Genie RMZ Z Series User manual

09/2021113103.00231
NOT FOR RESIDENTIAL USE
Sidemount Operator
This installation manual provides the information required to install,
program, troubleshoot and maintain
RMZJ & RMZH operators.
Jackshaft/Hoist Operators can be assembled in the following congurations:
• Chain Couple
Jackshaft/Hoist Operators can be installed on the following types of doors up to 16 feet high:
• Sectional Doors - Vertical Lift, Lift Clearance Type
• Rolling Steel Doors
APPLICATIONS:
HP/Max Door Weight/Height:
• Sectional - 1/2 HP Only - 620lbs/16 ft.
• Rolling Steel - 1/2 HP Only - 580lbs/16 ft.
For Z Series MODELS
OPRMZJ5011B & OPRMZH5011BL/BR
™

SECTION 1: General Information & Instructions
General Information & Instructions ........................................................................................................................ 1.1
Safety Information & Instructions.....................................................................................................................1.2-1.3
Critical Installation Information - General ............................................................................................................ 1.4
Critical Installation Information - Entrapment Protection .............................................................................. 1.5
SECTION 2: Operator Installation
Sectional Sidemount Installation......................................................................................................................2.1-2.2
Rolling Steel FOH & TOH Installation...............................................................................................................2.3-2.4
Rolling Steel Wall Mount Installation...................................................................................................................... 2.5
Hand Chain & Keeper Installation............................................................................................................................ 2.6
Release Cord Installation & Clutch Adjustment.................................................................................................. 2.7
SECTION 3: Operator Wiring
Wiring Safety Information.......................................................................................................................................... 3.1
General Internal Wire Diagram ................................................................................................................................. 3.2
Line Voltage..................................................................................................................................................................... 3.3
Low Voltage ..................................................................................................................................................................... 3.4
Wall Controls ............................................................................................................................................................3.5-3.6
Accessory Overview...................................................................................................................................................... 3.7
Interlocks, Sectional Doors......................................................................................................................................... 3.8
Photocells............................................................................................................................................................... 3.9-3.10
Monitored Sensing Edge, Hardwire......................................................................................................................3.11
Monitored Sensing Edge, Wireless........................................................................................................................3.12
Sensing Edge, Hardwire with Expansion Board................................................................................................3.13
Non-Monitored Sensing Edge ................................................................................................................................3.14
External Radio Controls.............................................................................................................................................3.14
SECTION 4: Operator Programming & Menus
Safety Information......................................................................................................................................................... 4.1
Control Panel & Display Structure ........................................................................................................................... 4.2
Close Direction ............................................................................................................................................................... 4.3
Travel Limits..................................................................................................................................................................... 4.4
Limit Overrun.................................................................................................................................................................. 4.5
Monitored Reversing Devices................................................................................................................................... 4.6
Open & Close Modes.................................................................................................................................................... 4.7
Transmitter Programming.......................................................................................................................................... 4.8
Mid-Stop ........................................................................................................................................................................... 4.9
Max Run Timer..............................................................................................................................................................4.10
Cycle Counter................................................................................................................................................................4.11
GDO Version & Firmware...........................................................................................................................................4.12
GDO Type........................................................................................................................................................................4.12
SECTION 5: Troubleshooting
Troubleshooting LED’s................................................................................................................................................. 5.1
Run Mode Details .......................................................................................................................................................... 5.2
Run Code Chart .............................................................................................................................................................. 5.3
Error Codes................................................................................................................................................................5.4-5.7
SECTION 6: Service & Maintenance
Service & Maintenance Schedule ............................................................................................................................ 6.1
Parts Break Downs..................................................................................................................................................6.2-6.5
WARRANTY
INDEX

