GeoVision FETIV212-A User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
User's Manual
GV-Fisheye IP Camera H.264
FETIV212-A

© 2014 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part,
without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind
and assumes no responsibility for errors or omissions. No liability is assumed
for incidental or consequential damages arising from the use of the information
or products contained herein. Features and specifications are subject to
change without notice.
Note:
1. GV-FE110 / FE420 / FE520 are excluded from Japan, EU and German
market.
2. No memory card slot or local storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows and Windows XP
are registered trademarks of Microsoft Corporation.
June 2014

Preface
Welcome to the GV-Fisheye IP Camera User’s Manual.
The GV-Fisheye IP Camera has the following models with different resolutions. This Manual
is designed for the following models and firmware versions:
Model Model Number Firmware Version
GV-FE110
GV-FE111 V1.08
GV-FE420
GV-FE421
GV-FE520
GV-FE521
GV-FE2301
GV-FE4301
V2.09
GV-FE2302/ 2303
GV-FE3402/ 3403
GV-FE4302/ 4303
Fisheye Camera
GV-FE5302/ 5303
V2.12
GV-FER3402 / 3403 V2.12
GV-FER521 V2.09
Fisheye Rugged Camera
GV-FER5302 / 5303 V2.12
Note: To upgrade the camera firmware from V2.07 or earlier to the latest version, back up
the files in the camera’s memory card first before the upgrade and it is required to re-format
the memory card after the upgrade.
i

Contents
Naming and Definition ...........................................................vii
Note for Connecting to GV-System .....................................viii
Note for Recording ................................................................iiix
Note for USB Storage and WiFi Adapter ................................x
Note for Installing Camera .....................................................xi
Chapter 1 Introduction ..........................................................1
1.1 Key Features ......................................................................................................... 2
1.2 Packing List ........................................................................................................... 5
1.3 System Requirement ............................................................................................10
1.4 Optional Accessories ............................................................................................12
1.5 Physical Description..............................................................................................13
GV-FE110 / 111 / 420 / 421 / 520 / 521 / 2301 / 4301 and GV-FER521 ...............13
GV-FE2302 / 2303 / 3402 / 3403 / 4302 / 4303 / 5302 / 5303...............................15
GV-FER3402 / 3403 / 5302 / 5303 .......................................................................16
1.6 Installation ............................................................................................................18
1.6.1 Hard Ceiling Mount ...................................................................................19
1.6.2 In-Ceiling Mount........................................................................................23
1.6.2 In-Ceiling Mount........................................................................................23
1.6.3 Standard Wall Mount and Ground Mount..................................................26
1.6.4 Ground Mount...........................................................................................26
1.7 Connecting the GV-Fisheye Camera ....................................................................27
1.7.1 GV-FE110 / 111 / 2301 / 420 / 421 / 4301 / 520 / 521...............................27
1.7.2 GV-FER521 ..............................................................................................29
1.7.3 GV-FE2302 / 2303 / 3402 / 3403 / 4302 / 4303 / 5302 / 5303 ...................30
1.7.4 Connecting PoE Converter and IR LED Ring for GV-FE2303 / 3403 / 4303 /
5303 .......................................................................................................31
1.7.5GV-FER3402 /3403 / 5302 / 5303............................................................33
Chapter 2 Getting Started ...................................................36
2.1 Installing on a Network..........................................................................................36
2.1.1 Checking the Dynamic IP Address............................................................37
ii

2.1.2 Assigning an IP Address...........................................................................39
2.1.2 Assigning an IP Address...........................................................................39
2.1.3 Configuring the Wireless Connection ........................................................41
2.2 Configuration the Basics .......................................................................................44
Chapter 3 Accessing the Camera.......................................45
3.1 Accessing Your Surveillance Images ....................................................................45
3.2 Functions Featured on the Main Page ..................................................................46
3.2.1 The Live View Window ............................................................................47
3.2.2 Fisheye View ............................................................................................49
3.2.3 The Control Panel of the Live View Window .............................................53
3.2.4 Snapshot of a Live Video ..........................................................................57
3.2.5 Video Recording .......................................................................................57
3.2.6 Wide Angle Lens Dewarping.....................................................................58
3.2.7 Picture-in-Picture and Picture-and-Picture View........................................59
3.2.8 Object Tracking.........................................................................................61
3.2.9 Alarm Notification......................................................................................63
3.2.10 Video and Audio Configuration ...............................................................65
3.2.11 Remote Configuration.............................................................................67
3.2.12 Camera Name Display............................................................................67
3.2.13 Image Enhancement...............................................................................67
3.2.14 I/O Control ..............................................................................................68
3.2.15 Visual Automation...................................................................................69
3.2.16 Network Status .......................................................................................70
Chapter 4 Administrator Mode ...........................................71
4.1 Video & Motion .....................................................................................................73
4.1.1 Video Settings ..........................................................................................73
4.1.2 Motion Detection.......................................................................................79
4.1.3 Privacy Mask ............................................................................................81
4.1.4 Text Overlay .............................................................................................82
4.1.5 Tampering Alarm ......................................................................................83
4.1.6 Visual Automation.....................................................................................85
4.2 I/O Control ............................................................................................................86
4.2.1 Input Settings............................................................................................86
4.2.2 Output Settings.........................................................................................87
iii

