Genie GCL-T User manual

TROLLEY
NOT FOR RESIDENTIAL USE
This Installation Manual provides the information required to install, troubleshoot and
maintain a GCL-T™Commercial / Industrial Door Operator.
PROPER APPLICATION
Operator Type Door Type Max Door Weight/HP
Trolley Sectional 1/2HP = 1120 lbs.
(Standard, Sidemount (Standard or Low 3/4HP = 1370 lbs.
or Dual)
Headroom Track only) 1HP = 1620 lbs.
Standard Duty Operator
GCL-T™
111848.501539 06-12
EZ Limit
Multivolt
TensiBelt™
™
™

www.geniecompany.com 06-12
THIS PAGE LEFT BLANK
Standard Duty Operator
GCL-T

TOC
www.geniecompany.com 06-12
Table of Contents
Section 1 How to use this manual ................................................. 1.1
Section 2 Safety Information & Instructions ................................2.1
Section 3 Critical Installation Information ............................ 3.1-3.2
Section 4 Installation................................................................4.1-4.9
Drawbar Assembly...............................................................4.1-4.6
Attach Operator ...........................................................................4.7
Connection to the Door............................................................4.8
Clutch Adjustment .......................................................................4.9
Section 5 Wiring........................................................................5.1-5.9
Line Voltage Wiring ....................................................................5.1
Low Voltage Control Wiring....................................................5.2
External Wire Diagram...............................................................5.3
Wall Control...................................................................................5.4
Interlock Switches ....................................................................... 5.5
Photocell Wiring ..........................................................................5.6
Sensing Edge Wiring..................................................................5.7
External Radio Installation .......................................................5.8
Connecting Motor/Safety Information ...............................5.9
Section 6 Operator Setup Procedures .....................................6.1-6.9
Setting Close Direction ...............................................................6.2
Setting Braking Rate ................................................................... 6.3
Setting Travel Limits ...................................................................6.4
......................................................................
Setting Limit Overrun..................................................................6.5
Monitored Reversing Devices ..................................................6.6
Setting Open & Close Modes ...................................................6.7
(Optional) Transmitter Programming....................................6.8
Setting Mid-Stop Limit................................................................6.9
Resetting the MRT 6.10
Section 7 Special Operational Features..................................7.1-7.2
Operator Cycle Count................................................................7.1
GDO & Display Firmware..........................................................7.1
Operator Type...............................................................................7.2
Section 8 Troubleshooting ......................................................8.1-8.5
Display Operation .......................................................................8.1
Error Codes .............................................................................8.1-8.2
Run Codes ...............................................................................8.2-8.3
Troubleshooting Example using Codes..............................8.3
LED Indicators...............................................................................8.4
Safe-T-Beam® Troubleshooting Chart ................................. 8.5
Section 9 Service & Maintenance................................................... 9.1
Preventive Maintenance Schedule.........................................9.1
Section 10 Appendixes ........................................................ 10.1-10.11
Appendix A ........................................................................10.1-10.9
Basic Operator Parts ...............................................................10.1
Basic Shafts Parts ......................................................................10.3
Basic Rail Parts ......................................................................10.4
Basic Carriage/Door Arms Parts.......................................10.5
Basic Electric Box Parts ......................................................10.6
Electric Box Layout ..............................................................10.7
Appendix B ..................................................................................10.8
Screw Terminal Assignments ..........................................10.8
Appendix C ...................................................................... 10.9-10.11
Run Codes...............................................................................10.9
Error Codes...............................................................10.10-10.11
Section 11 Warranty .......................................................................11.1
Standard Duty Operator
GCL-T