Check working condition of door before installing the operator. Door must be free from sticking and
binding. If equipped, deactivate any door locking device(s). Door repairs and adjustments, including
cables and spring assemblies MUST be made by a trained service representative using proper tools and
instructions.
CAUTION
!
ATTENTION
!
Vériez l’état de fonctionnement de la porte avant d’installer l’opérateur. La porte doit pouvoir bouger
librement et ne pas coincer. Désactivez tous les dispositifs de verrouillage de la porte (si équipés). Les
réparations et les réglages de porte, plus particulièrement pour les câbles et les ressorts DOIVENT être
eectués par un technicien qualié qui se sert d’outils appropriés et qui respecte les instructions.
DO NOT apply line voltage until instructed to do so.
WARNING
!
AVERTISSEMENT
!
NE PAS mettre sous tension tant que l’instruction n’est pas donnée de le faire.
Job Site Issues to Consider/Concerns
The following list of items should be considered prior to selecting an operator for a given job site.
1. Available power supply.
2. Type of door.
3. Potential operator mounting obstructions. Items to consider include, but are not limited to: side room,
room above door shaft, room below door shaft, available mounting surface integrity, power supply
location, and convenient chain hoist and release cable positioning.
4. Size of door for appropriate operator torque and door travel speed selection.
5. Operator mounting environment. Items to consider include operator location, dampness of location,
dustiness of the location and corrosiveness of the location.
6. Door activation needs/requirements. Examples include 3 button control stations, 1 button control
stations, radio controls, pull cords, loop detectors, photoelectric controls, key switches, etc. See
“Entrapment Protection” section.
7. Interlock switches are required under certain conditions for doors with pass doors, door lock and dock
levelers.
8. Accessory equipment. Examples include reversing edges and/or photocell beams, which are required for
doors set to operate as momentary contact, auxiliary control relays, warning lights, etc. See “Entrapment
Protection” section.
Section 1: General Information & Instructions
Sec-1.1

Sec-1.2
Section 1: Safety Information & Instructions
POTENTIAL HAZARD EFFECT PREVENTION
MOVING DOOR WARNING
Could result in Serious
Injury of Death
Do Not operate unless the doorway is in sight and free of obstructions.
Keep people clear of opening while door is moving.
Do Not allow children to play with the door operator.
Do Not change operator control to momentary contact unless and external
reversing means is installed.
Do Not operate a door that jambs or one that has a broken spring.
ELECTRICAL SHOCK WARNING
Could cause Serious
Injury or Death
Turn o electrical power before removing operator cover.
When replacing the cover, make sure wires are not pinched or near moving
parts.
Operator must be electrically grounded.
HIGH SPRING TENSION WARNING
Could cause Serious
Injury or Death
Do Not try to remove, repair or adjust springs or anything to which door
spring parts are fastened, such as wood block, steel bracket, cable or any
other structure or like item.
Repairs and adjustments must be made by trained service representative
using proper tools and instructions.
!
!
!
WARNING
Overhead Doors are large, heavy objects that move with the help of springs under high tension and electric motors.
Since moving objects, springs under tension, and electric motors can cause injury, your safety and the safety of
others depend on you reading the information in this manual. If you have any questions or do not understand
the information presented, call your nearest service representative. For the number of your local Overhead Door
Distributor, call 800-929-3667.
In this manual the words Danger, Warning, and Caution are used to stress important safety information. The word:
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION indicates potentially hazardous situation which, if not avoided, may result in injury or property
damage.
The word NOTE,is used to indicate important steps to be followed or important considerations.
!
!
!
!
1. Read manual and warnings carefully.
2. Keep the door in good working condition. Periodically lubricate all moving parts of door.
3. If door has a sensing edge, check operations monthly. Make any necessary repairs to keep it functional.
4. AT LEAST twice a year, manually operate the door by disconnecting it from the operator. The Door should open and close
freely. If it does not, the door must be taken out of service and a trained service representative must correct the condition
causing the malfunction.
5. The Operator Motor is protected against overheating by an internal thermal protector. If the motor protector is tripped,
a trained service technical may be needed to correct the condition which caused the overheating. When the motor has
cooled, thermal protector will automatically reset and normal operation can be resumed.
6. In case of power failure, the door can be operated manually by pulling the release cable to disconnect the operator drive
system.
7. Keep instructions in a prominent location near the pushbutton.
IMPORTANT
READ PRIOR TO ANY DOOR OPERATION

