SERVICE MANUAL
MP-3000X
DUAL PRO DIGITAL MP3/AUDIO CD-PLAYER
CONTENT’S:
Connections & Operations:...........................................................Page 2-6
Specifications:..................................................................................Page 6
Parts Lists:...................................................................................Page 7-30
PCBs:..........................................................................................Page 31-36
Schematics:...............................................................................Page 36-46
Gemini Sound Products Corp.
120 Clover Place P.O. Box 6928
Edison, NJ 08818-6928

(2)
VOLTAGE SELECTOR: To set the proper voltage, adjust the VOLTAGE SELECTOR (1) switch to 115 or 230 volts.
POWER JACK (AC IN): Connect the power plug into the POWER JACK (2) for power.
REMOTE CONTROL: Use the included CABLE & REMOTE CONTROL (3) jacks to connect the REMOTE CONTROL
to the MAIN UNIT.
LINE OUTPUT JACKS: LINE OUTPUT JACKS (4) provide stereo sound via RCA cables to your mixer or receiver.
NOTE: MAKE SURE CABLES ARE PLUGGED IN TIGHT FOR OPTIMAL SOUND.
BNC (DIGITAL OUTPUT): Use the BNC (5) jack to connect to any type of device that accepts digital signals.
POWER: Press the POWER (6) button to turn on the CD player.
NOTE: MAKE SURE VOLTAGE SELECTOR SWITCH (1) IS SET BEFORE USE.
DISC TRAY: Put a CD in the DISC TRAY (7) after pressing OPEN/CLOSE (8); trays hold both 12 cm and 8 cm CDs.
OPEN/CLOSE: Tap OPEN/CLOSE (8) once to open the tray and again to close it.
DISPLAY: The DISPLAY (9) shows the various functions for the CD Player. See FUNCTION DESCRIPTIONS for
details.
PLAYBACK DISPLAY BAR: The PLAYBACK DISPLAY BAR (10) shows the TIME ELAPSED and TIME REMAINING .
PLAY/PAUSE: Press PLAY/PAUSE (11) button to activate PLAY or PAUSE mode. See CUE or ROBO START
INSTRUCTIONS for details.
CUE/PREVIEW: Tap CUE/PREVIEW (12) to come back to a set CUE or press and hold to PREVIEW from a CUE,
refer to CUE INSTRUCTIONS.
SEARCH: Use the SEARCH (13) buttons to scan forward and reverse directions on a TRACK .
TRACK SEARCH: Press the TRACK SEARCH (14) buttons to select which TRACK to play.
TIME: Tap the TIME (15) button to switch the TIME preference in three modes: ELAPSED, REMAIN, TOTAL REMAIN.
STOP: Press STOP (16) once to stop the CD.
SINGLE AUTO CUE/CONTINUE: Tap SINGLE AUTO CUE/CONTINUE (17) for: SINGLE AUTO CUE, CONTINUOUS,
and NORMAL modes.
FLY CUE: FLY CUE (18) sets a CUE POINT on the fly.
B/EXIT: Press B/EXIT (19) in PLAY mode, after a CUE POINT is memorized to start a LOOP, press again to exit LOOP.
B-EDIT: Press B-EDIT (20) and use the JOG WHEEL (22) to edit an existing LOOP, press again to exit EDIT mode.
RETURN: To play from a saved CUE POINT or a LOOP, press RETURN (21) to play the LOOP or the CUE again .
JOG WHEEL: The JOG WHEEL (22) has various functions: PITCH BEND, CUEING, and TRACK SEARCHING.
SEARCH MODE: Press to change the SEARCH MODE (23) of the JOG WHEEL (22) from MUSIC to TRACK mode.
SEARCH MODE LED: The SEARCH MODE LED (24) displays which SEARCH MODE (23) is in use.
PITCH: The PITCH (25) button activates the PITCH CONTROL SLIDE (27)
PITCH BEND: Buttons for PITCH BEND (26), lower or raise the pitch percentage (- or +) 4% when pressed.
PITCH CONTROL SLIDE: Moving the PITCH CONTROL SLIDE (27) up or down will lower or raise the pitch
percentage (- or +) 4%, 8%, &16%.
VPS (VARIABLE PITCH SELECTOR) 4%, 8% & 16%: Use the VPS (28) buttons use to change the PITCH settings
from 4%, 8%, &16%.
ROBO START: Using ROBO START (29) enables you to alternate play between two CDs using both sides.
QUICK START GUIDE:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

(3)
MP-3000X
(REMOTE CONTROL UNIT)

(4)
(MAIN UNIT)
(DIGITAL MIXER OR AMP)

