Gigaset A160 User manual

1
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Gigaset A160/A260/A165/A265
Base station with answering
machine at a glance
1 Registration/Paging key:
Page handsets (press briefly, "Paging", page 7).
Register handsets (press and hold, page 7).
2 On/Off key: activate and deactivate answering
machine.
Lights up: answering machine is activated.
Flashes: there is at least one new message or
message is in the process of being recorded.
Flickers for about four seconds: memory is full.
2V
11.12. 11:56
INT MENU
1 Charge status of the
battery pack
2 Internal number
of the handset
3Displaykeys
4Messagekey
5Directorykey
6 Control key
7 Talk key
8 End call and
On/Off key
9 Ringtone on/off (press
and hold in idle status)
10 Key lock on/off
(press and hold)
11 Recall key
- Confer (flash)
- Dialling pause
(press and hold)
12 Microphone
13 Alarm clock key
14 Handsfree key
(only Gigaset A260/A265)
Base station without answering
machine
Display keys:
Pressing the keys launches whichever function
that appears above them in the display.
Display
icon
Function when pressed
INT Call all registered handsets.
MENU Open main/submenu
(see Menu tree, page 11).
“ Go back one menu level.
UScroll up/down or adjust volume
with u.
T Move cursor to left/right with u.
˜Backspace deletes one character at
a time.
OK Confirm menu function or save
entry.
Registration/Paging key
(page 7/page 7)
10
2
3
5
7
4
6
8
9
12
1
Handset for A160/A165
5
14
Handset for A260/A265
11
13
Issued by
Gigaset Communications GmbH
Schlavenhorst 66, D-46395 Bocholt
Gigaset Communications GmbH is a trademark
licensee of Siemens AG
© Gigaset Communications GmbH 2008
All rights reserved. Subject to availability.
Rights of modification reserved.
www.gigaset.com
This user guide is made from 100% recycled paper.
Version: 30.10.2008
3
7
6
1
5
4
2

2
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
During message playback:
3 Delete current message.
4 Skip to previous message.
5 Adjust volume (ð= quieter; ñ= louder):
During message playback: adjust volume.
While an external call is being signalled: adjust
ringtone volume.
6 Playback/stop key:
Play back messages from the answering ma-
chine, or cancel playback.
7 Skip to next message.
Please note:
◆If the answering machine is being operated
from a handset or if it is recording a message, it
cannot be operated from the base station.
◆If the On/Off key flashes although the answer-
ing machine is switched off, it means that there
is still at least one new message that has not
been played back yet.
Safety precautions
Emergency numbers cannot be dialled if the key lock
(page 1) is activated!
Not all of the functions described in this user guide are
available in all countries.
Setting up the telephone for use
Step 1: Connecting the base station
First connect the mains unit (230 V) to power
cord 1and then connect the phone jack to phone
cord 2, as shown above. Place the cords in the cord
recesses. The two cords must be plugged in at all
times.
◆Only use the mains unit supplied.
◆If you ever purchase another phone cord from
a store, ensure that the phone conductors are
correctly connected: 3-4 connection of the tele-
phone conductors/EURO CTR37.
WRead the user guide and the safety precautions
carefully before use. Explain their contents to your
children, and the potential hazards associated
with using the telephone.
Only use the mains unit supplied.
Fit only the approved rechargeable battery
pack! Never use a conventional (non-recharge-
able) battery pack as this could damage your
health and cause injury. Use the battery pack as
directed in this user guide (page 3).
The operation of medical appliances may be
affected. Be aware of the technical conditions
within the particular environment (e.g. doctor's
practice).
Do not hold the rear of the handset to your ear
when it is ringing or when the handsfree func-
tion is activated. This can cause severe, perma-
nent hearing damage.
The handset may cause an unpleasant hum-
ming noise in hearing aids.
Do not install the phone in a bathroom or
shower room. The handset and base station
are not splashproof.
Do not use the telephone in environments
subject to explosion hazard (e.g. auto paint
shops).