Section 1: How to use this manual
The 11 sections of this Installation Manual provide the information required to install, troubleshoot and maintain an GCL-T™ commercial/industrial
door operator.
Section 2
Provides important defining information related to safety terminology used throughout this manual, as well as safety related instructions which
must be followed at all times while doing any steps/tasks/instructions detailed in this manual.
Section 3
Details pre-installation concerns/issues/decisions that are recommended to be considered and/or resolved prior to beginning any commercial door
operator installation.
Sections 4-6
Provide step by step installation and set-up instructions for the GCL-T™ commercial door operator. Each section is written such that it must be
followed in a step by step order to complete a successful installation.
Sections 7-8
Detail important features and troubleshooting information for typical installation and normal operations that may occur.
Sections 9-11
Provide related information on service and maintenance items, operator drawings for use in troubleshooting and service activities, along with
important warranty and returned goods policy information.
Failure to correctly perform all steps in sections 4-6 can result in serious injury or death.
WARNING
1.1
www.geniecompany.com 06-12
Standard Duty Operator
GCL-T

2.1
www.geniecompany.com 06-12
Standard Duty Operator
GCL-T
Section 2: Safety Information & Instructions
WARNING
Commercial/Industrial Sectional and Rolling Steel Doors are large, heavy objects that move with the help of springs
under high tension and electric motors. Since moving objects, springs under tension, and electric motors can cause
injuries, your safety and the safety of others depend on you reading the information in this manual. If you have any
questions or do not under stand the information presented, call your nearest service representative. For the number
of your local Genie® Dealer, call 800-OK-GENIE, and for Genie® Factory Technical Advice, call 800-843-4084.
In this Manual, the words Danger, Warning, and Caution are used to stress important safety information. The word:
DANGER
indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in injury or property damage.
The word NOTE is used to indicate important steps to be followed or important considerations.
IMPORTANT
READ PRIOR TO ANY DOOR OPERATION
POTENTIAL HAZARD EFFECT PREVENTION
Do Not operate unless the doorway is in sight and free of
obstructions. Keep people clear of opening while door is moving.
Do Not allow children to play with the door operator.
Do Not change operator control to momentary contact unless an
external reversing means is installed.
Do Not operate a door that jams or one that has a broken spring.
Could result in
Serious Injury
or Death
Turn off electrical power before removing operator cover.
When replacing the cover, make sure wires are not pinched or near
moving parts.
Operator must be electrically grounded.
Do Not try to remove, repair or adjust springs or anything to which
door spring parts are fastened, such as, wood block, steel bracket,
cable or any other structure or like item.
Repairs and adjustments must be made by a trained service
representative using proper tools and instructions.
HIGH SPRING TENSION
WARNING
MOVING DOOR
1. Read manual and warnings carefully.
2. Keep the door in good working condition.
Periodically lubricate all moving parts of door.
3. If door has a sensing edge, check
operations monthly. Make any necessary
repairs to keep it functional.
4. AT LEAST twice a year, manually operate
door. The Door should open and close freely.
If it does not, the door must be taken out of
service and a trained service representative
must correct the condition causing
the malfunction.
5. The Operator Motor is protected against
overheating by an internal thermal protector.
If the operator ceases to function because
motor protector has tripped, a trained service
technician may need to correct the condition
which caused the overheating. When motor
has cooled, thermal protector will
automatically reset and normal operation can
be resumed.
6. In case of power failure, the door can be
operated manually by pulling the release
cable to disconnect the operator drive system.
7. Keep instructions in a prominent location
near the pushbutton.
Could result in
Serious Injury
or Death
WARNING
Could result in
Serious Injury
or Death
WARNING
ELECTRICAL SHOCK

