General MDF15 User manual

OPERATOR MANUAL
Includes Safety, Service and Replacement Part Information
Model MDF15 and MDF35
Long Reach Air Tool
Form: GOM6019801
Version 1.0
Do not discard this manual. Before operation, read and
comprehend its contents. Keep it readily available for reference
during operation or when performing any service related
function. When ordering replacement parts, please supply the
following information: model number, serial number and part
number. For customer service assistance, telephone
800.533.0524, +507.451.5510. Our Customer Service Department
telefax number is 877.344.4375 (DIGGER 5), +507.451.5511.
There is no charge for customer service activities .
Internet address: http://www.generalequip.com.
E-Mail location: [email protected].
Copyright 2003, General Equipment Company.

Manufacturers of light construction
equipment
620 Alexander Drive SW • P.O. Box 334 • Owatonna, Minnesota 55060-0334 USA
Telephone: [phone] • International Telephone: [phone]
Telefax: +507.451.5511 • Sales/Customer Service Department Toll Free: 877.344.4375 (DIGGER 5)
http://www.generalequip.com • e-mail: [email protected]
Congratulations on your decision to purchase a General light construction product. From our
humble beginnings in 1955, it has been a continuing objective of General Equipment Company to
manufacture equipment that delivers uncompromising value, service life and investment return.
Because of this continuous commitment for excellence, many products bearing the General name
actually set the standards by which competitive products are judged.
When you purchased this product, you also gained access to a team of dedicated and
knowledgeable support personnel that stand willing and ready to provide field support
assistance. Our team of sales representatives and inhouse factory personnel are available to
ensure that each General product delivers the intended performance, value and investment return.
Our personnel can readily answer your concerns or questions regarding proper applications,
service requirements and warranty related problems.
General Equipment Company places great emphasis upon not only product performance, but also
on product safety. It is important to remember that this product will only be as safe as the operators
which utilize it. It just makes good, common sense to take the time to read and fully understand the
contents of this manual before attempting to utilize this product in service. If you ever do have any
questions or concerns about this product, please feel free to contact our Customer Service
Department at the telephone numbers listed below for assistance.
If there is anything that I can do to assist your efforts when utilizing this product, please do not
hesitate to contact me. For assistance after normal business hours, telephone me at 507.451.9409
or 507.363.1033. If I am not immediately available, I will attempt to return your call as soon as
possible.
Sincerely,
GENERAL EQUIPMENT COMPANY
Dennis Von Ruden
President

DESCRIPTION PAGE
Notice to Operators
Operational Instructional Data Sheet
Safety Precautions
PREPARATION.
OPERATION.
MAINTENANCE, REPAIR AND STORAGE.
Assembly
INSTALLING THE AIR HOSE ASSEMBLY.
Before Operating the Long Reach Air Tool
INFORMATION RELATIVE TO MINIMUM SAFETY, OPERATIONAL
STANDARDS AND PARAMETERS FOR THE USE OF THE LONG REACH
AIR TOOL.
INSTALLING THE MODEL MDF-1000 AIR CADDY.
Operation
OPERATIONAL DISCLAIMER.
CALIFORNIA PROPOSITION 65 DISCLAIMER.
SAFETY RELATED EQUIPMENT AND APPAREL DISCLAIMER.
SET UP FOR OPERATION.
DETERMINATION OF POTENTIAL SUBSURFACE HAZARDS IN THE
PROPOSED WORK LOCATION(S).
INSTALLING AN ACCESSORY TOOL.
ATTACHING THE LONG REACH AIR TOOL TO THE AIR CADDY AND AIR
HOSE ASSEMBLIES.
OPERATING THE LONG REACH AIR TOOL.
STOPPING THE LONG REACH AIR TOOL.
TEMPORARY STORAGE FOR THE LONG REACH AIR TOOL WHILE ON
THE JOB SITE.
Troubleshooting
Repair
DISASSEMBLY OF THE CYLINDER ASSEMBLY FOR GENERAL
MAINTENANCE AND/OR REPAIR PURPOSES.
DISASSEMBLY OF THE THROTTLE CONTROL VALVE FOR GENERAL
MAINTENANCE AND/OR REPAIR PURPOSES.
4
5
7
7
8
9
10
10
12
12
13
14
14
15
15
15
16
16
18
20
23
23
23
24
24
26
Table of Contents
MDF Series LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 2

MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 3
DESCRIPTION PAGE
Storage
Specifications
Replacement Parts Diagrams
Accessory Tool Applications Chart
26
27
29
40

Notice to Operators
IF YOU CAN NOT READ OR DO NOT FULLY UNDERSTAND THE CONTENTS OF THIS
MANUAL, PLEASE CONTACT THE FACTORY FOR PROPER ASSISTANCE BEFORE
ATTEMPTING TO OPERATE THIS PRODUCT.
SI TU NO PUEDES LE'ER O NO COMPRENDES EL CONTENIDO DE ESTE MANUAL
FAVOR DE PONERSE EN CONTACTO CON LA. FABRICA PARA ASSISTENCIA- A
PROPIA ANTES DE INTENTAR PARA OPERAR ESTE PRODUCTO.
SOLLTEN SIE DIESE GEBRAUCHSANWEISUNG NICHT LESEN KOENNEN ODER ES
NICHT VOLLKOMMEN VERSTEHEN, WENDEN SIE SICH BITTE AN DEN
HERSTELLER FUER RICHTIGE HILFE EHE SIE VERSUCHEN DIESES PRODUKT ZU
OPERIEREN.
SI VOUS NE LISEZ OU NE COMPRENDRE ENTIEREMENT LES MATIERES DE CE
MANUEL, S'IL VOUS PLAIT, CONTACTEZ L'USINE POUR L'ASSISTANCE
APPROPRIEE AVANT D'UTILISER LE PRODUIT.
These safety alert symbols identify important safety messages in this manual. When you see these
symbols, be alert to the possibility of personal injury and carefully read the message that follows.
Do not allow anyone to operate the Long Reach Air Tool without first reading this Operator Manual and
becoming familiar with its operation. The manufacturer of this Long Reach Air Tool has gone to great
extremes to provide the owner(s) and/or operator(s) with the finest equipment available for its intended job
function of removing materials from vertical and horizontal surfaces. Yet, the possibility exists that the Long
Reach Air Tool can be utilized in and/or subjected to job applications not perceived and/or anticipated by the
manufacturer. Such misuse and/or misapplication of the Long Reach Air Tool can lead to the possibility of
serious damage, injury or even death. It is the responsibility of the owner(s) and/or operator(s) to determine
that the Long Reach Air Tool is being utilized and/or operated within the scope of its intended job function.
It is the responsibility of the owner(s) and/or operator(s) to establish, monitor and constantly upgrade all
safety programs and/or practices utilized in and for the operation of the Long Reach Air Tool. The purpose
of such programs is to provide for owner(s') and/or operator(s') safety. Operators must be instructed to
recognize and avoid unsafe conditions associated with their work (29 CFR 1926.21 (b)(2)) and/or applicable
updated revisions. It is the responsibility of the owner(s) and/or operator(s) to determine that no
modifications and/or alterations have been made to the Long Reach Air Tool. Modifications and/or
alterations can lead to the possibility of serious damage, injury or even death. It is the responsibility of the
owner(s) and/or operator(s) to make this Operator Manual available for consultation during all phases of
operation. Refer to OSHA 2207 and/or applicable updated revisions which contains all OSHA job safety and
health rules and regulations (1926 and 1910) covering construction.
The concept of portable, pneumatically powered, long reach type air tools has been successfully
utilized for many years as a practical solution to removing materials from vertical and horizontal
surfaces. The basic concept is proven and well accepted within the associated marketplaces. Use of
a Long Reach Air Tool requires strenuous work activity. This type of work activity can be considered
to be greater in magnitude than that experienced with the use of many other types of both light
MDF Series LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 4

MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 5
construction and lawn and garden related equipment. This type of work activity should only be
attempted by operators of adequate physical size and stature, mental awareness and physical
strength and condition. The body parts most noticeably affected during the material removal
process are the arms, hands, wrists, shoulders, lower back and legs. The process can also produce
excessive stress/strain directly to the back muscles, spinal vertebrae and many other body parts.
Back and wrist related pain can be side effects of utilizing a Long Reach Air Tool. A potential
operator with a chronic back related problem or a history of back and/or other medically related
problems should not attempt to utilize the Long Reach Air Tool. Use of the Long Reach Air Tool may
only aggravate this and any other medically related problem. Because of the diverse type of
prevailing job applications, job site conditions, operator experience levels and operator physical
characteristics, no warranty, guarantee, representation and/or liability is made by the manufacturer
as to the absolute correctness or sufficiency of any operational procedure, operational position
and/or technique. There is no absolute guarantee that an operator of any given experience level,
physical size and/or physical condition will be immune to the possibility of and/or probable physical
side effects of the normal use of the Long Reach Air Tool. Each potential operator must be made
aware of and assume the operational and physical liability described and/or associated with the use
of the Long Reach Air Tool. Improper use of the Long Reach Air Tool can result in property damage
and/or personal injury, including death. Each potential operator not willing to assume the
operational and physical liability described and/or associated with the use of the Long Reach Air
Tool, should not operate it. Proper levels of operator experience, skill and common sense are
essential for maximizing the safe and efficient operation of the Long Reach Air Tool.
Record the Long Reach Air Tool serial number in the spaces provided below.
_______________ Model Number
_______________ Serial Number
_______________ Date of Purchase
Specifications and design are subject to change without notice or obligation. All specifications are
general in nature and are not intended for specific application purposes. General Equipment
Company reserves the right to make changes in design, engineering or specifications and to add
improvements or discontinue manufacture at any time without notice or obligation. General
Equipment Company and its agents accept no responsibility for variations which may be evident in
actual products, specifications, pictures and descriptions contained in this publication.
Operator Instructional Data Sheet
The following undersigned operators of the Long Reach Air Tool described and/or pertaining to this
Operator Manual have received formal safety and operational information/instruction from the
undersigned owner(s)/instructor(s) in accordance to OSHA 29 CFR 1926.21 (b)(2) and/or applicable
updated revisions pertaining to, but not necessarily limited to the:
1) READING, COMPREHENSION AND ACKNOWLEDGEMENT OF THE MATERIAL COMPRISING THE
ENTIRE CONTENTS OF THE APPLICABLE OPERATOR MANUAL AND THE APPLICABLE SAFETY AND
OPERATIONAL INFORMATION VIDEO TAPE FOR THE LONG REACH AIR TOOL.
2) FORMALIZED OPERATOR SAFETY PROGRAM TO BE DEVISED BY THE OWNER OF THE LONG
REACH AIR TOOL IN CONJUNCTION WITH THE CONTENTS OF THE APPLICABLE OPERATOR

MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 6
MANUAL AND THE APPLICABLE SAFETY AND OPERATIONAL INFORMATION VIDEO TAPE FOR THE
LONG REACH AIR TOOL.
3) OSHA RULES AND REGULATIONS RESEARCHED FOR AND/OR BY THE OWNER OF THE LONG
REACH AIR TOOL AND DEEMED APPLICABLE TO THE SAFE AND PROPER USE AND/OR
OPERATION OF THE LONG REACH AIR TOOL FOR ANY SPECIFIC JOB APPLICATION.
4) LOCAL LAWS, REGULATIONS AND CUSTOMS RESEARCHED FOR AND/OR BY THE OWNER OF
THE LONG REACH AIR TOOL AND DEEMED APPLICABLE TO THE SAFE AND PROPER USE AND/OR
OPERATION OF THE LONG REACH AIR TOOL FOR ANY SPECIFIC JOB APPLICATION.
5) FORMALIZED MAINTENANCE PROGRAM FOR THE LONG REACH AIR TOOL TO BE DEVISED BY
THE OWNER OF THE LONG REACH AIR TOOL IN ACCORDANCE WITH, BUT NOT NECESSARILY
LIMITED TO, THE SPECIFICATIONS, GUIDELINES AND OPERATIONAL INFORMATION CONTAINED
IN THE APPLICABLE OPERATOR MANUAL.
6) COMPREHENSIVE OPERATIONAL INSTRUCTIONS FOR THE CORRECT AND PROPER USE OF
THE LONG REACH AIR TOOL AS PER THE CONTENTS OF THE APPLICABLE OPERATOR MANUAL
AND THE APPLICABLE SAFETY AND OPERATIONAL INFORMATION VIDEO TAPE.
_______________ Operator _______________ Owner/Instructor __________ Date
_______________ Operator _______________ Owner/Instructor __________ Date
_______________ Operator _______________ Owner/Instructor __________ Date
_______________ Operator _______________ Owner/Instructor __________ Date
_______________ Operator _______________ Owner/Instructor __________ Date
_______________ Operator _______________ Owner/Instructor __________ Date
NOTE: INSERT COPIES OF THIS PAGE WITHIN THE OPERATOR'S MANUAL IF SPACE FOR
ADDITIONAL OPERATORS IS REQUIRED.