Sec-1.3
DANGER POTENTIEL EFFET PRÉVENTION
PORTE EN MOUVEMENT AVERTISSEMENT
Pourrait entraîner des
blessures graves voire la
mort
Utiliser uniquement si la porte est en vue et libre de tout obstacle. Ne
laisser personne se tenir dans l’ouverture de la porte pendant qu’elle est en
mouvement.
Ne pas permettre aux enfants de jouer avec l’opérateur de la porte.
Ne pas modier la commande de l’opérateur à contact momentané à moins
qu’un moyen d’inversion externe soit installé.
Ne pas faire fonctionner une porte qui bloque ou dont le ressort est cassé.
CHOC ÉLECTRIQUE AVERTISSEMENT
Pourrait entraîner des
blessures graves voire la
mort
Couper le courant avant d’enlever le couvercle de l’opérateur.
Lorsque le couvercle doit être remplacé, s’assurer que les ls ne sont ni
coincés ni près des pièces mobiles.
L’opérateur doit être correctement mis à la terre.
TENSION ÉLEVÉE RESSORT AVERTISSEMENT
Pourrait entraîner des
blessures graves voire la
mort
Ne pas essayer d’enlever, réparer ni ajuster les ressorts ou toute autre
pièce à laquelle le ressort de la porte est attaché, y compris blocs de bois,
supports en acier, câbles ou autres articles semblables.
Les réparations et les réglages doivent être eectués par technicien qualié
qui se sert d’outils appropriés et qui respecte les instructions.
!
!
!
Les portes basculantes sont de gros objets lourds qui fonctionnent à l’aide de ressorts soumis à une haute
tension et de moteurs électriques. Dans la mesure où les objets en mouvement, les ressorts sous tension et les
moteurs électriques peuvent entraîner des blessures, votre sécurité et celle des autres exigent que vous preniez
connaissance des informations stipulées dans ce manuel. Si vous avez des questions ou si vous ne comprenez pas
les informations ci-incluses, veuillez contacter le représentant de service le plus près. Pour obtenir le numéro du
revendeur Overhead Door local, appelez le [phone].
Dans ce manuel, les mots Danger, Avertissement, et Attention sont utilisés pour faire ressortir d’importantes
informations relatives à la sécurité. Le mot :
DANGER signale une situation dangereuse imminente qui si elle n’est pas évitée, risque d’entraîner des blessures
graves, voire mortelles.
AVERTISSEMENT signale une situation potentiellement dangereuse qui, si elle n’est pas évitée, risque d’entraîner
la mort ou des blessures graves.
ATTENTION signale une situation potentiellement dangereuse qui, si elle n’est pas évitée, risque d’entraîner des
blessures ou des dommages matériels.
Le terme REMARQUE est utilisé pour signaler les étapes importantes à suivre ou d’importants éléments à prendre en
considération.
AVERTISSEMENT
!
!
!
!
Section 1: Safety Information & Instructions

