Glacier bay Sidemere 30609 User manual

ASSEMBLY INSTRUCTIONS
30 IN. SIDEMERE WALL HUNG
Item # 1005787576, 1005787584
Model # 30609, 30612
Questions, problems, missing parts?
Before returning to the store, call Glacier Bay Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1- 855- HD GLACIER (1-855-434-5224)
HOMEDEPOT.COM/GLACIERBAY
THANK YOU
We appreciate the trust and condence you have placed in Glacier Bay through the purchase of this vanity. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Glacier Bay!

2
Table of Contents
Warranty
LIMITED LIFETIME WARRANTY
WHAT IS COVERED
Glacier Bay products are manufactured with superior quality standards and workmanship and are backed by our limited lifetime warranty.
Glacier Bay products are warranted to the original consumer purchaser to be free of defects in materials or workmanship. We will replace
FREE OF CHARGE any product or parts that proves defective. Simply, return the product / part to any of The Home Depot retail locations
or call 1-855-HD Glacier (1-855-434-5224) to receive the replacement item. Proof of purchase (original sales receipt) from the original
consumer purchaser must be made available for all Glacier Bay warranty claims.
WHAT IS NOT COVERED
This warranty excludes incidental/inconsequential damages and failures due to misuse, abuse or normal wear and tear. This warranty
excludes all industrial, commercial & business usage, whose purchasers are hereby, extended a limited lifetime warranty from the date
of purchase, with all other terms of this warranty applying except the duration of warranty. Some states and provinces do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you. This warranty gives you
specic legal rights and you may also have other rights that vary from state to state and province to province. Please see a store or contact
1-855-HDGlacier for more details.
Table of Contents ...................................2
Safety Information ..................................2
Warranty ..........................................2
LIMITED LIFETIME WARRANTY .......................2
What is Covered ..................................2
What is Not Covered ...............................2
California and Minnesota Residents ....................3
California residents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Minnesota residents ...............................3
Pre-assembly ......................................3
Planning Assembly ................................3
Tools Required ...................................3
Hardware Required................................3
Points to Installer ...................................4
Pre-assembly (continued) ............................5
Package Contents.................................5
Installation ........................................6
Drawer adjustment.................................11
Maintenance ......................................11
Care and Cleaning .................................11
Troubleshooting ...................................12
Safety Information
WARNING CAUTION
□Two people are required for safe installation. Take extra
precautionary measures to ensure a secure grip on the vanity
base and vanity top when lifting.
□Read these instructions carefully and keep in a safe place.
□Do not over tighten connectors (screws, bolts, etc.)
Overtightening can lead to product damage.
□Assembly needs to be carried out by a qualied person.
Wrong assembly can lead to the furniture / object topples or
falls resulting in personal injury or damage.
□Screws or ttings are not included. Choose screws and
ttings that suits your wall and have sufcient holding power.
If you are uncertain, contact your local specialized retailer.
□The bathroom wall must be nished prior to installation of
the vanity base and top.
□Do not use water that exceeds temperatures of 140°F/46°C.
□Do not place any sharp or abrasive objects on the bare
surface of the vanity top.
□Be sure to check all packing materials carefully for small
parts that may have come loose inside the carton during
shipment. If parts are missing, contact THE HOME DEPOT to
obtain any missing parts.

3HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
California and Minnesota Residents
CALIFORNIA RESIDENTS
WARNING THIS PRODUCT CAN EXPOSE YOU TO STYRENE / WOOD DUST WHICH IS KNOWN TO THE
STATE OF CALIFORNIA TO CAUSE CANCER. GO TO WWW.P65WARNINGS.CA.GOV/PRODUCTS
Pre-assembly
PLANNING ASSEMBLY
To ensure your installation goes smoothly, please read these instructions carefully and review the recommended tools and hardware
before you begin.
To remove the old vanity (if applicable): 1) Turn off the water supply and drain out. 2) Disconnect the supply lines from the faucet.
3) Remove the old vanity top and vanity. If the new vanity is not installed immediately, temporarily stuff a rag into the drain pipes.
Using a level, locate any uneven wall areas where your vanity will be installed. Unevenness can cause your vanity to become misaligned
resulting in twisting of the cabinet. Repair any uneven areas.
TOOLS REQUIRED
MINNESOTA RESIDENTS
“IMPORTANT HEALTH NOTICE.
SOME OF THE BUILDING MATERIALS USED IN THIS HOME (OR THESE BUILDING MATERIALS) EMIT FORMALDEHYDE. EYE, NOSE, AND THROAT
IRRITATION, HEADACHE, NAUSEA AND A VARIETY OF ASTHMA-LIKE SYMPTOMS, INCLUDING SHORTNESS OF BREATH, HAVE BEEN REPORTED
AS A RESULT OF FORMALDEHYDE EXPOSURE. ELDERLY PERSONS AND YOUNG CHILDREN, AS WELL AS ANYONE WITH A HISTORY OF ASTHMA,
ALLERGIES, OR LUNG PROBLEMS, MAY BE AT GREATER RISK. RESEARCH IS CONTINUING ON THE POSSIBLE LONG-TERM EFFECTS OF
EXPOSURE TO FORMALDEHYDE.
REDUCED VENTILATION MAY ALLOW FORMALDEHYDE AND OTHER CONTAMINANTS TO ACCUMULATE IN THE INDOOR AIR. HIGH INDOOR
TEMPERATURES AND HUMIDITY RAISE FORMALDEHYDE LEVELS. WHEN A HOME IS TO BE LOCATED IN AREAS SUBJECT TO EXTREME
SUMMER TEMPERATURES, AN AIR-CONDITIONING SYSTEM CAN BE USED TO CONTROL INDOOR TEMPERATURE LEVELS. OTHER MEANS OF
CONTROLLED MECHANICAL VENTILATION CAN BE USED TO REDUCE LEVELS OF FORMALDEHYDE AND OTHER INDOOR AIR CONTAMINANTS.
IF YOU HAVE ANY QUESTIONS REGARDING THE HEALTH EFFECTS OF FORMALDEHYDE, CONSULT YOUR DOCTOR OR LOCAL HEALTH DEPARTMENT.”
Electric drill
with #2 drill bit
Measuring
tape
Safety
goggles Level
Wall anchors - if the
vanity will not be screwed
to wall studs
Phillips
screwdriver
Silicone
(optional)
HARDWARE REQUIRED
For wood wall
For brick wall
For dry wall