Safety Precautions
THE FOLLOWING SAFETY PRECAUTIONS
PROVIDE SOME COMMON SENSE GUIDES TO
PROMOTE SAFETY AND EFFICIENCY WITH THE
LONG REACH AIR TOOLS. NO WARRANTY,
GUARANTEE OR REPRESENTATION IS MADE BY
THE MANUFACTURER AS TO THE ABSOLUTE
CORRECTNESS OR SUFFICIENCY OF ANY
INFORMATION OR STATEMENT. THESE SAFETY
PRECAUTIONS ARE INTENDED TO DEAL
PRINCIPALLY WITH COMMON PRACTICES AND
CONDITIONS ENCOUNTERED IN THE USE OF THE
LONG REACH AIR TOOLS AND ARE NOT
INTENDED TO BE ALL INCLUSIVE. PROPER
LEVELS OF OPERATOR EXPERIENCE, SKILL AND
COMMON SENSE ARE ESSENTIAL FOR SAFE AND
EFFICIENT OPERATION.
THE BY PRODUCTS CREATED FROM THE
OPERATION OF LONG REACH AIR TOOLS CAN
CONTAIN CHEMICALS KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE CANCER, BIRTH
DEFECTS OR OTHER REPRODUCTIVE HARM.
THIS STATEMENT IS MADE IN COMPLIANCE TO
CALIFORNIA PROPOSITION 65.
INCORRECT USE OF THE LONG REACH AIR TOOL
CAN RESULT IN PROPERTY DAMAGE, PERSONAL
INJURY OR EVEN DEATH. TO REDUCE THIS
POSSIBILITY, GIVE COMPLETE AND UNDIVIDED
ATTENTION TO THE JOB AT HAND AND FOLLOW
THESE SAFETY PRECAUTIONS:
PREPARATION.
1) The Long Reach Air Tools are a specialized type of
powered equipment, designed for specific job functions
and require adequate and thorough instruction
BEFORE they are operated. The size, power,
complexity and operating characteristics of these types
of powered equipment would dictate that each operator
must receive adequate, professional instruction
regarding the proper operation of the Long Reach Air
Tool before being allowed to utilize it. BEFORE
attempting to utilize a Long Reach Air Tool read this
Operator's Manual and watch the applicable Safety
and Operational Information Video Tape to familiarize
each operator with its correct operating procedures.
Avoid the urge not to take the necessary time to read
this Operator's Manual before operating the Long
Reach Air Tool. DO NOT OPERATE THE LONG
REACH AIR TOOL UNTIL EACH OPERATOR
COMPLETELY COMPREHENDS THE CONTENTS
OF THIS MANUAL, THE APPLICABLE SAFETY AND
OPERATIONAL INFORMATION VIDEO TAPE, AND
APPLICABLE SUPPLEMENTAL INFORMATION.
2) Develop a comprehensive program for the safe
operation of the Long Reach Air Tool by its owner(s)
and/or operator(s). Such a program will include, but is
not limited to: instructional requirements for operation,
applicable OSHA requirements, local laws and
regulations, job site safety and a Long Reach Air Tool
maintenance program. Constantly examine and
upgrade this program to guarantee owner(s) and/or
operator(s) safety. Each operator must be fully
instructed regarding the specifics of this safety
program.
3) Determine that the Long Reach Air Tool is in its
original, factory configuration and has not been
modified in any manner. Many modifications can result
in potentially dangerous configurations that can lead to
property damage and/or personal injury. If there are
any questions about possible modifications made to
the Long ReachAir Tool, contact the Customer Service
Department for specific information BEFORE
utilization. There is no charge for this service.
4) Minors should never be allowed to operate the Long
Reach Air Tool. Bystanders, especially children and
animals, should not be allowed in the area where the
Long Reach Air Tool is in use. The hole digging
process can result in flying particles being emitted at
high velocity and striking the operator and/or
onlookers. This can lead to the possibility of property
damage and/or personal injury. Keep all body parts,
loose clothing, foreign objects and onlookers clear of
the rotating auger and/or auger extensions.
5) Operators must be in proper physical condition,
mental health and not under the influence of any
substance (drugs, alcohol, etc.) which might impair
vision, dexterity or judgment. Working with the Long
Reach Air Tool is strenuous. If you have any condition
that might be aggravated by strenuous work, check
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 7