4.3 Events & Alerts .....................................................................................................88
4.3.1 E-mail .......................................................................................................88
4.3.2 FTP...........................................................................................................90
4.3.3 Center V2 .................................................................................................92
4.3.4 VSM..........................................................................................................94
4.3.5 Backup Center..........................................................................................96
4.3.6 Video Gateway / Recording Server...........................................................98
4.3.7 ViewLog Server ......................................................................................100
4.3.8 RTSP......................................................................................................101
4.4 Monitoring...........................................................................................................102
4.5 Recording Schedule............................................................................................103
4.5.1 Recording Schedule Settings..................................................................103
4.5.2 I/O Monitoring Settings ...........................................................................104
4.6 Remote ViewLog ................................................................................................105
4.7 Network ..............................................................................................................106
4.7.1 LAN ........................................................................................................106
4.7.2 Wireless Client Mode..............................................................................108
4.7.3 Advanced TCP/IP ...................................................................................110
4.7.4 IP Filtering ..............................................................................................114
4.7.5 SNMP Setting .........................................................................................115
4.8 Management.......................................................................................................116
4.8.1 Date and Time Settings ..........................................................................116
4.8.2 GPS Maps Settings ................................................................................118
4.8.3 Storage Settings .....................................................................................120
4.8.4 User Account ..........................................................................................123
4.8.5 Log Information.......................................................................................124
4.8.6 System Log.............................................................................................126
4.8.7 Tools.......................................................................................................128
4.8.8 Language................................................................................................130
Chapter 5 Recording and Playback .................................131
5.1 Recording ...........................................................................................................131
5.2 Playback .............................................................................................................132
5.2.1 Playback from the Memory Card.............................................................132
5.2.2 Playback over Network ...........................................................................137
5.2.3 Access to the Recorded Files through FTP Server .................................138
5.2.4 Playback of Daylight Saving Time Events...............................................139
iv

Chapter 6 Advanced Applications ...................................140
6.1 Upgrading System Firmware...............................................................................140
6.1.1 Using the Web Interface .........................................................................142
6.1.2 Using the IP Device Utility.......................................................................143
6.2 Backing Up and Restoring Settings.....................................................................145
6.2.1 Backing Up the Settings..........................................................................145
6.2.2 Restoring the Settings.............................................................................146
6.3 Restoring to Factory Default Settings..................................................................147
6.3.1 Using the Web Interface .........................................................................147
6.3.2 Directly on the Camera ...........................................................................147
6.4 Verifying Watermark ...........................................................................................150
6.4.1 Accessing AVI Files ................................................................................150
6.4.2 Running Watermark Proof ......................................................................150
6.4.3 The Watermark Proof Window ................................................................151
6.5 Downloading Videos from the Micro SD Card .....................................................152
6.5.1 Installing the GV-SDCardSync Utility ......................................................152
6.5.2 The GV-SDCardSync Utility Window ......................................................155
Chapter 7 DVR Configurations .........................................156
7.1 Setting Up IP Cameras .......................................................................................159
7.1.1 Customizing the Basic Settings...............................................................162
7.2 Remote Monitoring with Multi View .....................................................................163
7.2.1 Connecting to the IP Camera..................................................................163
7.3 Remote Monitoring with E-Map...........................................................................164
7.3.1 Creating an E-Map for the IP Camera.....................................................164
7.3.2 Connecting to the IP Camera..................................................................165
Chapter 8 CMS Configurations.........................................166
8.1 Center V2 ...........................................................................................................166
8.2 VSM....................................................................................................................169
8.3 Dispatch Server ..................................................................................................170
v

vi
Appendix…............................................................................171
A. Settings for Internet Explore 8 or later.....................................................................171
B. RTSP Protocol Support...........................................................................................172
C. The CGI Command.................................................................................................173
D. Supported Firmware for Flash Memory...................................................................174
Specifications .......................................................................175