Sec-1.4
Section 1: Critical Installation Information
1. READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS.
2. Install only on a properly operating and balanced door. A door that is operating improperly could cause
severe injury. Have qualied service personnel make repairs to cables, spring assemblies and other hardware
before installing the operator.
3. Remove all pull ropes and remove, or make inoperative, all locks (unless mechanically and/or electronically
interlocked to the operator) that are connected to the door before installing the operator.
4. Install the door operator at least 8ft. (2.44m) or more above the oor if operator has exposed moving parts.
If the operator must be installed less than 8ft. (2.44m) above the oor, then exposed moving parts must be
protected by covers or guarding, provided by the operator manufacturer.
5. Do not connect the door operator to the power source until instructed to do so.
6. Locate the control station: (a) within sight of the door, (b) a minimum of 5 feet above the oor so that small
children cannot reach it, and (c) away from all moving parts of the door.
7. Install the Entrapment Warning Placard next to the control station and in a prominent location.
8. For products having a manual release, instruct the end user on the operation of the manual release.
IMPORTANT INSTALLATION INSTRUCTIONS
WARNING
To reduce the risk of severe injury or death:
!
1. LIRE ET RESPECTER TOUTES LES INSTRUCTIONS D’INSTALLATION.
2. Installez uniquement sur une porte fonctionnant correctement et bien équilibrée. Une porte qui fonctionne
mal peut provoquer des blessures graves. Demandez à un technicien qualié d’eectuer les réparations des
câbles, des ressorts et de toute autre quincaillerie avant de procéder à l’installation de l’opérateur.
3. Retirez toutes les cordes de traction ainsi que tous les verrous ou rendez-les inopérants (à moins qu’ils ne
soient mécaniquement et/ou électroniquement interverrouillés à l’unité motrices) qui sont connectés à la
porte avant de procéderà l’installation de l’opérateur.
4. Installez l’opérateur de porte à une distance de 2,44 m (8 pi) ou plus au-dessus du sol si des pièces en
mouvement de l’opérateur sont exposées. Si l’opérateur doit être installé à une distance de moins de 2,44
m (8 pi) au-dessus du sol, les pièces en mouvement exposées doivent être protégées par des couvercles ou
systèmes de protection fournis par le fabricant de l’opérateur.
5. Ne pas raccorder l’opérateur de la porte à la source d’alimentation avant que l’instruction ne soit donnée de
le faire.
6. Installez la station de commande : (a) en vue de la porte, (b) à 1,5 m minimum au-dessus du sol pour que les
jeunes enfants ne puissent pas l’atteindre, et (c) à l’écart de toutes les pièces mobiles de la porte.
7. Installez le poster d’avertissement de pincement à côté de la station de commande à un endroit bien en vue.
8. Pour les produits ayant un déclenchement manuel, indiquez à l’utilisateur comment déclencher
manuellement.
IMPORTANT INSTRUCTIONS D’INSTALLATION
AVERTISSEMENT
Pour réduire les risques de blessures graves ou de mort:
!

Sec-1.5
Section 1: Critical Installation Information
ENTRAPMENT PROTECTION:
The installation of a monitored fail safe external reversing device is required on all momentary contact
electronically operated commercial doors. If such a reversing device is not installed, the operator will
revert to a constant contact control switch for close operation.
The Reversing Devices currently UL Approved are:
• MillerEdge® ME and MT series monitored edge sensors used in combination with Timer-Close
Module (TCM) P/N OPABTCX.S or Sensing Module (ESM) P/N OPABESX.S
• MillerEdge® ME and MT series monitored edge sensors used in combination with MillerEdge
Interface Module P/N OPAKMEIX.S. (Direct connect through STB inputs.)
• MillerEdge® Wireless (MEL) monitored edge sensor P/N OPAKMMWE2.S. (Direct connect through STB
inputs.)
• ASO Sentir GF Series Monitored Sensing Edges used in combination with Timer Close Module (TCM)
P/N OPABTCX.S or Edge Sensing Module (ESM) P/N OPABESX.S
• Residential Safe-T-Beam® Monitored Photocells - P/N 37220R (GST B-BX) and commercial P/N
38176R.S (includes extension brackets).
• Series II Commercial Safe-T-Beam® Monitored Photocells - P/N OPAKPE2.S and OPAKPEN4X.S (NEMA
4).
• Monitored Retro-Reective Photocells - P/N OPAKRPEN4X.S
• Monitored MillerEdge Light Curtain -P/N OPAKMLC3.S & OPAKMLC6.S
Monitored Sensing Edges are available in any door width.
NOTE: DO NOT use take up reels in conjunction with the Monitored Sensing Edge system. Use Coil Cords Only.
IMPORTANT INSTALLATION INFORMATION

