Generac Mobile G4-ECO User manual

SAVE THIS MANUAL FOR FUTURE REFERENCE
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(1-888-436-3722)
Owner’s Manual
For
G4-ECO Light Tower
010827
For technical assistance contact:
www.generacmobileproducts.com
Technical Support
1-800-926-9768

ii Owner’s Manual for G4-ECO Light Tower
Use this page to record important information about your Generac Mobile Product
Unit Model Number
Unit Serial Number
Engine Model Number
Engine Serial Number
Generator Model
Number
Generator Serial
Number
Record the information found on your unit data label on this
page. See Serial Number Locations.
Engine and generator serial numbers are located on separate
data plates affixed to the engine and generator respectively.
When contacting a Generac Mobile Products Authorized
Service Dealer (ASD) about parts and service, always supply
the complete model number and serial number of the unit.
Operation and Maintenance: Proper maintenance and care of
the light tower ensures a minimum number of problems and
keeps operating expenses at a minimum. It is the operator’s
responsibility to perform all safety checks, to verify that all
maintenance for safe operation is performed promptly, and to
have the equipment checked periodically by an ASD. Normal
maintenance, service and replacement of parts are the
responsibility of the owner/operator and, as such, are not
considered defects in materials or workmanship within the
terms of the warranty. Individual operating habits and usage
may contribute to the need for additional maintenance or
service.
(000393a)
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warnings.ca.gov.
(000394)
WARNING
Breathing diesel engine exhaust exposes you
to chemicals known to the State of California
to cause cancer and birth defects or other
reproductive harm.
• Always start and operate the engine in a
well-ventilated area.
• If in an enclosed area, vent the exhaust to
the outside.
• Do not modify or tamper with the exhaust
system.
• Do not idle the engine except as necessary.
For more information go to
www.P65Warnings.ca.gov/diesel.

Owner’s Manual for G4-ECO Light Tower iii
Section 1: Introduction and Safety
Introduction ..........................................................1
Read This Manual Thoroughly ....................................1
How to Obtain Service .................................................1
Safety Rules .........................................................1
General Hazards ..................................................2

Electrical Hazards ................................................2
Battery Hazards ...................................................3
Fuel Hazards ........................................................3
Explosion and Fire Hazards ................................3
Engine Safety .......................................................4
Operating Safety ..................................................4
Positioning the Unit .....................................................4
Starting the Unit ...........................................................4
Raising and Lowering the Mast ...................................5
Service Safety ......................................................5
Trailer Hazards .....................................................6
Towing Safety ......................................................6
Hitch and Coupling ......................................................6
Running Lights ............................................................6
Wheels and Tires ........................................................6
Safe Towing Techniques .............................................6
Reporting Trailer Safety Defects ........................6
Safety and Operating Decals ..............................7
Section 2: General Information
Specifications ....................................................13
Serial Number Locations ..................................14
Unit Dimensions ...............................................14
Component Locations .......................................15
Control Panel .....................................................16
Controller ............................................................17
Controller Features and Functions ............................17
Accessing the Operator Menu ...................................18
Navigating Within the Operator Menu .......................18
Setting Light Sensor ..................................................18
Setting the Timer .......................................................19
Setting the Clock .......................................................19
Resetting Maintenance Alarms .................................19
Fuel Recommendations .................................... 20
Engine Oil Recommendations ......................... 20
Coolant Recommendations .............................. 20
Section 3: Operation
Operation Configuration ................................... 21
Adding Fuel ........................................................ 22
Adding Engine Oil ............................................. 22
Adding Engine Coolant ..................................... 22
Light Tower Setup ............................................. 23
Prestart Checklist .............................................. 24
Raising the Mast ................................................ 24
Start Procedure ................................................. 25
Lowering the Mast ............................................. 25
Customer Convenience Receptacles .............. 25
Engine Derating ................................................. 26
Shutting Down the Unit ..................................... 26
Towing the Unit ................................................. 26
Lifting the Unit ................................................... 27
Tying Down the Unit .......................................... 27
Table of Contents