3.1
www.geniecompany.com 06-12
Standard Duty Operator
GCL-T
Job Site Issues to Consider/Concerns
The following list of items should be considered prior to selecting an operator for a given job site.
1-Available power supply.
2-Type of door.
3-Potential operator mounting obstructions. Items to consider include, but are not limited to: side room, room above door shaft, room below door shaft, available mounting
surface integrity, power supply location, and convenient chain hoist and release cable positioning.
4-Size of door for appropriate operator torque and door travel speed selection.
ssenitsud,ssenpmaddnanoitacolrotarepoedulcniredisnocotsmetI.tnemnorivnegnitnuomrotarepO-5 and corrosiveness of the location.
6-Door activation needs/requirements. Examples include 3 button control stations, 1 button control stations, radio controls, pull cords, loop detectors, photoelectric controls,
key switches, etc. See “Entrapment Protection” section below.
7-Interlock switches are required under certain conditions for .5.5egapeeS.skcolrooddnasroodssaphtiwsrood
rofderiuqer(smaebllecotohpro/dnasegdegnisrevereraselpmaxE.tnempiuqeyrosseccA-8 .cte,sthgilgninraw,syalerlortnocyrailixua,),tcatnocyratnemomsaetarepoottessrood
WARNING: DO NOT apply line voltage until instructed to do so.
CAUTION:
Check working condition of door before installing the operator. Door must be free from sticking and binding. If equipped, deactivate
any door locking device(s). Door repairs and adjustments, including cables and spring assemblies MUST be made by a trained service
representative using proper tools and instructions.
Section 3:
Critical Installation Information
ENTRAPMENT PROTECTION
The installation of a fail safe external reversing device (such as a monitored reversing edge or photocell system) is required on all momentary contact electronically
operated commercial doors. If such a reversing device is not installed, the operator will revert to a constant contact control switch for operation (Closing only).
The Reversing Devices currently UL Approved with are:
MillerEdge ME, MT and CPT series monitored edge sensors used in combination with Timer-Close Module P/N OPABTCX.S or OPAKMEIGX.S INTERFACE MODULE.
2) Residential Safe-T-Beam® Monitored Photocells from The Genie® Company, model OSTB-BX (P/N 38176R).
3) Series II Commercial Safe-T-Beam®, Monitored Photocells P/N OPAKPE.S.
4) Series II Commercial Safe-T-Beam®, Monitored Photocells for NEMA4, P/N OPAKPEN4GX.S.
1)

3.2
www.geniecompany.com 06-12
ENTRAPMENT PROTECTION
.0102,92tsuguAgnitratsevitcastnemeriuqer523LUhtiwecnailpmocnisecivedtnempartnedetsiLLUgniwollofehthtiwdesuebnac™T-LCGehT
UNTIL ONE OF THESE MONITORED EXTERNAL ENTRAPMENT DEVICES IS INSTALLED, TH .NOITCERIDESOLCEHTNINOITAREPOTCATNOCYRATNEMOMWOLLATONLLIW
Section 3: Critical Installation Information
Standard Duty Operator
GCL-T
Type
Mounting
Max.
Door
Weight
(Lbs)
16GA.
Flush
Steel
16GA.
Flush
Steel
Insulated
20GA.
Ribbed
Steel
20GA.
Ribbed
Steel
Insulated
24GA.
Ribbed
Steel
24GA.
Ribbed
Steel
Insulated
Nominal
24GA.
Ribbed
Steel
Nominal
24GA.
Ribbed Steel
Insulated
Insulated
PU/FIP
Insulated
PU/FIP
1.38"
1/8" Glass
1.38" Glass
1.38"
Insulated
PU/FIP
2"
Insulated
PU/FIP
2"
20GA.
Y es TSC 1120 256 220 370 256 440 340 320 320 256 360 400 300 400 380 360 240
TSC 1370 330 256 440 310 530 400 320 320 256 450 450 370 460 440 400 330
TSC 1620 380 280 500 370 570 410 320 320 256 480 480 420 500 480 400 400
Y es
Yes
UL L is tedHPModel
T=Trolley
Aluminum
Door S eries ->
Note: Total door weight, and not the square footage, is the critical factor in selecting the proper operator.
Square footage measurements are based on "square doors." (Example=16' x 16')
NOTE: Doors that require special windloading and wide doors, normally require increased strutting (reinforcement). Strutting doors can significantly increase door
weight beyond weight shown. Consult Customer Service for the impact of wind load andstrutting on square foot limits.
NOTE: "PU-FIP" stands for "polyurethane, foamed-in-place." If no notation is present, insulation is "polystyrene, layed-iin-place."
Sectional Door Chart (sq. ft.)
GCL-J&H 1/2
GCL-J&H 3/4
GCL-J&H 1
216 216 ins. 220 220 ins. 2415 2415 ins. 2411 2411 ins. 125 150 200 200-20 5150 5200 451 452
CommercialSteelInsulated&Non-Insulated Thermospan Thermomark
Exterior
Insulated
PU/FIP
Raised
Panel
1.38"
Insulated 1/4" or 1/2"
PU/FIP
Raised
Panel
2"
E OPERATOR
APPROVED DEVICES
ANY WIDTH
30 FEET
30 FEET
30 FEET
Miller Edge ME, MT & CPT series monitored edge sensors used in combination with either the Genie®
Timer-Close Module or Direct connect through STB inputs.
Commercial Monitored PhotoeyeKit—P/N OPAKPE.S.
Safe-T-Beam® from Genie®—P/N 38176R.
Commercial NEMA4 Monitored Photocells—P/N OPAKPEN4GX.S.
ALLOWABLE DOOR WIDTH