If you give your Gigaset to someone else,
make sure you also give them the user guide.
$
ƒ
All electrical and electronic equipment should
not be disposed of separately from general
household waste using the sites designated by
local authorities.
The appropriate disposal and separate collec-
tion of used equipment serve to prevent poten-
tial harm to the environment and to health.
They are a precondition for the re-use and recy-
cling of used electrical and electronic equip-
ment.
For further information on disposing of your
used equipment, please contact your local
authority, your refuse collection service or the
dealer you purchased the product from.
12
Base station without answering machine
12
Base station with answering machine

3
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Step 2: Setting up the handset
Fitting the battery pack
◆Insert the plug into the socket as shown in the
enlarged view.
◆Insert the battery pack.
◆Place the cords in the cord routing.
Closing the battery cover
Insert the cover into the top end of the battery
compartment and press down until it clicks into
place.
Opening the battery cover
Place your fingernail between the cover and the
housing and pull the cover upwards.
Step 3: Registering the handset to
the base station and charging the
battery pack
Precondition: The handset is not already regis-
tered to a base station.
Registering the handset to the Gigaset A160/A260/
A165/A265 base station occurs automatically.
Place the handset in the charging cradle of the
base station with its display facing forward. You
will hear a confirmation tone. Leave the handset in
the base station until it is registered.
Automatic registration can take up to 5 minutes.
While this is happening, Registering flashes in the
screen. The handset is assigned the lowest unas-
signed internal number (1–4). If several handsets
are registered to the base station, the internal
number is shown in the top left of the display after
registration, e.g. 2. If the internal numbers 1 to 4
have already been assigned (four handsets have
already been registered), handset number four is
de-registered and overwritten.
Charging the battery pack
To charge the battery pack, leave the handset
in the base station for approx. 13 hours for the
Gigaset A160/A260 or approx. 6 hours for the
Gigaset A165/A265. The battery pack is now fully
charged. The charge status of the battery pack is
correctly displayed only after uninterrupted charg-
ing/discharging. Therefore you should not
interrupt the charging procedure.
Charging is electronically controlled to prevent the
battery pack from overcharging. The battery pack
heats up during charging. This is normal and not
dangerous. After a time its charge capacity will
decrease for technical reasons.
You must set the date and time to ensure that the
times of calls are logged correctly (see Menu tree,
page 11).
Once the phone is registered and the time set, the
idle display looks as shown on page 1.
Note:
The display is protected by a plastic film.
Please remove the protective film!
◆Place the battery leads in the cable guides so
that the battery cover cannot catch on the leads
and damage them when it is closed.
◆Use only the rechargeable battery pack rec-
ommended by Gigaset Communications GmbH *
(page 9), i.e. never use a conventional (non-
rechargeable) battery pack as this may cause sig-
nificant damage to health and property. For
example, the outer casing of the battery pack
could be destroyed or the battery pack could
explode. The phone could also malfunction or be
damaged as a result of using batteries that are not
of the recommended type.
◆Only use the battery charger supplied.
◆Only place the handset in the charging cradle
that is intended for it.
* Gigaset Communications GmbH is a trademark
licensee of Siemens AG.

4
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Making calls
Making external calls and ending a call
External calls are calls using the public telephone
network.
~(Enter the phone number) ¢c.
The number is dialled. (Or you can first press and
hold c [dial tone] and then enter the number.)
During the call you can adjust the earpiece volume
using u.
End the call/cancel dialling:
Press the end call key a.
You can automatically insert a network provider
dialling code before any phone number
(see "Preselection" Menu tree, page 11).
Answering a call
An incoming call is indicated by ringing, by a flash-
ing handsfree key d(Gigaset A260/A265) and a
display on the screen.
You can answer the call by:
◆Pressing the talk key c.
◆Press the handsfree key d(Gigaset A260/
A265).
When Auto Answer is activated (see Menu tree,
page 11), simply remove the handset from the
base station/charging cradle.