4
Points to Installer
X
Y
INSTALLATION TO BE PERFORMED BY QUALIFIED PROFESSIONAL ONLY.
Wall hung vanity cabinets require important wall preparation and installation. Please thoroughly read this notice and all other installation
instructions that might be included with the cabinetry.
Keep in mind
□Cabinets must be securely fastened with sufcient type, quantity and size of screws to wall studs and internal structural wall blocking.
□See below for examples and instructions for internal structural wall blocking necessary for proper installation
Internal wall blocking installation
□A horizontal row of wood 2 X 7 structural wall blocks are required and must be installed between wall studs at a height to match
where the top of the wall hung vanity cabinets will be installed. Carefully remove drywall in required locations to gain access to wall
studs. Use caution to not disturb any electrical or plumbing utilities found within the wall.
□Install a second row of 2 X 7 structural wall blocks to match the height of the cabinets to allow fastening near the bottom.
□The 2 X 7 structural wall blocks should be positioned between each wall stud where the cabinets will be located.
□Use wood screws installed at an angle to securely fasten the structural wall blocks to the wall studs.
WARNING
Serious or fatal injuries can occur should unit fail.
To prevent failure:
□Do not sit, stand, lean or climb on unit.
□Do not lay or sit beneath unit.
□Do not set heavy objects on the top of the unit, overload unit or overload drawers.
□Do not open more than one drawer at a time.
X - Required height for top of
the cabinet from the oor.
Y - Required distance to
match the cabinet height.

PACKAGE CONTENTS
5
A
B
C
Part Description Quantity
A Vanity base 1
B Vanity top 1
C Bumper 4
D Suspension rail 694mm (27-3/8in) 1
E Leg screw (required for leg option only) 16
Pre-assembly (continued)
D E
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

6
Installation
1 Preparing the wall
2 Marking the locations
□Determine the desired wall location for the cabinet.
□Determine desired height for top of cabinet and mark a
horizontal line on the wall using a pencil.
□Use a level to ensure the suspension rail markings will
be level before installing to the wall.
□Remove the drawers from the vanity by pushing the bracket lever underneath the drawer box (refer to below image) and disconnect
the drawer box from the slide.
□Measure the desired location of the vanity by placing into the wall and mark mounting hole guidelines on wall. Check alignment of
mounting hole guidelines against vanity base to ensure product is level.
CAUTION: Consult an expert for the proper screws / Bolts
to use when attaching the various constructions, 2” screws
(not included) mentioned here do not match to all wall type.
Anchors are not required if brackets are installed in stud.

3 Installing the suspension rail
□Place the suspension rail (D) against the wall and
determine the desired location.
□Insert the #8 x 2 in. screws (not included) through the
suspension rail (D) holes and screw them into the wall.
D
CAUTION: For wall stud installation, insert the screws with washers into the stud
locations (not included).
For drywall installation, drill holes at the appropriate locations and insert toggle bolts with
washers (not included).
For concrete wall installation, drill 1/4 in. holes at the appropriate locations and insert
wall anchors, followed by the screws (not included).
CAUTION: Different wall materials require different
types of xing hardware (not included). Use suitable
xing hardware for the walls in your home. For advice on
suitable xing systems, consult a local specialized retailer.
Installation (continued)
7
4 Hanging the vanity base
□Lift the vanity (A) above the suspension rail (D)
and place it against the wall.
□Slide the vanity (A) to the left or right to the
desired location.
□Hung the vanity (A) to the suspension rail (D)
properly by using wall suspension bracket.
□See diagram to the right for measurements and
hanging details.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
A
±15mm
±7mm
D

