Generac Portable Products 1042-3 User manual

2250PSI
The Reliable Ones
High Pressure Washer
Owner’s Manual
Problems?
Questions?
Before taking your unit
back to the store,
call the pressure washer
helpline at
1-800-2 0-1408
M-F 8-5 CST
This pressure
washer is
equipped with an
Automatic Cool
Down System.
See page 12 for
details
GENERAC
This symbol points out important safety instructions, which, if not followed, could
endanger the personal safety and/or property of yourself and others. Read and follow all
instructions in the manual before attempting to operate this unit.
Model No. 10423 (2250 PSI High Pressure Washer) Manual No. B3236 Revision 0 ( /13/98)

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
2
CAUTION: Disconnect spark plug wire and place wire where it cannot contact spark plug to
prevent accidental starting when setting up, transporting, adjusting or making repairs to your
high pressure washer.
 Engine exhaust gases contain DEADLY carbon
monoxi e gas. This angerous gas, if breathe
in sufficient concentrations, can cause
unconsciousness or even eath. Operate this
equipment only in the open air where a equate
ventilation is available.
 Gasoline is highly FLAMMABLE an its vapors
are EXPLOSIVE. Do not permit smoking, open
flames, sparks or heat in the vicinity while
han ling gasoline. Avoi spilling gasoline on a hot
engine. Allow unit to cool for 2 minutes before
refueling. Comply with all laws regulating storage
an han ling of gasoline.
 Locate this pressure washer in areas away from
combustible materials, combustible fumes or
ust.
 The high pressure equipment is esigne to be
use with Generac authorize parts only. If you
use this equipment with parts that o not comply
with minimum specifications, the user assumes
all risks an liabilities.
 Some chemicals or etergents may be harmful
if inhale or ingeste , causing severe nausea,
fainting or poisoning. The harmful elements may
cause property amage or severe injury.
 Do not allow CHILDREN to operate the pressure
washer at any time.
 Operate engine only at governe spee . Running
the engine at excessive spee s increases the
hazar of personal injury. Do not tamper with
parts which may increase or ecrease the
governe spee .
 Do not wear loose clothing, jewelry or anything
that may be caught in the starter or other rotating
parts.
 Before starting the pressure washer in col
weather, check all parts of the equipment an be
sure ice has not forme there.
 Units with broken or missing parts, or without
protective housing or covers shoul NEVER be
operate .
 The muffler an air cleaner must be installe an
in goo con ition before operating the pressure
washer. These components act as spark arrestors
if the engine backfires.
 Check the fuel system for leaks or signs of
eterioration such as chafe or spongy hose,
loose or missing clamps or amage tank or cap.
Correct all efects before operating the pressure
washer.
 Do not spray flammable liqui s.
 Never aim the gun at people, animals or plants.
 High pressure spray can cause paint chips or
other particles to become airborne an fly at high
spee s. Always wear eye protection when
operating the pressure washer
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects, or other reproductive harm.
WWAARRNNIINNGG::

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
3
 Never allow any part of the bo y to come in
contact with the flui stream. DO NOT come in
contact with a flui stream create by a leak in
the high pressure hose.
 The high pressure hose can evelop leaks from
wear, kinking, abuse, etc. Water spraying from a
leak is capable of injecting material into
skin. Inspect the hose each time before use.
Check all hoses for cuts, leaks, abrasions or
bulging of cover, or amage or movement of
couplings. If any of these con itions exist, replace
hose imme iately. Never repair the high pressure
hose. Replace it with another hose that meets
minimum pressure rating of your pressure
washer.
 The high pressure stream of water that this
equipment pro uces can pierce skin an its
un erlying tissues, lea ing to serious injury.
 Always wear eye protection when you use this
equipment or when you are in the vicinity where
the equipment is in use.
 Never move the machine by pulling on the high
pressure hose. Use the han le provi e on the
top of the unit.
 Always be certain the spray gun, nozzles an
accessories are correctly attache .
 Never use a spray gun which oes not have a
trigger lock or trigger guar in place an in working
or er.
 Use a respirator or mask whenever there is a
chance that vapors may be inhale . Rea all
instructions with mask so you are certain the
mask will provi e the necessary protection
against inhaling harmful vapors.
 High pressure spray may amage fragile items
inclu ing glass. Do not point spray gun at glass
when in high pressure mo e.
 Keep the hose connecte to machine an spray
gun while the system is pressurize .
Disconnecting the hose while the unit is
pressurize is angerous.
 Hol the spray gun firmly in your han s before
you start the unit. Failure to o so coul result in
an injury from a whipping spray gun. Do not leave
the spray gun unatten e while the machine is
running.
 The cleaning area shoul have a equate slopes
an rainage to re uce the possibility of a fall ue
to slippery surfaces.
 Keep water spray away from electric wiring. Fatal
electric shock may result.
 Do not secure trigger gun in the pull-back (open)
position.
 Do not by-pass any safety evice on this machine.
 The muffler an engine heat up uring operation
an remain hot imme iately after shutting it own.
Avoi contact with a hot muffler or engine.
 Operate an store this unit on a stable, level
surface.

