Genie Z-30/20N Installation and operating manual

Service and Repair Manual
Serial Number Range
Z-30/20N
from Z30N14-15222
This manual includes:
Repair procedures
Fault Codes
Electrical and
Hydraulic Schematics
Z-30/20N RJ
from Z30N14-15222
Z-34/22N
from Z34N14-10984
Z-34/22DC
from Z3414-9686
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
Part No. 1268498
Rev A
September 2015

Service and Repair Manual September 2015
Introduction
ii Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Intr od ucti o n Intr od ucti o n
Impor ta nt In for m at i on
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
procedure.
This manual provides troubleshooting and repair
procedures for qualified service professionals.
Basic mechanical, hydraulic and electrical skills
are required to perform most procedures. However,
several procedures require specialized skills, tools,
lifting equipment and a suitable workshop. In these
instances, we strongly recommend that
maintenance and repair be performed at an
authorized Genie dealer service center.
Compliance
Machine Classification
Group B/Type 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Find a Manual for this Model
Go to http://www.genielift.com
Use the links to locate Operator's, Parts,
Maintenance, and Service and Repair manuals.
Copyright © 2015 by Terex Corporation
1268498 Rev A, September 2015
First Edition, First Printing
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries.
“Z” is a trademark of Terex South Dakota, Inc.

September 2015 Service and Repair Manual
Introduction
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N iii
Revision History
Revision Date Section Procedure / Page / Description
A 9/2015 New Release
Reference Examples:
Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Repair Procedure, 4-2
Section – Fault Codes, All charts
Section – Schematics, Legends and schematics

Service and Repair Manual September 2015
Introduction
iv Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Serial Number Legend
1 Model
2 Model year
3 Sequence number
4 Serial number (stamped on chassis)
5 Serial label (located under cover)

September 2015 Service and Repair Manual
Safety Rules
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N v
Section 1 Safet y R ul es Gener al Saf et y R ules
Danger
Failure to obey the instructions and safety rules in
this manual and the appropriate Operator's Manual
on your machine will result in death or serious
injury.
Many of the hazards identified in the operator's
manual are also safety hazards when maintenance
and repair procedures are performed.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

Service and Repair Manual September 2015
Safety Rules
vi Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each procedure thoroughly. This
manual and the decals on the machine,
use signal words to identify the following:
Safety alert symbol
—used to
alert personnel to potential
personal injury hazards. Obey all
safety message
s that follow this
symbol to avoid possible injury or
death.
Indicates a imminently hazardous
situation which, if not avoided,
will result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
could result in
death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may cause minor or moderate
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may result in property damage.
Be sure to wear prote
ctive eye wear and
other protective clothing if the situation
warrants it.
Be aware of potential crushing hazards
such as moving parts, free swinging or
unsecured components when lifting or
placing loads. Always wear approved
steel
-toed shoes.
Workplace Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable and
combustible materials like battery gases
and engine fuels. Always have an
approved fire extinguisher within easy
reach.
Be sure that all tools and working areas
are properly maintained and ready for
use. Keep work surfaces clean and free
of debris that could get into machine
components and cause damage.
Be sure any forklift, overhead crane or
other lifting or supporting
device is fully
capable of supporting and stabilizing the
weight to be lifted. Use only chains or
straps that are in good condition and of
ample capacity.
Be sure that fasteners intended for one
time use (i.e., cotter pins and self
-locking
nuts) are not
reused. These components
may fail if they are used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please be environmentally safe.
Be sure that your workshop or work area
is properly ventilated and
well lit.

