GeoVision GV-IPCamera Series User manual

Quick Start Guide
GV-IPCamera
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Vandal Proof IP Dome
Target Vandal Proof IP Dome
ICH265-A

© 2019 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note: no memory card slot or local
storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
0Uhttp://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows is the
registered trademark of Microsoft Corporation.
November 2019

i
Contents
Caution.............................................................................. iv
Safety Notice .................................................................... iv
Options .............................................................................. v
Creating GV-IP Camera’s Login Credentials................. vi
Note for Adjusting Focus and Zoom............................. vii
Note for Installing Camera Outdoor............................. viii
Note for Silica Gel Bags ....................................................x
Note for TV-out Function...................................................x
Note for Avoiding IR Reflection.......................................xi
Chapter 1 GV-VD4711 / 5711............................................1
1.1 Packing List ..............................................................................2
1.2 Overview ..................................................................................5
1.3 Installation ................................................................................7
1.3.1 Installation of Weatherproof Shield.............................17
1.4 Connecting the Camera..........................................................18
1.4.1 Power Connection......................................................18
1.4.2 I/O Device Connections .............................................18
1.4.3 Voltage Load Expansion (Optional)............................19

ii
1.5 Loading Factory Default..........................................................20
1.5.1 Using the Web Interface.............................................20
1.5.2 Directly on the Camera ..............................................21
Chapter 2 GV-VD2702 / 2712 / 4702 / 4712....................22
2.1 Packing List ............................................................................24
2.2 Overview ................................................................................26
2.3 Installation ..............................................................................29
2.4 Connecting the Camera..........................................................39
2.5 I/O Connector .........................................................................40
2.5.1 Voltage Load Expansion (Optional)............................40
2.6 Loading Factory Default..........................................................41
2.6.1 Using the Web Interface.............................................41
2.6.2 Directly on the Camera ..............................................41
Chapter 3 GV-EVD2100 / 3100 / 5100 ............................42
3.1 Packing List ............................................................................43
3.2 Overview ................................................................................45
3.3 Installation ..............................................................................47
3.4 Connecting the Camera..........................................................57
3.5 Loading Factory Default..........................................................58
3.5.1 Using the Web Interface.............................................58
3.5.2 Directly on the Camera ..............................................58

iii
Chapter 4 Accessing the Camera..................................59
4.1 System Requirement ..............................................................59
4.2 Accessing the Live View .........................................................59
4.2.1 Checking the Dynamic IP Address .............................60
4.2.2 Configuring the IP Address ........................................61
4.3 Adjusting Image Clarity...........................................................63
4.3.1 Using Focus Adjustment Cap.....................................65
Chapter 5 The Web Interface .........................................66
Chapter 6 Upgrading System Firmware .......................69

iv
Caution
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Safety Notice
The GV-IPCAM uses a Lithium battery as the power supply for its internal
real-time clock (RTC). The battery should not be replaced unless required!
If the battery does need replacing, please observe the following:
Danger of Explosion if battery is incorrectly replaced
Replace only with the same or equivalent battery, as recommended by
the manufacturer
Dispose of used batteries according to the manufacturer's instructions

v
Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Device Description
Power Adapter
The power adapter is available for all Vandal Proof
IP Dome. Contact our sales representatives for the
countries and areas supported.
GV-PA191 PoE
Adapter
The GV-PA191 PoE adapter is designed to provide
power and network connection to the cameras over
a single Ethernet cable.
GV-POE Switch
The GV-POE Switch is designed to provide power
along with network connection for IP devices. The
GV-POE Switch is available in various models with
different numbers and types of ports.
GV-Mount
Accessories
The GV-Mount Accessories provide a
comprehensive lineup of accessories for installation
on ceiling, wall corner and pole. For details, see GV-
Mount Accessories Installation Guide.
GV-Relay V2
The GV-Relay V2 is designed to expand the voltage
load of GV IP devices. It provides 4 relay outputs,
and each can be set as normally open (NO) or
normally closed (NC) independently as per your
requirement.
Metal PG21
Conduit
Connector
The metal PG21 conduit connector is used for
running the wires of GV-VD4711 / 5711, GV-VD2702
/ 2712 / 4702 / 4712, and GV-EVD2100 / 3100 /
5100 through a 3/4” conduit pipe.
Weatherproof
Shield
The weatherproof shield is made for GV-VD4711 /
5711 to protect the camera from rain and snow.

vi
Creating GV-IP Camera’s Login
Credentials
The default Administrator and Guest accounts are no longer supported by
GV-IPCam H.265 series firmware V1.14 or later. When purchasing a new
camera or after resetting it, you need to set up a login username and
password for the camera.
1. Download and install GV-IP Device Utility from our website.
2. On the GV-IP Device Utility window, click to search for your GV-
IP camera.
3. Double-click your GV-IP camera in the GV-IP Device Utility list. This
dialog box appears.
4. Click the Change Username and Password tab to type a new
username and password. Note that the new password must meet
the password strength requirements.
5. Optionally click Upgrade all devices to use the same username
and password on all other devices.

vii
Note for Adjusting Focus and
Zoom
When adjusting the Focus and Zoom Screws, do not over tighten the
Focus and Zoom screws. The screws only need to be as tight as your
finger can do it. It is not necessary to use any tools to get them tighter.
Doing so can damage the structure of lens.
The maximum torque value for all the zoom and focus screws is 0.049 N.m

viii
Note for Installing Camera
Outdoor
When installing the camera outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from
entering the camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using
waterproof silicon rubber or the like.

ix
3. After opening the camera cover, ensure the screws are tightened
and the cover is in place.
4. Make sure the housing cover is properly secured to prevent water
from entering and damaging the inner housing.