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
4
CONGRATULATIONS on your purchase of a
GENERAC high pressure washer. It has been
esigne , engineere an manufacture to give you
the best possible epen ability an performance.
Shoul you experience any problem you cannot
easily reme y, please contact your nearest
GENERAC Authorize Service facility, or call the 1-
800 number liste on the front of this manual. We
have competent, well-traine technicians an the
proper tools to service or repair this unit.
Please rea an retain this manual. The instructions
will enable you to assemble an maintain your high
pressure washer properly.
CUSTOMER
RESPONSIBILITIES
 Rea an observe the safety rules.
 Follow regular sche ule in maintaining, caring for
an using your high pressure washer.
 Follow the instructions un er Customer
Responsibilities an Storage sections of this
Owner's Manual.
PRODUCT SPECIFICATIONS
Pressure Washer Specifications
Outlet Pressure . . . . 2250 psi
Flow Rate . . . . . . . . . 2.22 gallons per minute (gpm)
Detergent Mix . . . . . . Use un ilute etergent
approve for pressure
washers
Water Supply . . . . . . Not to Excee 140°F
Temperature
Automatic Cool . . . . Will cycle when water
Down System reaches 140°-145°F
Engine specifications
Engine Model . . . . . . Briggs & Stratton Intek
Rated Horsepower . . 6.0
Displacement . . . . . . 190cc
Spark Plug
Type . . . . . . . . RC-12YC
Set Gap To: . . 0.030 inch (0.76mm)
Gasoline Capacity . . 4.2 U.S. quarts
Oil . . . . . . . . . . . . . . . SAE 30
In the State of California a spark arrestor is require
by law (Section 4442 of the California Public
Resources Co e). Other states may have similar
laws. Fe eral laws apply on fe eral lan s.
NOTE: If you equip the engine of your pressure
washer with a spark arrestor muffler, the spark
arrestor must be maintaine in effective working or er
by the owner/operator.
You can or er a spark arrestor through your
authorize Generac service facility. See Engine
Owners Manual for part number.
Model Number 1042-3
Serial Number
Date of Purchase
The mo el an serial numbers will be foun on a
ecal attache to the pressure washer. Recor
both serial number an ate of purchase an
keep in a safe place for future reference.

KNOW YOUR PRESSURE WASHER
Read this owners manual and safety rules before operating your high pressure washer.
Compare the illustrations with your high pressure washer to familiarize yourself with the locations of various
controls an a justments. Save this manual for future reference.
Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
5
Pump  Develops high pressure.
Recoil Starter  Use for starting the engine manually.
Spray Gun  Controls the application of water onto
cleaning surface with trigger evice. Inclu es safety
latch.
Adjustable Nozzle Extension  Attach the a justable
nozzle extension to the spray gun to provi e high
pressure stream. The a justable nozzle allows you to
a just the spray pattern which, in turn, a justs the force
of spray.
Dual Element Air Filter  Filter limits the amount of
irt an ust that gets in the engine.
Water Inlet  Connect gar en hose here.
High Pressure Outlet  Connection for high pressure
hose.
High Pressure Hose  Connect one en to the water
pump an the other en to the spray gun.
Goggles  Always use the enclose goggles or other
eye protection when running your pressure washer.
Automatic Cool Down System  Cycles water
through pump when water reaches 140°-145°F. Warm
water will discharge from pump onto ground. This
system prevents internal pump damage.
Pressure Control Knob  Varies the pressure of the
high pressure spray.
Oil Fill Cap  Fill engine with oil here. See page 7 for
oil recommen ations.
Gas Tank  Fill tank with regular unlea e gasoline.
Always leave room for fuel expansion.
Spray Gun
Adjustable Nozzle
Extension
High Pressure Hose
Recoil Starter
Goggles
Gas Tank
Water Inlet
Pressure Control Knob
Pump equippe with
Automatic Cool Down System High Pressure Outlet
Dual Element Air Filter
Oil Fill Cap