Sec-2.1
Section 2: Sectional Operator Installation
FIG. 2
The RMZ Side Mount Operator can be ordered for right or left
hand mounting above or below the door shaft. FIG. 1.
NOTE: The operator output shaft extends 5” on each side of the MZ
operator frame.
1. Attach 12 tooth sprocket to operator output shaft.
2. Align keyways and insert key into sprocket and output shaft keyway. Do not tighten set screws at this
time.
3. Attach door sprocket to door shaft. Align keyways and insert key into sprocket and door shaft keyway.
Do not tighten set screws at this time.
4. Assemble chain using chain connecting link.
5. Place assembled chain over door shaft sprocket.
6. Raise or lower operator to remove slack from the chain.
7. Be certain operator output shaft is parallel with door shaft.
8. Align chain and secure operator to wall or mounting pad using lock down holes. FIG. 2.
9. Tighten operator and door sprocket set screws.
INSTALLATION TIP:
While sprocket set screws are loose, if possible, manually operate door to help align chain. A properly
tensioned drive chain should deect no more than 1/2”when thumb pressure is applied mid-way between
the 2 sprockets.
NOTE: If using slotted mounting holes to mount unit, you must use at least 2 lock down holes in opposite corners
to rmly mount unit to wall. FIG. 2.
Chain Couple:
IMPORTANT: DOOR SHAFT
& OPERATOR OUTPUT
SHAFT MUST BE PARALLEL.
DOOR SHAFT
LOCK DOWN HOLES
OPERATOR OUTPUT
SHAFT
12”-15”
CENTER
DISTANCE
NOTE: OPERATOR MUST BE
SECURELY FASTENED TO
THE WALL USING LOCK DOWN
HOLES TO ENSURE PROPER
CHAIN TENSION.
LOCK DOWN HOLES
FIG. 1

Sec-2.2
Section 2: Sectional Operator Installation
Complete the Installation:
If needed, realign operator sprocket with door sprocket. If you have excessive door shaft movement, an
optional chain tension bracket is available.
Chain Tension Bracket:
Bracket is available as an optional kit for 1”door shafts, P/N 111005.0001.S
Installation of optional chain spreader bracket: FIG 1 .
1. Place sprocket, upper plate and bearing assembly on door shaft as shown.
2. Place lower plate, bearing assembly and sprocket on operator shaft as shown.
3. Install chain assembly.
4. Install bolts and nuts through plates.
5. Tighten and align chain and plate and secure operator to wall.
6. Tighten spreader bracket bolts.
7. Tighten sprocket set screws.
OPERATOR
SHAFT
DOOR
SHAFT
DOOR SPROCKET
GOESON FIRST
OPERATOR SPROCKET
GOES ON LAST
DOOR SHAFT
SPROCKET
DOOR SHAFT
KEY
SET SCREW
CHAIN
SET SCREW
OPERATOR
SHAFT
SPROCKET
KEY
CHAIN
TENSION
PLATE
OPERATOR
OUTPUT
SHAFT
SOLID COUNTERBALANCE
DOOR SHAFT
SET SCREW
FIG. 1
Finish Installation:
See page 2.4 for Chain Hoist Installation
See page 2.5 for Clutch Adjustment and Release Cord Installation.

Sec-2.3
Section 2: Rolling Steel Operator Installation
Rolling Steel/Grill Doors. FIG. 1
Front & Top of Hood:
The Rolling Steel Door Operator is congured at the factory for right-hand or left-hand (Hoist & Jackshaft)
Front of Hood, Top of Hood and Wall Mount.
1. Mounting hardware and instruction will be supplied based on door specications. (Typical mounting
arrangements shown.)
2. Attach rolling steel mounting bracket (A) to the operator using the fasteners provided.
3. Weld Operator bracket to the door plate (B).
Chain Installation:
4. Install 12 tooth sprocket (C) on operator output shaft.
5. Align keyways and insert key into sprocket and output shaft keyway. Do not tighten set screw at this
time.
6. Install door sprocket (D) on door shaft. Align keyways and insert key into sprocket and door shaft
keyway. Do not tighten set screws at this time
7. Assemble chain (E) using chain master link.
8. Place assembled chain over door shaft sprocket and around the 12 tooth sprocket.
9. Using the slots in the mounting bracket (A), adjust the operator to remove slack from the chain. Be
certain operator output shaft is parallel with the door shaft.
10. Tighten operator mounting bracket nuts.
11. Tighten sprocket set screws.
Finish Installation:
See Sec- 2.6 for Chain Hoist Installation
See Sec- 2.7 for Clutch Adjustment and Release Cord Installation.