4.1
www.geniecompany.com 06-12
The Drawbar Operator consists of the Power Unit (A), Drawbar Rail
(B), Chain Guides (C), Front Spreader (D), Front Idler Pulley (E), Drive Chain (F), Drive
Sprocket (G) and Drawbar Arm (H). The Drawbar rail length, chain length and
quantity of chain guides will vary by door heights. Fig. 1.
Section 4: Installation
Drawbar Assembly
Figure 1
A
B
G
F
C
E
D
NOTE: Drawbar rail must be (29) inches longer than the door’s height. Rails
have been sized properly and pre-punched for the chain guide assemblies from
the factory.
IMPORTANT
INSTALLATION INSTRUCTIONS
WARNING-
To reduce the risk of severe injury or death:
1) READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS.
2) Install only on a properly operating and balanced door. A door that is operating
improperly could cause severe injury. Have qualified service personnel make
repairs to cables, spring assemblies and other hardware before installing the operator.
3) Remove all pull ropes and remove, or make inoperative, all locks (unless mechanically
and/or electronically interlocked to the power unit) that are connected to the door
before installing the operator.
4) Install the door operator at least 8 feet above the floor if the operator has exposed
moving parts.
5) Do not connect the door operator to the power source until instructed to do so.
6) Locate the control station: (a) within sight of the door, (b) a minimum of 5 feet above
the floor so that small children cannot reach it, and (c) away from all moving parts
of the door.
7) Install the Entrapment Warning Placard next to the control station and in a
prominent location.
8) For products having a manual release, instruct the end user on the operation of the
manual release.
Standard Duty Operator
GCL-T

4.2
www.geniecompany.com 06-12
Drawbar Assembly (continued)
1) Attach Rails to Power Unit using four (4) 7/16”-14 x 1” bolts,
7/16”-14 keps nuts and 7/16” lock washers (provided). Fig. 2.
2) Attach the chain guide assemblies to the drawbar rails using
Track Bolts and locknuts (provided). Fig. 3.
Figure 3
CHAIN GUIDE BRACKET
TRACK BOLTS/
LOCKNUTS
PLASTIC CHAIN GUIDE
NOTE: Space chain guides evenly between operator and header. Add a chain
guide for every 4 feet of door height per chart.
NOTE: Chain Guide mounting holes have been pre-drilled at standard loca-
tions along the track. If different locations are needed, hole size should be
1/4" dia. Be sure to de-burr the holes.
UNDER 12’12’to 16’16’to 20’20’to 24’
2 3 4 5
CAUTION
Verify that screws are properly seated in track. Failure to seat screws can
cause carriage to bind in door track.
Figure 2
7/16"
BOLTS
Standard Duty Operator
GCL-T

