Genie GDG360BT User manual

GDG360BT
Request To Exit Button
User Manual

CAP-REX-1G - Request To Exit Button
2
Function
PCB Setting Diagram
• As you put your hand near the exit button the capacitive technology will trigger the device without the
need to actually touch it. The color of the exit button will change from blue to green in colour when trig-
gered. At the same time, the relay inside the exit button device will trigger for 1 second and the built in
buzzer will beep once.
• To adjust the door open duration, please power off the exit button. Change the DIP Switch setting to
alter the door open duration from the table below, adjustable from 1 to 15 seconds, re-apply power
again for the change to take place.
• Support mechanical override.
• Support an external device/switch to trigger the unit.
• Remote Control is an option (Special order item)
The CAP-REX-1G is a contactless proximity exit button based on capacitive technology. It also equipped
with mechanical override function. In the event of power failure or electronic component failure, the button
will still function as a normal mechanical exit button.
For door open
duration setting
from 1 to 15 sec.

3
CAP-REX-1G - Request To Exit Button
Wiring
DIP Switch Setting
Installation
Label Description
+VDD Power input (+12V ~ +24VDC)
RTE_COM
Exit button output (dry contact)RTE_NO
RTE_NC
MO External device to trigger the door open, active low
GND Signal ground (0 VDC)
1ON 1 No. 1,2,3,4 are used for adjusting door open duration.
ON = Valid
OFF = Invalid
Door open duration = To add all the ON position switch numbers
Example:
If we set 1 and 4 to “ON”, the door open during will be:
1+8=9 the decimal number is 9 seconds (decimal number)
*Setting all DIP switch to OFF position means door duration = 1
sec.
OFF 0
2ON 2
OFF 0
3ON 4
OFF 0
4ON 8
OFF 0
5ON Turn off (buzzer) Turn off the buzzer
OFF Turn on (buzzer) Turn on the buzzer (default)
6ON N/A N/A
OFF N/A
7ON N/A N/A
OFF N/A
8ON Trigger distance (near) 2~3cm
OFF Trigger distance (far) 5cm (default)
NOTE Change the DIP Switch, please power off for changes to take
place.
1. Conrm the size of back box ts CAP REX-1G as
shown in Fig.1
2. Conrm all wiring is correct. Set the jumpers shown
below to the required positions.
3. Secure the exit button to the back box with correct
screws as shown in Fig.2.
4. There are 2 M-type buckles at the bottom of the
cover as shown in Fig.3. Align them into the slot at
the bottom of the module and then push the upper
part of the cover up as Fig.4 to secure exit button
cover. Unit is now ready to use.
M-Type Buckles
Fig 1
Fig 2 Fig 3 Fig 4

www.genieaccess.com
