cloth to clean the main body case.
-This appliance is not water resistance, never use and keep this appliance at or near
bathroom, shower nozzle, swimming pool or outdoor.
-Do not expose the product to high temperatures, hot gas, steam or damp heat from
other sources and under sunlight. Do not place the product on or near an operating
or still hot stove or cooker, do not use the appliance under humidity environment.
-Do not place any combustible and explosion object such as petroleum, paint around
the appliance. Do not use the appliance in an area full of combustible gas. Do not
use spray pesticide or other spray items near the appliance.
-Any time when appliance is operating, do not use anything to cover the front, rear
guard and mist outlet.
-When appliance is operating, do not get close with the front and rear guard to avoid

3
twisting of hair by the blades and get injury.
-Do not place the appliance near curtain, clothes to avoid being inhaled and damage
the appliance.
-Never put your fingers and other objects into the front and rear guard, or any moving
parts of the appliance to avoid injury. Especially take care of children.
-Do not adjust the appliance facing angle horizontally by hands to avoid appliance
damages.
-Do not adjust the facing angle when the appliance is operating, adjust only when
appliance is turned off.
-This appliance must be placed on level and solid surface.
-Do not carry and move the appliance when operating. To carry and move the
appliance, make sure it is turned off and unplug from power supply socket.
Caution
－Check if the voltage indicated on the appliance corresponds to the local mains
voltage before you connect the appliance.
－Do not use the appliance if the plug, the mains cord, the appliance itself, water tanks
and mist transfer pipe is damaged to avoid accident. It must be repaired by our service
center to avoid a hazard. Never repair, assembly and re-equip by yourself.
－Never press, roll, bend the power cord, and keep the power cord away from hot
surfaces.
Never pull the power cord to avoid loosen. And do not put the power cord under carpet
and any other things to avoid damages.
－Power cord must not be stepped or pressed by any things, or bitten by any pets to
avoid damages.
－Do not connect with external timer. This appliance is not intended to be operated by
means of an external timer or a separate remote-control system.
－Do not use the same power sources with other appliances to avoid overload.
－Do not plug or unplug the appliance into power socket with wet hands.
－Make sure the air circulation is enough when using the appliance.
－If you drop the screw inside the appliance when install or uninstall the front guard,
please send the appliance to repair service center for checking and handle.
－Do not disassembly the appliance by yourself.
－Do not expose yourself to wild generated by the appliance for a long time, especially
elder, children and sick people, it may cause health related issues.
－Do not operate the appliance under humid, dusty environment and surface. And do
not keep the appliance under sun light.
－Do not give impact or fall the appliance and press the front and rear guard to avoid

4
damages and accident.
－Before cleaning, assembling or disassembling, make sure the appliance is turned off
and unplug from power supply socket, and it is completely cool down.
－Clean the appliance regularly to avoid too many dust on blades, rear and front
guard.
－Never use scouring pads, abrasive cleaning agents or aggressive liquids such as
petrol or acetone to clean the appliance.
－The appliance is mainly for indoor and household use only.
－If the appliance has abnormal smell, smoke, overheat or abnormal noise or any
problems occur, stop using the appliance immediately, unplug from power supply
socket.
－Remote control use one piece CR2025 3V battery, if you find the remote control is not
function, it may be battery running out of power, change a new battery immediately.
－If you do not use the appliance for long period of time, take the battery out from
remote control, keep it at a safe place which is not easily access by children and pets.
－All photos are for reference only.
Warning
1.Do not connect or disconnect with wet hands as it will cause short circuit or electric
shock.
2.Please keep the fans in steady state using.
3.Without the guidance of technicians, automatic dismantling is not allowed.The inside
of the machine is charged body, so do not wash or plush.
4.Do not cut, damage, pull, twist, knot or press the power wire.
5.Do not put your fingers or other objects into the fan net frame.
6.When cleaning and maintaining this product, the power plug must be disconnected.
7.Do let the children to operate the fan by themselves.
8.Do not exertly more the oscillation manually,because Up-Down and Left-Right
Oscillation is by automatically.