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
6
ASSEMBLY
Rea entire owners manual before you attempt to
assemble or operate your new pressure washer.
Your new pressure washer has been assemble at
the factory with the exception of those parts left
unassemble for shipping purposes.
REMOVE PRESSURE
WASHER FROM CARTON
 Remove parts box inclu e with pressure washer.
 Slice two corners at gui e han le en of carton
from top to bottom so the panel can be fol e own
flat, then remove all packing material.
 Roll pressure washer out of carton.
CARTON CONTENTS
Items in the carton inclu e:
 Main Unit
 Manual Bag Contents
 Manual
 O-Ring Kit
 Nozzle Cleaning Kit
 Parts Box (which inclu es the following):
 Vi eo
 Wireform
 Goggles
 Owners Manual
 Engine Manual
 Spray Gun
 Nozzle Extension
 High Pressure Hose
 Han le
 Parts Bag (which inclu es the following):
 2 carriage bolts
 2 knobs
If any of the above parts are missing or amage , call
the Pressure Washer Helpline at 18002 01408.
PREPARING THE PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or amage ,
call the Pressure Washer Helpline at 1-800-2 0-1408.
To prepare your pressure washer for operation you
will nee to perform these tasks:
 Attach the han le an attach the wire form that
hol s the high pressure hose an spray gun.
 Connect the high pressure hose to the spray gun
an the pump an connect water supply to the
pump.
 A oil to engine crankcase.
 A fuel to fuel tank.
Attach the Handle
 Place the han le onto the han le supports alrea y
connecte to the main unit. Make sure the holes in
the han le align with the holes on the han le
supports. (Figure 1)
Note: It may be necessary to move the han le
supports from si e to si e in or er to align the han le
so it will sli e over the han le supports.
Figure 1 — Attach the handle to the handle
supports.
Make sure
the holes on
the handle
are aligned
with the
holes on the
handle
supports
Handle
Handle
Supports

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
7
ASSEMBLY
 Insert the carriage bolts through the holes on the
han le an attach the plastic knobs. Tighten the
knobs by han (Figure 2).
 Insert the wire support with the longer arm positione
on the left. From this view (from rear of unit) the hook
shoul resemble a J. (Figure 3)
Add Engine Oil
IMPORTANT: Any attempt to start the engine before
it has been properly service with the recommen e
oil may result in an engine failure.
Note: When a ing oil to the engine crankcase, use
only high quality etergent oil rate with API service
classification SF,SG, SH or rate SAE 30 weight.
Select the oils viscosity gra e accor ing to your
expecte operating temperature. Do Not Use SAE
10W40 Oil.
Although multi-viscosity oils (5W30, 10W30, etc.)
improve starting in col weather, these multi-viscosity
oils will result in increase oil consumption when use
above 32°F. Check your engine oil level more
frequently to avoi possible amage from running low
on oil.
 Place pressure washer on a level surface.
 Clean area aroun oil fill an remove yellow oil fill
cap (Figure 4)
 Wipe ipstick clean. Pour oil into oil fill opening until
oil reaches FULL mark on the ipstick. Stop
occasionally to check oil level. DO NOT OVERFILL.
 Install oil ipstick, han tighten securely.
Note: Check oil often during engine breakin.
Add Gasoline
DANGER! Never fill fuel tank indoors.
Never fill fuel tank when engine is
running or hot. Do not smoke when filling
fuel tank.
WARNING! Never fill fuel tank completely
full. Fill tank to about 1/2" below the
bottom of the filler neck to provide space
for fuel expansion. Wipe away any fuel
spillage from engine and equipment
before starting.
DANGER! DO NOT operate or refuel
engine with spark plug access hole
cover removed. Allow engine to cool 2
minutes before refueling.
Figure 3 — Fit wire form on handle.
Figure 4 — Add oil to engine crankcase. Do not
attempt to start engine without
adding oil.
Oil Fill Cap
Figure 2 — Insert the carriage bolts and attach
the plastic knobs.
col er 32°F warmer
5W30 SAE 30