8
Installation (continued)
6 Attaching the vanity top
□Place the porcelain top (B) centered on the vanity base (A).
For additional stability, clear silicone may be used to secure
the porcelain top onto the vanity base.
□Connect the faucet and drain (not included) as per the
instruction sheets provided with those items and ensure
that there is no leakage.
□Please wipe clean excess silicone squeeze out after the
usage.
□After installing the vanity top please adjust the drawer
slides if required.
NOTE: For instructions on how to use the provided
bumpers (C), see the Troubleshooting section of this
document.
Silicone
5 Securing the vanity to the wall
A
B
□Place the vanity (A) in the desired position taking into account the location of your plumbing. Ensure the vanity (A) is level front to
back and at both sides.
□Secure the vanity (A) to the wall by inserting #8 x 2 in. screws (not included) through the back rail of the vanity.
□To install the drawers, open each drawer slide and place the drawer box on the slide and push forward to lock with the slide.
A

9HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
Installation – [Floor-standing unit]
Attaching the hairpin legs
1
Attaching the felt pad
2
□Install each hairpin leg matching each corner of the leg into each
corner of the vanity. Provide sufcient protection on the oor to
protect the vanity from damage.
□Tilt the vanity backwards and position the hairpin legs, aligned over
the pre-drilled holes (refer the image). Attach hairpin legs to the vanity
using the provided leg screws (E). Evenly position the screws with
vanity base pre-drilled holes.
□Ensure all the screws are tightened properly. With assistance, turn the
vanity upright to rest on its legs.
□Place the vanity base on the desired location and mark the felt pad location on the oor. Remove the vanity and stick the hairpin
leg felt pad to the oor. Place the vanity on the felt pad.
E
NOTE: Crawley hairpin legs not included with
this pack. Buy separately.

10
Installation (continued)
□Place the porcelain top (B) centered on the vanity base (A).
For additional stability, clear silicone may be used to secure
the porcelain top onto the vanity base.
□Connect the faucet and drain (not included) as per the
instruction sheets provided with those items and ensure
that there is no leakage.
□Please wipe clean excess silicone squeeze out after the
usage.
□After installing the vanity top please adjust the drawer
slides if required.
Attaching the vanity top
4
NOTE: For instructions on how to use the provided
bumpers (C), see the Troubleshooting section of this
document.
□Place the vanity (A) in the desired position taking into
account the location of your plumbing.
□Ensure the vanity (A) is level front to back and at both sides.
□Secure the vanity (A) to the wall by inserting two #8 x 2 in.
screws (not included) through the back rail of the vanity.
CAUTION: For wall stud installation, insert the screws with
washers into the stud locations (not included).
For drywall installation, drill holes at the appropriate
locations and insert toggle bolts with washers (not included).
For concrete wall installation, drill 1/4 in. holes at the
appropriate locations and insert wall anchors, followed by
the screws (not included).
Securing the vanity to the wall
3
A
Silicone
A
B

11 HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
Drawer Adjustment
Under mount slide Drawer box side Drawer box side
Drawer
bracket
Drawer box
bottom Drawer
bracket
Drawer
front
Drawer
front
Drawer
front
Removing the drawer:
Open the drawer as far as possible.
Push the bracket lever underneath the
drawer box and disconnect the drawer
box from the slide.
Drawer adjustment:
For drawer alignment move the drawer
up and down adjustable to the desired
position while moving left and right.
Re-installing the drawer:
To install the drawer, open each drawer
slide and place the drawer box on the
slide and push forward to lock with
the slide.
Maintenance
Care and Cleaning
□To maintain the beauty of the furniture nish, avoid placing the vanity in direct sunlight.
□Avoid exposing the vanity to extreme temperatures by installing away from heat and air vents.
□Dust frequently with a clean, soft and dry cloth.
□Wipe away any water or liquid spills on the vanity base immediately with a clean, soft and dry cloth.
□Clean the vanity top only with non-abrasive cleaners or mild detergents – do not use powder cleansers. For extremely stubborn
stains, use a small amount of acetone on a cloth and gently rub out the stain.

Problem Possible Cause Corrective Action
Vanity drawers rub against another surface. Wall is not level. □Adjust the drawer slides.
There is an uneven gap between the
drawers and cabinet.
Wall is not level. □Adjust the drawer slides.
Vanity top wobbles when placed on the
vanity base.
□The vanity base is not installed level
and plumb.
□The underside of the vanity top is
uneven. This can be a common
occurrence in porcelain tops due to
the manufacturing process.
1) Ensure the vanity base is level and plumb. It
may be necessary to use shims if the base
sits uneven (see Planning Assembly section).
2a) Identify which corners have the wobble.
2b) Carefully remove the vanity top and turn
it over.
2c) Apply the bumpers (C) adhesive side down
on the corners of the vanity top that you
identied in Step 2a.
2d) Carefully place the top back onto the
vanity base and make any necessary
adjustments to the bumper placement(s)
until the vanity top does not wobble.
Troubleshooting
C
C
12

Questions, problems, missing parts?
Before returning to the store, call Glacier Bay Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1- 855- HD GLACIER (1-855-434-5224)
HOMEDEPOT.COM/GLACIERBAY
Retain this manual for future use.
Revision-01-Dt: 05.03.2021