Displaying the caller's phone number
When you get a call, the caller's phone number will
be displayed on your handset; or the caller's name
will be displayed if it is stored in the directory or if
CNIP has been requested.
Requirements:
1 You have asked your network provider for the
caller's phone number (CLIP) or name (CNIP) to
be displayed on your handset screen.
2 The caller has asked the network provider for
his phone number to be identified (CLI).
®appears in the display if you have not
requested Calling Line Identification, Withheld
appears if the caller has withheld CLI, and Unavail-
able if CLI has not been requested by the caller.
Handsfree talking
(only Gigaset A260/A265)
Once you have entered the phone number you can
immediately call in handsfree mode by pressing d
(the dkey lights up continuously). During a call
and when playing back the answering machine
(if available) you can switch between earpiece and
handsfree mode by pressing d. Set the handsfree
volume with u.
Operating the handset
Activating/deactivating the handset
Press and hold the end call key a.
If you place a deactivated handset in the base sta-
tion or charging cradle, it will automatically acti-
vate.
Using the directory and lists
Directory
To open the directory: press h(Gigaset A160/
A165) or v(Gigaset A260/A265).
You can save up to 40 phone numbers (max. 32
digits) with corresponding names (max. 14 charac-
ters).
Saving the first number in the directory
hor v¢New Entry? ¢OK
Saving a number in the directory
hor v¢MENU ¢New Entry ¢OK
Selecting a directory entry
Open the directory with hor v. You have the fol-
lowing options:
◆Use uto scroll to the entry until the required
name is selected.
◆Enter the first character of the name or scroll to
the entry with u, if required.
Dialling with the directory
v¢u(Select entry) ¢c
Using other functions
v¢v(Select entry) ¢MENU
Note:
You can assign a number from the directory to a
key for speed dial (page 5).
~Enter number and press OK.
~Enter name and press OK.
~Enter number and press OK.
~Enter name and press OK.

5
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
The following functions can be selected with u:
Using speed dial keys
Press and hold the required speed dial key.
Sending the directory to another handset
Preconditions:
◆The sending and receiving handsets must both
be registered to the same base station.
◆The other handset and the base station can
send and receive directory entries.
v¢u(Select entry) ¢MENU ¢Send Entry /
Send List ¢OK ¢~(Enter the internal number
of the receiving handset) ¢OK
Last number redial list
This list contains the ten last dialled numbers.
Dialling from the last number redial list
Managing entries in the last number redial list
You can select the following functions:
Calls list/ answering machine (network
mailbox) list
When a new message arrives in the calls/answer-
ing machine list, an advisory tone sounds and the
display blinks. The display also shows a message.
When you press the fkey, all the lists are dis-
played. If only one list contains new messages, this
will be opened automatically.
Calls list
Precondition: CLIP (page 4)
The numbers of the last 20 missed calls are saved.
Multiple calls from the same number are only
saved once (the last call).
The calls list is displayed as follows:
Number of new entries + number of old, read entries
Opening the calls list
f¢CallsList 01+02 ¢OK
Select entry with u. The last incoming call is dis-
played in the calls list.
Using other functions
u(Select entry) ¢MENU
The following functions can be selected with u:
Show Number Display the phone number.
Use Number Edit or add to a saved number.
Then dial or use other functions
with MENU.
Edit Entry Edit selected entry.
Delete Entry Delete selected entry.
Send Entry Send a single entry to another
handset (page 5).
Delete List Delete all directory entries.
Send List Send the complete list to
another handset (page 5).
Shortcut For speed dial, assign the cur-
rent entry to a key.
cPress the key briefly.
uSelect entry.
cPress the talk key again. The number is
dialled.
cPress the key briefly.
uSelect entry.
MENU Press the display key.
Use Number (as in the directory, page 5)
Copy to Dir. Copy an entry to the directory
Delete Entry (as in the directory, page 5)
Delete List (as in the directory, page 5)
Note:
If calls are saved in the network mailbox, you will receive
a message if the appropriate settings have been made
(depending on your network provider).