with your doctor BEFORE operating the Long Reach
Air Tool. Guard against the possibility of back related
injuries. Always lift the Long Reach Air Tool with leg
muscles and not with the back.
6) Prolonged use of the Long Reach Air Tool (or other,
similar machines) exposes the operator to vibrations
which may produce Whitefinger Disease (Raynaud's
Phenomenon). This phenomenon reduces the hand's
ability to feel and regulate temperature, produces
numbness and burning sensations and may cause
nerve and circulation damage and tissue necrosis.
Antivibration systems do not guarantee that you will not
sustain Whitefinger Disease. Therefore, continuous
and regular users should closely monitor the condition
of their hands and fingers. After each period of use,
exercise to restore normal blood circulation. If any of
the symptoms appear, seek medical advice
immediately. It is recommended that special gloves,
designed to reduce the effects of Whitefinger Disease
be worn whenever possible and practical. Contact the
Customer Service Department for additional
information. There is no charge for this service.
7) Clothing must be sturdy and snug fitting, but allow
complete freedom of movement. Never wear loose
fitting jackets, scarves, neckties, jewelry, flared or
cuffed pants or anything that could become caught on
controls or moving parts. Wear long pants to protect
your legs. Protect your hands with heavy duty, nonslip
gloves to improve your grip. Good footing is most
important when operating the Long Reach Air Tool.
Wear sturdy boots with nonslip soles. Steel-toed safety
shoes are highly recommended. Keep shoes properly
laced. Never wear tennis shoes or other, similar type
shoes which afford little or no protection. Wear an
approved safety hard hat to protect the operator'(s')
head(s) where there is a danger of head injuries. Noise
generated by the Long Reach Air Tool and the actual
operating process itself can damage your hearing.
Wear approved sound barriers (ear plugs or ear
mufflers) to protect your hearing. Continuous and
regular operators should have their hearing checked
regularly.
8) Visually inspect the Long Reach Air Tool and
accessory tools for damaged or worn parts. Look for
loose and/or damaged handle grips. Check for loose
and/or broken parts. Determine that operator controls
work freely, all safety devices are operative and
information/safety decals are readable. Check to
determine that the Long Reach Air Tool and all related
accessories are in good mechanical condition
BEFORE utilization.
9) Contact appropriate representatives to determine
if/where electrical cables, gas lines and other
hazardous items are buried under the work surface
BEFORE utilization. The Long Reach Air Tool and
related accessories are not classified as being
insulated. Contact with buried electrical cables, gas
lines and other hazardous items can result in
electrocution and/or an explosion.
10) Know how the controls operate. Know how to stop
the Long Reach Air Tool quickly in an emergency.
11) Never exceed the recommended capacities of the
Long Reach Air Tool. Refer to the Specifications
section of this manual for more detailed information.
Always utilize the correct accessory tool designed for
use with the Long Reach Air Tool. Use of an incorrect
accessory tool can result in property damage and/or
personal injury.
OPERATION.
1) Give complete and undivided attention to the job at
hand. Do not chew gum, smoke and/or use smokeless
tobacco while utilizing the Long Reach Air Tool. Do not
attempt to eat and/or drink while utilizing the Long
ReachAir Tool. Determine that eyeglasses, hearing aid
devices and other medical related devices are properly
secured. Keep shoes properly laced. Use of the Long
Reach Air Tool is strenuous and causes fatigue. Help
prevent the cause of an accident. Plan to take work
breaks as required to help maintain proper mental and
physical alertness.
2) The MDF Series Long Reach Air Tools are not
sealed or insulated. Do not operate any Long Reach
Air Tool in an explosive atmosphere or near
combustible materials. Refer to current OSHA and
National Electric Code® rules and regulations.
3) The MDF Series Long ReachAir Tools are designed
for use by one operator. Use of the Long Reach Air
Tool by more then one operator can lead to confusion
and loss of control, resulting in property damage and/or
personal injury. Never operate the Long Reach Air Tool
with an improper number of operators. If it is felt that
more than one operator is required to furnish additional
"down pressure" to the accessory tool STOP and
contact the Customer Service Department for specific
operational and service/maintenance information.
There is no charge for this service.
4) Do not operate the Long Reach Air Tool with
onlookers close by. Caution all onlookers to stand
clear. The operational process can result in flying
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 8

particles being emitted at high velocity and striking the
operator and/or onlookers. This can lead to the
possibility of property damage and/or personal injury.
Keep all body parts, loose clothing and foreign objects
clear of the accessory tool.
5) Do not utilize a shovel and/or foreign object to
remove loose material from around the work area while
the Long Reach Air Tool is in use. Such a practice can
result in the shovel and/or foreign object to become
entrapped by the accessory tool, leading to property
damage and/or personal injury.
6) Operate the Long Reach Air Tool only in a well
ventilated area. Dusts created as a by product of the
operating process can be hazardous. Breathing these
dusts can result in property damage and/or personal
injury. Operate the Long Reach Air Tool only
when/where visibility and light are adequate for the job
at hand. Work carefully. Always hold the Long Reach
Air Tool firmly with both hands. Wrap your fingers
around the barrel, keeping it cradled between your
thumbs and fingers. Always make sure the handle
grips are in good condition and free of moisture, pitch,
oil or grease. Wear gloves to improve your grip. Never
leave the Long Reach Air Tool operating unattended.
7) Stop the Long Reach Air Tool when moving it on the
job site. Allowing the Long Reach Air Tool to remain
operating while moving it substantially increases the
potential for property damage and/or personal injury.
Special care must be exercised on slippery conditions
and on difficult, uneven surfaces. Watch for cracks,
high spots and other, surface irregularities. Keep
proper footing and balance at all times. The normal use
of the Long Reach Air Tool is on level surfaces. Other
terrains can be dangerous and should be avoided.
Only properly trained operators should attempt these
techniques.
8) Because the Long Reach Air Tool is classified as a
low cost, hand held, portable type machine, it is limited
in the number of practical and/or suitable job
applications. A particular job site, actual surface
conditions, job specifications and operator
skill/common sense may dictate that a different type of
machine (with characteristics of higher purchase cost,
being mounted to a carrier vehicle, with greater
horsepower and less mobility), method and/or process
be utilized to properly complete the job with the degree
of efficiency and safety required. Contact the Customer
Service Department for specific information regarding
suitable job applications, job site surface conditions
and operator experience/skill/common sense
recommendations for the Long Reach Air Tool
BEFORE utilization. There is no charge for this service.
MAINTENANCE, REPAIR AND STORAGE.
1) Use only genuine, approved replacement parts and
accessories for maintenance and repair. Use of parts
and accessories manufactured by others can result in
property damage and/or personal injury.
2) Follow the Service instructions as outlined in the
appropriate section of this manual.
3) Always stop and disconnect the compressed air
source BEFORE checking or working on the Long
Reach Air Tool.
4) Always properly maintain the Long Reach Air Tool.
Frequently check all fasteners and individual parts.
Built in safety features are effective only if they are
maintained in good working condition. Replace any
questionable part or assembly with a genuine, factory
approved, replacement part. Do not forsake proper
maintenance for the price of a few replacement parts.
Proper maintenance does not cost...it actually pays
dividends. Do not attempt any maintenance repair
work not described in this manual. Have such work
performed at your dealer's service facility.
5) Determine the throttle control is not damaged and
allows for complete freedom of movement to allow it to
perform its intended job function. Do not operate the
Long Reach Air Tool with a damaged throttle control.
6) Maintain all safety and operation decals in proper
condition. If any decal becomes damaged and/or
unreadable, replace with a genuine, factory approved,
replacement part only.
7) The Long ReachAirTool may utilize self locking type
hexagon head nuts to minimize the effects of vibration.
Replace all self locking hardware with genuine, factory
approved, replacement parts only.
8) Replace the accessory tool when signs of excessive
wear is seen. When such components are not replaced
at proper intervals, excessive wear will occur. Utilizing
accessory tools that are past their useful service life or
that have not been properly maintained can result in
substandard productivity, excessive property damage
and/or personal injury. Accessory tool service life can
be greatly extended with a consistent maintenance
program.
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 9