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
8
ASSEMBLY
The manufacturer recommen s fresh, clean unlea e
automotive gasoline with a minimum of 85 octane.
 Use clean fuel an store in approve , clean,
covere containers. Use clean fill funnels. Never
use stale gasoline left over from last season or
gasoline store for long perio s (over 30 ays).
 Clean area aroun fuel fill cap, remove cap.
(Figure 5).
 A UNLEADED regular gasoline, slowly, to fuel
tank. Use a funnel to prevent spillage.
 Install fuel cap an wipe up any spille gasoline.
Note: Some fuels, calle oxygenate or reformulate
gasolines, are gasoline blen e with alcohols or
ethers. Excessive amounts of these blen s can
amage the fuel system or cause performance
problems. If any un esirable operating systems occur,
use gasoline with a lower percentage of alcohol or
ether.
Connect Hose and Water
Supply to Pump
IMPORTANT: You must assemble wan an attach
all hoses before you start engine. Starting engine
without all hoses connecte an water supplie will
amage pump.
 Uncoil high pressure hose an attach one en of
hose to the base of the spray gun (Figure 6).
Tighten by han .
 Attach other en of high pressure hose to the high
pressure outlet on the pump (Figure 7). Tighten by
han .
 Before you connect your gar en hose to the water
inlet, inspect the Inlet Screen (see Figure 8). Clean
the screen if it contains ebris or have it replace if
amage . Do not run the pressure washer if the
inlet screen is damaged.
Figure 7 — Connect high pressure hose to
pump.
Figure 6 — Connect high pressure hose
to spray gun.
Figure 5 — Add gasoline to fuel tank.
Gas Cap
Connect High Pressure
Hose Here
Connect High
Pressure Hose
Here

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
9
ASSEMBLY
 Connect gar en hose to water inlet. Tighten by
han (Figure 8).
 Turn ON the water (open valve completely).
 Squeeze trigger on gun to purge pump system of
air an impurities.
CAUTION: Before starting the pressure
washer, be sure you are wearing
adequate eye protection.
 Attach nozzle extension to spray gun. Tighten by
han (Figure 9).
CHECKLIST BEFORE
STARTING ENGINE
If you have reache this point, look back over the
assembly to see if you have performe all of the
following.
 Check for properly tightene hose connections
(high pressure an water supply) an for tight
connections an that there are no kinks, cuts, or
amage to the high pressure hose.
 Check that oil has been a e to proper level in
engine crankcase before trying to start the pressure
washer.
 A proper gasoline to fuel tank.
 Provi e proper water supply (not to excee 140°F).
 Be sure to rea Safety Rules an Operation
sections before using the pressure washer.
Figure 9 — Connect nozzle extension to spray
gun.
Figure 8 — Connect the garden hose to water
inlet and turn ON the water.
Check Screen
for Damage

