27460 –DELUXE TROLLEY
27461 –DELUXE
TROLLEY W/DRAWER
(Product complies with Directive 2007/47 / EC MEDICAL DEVICES CLASS I)
USER MANUAL AND ASSEMBLY ISTRUCTIONS
INTRODUCTION
According to 2007/47/EC the Council Directive the trolley is a CLASS I MEDICAL DEVICE.
You should carefully read this manual before using this medicaldevice.
DESCRIPTION
This article is a high quality trolley made of light anodized aluminum alloy with removable shelves in stainless
steel. It is a medication trolley for hospital use.
27460
27461

Manuale d’uso / User manual
27460.61_DELUXE_ITA_ENG - 2 -
COMPONENTS:
- N.1
upper frame with drawer (27461)
or only frame with 2 trough holes
(27460).
- N.1
lower aluminum frame
- N. 2 / stainless
steel trays
- N. 2
alluminum short front legs
- N. 2
aluminum rear legs with curve for
assembly of the push handle.
N.1 aluminum tubular to be
inserted in the 2 angular to
assemble the push handle.
- N. 2
angular junction for push handle
- N. 4wheels ø 80
- N. 10 6x20 screws
Allen key for assembly

Manuale d’uso / User manual
27460.61_DELUXE_ITA_ENG - 3 -
DATI TECNICI / TECHNICAL DATA:
measurement
Cm 50,5x73x97,5 h
Vassoio / tray 41x61x2,5h
weight
9 kg
max capacity 30 kg (15 kg carico massimo per ripiano / max load each shelf)
ASSEMBLY INSTRUCTION
Prepare a sufficiently large shelf to work on.
Insert the short front legs into the blind holesof the upper drawer / tray frame.
. Insert the curved hind legs in the upper frame and fix withthe screws using appropriate key.
Inserire il telaio inferiore nelle gambe e fissarli tramite viti, facendo attenzione a posizionare i rivetti
visibili verso la ruota.

Manuale d’uso / User manual
27460.61_DELUXE_ITA_ENG - 4 -
Insert the lower frame into the legs and fix them with screws, taking care to position the visible rivets
towards the wheel.
Put the 4 wheels by pressing untili it clicks.
Fit the push handle by inserting the tubular into the 2 plastic corner joints and insert them into the
upper side of the curved legs.
Finally, place the trolley on the ground and place the trays into supporting frames.

Manuale d’uso / User manual
27460.61_DELUXE_ITA_ENG - 5 -
WARNINGS!
-Fasten the screws with the allen key supplied.
-Check the locking nuts are tightened.
-Observe the maximum flow rates indicated in the data sheets.
-Avoid direct contact with open wounds.
-Not for use in open environments.
MAINTENANCE AND CLEANING
-Use only original spare parts.
-Periodically check all fixing points.
-To preserve at best, it is recommended to avoid prolonged exposure to sunlight, to contact and
deposit in saline and very humid environments.
-Extract the trays before cleaning.
-Wash the stainless steel surfaces with soapy water and use appropriate disinfectants.
-Rinse with a damp cloth and dry thoroughly.
-Do not spill on the surface cleaners containing chlorine or ammonia, fatty and oily substances.
-Do not use cleaning utensils containing iron. If necessary disinfection only use suitable non-corrosive
products.
WARRANTY
-The product is guaranteed for ONE YEAR for defects in materials and workmanship, excluding
consumables.
-Tampering or damage caused by improper use of the product implies the immediate loss of
guarantee.
-This medical device was created exclusively for the above-mentioned methods. Any other use is to
be considered improper.
-We can not be held liable for damages to persons or things due to improper use of the garrison.
IT - Conservare in luogo fresco ed asciutto.
GB - Keep in a cool, dry place.
IT - Prodotto conforme alla Direttiva Europea
GB - Product complies with European Directive
IT - Leggere e seguire attentamente le istruzioni per l’uso
GB - Read instructions carefully
IT - Fabbricante
GB - Manufacturer
IT -
Conservare al riparo dalla luce solare
GB - Keep away from sunlight -
IT - Leggere attentamente le istruzioni per l’uso
GB - Please read instructions carefully
IT - Codice prodotto
GB - Product code
IT - Numero di lotto (vedi scatola / bustina)
GB - Lot number (see box / package)
