GIT G-scan3 G3 User manual

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
G-scan3
TROUBLE SHOOTING GUIDE

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
Index
2
Chapter 1. Power Supply Problems
Chapter 2. Rechargeable Battery Problems
Chapter 3. Communication Problems
Chapter 4. LCD Problems
Chapter 5. G-Scan3 System Lock
Chapter 6. Keypad Problems
Chapter 7. Wireless function related Problems
Chapter 8 Camera & Flash Problems
Chapter 9 LAN & HDMI problems
Chapter 10 AUDIO problems
3 - 9
10-15
16-22
23-31
32-37
38-41
42-45
46-52
53-55
56-59

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
Chapter 1. Power Supply
Power Supply Problems
3

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
4
Check power supply from the
vehicle battery
Vehicle
battery
voltage
9~30V?
Check Firm connection
of the DLC cable.
Is G-scan3
charging
normally?
Check power
supply voltage.
G-scan3 is unable to
receive the power
Is voltage
reading
12V?
Replace or charge
the vehicle battery
G-scan3 is not defective,
make sure the firm connection of
the main DLC cable.
Check power supply through
the external
power source.
Is G-scan3
charging
normally?
Power could
come on after
replacing the
DLC cable
Mitsubi
shi 12P
or
Kia 6P
used?
Checked by the customer
Checked by the distributor
Normal.
No power is
supplied through
these adapters.
Does LED
normally
turn on?
Replace main
board
Check
rechargeable
battery (Chapter2)
G-scan3 base unit is
not defective.
Replace defective
power supply.
Replace the LCD
module (front
case)
No
Yes
Yes
Yes
Yes
No
No
No
No
No
Yes
Yes
1
2
3
4
5
Power Supply Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
①Check the power supply from the vehicle battery
Using a multi-meter, please check condition of the vehicle battery first. Recharge or replace
the battery as necessary.
5
Please check for power supply from the vehicle side Data Link Connector (mostly located under
left side of the dash.) Turn the Ignition ON and check for voltage at Pin #4 or #5 (Ground) and
#16 (Battery positive) by using the multi-meter.
If power supply from the vehicle battery seems flawless, go to step 2 to continue diagnosis.
*Note: Some vehicles do not provide power through the DLC. G-scan3 may require an external power supply other than
just the main DLC cable, G-Scan3 can receive power by additionally connecting the Cigar Lighter cable.
Power Supply Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
②Check power supply through the main DLC cable
Please connect the main DLC cable and check for firm connections.
Check if the LED illuminates RED color on the top right corner.
If G-scan3 is still unable to receive power, please go to step 2.
6
Power Supply Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
③Check power supply through the external power source
Check to see if power comes on by connecting the external power source such as AC/DC
power adapter and Cigar Lighter cable.
If power comes on after connecting the external power source, the main DLC cable is
suspected to be defective. Please replace the main DLC cable.
If power does not come on after connecting the external power source, please go to step 4.
7
Power Supply Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
④Check the Power Supply Voltage
If Cigar Lighter cable, and AC/DC adapter’s voltage falls within 9 ~30V range,
proceed to the step 5.
If Cigar Lighter cable, and AC/DC Adapter’s voltage does not fall between 9 ~30V range,
external power source is defective.
Please replace the AC/DC adapter, or Cigar Lighter cable as necessary.
→ If Cigar Lighter cable, and AC/DC Adapter’s voltage is normal, go back to step 2. Rechargeable
battery.
8
Please check the power supply (through the Cigar Lighter cable or AC/DC power adapter)
voltage using the multi-meter.
Power Supply Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
⑤Check the LED Illumination
G-scan3 has 2 color LEDs
When the system charges normally, the LED illuminates Red,
And when it is fully charged the LED illuminates Green.
If power supply from the AC/DC adapter is normal but G-scan3 cannot be turned on, go to chapter 2.
If charging circuit is abnormal, G-scan3 will not be turned on and its LED indicator will not be
illuminated although external power supply is connected.
9
*Note: After following the trouble shooting guide and power supply problem still exists, please contact our
Head Quarter in South Korea for further assistance.
Power Supply Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
Rechargeable Battery
Chapter 2. Rechargeable Battery
10

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
11
Recharge the battery and
check the condition
(Battery Graph)
Is there a
sudden
voltage drop?
Remove the battery pack
cover and Check the battery
voltage (without disconnect)
Is the battery
charge voltage
3.7V ~ 4.2V?
G-scan3 has a charging
problem
Yes
Yes
No
Normal.
Battery was temporarily
discharge
No
Replace the battery packReplace the main board
Checked by the customer
Checked by the distributor
1
2
3
Rechargeable Battery