x
Note for Silica Gel Bags
1. The silica gel bag loses it effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel
bag every time you open the camera, and conceal the gel bag in
camera within 2 minutes of exposing to open air.
2. When the camera is shipped, a silica gel bag will be included inside
the camera. For the first-time user, replace the silica gel bag prior to
the installation to avoid foggy live view.
Note for TV-out Function
Some cameras have a TV-out connector. The TV-out function can only be
used during installation to adjust the focus of the camera. To use the TV
out function, connect the supplied black BNC wire to a monitor and select
your signal format (NTSC or PAL) at the TV Out field on the Web interface.
The default signal format is NTSC. For details, see 4.1.1 Video Settings,
GV-IPCam Firmware Manual. The TV-out wire must be removed before
you secure the housing cover.

xi
Note for Avoiding IR Reflection
For GV-VD4711 / 5711, to avoid IR reflection and improve camera night
view, take precautions for installing the camera on the wall and ceiling. The
minimum distances between the camera body and walls, any objects or
light sources are:
25 cm (0.82 ft) to the sides;
200 cm (6.56 ft) right below the IR LED (when installing on the
wall), or the rear of the IR LED (when installing on the ceiling).

1
Chapter 1 GV-VD4711 / 5711
These Vandal Proof IP Domes are outdoor cameras designed with IK10+
vandal resistance and IP67 ingress protection. They provide superior night
vision with their high power LEDs and allow up to 20 m (65.6 ft), 25 m (82
ft), 30 m (98.4 ft) effective IR distance. The super low lux models are able
to display color live view in dear darkness. The WDR Pro models can
process scenes with contrasting intensity of lights. The motorized
varifocal models support remote focus and zoom adjustment. The arctic
models can withstand extreme temperatures.
These Vandal Proof IP Domes can be installed on the ceiling using the
standard package. They can also be installed on wall surfaces, wall
corners and poles using the GV-Mount accessories (optional). For more
details, see GV-Mount Accessories Installation Guide.
Model No. Specification Description
GV-VD4711
Motorized
varifocal lens,
high power IR
LEDs
Auto Iris,
f: 2.8 ~ 12 mm,
F/1.7, 1/2.7”
ø 14 mm lens
mount
4 MP Super Low
Lux, WDR Pro,
H.265
GV-VD5711
Motorized
varifocal lens,
high power IR
LEDs
Auto Iris,
f: 4 ~ 8 mm,
F/1.65, 1/1.8”
ø 14 mm lens
mount
5 MP. Low Lux,
WDR, H.265

2
1.1 Packing List
Vandal Proof IP Dome Torx Wrench
Power Adapter (excluding
GV-VD4711 / 5711)
Back Plate
RJ-45 Connector x 2
Installation sticker
1
1
1
Ceiling mount template

3
Long Screw x 4
Screw Anchor x 4
Short Screw x 2 Flat Screw
Conduit Converter
Plastic PG21 conduit
connector
Sticker (for Silica Gel Bag) Ruler
Silica Gel Bag
Download Guide
Warranty Card
Note: The power adapter can be excluded upon request.

4
Note: You can choose to run the wires through a conduit pipe. After you
have threaded all the wires, install the supplied conduit converter and
plastic PG21 conduit connector with a self-prepared 1/2’’ conduit pipe
to the camera. Power will have to be supplied through a PoE adapter,
because the power adapter wire does not fit in a 1/2” pipe. You will have
to purchase your own PG21 conduit connector if you want to use 3/4” or
1” pipe.
Conduit pipe
Conduit converter
Plastic PG21
conduit connector
A metal PG21 conduit connector can be purchased upon request,
which can be connected with a 3/4” pipe.

5
1.2 Overview
1
2
3
4 5
6
8
7
9
10
12
11
13
14

6
No. Name Description
1 LED Indicators
The power LED (top) turns on (green) when
the power is on and turns off when there is
no power supply. The status LED (bottom)
turns on (green) when the system operates
normally and turns off when system error
occurs.
2 Audio In Connects to a microphone for audio output.
3 LAN / PoE Connects to a 10/100 Ethernet or PoE.
4 Default Button Resets the camera to factory default. For
details, see 1.5 Loading Factory Default.
5 Video Out
Connects to a portable monitor for setting
the focus and angle of the camera during
initial setup.
6 Memory Card Slot Inserts a micro SD card (SD/SDHC, version
2.0 only, Class 10) to store recording data.
7 Audio Out Connects to a speaker for audio output.
8 DC 12V / AC 24V Connects to power.
9 I/O Terminal Block Connects to an I/O device.
10 Rotational Screw Loosens to rotate the camera.
11 Cable Gland Waterproofs the Ethernet cable.
12 Tilt Screw Loosen the screw to tilt the camera.
13 Conduit Connector
Waterproofs the audio, TV out, power
adapter and I/O wires.
14 Silica Gel Bag Absorbs moisture in the camera body.

7
1.3 Installation
The Vandal Proof IP Dome is designed for outdoors. With the standard
package, you can install the camera on the ceiling.
Note: You can also install the camera:
on a power box (of the 4" square and double gang type) using the
standard package
to ceilings, wall corners (concave or convex), and poles using
optional mounting kits
For details on these installations, see GV-Mount Accessories Installation
Guide.
IMPORTANT: When installing the Vandal Proof IP Dome near the
corner, maintain at least 25 cm away from the walls to avoid reflection
problems.
1. Remove the housing cover with the supplied torx wrench.
2. Thread wires into the camera.
A. Unscrew the conduit connector from the back.