4.3
www.geniecompany.com 06-12
Drawbar Assembly (continued)
3) Insert the carriage into the rails as shown in Fig. 4.
NOTE: The end of the carriage with the chain tension adjustment bolt should be
toward the operator.
4) Place the spreader bracket in position around the drawbar rail. Do not
redaerpsehT.emitsihttastunkcoldnastlobkcartehttresni bracket
will be held in place (temporarily) by the clevis pin which holds
the pulley.
5) Install the idler pulley inside the rails by inserting the 3/8” x 4-1/2” clevis
pin through one of the rails and as you feed it through an idler
sleeve and the idler pulley followed by the second sleeve . Place fender
washer (7/16” x 1-1/4”) over end of clevis pin. Secure clevis pin using
RAIL
Figure 4 Figure 5
FRONT
SPREADER
BRACKET
WASHER
COTTER PIN
CLEVIS PIN
IDLER PULLEY
/STLOBKCART
LOCKNUTS
DO NOT INSTALL YET!
SLEEVE
NOTE: For building of the spreader bracket assembly on a Dual Trolley unit see
the separate Drawbar instruction sheet for Sidemount and Dual Trolley models.
OPERATOR DOOR
Standard Duty Operator
GCL-T
cotter pin. Fig. 5.
CARRIAGE

4.4
www.geniecompany.com 06-12
6) Uncoil the drawbar chain and install by routing the chain over the chain
guides (A) and around the drive sprocket (B) on the output shaft as shown
in Fig. 6.
7) Attach to Chain Tension Adjusting Bolt (C) using a master link (provided).
8) Pass the other end of the chain between the front spreader bracket and
the idler pulley (D). Make certain the chain is not twisted.
9) Attach the chain to the carriage (E) using a master link.
10) Insert the Adjusting Bolt through the hole in the Carriage and place the
tensioning spring, flat washer and adjusting nut onto the bolt. Detail A,
Fig 6.
11) Tighten Chain so that it will not jump a sprockets or pulley. Add locknut.
Check to ensure the following:
•The chain is properly engaging the output sprocket.
•The chain is not twisted.
WARNING
•DO NOT apply line voltage until instructed to do so.
•Repairs and adjustments, including particularly to cables and spring
assemblies under high tension, must be made by a trained service
representative using proper tools and instructions.
Drawbar Assembly (continued)
Detail A
CHAIN
TENSION
ADJUSTMENT
SCREW
FLAT WASHER
LOCKNUT
ADJUSTING NUT
TENSIONING
SPRING
MASTER
LINK
MASTER
LINK
Figure 6
AA
C
D
E
B
Standard Duty Operator
GCL-T

4.5
www.geniecompany.com 06-12
VERT CAL L NE
(SEE STEP 1)
HEADER
ATTACHMENT MATER AL
(SEE STEP 2)
HOR ZONTAL L NE
(SEE STEP 6)
CENTERLINE
OF DOOR
CAUTION
Check the working condition of the door before installing the operator. The
Door must be free from sticking and binding. If the door is equipped with a
latching device, secure the locking bar in the open (unlocked) position. This
style operator will act as a latching device when the door is down and
therefor the door’s lock is no longer needed.
If the door lock is to remain functional, an interlock switch MUST be installed
which will prevent operation of the door whenever the door lock is engaged.
Refer to the Wiring Instructions, section 5.5, of this manual for proper
connection of the interlock switch.
1) Measure the width of the door to determine the center. Make a vertical
line above the door, as shown in Fig. 7. (If the vertical line is not in line
with a door stile, a means of attaching the door bracket to the door must
be provided. This can be accomplished by spanning the center of the
door’s top section (between the top and bottom rail) with a suitable
material such as wood or steel).
2) Prepare for attaching drawbar to header. If woodwork, or other suitable
material is not already in place, securely affix a 2” x 6” block of wood or
metal plate as shown in Fig. 7.
3) Center the block/plate on the header.
4) Mark the door’s vertical center line on this block/plate.
5) Use a level, as shown in Fig. 8 (pg 4.6) to find the highest point of travel for
the door.
6) Mark a horizontal line across the vertical line you made on the header
at 5” above the highest point of door travel.
Drawbar Installation
Figure 7
NOTE: On torsion spring doors with an uneven number of panels, the operator
may be attached to the stile nearest to the center.
Standard Duty Operator
GCL-T

