GeoVision GV-VD120D User manual

Quick Start Guide
GV-IPCamera
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Vandal Proof IP Dome
Target Vandal Proof IP Dome
ICH265HISIV108-B

© 2017 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note: no memory card slot or local
storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows is the
registered trademark of Microsoft Corporation.
September 2017

Content
Content ................................................................................i
Caution............................................................................... v
Safety Notice ..................................................................... v
Options ............................................................................. vi
Note for Adjusting Focus and Zoom............................ viii
Note for Installing Camera Outdoor................................ix
Note for Silica Gel Bags...................................................xi
Chapter 1 Vandal Proof IP Dome (Part I)........................1
1.1 Packing List..............................................................................3
1.2 Overview ..................................................................................4
1.3 Installation................................................................................6
1.3.1 Hard-Ceiling Mount......................................................7
1.3.2 In-Ceiling Mount.........................................................12
1.4 Connecting the Camera..........................................................15
1.4.1 Wire Definition ...........................................................15
1.4.2 Power Connection......................................................17
1.4.3 Voltage Load Expansion (Optional)............................18
1.5 Loading Factory Default..........................................................19
1.5.1 Using the Web Interface.............................................19
1.5.2 Directly on the Camera ..............................................20
i

Chapter 2 Vandal Proof IP Dome (Part II).....................21
2.1 Packing List............................................................................24
2.2 Overview ................................................................................27
2.3 Installation..............................................................................29
2.3.1 Installation of Weatherproof Shield.............................39
2.4 Connecting the Camera..........................................................41
2.4.1 Power Connection......................................................41
2.4.2 I/O Device Connections .............................................41
2.4.3 Voltage Load Expansion (Optional)............................42
2.5 Loading Factory Default..........................................................43
2.5.1 Using the Web Interface.............................................43
2.5.2 Directly on the Camera ..............................................43
Chapter 3 Vandal Proof IP Dome (Part III)....................44
3.1 Packing List............................................................................45
3.2 Overview ................................................................................47
3.3 Installation..............................................................................49
3.4 Connecting the Camera..........................................................55
3.4.1 Definition....................................................................55
3.4.2 Power Connection......................................................56
3.4.3 Voltage Load Expansion (Optional)............................57
3.5 Loading Factory Default..........................................................58
3.5.1 Using the Web Interface.............................................58
ii

3.5.2 Directly on the Camera ..............................................58
Chapter 4 Vandal Proof IP Dome (Part IV)....................59
4.1 Packing List............................................................................61
4.2 Overview ................................................................................64
4.3 Installation..............................................................................68
4.4 Connecting the Camera...........................................................79
4.5 I/O Connector.........................................................................80
4.5.1 Voltage Load Expansion (Optional)............................80
4.6 Loading Factory Default..........................................................81
4.6.1 Using the Web Interface.............................................81
4.6.2 Directly on the Camera ..............................................81
Chapter 5 Target Vandal Proof IP Dome.......................82
5.1 Packing List............................................................................83
5.2 Overview ................................................................................86
5.3 Installation..............................................................................88
5.4 Connecting the Camera..........................................................99
5.5 Loading Factory Default........................................................100
5.5.1 Using the Web Interface...........................................100
5.5.2 Directly on the Camera ............................................100
Chapter 6 Accessing the Camera................................101
6.1 System Requirement............................................................101
6.2 Accessing the Live View.......................................................102
iii

6.2.1 Checking the Dynamic IP Address...........................103
6.2.2 Configuring the IP Address ......................................105
6.3 Adjusting Image Clarity.........................................................107
6.3.1 Using Focus Adjustment Cap...................................110
Chapter 7 The Web Interface .......................................112
Chapter 8 Upgrading System Firmware .....................115
iv

Caution
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Safety Notice
The GV-IPCAM uses a Lithium battery as the power supply for its internal
real-time clock (RTC). The battery should not be replaced unless required!
If the battery does need replacing, please observe the following:
Danger of Explosion if battery is incorrectly replaced
Replace only with the same or equivalent battery, as recommended by
the manufacturer
Dispose of used batteries according to the manufacturer's instructions
v

Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Device Description
Power Adapter The power adapter is available for all Vandal Proof
IP Dome. Contact your sales representative for the
countries and areas supported.
GV-PA191 PoE
Adapter
The GV-PA191 PoE adapter is designed to provide
power and network connection to the cameras over
a single Ethernet cable.
GV-POE Switch
The GV-POE Switch is designed to provide power
along with network connection for IP devices. The
GV-POE Switch is available in various models with
different numbers and types of ports.
GV-Mount
Accessories
The GV-Mount Accessories provide a
comprehensive lineup of accessories for installation
on ceiling, wall corner and pole. For details, see GV-
Mount Accessories Installation Guide on the
Software DVD.
vi

Device Description
GV-Relay V2
The GV-Relay V2 is designed to expand the voltage
load of GV IP devices. It provides 4 relay outputs,
and each can be set as normally open (NO) or
normally closed (NC) independently as per your
requirement.
GV-Relay V2 does not support GV-EVD2100 / 3100
/ 5100.
Metal PG21
Conduit
Connector
The metal PG21 conduit connector is used for
running the wires of GV-VD1530 / 2430 / 2530 /
3430, GV-VD1540 / 2440 / 2540 / 3440 / 4711 /
5340 / 5711, GV-VD2540-E / 5340-E, GV-VD2702 /
2712 / 4702, and GV-EVD2100 / 3100 / 5100
through a 3/4” conduit pipe.
Weatherproof
Shield
The weatherproof shield is made for GV-VD1530 /
2430 / 2530 / 3430, GV-VD1540 / 2440 / 2540 /
3440 / 4711 / 5340 / 5711, and GV-VD2540-E /
5340-E to protect the camera from rain and snow.
vii