iv Owner’s Manual for G4-ECO Light Tower
Section 4: Maintenance
Emissions Information ......................................29
Daily Walk-Around Inspection ..........................29
General Maintenance .........................................29
Preparing for Service ................................................ 29
Cleaning the Unit ...................................................... 29
Inspecting the Unit .................................................... 29
Basic Maintenance Schedule ...........................29
Basic Maintenance Schedule - 
Mitsubishi Engine ..............................................30
Changing Engine Oil .........................................31
Winch Maintenance ...........................................31
Prior to Each Use ...................................................... 31
Maintenance ............................................................. 31
Winch Mechanical Brake .......................................... 31
Trailer Wheel Bearing 
Lubrication .........................................................32
Hub Removal ............................................................ 32
Bearing Lubrication ................................................... 32
Hub Replacement ..................................................... 32
Jack Maintenance ..............................................32
Section 5: Troubleshooting
General Troubleshooting .................................. 33
Section 6: Wiring Diagrams
AC Schematic .................................................... 35
GTL04 Controller ............................................... 36
DC Schematic .................................................... 37
LED Light Wiring ............................................... 38

Introduction and Safety
Owner’s Manual for G4-ECO Light Tower 1
Section 1: Introduction and Safety
Introduction
Thank you for purchasing a Generac Mobile Products LLC
product. This unit has been designed to provide high
performance, efficient operation, and years of use when
maintained properly.
The information in this manual is accurate based on prod-
ucts produced at the time of publication. The manufacturer
reserves the right to make technical updates, corrections,
and product revisions at any time without notice.
Read This Manual Thoroughly
(000100a)
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
If any section of the manual is not understood, contact your
nearest Generac Mobile Products Authorized Service
Dealer, or contact
Generac Mobile Products LLC at 1-800-
926-9768, or
Generac Mobile Products Technical Service at 
1-800-926-9768 or www.generacmobileproducts.com
with any questions or concerns.
The owner is responsible for proper maintenance and safe
use of the equipment. Comply with regulations the
Occupational Safety and Health Administration (OSHA)
has established, or with equivalent standards. Also, verify
that the unit is applied, used, and maintained in accordance
with the manufacturer's instructions and recommendations.
Do nothing that might alter safe application/usage and
render the unit in noncompliance with the aforementioned
codes, standards, laws, and regulations
.
Save these instructions for future reference. This manual
contains important instructions for the unit that should be
followed during setup, operation and maintenance of the
unit and battery. ALWAYS supply this manual to any
individual that will use this machine.
How to Obtain Service
W hen the unit requires servicing or repairs, contact a
Generac Mobile Products Authorized Service Dealer (GMP
ASD) for assistance. Service technicians are factory-trained
and are capable of handling all service needs. For
assistance locating a dealer, visit
www.generacmobileproducts.com/parts-service/find-
service
. When contacting a GMP ASD about parts and
service, always supply the complete model number and
serial number of the unit as given on its data decal located
on the unit. Record the model number and serial numbers
in the spaces provided on the inside front cover of this
manual.
Safety Rules
The manufacturer cannot anticipate every possible
circumstance that might involve a hazard. The warnings in
this manual, and on tags and decals affixed to the unit are,
therefore, not all inclusive. If using a procedure, work
method or operating technique that the manufacturer does
not specifically recommend, verify that it is safe for others.
Also make sure the procedure, work method or operating
technique utilized does not render the equipment unsafe.
Throughout this publication, and on tags and decals affixed
to the unit, DANGER, WARNING, CAUTION and NOTE
blocks are used to alert personnel to special instructions
about a particular operation that may be hazardous if
performed incorrectly or carelessly. Observe them
carefully. Their definitions are as follows:
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTE: Notes contain additional information important to
a procedure and will be found within the regular text of
this manual.
These safety alerts cannot eliminate the hazards that they
indicate. Common sense and strict compliance with the
special instructions while performing the action or service
are essential to preventing accidents.

Introduction and Safety
2Owner’s Manual for G4-ECO Light Tower
General Hazards
(000103)
Asphyxiation. Running engines produce carbon
monoxide, a colorless, odorless, poisonous
gas. Carbon monoxide, if not avoided, will
result in death or serious injury.
DANGER
(000107)
Hearing Loss. Hearing protection is
recommended when using this machine.
Failure to wear hearing protection could
result in permanant hearing loss.
WARNING
(000111)
WARNING
Moving Parts. Keep clothing, hair, and
appendages away from moving parts. Failure
to do so could result in death or serious injury.
(000108)
WARNING
Hot Surfaces. When operating machine, do not
touch hot surfaces. Keep machine away from
combustibles during use. Hot surfaces could
result in severe burns or fire.
WARNING
Risk of injury. Do not operate or service this machine
if not fully alert. Fatigue can impair the ability to
service this equipment and could result in death or
serious injury. (000215)
(000139)
WARNING
Risk of burns. Allow engine to cool before
draining oil or coolant. Failure to do so could
result in death or serious injury.
WARNING
Personal Injury. Do not use lifting eye if there are
signs of damage or corrosion. Doing so could result
in death, serious injury, or property damage.
(000433)
WARNING
Personal Injury. Do not use lifting eye other than as
directed. Doing so could result in death, serious
injury, or property damage.
(000434)
DANGER
Asphyxiation. Do not operate unit without
a properly functioning exhaust system.
Doing so will result in death or serious injury.
(000340)