September 2015
Table of Contents
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N vii
Introduction Introduction...........................................................................................................ii
Important Information ............................................................................................. ii
Find a Manual for this Model .................................................................................. ii
Revision History..................................................................................................... iii
Serial Number Legend .......................................................................................... iv
Section 1 Safety Rules ..........................................................................................................v
General Safety Rules ............................................................................................. v
Section 2Specifications .......................................................................................................1
Machine Specifications...........................................................................................1
Performance Specifications....................................................................................2
Hydraulic Specification ...........................................................................................3
Hydraulic Component Specifications......................................................................5
Manifold Component Specifications .......................................................................5
Machine Torque Specifications ..............................................................................6
Hydraulic Hose and Fitting Torque Specifications .................................................7
Torque Procedure ..................................................................................................8
SAE and Metric Fasteners Torque Charts ...........................................................10
Section 3 Repair Procedures .............................................................................................11
Introduction...........................................................................................................11
Platform Controls ...............................................................................................13
1-1 Controllers ......................................................................................................13
Platform Components........................................................................................15
2-1 Platform Leveling Slave Cylinder ...................................................................15
2-2 Platform Rotator .............................................................................................16
2-3 Platform Overload System .............................................................................17
Jib Boom Components ......................................................................................20
3-1 Platform Overload System .............................................................................20
3-2 Jib Boom Bell Crank (models without rotating jib boom) ...............................21
3-3 Jib Boom Bell Crank (models with rotating jib boom) ....................................22
3-4 Jib Boom Lift Cylinder ....................................................................................24

September 2015
Table of Contents
viii Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Primary Boom Components ............................................................................. 25
4-1 Cable Track.................................................................................................... 25
How to Repair the Primary Boom Cable Track............................................... 25
4-2 Primary Boom ................................................................................................ 26
How to Remove the Primary Boom ................................................................ 26
How to Disassemble the Primary Boom ......................................................... 28
4-3 Primary Boom Lift Cylinder ............................................................................ 29
4-4 Primary Boom Extension Cylinder ................................................................. 31
4-5 Platform Leveling Master Cylinder................................................................. 33
Secondary Boom Components ........................................................................ 34
5-1 Secondary Boom ........................................................................................... 35
5-2 Secondary Boom Lift Cylinders ..................................................................... 40
Hydraulic Pump.................................................................................................. 43
6-1 Auxiliary and Function Pump ......................................................................... 43
Manifolds ............................................................................................................ 44
7-1 Function Manifold Components ..................................................................... 44
7-2 Valve Adjustments - Function Manifold ......................................................... 48
How to Adjust the System Relief Valve .......................................................... 48
How to Adjust the Primary Boom Down Relief Valve ..................................... 48
How to Adjust the Secondary Boom Down Relief Valve ................................ 49
How to Adjust the Primary Boom Extend Relief Valve ................................... 49
How to Adjust the Turntable Rotate Relief Valve ........................................... 50
7-3 Jib Boom and Platform / Jib Boom Rotate Manifold Components ................ 51
7-4 Valve Coils ..................................................................................................... 53
How to Test a Coil Diode ................................................................................ 54
Turntable Rotation Components ...................................................................... 55
8-1 Turntable Rotation Hydraulic Motor ............................................................... 55
Steer Axle Components .................................................................................... 56
9-1 Hub and Bearings .......................................................................................... 56
How to Remove the Hub and Bearings .......................................................... 56
How to Install the Hub and Bearings .............................................................. 56
Non-steer Axle Components............................................................................. 57
10-1 Motor Controller ........................................................................................... 57

September 2015
Table of Contents
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N ix
Section 4 Fault Codes .........................................................................................................58
Introduction...........................................................................................................58
Fault Code Charts ...........................................................................................60
Section 5 Schematics..........................................................................................................63
Introduction...........................................................................................................63
Electrical Symbol Legend.....................................................................................64
Hydraulic Symbols Legend...................................................................................65
Limit Switch Location Legend...............................................................................66
Electrical Schematics – Options.......................................................................67
Power Cable Wiring Diagram ...............................................................................68
Drive Contactor Panel Wiring Diagram ................................................................69
Manifold and Limit Switch Wiring Diagram...........................................................72
LVI/BCI Option Wiring Diagram............................................................................73
Charger Interlock Option ......................................................................................76
CTE Option, (CE Models).....................................................................................77
Hydraulic Schematics ........................................................................................79
Hydraulic Schematic.............................................................................................80
Electrical Schematics – ANSI / CSA / AS Models..........................................81
Electrical Schematic, (ANSI / CSA / AS), (before serial numbers
Z30N10-12119, Z34N10-8857 and Z3410-7774).........................................82
Ground Control Box Terminal Strip Wiring Diagram, (ANSI / CSA / AS),
(before serial numbers Z3010-12119, Z34N10-8857 and Z3410-7774) ......83
Ground Control Box Terminal Strip Wiring Diagram, (ANSI / CSA / AS),
(before serial numbers Z3010-12119, Z34N10-8857 and Z3410-7774) ......86
Ground Control Box Switch Panel Wiring Diagram, (ANSI / CSA / AS),
(before serial numbers Z30N10-12119, Z34N10-8857 and Z3410-7774)....87
Platform Control Box Wiring Diagram, (ANSI / CSA / AS),
(before serial numbers Z30N10-12119, Z34N10-8857 and Z3410-7774)....90