Sec-2.4
FIG. 1
A
B
C
D
E
Section 2: Rolling Steel Operator Installation
FRONT OF HOOD MOUNTING
TOP OF HOOD MOUNTING
A
B
C
D
E

Sec-2.5
WALL MOUNTING
Rolling Steel/Grill Doors. FIG. 1
Wall Mount:
The Rolling Steel Door Operator is congured at the factory for right-hand or left-hand (Hoist & Jackshaft)
Front of Hood, Top of Hood and Wall Mount.
1. Mounting hardware and instruction will be supplied based on door specications. (Typical mounting
arrangements shown.)
2. Operator must be fastened to the door framing material with suitable hardware designed for the
mounting surface (i.e. wood, masonry etc.
Installation:
3. Install 12 tooth sprocket (C) on operator output shaft.
4. Align keyways and insert key into sprocket and output shaft keyway. Do not tighten set screw at this time.
5. Install door sprocket (D) on door shaft. Align keyways and insert key into sprocket and door shaft keyway.
Do not tighten set screws at this time.
6. Assemble chain (E) using chain master link.
7. Place assembled chain over door shaft sprocket and around the 12 tooth sprocket.
8. Using the slots in the mounting bracket (A), adjust the operator to remove slack from the chain. Be certain
operator output shaft is parallel with the door shaft.
9. Align and square operator. Mark within slotted mounting holes on operator and install mounting hardware.
10. Tighten operator mounting bracket hardware.
11. Install suitable hardware in, at least 2, of the 4 lock down holes located in each corner of the mounting
brackets (B).
12. Tighten sprocket set screws.
Finish Installation:
See page 2.6 for Chain Hoist Installation
See page 2.7 for Clutch Adjustment and Release cord installation.
Section 2: Rolling Steel Operator Installation
A
B x4
C
D
EParallel

Sec-2.6
FIG. 1
Hand Chain & Keeper
1. Route the hand chain through the chain guide, around the pocket wheel and back through the chain
guide. FIG.1.
2. Connect the hand chain ends together as shown in FIG 2. by twisting open the last link on one end of the
chain, and slipping the last link on the opposite end onto the open link.
3. Twist open link closed again.
4. Mount chain keeper to wall in line with chain approximately 4 feet from oor.
5. Loop chain around keeper as shown. FIG. 3. Optional Padlock not provided.
NOTE: To ensure smooth operation, make sure there are no twist in the hand chain before connecting the link
ends together.
FIG. 2
FIG. 3
Section 2: Operator Installation

Sec-2.7
Section 2: Operator Installation
Clutch Adjustment:
The RMZ Operators have a friction style clutch that can be adjusted.
NOTE: The clutch is intended to provide protection for the door, the operator and associated equipment. It is not
intended for entrapment protection. Therefore, the adjustment of the clutch should be such that the door and
operator function in this manner.
To Adjust the Clutch:
1. Decrease the tension on the clutch until the operator will not lift the door. Turn the adjusting castle nut
counter-clockwise to decrease clutch tension and clockwise to increase clutch tension.
2. After completing step 1, begin to increase tension on the clutch until the operator is capable of lifting
the door through the complete cycle without clutch slippage.
3. Insert the cotter pin through the castle nut and shaft and
bend the outer leg of the cotter pin.
NOTE: Periodically check the system for proper clutch action. If
clutch starts to slip after working properly for some time, check
manual operation of door BEFORE adjusting clutch. The door
may not be operating freely or the counterbalance spring may
need adjusting. Repairs and adjustments must be performed by a
trained service representative using proper tools and instructions.
CLUTCH PAD
CLUTCH PLATE
CLUTCH PULLEY
WASHER
COTTER PIN
ADJUSTING NUT
SPRING
FIG. 1
Attach Release Cord to
Connection Point. (Hoist shaft
assembly removed for clarity)
Install Release Cord:
• HOIST MODELS: Attach release cord to clutch shaft release lever and route as shown in FIG. 1.
• NON-HOIST MODELS: Feed release cord through washer and tie o. Route through brake assembly and
bracket as shown in FIG 2. Install emergency release handle to other end.
FIG. 2
Route through cord
hold down clamps.
Tie cord behind washer and route
through brake plate and bracket.
Tie release knob to bottom end
approximately 5 feet from oor.