Note for Adjusting Focus and Zoom
When adjusting the Focus and Zoom Screws, do not over tighten the
Focus and Zoom screws. The screws only need to be as tight as your
finger can do it. It is not necessary to use any tools to get them tighter.
Doing so can damage the structure of lens.
The maximum torque value for all the zoom and focus screws is 0.049 N.m
viii

Note for Installing Camera Outdoor
When installing the camera outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from
entering the camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using
waterproof silicon rubber or the like.
ix

3. After opening the camera cover, ensure the screws are tightened
and the cover is in place.
4. Make sure the housing cover is properly secured to prevent water
from entering and damaging the inner housing.
x

xi
Note for Silica Gel Bags
1. The silica gel bag loses it effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel
bag every time you open the camera, and conceal the gel bag in
camera within 2 minutes of exposing to open air.
2. When the camera is shipped, a silica gel bag will be included inside
the camera. For the first-time user, replace the silica gel bag prior to
the installation to avoid foggy live view.

Vandal Proof IP Dome (Part I)
1
Chapter 1 Vandal Proof IP Dome
(Part I)
The Vandal Proof IP Dome is a series of outdoor camera designed for
vandal protection. They are equipped with automatic infrared cut filters and
IR LED for day and night surveillance. The WDR Pro models can produce
clear image for scenes containing contrasting intensity of lights. The super
low lux models can display color live view in near darkness.
These Vandal Proof IP Domes can be installed on wall and ceiling using
the standard package. They can also be installed on wall corners and
poles using the GV-Mount accessories (optional). For more details, see
GV-Mount Accessories Installation Guide on the Software DVD.
Model No. Specification Description
GV-VD120D
(IK10+, Transparent Cover)
GV-VD121D
(IK10+, Smoked Cover)
GV-VD122D
(IK7, Transparent Cover)
GV-VD123D
(IK7, Smoked Cover)
Varifocal
Lens
Auto Iris, f:3 ~ 9
mm, F/1.3, 1/2.7”
ø 14 mm lens
mount
1.3 MP Low
Lux, H.264
1

Vandal Proof IP Dome (Part I)
1
Model No. Specification Description
GV-VD220D
(IK10+, Transparent Cover)
GV-VD221D
(IK10+, Smoked Cover)
GV-VD222D
(IK7, Transparent Cover)
GV-VD223D
(IK7, Smoked Cover)
2 MP, H.264
GV-VD320D
(IK10+, Transparent Cover)
GV-VD321D
(IK10+, Smoked Cover)
GV-VD322D
(IK7, Transparent Cover)
GV-VD323D
(IK7, Smoked Cover)
Varifocal
Lens
Auto Iris, f:3 ~ 9
mm, F/1.3, 1/2.7”
ø 14 mm lens
mount
3 MP, H.264
GV-VD1500
(IK10+, Transparent Cover)
GV-VD2500
(IK10+, Transparent Cover)
1.3 MP / 2 MP
Super Low Lux
GV-VD2400
(IK10+, Transparent Cover)
GV-VD3400
(IK10+, Transparent Cover)
Varifocal
Lens
Auto Iris, f:3 ~ 9
mm, F/1.2, 1/2.7”
ø 14 mm lens
mount 2 MP / 3 MP,
H.264, WDR
Pro
2

Vandal Proof IP Dome (Part I)
1
1.1 Packing List
Vandal Proof IP Dome Silica Gel Bag x 2
Screw Anchor x 4
Torx Wrench
Ceiling Screw x 4
Blue Screw x 3
T-Cap Screw x 3
Small Screw Cap x 3
T-Cap x 3
Plastic Clip x 3
Focus Adjustment Cap
2-Pin Terminal Block
Power Adapter
GV-Software DVD GV-IPCAM Software DVD
Warranty Card
Note:
1. Focus Adjustment Cap is only needed and supplied for IK10+
models.
2. The power adapter can be excluded upon request.
3

Vandal Proof IP Dome (Part I)
1
1.2 Overview
1234 5
6 7 8 9 7
10 11
Figure 1-1
No. Name Description
1 Power LED Turns on (green) when the power is on and
turns off when there is no power supply.
2 Status LED Turns on (green) when the system operates
normally and turns off when system error
occurs.
3 Default Button Resets the camera to factory default. For
details, see 1.5 Loading Factory Default.
4 Memory Card
Slot Inserts a micro SD card (SD/SDHC, version 2.0 only, Class 10) to store recording data.
5 Thread Lock Locks the housing cover to the camera body
to prevent the cover from falling.
6 Pan Disc Loosens to pan the camera.
7 Tilt Screw Loosen the screw to tilt the camera.
4

Vandal Proof IP Dome (Part I)
1
No. Name Description
8 Rotational Screw Loosens to adjust the camera angle.
9 Zoom Screw Adjusts the zoom of the camera.
10 Focus Screw Adjusts the focus of the camera.
11 Silica Gel Bag Absorbs moisture in the camera body.
5

Vandal Proof IP Dome (Part I)
1
1.3 Installation
The Vandal Proof IP Dome is designed for outdoors. With the standard
package, there are two ways to install the Vandal Proof IP Dome: hard-
ceiling mount and in-ceiling mount.
Note: You can also install the camera:
on a power box (of the 4" square and double gang type) using the
standard package
to ceilings, wall corners (concave or convex), and poles using
optional mounting kits
For details on these installations, see GV-Mount Accessories Installation
Guide on the Software DVD.
6

Vandal Proof IP Dome (Part I)
1
1.3.1 Hard-Ceiling Mount
Figure 1-2
1. Unpack the camera package and take out the camera body.
Unscrew the
housing cover
Unscrew thread
lock
7
