GigaTera EFL Series User manual

!
1
EFL
User Guide
LED Bay Lighting
Document Revision – V1.7_E
⏏EFL 100W
!
Safety precautions
1. Electrical work must be performed by a qualified licensed electrician.
2. Disconnect or turn off power before installation or servicing.
3. Do not take apart or modify the product.
4. Do not drop the product or apply a strong impact to it.
5. The manufacturer or the seller do not bear liability for damage caused by inappropriate use or application.
6. Contact the manufacturer or the seller for inquiry when there is a problem with the product.

For luminaires with type Y attachments, the mounting instructions shall contain the substance of the following information
for type Y attachments
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or his service agent
or a similar qualified person in order to avoid a hazard

!
2
!
User Guide
EFL
LED Bay Lighting
KMW INC.
183-6, Yeongcheon-ro, Dongtan-myeon, Hwaseong-si, Gyeonggi-do, South Korea
Tel : [phone] / E-Mail : [email protected] / Homepage : www.gigateraled.com
!
Product Dimension
mm (inch)
Model Name
EFL070
EFL100
Size (D x H)
9.6 x 9.8 (inch)
244 x 249 (mm)
12.4 x 10.8 (inch)
316 x 273 (mm)
Weight (Driver included)
8.2 lb
3.7 Kg
10.8 lb
4.9 Kg
!
AC Power Cable

!
!

!
3
!
User Guide
EFL
LED Bay Lighting
KMW INC.
183-6, Yeongcheon-ro, Hwaseong-si, Gyeonggi-do, South Korea
Tel : [phone] / E-Mail : [email protected] / Homepage : www.gigateraled.com
!
Ceiling Bracket Dimension
mm (inch)

Installation Instruction
1

Install ceiling bracket & chain.

!
4
!
User Guide
EFL
LED Bay Lighting
KMW INC.
183-6, Yeongcheon-ro, Hwaseong-si, Gyeonggi-do, South Korea
Tel : [phone] / E-Mail : [email protected] / Homepage : www.gigateraled.com
!
Installation Instruction
2

3

Connect the AC Cable to the main power supply. (Refer to “AC Power Cable”)
Copyright © 2014 KMW INC. All rights reserved. / www.kmw.co.kr
The information in this document is subject to change without notice. / Document Revision V 1.7 2015.04.27!