Sec-3.1
Section 3: Wiring
WARNING
• DO NOT apply power to operator until instructed to do so.
• It is strongly recommended, and may be required by law in some areas, that line voltage wiring be
performed by a qualied electrician.
• Be sure that electrical power has been disconnected from the input power wires being connected
to the operator prior to handling these wires. An appropriate lock-out/tag-out procedure is
recommended.
• Line voltage wiring must meet all local building codes.
• Make sure operator voltage, phase and frequency nameplate ratings are identical to the job site line
voltage ratings.
• Input power wiring must be properly sized for the operators amperage rating located on the
nameplate.
• To reduce the risk of electric shock, make sure the chassis of this unit is properly grounded.
!
• NE PAS mettre sous tension tant que l’instruction n’est pas donnée de le faire.
• Il est fortement recommandé voire même exigé par la loi dans certaines régions, de contacter un
électricien qualié pour l’acheminement du l électrique.
• Assurez-vous que l’alimentation électrique a été déconnectée des câbles d’alimentation d’entrée
connectés à l’opérateur avant de manipuler ces câbles. Une procédure de verrouillage/étiquetage
appropriée est recommandée.
• Le câblage au secteur doit satisfaire à tous les codes de construction locaux.
• Assurez-vous que les valeurs nominales de la plaque signalétique pour tension, phase et fréquence de
l’opérateur correspondent à celles des tensions de l’alimentation sur site.
• La capacité d’entrée doit correspondre à la valeur nominale de l’ampérage des opérateurs indiquée sur
la plaque signalétique.
• Pour réduire le risque de choc électrique, assurez-vous que le châssis de l’unité est correctement mis à
la terre.
AVERTISSEMENT
!
Installation of all wiring and connections, including Power Limited Class 1 and Class 2 circuits, shall be performed in
accordance with, but not limited to, the latest NFPA, UL, and N.E.C. standards and codes.
In addition, all installations subject to Canadian standards shall be performed in accordance with the Canadian
Electrical Code, Part 1, with respect to wiring material type, wiring gauge related to power capacity requirements,
circuit length and wiring methods.
NOTE

Sec-3.2
L1 N
GND
PWR RAD GND
OPEN CLOSE STOP GND 1-BTN N-O
SAFETY
N-O SAFETY
ODC STB
ODC STB
EXT INTLK
EXT INTLK
OPEN
CLOSE
STOP
1-BTN
STATION
KEY
SWITCH
STATION
CARD
READER
O/C
PULL
SWITCH
RELAY
GND
NOM + 24VDC
SENSING EDGE SWITCH
N-O N-O N-O N-O
3-BUTTON STATION SERIES II (STB) PHOTOCELLS
+
-
+
-
THRU-BEAM PHOTOCELLS
RADIO
REMOVE JUMPER WHEN INSTALLING EXTERNAL INTERLOCK
CONTROL SIGNAL TERMINAL STRIP
MULTIPLE 3-BUTTON
STATION INSTALLATIONS REQUIRE THE STOP
BUTTON TO BE WIRED IN SERIES
REMOVE JUMPER IF STOP BUTTON IS USED
LINE IN
POWER CONNECTIONS CLASS 2 SUPPLY 20-40 VDC
120V
EXTERNAL RADIO CONNECTIONS
CLASS 2 SUPPLY 20-40 VDC
(*CONNECT STB WIRES TO EITHER TERMINAL)
LINE (HOT) NEUTRAL
*
GND
PWR
20-40 VDC @ 300MA
MAX CURRENT
BLUE
ORANGE
YELLOW
*
*
Interface Module
2-wire monitored edge switch
GENERAL INTERNAL WIRE DIAGRAM
Section 3: Wiring