5
The structure of the product
(1)Rear Grille
(2)Front Grille
(3)Blade
(4)Back Cover
(5)Extension Tube
(6)Extended Tube
Switch
(7)Control Display
(8)Remote Control
Placement
(9)Infrared Receiving
Point
(10)Pedestal
(11)AC Connector
(12)Base Fixed Knob
Accessories
Fan *1
User Manual *1
Warranty Card *1
Power Line *1
Remote Controller *1
Bottom View

6
Product Introduction
1.Introduction of Control Panel
1.LED Display
2.ECO Wind
Indicator
3.Natural Wind
Indicator
4.Sleep Wind
Indicator
5.WiFi Function
Indicator
6.Timer Key
7.Model
Conversion Key
8.Up-Down Swing Key
9.Left-Right Oscillation
Key
10.Wind Speed
11.On/Off Key
⚫ON/OFF Key :After connect the main power plug to wall socket,press the
ON/OFF key to turn the fan on.It will be started at a default speed of 8 level once
it is on.Press the key again to turn off the machine.
⚫TIMER OFF Key :Press Timer Off Key to set the turn off hour,the fan will switch
between 1h-9h.Without operation the fan after 5 seconds,the display screen shows
the wind speed and timing switch alternatively switching.
⚫SPEED Key :Product has 12 speed with LED display, from 01-12 as speed. You can
adjust the speed by press “SPEED”key.
⚫SWING Key : Press the swing key to activate the up & down vertical direction of
fan head.
⚫OSC Key : Press OSC key to start left & right.
⚫MODE Key : There are ECO Wind Mode 、 Natural Wind Mode 、 Sleep Wind
Mode.Press the mode key to choose the mode.Under the ECO Wind Mode,the display
screen will display the ambient temperature.The fan will adjust the wind speed into
ideal fan speed according to the ambient automatically.Under the Natural Wind
WiFi
SLEEP
NATURAL
ECO
ON/OFF SPEED OSC SWIMG TIMER MODE

7
Mode, the fan will work at the system setting gear speed.The fan will be quite
operation in Sleep Wind Mode which is soft wind for sleeping.
2.Function Key of Remote Controller
(1) ON/OFF
(2) TIMER
(3) SPEED+
(4) SPEED-
(5) OSC:Left-right direction
(6) SWING:Up-down direction
(7)MODE:ECO/NATURAL/SLEEP
Note:
1. The remote controller is normally used within 6 meters in the front of the fan and the
deviation angle is within 45 degrees.
2. Put a CR2025 battery on the holder,make sure the "+" side face top, and face down.
3. There has a battery inside the remote controller, please take off the insulating strip
before use.After the battery's power is using out,please throw according to battery
classification collection.

8
3. Swing & Oscillation
Press the OSC & SWING key to turn on the automatic oscillation mode.
Left-right oscillation in 100° by automatically Up-down swing in 90° by automatically
Note:It is forbidden to twist the fan head at up-down or left-right oscillation direction
over 90° manually.
Signal Receiver

9
4.Installation
1.Take out the fan's assemble parts
Take out the fan's assemble parts from the packaging and disassemble the fan parts
from the rear head grille.Rotate the front grille at clockwise direction,remove the front
grille and take out the blade.
2.Install the fan Pedestal
3.Install the Rear Grille to motor head
(1) Firsyty remove the PVC casing,align
the motor and pilar with the base
socket the direction shown,and
insert the lower end of the pillar
into the base socket
(3) Turn the screw clockwise direction
and tighten the base bolt to fix it
(2) Put the screw into the bottom
Screw
PVC Casing
Base Socket
Pillar

10
Put the position of the fan rear grille on the motor head（STEP1）, and tighten the knob
clockwise to fix the rear grille cover to motor head(STEP2).
4.Install the Fan Blade
Put fan blade to the motor shaft, and tighten the knob in clockwise direction(STEP1).
Then use the screw to fix the front grille.
Note:Please make sure the fan blade is tightened, otherwise there will be danger!
Cleaning and Maintenance
－Warning
Before clearing, please turn off the power switch and pull out the plug, do not spray
water or spray mist directly on the fan.
－Cleanable Parts
Use the screwdriver to remove the screws between the front grille and the rear grille. Use
the soft cloth or sponge and neutral detergent to wipe the exterior. And let the parts
drying completely after cleaning.