Delete Entry Delete current entry.
Copy to Dir. Copy an entry to the directory.
Date/Time Call date and time (if set).
Status New Call: new missed call.
Old Call: entry already read.
Answ.: call taken.
Show Name If you have requested CNIP, you
can show the name and town
that are registered for your phone
number with your network pro-
vider.
Delete List Caution! All old and new entries
will be deleted.
CallsList 01+02

6
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Calling back a caller from the list
f¢CallsList 01+02 ¢OK ¢u(Select entry)
¢c
Additional functions for devices with
answering machines
Answering machine list
You can use the answering machine list to listen to
the messages that are on the answering machine.
The answering machine list is displayed as follows:
Number of new messages + number of old, played back
messages
Opening the answering machine list
f¢VoiceMail 01+02 ¢OK
The playback starts.
Using other functions
u(Select entry) ¢MENU
The following functions can be selected with u:
Automatic network provider code
(preselection)
See Menu tree, page 11.
Using the answering machine
(A165/A265)
The answering machine can be operated both via
the handset (see Menu tree, page 11) and via the
keys on your base station (page 1).
Activating/deactivating the answering machine
Icon ±appears in the display. The ökey lights up
on the base station.
The telephone is supplied with a pre-recorded
announcement. This pre-recorded announcement
is used if no personal announcement is available.
If the memory is full the answering machine
switches itself off automatically. It activates again
automatically when you delete old messages.
Recording your own announcement
See Menu tree, page 11.
You hear the ready tone (short tone). Now speak
your announcement (at least 3 sec.). Press OK to
confirm or press aor ”to reject your recording.
After recording, the announcement is played back
for you to check.
Please note:
Recording ends automatically when the max.
recording time of 170 seconds is reached or if
there is a break in speaking of more than
2seconds.
Playing back or deleting announcements
See Menu tree, page 11.
Playing/deleting messages
Playback begins with the first new message.
Playing back old messages
See answering machine list, page 6.
Stopping and controlling playback
During message playback:
Reading CNIP information of a message
◆Please read page 5.
Continue Resume paused playback
(see page 6).
Volume Set the volume.
Copy to Dir. Copy an entry to the directory.
Show Name If you have requested CNIP,
you can show the name and
town that are registered for your
phone number with your net-
work provider.
Delete all old Delete all old messages.
VoiceMail 01+02
2Stop playback: Press 2again to resume
tGo to the start of the current message.
2 x tTo the previous message.
vTo the next message.
2 x vTo the next message but one.

7
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Deleting an individual message
While playback is paused, press the ˜display key.
Deleting all old messages
During playback or pause:
MENU ¢Delete all old ¢OK (Confirm the secu-
rity prompt)
Picking up a call from the answering machine
You can still answer a call while the answering
machine is recording it by pressing cor d
(handsfree). Recording stops and you can speak to
the caller.
Activating/deactivating listening in
During the recording of a message you can listen in
via the base station loudspeaker and the registered
handsets (only Gigaset A265), see Menu tree,
page 11.
Setting up the answering machine
The answering machine has already been preset at
the
factory. Make individual settings using the
handset.
Setting call acceptance
You can set when you want the answering
machine to accept a call.
MENU ¢Voice Mail ¢OK ¢Ring Delay
¢OK ¢Select Immediately / 10 sec / 20 sec /
30 sec / Auto ¢OK (‰=on)
Setting the recording time
See Menu tree, page 11.
Setting a different language
You can change the language used for voice
prompts and the pre-recorded announcement.
MENU ¢3392(starts the procedure).
Select the language: 1(English), 2(French),
3(Arab), 4(beep). Press OK to confirm.
In the "beep" setting, certain answering machine
phrases are replaced by tones. The remaining
phrases and the pre-recorded announcements are
played back in English.
Assigning key 1 for speed dial to the
answering machine (network mailbox)
Simply press and hold key 1on the handset and
you will be connected directly to the answering
machine (network mailbox).