4.6
www.geniecompany.com 06-12
Drawbar Installation (continued)
2" X 6"
HEADER
MARK A HORIZONTAL LINE
5" ABOVE HIGHEST POINT OF TRAVEL
LEVEL
HIGHEST POINT
OF TRAVEL
Figure 8
Figure 9
7) Raise the door end (idler pulley) of the drawbar while resting the operator
on the floor or other desired material.
8) Position the spreader bracket on your centerline with its bottom edge on
your horizontal mark. Fig. 9.
•Fasten spreader bracket to header using fasteners appropriate for the
header material.
Standard Duty Operator
GCL-T

4.7
www.geniecompany.com 06-12
1) Raise the operator and position it so that the drawbar rails are
level and perpendicular to the face of the door (or the stile where
the door bracket will be attached). Fig. 10.
2) Lock the drawbar rails into the spreader bracket using the
two (2)
track bolts (1/4”-20 X 9/16”) and two(2) locknuts.
3) Secure the operator in position by installing steel angles (not
provided) between the ceiling superstructure and the operator
power unit. Fig. 11.
Attach Operator
TRACK BOLTS
& LOCK NUTS
ROPE, CABLE,
CHAIN, ETC.
LEVEL
WALL WALL
RAILS 90°
DOOR FROM ABOVE
Figure 10
DRILL HOLE IN ANGLE
AND MOUNT USING
REAR SUPPORT
CARRIAGE BOLT
STEEL
ANGLES
(NOT INCLUDED)
Figure 11
NOTE: Track bolts MUST be installed from inside the rails.
Standard Duty Operator
GCL-T

4.8
1) Pull down on the drawbar arm locking sleeve and attach to carriage. (See NOTE 2.)
2) Position the door bracket on the door as shown in Fig. 11, with mounting
. )holes on the door centerline. (Even with or above top door roller
3) For wood doors fasten the door bracket to the door using two 1/4” -20 X 2-1/4”
carriage bolts and nuts. For metal doors use two 1/4”- 20 self tapping sheet
metal screws, or as recommended by the door manufacturer.
4) Use two (2) 3/8” -16 X 7/8” bolts and nuts to attach the door arms together.
NOTE: Use the set of holes that align the drawbar in a near vertical position for operators
without a brake. Set arms at a 20-30 degree rearward angle for operators with a brake.
Fig. 12.
For units without a brake, set arms as close to 0 degrees (vertical) as possible.
NOTE: If the door strut interferes with the mounting of the door bracket, position
NOTE 2: In case of emergency, pulling the Emergency
Release Knob (Fig. 12) disengages the door from operator
allowing for the door to be shut manually.
the door bracket below the strut. DO NOT, in any way, cut or modify the strut.
Connection to the Door
Figure 12
Figure 11
20°-30°
with Brake
When installing non-brake units
with drawbar near vertical, it is
important to make sure there
is adequate room between the
door bracket and drawbar rail
for the door arms to go vertical.
Without sufficient clearance
and by running the dood arms
vertical, a significant amount of
force could be applied possibly
leading to damage.
There is an optional drawbar
kit with a cusion springbox
available: P/N OPAKDBT.S
WITH BRAKE WITHOUT BRAKE
AVOID THIS SETUP
WITHOUT BRAKE
CORRECT
www.geniecompany.com 06-12
Standard Duty Operator
GCL-T