11
See below Images:
－Cleaning of external non detachable parts
Use the soft cloth in warm water below 40°,then wipe off the fan surface stains.
－Storage
If product is not used for a long time, clean it and dry it, then put it into the original
packing box and store in a dry place.
Mobile APP’s TUYA Operation Manual
Note:User needs to install Tuya App correctly to connect the WiFi function of the fan
successfully!
1.Download Tuya Smart APP
Please use your mobile phone to scan the
QR code, then download and install the
Tuya Smart APP for mobile control function,
Please reference the APP interface below.
Fixed Screw

12
2.Tuya App Connection Instruction
1.Dowload TUYA
APP from APP
store.
2.Create a new user
account.
3.Register an
account to get
verification code.
4.Enter the
verification code.
5.Set your
password.
1
6.Tap the "+" icon
on the right corner
of "Home" page to
enter into "Select
Device Type"
interface.
5
4
6

13
7.Select the "Fan"
option in
“Small Home
Appliances”.
1
8.Choose the
local WiFi routers
(Only supports
2.4GHz) and enter
the correct
password,then
click next to
complete.
9.In shutdown
mode of the fan
after connect the
main p ower,press
the fan's ON/OFF
key and MODE
key at the same
time until the WiFi
indicator light is
released from
slow flash to fast
flash,then loosen
your grip,and
according to the
instructions to
operate the APP.
1
10.Select the
corresponding
option according to
the WiFi indicator
status prompt.
8

14
1
13.The fan can be
controlled after
connecting the
device.
14.Press the
"Switch" key to turn
on the fan.The fan
wind speed is
setted to "8" level
by default,and the
fan wind speed of
1-12 level can be
adjusted on the
horizontal line.
1
15.Press the
"Switch" key to
turn off the
fan,restart to
restore the last
shutdown gear.
1
16.Press "Mode"
key to select
Normal、Sleep、
Natural and ECO,if
do not select, the
default is Normal if
you choose the
working mode after
shutdown and
restart.
1
11. Please ensure
the device is
powerd on when
connecting.
1
12.Add device
successfully,then
click finish.

15
17.Press "Settings"
key to control Up-
and-Down Swing
and Left-and-
Right
Swing;Press"Timer
off setting"to
select 1-9h timing
(The timing
function can only
be used when
shutdown).
3.Retrieve Password Operation Instruction
1
1.Click to log in
with an existing
account.
1
2.Click "Forget
Password".
1
3.Get verification
code if you forget
the password.
1
4.Enter verification
code.

16
1
5.Set your
password.
Important Note:
•The appliance must be connected with
power supply and WIFI.
•Due to the continuous product
improvement and updates on the Mobile
APP interface, the above mentioned data
and user interfaces are only for reference.
The actual APP interface is subjected to the
final download version and won't notice to
user in advance.
Product Specification
Model: GWSF12
Voltage: 100-240V~
DC Brushless Motor: DC15V 30W
Timer Off:1-9hours
Noise: <53db
MAX RPM:1100
Max Wind Speed: 6 m / s
Product size: 360Wx1030Hx360D mm (Max. height) 360Wx800Hx360D mm(Min.height)
*The final product specification may be varied according to a different lot of material and
actual input voltage power of the usage area.