Electrical Hazards
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.
(000104)
DANGER
Electrocution. Water contact with a power
source, if not avoided, will result in death
or serious injury.
(000144)
DANGER
Electrocution. Contact with bare wires,
terminals, and connections while generator
is running will result in death or serious injury.
(000152)
DANGER
Electrocution. Verify electrical system is
properly grounded before applying power.
Failure to do so will result in death or serious
injury.
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
DANGER
Electrocution. DO NOT use the unit if
electrical cord is cut or worn through. Doing
so will result in death or serious injury.
(000263a)

Introduction and Safety
Owner’s Manual for G4-ECO Light Tower 3
Battery Hazards
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
(000137a)
WARNING
Explosion. Batteries emit explosive gases while
charging. Keep fire and spark away. Wear protective
gear when working with batteries. Failure to do so
could result in death or serious injury.
(000162)
Explosion. Do not dispose of batteries in a fire.
Batteries are explosive. Electrolyte solution can cause
burns and blindness. If electrolyte contacts skin or eyes,
flush with water and seek immediate medical attention.
WARNING
(000163a)
Risk of burn. Do not open or mutilate batteries.
Batteries contain electrolyte solution which can cause
burns and blindness. If electrolyte contacts skin or
eyes, flush with water and seek immediate medical
attention.
WARNING
WARNING
(000228)
Environmental Hazard. Always recycle batteries at an
official recycling center in accordance with all local
laws and regulations. Failure to do so could result in
environmental damage, death, or serious injury.
Contact your local solid waste collection site or recycling
facility to obtain information on local recycling processes.
For more information on battery recycling, visit the Battery
Council International website at: 
http:// batterycouncil.org.
Fuel Hazards
(000192)
DANGER
Explosion and fire. Fuel and vapors are extremely
flammable and explosive. No leakage of fuel is
permitted. Keep fire and spark away. Failure to do
so will result in death or serious injury.
(000174)
DANGER
Risk of fire. Allow fuel spills to completely dry
before starting engine. Failure to do so will
result in death or serious injury.
WARNING
Explosion and Fire. Do not smoke while
refueling unit. Failure to do so could result in
death, serious injury, or property or equipment
damage. (000284a)
(000105)
Explosion and Fire. Fuel and vapors are extremely
flammable and explosive. Add fuel in a well
ventilated area. Keep fire and spark away. Failure
to do so will result in death or serious injury.
DANGER
Explosion and Fire. Fuel and vapors are
extremely flammable and explosive. Keep fire
and spark away. Failure to do so will result
in death or serious injury. (000168)
DANGER
•DO NOT fill fuel tank while the engine is running.
•DO NOT operate with the fuel tank cap loose or
missing.
Explosion and Fire Hazards
(000147)
WARNING
Risk of Fire. Unit must be positioned in a
manner that prevents combustible material
accumulation underneath. Failure to do so
could result in death or serious injury.
(000110)
WARNING
Risk of Fire. Hot surfaces could ignite
combustibles, resulting in fire. Fire could
result in death or serious injury.