4.9
www.geniecompany.com 06-12
The Operators have a friction style clutch that can be adjusted.
NOTE: The clutch is intended to provide protection for the door, the operator and
yellorT.noitcetorptnempartnerofdednetnitonsitItnempiuqedetaicossa
operators have a motor reversing feature that is integrated with the clutch
assembly. If an obstruction is placed in the pathway of the door during operation
the motor will stop and reverse when the clutch begins to slip.
The adjustment of the clutch should be such that the door and operator function in
this manner. The steps for clutch adjustment follow:
To Adjust the Clutch
1) Decrease the compression on the clutch until the operator will not lift
the door.
•Turn the adjusting castle nut counter-clockwise to decrease clutch
compression and clockwise to increase clutch compression.
2) After completing step 1, begin to increase compression on the
clutch until the operator is capable of lifting the door through the
complete cycle without clutch slippage.
3) Test the reversing feature of the operator by placing an obstruction
under the door during a close cycle. The door should reverse on the
obstruction and return to the open position. If the door does not
close but comes down part way and reverses without any
obstructions in its path, then increase the clutch compression until
the door will close fully.
4) Finally, insert the cotter pin through the castle nut and shaft and bend
the outer leg of the cotter pin.
NOTE:
Periodically check the system for proper clutch action. If clutch starts to slip after
working properly for some time, check manual operation of door BEFORE adjusting
clutch. The door may not be operating freely or the counterbalance spring may
need adjusting. Repairs and adjustments must be performed by a trained service
representative using proper tools and instructions.
Clutch Adjustment Fig. 13
CLUTCH PULLEY
WASHER
COTTER PIN
ADJUSTING NUT
CLUTCH
PAD
CLUTCH
PLATE
SPRING
Figure 13
Standard Duty Operator
GCL-T

5.1
www.geniecompany.com 06-12
WARNING
•DO NOT apply power to operator until instructed to do so.
•The Genie® Company recommends that line voltage wiring
be performed by a qualified electrician.
•Be sure that electrical power has been disconnected from the
input power wires being connected to the operator prior to
handling these wires. An appropriate lock-out /tag-out procedure
is recommended.
•Line voltage wiring must meet all local building codes.
•Make sure operator voltage, phase and frequency nameplate
ratings are identical to the job site line voltage ratings.
•Input power wiring must be properly sized for the operators
amperage rating located on the nameplate.
•To reduce the risk of electric shock, make sure the chassis of this
unit is properly grounded.
1) Remove LINE VOLTAGE INPUT PLUG and install proper
fittings and 1/2”conduit.
2) Route proper LINE VOLTAGE wires into operator.
3) Locate LINE INPUT terminals on circuit board. Using
correct connectors, attach wires to LINE INPUTS, and GROUND
terminal.
•Keep low voltage and line voltage wires separate.
•Route all line voltage wires as shown.
•Plug all unused conduit holes.
P
HIGH
VOLTAGE
INPUT PLUGS
(Right & Left)
ROUTE HIGH VOLTAGE WIRING
IN THE SHADED AREA AS SHOWN
LINE INPUT
TERMINALS
LINE
GROUND
LINE INPUT
TERMINALS
LINE
GROUND
ROUTE HIGH VOLTAGE WIRING
IN THE SHADED AREA AS SHOWN
N/ 2
GND
LINE IN
POWER CONNECTIONS
LINE IN
POWER CONNECTIONS
LINE
(HO NEU RAL
LINE LINE 2
12
GND
LINE 1 LINE 2 L NE 3
Three Phase
Single Phase
5V
208V
230V
HIGH
VOLTAGE
INPUT PLUGS
(Right & Left)
Section 5: Wiring
Figure 1
Line Voltage Wiring Fig. 1
Standard Duty Operator
GCL-T

5.2
1) Connect all LOW VOLTAGE control circuit wires to this end
of the unit using 1/2” conduit or flexible convoluted tubing.
•Keep low voltage and line voltage wires separate.
•Route all low voltage control wiring as shown. This includes
all control circuit wires such as wall controls, timers and single
button input devices as well as radio control and safety
circuit wiring. See Figs 2 through 10 in this section.
•Plug all unused conduit holes.
Low Voltage Control Wiring (general) Fig. 2
ROUTE LOW VOLTAGE WIRING
IN THE SHADED AREA AS SHOWN
LOW
VOLTAGE
INPUT
PLUGS
(Left &
Right)
LOW VOLTAGE
CONTROL WIRE
TERMINALS
Optional
Accessory
Modules
Figure 2
NOTE: For a detailed description of control wire terminals see Appendix B.
www.geniecompany.com 06-12
Standard Duty Operator
GCL-T