17
安全注意事項
感謝您選擇我們的產品。為了您的消費者權益，請仔細閱讀保養卡並妥善保管。與產品保修
相關的專案如下所示：
-一般電器產品並不是為體質、感覺或智力有障礙人士(包括八歲以下兒童)、或缺乏經驗及
知識者使用，除非他們曾經接受負責安全人士的監督或指示，大人應指導小孩不可把玩電
器。
-使用前請細閱及了解所有說明書內容，以免誤用產品。請保存好說明書作日後參閱。
-不可對風扇使用說明書上記載以外的方法及用途，以免發生意外。
-在任何情況下包括使用前、使用中、使用後及存放時，不可讓八歲以下兒童接觸、使用、
當玩具把玩、清洗及靠近本風扇、電源線及所有配件，以免發生意外。
-請勿將包装袋置於幼兒拿得到的地方。若套穿在頭上等，可能會堵塞口鼻導致窒息死亡。
-未完全安裝好扇葉、前 / 後網，切勿把電插頭連接電源插座啟動風扇，避免發生意外。
-風扇運作時必須有人看管，不要讓小童靠近接觸。
-在沒有任何人看管的情況下，切勿啟動風扇，以免發生意外。
-如使用時或放置時不慎把風扇傾倒，請即時先把電插頭拔離電源插座把風扇馬上關掉，把
風扇放置好，檢查風扇沒問題才可再次使用。如有任何不確定或疑問請先交往維修中心檢
查。
-本風扇並不防水，切勿把風扇整機、遙控器、電源線和電插頭浸在水中或任何液體裏，也
不可將其放在水龍頭下沖洗和被濺水，以免發生意外。機身外殼只能以乾軟布清潔。
-風扇不防水，切勿把風扇放置在浴室、花灑、洗滌地方、泳池邊附近及室外使用及存放。
-切勿將風扇放置/靠近明火或發熱體/產品旁邊使用及存放。同樣切勿放置在可被水濺到
的地方使用及存放，以免破壞風扇及引起短路等意外。
-切勿把易燃及爆炸性物品如石油、油漆或其他易燃物品放置在風扇附近位置 ; 切勿在充
滿易燃氣體的地方使用及存放風扇 ; 切勿在風扇附近使用任何噴霧劑或殺蟲劑等，以免
發生意外或破壞風扇。
-切勿將手指或其他物品伸入前網和後網內或轉動部位，否則會造成重大傷害。特別注意兒
童，防止他們做出此動作。
-切勿在風扇上的任何縫隙及轉動位置等地方插入任何物件，以免損壞風扇或發生意外。
-風扇運作時切勿用任何物品遮蓋前 / 後網。
-風扇啟動時或轉動時，切勿調節風扇高度或上下風向角度，必須待風扇完全關機後才可進
行調節。
-風扇只可放置在平坦穩固的地上使用，切勿用任何方法把風扇安裝在牆身或天花板上。
-風扇啟動時注意切勿靠近前網和後網，以免頭髮被捲入風扇導致受傷。
-風扇不要放置在靠近窗簾、枱布、衣物等地方使用，以免被吸入風扇，同樣亦注意避免讓
紙張等物被吸入風扇，造成風扇破壞或發生意外。
-切勿強行以人手轉動調節風扇左右風向角度，以免破壞風扇。