See Menu tree, page 11.
Registering corresponding
handsets
You can register up to four handsets on your base
station.
For automatic registration of handsets to
Gigaset A160/A260/A165/A265, see page 3.
Manual registration of handsets to A160/A260/
A165/A265
1. On the handset: MENU ¢Settings ¢OK
¢Handset ¢OK ¢Register HS ¢Enter the
system PIN of the base station (default is 0000)
¢OK.
Registering flashes in the display.
2. On the base station: within 60 sec. of entering
the system PIN, press and hold the registration/
paging key ÷or ù (page 1) (min. 1 sec.).
Registration can take up to 5 minutes.
Locating a handset ("Paging")
You can locate your handset using the base station.
◆Briefly press the registration/paging key ÷or
ùon the base station (page 1).
◆All handsets will ring at the same time ("pag-
ing"), even if the ringtones are switched off.
End paging: briefly press the register/paging key
÷or ù on the base station (page 1) or the talk
key con a handset.
Using several handsets
Making internal calls
Internal calls are no-cost calls to other handsets
that are registered to the same base.
Press the INT display key. All handsets are called.
When an internal participant answers you can
speak to them. To end the call, press a.
Internal consultation call/connecting
acall
You are in conversation with an external partici-
pant. Press the INT display key. All handsets are
called. The external participant hears the hold
music.
◆Before the internal participant has answered,
press the end call key a; the call is forwarded
to the participant who answers the call.
◆After the internal participant has answered,
you can talk to him. Press the end call key a;
the call is forwarded, or press the ”display key;
you are reconnected to the external participant.

8
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Listening in to an external call
You are conducting an external call. An internal
caller can listen in on this call and take part in the
conversation. All the participants are made aware
of the 'listening in' by a beep.
Precondition: The Listening in function must be
activated.
Activating/deactivating internal listening in
MENU ¢Settings ¢OK ¢Base ¢OK
¢Listening in ¢OK (‰=on)
Internal listening in
You want to listen in to an existing external call.
Press and hold the talk key c. You are linked into
the call. All participants hear a beep.
To end: press the end call key a. All participants
hear a beep.
If the first internal participant presses the end call
key a, the handset that has 'listened in' remains
connected to the external caller.
Handset settings
Change display language
MENU ¢Settings ¢OK ¢Handset ¢OK
¢Language ¢OK ¢Select the language
¢OK
The current language is indicated by ‰.
If you accidentally choose a language you do not
understand:
MENU ¢321(Press the keys one after the other)
Select the correct language with uand press OK.
Setting the alarm clock
Activating/deactivating the alarm clock
MENU ¢Alarm Clock ¢OK ¢Activation
¢OK (‰=on)
Or: Press the alarm clock key g.
When the alarm clock rings, press any key to switch
it off for 24 hours.
Setting the wake up time
MENU ¢Alarm Clock ¢OK ¢Wake-up time
¢OK
Enter the wake up time in hours and minutes, then
press OK.
Resetting the handset
You can reset any individual settings and changes
that you have made. Entries in the directory, the
calls list and the handset's registration on the base
station will be retained.
MENU ¢Settings ¢OK ¢Handset ¢OK
¢Reset Handset ¢OK
Cancel the reset with a.
Base station settings
The base station settings are carried out using a
registered handset.
For details on how to set the system PIN for the
base station, and for how to select the ringtone
volume and melody on devices with answering
machines, see Menu tree, page 11.
Restoring the base station to the factory
settings
When the settings are restored all handsets are de-
registered. The individual settings are reset. Only
the date and time are retained.
MENU ¢Settings ¢OK ¢Base ¢OK
¢Base Reset ¢OK
If you have forgotten your system PIN you can reset
the base station to the original code 0000:
Disconnect the power cord from the base station.
Hold down the registration/paging key ÷ or ù
(page 1) on the base station while reconnecting
the power cable to the base station at the same
time. If your device has an answering machine you
will also hear a beep. The base station has now
been reset and the system PIN 0000 set.