(5)
INTRODUCTION:
Congratulations on your purchase of a Gemini MP-3000X CD Player. Your state-of-
the-art professional CD Player is backed by a three-year warranty that excludes
lasers, which are covered by a separate one-year warranty. Prior to use of this unit,
we suggest you carefully read the following instructions. Your Gemini MP-3000X
CD Player comes equipped with ADCS (Automatic Disc Calibration System), a
unique state-of-the-art feature. CDs are produced by a variety of manufacturers and
recorded by many different professional companies as well as the do-it-yourselfers
at home. Therefore, all CDs do not play the same. The ADCS automatically
adjusts the laser in your MP-3000X CD Player for each individual CD you insert into
the tray, to give you the best possible performance for every CD you play regardless
of how it was manufactured or how it was recorded. With this exclusive system you
always get consistent and reliable performance as well as exceptional sound quality
every time you play a CD... any CD.
FEATURES:
• Can Play: MP3/AUDIO CDS, CDR, CDRW
• Frame- Accurate & Ultra-Fast Track Music Search
• ADCS (Automatic Disc Calibration System)
• 4%, 8%, 16% Pitch Control Range
• Pitch Bend • Robo-Start
• Instant Start • Anti-Shock Buffer Memory
• Search Mode Selector • Inner/Outer Jog Wheel
• Adjustable Pitch Control • Real-Time Editing For Loop
• High-Visibility Blue LED Display • Cue, Pitch, Loop & Bend
CAUTIONS:
Do not use this CD player at temperatures below 41°F/5°C or higher than 95°F/35°C.
The apparatus should not be exposed to dripping or splashing, and no objects filled
with liquids such as vases should be placed on the apparatus.
Place the unit in a clean and dry location.
Do not place the unit in an unstable location.
When disconnecting the power cord from an AC outlet, always grasp it by the plug.
Never pull the power cord.
To prevent electric shock, do not remove the cover or the bottom screws.
There are no user serviceable parts inside.
Please refer servicing to a qualified technician.
Do not use chemical solvents to clean the unit.
Keep the laser pickup clean by keeping the tray closed.
Keep this manual in a safe place for future reference.
SAFETY CERTIFICATIONS:
Laser Diode Properties
Material: Ga - Al - As
Wavelength: 755 - 815 nm (25° C)
Laser Output: Continuous Wave, max. 5mWCAUTIONS
LINE VOLTAGE SELECTION:
The Gemini MP-3000X CD Player is a dual voltage unit operating at 115 or 230
volts. Be sure to set the proper voltage:
1. Place the head of a screwdriver in the center of the VOLTAGE SELECTOR (1)
switch found on the rear panel.
2. Slide the switch to 115 or 230 volts.
3. Do not force or twist the switch. Excessive force may cause damage. If the switch
does not move smoothly, contact a qualified technician.
CONNECTIONS:
1. Using the included cable, plug one end into the REMOTE CONTROL (3) jack and
the other end in the (MAIN UNIT) REMOTE CONTROL (3) jack.
2. Plug one end of a set of RCA connectors into the two LINE OUTPUT JACKS (4) on
the back of your CD unit.
3. Plug the other end of the RCA connectors into any of the available line level input
jacks on your mixer. If you are playing the MP-3000X through a receiver, you can
plug the RCA connectors into the CD or AUX INPUT JACKS located on the
receiver. If there are no CD or AUX INPUTS, use any line level (not phono) input.
4. The DIGITAL OUTPUT- BNC (5) jacks are for connecting to any type of DAT, MD,
HARD DRIVE, or any other type of device that accept digital signals.
FUNCTIONS:
POWER :After making sure the VOLTAGE SELECTOR (1) switch is properly set, plug
the unit in and press the POWER (6) button. The unit will turn on. Pushing
POWER (6) a second time turns the unit off.
DISC TRAY : The DISC TRAY (7) is where the CD is held during loading, unloading and
playback. Pressing OPEN/CLOSE (8) opens or closes the tray. The DISC TRAY
(7) holds both 12 cm and 8 cm CDs and automatically closes after remaining open
for three minutes.
NOTE: THE DISC TRAY (7) WILL NOT OPEN WHEN THE MP-3000X IS IN THE PLAY MODE.
OPEN/CLOSE :Press OPEN/CLOSE (8) to load or remove a CD from the DISC TRAY (7).
DISPLAY :The DISPLAY (9) shows: TOTAL TRACKS, TRACK NUMBER, PITCH
VALUE, SINGLE-AUTO CUE, CONTINUE (continuous play), and three different
time displays: ELAPSED, REMAIN and TOTAL REMAIN on a disc. Time is
measured in MINUTES, SECONDS and FRAMES.
NOTE: FOR MP3 DISCS THE DISPLAY WILL ONLY SHOW THE ELASPSED AND REMAIN TIME.
PLAYBACK DISPLAY BAR :The PLAYBACK DISPLAY BAR (10) displays the
remaining play time and time elapsed for each track. The display flashes slowly
when the track has 15 seconds remaining and pulses rapidly when play time is
down to 5seconds.
PLAY/PAUSE : Each press of PLAY/PAUSE (11) causes the operation to change
from PLAY to PAUSE or PAUSE to PLAY.
CUE/PREVIEW :With the unit in the PLAY mode and after the CUE POINT has been
programmed, pressing CUE/PREVIEW (12) will cause the CD player to enter the
PAUSE mode at the programmed CUE POINT. Holding down the CUE/PREVIEW
(12) button changes the function to PREVIEW and starts the CD from the
programmed CUE POINT. Releasing the CUE/PREVIEW (12) button will return the
CD laser to the preset CUE POINT.
SEARCH : The SEARCH (13) buttons are used to move forward or reverse while
in PLAY or PAUSE mode. See the CUE INSTRUCTIONS section for more information.
TRACK SEARCH :The TRACK SEARCH (14) buttons let you select a track to play.
TIME :The TIME (15) button switches the time display between the three available
choices listed under DISPLAY (9).
STOP :The STOP (16) button ends CD play.
SINGLE AUTO CUE/CONTINUE : Pressing SINGLE AUTO CUE/CONTINUE (17)
activates the AUTO CUE function. The AUTO CUE causes the CD to pause at
the recorded beginning of the next track and allows you to start play into the next
song with no space in between songs. Pressing SINGLE AUTO CUE/CONTINUE
(17) a second time will activate the CONTINUOUS function. This causes the CD to
repeat play continuously until SINGLE AUTO CUE/CONTINUE (17) is pressed
a third time to deactivate the CONTINUOUS function. Player will play from the
beginning to the end of a CD and stop, in NORMAL mode.
FLY CUE :The FLY CUE (18) function lets you set cues “on the fly” with the press of a
button. Press FLY CUE (18) when the disc reaches the musical location you wish to
make your cue or start point. The CUE POINT is now programmed. Press CUE/
PREVIEW (12) to return to the CUE POINT. Press PLAY/PAUSE (11) and the unit
starts from the pre-programmed spot.
B/EXIT :After a CUE POINT is memorized, pressing the B/EXIT (19) button in PLAY
mode, repeats the section between the CUE POINT and the point where the B/EXIT
(19) button was pressed. Press the B/EXIT (19) button again or pause play to exit
the repeating play.
B-EDIT : After a LOOP has been memorized you can change the length of the LOOP
by pressing B-EDIT (20) then use the JOG WHEEL (22) to adjust the length. To
exit EDIT mode press B-EDIT (20) again.
RETURN : The RETURN (15) button has two functions. To return to a previously saved
LOOP from normal play, press the RETURN (15) button after saving the LOOP. To
return to and instantly play from a previously saved CUE POINT, press the RETURN
(15) button after setting the CUE POINT (if you do not have a LOOP saved).
JOG WHEEL :The JOG WHEEL (22) has two modes: MUSIC and TRACK modes.
Press SEARCH MODE (23) to change between modes. In MUSIC mode you can
use the INNER WHEEL to make fine adjustments in PAUSE mode for CUEING and
to bend the pitch for precise synchronization in PLAY mode. Use the OUTER
WHEEL for rapid searching just like the SEARCH (13) buttons. In TRACK mode
the INNER WHEEL will skip a few tracks as you turn the wheel, and the OUTER
WHEEL will jump through many tracks when turned.
PITCH :Pushing the PITCH (25) button activates the PITCH section of the unit. The
pitch of the CD will change according to the position of the PITCH CONTROL SLIDE (27).
PITCH BEND : Pushing the PITCH BEND (26) buttons will automatically raise
the pitch up to +4% or lower the pitch down to -4% from the existing setting.
Releasing the buttons returns pitch to the original setting. Use this function to
match the pitch bend when mixing from one song to another.
VPS (VARIABLE PITCH SELECTOR) 4%, 8% and 16% : Use the VPS (28) buttons to
assign the percent the PITCH CONTROL SLIDE (27) will have. The 4% button will assign
+/- 4% to the PITCH CONTROL SLIDE (27). The 8% button will assign +/- 8% to the
PITCH CONTROL SLIDE (27). The 16% button will assign +/- 16% to the PITCH
CONTROL SLIDE (27). The PITCH (25) button must be ON for the VPS (28) to work.
OPERATING INSTRUCTIONS:
1. Make sure that the VOLTAGE SELECTOR SWITCH (1),found on the rear panel, is
set for the proper voltage. Plug the unit in and press the POWER (6) switch. The
unit is ON. Pushing POWER (6) a second time turns the unit OFF.
2. Press OPEN/CLOSE (8) and place a CD in the DISC TRAY (7). Press OPEN/
CLOSE (8) again. The tray will close.
3. Push TRACK SEARCH (14) to select the track you wish to play.
4. Press PLAY/PAUSE (11) and the unit will instantly play.