Introduction and Safety
4Owner’s Manual for G4-ECO Light Tower
Engine Safety
Internal combustion engines present special hazards
during operation and fueling. Failure to follow the safety
guidelines described below could result in severe injury or
death. Read and follow all safety alerts described in the
engine operator's manual. A copy of this manual was
supplied with the unit when it was shipped from the factory.
WARNING
(000281)
Fire risk. Fuel and vapors are extremely
flammable. Do not operate indoors. Doing
so could result in death, serious injury, or
property or equipment damage.
(000249)
WARNING
Risk of fire. Never operate engine without the
air cleaner installed. Operating engine without
the air cleaner could result in death or serious
injury.
CAUTION
Equipment damage. Do not clean air filter elements.
Contaminants may remain after cleaning, shortening
air filter service life. Doing so could result in engine or
equipment damage. (000317)
•DO NOT run engine indoors or in an area with poor
ventilation. Make sure engine exhaust cannot seep
into closed rooms or ventilation equipment.
•DO NOT clean air filter with gasoline or other types
of low flash point solvents.
•DO NOT operate the unit without a functional
exhaust system.
•Shut the engine down if any of the following
conditions exist during operation:
• Noticeable change in engine speed.
• Loss of electrical output.
• Equipment connected to the unit overheats.
• Sparking occurs.
• Engine misfires or there is excessive engine/
generator vibration.
• Protective covers are loose or missing.
• Ambient air temperature is above 113°F (45°C).
Operating Safety
Positioning the Unit
(000260a)
High Voltage. Verify area above unit is clear
of overhead wires and obstructions. Contact
with high-voltage power lines will result in
death or serious injury.
DANGER
(000147)
WARNING
Risk of Fire. Unit must be positioned in a
manner that prevents combustible material
accumulation underneath. Failure to do so
could result in death or serious injury.
WARNING
Equipment and property damage. Do not operate unit on
uneven surfaces, or areas of excessive moisture, dirt, dust
or corrosive vapors. Doing so could result in death, serious
injury, property and equipment damage. (000250)
•If the unit is equipped with a frame grounding stud,
follow the National Electrical Code (NEC), state,
and local regulations when connecting.
Starting the Unit
DANGER
Electrocution. DO NOT use the unit if
electrical cord is cut or worn through. Doing
so will result in death or serious injury.
(000263a)
WARNING
Equipment damage. Do not attempt to start or operate
a unit in need of repair or scheduled maintenance.
Doing so could result in serious injury, death, or
equipment failure or damage. (000291)

Introduction and Safety
Owner’s Manual for G4-ECO Light Tower 5
Raising and Lowering the Mast
WARNING
Electrocution. Do not set up or operate this
unit if severe weather is expected. Lightning
strikes can kill or cause severe injury even if
you are not touching the unit. (000296)
Tipping hazard. Do not set up the unit if high
winds are expected. High winds can cause
the unit to tip or fall, causing severe injury or
machine damage.
(000594a)
WARNING
> 50 mph
(80 km/h)
WARNING
(000266)
Tipping hazard. Extend the outriggers and level the unit
before raising the mast. Keep the outriggers extended while
the mast is up. Failure to do so could cause the unit to tip
and fall and could result in death or serious injury.
WARNING
Personal Injury. Stop immediately if the mast hangs
up or the winch cable develops slack. Excess slack
could cause the mast to collapse, resulting in personal
injury or equipment damage. (000265)
•Keep area around the unit clear of people while
raising and lowering the mast.
•ALWAYS lower the mast when not in use.
•If for any reason any part of mast hangs up or
winch cable develops slack while raising or
lowering tower, STOP immediately! Contact a
Generac Mobile Products Authorized Service
Dealer.
Service Safety
(000148a)
WARNING
Accidental start-up. Disconnect negative battery
terminal before servicing to prevent accidental
engine rotation. Failure to do so could result in death
or serious injury.
(000187)
WARNING
Electrocution. Potentially lethal voltages are generated
by this equipment. Render the equipment safe before
attempting repairs or maintenance. Failure to do so
could result in death or serious injury.
(000419)
CAUTION
Personal injury. Wear appropriate personal protective
equipment at all times while operating and servicing
unit. Failure to do so could result in personal injury.
This unit uses high voltage circuits capable of causing
serious injury or death. Only a qualified and licensed
electrician should troubleshoot or repair problems
occurring in this equipment.
•Before servicing the unit, verify the control power
switch and circuit breakers are OFF (0), and the
negative (-) terminal on the battery is
disconnected. DO NOT perform even routine
service (oil/ filter changes, cleaning, etc.) unless all
electrical components are shut down.
•ALWAYS use extreme caution when servicing this
unit in damp conditions. Do not service the unit if
skin or clothing is wet. Do not allow water to collect
around the base of the unit.
•DO NOT wash the unit with high pressure hoses,
power washers, or steam cleaners. Water may
collect in unit, causing damage to electrical parts.
•Replace all missing and hard to read decals.
Decals provide important operating instructions
and warn of dangers and hazards.
•Wear heavy leather gloves when handling winch
cables. Never let cables slip through bare hands.