Naming and Definition
GV-System GeoVision Analog and Digital Video Recording Software. The GV-
System also refers to Multicam System, GV-NVR System, GV-
Hybrid DVR System and GV-DVR System at the same time.
vi

Note for Connecting to GV-System
The GV-Fisheye IP Camera is designed to work with GV-System, a hybrid or digital video
management system. Note the following when the camera is connected to GV-System:
1. By default, the images are recorded to the memory card inserted in the GV-Fisheye IP
Camera.
2. Once the camera is connected to the GV-System, the resolution set on the GV-System
will override the resolution set on the camera’s Web interface. You can only change the
resolution settings through the Web interface when the connection to the GV-System is
interrupted.
vii

Note for Recording
1. By default, the images are recorded to the memory card inserted in the GV-Fisheye IP
Camera. Make sure the Write recording data into local storage option (see 4.1.1 Video
Settings) is enabled. If this option is disabled, the camera will stop recording to the
memory card while the live view is accessed through Web browsers or other applications.
2. Mind the following when using a memory card for recording:
Recorded data on the memory card can be damaged or lost if the data are accessed
while the camera is under physical shock, power interruption, memory card
detachment or when the memory card reaches the end of its lifespan. No guarantee
is provided for such causes.
To avoid power outage, it is highly suggested to apply a battery backup (UPS).
For better performance, it is highly suggested to use Micro SD card of MLC NAND
flash, Class 10.
Replace the memory card when its read/write speed is lower than 6 MB/s or when the
memory card is frequently undetected by the camera.
viii

Note for USB Storage and WiFi Adapter
Mind the following limitations and requirements for using USB storage and GV-WiFi Adapter:
1. The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above.
2. The USB hard drive’s storage capacity must not exceed 2TB.
3. USB flash drives and USB hubs are not supported.
4. External power supply is required for the USB hard drive.
5. To connect a GV-WiFi Adapter, make sure it is connected before the camera is powered
on.
ix

Note for Installing Camera
When installing GV-FER outdoor models, be sure that:
1. The camera is set up above the junction box to prevent water from entering the camera
along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber
or the like.
3. The screws are tightened and the cover is in place after opening the camera cover.
x

xi
4. The silica gel bag loses it effectiveness when the dry camera is opened. To prevent the
lens from fogging up, use the supplied adhesive tap and replace the silica gel bag every
time you open the camera, and conceal the gel bag in camera within 2 minutes of
exposing to open air.
5. For each newly replaced silica gel bag, allow it to absorb moisture for at least 5 hours
before operating the camera.
When installing GV-FE indoor models, be sure that:
Keep the indoor camera shielded from rain and moisture.
When installing GV-FE or GV-FER models with IR LED rings, be sure that:
An operating IR LED ring may reach high temperatures of up to 60°C (140°F).
Disconnect the power supply and allow the IR LED ring to cool down before handling
the device.
IR LED Ring

Introduction
1
Chapter 1 Introduction
The fisheye camera allows you to monitor all angles of a location using just one camera. It
can be installed to the ceiling, wall, wall corner and pole. The distorted hemispherical image
of the fisheye camera will be converted into the conventional rectilinear projection.
Without installing any software, you can watch live view and utilize functions such as motion
detection, privacy mask, and alert notification through the Web interface. In addition, the GV-
Fisheye IP Camera seamlessly integrates with the GV-System, providing advanced
monitoring and video management features.
The following GV-Fisheye Cameras are available:
Models Type Description
GV-FE110 / 111 / 2301 / 420 /
421 / 4301 / 520 / 521 1.3 MP / 2 MP / 4 MP / 5 MP
GV-FE2302 / 3402 / 4302 / 5302 2 MP / 3 MP WDR Pro / 4 MP / 5 MP
GV-FE2303 / 3403 / 4303 / 5303
Indoor
2 MP / 3 MP WDR Pro / 4 MP / 5 MP, IR
LED ring
GV-FER521 5 MP, IP66, IK10 for metal casing
GV-FER3402 / 5302 3 MP WDR Pro / 5 MP, IP67, IK10+ for
metal casing
GV-FER3403 / 5303
Outdoor
3 MP WDR Pro / 5 MP, IR LED ring, IP67,
IK10+ for metal casing
1