September 2015
Table of Contents
x Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Electrical Schematics – CE Models ................................................................. 91
Electrical Schematic, (CE), (before serial numbers Z30N10-12119,
Z34N10-8857 and Z3410-7774)................................................................... 92
Ground Control Box Terminal Strip Wiring Diagram, (CE), (before serial
numbers Z30N10-12119, Z34N10-8857 and Z3410-7774) ......................... 96
Ground Control Box Switch Panel Wiring Diagram, (CE), (before serial
numbers Z30N10-12119, Z34N10-8857 and Z3410-7774) ......................... 97
Platform Control Box Wiring Diagram, (CE), (before serial numbers
Z30N10-12119, Z34N10-8857 and Z3410-7774) ...................................... 100
Electrical Schematics – ANSI and CSA Models............................................ 101
Electrical Schematic, (ANSI / CSA), (from serial numbers Z30N10-12119,
Z34N10-8857 and Z3410-7774)................................................................. 102
Ground Control Box Terminal Strip Wiring Diagram, (ANSI / CSA),
(from serial numbers Z30N10-12119, Z34N10-8857 and Z3410-7774) .... 106
Ground Control Box Switch Panel Wiring Diagram, (ANSI / CSA),
(from serial numbers Z30N10-12119, Z34N10-8857 and Z3410-7774) .... 107
Platform Control Box Wiring Diagram, (ANSI / CSA), (from serial
numbers Z30N10-12119, Z34N10-8857 and Z3410-7774) ....................... 110
Electrical Schematics – AS / CE Models ....................................................... 111
Electrical Schematic, (AS / CE), (from serial numbers Z30N10-12119,
Z34N10-8857 and Z3410-7774)................................................................. 112
Ground Control Box Terminal Strip Wiring Diagram, (AS / CE),
(from serial numbers Z30N10-12119, Z34N10-8857 and Z3410-7774) .... 116
Ground Control Box Switch Panel Wiring Diagram, (AS / CE),
(from serial numbers Z30N10-12119, Z34N10-8857 and Z3410-7774) .... 117
Platform Control Box Wiring Diagram, (AS / CE), (from serial numbers
Z30N10-12119, Z34N10-8857 and Z3410-7774) ...................................... 120

September 2015 Service and Repair Manual
Specifications
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N 1
Section 2 Speci fi c ati ons
Machi ne Sp ec if ic atio ns
Machine Specifications
Tires and wheels,
Z
-30/20N, Z-30/20N RJ and Z-34/22N
Tire size (solid rubber)
22 x 7 x 17.5 i
n
56 x 18 x 44 c
m
Load range
7600 l
bs
3447 k
g
Overall tire diameter
22 i
n
56 c
m
Wheel diameter
17.5 i
n
44 c
m
Wheel width
7 i
n
18 c
m
Tires and wheels, Z
-34/22
Tire size
9-
14.5 LT
Tire ply rating
12
Tire weight, new foam
-filled
(minimum)
175 l
bs
79 k
g
Overall tire diameter
28 i
n
71 c
m
Wheel diameter
14.5 i
n
37 c
m
Wheel width
7 i
n
18 c
m
Wheel lugs
Front
8 @ 5/8 -
18
Rear
9 @ 5/8 -
18
Lug nut torque, dry
125 ft-
lbs
169.5 Nm
Lug nut torque, lubricated
95 ft-
lbs
129 Nm
Fuel capacities
Hydraulic tank
4 g
allons
15.1 l
iters
Hydraulic system (including tank)
6 g
allons
22.7 l
iters
Drive hubs
48:1
57:1
24.5 fl oz/725 c
c
24.5 fl oz/725 c
c
Drive hub oil type: SAE 9
0 multipurpose hypoid gear oil
API service classification GL5
For operational specifications, refer to the
Operator's Manual.
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice or obligation.