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
10
HOW TO USE YOUR
PRESSURE WASHER
If you have any problems operating your pressure
washer, please call the pressure washer helpline at
1-800-2 0-1408.
How to Start Your Engine
The best way to start your engine-powere pressure
washer for the first time is to follow these instructions
step-by-step.
 This pressure washer requires a water source that
flows at least 2.5 gallons per minute. Do not
attempt to siphon water from a non-pressurized
container. Place the pressure washer close
enough to an outsi e water source so that no more
than 50' of gar en hose is nee e .
 Check that the high pressure hose is tightly
connecte to the spray gun an to the pump. See
ASSEMBLY section for illustrations.
 Connect the gar en hose to water inlet on the
pressure washer pump an turn the water on all
the way.
IMPORTANT: Do not run pump without the water
supply connecte an turne on. You must follow this
caution or the pump will be amage .
 Set choke lever to Choke position. Note: This is
a multi-position choke.
 Move the throttle control lever to the Fast position.
Note: For a warm engine, be sure the throttle control
is in the Fast position an the choke lever is in the
Run position.
 Turn the fuel shutoff valve to the On position.
 Move the stop control to the On position.
 Squeeze the trigger on the spray gun to relieve air
pressure cause by turning ON the water. Water
will spew out the gun in a thin stream. Continue to
hol trigger until you have a stea y stream of water
an no air remains.This will make it easier to pull
start the engine. Release the trigger.
 Apply the safety latch to the spray gun trigger
(Figure 10).
 Grasp rope han le an pull slowly until you feel
some resistance. Then pull cor rapi ly to
overcome compression, prevent kickback an start
the engine. Let rope return to starter slowly.
Note: Always keep the throttle control in the Fast
position when operating the pressure washer.
 When the engine starts, gra ually move the choke
control from one position to the next until it is in the
Run position.
If after 3 pulls the engine fails to start, isengage the
spray gun safety latch, squeeze the trigger to relive
water pressure, re-engage the spray gun safety latch,
move the choke control to the Run position an pull
the recoil starter han le rapi ly (Max. 3 pulls).
How to Stop Your Pressure
Washer
Important: Do Not move the choke control to
Choke position to stop the engine. Backfire or
engine amage may occur.
 Move the throttle control to the Idle or Slow
position.
 Wait for the engine to i le own.
 Move the stop control to the Off position.
 Close the fuel shutoff valve.
Squeeze trigger on the spray gun to relieve
pressure in the hose. Simply shutting off the
engine will not release pressure in the system.
Note: A small amount of water will squirt out when
you release the pressure.
Figure 10 — Safety Latch.
Safety Latch ON

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
11
You now shoul know how to START your pressure
washer an how to STOP it. The information in this
section will tell you how to a just the spray pattern,
a just pressure, apply etergent. an rinse.
How to Use the Adjustable
Nozzle and Adjust Pressure
DANGER! Never adjust spray pattern
when spraying. Never put hands in front
of nozzle to adjust spray pattern.
 Sli e the nozzle forwar for low pressure. . Sli e
the nozzle backwar for high pressure (Figure 11).
 Twisting the nozzle from si e to si e a justs the
spray pattern from a narrow jet spray to a fan
pattern.
 Point the nozzle towar the groun an press the
trigger to test the pattern.
 Locate on the si e of the pump is a pressure
control knob. You can increase an ecrease the
pressure of the spray by turning the knob clockwise
or counterclockwise respectively (Figure 12).
Figure 11 — Using the adjustable nozzle.
Slide Nozzle Backward
for High Pressure
Mode
Slide Nozzle Forward
for low pressure
mode and detergent
application
Twist nozzle
counterclockwise for
fan spray pattern
Twist nozzle
clockwise for narrow
spray pattern
Figure 12 — Pressure control knob.
Pressure Control
Knob

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
12
Applying Detergent with the
Adjustable Nozzle
IMPORTANT: Use soaps designed specifically for
pressure washers. Househol etergents coul
amage the pump.
To apply detergent follow these steps:
 Review the use of a justable nozzles on Page 11.
 Prepare the etergent as require on the bottle.
 Hang the etergent solution on hook of the
wireform on the han le as shown (Figure 13).
 Place small filter en of the chemical injection tube
into the etergent container (Figure 13).
 Sli e the a justable nozzle forwar to low pressure
mo e. Detergent cannot be applie with nozzle in
high pressure position.
IMPORTANT: Detergent cannot be applie without
the water source turne on.
 Make sure gar en hose is connecte to water inlet.
Check that high pressure hose is connecte to
spray gun an pump (see ASSEMBLY), an start
engine.
 Apply etergent to a ry surface, starting from the
bottom an working up to avoi streaking.
 Allow the etergent to soak in for 3-5 minutes
before washing an rinsing.
 For washing, start at lower portion of area to be
washe an work upwar , using long, even,
overlapping strokes.
CAUTION: Keep the plastic chemical
injection tube from coming in contact with
the hot muffler. This will damage the
plastic tube. When inserting the filter into
a cleaning agent bottle, route the tube so
as to keep it from inadvertently contacting
the hot muffler.
Pressure Washer Rinsing
WARNING: Be extremely careful if you
must use the pressure washer from a
ladder, scaffolding or any other relatively
unstable location. Pressure in a running
washer builds as you climb. When you
press the trigger, the recoil from the initial
spray could force you to fall. The high
pressure spray could also force you to fall if
you are too close to the cleaning surface.
For Rinsing:
 Sli e nozzle backwar to high pressure an wait for
etergent to clear.
Note: You can also stop etergent from flowing by
simply removing the chemical injection tube from the
bottle.
 Keep the spray gun a safe istance from the area
you plan to spray.
 Apply a high pressure spray to a small area an
then check the surface for amage. If no amage
is foun , you can assume it is okay to continue
cleaning.
 Start at top of area to be rinse , working own with
the same overlapping strokes you use for
cleaning.
 For most effective cleaning, keep spray nozzle
between 8 to 24 inches away from cleaning
surface.
 If you get spray nozzle too close, especially using
high pressure mo e, you may amage the cleaning
surface.
 Do not get closer than 6 inches when cleaning
automobile tires.
Automatic Cool Down System
(Thermal Relief)
If you run the engine on your pressure washer for 3-5
minutes without pressing the trigger on the spray gun,
circulating water in the pump can reach a
temperature between 140145°F. When the water
reaches this temperature, the automatic cool own
system engages an cools the pump by discharging
the warm water onto the base of the unit. This
system prevents internal amage to the pump.
Figure 13 — Insert the small filter into container
of cleaning solution.