9
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Operating the base station on the PABX
The following settings are only necessary when
your PABX requires them, see the PABX user guide.
Changing the dialling mode
MENU ¢33911 ¢The number for the set
dialling mode flashes: 0= Touch tone dialling
(DTMF); 1= Dial pulsing (DP) ¢Enter number
¢OK.
Setting the flashing time
MENU ¢IIO12¢The number for the cur-
rent flashing time flashes: 0=80ms;1= 100 ms;
2=120ms;3= 400 ms; 4= 250 ms; 5= 300 ms;
6= 600 ms; 7= 800 ms ¢Enter number ¢OK.
Changing pause after line seizure
You can set the length of the pause inserted
between pressing the talk key cand sending the
phone number.
MENU ¢IIO1O¢The number for the current
pause length flashes: 1= 1 sec.; 2= 3 sec.; 3= 7 sec.
¢Enter number ¢OK.
Changing the pause after the recall key
MENU ¢IIO14¢The number for the current
pause length flashes: 1= 800 ms; 2= 1600 ms;
3= 3200 ms ¢Enter number ¢OK.
Appendix
Entering special characters
Standard characters
Specifications
Recommended battery pack
(Valid at the time of going to press)
Nickel-metal-hydride (NiMH):
Handset A16: V30145-K1310-X383
Handset A26: V30145-K1310-X359, X402
The handset is supplied with the recommended
battery pack.
Base station power consumption
In standby mode: approx. 2W
During a call: approx. 3W
General specifications
1x 2x 3x 4x 5x 6x
1Space 1 £ $ ¥ ¤
Q.,?!0+
P* / ( ) < =
#Abc-->
123
123-->
abc #@ \ &
DECT standard is supported
GAP standard is supported
Range up to 300 m outdoors,
up to 50 m in buildings
Base station power supply 230 V ~/50 Hz
Environmental conditions
in operation
+5 °C to +45 °C;
20% to 75% humidity

10
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Care
Wipe the base station, charging cradle and handset
with a damp cloth (do not use solvent) or an anti-
static cloth.
Never use a dry cloth. This can cause static.
Contact with liquid
If the handset has come into contact with liquid:
1. Switch off the handset and remove the bat-
tery pack immediately.
2. Allow the liquid to drain from the handset.
3. Pat all parts dry, then place the handset with
the battery compartment open and the keypad
facing down in a dry, warm place for at least
72 hours (not in a microwave, oven etc.).
4. Do not switch on the handset again until it is
completely dry.
When it has fully dried out, you will normally be
able to use it again.
Questions and answers
If you have any queries about the use of
your phone, you can contact us any time at
www.gigaset.com/customercare.
The table below contains a list of common
problems and possible solutions.
Service (Customer Care)
We offer you support that is fast and tailored to
your specific needs!
Our Online Support on the Internet can be reached
any time from anywhere.
www.gigaset.com/customercare
It provides you with 24/7 support for all our prod-
ucts. It also provides a list of FAQs and answers plus
user guides and current software updates (if avail-
able for the product) for you to download.
You will also find frequently asked questions and
answers in the appendix of this user guide.
For fast and dependable assistance with any
repairs or guarantee/warranty claims, contact our
Service Centre.
NewPan Tel. [phone]
Please have your proof of purchase ready when
calling.
Replacement or repair services are not offered in
countries where our product is not sold by author-
ised dealers.
Authorisation
This device is intended for connection to analogue
networks outside the EEA (with the exception of
Switzerland) depending on national type approval.
Country-specific requirements have been taken
into consideration.
We, Gigaset Communications GmbH, declare that
this device meets the essential requirements and
other relevant regulations laid down in Directive
1999/5/EC.
A copy of the declaration of conformity is available
at this Internet address:
www.gigaset.com/docs.
Problem Cause Solution
Nothing
appears in the
display.
The handset is not
switched on.
Battery pack is
flat.