Service and Repair Manual September 2015
Specifications
2 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Perf orm a nc e Sp ec i fic ati ons
Performance Specifications
Z-30/20N and Z-30/20N RJ
Drive speed, maximum
Stowed position
4.5 m
ph
7.2 k
m/h
40 ft / 6.0 s
ec
12.2 m / 6.0 s
ec
Boom raised or extended
0.6 mph1 km/h40 f
t /
42 sec12.2 m / 42 s
ec
Braking distance, maximum
High range on paved surface
2 to 4 f
t
0.6 t
o 1.2m
Gradeability
See Operator's
Manual
Boom
function speeds, maximum from platform
controls (with rated load secured to platform)
Jib boom up
19 to 23 s
econds
Jib boom down
17 to 21 s
econds
Jib boom rotate, 180°
13 to 17 s
econds
Primary boom up
14 to 22 s
econds
Primary boom down
12 to 20 s
econds
Primary boom extend
15 to 19 s
econds
Primary boom retract
10 to 14 s
econds
Secondary boom up
11 to 18 s
econds
Secondary boom down
7 to 15 s
econds
Turntable rotate, 355°
62 to 68 s
econds
Platform rotate, 180°
5 to 11 s
econds
Platform level up
14 to 19 s
econds
Platform level down
13 to 18 s
econds
Performance Specifications
Z-34/22 and Z-34/22N
Drive speed, maximum
Stowed position
4.5 m
ph
7.2 k
m/h
40 ft / 6.0 s
ec
12.2 m / 6.0 s
ec
Boom raised or extended
0.6 mph1 km/h40 f
t /
42 sec12.2 m / 42 s
ec
Braking distance, maximum
High range on paved surface
2 to 4 f
t
0.6 t
o 1.2m
Gradeability
See Operator's
Manual
Boom function speeds, maximum from platform
controls (with rated load secured to platform)
Jib boom up
20 to 24 s
econds
Jib boom
down 18 to 22 s
econds
Primary boom up
16 to 22 s
econds
Primary boom down
13 to 20 s
econds
Primary boom extend
11 to 15 s
econds
Primary boom retract
13 to 17 s
econds
Secondary boom up
15 to 22 s
econds
Secondary boom down
11 to 18 s
econds
Turntable
rotate, 355° 62 to 68 s
econds
Platform rotate, 180°
5 to 11 s
econds
Platform level up
14 to 19 s
econds
Platform level down
13 to 18 s
econds
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice or obligation.