Sec-3.3
1. Remove LINE VOLTAGE INPUT PLUG and install proper ttings and 1/2”conduit.
2. Route proper LINE VOLTAGE wires into operator.
3. Locate LINE INPUT terminals on circuit board. Using correct connectors, attach wires to LINE INPUTS, and
GROUND terminal.
• Keep low voltage and line voltage wires separate.
• Route all line voltage wires as shown.
• Plug all unused conduit holes.
Line Voltage Wiring
Section 3: Wiring
-
HIGH VOLTAGE
INPUT PLUG
LINE INPUT
TERMINALS
LINE
GROUND
ROUTE LINE VOLTAGE
WIRING IN SHADED
AREA AS SHOWN
L1 N
GND
LINE IN
120V LINE
(HOT) NEUTRAL
HIGH VOLTAGE
INPUT PLUG
POWER CONNECTIONS
DO NOT DRILL ELECTRIC BOX
Remove plugs to install wiring

Sec-3.4
1. Connect all LOW VOLTAGE control circuit wires using 1/2” conduit or exible convoluted tubing.
• Keep low voltage and line voltage wires separate.
• Route all low voltage control wiring as shown. This includes all control circuit wires such as wall
controls, timers and single button input devices as well as safety circuit wiring.
• Plug all unused conduit holes.
Low Voltage Control Wiring
Section 3: Wiring
LOW VOLTAGE
CONTROL WIRE
TERMINAL STRIP
ROUTE LOW VOLTAGE
WIRE IN SHADED AREA
LOW VOLTAGE
INPUT PLUG
DO NOT DRILL ELECTRIC BOX
Remove plugs to install wiring

Sec-3.5
Wall Controls
WARNING
• Wall Control(s) must be located so that the door is within sight of the user and is far enough from
the door, or positioned such that the user is prevented from coming in contact with the door while
operating controls.
• Attach the Warning placard adjacent to the Wall Control. FIG. 4.
!
AVERTISSEMENT
!
• La ou les commandes murales doivent être situées de telle sorte que l’utilisateur puisse voir la porte
et positionnées de telle sorte que l’utilisateur ne puisse pas entrer en contact avec la porte lorsqu’il se
sert des commandes.
• Fixez le poster d’avertissement à côté de la commande murale. FIG. 4
Avant d’utiliser la commande à contact momentané sur le bouton FERMETURE, un dispositif d’inversion
externe surveillée tel qu’un système de cellule photoélectrique ou un commutateur de détection de bord
doit être utilisé.
Voir l’installation des dispositifs de protection contre le coincement en.
WARNING
Before momentary contact control can be used on the CLOSE button, a monitored external reversing
device such as a photocell system or sensing edge switch must be used.
See ENTRAPMENT SECTION for installation of entrapment protection devices.
!
AVERTISSEMENT
!
Section 3: Wiring

Sec-3.6
1. For a single open/close/stop installation, make connections as shown in FIG. 1.
2. For single button accessory controls, make connections as shown in FIG. 2.
3. For a multiple open/close/stop installations, make connections as shown in FIG. 3.
4. Install WARNING placard next to control station. FIG. 4
OPEN
CLOSE
STOP
CONTROL SIGNAL TERMINAL STRIP
NOTE:
JUMPER BETWEEN
STOPAND GND
TERMINALS MUST
BE REMOVED
OPEN CLOSE STOP GND 3-BTN
Station
Entrapment Warning
Placard
CONTROL SIGNAL TERMINAL STRIP
1-BTN
Station
Key
Switch
Station
Card
Reader
Open/Close
Pull Switch
STOP GND 1-BTN ODC
STB
CONTROL SIGNAL TERMINAL STRIP
OPEN
CLOSE
STOP
OPEN
CLOSE
STOP
OPEN CLOSE STOP GND NOTE: JUMPER
BETWEEN STOP
AND GND TERMINALS
MUST BE REMOVED
3-BTN
STATION
3-BTN
STATION
NOTE: If an External STOP button is NOT being installed, a jumper wire must be installed between the “STOP” and
“GND” terminals as shown.
NOTE: Low voltage wiring can be run a maximum of 1000 feet. DO NOT use long distance wiring kits on this
operator.
FIG. 1
FIG. 2
FIG. 3
FIG. 4
Section 3: Wiring