Assembly
Open the shipping carton immediately upon receipt.
Visually inspect the contents of the carton for freight
damage and/or missing parts. If shipping damage is
evident, contact the delivering carrier immediately to
arrange for an inspection of the damage by their claims
representative. Federal law requires that a claim be
filed within a specific time period. If missing parts are
detected, notify your dealer or contact the Customer
Service Department for assistance in obtaining them.
Included in the shipment for all models of Long Reach
Air Tools should be the following:
1 each, Long Reach Air Tool Assembly.
1 each, air hose assembly, complete with support
spring.
Accessory tools and/or replacement parts will be
shipped in separate shipping containers.
INSTALLING THE AIR HOSE ASSEMBLY.
Applications: All models.
Tools Required:
1 each, long nose pliers.
1 each, small, adjustable wrench.
Parts Required:
1 each, 1/4 inch female quick type coupling device of
operator's choice, complete with appropriate
retention mechanism.
The Long Reach Air Tool is shipped from the factory
complete with a 60 inch nominal length air hose
assembly. No device for direct coupling to the air
source is provided, given the variances in job site
applications, available power sources and
mechanisms for delivering the required air flow to the
air tool.
All coupling devices utilized with the air tool must
comply with all applicable OSHA and/or industry
standards for configuration, capacity and safety.
UTILIZING COUPLING DEVICES NOT MEETING
APPLICABLE OSHA AND/OR INDUSTRY
STANDARDS FOR CONFIGURATION, CAPACITY
AND SAFETY CAN RESULT IN PROPERTY
DAMAGE AND/OR PERSONAL INJURY.
The assembly of the air hose to the Long Reach Air
Tool will require a level working platform of sufficient
size and appropriate height.
1) Inspect the air hose to determine it is free of any
cuts, tears, abrasions or other damage. If any damage
is detected, replace the hose assembly with a factory
approved replacement only. The hose material is
designed to withstand the internal forces developed by
the specified operating pressure of the air tool.
DO NOT UTILIZE ANY HOSE MATERIAL WITH THE
LONG REACH AIR TOOL UNLESS IT IS OF THE
IDENTICAL DIMENSIONS AND PROPERLY
MARKED WITH A MINIMUM WORKING PRESSURE
OF 100 PSI. USE OF IMPROPER HOSE MATERIAL
CAN RESULT IN PROPERTY DAMAGE AND/OR
PERSONAL INJURY.
2) The air hose may utilize a coil spring assembly. The
coil spring is designed to provide additional support for
the hose where it is crimped to the attach fitting. The
spring slides over the perimeter of the attach fitting and
is held in place by an interference fit. If physical
damage prevents the spring from being properly
secured to the attach fitting, replace it with a factory
approved replacement only, FIGURE 1.
FIGURE 1
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 10

DO NOT OPERATE THE LONG REACH AIR TOOL
WITHOUT THE PROPER SUPPORT SPRING
SECURED TO THE ATTACH FITTING IF THE AIR
HOSE IS NOT OF THE WIRE REINFORCED TYPE.
USE OF THE TOOL WITHOUT THE SUPPORT
SPRING PROPERLY ATTACHED CAN RESULT IN
DAMAGE TO THE HOSE WHERE IT IS CRIMPED TO
THE ATTACH FITTING. SUCH AN OCCURRENCE
CAN RESULT IN PROPERTY DAMAGE AND/OR
PERSONAL INJURY.
3) The air hose can be of a wire reinforced
construction. This type of material incorporates an
internal wire reinforcement similar to that of a hydraulic
hose. A wire reinforced air hose does not utilize an
external support spring, FIGURE 2.
FIGURE 2
4) Using the long nose pliers, remove the protective
closure from the manifold. Determine the manifold is
clear of dirt or any foreign material accumulation,
FIGURE 3.
FIGURE 3
5) Insert the attach fitting into the manifold and secure
tight. There is no gasket or O type ring utilized for
sealing purposes. Inspect the attach fitting and
manifold area for proper fit and security. If you feel the
attach fitting and manifold do not have proper fit and
security, do not proceed further with the assembly
process. Contact the Customer Service Department for
assistance. There is no charge for this service.
6) Install the coupling device of choice to the open end
of the hose assembly. The coupling device must be of
the following type:
a) Male, quick type design of sufficient capacity to
couple with the appropriate female design. The female
coupler will immediately stop the airflow from the
compressed air source in the event that it becomes
disconnected for any reason while the air tool is in use,
FIGURE 4. Various safety type lanyards can also be
utilized for redundancy.
FIGURE 4
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 11