September 2015 Service and Repair Manual
Specifications
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N 3
Hydra ul i c Speci fi c at i on
Hydraulic Oil Specifications
Hydraulic Fluid Specifications
Genie specifications require hydraulic oils which are
designed to give maximum protection to hydraulic
systems, have the ability to perform over a
wide
temperature range, and the viscosity index should
exceed 140. They should provide excellent antiwear,
oxidation prevention, corrosion inhibition, seal
conditioning, and foam and aeration suppression
properties.
Cleanliness level,
minimum
ISO 15/13
Water content,
maximum
250 p
pm
Recommended Hydraulic Fluid
Hydraulic oil type
Chevron Rando HD Premium
Viscosity grade
32
Viscosity index
200
Optional Hydraulic Fluids
Mineral based
Shell Tellus S2 V 32
Shell Tellus S2 V 46
Shell Tellus S4 VX 32
Shell
Shell Donax TG (Dexron III)
Chevron 5606A
Biodegradable
Petro Canada Environ MV
46
Fire resistant
UCON Hydrolube HP-
5046
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult Genie
Product Support before use.
Optional fluids may not have
the same hydraulic lifespan and
may result in component
damage.
Note: Extended machine operation can cause the
hydraulic fluid temperature to increase beyond it's
maximum allowable range. If the hydraulic fluid
temperature consistently exceeds 200°F / 90°C an
optional oil cooler may be required.
Do not top off with incompatible
hydraulic fluids. Hydraulic fluids
may be incompatible due to the
differences in base additive
chemistry. When incompatible
fluids are mixed, insoluble
materials may form and deposit
in the hydraulic system,
plugging hydraulic lines, filters,
control valves and may result in
component damage.
Note: Do not operate the machine when the
ambient air temperature is consistently above
120°F / 49°C.
Hydraulic Fluid Temperature
Range
Ambient air temperature
1 Chevron hydraulic oil 5606A
2 Petro-Canada Environ MV 46
3 UCON Hydrolube HP-5046D
4 Chevron Rando HD premium oil MV

Service and Repair Manual September 2015
Specifications
4 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Chevron Rando HD Premium Oil
MV Fluid Properties
ISO Grade
32
Viscosity index
200
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
7.5
33.5
Brookfield Viscosity
cP @
-4°F / -20°C
cP @
-22°F / -30°C
1040
3310
Flash point
375°F / 190°C
Pour point
-58°F / -
50°C
Maximum
continuous operating
temperature
171°F / 77°C
Note: An hydraulic oil heating system is
recommended when the ambient temperature is
consistently below 0°F / -18°C.
Note: Do not operate the machine when the
ambient temperature is below -20°F / -29°C with
Rando HD Premium MV.
Chevron 5606A Hydraulic Oil
Fluid Properties
ISO Grade
15
Viscosity index
300
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
cSt @
-40°F / -40°C
5.5
15.0
510
Flash point
180°F / 82°C
Pour point
-81°F / -
63°C
Maximum
continuous operating
temperature
124°F / 51°C
Note: Use of Chevron 5606A hydraulic fluid, or
equivalent, is required when ambient temperatures
are consistently below 0°F / -17°C unless an oil
heating system is used.
Continued use of Chevron
5606A
hydraulic fluid, or
equivalent, when ambient
temperatures are consistently
above 32°F / 0°C may result in
component damage
Petro-Canada Environ MV 46
Fluid Properties
ISO Grade
46
Viscosity index
154
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F /
40°C
8.0
44.4
Flash point
482°F / 250°C
Pour point
-49°F / -
45°C
Maximum continuous operating
temperature
180°F / 82°C
UCON Hydrolube HP-5046 Fluid
Properties
ISO Grade
46
Viscosity index
192
Kinematic Viscosity
cSt @ 149°F / 65°C
cSt @ 104°F /
40°C
cSt @ 0°F /
-18°C
22
46
1300
Flash point
None
Pour point
-81°F / -
63°C
Maximum continuous operating
temperature
189°F / 87°C