(6)
ORDER OF READING FOR MP3 FILES:
All MP3 files must have the extension *.mp3. If there are no files with *.mp3
extensions or MP-3000X cannot read the file system correctly the CD player will
indicate NO DISK and the MP3 segment in the right corner of LCD display will blink.
If a file has no *.mp3 extension, it will be skipped, during the file system reading.
(See w.wna and r.jpg files in the diagram). UDF format is not supported. For MP3
files with adaptive bit-rates, the ELAPSED and REMAIN time indication may be
inaccurate. The MP-3000X will only play the first session of tracks on a CD that has
been recorded in a MULTISESSION or MIXED mode.
Order of reading for MP3 files:a.mp3, f.mp3, e.mp3, c.mp3, b.mp3, d.mp3,
g.mp3, h.mp3.
FLY CUE & CUE INSTRUCTIONS:
The FLY CUE (18) function lets you set cues “on the fly” with the press of a button.
Press FLY CUE (18) when the disc reaches the musical location you wish to make
your CUE or START POINT. The CUE POINT is now programmed. Press CUE/
PREVIEW (12) to return to the CUE POINT. Press PLAY/PAUSE (11) and the unit
will instantly start from this pre-programmed spot.
AND/OR:
1. To preprogram a cue point (the spot on a CD at which you want play to start) select
the proper track and push PLAY/PAUSE (11) so the unit enters the PLAY mode.
When the CD reaches the approximate musical spot you wish to make your cue,
push PLAY/PAUSE (11) so the unit enters the PAUSE mode (PLAY/PAUSE LED
blinks). Move the JOG WHEEL (22) forward or in reverse until the precise spot at
which you want CD play to begin is located. For MP3 disks use the INNER WHEEL
to find the precise spot. (You will not hear the music when moving OUTER WHEEL).
Push PLAY/PAUSE (11). The cue point is now programmed. Press CUE/PREVIEW
(12) to return to this preprogrammed cue point at any time. Push PLAY/PAUSE (11)
and the unit will instantly play from the pre-selected spot.
2. To fine-tune your pre-programmed CUE POINT, push PLAY/PAUSE (11) so the unit
enters the PLAY mode. Push the CUE/PREVIEW (12) button and the CD will return
to the CUE POINT you programmed in step #1 and begin play from that point. If
you decide this CUE or STARTING POINT is okay, leave the unit alone until you are
ready to play.
3. If, however, the selected spot is not exactly where you want it, push the CUE/
PREVIEW (12) button while the CD is playing and the disc will return to the pre-
programmed cue point. Locate the exact spot on the CD at which you want play to
start by turning the JOG WHEEL (22). Push PLAY/PAUSE (11) to preprogram this new
cue point. Press the CUE/PREVIEW (12) button to pause play at the new CUE POINT.
Push PLAY/PAUSE (11) at any time and the unit will play from the pre-selected spot.
ROBO START INSTRUCTIONS:
IN SINGLE-AUTO CUE MODE:
Use ROBO START (29) in SINGLE AUTO CUE mode to alternate play between the
MP-3000Xs two sides (one track from one side, then one from the other). In
SINGLE AUTO CUE mode play starts immediately with no blank or “dead” space.
ROBO START (29) causes one side of the CD player to play when the other side is
paused.
1. Engage SINGLE AUTO CUE mode with the SINGLE AUTO CUE/CONTINUOUS
(17) button.
2. Press the ROBO START (29) button to activate ROBO START (29). Play will
alternate between the two CD players. At the end of a track, the playing side
pauses and the other CD deck plays a track. At the end of this track, the playing
side pauses and the first CD deck resumes play.
IN CONTINUOUS MODE OR DURING NORMAL PLAY:
If you use the ROBO START (29) function without SINGLE AUTO CUE MODE (in
CONTINUOUS MODE or during normal play), CD deck play does not alternate
automatically. The PLAY/PAUSE (11) button must be pressed on the playing deck
for the second deck to play.
1. During normal play, set a cue point on the second CD deck.
2. Press the ROBO START (29) button to activate ROBO START.
3. Press PLAY/PAUSE (11) button on the playing side to start play from the cue point
on the other CD deck.
NOTE : PAUSING PLAY IN THE MIDDLE OF A TRACK CAUSES THE OTHER CD DECK TO
PLAY. WHEN THE NEW TRACK ENDS, PLAY RESUMES ON THE FIRST CD PLAYER FROM
THE POINT AT WHICH, IT WAS PAUSED.
TROUBLESHOOTING:
•If a disk will not play, check to see that it was loaded correctly (label side up) and that the CD unit
is on a flat, level, stable surface. Check disc for dirt, scratches, spills, etc.
•If the disc spins but there is no sound, check the cable connections. If they are okay, check your
amplifier or receiver.
•If the CD skips, check it for dirt, oil or scratches. Do not assume that the CD player or laser is
defective. Many CDs are recorded “out of spec” and skip on most or all CD players. Before
sending the unit to an authorized Gemini service technician, insert a disc that plays properly in
another unit.
NOTE : DEPENDING ON THE CONDITIONS OF THE RECORDING EQUIPMENT OR THE CD-R/RW
DISC ITSELF, SOME CD-R/RW DISCS CANNOT BE PLAYED.
In the U.S.A., if you have any problems with this unit, call 1-732-738-9003 for
customer service. Do not return equipment to your dealer!
SPECIFICATIONS:
GENERAL:
Type.........................................................Dual Mechanism Compact Disc / MP3 Player w/wired remote
Disc Type.................................................................................Standard Compact discs (12 cm & 8 cm)
Time Display.....................................................................Track Elapsed, Track Remain, or Total remain
Instant Start...........................................................................................................Within 0.015 seconds
Track Selection................................................................................................................1 to 999 Tracks
Installation............................................................(3U Remote Control / 2U Main Unit) 19"/482mm each
Dimensions:..................................................Remote Control-W 19” x H 5 3/16” x D 1 5/8” (482x35x38)
Main Unit-W 19” x H 3.5” x D 10” (482x88x254)
Weight Per Unit...........................................Remote Control-3.5 lbs (1.5 kg) / Main Unit-9.5 lbs. (4.3 kg)
AUDIO SECTION:
Bit Rate................................................................................................................................32-392 kbps
Quantization..................................................................................16 Bit Linear/Channel, 3 Beam Laser
Oversampling Rate......................................................................................................................8 Times
Sampling Frequency..................................................................................................................44.1 kHz
Frequency Response......................................................................................................20 Hz to 20 kHz
Total Harmonic Distortion.............................................................................................Less Than 0.05%
Signal to Noise Ratio....................................................................................................................100 dB
Dynamic Range..............................................................................................................................96 dB
Channel Separation...........................................................................................................90 dB (1 KHz)
Output Level...................................................................................................................1.9 Volts R.M.S.
Power Supply......................................................................................................AC 115/230V, 60/50 Hz
NOTE : SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE FOR
PURPOSE OF IMPROVEMENT.
(1) a.mp3
w.wna
(2) f.mp3
(7) g.mp3
(8) h.mp3
(3) e.mp3
(6) d.mp3
(4) c.mp3
(5) b.mp3
FILE/FOLDER SAMPLE DIAGRAM:

GEMINI
MP-3000X CA PARTS LIST :
(MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò REMARK
1 012-075 1 PANEL CONTROL
Â
2 031-089 1 COVER Â
3 021-624 1 VR ANGLE Â
4 003-427 2 PLATE LAMP
+ CDX-602 CA
5 003-428 2 LAMP HOLDER
+ CDX-602 CA
6
7 002-572 1 KNOB PUSH (CA)
+ CDX-602 CA
8 003-168 2 KNOB ROTARY (A)
 ( + Y PE ê  )
9 003-169 2 KNOB ROTARY (B)
 ( + Y PE ê  )
10 002-720 2 KNOB SLIDE
+ CDX-602 CA
11 148-316 1 NAME PLATE (SMALL)
+ CDX-802 CA
12
13 003-738 2 VR INLAY (CA)
+ CDX-602 CA
14 003-739 1 PR OTECTOR INLAY
+ CDX-602 CA
15 003-711 4    ! 
+ BPM250(  Õ LED-7)
16
17 002-590 2 KNOB PUSH KEY ASS'Y (A)
Â
18 002-591 2 KNOB PUSH KEY ASS'Y (B)
Â
19 002-592 2 KNOB PUSH KEY ASS'Y (C)
Â
20 002-593 2 KNOB PUSH KEY ASS'Y (D)
Â
21 003-741 2 PUSE KEY INLAY (CA)
+ CDX-602 CA
22
23 049-216 4 PAD FOOT
 (  Õ GL-18)
24 159-227 2 VR DUST PROOF CLOTH (CA)
+ CDX-602 CA
25