b) A standard air tool coupling device (sometimes
referred to as a Chicago type coupler) equipped with a
safety pin connection or a short connecting cable.
These safety mechanisms are designed to prevent
escaping, high pressure air from uncontrollably
whipping the hose in the event that it becomes
disconnected for any reason while the air tool is in use,
FIGURE 5.
FIGURE 5
Follow the manufacturer's instructions for proper
installation of the coupling device of choice. If you
require additional assistance with the installation
process, contact the Customer Service Department for
specific information. There is no charge for this service.
DO NOT UTILIZE ANY COUPLING DEVICE
WITHOUT AN APPROPRIATE SAFETY DEVICE
PROPERLY INSTALLED TO PREVENT ESCAPING,
HIGH PRESSURE AIR FROM UNCONTROLLABLY
WHIPPING THE HOSE IN THE EVENT IT BECOMES
DISCONNECTED OR SEVERED FOR ANY REASON
WHILE THE AIR TOOL IS IN USE. SUCH AN
OCCURRENCE CAN RESULT IN PROPERTY
DAMAGE AND/OR PERSONAL INJURY.
6) Inspect the individual components of the Long
Reach Air Tool. Inspect all fasteners for security.
Consult a fastener torque chart for the proper value if
any fastener is found to require retorquing.
Before Operating the Long
Reach Air Tool
INFORMATION RELATIVE TO MINIMUM SAFETY,
OPERATIONAL STANDARDS AND PARAMETERS
FOR THE USE OF THE LONG REACH AIR TOOL.
Applications: All models.
Before operating the Long Reach Air Tool, it is
essential that a comprehensive safety and operational
information program be established to increase
personal safety and help maximize overall productivity.
Such a program will include, but not be limited to the
following:
a) Determine the compressed air power source is in
proper mechanical condition, including power source,
reservoir, valves, connections, couplers, etc.
Determine the air reservoir has a current inspection by
an appropriate government and/or testing agency.
b) Inspect all hoses, valves, connections, couplers, etc
to determine that each is of appropriate structural
integrity and/or proper rating and/or capacity.
c) Use of a compressed air power source equipped
with a gasoline/diesel engine can create Carbon
Monoxide, an orderless, poisonous gas. Breathing
Carbon Monoxide fumes can cause personal injury. If
the Long Reach Air Tool is to be operated in a closed
area near the compressed air power source, determine
if supplemental ventilation is required to minimize the
potential effects of Carbon Monoxide to personnel.
Follow current OSHA regulations pertaining to
ventilation.
d) Use of the Long ReachAir Tool can create dusts and
other hazardous classified by-products which can
contaminate the atmosphere within the work space
area. Determine each operator and/or support
personnel is provided with appropriate respiratory
equipment. Follow current OSHA regulations
pertaining to ventilation
e) Each operator and/or support personnel must be
provided with appropriate safety equipment as deemed
necessary for the job application. Typical equipment
may include, but not be limited to, the following:
specialty glove types, safety eyewear, safety type
shoes, special clothing, safety headwear and hearing
protection.
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 12

f) Operate the air tool with operator positions which
enhance stability, productivity and overall productivity.
g) Do not operate the air tool without a suitable
accessory tool properly installed. Damage to the air
tool can result.
h) Do not install/remove accessory tools with the air
tool connected to the air source. Properly shutting off
the air source and/or releasing air pressure from the
hose BEFORE installing/removing accessory tools will
maximize safety and overall productivity.
i) For proper operation and extended service life, the
Long Reach Air Tool will require a compressed air
source which provides:
1) Clean air free of moisture, dirt, sand and other
foreign substances.
2) Optimum air flow rate for each tool delivered at the
specified pressure level.
3) The addition of lubrication oil at specific intervals to
provide for the necessary lubrication between moving
parts.
INSTALLING THE MODEL MDF-1000 AIR CADDY.
Application: All models.
Tools Required:
1 each, small, clean funnel.
1 each, small, adjustable wrench (if required).
Parts Required:
1 each, quantity of pneumatic tool lubrication oil
conforming to ISO 3498 HM.32. Refer to the
Specifications section for additional
information.
The MDF-1000 Air Caddy is an optional accessory
designed to be placed between the compressed air
source and the Long Reach Air Tool. The function of
the Air Caddy is to provide clean, lubricated air at the
specified pressure level and is composed of the
following components:
a) An inline air filter designed to remove contaminants
such as water, dirt, etc.
b) An adjustable regulator designed to allow the air
pressure to the Long Reach Air Tool to be constantly
regulated to a maximum 90 PSI (600 kPa), regardless
of the air pressure being developed by the compressed
air source.
c) An adjustable oiler unit designed to provide the
necessary lubrication to the moving components of the
Long Reach Air Tool. Lubrication oil is utilized to
minimize component wear and to allow the tool to
produce the stated blow frequency and blow force.
1) The filter is located at the inlet. Remove or loosen
the drain plug located on the bottom of the filter
reservoir to remove all contamination. Variances in
specific design configurations can exist. Replace or
tighten the drain plug after all the contamination has
properly drained from the reservoir. FIGURE 6.
FIGURE 6
2) Turn the screw located on the bottom of the
pressure regulator out in a counterclockwise direction
to release all air pressure from the internal diaphragm.
Variances in specific design configurations can exist.
Do not allow the screw to become loose from the
regulator. FIGURE 7.
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 13

FIGURE 7
3) Visually inspect the oil level in the oiler unit.
Variances in specific design configurations can exist. If
the reservoir requires the addition of oil, carefully clean
the filler plug located on top of the unit and
surrounding area to insure no dirt or debris falls into the
reservoir. Using the funnel, fill the reservoir to the
specified level with air tool lubrication oil conforming to
ISO 3498 HM.32. This oil can usually be obtained from
an industrial air tool distributor or automotive parts
store. Do not substitute hydraulic or motor oil. Inspect
the oil filler plug gasket for property security. If
necessary, replace the gasket with a factory approved
replacement part only. Reinstall the oil filler plug.
Tighten securely. Wipe off any excess oil spilled on the
oiler unit and/or Air Caddy. FIGURE 8.
FIGURE 8
4) The Air Caddy utilizes 1/2 inch NPT male nipples to
facilitate the addition of connecting devices to the air
hose assemblies. Most operating configurations will
allow for air hose (of specific lengths) to be attached to
the inlet and outlet nipples by use of direct, permanent
fittings or coupling type devices. All coupling devices
utilized with the Air Caddy must comply with all
applicable OSHA and/or industry standards for
configuration, capacity and safety. FIGURE 9.
FIGURE 9
UTILIZING COUPLING DEVICES NOT MEETING
APPLICABLE OSHA AND/OR INDUSTRY
STANDARDS FOR CONFIGURATION, CAPACITY
AND SAFETY CAN RESULT IN PROPERTY
DAMAGE AND/OR PERSONAL INJURY.
OPERATING THE AIR CADDY WITH THE
COMPRESSED AIR INLET AND OUTLET
LOCATIONS MISMATCHED CAN RESTRICT THE
AIR FLOW RATE AND PRESSURE VALUES. THIS
OCCURRENCE CAN RESULT IN PROPERTY
DAMAGE AND/OR PERSONAL INJURY.
Operation
OPERATIONAL DISCLAIMER.
Applications: All models.
THE MANUFACTURER OF THIS LONG REACH AIR
TOOL MAKES NO WARRANTY OR GUARANTEE
THAT IT IS MERCHANTABLE FOR ANY SPECIFIC
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 14