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
13
GENERAL MAINTENANCE
RECOMMENDATIONS
The warranty of the high pressure washer oes not
cover items that have been subjecte to operator
abuse or negligence. To receive full value from the
warranty, operator must maintain the high pressure
washer as instructe in this manual.
 Some a justments will nee to be ma e
perio ically to properly maintain your high pressure
washer.
 All a justments in the Service an A justments
section of the engine owners manual shoul be
ma e at least once each season.
BEFORE EACH USE
 Check engine oil level.
 Check water inlet screen for amage.
 Check high pressure hose for leaks.
 Check chemical injection tube an filter for amage.
 Check gun an wan assembly for leaks.
PRESSURE WASHER
MAINTENANCE
Check and Clean Inlet Screen
Examine screen on the water inlet. Clean if the
screen is clogge or replace if screen is amage .
Check High Pressure Hose
The high pressure hose can evelop leaks from wear,
kinking, or abuse. Inspect the hose each time before
using it. Check for cuts, leaks, abrasions or bulging of
cover, amage or movement of couplings. If any of
these con itions exist, replace hose imme iately.
DANGER: Water spraying from a leak is
capable of injecting material into skin.
Inspect hose each time before using it.
Never repair a high pressure hose.
Replace it with another hose that meets
the maximum pressure rating of your
pressure washer.
Check Chemical Injection Tube
Examine the filter on the chemical injection tube an
clean if clogge . The tube shoul fit tightly on barbe
fitting. Examine tube for leaks or tears. Replace the
filter or tube if either is amage .
Check Gun and Wand
Examine hose connection to gun an make sure it is
secure. Test trigger by pressing it an making sure it
springs back into place when you release it. Put safety
latch in On position an test trigger. You shoul not
be able to press trigger.
Purge Pump of Air and
Contaminants
To remove the air from the pump, follow these steps:
 Set up the pressure washer as escribe in the
ASSEMBLY section an connect the water supply.
 Remove the wan extension from the gun.
 Squeeze the trigger on the gun an hol .
To remove any contaminants from the pump, follow
these steps:
 Set up the pressure washer as escribe in the
ASSEMBLY section, an connect the water supply.
 Remove the nozzle extension from the spray gun.
 Start the engine accor ing to instructions in
OPERATION section.
 Squeeze the trigger on the spray gun an hol .
 When the water supply is stea y an constant,
engage the safety latch an refasten the nozzle
extension.