GEMINI
MP-3000X CA PARTS LIST :
(MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
26 099-252 2 LAMP PAPER
+
CDX-602 CA
27
28 099-275 1 LAMP PAPER (ROBO)
Â
29 099-253 2 LAMP LABEL
+
CDX-602 CA
30
31 153-239 1
µ
POLYFORM
Â
32 196-223 * 1 SERIAL NO:LABEL
+ MP-3000X DA ( [  ×1) n m ( Ç \ DA È ó n «
33
34 099-014 1  ( ö ª
35 099-214 1  ½ ö ª
36
37 190-062 1
38 160-045 1 PE BAG 160×650mm [  ª
39
40 110-172A 4 BAND-HEAD TAPPING SCREW/TWIN SCREW VR
p 
:
½ Ê (4)
41 111-046A 18 BAND-HEAD TAPPING SCREW
;  y : DIN JACK(2),PCB : VR p  (16)
42 111-057 6 FLAT-HEAD TAPPING SCREW
Y ü : VR p  (6)
43 121-002A 6 BAND-HEAD TAPPING SCREW
 ü (6)
44
45
46
47
48
49
50

GEMINI
MP-3000X CA PARTS LIST :
(MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
1 262-492 1 PRINTED CIRCUIT BOARD MP3000-5 CONTROL UNIT (428×122 FR-4
Ú ° )
2 262-491 1 PRINTED CIRCUIT BOARD MP3000-4
L MIN DIN (48×28 94V0 Ú ° ) MP3000-3 R ¨   MP3000-4 L 
3 262-493 2 PRINTED CIRCUIT BOARD MP3000-6 LED (84×10 94V0
Ú ° ) û ¨ 10 
£ \ CDX-602 PC-8 R ª ¨ U , Á Ú  + ¤
4
5 074-205 2 INTEGRATED CIRCUIT LC75824E SANYO;PC5
6 074-206 1 INTEGRATED CIRCUIT TMP93PW32F TOSHIBA;PC5 (
Ã Ø ß ã .hex )
7 074-074 1 INTEGRATED CIRCUIT NJM7805FA JRC
¢ ª   n m  a ;PC4
8 074-204 1 INTEGRATED CIRCUIT SN74LV164A TEXAS;PC5
9
10 076-095 1 TRANSISTOR 2SC2878 PC5
11 079-003 21 SILICON DIODE 1N4148 PC5
12
13 080-119 2      !
 ç SDL-3N2FGD;PC5
14 080-118 2      !
 ç SDL-3N2HD;PC5
15 080-124 6 LED (WHITE) 2×4
 ç SDL-20403PW;PC6(3)×2
16 080-125 8 LED (RED) 2.2×3.0
 ç SDS-2230JO;PC5
17 080-126 6 LED (BLUE) 2.2×3.0
 ç SDS-2230SB;PC5
18
19 001-083 2 LCD PANEL USS-H364ENV-B(
£ ) _ < );PC5
20 072-112 I 2 SLIDE VR 60mm
¨ W RA6044-20T-10C1-B14-0015G,
6 W RS6011YP9201-10KB;PC5
21
22 082-050 6 TACT SWITCH (LED/RED)
ö ä TL-SXXR;PC5
23 082-051 4 TACT SWITCH (LED/GREEN)
ö ä TL-SXXN;PC5
24 082-042F 33 TACT SWITCH
6 W SKHVBE3520-CE;PC5
25 083-116 2 ROTARY ENCODERS
Ï # RE35C-B-2-1-RR;PC5