JOB APPLICATION AND THAT IT WILL HAVE
SUFFICIENT POWER AND PRODUCTIVITY TO
PERFORM ANY SPECIFIC JOB APPLICATION.
IT IS THE RESPONSIBILITY OF THE OPERATOR(S)
AND/OR OWNER(S) OF THE LONG REACH AIR
TOOL TO DETERMINE OPERATION FOR ANY
SPECIFIC JOB APPLICATION IS IN COMPLIANCE
WITH ALL APPLICABLE OSHA AND/OR EPA
REGULATIONS REGARDING ITS USE.
CALIFORNIA PROPOSITION 65 DISCLAIMER
.
Applications: All models.
DUSTS AND BYPRODUCTS FROM THE
OPERATIONAL PROCESS OF THIS PRODUCT
CONTAIN CHEMICALS KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE CANCER, BIRTH
DEFECTS, OR OTHER REPRODUCTIVE HARM.
SAFETY RELATED EQUIPMENT AND APPAREL
DISCLAIMER.
OPERATION OF THE LONG REACH AIR TOOL
REQUIRES THE USE OF SPECIFIC SAFETY
RELATED EQUIPMENT AND APPAREL
INCLUDING, BUT NOT LIMITED TO: SAFETY
EYEWEAR, HARD HAT, HEARING PROTECTION,
PROTECTIVE BREATHING MASK, ANTI-
VIBRATION GLOVES, SAFETY CLOTHING AND
SAFETY FOOTWEAR. IT IS THE RESPONSIBILITY
OF THE OWNER(S) AND/OR OPERATOR(S) TO
DETERMINE THE REQUIRED AND/OR
APPROPRIATE SAFETY RELATED EQUIPMENT
AND APPAREL FOR ANY SPECIFIC JOB
APPLICATION. FAILURE TO WEAR THE
REQUIRED AND/OR APPROPRIATE SAFETY
RELATED EQUIPMENT AND APPAREL FOR ANY
SPECIFIC JOB APPLICATION CAN RESULT IN
PROPERTY DAMAGE AND/OR PERSONAL INJURY.
INFORMATION RELATIVE TO MINIMUM
COMPONENT STANDARDS FOR THE OPERATION
OF THE LONG REACH AIR TOOL.
For operational safety and overall productivity
considerations, it is required that specific Long Reach
Air Tool components meet minimum acceptable
operational standards BEFORE utilization:
1) The air hose assemblies and coupling devices are of
proper type and structural condition that allow them to
perform their intended job function as outlined within
this manual.
2) Throttle valve control is in a proper mechanical
condition that allows it to perform its intended job
function as outlined in this manual. A throttle valve with
a damaged or bent lever, a sticking or damaged valve
mechanism must be replaced with a factory approved
replacement only.
3) The protective cover for the throttle valve control is
in proper structural condition to afford protection for the
valve in the event it comes in direct contact with a
foreign object, thereby preventing inadvertent
actuation.
4) The tool receiver is in a structural condition that
allows it to perform its intended job function of properly
containing the accessory tool shank as outlined within
this manual.
5) The tool retainer assembly (cover and retaining
bushing) is in a structural condition that allows it to
perform its intended job function of properly retaining
the accessory tool as outlined within this manual.
OPERATION OF A LONG REACH AIR TOOL
UTILIZING COMPONENTS NOT MEETING
MINIMUM COMPONENT STANDARDS CAN
RESULT IN PROPERTY DAMAGE AND/OR
PERSONAL INJURY.
SET UP FOR OPERATION.
Applications: All models.
In order to minimize the possibility of damage to the
Long Reach Air Tool, always transport it to the job site
disconnected from the air hoses and/or Air Caddy. All
equipment must be secured in/on vehicles with
suitable strapping or tie downs. Personnel should not
be transported in the same compartment as equipment
and fuel supplies. Consult applicable OSHA
regulations.
1) The Long Reach Air Tool is designed to be utilized
by one operator.
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 15