18
-使用風扇期間不要移動風扇，移動風扇前必須先關掉風扇，把電插頭拔離電源插座，用機
身背後的手挽提起風扇，切勿拖拉本風扇，以免破壞風扇及刮傷地面表面。
重要事項 :
-連接電源之前，請檢查本地的電源電壓是否與產品所標示的電壓相符。
-當插頭、電源線、風扇本身出現任何受損時，請即停止使用。盡快交往維修中心檢查，切
勿自行改裝、拆卸或維修，以免發生意外。
-不要擠壓、扭曲、拉扯電源線，以免電源線和插頭受損及鬆脫。電源線應遠離高溫表面。
電源線如有受損請立即停止使用。切勿把電源線翹在風扇上，以免損壞電源線。
-不要把電源線放在地毯底下或用任何物件覆蓋電源線，以免損傷電源線或引起火警。
-電源線不可被任何物品踏過、重壓或被寵物咬破，以免損壞或折斷電源線，發生意外。
-不要使用外接定時器連接本風扇。本風扇並非以外置時間設定的裝置操作。
-使用風扇時切勿與其他電器共用同一電源座，以免電力過負發生意外。同時亦不要使用延
長線及延長拖板連接風扇使用。
-把風扇放置離開電視機、收音機或其他影音器材最少 1 米以外的地方使用，否則可能會
對以上器材造成干擾。
-請勿用濕手接觸電插頭、電源插座及使用風扇，以免發生觸電意外。
-拆卸或安裝前網時如不慎把螺絲掉進風扇內，請把風扇交往維修中心處理，切勿自行拆卸
處理。
-使用風扇時需注意保持室內空氣流通，以免影響進風效果。
-請勿長時間直接對着人體吹風，特別是長者、幼兒、病人和不能自行調節體溫人士等，否
則對健康有影響問題。
-不要在潮濕、多塵的環境及表面下使用此風扇，及不要把風扇放置在陽光直射的地方使用
和存放。
-不要對風扇進行任何沖擊及摔落，亦不要按壓前網後網，以免造成風扇破壞及發生意外。
-用戶應定期清潔機身、扇葉、前網及後網，以免積聚過多塵埃影響吹風效果。
-進行風扇清潔、拆卸或安裝前，必須先把電源插頭拔離電源插座。
-此風扇只供室內家庭使用及存放，不能作其他如商業用途及存放於室外。
-如產品出現異常現象，如異味、冒煙、不正常聲響、過度發熱等情況，請立即把產品停止
運作，拔掉電源插頭，停止使用。
-遙控器使用電池，如使用時發現遙控距離變短或控制不良，可能是電池開始耗盡，需要更
換全新電池。
-如長時間不使用風扇，請把遙控器內的電池取出放好，把風扇放回包裝盒內並存放在乾爽
通風及不易被小孩或寵物接觸的位置。
-所有圖片只供參考，一切以實物為準。

19
警告
1. 請不要濕手拔電源線插頭，以免產生觸電危險。
2. 請保持平穩狀態使用。
3. 不得隨意分解機體，機器內部為帶電體，請勿水洗或沖水。
4. 電源線不得割傷、損壞、拉扯、扭轉、打結也不要壓上重物。
5. 請勿將手指或者其他物體塞入到風扇網框中。
6. 清潔和維護本產品時，必須電源插頭脫離連接。
7. 請勿讓兒童操作機器。
8. 由於此款循環扇上下和左右擺頭都是電動自動控制，故不能用手動大力搬動。
產品結構圖
(1)後網罩
(2)前網罩
(3)風葉
(4)後殼
(5)伸縮管
(6)伸縮管調校鍵
(7)顯示屏
(8)遙控器放置處
(9)紅外線接收點
(10)底座
(11)AC 插座
(12)底座固定旋鈕
備註：產品圖片僅供參考，具體以實物為準。
底座展示

20
產品配件
風扇*1
說明書*1
保養卡*1
電源線*1
遙控器*1
使用指南
1.操作面板介紹及整機使用操作說明
1.LED 顯示屏
2.智能模式指示燈
3.自然風指示燈
4.睡眠風指示燈
5.WiFi 無線網絡功能
指示燈
6.定時功能按鍵
7. 模式轉換按鍵
8.上下搖頭按鍵
9.左右搖頭按鍵
10.風速調節按鍵
11.開/關按鍵
開/關鍵 風扇接駁電源後，按動此鍵機器開機，風速檔位預設默認為 8 檔，再次按動此
鍵，關閉本機。
定時關機鍵 按定時器關閉鍵設置關閉時間，風扇將在 1h-9h 之間切換。5秒後不操作
風扇，顯示屏顯示風速和定時開關交替切換。
風速鍵 點擊風速鍵，增加風量，1-12 檔，到 12 檔以後再次點擊返回 1 檔。
WiFi
SLEEP
NATURAL
ECO
ON/OFF SPEED OSC SWIMG TIMER MODE