September 2015 Service and Repair Manual
Specifications
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N 5
Hydra ul i c C omp o ne nt Spec i fic a ti o ns
Hydraulic Component
Specifications
Function pump
Type: Fixed displacement gear
pump
Displacement
0.183 c
u in
3 c
c
Flow rate @280
0 psi / 172 bar 2.1 g
pm
7.9 L/min
Hydraulic tank return filter
10 micron with 25 p
si /
1.7 bar bypass
Function manifold
System relief valve pressure,
Z
-30/20N and Z-30/20N RJ
2800 p
si
193 b
ar
System
relief valve pressure,
Z
-34/22 and Z-34/22N
3200 p
si
221 b
ar
Primary boom down relief pressure
1600 p
si
110 b
ar
Secondary boom down relief pressure
1600 p
si
110 b
ar
Primary boom extend relief pressure
Models with rotating jib
1800 p
si
124 b
ar
Turntable
rotate relief pressure 1100 p
si
76 b
ar
Auxiliary pump
Type: Fixed displacement gear pump
Displacement
0.3 g
pm
1.14 L/min
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice or obligation.
Manif ol d Com p on e nt Spec ifi c ati on s
Manifold Component
Specifications
Plug torque
SAE No. 2
36 in-
lbs / 4 Nm
SAE No. 4
10 ft-
lbs / 13 Nm
SAE No. 6
14 ft-
lbs / 19 Nm
SAE No. 8
38 ft-
lbs / 51 Nm
SAE No. 10
41 ft-
lbs / 55 Nm
SAE No. 12
56 ft-
lbs / 76 Nm
Valve Coil Resistance
Note: The following coil resistance specifications are at
an ambient temperature of 68°F / 20°C. As valve coil
resistance is sensitive to changes in air temperature,
the coil resistance will typically increase or dec
rease by
4% for each 18°F / 10°C that your air temperature
increases or decreases from 68°F / 20°C.
Valve Coil Resistance Specification
Description
Specification
Solenoid valve,
3 position 4 way, 20V DC
(schematic items A, J, K, U, V, Y, AA, AB
and CC)
22
Ω
Proportional solenoid valve, 24V DC
(schematic item H)
19.5
Ω
Solenoid valve, N.C. poppet, 20V DC
(schematic item M)
23.5
Ω
Solenoid valve, N.O. poppet, 20V DC
(schematic item P)
23.5
Ω

Service and Repair Manual September 2015
Specifications
6 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Machi ne T orq ue Spe c if ic a ti o ns
Machine Torque Specifications
Platform rotator and jib boom rotator (Z
-30/20N RJ)
1
-8 center bolt, GR 5, lubricated
(Jib boom rotator)
480 ft-
lbs
650 Nm
3/4
-10 bolt, GR 8, lubricated
(Platform rotator)
280 ft-
lbs
379 Nm
3/8
-16 bolts, GR 8, lubricated
(Platform
rotator)
23 ft-
lbs
31 Nm
1/2
-13 bolts, GR 5, lubricated
(Jib boom rotator)
57 ft-
lbs
77 Nm
Platform rotator
(Z
-30/20N, Z-34/22 and Z-34/22N)
3/4
-10 bolt, GR 8, lubricated 280 ft-
lbs
379 Nm
3/8
-16 bolts, GR 8, lubricated 23 ft-
lbs
31 Nm
Turntable
rotate bearing
Rotate bearing mounting bolts, lubricated
180 ft-
lbs
244 Nm
Drive hubs, brakes and motors
Drive hub mounting bolts, lubricated
180 ft-
lbs
244 Nm
Brake mounting bolts, lubricated
93 ft-
lbs
126 Nm
Drive motor mounting bolts
31 ft-
lbs
42
Nm
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice or obligation.

