G-scan3
PART REPLACEMENT MANUAL

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Preparation
Chapter 1. Preparation
PR1-1

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Preparation
A.
Screw Driver (medium: +)
B. Automotive Trim Removal Tool (
small)
C
. Tweezer
* Additional
Recommended Tools
A. Anti
-static gloves
B. Power supply (12V 3A
or more)
C. Warranty void seals
PR1-2
A B C
1. Tools and Equipment

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
Chapter 2. Disassembling the Front Case
PR2-1

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
PR2-3
2. Case Opening
2.1. Remove the Stylus Pen
1
2

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
PR2-4
2. Case Opening
1.2. Unscrew the 2 screws from battery cover
1 2

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
PR2-5
2. Case Opening
2.3. Disconnect the connector inside and remove the battery
1 2

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
PR2-6
2. Case Opening
2.4. Remove the “warranty void seal” ** Warranty void if the seal is broken
Warranty Void Seal
1

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
PR2-7
2. Case Opening
2.5. Unscrew the 4 screws (M3*10)
1
3
2
4
1

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
PR2-8
2. Case Opening
2.6. Use “trim removal tool” to gently open up each corner of the case
1
* Too much tension on
prying action may
damage the LCD while
disassembling the
front case.

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
PR2-9
2. Case Opening
2.7. Widen up the top and bottom, and remove all the FPCB cables from LCD and Touch Panel.
1
** An individual LCD module itself cannot be replaced. Only the front case assembled with LCD shall be replaced at one go.
BOTTOM
TOP FPCB Cables
1
2
LCD F-PCB
Touch F-PCB

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
Chapter 3. LCD Replacement
PR3-1

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
PR3-2
3. LCD Replacement
3-1. Put the new LCD in place following the reversed procedure.
3-2. When connecting the F-PCB cables, make sure the wires must be aligned on the line
Locking Bar
Locking Bar
Kapton Tape
* Kapton tape should be re-
attached after replacing the
LCD
* Make sure not to bend the
LCD F-PCB cable
* Power on and see if the
LCD is working correctly.
F-PCB
wires must
be aligned
on the line

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
Chapter 4. Disassembling the VCI & Main Board
PR4-1

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
4. Disassembling the VCI Board
4.1. Unscrew the 7 screws
4.2. Detach the F-PCB cable and 6P connector to remove the VCI board
** VCI board must be replaced in case the “tackle buttons” doesn’t work.
Repair Procedure Disassemble
PR4-2
VCI Board
VCI
Board MAIN
Board
tackle buttons
Main DLC connector
24 pin connector
6 pin connector

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
4. Disassembling the Main Board
4.3. Remove all the connectors on main board
4.4. Unscrew the 6 screws and detach the board
Repair Procedure Disassemble
PR4-3
MIC
Antenna
Camera
Flash
Speaker
LAN & HDMI connectors
Micro 5 Pin USB,
Micro SD card slot,
USB slot, Earphone

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Disassemble
Chapter 5. Disassembling small parts
PR5-1

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
5. Disassembling small parts
5.1. Entirely remove the double-sided tape
around MIC,Antenna, Speaker before detaching the parts
Repair Procedure Disassemble
PR5-2
MIC
Antenna
Speaker

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
5. Disassembling small parts
5.2. Remove the Flash Module first,
when replacing the new camera.
* F-PCB cable must not have any cracks
5.3. Remove the VCI board first,
when replacing the new keypad.
* Tighten the new keypad to holes correctly
Repair Procedure Disassemble
PR5-2
Camera
Flash
Keypad

Feb 20th, 2019 FIRST EDITION GIT-EZDS Aftermarket Distributorship Manual
GIT-EZDSAftermarket Distributorship Manual
GIT-EZDS
This GIT-EZDS Aftermarket Distributorship Manual contains important informationon the sensitive business practice and confidential business facts and figuresthat must be kept confidential and protected from the third party’s unauthorized approach. Duplication, photo copy, reproduction or translation to the other language is strictly prohibited without GIT and EZDS’ prior written consent, and any violation of such prohibition will entitle GIT or EZDS to terminate the distributorship contract.
ADM-SVC:2.01
Repair Procedure Assemble
Chapter 6. Assembling
PR6-1