NEVER UTILIZE THE LONG REACH AIR TOOL
WITH AN IMPROPER NUMBER OF OPERATORS.
USE OF MORE THAN ONE PERSON TO OPERATE
THE LONG REACH AIR TOOL CAN LEAD TO
CONFUSION AND LOSS OF CONTROL,
RESULTING IN PROPERTY DAMAGE AND/OR
PERSONAL INJURY.
UNLESS CLEARLY MARKED WITH PROPER
IDENTIFICATION, THE LONG REACH AIR TOOL
AND ACCESSORY TOOLS ARE NOT DESIGNED TO
BE OPERATED IN A HAZARDOUS CLASSIFIED
LOCATION (AS DEFINED BY THE NATIONAL
ELECTRIC CODE®). OPERATION OF THE LONG
REACH AIR TOOL AND ACCESSORY TOOL NOT
DESIGNED FOR USE IN A HAZARDOUS
CLASSIFIED LOCATION CAN RESULT IN A
RANDOM SPARK BEING THE IGNITION SOURCE
OF AN EXPLOSION. SUCH AN OCCURRENCE CAN
RESULT IN PROPERTY DAMAGE AND/OR
PERSONAL INJURY.
OPERATION OF THE LONG REACH AIR TOOL AND
ACCESSORY TOOL THAT RESULTS IN DIRECT
AND/OR INDIRECT CONTACT WITH A
SUBSURFACE HAZARD CAN RESULT IN
PROPERTY DAMAGE AND/OR PERSONAL INJURY.
DETERMINATION OF POTENTIAL SUBSURFACE
HAZARDS IN THE PROPOSED WORK
LOCATION(S).
BEFORE ATTEMPTING TO UTILIZE THE LONG
REACH AIR TOOL, DETERMINE THE POTENTIAL
OF SURFACE AND SUBSURFACE HAZARDS
WHICH MAY EXIST AND HOW THE IDENTIFIED
HAZARDS MAY AFFECT OPERATION IN THE
PROPOSED WORK LOCATION(S). POTENTIAL
SURFACE AND SUBSURFACE HAZARDS MAY
INCLUDE, BUT NOT BE LIMITED TO, THE
FOLLOWING:
1) BURIED PRESSURIZED PIPELINES
CONTAINING SUCH MATERIALS AS NATURAL
GAS, PROPANE, ETC.
2) BURIED POWER CABLES.
BEFORE OPERATING THE LONG REACH AIR
TOOLAND ACCESSORY TOOL IN THE PROPOSED
LOCATION(S), CONTACT ALL APPROPRIATE
AGENCIES TO DETERMINE THE EXACT
LOCATION(S) OF ALL BURIED PIPELINES, POWER
CABLES AND OTHER HAZARDS AND HOW THE
HAZARDS MAY AFFECT OPERATION.
3) SURFACE AND/OR SUBSURFACE MATERIALS
SUCH AS ASBESTOS OR OTHER, SIMILAR TYPE
MATERIALS CLASSIFIED AS HAZARDOUS.
INSTALLING AN ACCESSORY TOOL.
Applications: All models.
DO NOT INSTALL AN ACCESSORY TOOL WHILE
THE LONG REACH AIR TOOL IS DIRECTLY
CONNECTED TO AN AIR SOURCE UNDER
PRESSURE. SUCH A CONFIGURATION CAN
ALLOW THE THROTTLE VALVE CONTROL TO
EXPERIENCE ACCIDENTAL ACTUATION FROM AN
EXTERNAL FORCE, RESULTING IN PROPERTY
DAMAGE AND/OR PERSONAL INJURY.
1) Select the accessory tool of proper size and
configuration for the intended job application. The male
hexagon shank of the accessory tool must be of the
identical nominal size of that of the tool receiver. If
there are any questions regarding the selection of an
accessory tool for a specific job application, consult the
Customer Service Department for assistance BEFORE
operation. There is no charge for this service.
2) Inspect the accessory tool for proper structural
integrity. Do not utilize a worn or damaged accessory
tool. Properly discard a worn or damaged accessory
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 16

tool. The end of the male hexagon shank should be
flat and perpendicular to the axis of the tool. FIGURE
10. Properly discard any tool of a bent, crowned or
"mushroomed" configuration.
FIGURE 10
USE OF AN ACCESSORY TOOL OF IMPROPER
SIZE AND/OR CONFIGURATION FOR THE
INTENDED JOB APPLICATION, OR AN
ACCESSORY TOOL WHICH IS WORN AND/OR
DAMAGED CAN RESULT IN PROPERTY DAMAGE
AND/OR PERSONAL INJURY.
3) Remove the tool retainer from the barrel. The tool
retainer incorporates a right hand thread configuration.
Remove the retaining bushing. FIGURE 11.
FIGURE 11
4) Insert the male hexagon shank of the accessory tool
through the opening of the tool retainer. Install the
retaining bushing over the round shank of the
accessory tool with the shoulder of the retaining
bushing against the upset collar. The retaining bushing
incorporates a split to facilitate installation. FIGURE
12.
DO NOT OPERATE THE LONG REACH AIR TOOL WITHOUT THE
PROPER RETAINING BUSHING INSTALLED WITHIN THE TOOL
RETAINER. USE OF THE LONG REACH AIR TOOL WITHOUT
THE PROPER RETAINING BUSHING INSTALLED CAN RESULT IN
PROPERTY DAMAGE AND/OR PERSONAL INJURY.
FIGURE 12
5) Install the male hexagon shank of the accessory tool
into the tool receiver. If the accessory tool is of a chisel
configuration, determine the desired orientation of the
chisel blade in relationship to the throttle valve control
to facilitate maximum comfort and control during
operation. FIGURE 13.
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 17

FIGURE 13
6) Install the tool retainer to the tool receiver assembly.
The tool retainer incorporates a right hand thread
configuration. Tighten by hand only until the retainer
bottoms against the plastic gasket. Do not operate the
Long Reach Air Tool without a tool receiver gasket of
proper structural integrity and without the tool retainer
properly attached to the tool receiver assembly.
HAND TIGHTEN THE TOOL RETAINER AGAINST
THE TOOL RECEIVER GASKET BY HAND ONLY.
USE OF A WRENCH CAN RESULT IN DAMAGE TO
THE THREADED COMPONENTS.
DO NOT OPERATE THE LONG REACH AIR TOOL
WITHOUT THE TOOL RETAINER PROPERLY
ATTACHED TO THE TOOL RECEIVER ASSEMBLY.
WITHOUT THE TOOL RETAINER PROPERLY
ATTACHED TO THE TOOL RECEIVER ASSEMBLY,
SIGNIFICANTLY REDUCED OPERATOR CONTROL
OF THE ACCESSORY TOOL WILL RESULT. SUCH
OCCURRENCE CAN RESULT IN PROPERTY
DAMAGE AND/OR PERSONAL INJURY.
7) Accessory tool removal is accomplished by
reversing the installation process. The PN MDF15-
7010 Service Tool can be utilized to help separate the
retaining bushing from the tool retainer. A 1/8 inch long
handle Allen wrench can also be utilized. FIGURE 14.
FIGURE 14
ATTACHING THE LONG REACH AIR TOOL TO THE
AIR CADDY AND AIR HOSE ASSEMBLIES.
1) Position the Long Reach Air Tool and installed
accessory tool on a suitable horizontal surface that
allows the throttle control valve to be protected from
unexpected actuation by an external force.
UNEXPECTED THROTTLE VALVE ACTUATION
FROM AN EXTERNAL FORCE CAN RESULT IN
PROPERTY DAMAGE AND/OR PERSONAL INJURY.
2) Disconnect the air hose from the compressed air
source.
3) Turn the screw located on the bottom of the
pressure regulator out in a counterclockwise direction
to release pressure from the internal diaphrarm.
Variances in specific design configurations can exist.
Do not allow the screw to separate from the regulator.
FIGURE 15.
MDF SERIES LONG REACH AIR TOOLS FORM GOM6019801, VERSION 1.0, AUTHORIZATION: DVR, PAGE: 18