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
14
Cleaning Chemical Injection Tube
If you have use the chemical injection tube you must
flush it with clean water before stopping the engine.
 Place the small filter en of the chemical injection
tube in a bucket of clean water.
 Sli e the a justable nozzle forwar .
 Squeeze the spray gun trigger for two minutes to
flush the chemical injection tube.
 Shut off the engine.
Important: Simply shutting OFF engine will not release
pressure in the system. When engine has shut own,
squeeze the trigger on the gun to relieve the
pressure in the hose.
Nozzle Maintenance
If the a justable nozzle becomes restricte or
clogge with foreign materials, such as irt, excessive
pump pressure may evelop. If this nozzle becomes
partially clogge , it can cause a pulsing sensation
uring use. This generally is not a pump relate
problem, but rather a clogge or partially restricte
a justable nozzle.
If the a justable nozzle becomes clogge or partially
restricte , imme iately clean the nozzle with the kit
inclu e with your pressure washer by following
these instructions:
 Shut off the engine an turn off the water supply.
 Separate the nozzle extension from the gun.
 A just the nozzle extension to the stream position.
 Remove nozzle from the en of the wan extension
(Figure 17) using a 2mm or 5/64 allen wrench (like
the one inclu e in the kit).
 Use the wire inclu e in the kit (Figure 17) or a
small paper clip to free the foreign materials
clogging or restricting the nozzle.
Figure 17 — Removing and cleaning nozzle.
 Remove a itional ebris by back flushing water
through wan extension (Figure 18). Back flush
between 30 to 60 secon s. Turn nozzle extension
to stream spray an move nozzle forwar an
backwar while flushing.
Figure 18 — Backflushing the nozzle.
 Reinstall nozzle into the wan extension. DO NOT
overtighten.
 Reconnect the nozzle extension to the spray gun.
 Reconnect the water supply, turn on the water, an
start the engine.
 Test the pressure washer by operating with nozzle
in the high an in the low position.
ENGINE MAINTENANCE
See the Engine Owners Manual for instructions on
how to properly maintain the engine.
SERVICE AND
ADJUSTMENTS
See the Engine Owners Manual for instructions on
how to properly service an a just the engine.

Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
15
PREPARING THE UNIT FOR
STORAGE
Water shoul not remain in the unit for long perio s of
time. Se iments of minerals can eposit on pump
parts an freeze pump action. If you o not plan to
use the pressure washer for more than 30 ays,
follow this proce ure:
1.Flush chemical injection tube by placing the injector
filter into a pail of clean water while running
pressure washer an squeezing the spray gun
trigger with the a justable nozzle in low pressure
mo e. Flush for two minutes.
2.Shut off the engine an let it cool, then remove all
hoses.
3.Place throttle lever in STOP position.
CAUTION: Be sure throttle lever is in
STOP position before you continue. If
you start engine without proper water
supply connected, you can damage the
pump.
4.Empty the pump of all pumpe liqui s by pulling
recoil han le about 6 times. This shoul remove
most of the liqui in the pump.
NOTE: To protect unit from freezing temperatures,
pour RV Antifreeze flui (antifreeze without any
alcohol) into a 3-foot section of gar en hose
connecte to inlet a apter an pulling recoil han le
twice.
5.Store in a clean, ry area.
STORING THE ENGINE
See the engine Owners manual for instructions on
how to properly store the engine.

Troubleshooting Points
Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
16
Problem Cause Correction
Pump has following problems: 1. Nozzle in low pressure mode. 1. Pull nozzle backward for high
failure to produce pressure, erratic pressure mode.
pressure, chattering, loss of pressure, 2. Water inlet is blocked. 2. Clear inlet.
low water olume. 3. Inadequate water supply. 3. Pro ide adequate water flow.
4. Inlet hose is kinked or leaking. 4. Straighten inlet hose, patch leak.
5. Clogged inlet hose strainer. 5. Check and clean inlet hose
strainer.
6. Water supply is o er 140°F. 6. Pro ide cooler water supply.
7. Outlet hose is blocked or leaks. 7. Clear blocks in outlet hose.
8. Gun leaks. 8. Replace gun.
9. Nozzle is obstructed. 9. Clear nozzle.
10. Pump is faulty. 10. Contact Generac ser ice facility.
Detergent fails to mix with spray. 1. Chemical injection tube is not submerged. 1. Insert chemical injection tube into
detergent.
2. Chemical injection tube filter is clogged. 2. Clean or replace filter/chemical
injection tube.
3. Nozzle is in high pressure mode. 3. Push nozzle forward for
low pressure mode.
Engine runs good at no-load but bogs Engine speed is too slow. Mo e throttle control to FAST .
when load is added. position. If engine still bogs down
contact Generac ser ice facility.