GEMINI
MP-3000X CA PARTS LIST :
(MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
26 092-147 1 8P DIN MINI JACK
 ¢ LNB0512;PC4
27
28 050-203T 1     ! ×8 L L 4.7  
/ ± 5mm;PC5 Ð I 
29 050-166T 3     ! ×7 47  
/ ± 5mm;PC5
30 050-174T 4     ! ×7 100  
/ ± 5mm;PC4(1),PC5(3)
31
32 054-026T 2     
/ ± 5mm;PC5
33
34 058-024 1 CRYSTAL OSCILLATOR 20MHz PC5
35
36 057-015 2 MLC. CHIP CAPACITOR 27P/50V PC5 SIZE 0603
37 057-022 2 MLC. CHIP CAPACITOR 100P/50V PC5 SIZE 0603
38 057-058 10       PC5 SIZE 0603
39
40 060-242 2         PC4
41
42 064-050 28 !    ""  PC5 SIZE 0805
43
44 065-071 6     #  PC5 SIZE 0603
45 065-087 1     #  PC5 SIZE 0603
46 065-088 2     #  PC5 SIZE 0603
47 065-095 14     #  PC5 SIZE 0603
48 065-135 2     #  PC5 SIZE 0603
49 065-151 1       PC5 SIZE 0603
50

GEMINI
MP-3000X CA PARTS LIST :
(MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
51 060-702 2 JUMP WIRE "
Q $   ! % "
PC4
52 060-702 2 JUMP WIRE "
Q $   ! % "
PC4
53 060-702 2 JUMP WIRE "
Q $   ! % "
PC6
54
55 092-148 1 8P PIN HEADER P=2.54 90° PC4 H=6.5mm
56 092-044A 2 2P CONNECTOR BASE B2B-XH-A 90° PC6(1)×2
57
58 091-458A 1 2P CONNECTOR WITH WIRE XH-2P 70mm
 á (PC4,X5
:
R PC6,X5) 26AWG ì "
59 091-521A 1 2P CONNECTOR WITH WIRE XH-2P 120mm
 á (PC4,X4
:
L PC6,X5) 26AWG ì "

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò REMARK
1 012-076 1 PANEL CONTROL
 ( + CDX-602 DA Ä  , Á Ú Â )
2 031-040 1 TOP COVER
+ CDX-602 DA
3 032-178 1 BOTTOM COVER
 ( + CDX-602 DA, Ä Õ 3 9 Ï )
4 021-604 1 SUB PANEL
+ CDX-602 DA
5 041-558 1 HEAT SINK
Â
6 041-559 2 HEAT SINK (C)
Â
7 022-860 2 MOUNTING BRACKET
+ CDX-602 DA
8 022-493 2 HOLDER BNC
Â
9
10 003-737 2 DESK DOOR
+ CDX-602 DA
11 002-573 1 KNOB PUSH (DA)
+ CDX-602 DA
12 003-743 1 PUSE KEY INLAY (DA)
+ CDX-602 DA
13 002-576 1 KNOB PUSH KEY ASS'Y (C)
+ CDX-602 CA
14 003-739 1 PR OTECTOR INLAY
+ CDX-602 CA
15 003-711 1    ! 
+ BPM250(  Õ LED-7)
16
17 047-494 6 PCB SUPPORT
+ CDX-602 DA(  Õ SCC-8)
18 148-316 1 NAME PLATE (SMALL)
+ CDX-802 CA
19 049-216 4 PAD FOOT
+ MP-3000X CA(  Õ GL-18)
20
21 153-213 1
µ
POLYFORM
+ CDX-602 DA
22 196-223 * 3 SERIAL NO:LABEL
 ( [  ×1, ; U ×1,  « ×1) n m ( Ç \ CA È ó n «
23 255-299 1 GIFT BOX Â
24 257-039 1 OWNER'S MANUAL Â
25 156-089 1 WARRANTY CARD

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
26 159-233 4 DOUBLE LABEL
+
CDX-802 DA(20mm×2mm×1t)
27
28 190-062 1
29
30 099-167 1 A LABEL UL/110V;
ä áþ 
31 099-168 1 J LABEL T-MARK/100V;
ã Ä þ 
32 099-169 1 V LABEL VDE/230V;
ä / : / ÷ / þ / õ þ 
33 099-014 1  ( ö ª
34 099-214 1  ½ ö ª
35
36 099-232 2
ö ª È 230V þ   È e Î L ¥  ê ¡  6×6 \ Ç p ; ( §  þ   ê Ù p ö ª )
37 099-233 2
ö ª È 117V þ   È e Î L ¥  ê ¡  6×6 \ Ç p ; ( §  þ   ê Ù p ö ª )
38 099-234 2
ö ª È 230V-BS þ   È e Î L ¥  ê ¡  6×6 \ Ç p ; ( §  þ   ê Ù p ö ª )
39
40
41 160-009 1 PE BAG 230×300mm ~ â Ì ü
42 160-044 1 PE BAG 160×250mm  . " ª
43 160-052 1 PE BAG 650x650mm [  ª
44
45
46 121-002A 16 BAND-HEAD TAPPING SCREW
p  :   (5) 8   (5), ?x : Y ü (2),  ²  :   (2),PCB
: Y ü µ (2)
47 111-046A 14 BAND-HEAD TAPPING SCREW 110V
?x :   (2), Ï 3 :   (8), ;  y : DIN
JACK(2),BNC Õ o  :   (2)
48
49 110-172A 6 BAND-HEAD TAPPING SCREW/TWIN SCREW
 
:
RCA JACK(2),  ²  (C)
:
IC(4)
50 101-043 3 FLAT-HEAD MACHINE SCREW
 ²  : TR(3)

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
51 110-078 2 PAN-HEAD TAPPING SCREW
ê z :   (2)
52 111-030 1 PAN-HEAD TAPPING SCREW
 þ (1)
53 111-044A 4 BAND-HEAD TAPPING SCREW ( "NUT" )
  :   (4)
54
55 111-057 6 FLAT-HEAD TAPPING SCREW
Y ü : p  (6)
56
57 131-081 3 NUT/WASHER 3mm TR(3)
58
59 170-469
60
61
62
63
64
65