Introduction and Safety
6Owner’s Manual for G4-ECO Light Tower
Trailer Hazards
WARNING
(000233a)
Personal injury. Trailer must be securely coupled to the
hitch with the chains correctly attached. Uncoupled or
unchained towing could result in death or serious injury.
(000231a)
Personal injury. Do not operate unit during transport.
Doing so could result in death, serious injury, or
property damage.
WARNING
(000234a)
Crushing hazard. Verify unit is properly secured and
on level ground. An unsecured unit can suddenly roll
or move, causing death or serious injury.
WARNING
WARNING
Property or Equipment Damage. Tighten wheel lug
nuts after first 50 miles to factory specifications.
Failure to do so could result in death, serious injury,
property or equipment damage. (000235)
Towing Safety
Towing a trailer requires care. Both the trailer and vehicle
must be in good condition and securely fastened to each
other to reduce the possibility of an accident. Some states
require that large trailers be registered and licensed.
Contact your local Department of Transportation office to
check on license requirements for your particular unit.
Hitch and Coupling
WARNING
(000233a)
Personal injury. Trailer must be securely coupled to the
hitch with the chains correctly attached. Uncoupled or
unchained towing could result in death or serious injury.
WARNING
Property or equipment damage. Do not alter the
trailer. Alterations can damage essential safety items.
Doing so could result in death, serious injury, or
property or equipment damage.
(000285)
•Verify the hitch and coupling on the towing vehicle
are rated equal to, or greater than, the trailer's
gross vehicle weight rating (GVWR).
•DO NOT tow trailer using defective parts. Inspect
the hitch and coupling for wear or damage.
•Before towing the trailer, verify that the weight of
the trailer is equal across all tires. On trailers with
adjustable height hitches, adjust the angle of the
trailer tongue to keep the trailer as level as
possible.
Running Lights
Verify directional and brake lights on the trailer are
connected and working properly.
Wheels and Tires
•Inspect trailer tires for wear and proper inflation.
•Verify wheel lug nuts are present and tightened to
the specified torque.
Safe Towing Techniques
•Practice turning, stopping, and backing up in an
area away from heavy traffic prior to transporting
the unit.
•Maximum recommended speed for highway towing
is 45 mph (72 km/h). Recommended off-road tow-
ing speed is 10 mph (16 km/h) or less, depending
on terrain.
•When towing, maintain extra space between vehi-
cles and avoid soft shoulders, curbs, and sudden
lane changes.
Reporting Trailer Safety Defects
If you believe your trailer has a defect which could cause
a crash or could cause injury or death, you should
immediately inform the National Highway Traffic Safety
Administration (NHTSA) in addition to notifying Generac
Mobile.
If NHTSA receives similar complaints, it may open an
investigation; and if it finds that a safety defect exists in a
group of vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot become involved in
an individual problem between you, your dealer, or
Generac Mobile.
To contact NHTSA, you may either call the Auto Safety
Hotline toll-free at 1-888-327-4236 (TTY:1-800-424-9153),
go to http://www.safercar.gov; or write to:
Administrator
NHTSA
1200 New Jersey Avenue S.E.
Washington, DC 20590
You can also obtain other information about motor vehicle
safety from http://www.safercar.gov.

Introduction and Safety
Owner’s Manual for G4-ECO Light Tower 7
Safety and Operating Decals
See Figure 1-1 through Figure 1-5. This unit features numerous safety and operating decals. These decals provide
important operating instructions and warn of dangers and hazards. The following diagrams illustrate decal locations and
descriptions.
Replace any missing or hard-to-read decals and use care when washing or cleaning the unit. Decal part numbers can
be found in the parts manual at www.generacmobileproducts.com.
ID Description ID Description
1Correct position of the floodlights for transport 15 Radiator cap
2Mast alignment arrow 16 Danger - do not open when the engine is hot
3Alignment arrow for mast position before transport 17 Forklift
4Tie-down point 18 Warning - Danger of electrical discharge - consult the
manual - do not clean, lubricate or service while unit is in
motion - do not use water to extinguish fire, use only
extinguishers
5High temperature, exhaust fumes KEEP AWAY 19 Danger - possible spillage of corrosive substances
6Do not lift the mast beyond the red line 20 Correct floodlight position for lifting
7Lock before towing 21 Lifting point
8Read the manual 22 Oil level control
9Electrical ground connection 23 Warning - ultra low sulfur diesel fuel only
10 Warning - extended stabilizers 24 Operation instructions
11 Diesel fuel tank cap; open the door 25 Warning - hot surfaces
12 High temperature, exhaust fumes KEEP AWAY 26 Refilling oil
13 Maximum wind stability 27 Battery switch ON/OFF (optional)