5.3
External Wire Diagram
See Appendix B for detailed description of terminals.
www.geniecompany.com 06-12
1-BTN
STATION
KEY
SWITCH
STATION
CARD
READER
O/C
PULL
SWITCH
N/O
N/O
N/O
N/O
REMOVE
JUMPER
WHEN
INSTALLING
EXTERNAL
INTERLOCK
MULTIPLE
3-BUTTON
STATION
INSTALLATIONS
REQUIRE THE
STOP BUTTON
TO BE WIRED
IN SERIES.
See Fig. 5, pg 5.4
*
EXT
INTLK
EXT
INTLK
N-O
REVERSE
N-O
REVERSE
ODC
STB
ODC
STB
1-BTNGNDSTOPCLOSEOPEN
EXT RADIO CONNECTOR
SENSING EDGE SWITCH
(DO NOT CONNECT
2-WIRE MONITORED
SENSING EDGE SWITCH
TO THESE INPUTS)
THRU-BEAM PHOTOCELLS
+
-
+
-
PWR
20-40 VDC @ 250mA
MAX CURRENT
RELAY
GND
NOM
+24VDC
RADIO
SERIES II SAFE-T-BEAM ®
(STB)
(*CONNECT STB WIRES
TO EITHER TERMINAL)
*
OPEN
CLOSE
STOP
REMOVE
JUMPER
IF STOP
BUTTON
IS USED
3-BUTTON
STATION
*
BLUE
ORANGE YELLOW
Located inside
Electrical Box
2-WIRE MONITORED SENSING EDGE SWITCH
SIGNATURE
MODULE
Standard Duty Operator
GCL-T

1) For a single 3 - button installation, make connections as
shown in Fig. 3.
2) For single button accessory controls, make connections as
shown in Fig. 4.
3) For a multiple 3 - button installations, make connections as
shown in Fig. 5.
NOTE: If an External STOP button is NOT being installed, a jumper wire
must be installed between the “STOP” AND “GND” terminals as shown.
NOTE: Long Distance Relay Kit wiring is not required for long
distance control runs and should not be used
5.4
Wall Control
WARNING:
•Wall Control(s) must be located so that the door is within sight of
the user and is far enough from the door, or positioned such that
the user is prevented from coming in contact with the door while
operating the controls .
•Attach the Warning placard adjacent to the Wall Control. Fig. 3A.
WARNING:
If momentary contact control is to be used, an external reversing device such
as a photocell system or sensing edge switch must be used. See pages
5.6-5.7 for installation of entrapment protection devices.
NOTE:
JUMPER BETWEEN
STOP AND GND
TERM NALS MUST
BE REMOVED
3-BUTTON
STAT ON
CONTROL SIGNAL TERMINAL STRIP
OPEN CLOSE STOP GND
3-BUTTON
STAT ON
OPEN
CLOSE
STOP
OPEN
CLOSE
STOP
Figure 4
1-BTN
STAT ON
KEY
SW TCH
STAT ON
CARD
READER
OPEN/CLOSE
PULL SW TCH
CONTROL SIGNAL TERMINAL STRIP
ODC
STB
GNDSTOP 1-BTN
Figure 5
OPEN
CLOSE
STOP
3-BUTTON
STAT ON
CONTROL SIGNAL TERMINAL STRIP
NOTE:
JUMPER BETWEEN
STOP AND GND
TERMINALS MUST
BE REMOVED
OPEN CLOSE STOP GND
Figure 3
11 735
Entrapment
Warning
Placard
Figure 3A
www.geniecompany.com 06-12
Standard Duty Operator
GCL-T