Troubleshooting Points
Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
17
PROBLEM CAUSE CORRECTION
Engine will not start; or starts 1. Low oil le el. 1. Fill crankcase to proper le el.
and runs rough. 2. Dirty air cleaner. 2. Clean or replace air cleaner.
3. Out of gasoline. 3. Fill fuel tank.
4. Stale gasoline. 4. Drain gas tank; fill with fresh fuel.
5. Spark plug wire not connected 5. Connect wire to spark plug.
to spark plug.
6. Bad spark plug. 6. Replace spark plug.
7. Water in gasoline. 7. Drain gas tank; fill with fresh fuel.
8. O erchoking. 8. Open choke fully and crank
engine.
9. Excessi ely rich fuel mixture. 9. Contact Generac ser ice facility.
10. Intake al e stuck open or closed. 10. Contact Generac ser ice facility.
11. Engine has lost compression. 11. Contact Generac ser ice facility.
Engine shuts down during operation. 1. Out of gasoline. 1. Fill fuel tank.
2. Low oil le el. 2. Fill crankcase to proper le el.
Engine lacks power. Dirty air filter. Replace air filter.
Engine hunts or falters. Choke is opened too soon. Mo e choke to halfway position
until engine runs smoothly.

18
Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
Exploded View  Pressure Washer
Drawing No. B3288

19
Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
Parts List  Pressure Washer
Drawing No. B3288
Item Part # Qty Description Item Part # Qty Description
1 A1040D 1 HOSE, 4-1/2 Chemical Clear
2 A1041 1 FILTER, Chemical Hose
3 70453 1 TAG, Warning Oil
4 97178 2 KNOB, Han le 1/4 - 20 PW
5 31669 2 BOLT, 1/4 - 20 x 1-3/4 Carriage
6 21424 1 CONNECTOR, Gar en Hose
7 99583 8 NUT, Flange Lock 5/16-28
8 B1982 1 BUMPER
9 97054 1 TAG, Pres. A just
10 B1288 1 TAG, PW Breather Cap
11 B2718 1 CLAMP, Hose 7/16" Dia.
13 32713 1 SCREW, Taptite #10 - 32 x 5/8" Lg
12 97566 1 TAG, Nozzle
14 45771 8 NUT, M8 - 1.25 Hex
15 22129 8 LOCKWASHER, M8
16 21217 4 MOUNT, Rubber Shock
17 B1236F NOZZLE, Replacement 1.25 mm
18 97100 1 CAP, H.P. A aptor
19 97098 1 CAP, Gar en Hose Inlet
20 B2043 7 BOLT, 5/16 - 18 x 1-3/4" Carriage
21 N/A 1 ASSEMBLY, Pump
(see pump explo e view)
22 B1827 1 ENGINE
23 B1983 1 HANDLE
24 B1631A 1 BILLBOARD, Plastic
25 B1932 1 DECAL, Instructions
26 B1981 2 SUPPORT, Han le
27 B2192 1 DECAL, Generac
28 B1760 2 ASSEMBLY, 10" Tire & Wheel
29 75402 2 PUSHNUT, .50 Dia.
30 AB1770 1 BASE
31 52858 2 NUT, M8 1.25 Locking
32 42909 2 HHCS, M8 1.25 x 30
33 50190 2 WASHER, M8 Flat
34 27007 2 MOUNT, Donut Type Vibration
35 20566 1 DECAL, Generac #1-800
36 B2150 1 HOOK , Gun
37 B2146 1 DECAL, Logo
41 B3057 1 KIT, O-Ring
42 B1969 1 HOSE, High Pressure
43 87815 1 GOGGLES, Saftey
44 B1867F 1 WAND
45 B1861 1 GUN, High Pressure
46 B2203 1 KIT, Han le Fastening
47 B2163 1 KIT, Cleaning
48 B1460 2 CAP, Vinyl (black)
49 B2168 1 HANGER, Hose, Gun, Jug
50 B2516 1 CAP, Vinyl (black)
51 B3236 1 MANUAL

20
Generac 2250PSI High Pressure Washer
GENERAC
The Reliable Ones
Exploded View  Pump
Drawing No. B3186