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
1 262-488 2 PRINTED CIRCUIT BOARD MP3000-1 MAIN UNIT (160.4×93.75 FR-4
Ú ° )
2 262-291 1 PRINTED CIRCUIT BOARD CD01-4 OPEN CLOSE (68×45,5 94V0
Ú ° ) û ¨ 2 
3 262-489 1 PRINTED CIRCUIT BOARD MP3000-2 POWER SUPPLY (57×107 94V0
Ú ° ) û ¨ 3 
4 262-490 1 PRINTED CIRCUIT BOARD MP3000-3
v POWER SW (18×28 94V0 Ú ° ) û ¨ 2  \ MP3000-4 R ¨
5
6 074-184 2 INTEGRATED CIRCUIT PCM1717E BURR BROWN;PC1(1)×2
7 074-185 1 INTEGRATED CIRCUIT NJM79L05 JRC
¢ ª   n m   ;PC2
8 074-074 1 INTEGRATED CIRCUIT NJM7805FA JRC
¢ ª   n m   ;PC2
9 074-104S 2 INTEGRATED CIRCUIT NJM4558LD (M5218AL,BA15218N) PC1(1)×2
10 074-186 2 INTEGRATED CIRCUIT NJM317F JRC
¢ ª   n m   ;PC2
11 074-182A 2 INTEGRATED CIRCUIT BA6392FP (AT6392H) R OHM;PC1(1)×2
12 074-181 2 INTEGRATED CIRCUIT BA6218 R OHM;PC1(1)×2
13
14 074-200 2 INTEGRATED CIRCUIT CS8405A CRYSTAL;PC1(1)×2
15 074-201 2 INTEGRATED CIRCUIT CXA2581N SONY;PC1(1)×2
16 074-192 2 INTEGRATED CIRCUIT CXD3068Q SONY;PC1(1)×2
17 074-194 2 INTEGRATED CIRCUIT MM74HCT00M FSC;PC1(1)×2
18 074-203 2 INTEGRATED CIRCUIT MLC3100A MCS LOGIC;PC1(1)×2
19 074-202 2 INTEGRATED CIRCUIT HY57V64820GHT-H HYNIX;PC1(1)×2
 SAMSUNG K4S640832D
20 074-206 2 INTEGRATED CIRCUIT TMP93PW32F TOSHIBA;PC1(1)×2 (
Ã Ø ß ã .hex)
21
22 076-137 2 TRANSISTOR 2SA954(L) OR 2SA817(Y) PC1(1)×2
23 076-104 2 TRANSISTOR 2SA1048 OR 2SA1317 PC1(1)×2
24 076-095 6 TRANSISTOR 2SC2878 PC1(3)×2
25

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
26 076-002 2 TRANSISTOR 2SC945 PC1(1)×2
27 076-003 SILICON TRANSISTORS OR 2SC1815
28
29 079-027 8 RECTIFIER DIODE 1N4002 (1N4003,1N4004) PC1(1)×2,PC2(6)
30 079-003 12 SILICON DIODE 1N4148 PC1(6)×2
31
32
33 080-118 1
     !
 ç SDL-3N2HD;PC4
34
35 001-062A 2 CD PLAYER LOADER KSL-2130CCM
36 058-021 2 CRYSTAL OSCILLATOR 16.9344MHz PC1(1)×2
37 058-024 2 CRYSTAL OSCILLATOR 20MHz PC1(1)×2
38
39 092-161 2 BNC CONNECTOR
ü ] IAJ03;PC1(1)x2
40 161-173 2 2P RCA JACK
R  042M;PC1(1)×2
41 092-105 1 AC INLET
 ´ SY211[0717-1], u · Õ 9
42 100-069 1 FUSE 20mm UL 1A AC250V AC INLET
ö ª
43
44 147-028 4      PC1(2)×2
45 147-026 12      PC1(6)×2
46
47 059-229 1 POWER TRANSFORMER EI-57×30
115/230V IN 8.3V 0 8.3V 850mA,11.7V 0 11.7V 900mA VDE
_ Ù
48 059-236 1 CHOKE EE25.4 24mH PC2 EMC1
49 059-237 1 FERRIT BEAD 14×28×9H 091-482 3P
 " ¯ á ö ª
50

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
51 093-370
 1 AC CORD 18AWG×3C VW-1
ä Ù ,3P " , " Ã j  z ,   n
52 093-371  1 AC CORD 220V VDE
O Ù ,3P " , " Ã j  z ,   n
53 093-372N  1 AC CORD
÷ á Ã ª ,3P " , " Ã j  z ,   n
54 093-410  1 AC CORD
 n h à ª ,3P " , " Ã j  z ,   n
55
56 081-023 1 SLIDE SWITCH 2P2C UL
E æ SL14-22AM(1A); ß ü ª
57 082-042F 2 TACT SWITCH
T W SKHVBE3520-CE;PC4
58 083-065F 1 POWER SWITCH UL
T W SFDLB11G7U-CE;PC3
59
60 091-456 1 8P DIN MINI CONNECTOR WITH WIRE 1200mm   ª
61 092-147 1 8P DIN MINI JACK
 ¢ LNB0512-8;PC2
62 091-473 2 (RCA TYPE) CONNECTOR CORD 1M   ª
63
64 050-029T 4    ! ×11 10  
/ ± 5mm;PC2
65 050-195 1    ! ×32 10000   PC2
66 050-194 1    ! ×26 4700   PC2
67 050-082 1    ! ×21 2200   PC2
68 050-146T 2    !   
/ ± 5mm;PC1(1)×2
69 050-147 2    ! ×11 470  
/ ± 5mm;PC1(1)×2
70
71 050-203T 2     ! ×8 LL 4.7  
/ ± 5mm;PC1(1)×2 Ð s 
72 050-115T 16     ! ×8 10  
/ ± 5mm;PC1(8)×2
73 050-111T 2     ! ×8 22  
/ ± 5mm;PC1(1)×2
74 050-166T 10     ! ×7 47  
/ ± 5mm;PC1(5)×2
75 050-174T 40     ! ×7 100  
/ ± 5mm;PC1(20)×2