3
4
5
1
10
9
8
010828
2
Introduction and Safety
8Owner’s Manual for G4-ECO Light Tower
Figure 1-1. Decal Locations (1 of 5)

16
17
17
11
12
14 15
010829
4
Introduction and Safety
Owner’s Manual for G4-ECO Light Tower 9
Figure 1-2. Decal Locations (2 of 5)

5
20
14
6
010830
18
19
14
17
13
21
4
Introduction and Safety
10 Owner’s Manual for G4-ECO Light Tower
Figure 1-3. Decal Locations (3 of 5)

7
22
23
25
26
24
010831
Introduction and Safety
Owner’s Manual for G4-ECO Light Tower 11
Figure 1-4. Decal Locations (4 of 5)

27
010832
Introduction and Safety
12 Owner’s Manual for G4-ECO Light Tower
Figure 1-5. Decal Locations (5 of 5)

Owner’s Manual for G4-ECO Light Tower 13
General Information
Section 2: General Information
Specifications
Description Units G4-ECO
Alternator
Model -LINZ ALUMEN SB
Generator
Model -Synchronous
Output kVA 4.2
Output Voltage V120/240, single phase
Insulation Class - H
Mechanical Protection -IP 23
Engine
Make/Type -Mitsubishi L2E
Cylinders qty 2
Displacement in3 (L) 38.7 (0.635)
Horsepower* hp (kW) 7.1 (5.2)
Operating Speed rpm 1800
Cooling -Water
Fuel -Diesel
Starting System -Electrical
Oil Sump Capacity (including filter) qt (L) 2.65 (2.5)
Radiator Capacity (in engine only) qt (L) 1.27 (1.2)
Fuel Consumption - Full Power gph (Lph) .43 (1.64)
Fuel Consumption - Lights Only gph (Lph) .26 (.98)
Fuel Tank Capacity gal (L) 52.8 (200)
Usable Fuel Volume gal (L) 48.3 (183)
Liquid Containment (110%) -Yes
Battery Voltage volts 12
Lighting Tower
Maximum Height ft (m) 25.67 (7.8)
Raising -Manual
Sections - 5
Rotation Section degrees 340°
Maximum Wind Stability mph (km/h) 50 (80)
Dry Weight lbs (kg) 1588 (720)
Operational Weight lbs (kg) 1952 (885)
Lighting (LED)
Lamps Power watts 4 x 320 W
Total Lu m e n LM 192,000
Trailer
Number of Axles - 1
Capacity - Axle Rating lbs (kg) 2,500 (1134)
Tire Size in (cm) 13 (33) 175/80D13
Hitch - Standard in 2 in ball
Maximum Tire Pressure psi (kPA) 50 (345)
Specifications are subject to change without notice. Refer to the product specification sheet for complete list.
*Prime after 50 hour break-in.

14 Owner’s Manual for G4-ECO Light Tower
General Information
Serial Number Locations
Refer to Figure 2-1 to locate unit serial number (A) and
nameplate (B). Record the information from these tags
so it is available if the tags are lost or damaged. When
ordering parts or requesting assistance, you may be
asked to provide this information.
B
A
Figure 2-1. Serial Number Locations
Unit Dimensions
A
B
C
E
D
Figure 2-2.
A B C D E
G4-ECO
Unit Dimensions
Specifications are subject to change without notice.
118.7 in
(3.02 m)
103.3 in
(2.62 m)
25.67 ft
(7.82 m)
49.5 in
(1.26 m)
86.3 in (2.19 m)

Owner’s Manual for G4-ECO Light Tower 15
General Information
Component Locations
010835
L
C
E
B
K
D
G
H
I
G
J
N
M
M
AF
Figure 2-3. Component Locations
ALED lights HWinch
BGrounding stud IEngine access
COutrigger and jack JRear jack
DTongue jack KCentral lift point
ERadiator cap LFuel fill
FEngine access MForklift pockets
GTie-down location NControl panel

16 Owner’s Manual for G4-ECO Light Tower
General Information
Control Panel
010839
C
D
F
H
B
A
G
J
E
I
Figure 2-4. Control Panel Components and Functions
AUtility/OFF/Generator selector F15 A MCB circuit breaker for main control
B10 A DC fuse GConvenience receptacle (L14-20R)
C2 A AC fuses H120/240VAC-20A (shore power input)
DGTL04 control panel I120VAC-15A GFCI convenience receptacle (5-15R)
ELED lamps circuit breakers JEmergency stop button