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
①Recharge the battery and check the battery condition
Disconnect the AC/DC power adapter and go to Settings and Battery. Observe any
abnormality in percentage drop in the graph.
If any abnormality is detected during observation, go to step 2.
12
Connect AC/DC Power adapter and fully charge the battery.
Then, go to Settings and Display. Adjust Brightness level to its maximum level.
Rechargeable Battery

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
Remove the battery cover case.
Using the multi-meter, please check the voltage of the rechargeable battery without disconnecting
the battery connector.
13
Remove 2 screws
②Check the battery charging circuit voltage
Rechargeable Battery

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
③Check the battery charging circuit voltage
*When measuring the charging voltage, keep the battery connected.
If Main board does not detect battery, recharging circuit is not enabled and thus, powering on and
charging the battery is not available.
Using the Multi-meter, check the voltage of the battery charging circuit at the terminal shown
above. Measure cell voltage at each same numbered pin for positive and GND
Normally average voltage should be around 3.7~ 4.2 V
The charging voltage can be as low as 3.7V when the battery is fully discharged.
14
If the charging voltage is lower than 3.7V, replace the Main Board.
If the battery cannot be charged, go to Step 3.
1 2 3 12
3
Battery temp sensor
Rechargeable Battery

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
Communication Problems
Chapter 3. Communication Problems
15

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
Checked by the customer Checked by the distributor
16
Check the main DLC cable
and adapter connection.
Is
communication
OK?
Replace the VCI
Attach the self-test adapter
to the end of the main DLC
cable & supply AC/DC power
and execute hardware
self-test function from
configuration menu.
STEP A Error
found?
Press Fix in the
menu and
download the
software again.
Execute Software self-test
function from configuration
menu
Communication error
STEP B Error
Found?
Replace the main
DLC Cable
Found error
during Quick
/Detail self-
test?
Log capture
EZDS
Checks:
software
problem?
Software problem.
Send the patch &
retry diagnosis.
Yes
No
No
No
Yes
Yes
Yes
Make firm
connections
for proper
communication
No
1
2
3
4
5
Communication Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
①Check the DLC & Adapter Cable connection
Check if all the adapters and cables are firmly connected.
1. Check if the correct diagnostic adapter is connected.
Do not use the Self-Test adapter for vehicle communication.
2. Extend the diagnostic adapter to the vehicle-side adapter and make firm connection.
If the communication still fails, attach the Self-Test adapter to the end of the main DLC cable
and execute the Self-Test function described in step 2.
17
Communication Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
②Self-Test <Step A>
Through this Step A test procedure, G-Scan3 tests the internal circuits used for the communication
protocols such as ISO9141, ISO9141-2, KWP2000, Melco (Old Mitsubishi).
Circuits for CAN-Bus, J1850 (American cars in general) and some specific communication protocols
are not tested, therefore passing this test without error should not be interpreted as representing that
G-Scan3 is not defective.
If the result is “No Error found”, proceed to the Step B test procedure described in step 3.
If the result is “Error Found”, replace the VCI Board.
When VCI module is replaced, the new serial number contained in the new VCI module is copied to the
main board automatically.
*Register the new serial number to SMS server and put the new serial number sticker to the base unit.
18
1. Connect the DLC main cable to the Diagnosis Scanner main body and connect the
self test adapter with the AC/DC power as show in the right screen.
2. Press the “Start” Button to perform the function.
3. After completing the self test, check the result values.
Communication Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
③Self-Test <Step B>
Select “Step B” from the Self-Test menu.
1. Extend the Self-Test adapter attached to the end of the main DLC Cable to the vehicle-side
diagnostic socket.
2. Select Step B and click “Start” in the bottom.
3. Check the result.
With Step B test, each communication wire of the main DLC cable is tested to verify if there is any
short or open circuit inside the cable.
If the result is “No Error Found”, proceed to the step 4.
If the result is “Error Found”, replace the Main DLC Cable.
19
Communication Problems

This GIT-EZDS Aftermarket Distributorship Manual contains important information on the sensitive business practice and confidential business facts and figures that must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violationof such prohibitionwill entitle GIT or EZDS to terminatethe distributorship contract.
TROUBLE SHOOTING GUIDE
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
Feb 19th, 2019
FIRST EDITION
20
④Software Self Test
Unlike predecessors, two types of software self test is available in G-scan3.
•Quick self- test checks main software to find any corrupted data.
•Detail self-test checks all software including main software to find any corrupted data.
1. Select Quick or Detail button.
2. Press Start button to begin the test.
3. If NG is displayed, press red colored Fix button.
4. Pressing Fix button will move to software update menu.
5. The software that contains corrupted data is automatically selected.
6. Begin software update.
7. Perform software self test again to see if the problem persists.
If communication is OK after software update, it was the software causing communication
problem.
If the communication problem persists, go to step 5.
Quick Self-Test Detail Self-Test
Communication Problems