Press the end call key
afor approx. 5 sec.
or place the handset
in the base station.
Charge/replace the
battery pack (page 3).
No reaction to
keystroke.
The key lock is
activated.
Press the hash key R
for approx. 2 sec.
(page 1).
No wireless
connection to
the base sta-
tion, Base
flashes in the
display.
The handset is
outside the range
of the base sta-
tion.
The handset is not
registered.
The base station is
not switched on.
Cords not routed
correctly
Move the handset
closer to the base
station.
Register the handset
(page 3).
Check the power
connector at the base
station (page 2).
Check cord routing
(page 2).
!

11
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
Menu tree
Your phone has an extensive range of features.
These are offered in the form of menus.
With the phone in the idle status, press MENU
(open menu), scroll to the required function and
then press OK to confirm your choice.
To return to idle status: press and hold key a.
There are two ways in which you can access a func-
tion:
◆Scroll with keys tand v,
◆Key in the appropriate digit combination,
e.g. MENU I1to set the date and time.
1 Alarm Clock
1-1 Activation Activating/deactivating the alarm clock
1-2 Wake-up time Input format: HHMM
2 Audio Settings
2-1 Ringer Volume 5 levels + "Crescendo" selectable
2-2 Ringer Melody 2-2-1 External Calls 10 ringtones, selectable for external calls
2-2-2 Internal Calls 10 ringtones, selectable for internal calls
2-2-3 Alarm Clock 10 ringtones, selectable for alarm clock
2-3 Advis. Tones Activating/deactivating
2-4 Battery Low 2-4-1 Off Tone when battery pack is
almost flat:
never
2-4-2 On always
2-4-3 During Call only during a call
3Settings
3-1 Date/Time Enter date (DDMMYY format), then time (HHMM format)
3-2 Handset 3-2-1 Language Set the display language
3-2-2 Auto Answer Activate/deactivate auto answer
3-2-3 Register HS Manually register the handset
3-2-4 Reset Handset Reset the handset
3-3 Base 3-3-1 Audio Settings (only
Gigaset A165/A265)
3-3-1-1 Ringer Volume 5 level settings + "Crescendo"
+OFF
3-3-1-2 Ringer Melody 10 selectable melodies
3-3-2 System PIN Change system PIN (default is 0000)
3-3-3 Base Reset Restore factory settings (system PIN does not change; handsets
are de-registered)
3-3-4 Listening in Activate/deactivate the function
3-3-5 Preselection 3-3-5-1 Presel. Number Network provider dialling code,
should be inserted automati-
cally before the dialled phone
number.
3-3-5-2 With Preselect First digits of the dialling codes,
should be dialled with preselec-
tion.
3-3-5-3 Without Presel First digits of dialling codes,
should be dialled without
preselection.

12
Athen / Israel - EN / A31008-M1801-B501-1-UV19 / Athen_Kombi_iw_en_neu.fm / 28.10.2008
4 Voice Mail
4-1 Set Key 1
(all devices)
4-1-1 Netw. Mailbx Assign key 1with answering machine or network mailbox (in idle
status, press and hold to dial).
Netw. Mailbx: your network provider's answering machine;
must be requested separately. The network mailbox can be dis-
played if your network provider supports this function and if key
1has been assigned with the network mailbox.
4-1-2 Answer Mach.
4-2 Answer Mach.
4-3 Listening in 4-3-1 Handset
4-3-2 Base
4-4 Announcements 4-4-1 Rec announce
4-4-2 Play announce
4-4-3 Del announce
4-5 Message Length 4-5-1 Maximum
4-5-2 30 sec
4-5-3 60 sec
4-5-4 120 sec
4-6 Ring Delay 4-6-1 Immediately
4-6-2 10 sec
4-6-3 20 sec
4-6-4 30 sec
4-6-5 Auto If no new messages are present, the answering machine accepts
a call after 20 seconds. If new messages are present, the answer-
ing machine accepts a call after just 10 seconds.