September 2015 Service and Repair Manual
Specifications
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N 7
Hydra ul i c H ose an d Fi t ti n g T or q ue Sp ec ifi c atio ns
Hydraulic Hose and Fitting
Torque Specifications
Your machine is equipped with Parker Seal-Lok™
ORFS or 37° JIC fittings and hose ends. Genie
specifications require that fittings and hose ends
be torqued to specification when they are removed
and installed or when new hoses or fittings are
installed.
Seal-Lok™ Fittings
(hose end - ORFS)
SAE Dash Size
Torque
-4 10 ft-lbs / 13.6 Nm
-6 30 ft-lbs / 40.7 Nm
-8 40 ft-lbs / 54.2 Nm
-10 60 ft-lbs / 81.3 Nm
-12 85 ft-lbs / 115 Nm
-16 110 ft-lbs / 150 Nm
-20 140 ft-lbs / 190 Nm
-24 180 ft-lbs / 245 Nm
JIC 37° Fittings
(swivel nut or hose connection)
SAE Dash Size Thread Size Flats
-4 7/16-20 2
-6 9/16-18 1 ¼
-8 3/4-16 1
-10 7/8-14 1
-12 1 1/16-12 1
-16 1 5/16-12 1
-20 1 5/8-12 1
-24 1 7/8-12 1
SAE O-ring Boss Port
(tube fitting - installed into Aluminum)
(all types)
SAE Dash Size Torque
-4 14 ft-lbs / 19 Nm
-6 23 ft-lbs / 31.2 Nm
-8 36 ft-lbs / 54.2 Nm
-10 62 ft-lbs / 84 Nm
-12 84 ft-lbs / 114 Nm
-16 125 ft-lbs / 169.5 Nm
-20 151 ft-lbs / 204.7 Nm
-24 184 ft-lbs / 249.5 Nm
Adjustable Fitting Non-adjustable fitting
1 jam nut
SAE O-ring Boss Port
(tube fitting - installed into Steel)
SAE Dash Size Torque
-4 ORFS / 37° (Adj)
ORFS (Non-adj)
37° (Non-adj)
15 ft-lbs / 20.3 Nm
26 ft-lbs / 35.3 Nm
22 ft-lbs / 30 Nm
-6 ORFS (Adj / Non-adj)
37° (Adj / Non-adj)
35 ft-lbs / 47.5 Nm
29 ft-lbs / 39.3 Nm
-8 ORFS (Adj / Non-adj)
37° (Adj / Non-adj)
60 ft-lbs / 81.3 Nm
52 ft-lbs / 70.5 Nm
-10 ORFS (Adj / Non-adj)
37° (Adj / Non-adj)
100 ft-lbs / 135.6 Nm
85 ft-lbs / 115.3 Nm
-12 (All types) 135 ft-lbs / 183 Nm
-16 (All types) 200 ft-lbs / 271.2 Nm
-20 (All types) 250 ft-lbs / 339 Nm
-24 (All types) 305 ft-lbs / 413.5 Nm

Service and Repair Manual September 2015
Specifications
8 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
Torq ue Proc e d ur e
Torque Procedure
Seal-Lok™ fittings
1 Replace the O-ring. The O-ring must be
replaced anytime the seal has been broken.
The O-ring cannot be re-used if the fitting or
hose end has been tightened beyond finger
tight.
Note: The O-ring in Parker Seal Lok™ fittings and
hose end are custom-size O-rings. They are not
standard size O-rings. They are available in the
O-ring field service kit (Genie part number 49612).
2 Lubricate the O-ring before installation.
3 Be sure the O-ring face seal is seated and
retained properly.
4 Position the tube and nut squarely on the face
seal end of the fitting, and tighten the nut
finger tight.
5 Tighten the nut or fitting to the appropriate
torque. Refer to the appropriate torque chart
in this section.
6 Operate all machine functions and inspect the
hose, fittings and related components to
confirm there are no leaks.
JIC 37° fittings
1 Align the tube flare (hex nut) against the nose
of the fitting body (body hex fitting) and tighten
the hex nut to the body hex fitting to hand
tight, approximately 30 in-lbs / 3.4 Nm.
2 Using a permanent ink marker, make a
reference mark on one the flats of the hex nut
and continue the mark onto the body of the
hex fitting. Refer to Illustration 1.
Illustration 1
1 hex nut
2 reference mark
3 body hex fitting

September 2015 Service and Repair Manual
Specifications
Part No. 1268498 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N 9
3 Working clockwise on the body hex fitting,
make a second mark with a permanent ink
marker to indicate the proper tightening
position. Refer to Illustration 2.
Note: Use the JIC 37° Fitting table in this section to
determine the correct number of flats, for the
proper tightening position.
Note: The marks indicate the correct tightening
positions have been determined. Use the second
mark on the body hex fitting to properly tighten the
joint after it has been loosened.
Illustration 2
1 body hex fitting
2 reference mark
3 second mark
4 Tighten the hex nut until the mark on the hex
nut is aligned with the second mark on the
body hex fitting.
5 Operate all machine functions and inspect the
hose, fittings and related components to
confirm there are no leaks.

Service and Repair Manual September 2015
Specifications
10 Z-30/20N • Z-30/20N RJ • Z-34/22 • Z-34/22N Part No. 1268498
SAE and M etr i c F ast e ner s Tor qu e C h ar ts