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
76 055-062 2
  !   
/ ± 15mm;PC2
77
78 051-002T 2 CERAMIC CAPACITOR 2P/50V
/ ± 5mm;PC1(1)×2
79 051-156 1   "   
POWER SW, û x / ± ;PC3
80
81 057-015 12 MLC. CHIP CAPACITOR 27P/50V PC1(6)×2 SIZE 0603
82 057-020 4 MLC. CHIP CAPACITOR 68P/50V PC1(2)×2 SIZE 0603
83 057-022 2 MLC. CHIP CAPACITOR 100P/50V PC1(1)×2 SIZE 0603
84 057-028 4 MLC. CHIP CAPACITOR 330P/50V PC1(2)×2 SIZE 0603
85 057-030 8 MLC. CHIP CAPACITOR 470P/50V PC1(4)×2 SIZE 0603
86 057-033 2 MLC. CHIP CAPACITOR 820P/50V PC1(1)×2 SIZE 0603
87
88 057-034 6       PC1(3)×2 SIZE 0603
89 057-036 4       PC1(2)×2 SIZE 0603
90 057-039 4       PC1(2)×2 SIZE 0603
91 057-044 2       PC1(1)×2 SIZE 0603
92 057-046 4       PC1(2)×2 SIZE 0603
93 057-048 2       PC1(1)×2 SIZE 0603
94
95 057-054 2       PC1(1)×2 SIZE 0603
96 057-058 102       PC1(51)×2 SIZE 0603
97 057-062 2       PC1(1)×2 SIZE 0603
98 057-064 2       PC1(1)×2 SIZE 0603
99 057-101 2       PC1(1)×2 SIZE 0603
100

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
101 054-017T 2
!    
/ ±
5mm;PC2
102 054-026T 5
!    
/ ±
5mm;PC2
103 054-032T 2
!    
/ ±
5mm;PC2
104
105 073-504 2
!! #!    
5 Ô RAA06103J;PC1(1)×2
106
107 064-018 4  #  !!!   PC1(2)×2 SIZE 0805
108 064-026 2  #  !!!   PC1(1)×2 SIZE 0805
109 064-119 2  #  !!!   PC1(1)×2 SIZE 0805
110
111 065-038 2  #  !!!   PC1(1)×2 SIZE 0603
112 065-042 16  #  !!!   PC1(8)×2 SIZE 0603
113 065-050 4  #  !!!   PC1(2)×2 SIZE 0603
114 065-054 36  #  !!!   PC1(18)×2 SIZE 0603
115 065-058 2  #  !!!   PC1(1)×2 SIZE 0603
116 065-060 2  #  !!!   PC1(1)×2 SIZE 0603
117
118 065-071 2  #  !!!   PC1(1)×2 SIZE 0603
119 065-079 8  #  !!!   PC1(4)×2 SIZE 0603
120 065-081 2  #  !!!   PC1(1)×2 SIZE 0603
121 065-083 10  #  !!!   PC1(5)×2 SIZE 0603
122 065-087 8  #  !!!   PC1(4)×2 SIZE 0603
123 065-088 6  #  !!!   PC1(3)×2 SIZE 0603
124 065-089 4  #  !!!   PC1(2)×2 SIZE 0603
125

GEMINI
MP-3000X DA PARTS LIST:
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME WHERE USED
Ò
REMARK
126 065-095 18
 #  !!!  
PC1(9)×2 SIZE 0603
127 065-099 6
 #  !!!  
PC1(3)×2 SIZE 0603
128 065-102 4
 #  !!!  
PC1(2)×2 SIZE 0603
129 065-103 2
 #  !!!  
PC1(1)×2 SIZE 0603
130 065-107 4
 #  !!!  
PC1(2)×2 SIZE 0603
131 065-112 2
 #  !!!  
PC1(1)×2 SIZE 0603
132
133 065-119 6
 #  !!!  
PC1(3)×2 SIZE 0603
134 065-126 2
 #  !!!  
PC1(1)×2 SIZE 0603
135 065-137 2
 #  !!!  
PC1(1)×2 SIZE 0603
136 065-141 2
 #  !!!  
PC1(1)×2 SIZE 0603
137
138 065-151 4
 #  !!!  
PC1(2)×2 SIZE 0603
139 065-159 2
 #  !!!  
PC1(1)×2 SIZE 0603
140
141 066-544 2
 # $  !! !   PC2
142 066-551 1  # $  !! !   PC2
143 066-566 2  # $  !! !   PC1(1)×2
144
145 066-602 2  # $  !! !   PC1(1)×2
146 066-663 1  # $  !! !   PC2
147
148 060-702 1 JUMP WIRE "
Q %   ! & 
PC2
149 060-702 2 JUMP WIRE "
Q %   ! & 
PC2
150