1.1 Key Features
Image sensor
Camera Model Image Sensor
GV-FE110 / 111 1/3’’ progressive scan CMOS
GV-FE2301 / 2302 / 2303
GV-FE420 / 421
GV-FE4301 / 4302 / 4303
GV-FE520 / 521
GV-FE5302 / 5303
GV-FER521 / 5302 / 5303
1/2.5’’ progressive scan CMOS
GV-FE3402 / 3403
GV-FER3402 / 3403 1/3.2’’ progressive scan CMOS
Video Compression
Camera Model Video Compression
GV-FE110 / 111 H.264, MPEG4, MJPEG
GV-FE2301 / 2302 / 2303
GV-FE3402 / 3403
GV-FE420 / 421
GV-FE4301 / 4302 / 4303
GV-FE520 / 521
GV-FER3402 / 3403
GV-FER521
GV-FER5302 / 5303
H.264, MJPEG
2

Introduction
1
Frame
rate
Camera Model Frame Rate
GV-FE110 / 111 Up to 15 fps at 1280 x 1024
GV-FE2301 / 2302 / 2303 Up to 15 fps at 1440 x1376
GV-FE3402 / 3403
GV-FER3402 / 3403 Up to 15 fps at 2048 x 1536
GV-FE420 / 421
GV-FE4301 / 4302 / 4303 Up to 15 fps at 2048 x 1944
GV-FE520 / 521
GV-FE5302 / 5303
GV-FER521 / 5302 / 5303
Up to 10 fps at 2560 x 1920
Day and night function
Camera Model Day / Night function
GV-FE110 / 111 N/A
GV-FE2301
GV-FE420 / 421
GV-FE4301
GV-FE520 / 521
GV-FER521
Electronic
GV-FE2302 / 2303
GV-FE3402 / 3403
GV-FE4302 / 4303
GV-FE5302 / 5303
GV-FER3402 / 3403
GV-FER5302 / 5303
Removable IR-cut filter
IR LED with effective distance up to 10 m / 32.81 ft (GV-FE2303 / 3403 / 4303 / 5303 and
GV-FER3403 / 5303)
Wide Dynamic Range (WDR for GV-FE2302 / 2303 / 4302 / 4303 / 5302 / 5303 and GV-
FER5302 / 5303)
Wide Dynamic Range Pro (WDR Pro for GV-FE3402 / 3403 and GV-FER3402 / 3403)
Defog
IP66 rating (GV-FER521 only)
IP67 rating (GV-FER3402 / 3403 / 5302 / 5303 only)
3

IK10 rating for metal casing (GV-FER521 only)
IK10+ for metal casing (GV-FE2302 / 2303 / 3402 / 3403 / 4302 / 4303 / 5302 / 5303 and
GV-FER3402 / 3403 / 5302 / 5303 only)
EN50155 compliance for rolling stock applications (GV-FER521 only)
Built-in micro SD card slot (SD/SDHC) for local storage
Built-in microphone and speaker
Mini USB slot for WiFi adapter or USB hard drive (GV-FE2302 / 2303 / 3402 / 3403 / 4302
/ 4303 / 5302 / 5303 only)
One sensor input and alarm output (GV-FE110 / 111 / 2301 / 420 / 420 / 4301 / 520 / 521
only)
Virtual PTZ function
Auto Pan function
Object tracking
Provides 360° and 180° panorama view
No mechanical moving parts
Different angle of view controllable by multiple users at the same time
Playback from any view angle and zoom level
Privacy mask
Visual automation
Tampering alarm
Text overlay
31 languages on Web interface
ONVIF (Profile S) conformant
4

Introduction
1
1.2 Packing List
GV-FE110 / 111 / 420 / 421 / 520 / 521 / 2301 / 4301 and GV-FER521
Fisheye Camera
Support Bracket x 3
Camera Cover (Hard Ceiling Mount)
Camera Cover (In-Ceiling Mount)
Screw (Hard Ceiling Mount) x 3
Screw (In-Ceiling Mount) x 3
Torx Wrench
Plastic Screw Anchor x 3
Installation Sticker
GV-Fisheye IP Camera Software DVD
GV-NVR Software DVD
GV-NVR Quick Start Guide
For GV-FE110 / 111 / 420 / 421 / 520 / 521 / 2301 / 4301 only:
- 3-Pin or 2-Pin Terminal Block
- DC 12V Power Adapter
For GV-FER521 only:
- Cable Connector
- Silica Gel Bag and Adhesive Tape x 2
5

GV-FE2302 / 3402 / 4302 / 5302 and GV-FE2303 / 3403 / 4303 / 5303
Fisheye Camera
Support Bracket x 3
Camera Cover (Hard Ceiling Mount)
Camera Cover (In-Ceiling Mount)
Screw (Hard Ceiling Mount) x 3
Screw (In-Ceiling Mount) x 3
Torx Wrench
Plastic Screw Anchor x 3
Mini USB Extension Cable
IR LED Ring (GV-FE2303 / 3403 /
4303 / 5303 only)
6
